Cheng Uei Precision Industry H681 Bluetooth handsfree Headset User Manual 9510a87o Front

Cheng Uei Precision Industry Co., Ltd. Bluetooth handsfree Headset 9510a87o Front

User manual

MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. The use of wireless devices and their
accessories may be prohibited or restricted in certain areas.
Always obey the laws and regulations on the use of these
products. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. All other
product or service names are the property of their respective
owners.
© Motorola, Inc. 2007.
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-877-MOTOBLU
1-888-390-6456 (TTY/TDD United States for
hearing impaired)
Guide Number: 6809510A87-O
motorola
Bluetooth®
Handsfree Headset
Get connected in 4 quick steps.
H680
Volume
Buttons
Microphone
Speaker
Power
Switch Call
Button
Indicator
Light
Indicator Light
(steadily blue
for pairing mode)
Charging
Contacts
(on reverse
side)
My headset will not enter pairing mode.
Make sure that any devices previously paired with
the headset are turned off. If the indicator light is
not steadily lit in blue, turn off both the other
device and headset, wait 10 seconds, then turn
headset back on. Wait for the indicator light to
become steadily lit in blue, indicating the headset
is now in pairing mode.
My phone doesn't find my headset.
Make sure the indicator light on your headset is
on (lit in blue) and steady when your phone is
searching for devices (see step 3).
My headset worked before but now it's not
working.
Make sure your phone is on and the Bluetooth
feature is turned on in your phone (see step 2). If
the Bluetooth feature was turned off or was
turned on only temporarily, you may need to
restart the Bluetooth feature (see step 2) and pair
your phone and headset again (see step 3).
Support.
If you need more help, contact us at
1-877-MOTOBLU or visit us at
www.hellomoto.com/Bluetoothsupport
TROUBLESHOOTING
Before using this product, read the Important Safety and Legal Information pamphlet and follow its instructions.
Take a moment before you get started to familiarize yourself with your new H680
Bluetooth Handsfree Headset. Along with your headset, a charger base is provided for
both charging and storage.
Charger
Port
BEFORE YOU BEGIN
12
START BLUETOOTH
FEATURE
Your Phone
Press (Menu) > Settings > Connection >
Bluetooth Link > Setup.
Scroll to Power.
Select Change.
Scroll to On.
Press Select to turn on the Bluetooth
feature. The Bluetooth feature remains on
until you turn the feature off.
Note: These steps are for most Motorola phones.
For other phones, see your phone's user's guide.
1
2
3
4
5
Your phone's Bluetooth feature is off by default.
To use your headset, you must turn on the
Bluetooth feature in your phone.
For most Motorola phones (at the main menu):
M
3
PAIR
Your Headset
Before you can use your headset, you must pair
(link) it with your phone.
Step A - ENSURE HEADSET IS IN PAIRING
MODE
Remove headset from charging base and
power on by sliding Power switch to the On
position (towards Power symbol on headset).
The indicator light flashes to initiate easy
pairing. After a few moments, the indicator
light will be steadily lit in blue to indicate
headset is in pairing mode.
If the headset does not enter pairing mode,
see TROUBLESHOOTING for help.
PAIR CONTINUED
Your Phone
Step B - SET YOUR PHONE TO LOOK FOR
YOUR HEADSET
3
4
5
1
2
For most Motorola phones:
On your Motorola phone, press (Menu) >
Settings > Connection > Bluetooth Link >
Handsfree > Look for Devices.
The phone lists Bluetooth devices it finds.
Select Motorola H680.
Select OK or Yes to pair your headset with
your phone.
Enter the passkey: 0000
Select OK.
When your headset successfully pairs and
connects with your phone, the indicator light
changes from steadily lit to flashing blue.
Note: These steps are for most Motorola phones.
For other phones, see your phone's user's guide.
M
4
TEST AND USE
Your phone and headset are now paired and
ready to make and receive calls.
To make a call:
Place the headset over your ear. See
"Wearing the Headset" on the reverse side
of this guide.
On the phone, dial the number you want to
call and press SEND key on your phone.
If your phone and headset are successfully
paired, you will hear ringing on the headset.
After you have successfully paired your
phone and headset, you don't need to
repeat these steps. For daily use, ensure
that your headset is turned ON and that
your phone's Bluetooth feature is ON.
1
2
USING YOUR H680
See
Features and
Functions Guide
on the reverse side
for information on
using your H680
1
2
Note: Headset is not functional while charging.
3
Plug the Motorola charger into the port on the
charger base.
Place headset into charger base ensuring that
charging contacts on the headset and
charging base connect.
The indicator light turns red when the battery
is charging. It may take up to 1 minute for the
indicator light to turn on. When the headset's
battery is fully charged (about 2 hours), the
indicator light turns off.
Disconnect the charger.
CHARGE
Your Headset's Battery
3
STORING YOUR
HEADSET
The charger base provided is used to charge
and store your headset. When not using your
headset, you should place it in the charger
base.
As shown, the charger cover can be placed on
top of the charger base, or underneath it to
provide support for desktop placement.
Charger
Cover
Charging
Contacts Charging
Contacts
DRAFT
DRAFT
