User manual Part 2
20 21
U818A WIFI-01
Main Frame
U818A WIFI-05
Carbon Tube
and Tooth Gear
U818A WIFI-09
Standard Motor
Parts (Red Light)
U818A WIFI-13
Camera Box
U818A WIFI-02
Blade
U818A WIFI-06
Standard Motor
(Red and Blue Wire)
U818A WIFI-10
Reverse Motor
Parts (Blue Light)
U818A WIFI-14
SD Card
U818A WIFI-03
Drone Cover
U818A WIFI-07
Reverse Motor
(Black and
White Wire)
U818A WIFI-11
Reverse Motor
Parts (Red Light)
U818A WIFI-15
Battery
U818A WIFI-04
Base Leg
U818A WIFI-08
Standard Motor
Parts (Blue Light)
U818A WIFI-12
Receiving Board
U818A WIFI-16
USB Wire
U818A WIFI-17
Card Reader
U818A WIFI-18
Transmitter
