Chevrolet 2010 Silverado 1500 Navigation Manual Guide

2015-10-23

: Chevrolet Chevrolet-2010-Chevrolet-Silverado-1500-Navigation-Manual-814356 chevrolet-2010-chevrolet-silverado-1500-navigation-manual-814356 chevrolet pdf

Open the PDF directly: View PDF .
Page Count: 86

Infotainment System ......... 3

Introduction ...................... 3

Overview ....................... 4

Radio ............................. 14

AM-FM Radio ............... 14

Satellite Radio .............. 21

Audio Players ................ 24

CD/DVD Player ............ 24

Auxiliary Devices .......... 41

Navigation ...................... 42

Using the Navigation

System .................. 42

Maps .......................... 44

Navigation Symbols ....... 47

Navigation Menu ........... 53

Destination .................. 65

Global Positioning

System (GPS) ......... 77

Vehicle Positioning ........ 78

Problems with Route

Guidance ................ 78

If the System Needs

Service .................. 79

Ordering Map DVDs ...... 79

Database Coverage

Explanations ........... 80

Voice Recognition .......... 80

Index ...................................i-1

2010 Full-Size Truck Navigation System M

Introduction

GENERAL MOTORS, GM, the GM

Emblem, CHEVROLET, the

CHEVROLET Emblem, and the

names TAHOE, SUBURBAN,

AVALANCHE, and SILVERADO,

GMC, the GMC Truck Emblem, and

the names SIERRA, SIERRA

DENALI, YUKON, and DENALI,

HUMMER, the name HUMMER, H2,

and the H2 Design are registered

trademarks of General Motors

Corporation.

Manufactured under license under

license under U.S. Patent #’s:

5,451,942; 5,956,674; 5,974,380;

5,978,762; 6,487,535 & other

U.S. and worldwide patents issued

& pending. DTS and DTS Digital

Surround are registered trademarks

and the DTS logos and Symbol

are trademarks of DTS, Inc.

Reserved.

Dolby

is manufactured under

license from Dolby

Laboratories.

Dolby

and the double-D symbol are

trademarks of Dolby

Laboratories.

“Made for iPod” means that an

electronic accessory has been

designed to connect speciﬁcally to

iPod and has been certiﬁed by

the developer to meet Apple

performance standards.

Litho in U.S.A.

Part No. 25872529 B Second Printing

Infotainment System 3

iPod is a trademark of Apple

Computer, Inc., registered in the

U.S. and other countries.

The information in this manual

supplements the owner manual.

This manual includes the latest

information available at the time it

was printed. We reserve the right to

make changes in the product

after that time without notice. For

vehicles ﬁrst sold in Canada,

substitute the name General Motors

of Canada Limited for Chevrolet

Motor Division, GMC, or HUMMER

whenever it appears in this

manual.

Keep this manual with the owner

manual in the vehicle, so it will

be there if it is needed. If the vehicle

is sold, leave this manual in the

vehicle.

Canadian Vehicle Owners

(Propriétaires des Véhicules

Canadiens)

A French language copy of this

manual can be obtained from your

dealer or from:

On peut obtenir un exemplaire de

ce guide en français auprès du

concessionnaire ou à l’adresse

Helm, Incorporated

P.O. Box 07130

Detroit, MI 48207

1-800-551-4123

Numéro de poste 6438 de langue

française

www.helminc.com

Overview

Read this manual thoroughly to

become familiar with how the

navigation system operates.

The navigation system includes

navigation and audio functions.

While entering the vehicle or when

turning the vehicle off, some

DVD Map Disc noise is normal.

Keeping your eyes on the road and

your mind on the drive is important

for safe driving. The navigation

system has built-in features intended

to help keep your eyes on the

road and mind on the drive. Some

features may be disabled while

driving. Note that these functions will

be grayed-out. A grayed-out

function indicates it is not available

when the vehicle is moving.

All functions are available when the

vehicle is parked. Do the following

before driving:

•Become familiar with the

navigation system operation, hard

keys on the faceplate, and

touch-sensitive screen buttons of

the navigation system.

•Set up the audio by presetting

favorite stations, setting the

tone, and adjusting the speakers.

4 Infotainment System

•Set up the navigation features

before beginning driving, such

as entering an address or a

preset destination.

•Set up your phone numbers in

advance so they can be called

easily with the press of a

single button or a single voice

command (for navigation systems

equipped with phone capability).

{WARNING

Taking your eyes off the road too

long or too often while using the

navigation system could cause a

crash resulting in injury or death

to you or others. Focus your

attention on driving.

{WARNING

Avoid looking too long or too often

at the moving map on the

navigation screen. This could

cause a crash and you or others

can be injured or killed. Use the

turn-by-turn voice guidance

directions whenever possible.

Use the navigation system to:

•Plan a route.

•Select a destination using

various methods and choices.

•Follow turn-by-turn route and

map guidance with voice

prompts, only if permitted by

traffic laws, controls, and

conditions.

You should always be alert and

obey traffic and roadway laws and

instructions, regardless of the

guidance from the navigation

system. Because the navigation

system uses street map information

that does not include all traffic

restrictions or the latest road

changes, it may suggest using a

road that is now closed for

construction or a turn that is

prohibited by signs at the

intersection. Because the system

uses limited information, you

must always evaluate whether

following the system’s directions is

safe and legal for the current

conditions.

When the navigation system is

turned on, a screen may appear with

the information below, and you

must read and acknowledge

the information it contains.

Infotainment System 5

{WARNING

Taking your eyes off the road for

extended periods could cause a

crash resulting in injury or death

to you or others.

To help avoid a crash in which you

or others could be killed:

•Always concentrate on your

driving ﬁrst by keeping your eyes

and mind on the road, and

your hands on the wheel.

•Follow system directions only if

permitted by traffic laws,

controls, and conditions.

•Before using this system, read

the owner’s manual and learn

how it operates.

•Some system controls cannot be

used the when vehicle is moving.

After you acknowledge the start up

information you will be able to

access the NAV (navigation) and

DEST (destination) functions. Once

accessed, you can enter or

delete information in the navigation

system or access other functions.

See instructions later in this section.

Every ﬁfty times the vehicle is started

and the navigation system is turned

on, the Caution screen appears.

After reading the caution, select OK

to load the map DVD information.

If OK is not selected, all hard keys

except for NAV (Navigation) and

DEST (Destination) can be

accessed. You can also press the

NAV hard key to have this Caution

screen appear.

When getting started, set the

navigation system to your

preference or delete information you

may have entered using various

options.

6 Infotainment System

A. DVD Map Disc. See “Installing

the Map DVD” under Maps on

page 44 for more information.

B. FULL MAP Touch Screen

Button. See “NAV” under “Hard

Keys” under Using the

Navigation System on page 42

for more information.

C. North Up/Heading Up Symbol.

See Navigation Symbols on

page 47 for more information.

D. O(Power/Volume) Knob. See

AM-FM Radio on page 14 and

Satellite Radio on page 21

for more information.

E. No GPS Signal Symbol. See

Navigation Symbols on

page 47 for more information.

F. NAV (Navigation) Hard Key. See

“Hard Keys” under Using the

Navigation System on page 42

for more information.

G. Distance and Time to Distance

Symbol. See Navigation

Symbols on page 47 for more

information.

Screen Shown with Map Disc Inserted

Infotainment System 7

H. DEST (Destination) Hard Key.

See Destination on page 65 for

more information.

I. Map Scale. See “Map Scales”

under Maps on page 44 for

more information.

J. RPT (Repeat) Hard Key for

Voice Guidance. See “Hard

Keys” under Using the Navigation

System on page 42 for more

information.

K. FAV (Favorite) Hard Key. See

“Storing Radio Station Presets”

under Using the Navigation

System on page 42 for more

information.

L. V(Zoom In) Touch Screen

Button. See “Map Scales” under

Maps on page 44 for more

information.

M. Mark Touch Screen Button. See

“Adding Destinations to the

Address Book” under Destination

on page 65 for more information.

N. Source (AM, FM, XM, CD, etc.)

Touch Screen Button. See

AM-FM Radio on page 14,

Satellite Radio on page 21, and

CD/DVD Player on page 24

for more information.

O. Audio CD/Video DVD Slot. See

CD/DVD Player on page 24 for

more information.

P. Z(Audio CD/Video DVD Eject)

Hard Key. See CD/DVD Player

on page 24 for more information.

Q. Auxiliary Input Jack. See

Auxiliary Devices on page 41 for

more information.

R. Clock Touch Screen Button. See

Navigation Menu on page 53 for

more information.

S. Distance to Next Turn Symbol.

See Navigation Symbols on

page 47 for more information.

T. f(Tune/Sound) knob. See

AM-FM Radio on page 14

and Satellite Radio on page 21

for more information.

U. AUDIO Hard Key. See AM-FM

Radio on page 14 and Satellite

Radio on page 21 for more

information.

V. MENU Hard Key (Settings and

Preferences). See Navigation

Menu on page 53 for more

information.

W. ¨SEEK (or Next) Key. See

AM-FM Radio on page 14,

Satellite Radio on page 21, and

CD/DVD Player on page 24

for more information.

X. U(Zoom Out) Touch Screen

Button. See “Map Scales”

under Maps on page 44 for more

information.

Y. ©SEEK (or Previous) Key. See

AM-FM Radio on page 14,

Satellite Radio on page 21, and

CD/DVD Player on page 24

for more information.

Z. POI (Point of Interest) Touch

Screen Button. See “Displaying

Points of Interest (POI) on

8 Infotainment System

the Map Screen” under

Navigation Symbols on page 47

for more information.

Language — English/Metric

To change the language of the

navigation screens, see “Driver

Information Center (DIC)” in

your vehicle’s owner manual index

for more information.

To change the navigation screens

from English or metric, see “DIC

Operation and Displays” in your

vehicle’s owner manual index for

more information.

Deleting Personal Information

This navigation system can

record and store personal

information such as names and

addresses. At times, such as when

you are disposing of your vehicle,

you may want to delete this

information. See “Edit Address

Book — Edit/View” under Navigation

Menu on page 53 for deleting

information from the address book.

Limit Features While Driving

The navigation system may

have this feature.

Touch the Limit Features While

Driving screen button to turn on and

off the ability to limit functions

while driving. When this screen

button is highlighted, the following

functions are limited while driving:

•Music Navigator Scrolling

•Radio Category Scrolling

•Navigation Menu Scrolling and

some functions

See “Category” under AM-FM Radio

on page 14 and Satellite Radio

on page 21 for more information.

See “From Map” under Destination

on page 65 for more information.

Some functions will remain limited

regardless of the setting.

Storing Radio Station Presets

To set preset radio stations, do

the following:

1. Press the O(power) knob to

turn the system on.

2. Press the AUDIO hard key and

select the desired band (AM,

FM1, FM2, XM1, or XM2

(if equipped)).

3. Use the f(tune) knob or the

SEEK arrows to tune to the

desired station.

4. Press and hold one of the ﬁve

preset screen buttons, at the

bottom of the screen, until

you hear a beep or see the

station displayed on the selected

preset button.

5. Repeat the steps for each

preset.

See “Storing Radio Station Presets”

under AM-FM Radio on page 14

and Satellite Radio on page 21 for

more information.

Infotainment System 9

Setting the Clock

To set the time, do the following:

1. Press the clock touch screen

button located in the upper

right corner of the screen.

2. Press the Set screen button.

3. Press the Hours and

Minutes −(minus) and + (plus)

signs to decrease and to

increase the time. See “Setting

the Clock” under Navigation

Menu on page 53 for more

information.

Setting the Search Area,

Entering an Address and Point

of Interest, and Storing

Preset Destinations

Before entering an Address, Point of

Interest, Home, or Preset

Destination, select the appropriate

region that contains the ﬁnal

destination. Your vehicle must be in

P (Park) to perform this operation.

Setting the Search Area

To set the search area, do the

following:

1. If the radio is already on with a

map disc inserted, skip to

Step 5.

2. Press the O(power) knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 44 for more

information.

4. A caution may appear. Touch the

OK screen button to proceed.

5. Press the DEST hard key.

6. Press the Change Search Area

screen button.

7. Select the appropriate region

numbered screen button that

contains your ﬁnal destination.

8. Press the Back screen button to

return to the Destination Entry

menu. See Destination on

page 65 for more information.

Entering an Address

If you are having trouble ﬁnding a

city or a street name, do the

following:

•Input the street name ﬁrst

instead of the city name, or vice

versa.

•Input more characters or reduce

the amount of characters to

reduce or expand the available

options.

To set a destination by entering a

city name, do the following:

1. If the radio is already on with a

map disc inserted, skip to

Step 5.

2. Press the O(power) knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 44 for more

information.

4. A caution may appear. Touch the

OK screen button to proceed.

5. Press the DEST hard key.

10 Infotainment System

6. Press the 6Address Entry

screen button.

7. The City name category will

automatically be selected for

entry. Start entering the

city name.

If ﬁve or less names are available

for the entered characters, a

list will display. If more than ﬁve

are available, there will be a

screen button with a number in

it, it represents the number

of available cities. Select this

button to view the list and select

a city.

8. Once a city is selected the street

name category will automatically

be selected for entry. Start

entering the street name.

Do not enter directional

information or street type, and

use the space symbol screen

button ( U) between street or

city names. For example, the

street name N. Royal Oak

Rd. should be entered as

royal Uoak. Use the

backspace ( q) screen button if

an incorrect character has

been entered.

If ﬁve or less names are available,

a list will display. If more than ﬁve

are available, there will be a

screen button with a number in

it, it represents the number of

available streets. Select this

button to view the list.

9. Select the street name with the

correct preﬁx from the list (Dr.,

Ln., St., etc.).

10. Once a street has been

selected, the numeric keyboard

will display, allowing you to

enter the house number. The

system will display the

house number range that is

available for the street.

11. Select the Go screen button. A

map screen, with the destination

marked, will appear.

12. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

13. Select the Start Guidance

screen button. You are now

ready to start your route.

See “Address Entry” under

Destination on page 65 for more

information.

Entering a Point of Interest (POI)

To set a destination by entering

a Point of Interest (POI), do

the following:

1. If the radio is already on with a

map disc inserted, skip to

Step 5.

2. Press the O(power) knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 44 for more

information.

4. A caution may appear. Touch the

OK screen button to proceed.

Infotainment System 11

5. Press the DEST hard key.

6. Press the iPoint of Interest

screen button.

7. Enter the speciﬁc title of the POI

in the POI name space (i.e.

Washington Monument).

If ﬁve or less names are

available, a list will display. If

more than ﬁve are available,

there will be a screen button with

a number in it, it represents

the number of available POIs.

Select this button to view the list.

8. Select the Go screen button.

A map screen, with the

destination marked, will appear.

9. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

10. Select the Start Guidance

screen button. You are now

ready to start your route.

See “Point of Interest (POI)” under

Destination on page 65 for more

information.

Storing Preset Destinations

1. If the radio is already on with a

map disc inserted, skip to

Step 5.

2. Press the O(power) knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 44 for more

information.

4. A caution may appear. Touch the

OK screen button to proceed.

5. Press the DEST hard key.

6. Enter a destination. See

Destination on page 65 for

information on how to enter a

destination.

7. Press the Mark screen button

from the map screen to add

the current ﬁnal destination as a

preset destination.

The address book screen will

appear.

8. Select the Name screen button.

An alpha-keyboard will display.

Enter the name.

9. Press and hold one of the screen

buttons at the bottom of the

screen until a pop-up

conﬁrmation displays.

The name will appear in that

preset destination screen button

and is now available to select

from the Destination Entry

screen. See “Using Your Stored

Preset Destinations” next in

this section to select it as

a destination.

See “Adding or Changing Preset

Destinations” under Destination

on page 65 for more information

on how to add preset

destinations.

12 Infotainment System

Using Your Stored Preset

Destinations

These destinations are available for

selection while driving.

1. If the radio is already on with a

map disc inserted, skip to

Step 5.

2. Press the O(power) knob to

turn the system on.

3. Insert the DVD map disc. See

“Installing the Map DVD” under

Maps on page 44 for more

information.

4. A caution may appear. Touch the

OK screen button to proceed.

5. Press the DEST hard key.

6. Select one of the available preset

destination screen buttons. A

map screen, with the destination

marked, will appear.

7. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

8. Select the Start Guidance screen

button. You are now ready to

start your route.

See “Preset Destination” under

Destination on page 65 for more

information.

Canceling Guidance

Guidance will be canceled once you

arrive at your ﬁnal destination. To

cancel guidance prior to arrival

at the ﬁnal destination, do the

following:

1. Press the DEST hard key.

2. Press the Cancel Guidance

screen button.

Guidance Volume

To adjust the volume of voice

guidance prompts, do the following:

1. Press the MENU hard key to

enter the menu options, then

press the MENU key repeatedly

until Nav is selected or touch

the Nav screen button.

2. Press the >Voice Prompt

screen button.

3. Press the + (plus) or – (minus)

screen buttons to increase or

to decrease the volume of

the voice prompts.

See “Voice Prompt” under

Navigation Menu on page 53 for

more information.

Hybrid Screens

See the “Two-Mode Hybrid Manual”

for more information.

Cleaning the Display Screen

Use a soft clean cotton cloth

dampened with clean water.

Infotainment System 13

Radio

AM-FM Radio

Notice: Before adding any sound

equipment to the vehicle, such

as an audio system, CD player,

CB radio, mobile telephone,

or two-way radio, make sure that

it can be added by checking

with your dealer. Also, check

federal rules covering mobile

radio and telephone units.

If sound equipment can be added,

it is very important to do it

properly. Added sound equipment

can interfere with the operation

of the vehicle’s engine, radio,

or other systems, and even

damage them. The vehicle’s

systems can interfere with the

operation of sound equipment

that has been added.

Notice: The chime signals

related to safety belts, parking

brake, and other functions of the

vehicle operate through the

navigation system. If that

equipment is replaced or

additional equipment is added to

the vehicle, the chimes may

not work. Make sure that

replacement or additional

equipment is compatible with the

vehicle before installing it. See

“Accessories and Modiﬁcations”

in the Index of the vehicle’s

owner manual.

Playing the Radio

O(Power/Volume): Press this

knob to turn the audio system

on and off. Turn the knob to

increase or to decrease the volume.

f(Tuning/Sound Knob): Turn

this knob to go to the next or

previous frequency.

Press this knob to display the

Sound menu. See “Sound Menu”

later in this section.

AUDIO: Press this key to display

the audio screen. Press the

key to switch between AM, FM, or

XM, if equipped, DISC, or AUX

(Auxiliary), or touch the screen

button. See AM-FM Radio on

page 14,Satellite Radio on page 21,

CD/DVD Player on page 24, and

Auxiliary Devices on page 41

for more information.

14 Infotainment System

Finding a Station

If viewing a map screen, touch the

source screen (AM, FM, XM,

CD, etc.) button. The display will

split between the audio screen and

the map screen. All station-changing

functions can be performed from

this screen.

If you do not want to view a split

screen or you are not on a

map screen, press the AUDIO

hard key.

AM/FM/XM: Touch the source

(AM, FM, or XM, if equipped) screen

button or press the AUDIO key

repeatedly until the desired source

is highlighted.

Category: Touch the screen

button, located in the middle of the

screen, to receive a list of all of

the selected band stations in

the area. Use the up and down

arrow screen buttons to scroll the

frequencies. Touch the desired

frequency.

FM lists may also contain a category

to select if stations in your area

support Radio Data Systems (RDS).

FM source shown, other sources

similar

FM source shown, other sources

similar FM source shown, other sources

similar

Infotainment System 15

$Refresh List: Touch this screen

button to refresh the list of stations.

When viewing a map screen,

the name of the station or channel

will appear on the display.

¨SEEK / ©SEEK: To seek

stations, press the left or right arrow

keys to go to the next or previous

station and stay there.

To scan stations, press and hold

either arrow for more than two

seconds. The radio will go to

a station, play for a few seconds,

then go on to the next station.

To stop scanning, press either

arrow again.

Storing Radio Station Presets

This feature allows you to store

up to 30 preset stations. See

“Number of Preset Pages” under

“Radio Menu” later in this section for

more information. You can mix

AM, FM, and XM (if equipped). To

store presets, do the following:

1. Press the O(power) knob to turn

the system on.

2. If viewing a map screen, touch

the source screen button,

press the AUDIO key, or press

the FAV (favorite) key.

3. Select the band.

4. Seek, scan, or tune to the

desired station, to select

the station.

5. Press and hold one of the preset

screen buttons for more than

two seconds or until you hear

a beep.

6. Repeat the steps for each

preset.

Sound Menu

f(Sound Menu): Press this knob

or press the MENU key to access

the Sound menu to adjust the treble,

midrange, bass, fade, balance,

and equalization or Digital Signal

Processing (DSP), if equipped with

the Bose

sound system.

Digital Signal Processing (DSP)

shown, Equalization similar

16 Infotainment System

Setting the Tone

TREBLE: Touch the plus (+) or

minus (−) sign to increase or

decrease the treble. If a station is

weak or noisy, decrease the treble.

MID (Midrange): Touch the

plus (+) or minus (−) sign to increase

or decrease the midrange.

BASS: Touch the plus (+) or

minus (−) sign to increase or

decrease the bass.

Adjusting the Speakers

L/R (Left/Right) (Balance): To

adjust the balance between the left

and the right speakers, touch and

hold the L or R screen buttons. To

center the balance and the fade,

touch the center, where the two

lines meet.

Front/Rear (Fade): To adjust the

fade between the front and the rear

speakers, touch and hold the Front

or Rear screen buttons. To center

the balance and the fade, touch the

center, where the two lines meet.

Automatic Equalization

If the system has automatic

equalization, you can select

customized equalization settings

designed for Talk. Touch the

Talk screen button to hear the

change in sound. The system will

save the setting for each source.

To not use the automatic

equalization setting, press any of

the screen buttons that will change

the treble, midrange, bass,

balance, or fade. This will take the

system out of the equalization

setting so that you can create your

own sound.

Digital Signal Processing (DSP)

If the system has Digital Signal

Processing (DSP), DSP is used to

provide a choice of four different

listening experiences. DSP can be

used while listening to the audio

system. The type of DSP selected is

displayed on the status line.

Select from the following DSP

settings:

Normal: Select this screen button

to adjust the audio to be in

normal mode. This provides the

best sound quality for all seating

positions.

Surround (Centerpoint

): Select

this screen button to turn on

Bose Centerpoint

signal processing

circuitry. Centerpoint

produces a

full vehicle surround sound listening

experience from a CD, MP3/WMA,

DVD, or XM stereo digital audio

source and delivers ﬁve independent

audio channels from the

conventional two channel stereo

recordings. This is not available for

AM or FM.

Driver: Select this screen button to

adjust the audio to give the driver

the best possible sound quality.

Rear: Select this screen button to

adjust the audio to give the rear seat

occupants the best possible

sound quality.

Infotainment System 17

The 2 CH and 5.1 CH buttons are

available only when a 5.1 CH disc is

available and RSA is off.

2 CH (Channel): Select this screen

button to enhance surround

sound. The Surround screen button

must be selected to select the

2 CH screen button.

5.1 CH (Channel): Select this

screen button, when listening to a

DVD, to give a full affect of surround

sound listening. The Surround

screen button must be selected to

select the 5.1 CH screen button.

Downmix: If a 5.1 CH disc

is playing, and the 2 CH screen

button is selected or RSA is turned

on, the system will downmix the

audio from 5.1 CH to 2 CH if

this feature is supported on the disc.

Radio Menu

Press the MENU key to enter the

menu screen, then press the MENU

key repeatedly until Radio is

selected or touch the Radio screen

button to make changes for radio

information displayed or to limit

features while driving, number of

preset pages, XM categories,

and Automatic Volume Control or

Bose

AudioPilot

Additional Information Displayed

The navigation system may have

this feature.

Touch the 4Additional Information

Displayed screen button to turn

station, channel, CD, and MP3

information on or off.

Touch the YES screen button to

receive information, when it is

available, for the following; FM: RDS

category name and radio text,

XM: Song Title and Artist Name,

CD: CD text, MP3: tag information.

Touch the NO screen button to

receive no information.

18 Infotainment System

Limit Features While Driving

The navigation system may have

this feature.

Touch the Limit Features While

Driving screen button to turn on and

off the ability to limit functions

while driving. When this screen

button is highlighted, the following

functions will be limited while driving:

•Music Navigator Scrolling

•Radio Category Scrolling

•Navigation Menu Scrolling and

some functions

See “Category” earlier in this

section for more information. See

“From Map” under Destination

on page 65 for more information.

Number of Preset Pages

Touch the /Number of Preset

Pages screen button to change the

number of preset pages, 1 through 6.

Each preset page can contain ﬁve

preset stations. Touch the desired

numbered screen button.

Automatic Volume Control or

Bose AudioPilot

>Automatic Volume

Control: With automatic volume

control, your audio system adjusts

automatically to make up for

road and wind noise as you drive.

To use Automatic Volume Control:

1. Set the volume at the desired

level.

2. Press the MENU key to enter the

menu screen, then press the

MENU key repeatedly until Radio

is selected or touch the Radio

screen button.

3. Press the >Automatic Volume

Control screen button to access

the Speed Compensated

Volume screen.

4. Touch the Low, Medium, or High

screen buttons. Each higher

setting allows for more

compensation at faster vehicle

speeds.

Then, as you drive, automatic

volume control automatically

increases the volume, as necessary,

to overcome noise at any speed.

The volume level should always

sound the same to you as you drive.

To turn automatic volume control

off, touch the OFF screen button.

Infotainment System 19

AudioPilot: If the system has the

Bose

sound system it may

include Bose AudioPilot

noise

compensation technology.

To use AudioPilot

1. Press the MENU key to enter the

menu screen, then press the

MENU key repeatedly until Radio

is selected or touch the Radio

screen button.

2. Press the >Automatic Volume

Control screen button to access

the AudioPilot menu.

3. Press the ON screen button.

To turn it off, touch the OFF screen

button.

When on, AudioPilot

continuously

adjusts the audio system

equalization, to compensate for

background noise, so that your

music always sounds the same at

the set volume level.

This feature is most effective at

lower volume settings where

background noise can affect how

well you hear the music being

played through your vehicle’s audio

system. At higher volume settings,

where the music is much louder than

the background noise, there may

be little or no adjustments by

AudioPilot

. For more information

on AudioPilot

, please visit

bose.com/audiopilot.

Radio Data System (RDS)

The audio system has a Radio Data

System (RDS). RDS features are

available for use only on FM stations

that broadcast RDS information.

With RDS, the radio can do

the following:

•Seek to stations broadcasting the

selected type of programming

•Receive announcements

concerning local and national

emergencies

•Display messages from radio

stations

This system relies on receiving

speciﬁc information from these

stations and will only work when the

information is available. In rare

cases, a radio station may broadcast

incorrect information that will

cause the radio features to work

improperly. If this happens, contact

the radio station.

The RDS system is always on.

When information is broadcast from

the FM station you are listening

to, the station name or call letters

will be displayed on the audio

screen. RDS may provide a program

type (PTY) for current programming

and the name of the program

being broadcasted.

20 Infotainment System

Satellite Radio

Notice: Before adding any sound

equipment to the vehicle, such

as an audio system, CD player,

CB radio, mobile telephone,

or two-way radio, make sure that

it can be added by checking

with your dealer. Also, check

federal rules covering mobile

radio and telephone units.

If sound equipment can be added,

it is very important to do it

properly. Added sound equipment

can interfere with the operation

of the vehicle’s engine, radio,

or other systems, and even

damage them. The vehicle’s

systems can interfere with the

operation of sound equipment

that has been added.

Notice: The chime signals

related to safety belts, parking

brake, and other functions of the

vehicle operate through the

navigation system. If that

equipment is replaced or

additional equipment is added to

the vehicle, the chimes may

not work. Make sure that

replacement or additional

equipment is compatible with the

vehicle before installing it. See

“Accessories and Modiﬁcations”

in the Index of the vehicle’s

owner manual.

Playing the Radio

O(Power/Volume): Press this

knob to turn the audio system

on and off. Turn the knob to

increase or to decrease the volume.

f(Tuning/Sound Knob): Turn

this knob to go to the next or

previous frequency.

Press this knob to display the

Sound menu. See “Sound Menu”

later in this section.

AUDIO: Press this key to display

the audio screen. Press the

key to switch between AM, FM, or

XM, if equipped, DISC, or AUX

(Auxiliary), or touch the screen

button. See AM-FM Radio on

page 14,Satellite Radio on page 21,

CD/DVD Player on page 24, and

Auxiliary Devices on page 41

for more information.

Finding a Station

For information on ﬁnding and

changing a station, see AM-FM

Radio on page 14 earlier in

this section.

AM/FM/XM: Touch the source

(AM, FM, or XM, if equipped) screen

button or press the AUDIO key

repeatedly until the desired source

is highlighted. See AM-FM Radio

on page 14 earlier in this section.

Infotainment System 21

Category: Touch the screen

button, located in the middle of the

screen, to receive a list of all of

the selected band stations in

the area. Use the up and down

arrow screen buttons to scroll the

frequencies. Touch the desired

frequency.

XM lists will also contain a category

to select and the stations or channels

that pertain to the category. For XM,

touch the left and right arrow screen

buttons to change categories. The

station information will appear on the

display. See “Radio Menu” later in

this section to add and remove XM

categories from the category list.

When listening to XM stations, you

will be able to select all of the

categories when using the right and

left arrow screen buttons on the main

audio screen. The categories, when

removed, will not be enabled to

select from the category list screen.

$Refresh List: Touch this screen

button to refresh the list of stations.

When viewing a map screen,

the name of the station or channel

will appear on the display.

¨SEEK / ©SEEK: To seek

stations, press the left or right arrow

keys to go to the next or previous

station and stay there.

To scan stations, press and hold

either arrow for more than two

seconds. The radio will go to

a station, play for a few seconds,

then go on to the next station.

To stop scanning, press either arrow

again.

Storing Radio Station Presets

This feature allows you to store

up to 30 preset stations. You can

mix AM, FM, and XM (if equipped).

To store presets, see AM-FM

Radio on page 14 earlier in this

section.

Sound Menu

For more information on setting the

tone, adjusting the speakers,

Digital Signal Processing (DSP),

and automatic equalization,

see AM-FM Radio on page 14

earlier in this section.

Digital Signal Processing (DSP)

shown, Equalization similar

22 Infotainment System

Radio Menu

Press the MENU key to enter the

menu screen, then press the MENU

key repeatedly until Radio is

selected or touch the Radio screen

button to make changes for radio

information displayed or to limit

features while driving, number of

preset pages, XM categories,

and Automatic Volume Control or

Bose

AudioPilot

, see AM-FM

Radio on page 14 earlier in

this section.

Remove/Add XM Categories

Touch the &Remove/Add XM

Categories screen button to remove

or add XM categories when

selecting XM categories from the

category list screen. The list of XM

categories will appear on the

screen. Use the up and down arrow

screen buttons to scroll through

the list. The categories to remove

will be highlighted and the

categories to add will be dark in

color. Touch the category that you

would like to add or remove.

Touch the Restore All Categories

screen button to add all categories

that have been removed.

XM™ Satellite Radio Service

XM™ is a satellite radio service that

is based in the 48 contiguous

United States and 10 Canadian

provinces. XM Satellite Radio

has a wide variety of programming

and commercial-free music,

coast-to-coast, and in digital-quality

sound. During your trial or when

you subscribe, you will get unlimited

access to XM Radio Online for

when you are not in the vehicle. A

service fee is required to receive the

XM service. For more information,

contact XM at www.xmradio.com or

call 1-800-929-2100 in the U.S.

and www.xmradio.ca or call

1-877-438-9677 in Canada.

When XM™ is active, the channel

name and number, song title,

and artist will display on the screen.

XM™ Radio Messages

See “XM™ Radio Messages” in the

vehicle’s owner manual” for a list

of possible XM messages.

Infotainment System 23

Audio Players

CD/DVD Player

Playing an Audio CD

The player can be used for CD and

MP3. If your vehicle has RSE,

the player can be used for CD, MP3,

DVD audio, and as a DVD video

player. See “Playing a DVD” later in

this section.

With the ignition on, insert a CD

partway into the slot, label side up.

The player will pull it in and the

CD should begin playing. While

playing a CD, the navigation system

is available. If you insert a CD

with the system off and the ignition

on, it will start to play.

When you insert a CD, the CD tab

will display.

If you turn off the ignition or radio

with a CD in the player, it will stay in

the player. When you turn on the

ignition or radio, the CD will start

playing where it stopped, if it

was the last selected audio source.

As each new track starts to play,

the track number will appear on the

display.

The CD player can play the smaller

3 inch (8cm) single CDs with an

adapter ring. Full-size CDs and the

smaller CDs are loaded in the

same manner.

If an error appears on the display,

see “CD/DVD Messages” later

in this section.

If viewing a map screen, touch the

CD screen button. The display

will split between the audio screen

and the map screen. If you do

not want to view a split screen or

you are not on a map screen, press

the AUDIO key then press the

AUDIO key until CD is selected or

touch the CD screen button.

j/r(Pause/Play): Touch this

button to pause the CD. This button

will then change to the play button.

Touch the play button to play the CD.

RANDOM: Touch this button to hear

the tracks in random, rather than

sequential, order. Touch RANDOM

again to turn off random play.

r(Rewind): Touch and hold this

button to rewind quickly through

a track selection. You will hear

sound at a reduced volume. Release

this button to stop rewinding. The

display will show the elapsed time of

the track.

24 Infotainment System

[(Forward): Touch and hold this

button to fast forward quickly

through a track selection. You will

hear sound at a reduced volume.

Release this button to stop fast

forwarding. The display will show

the elapsed time of the track.

¨SEEK / ©SEEK: Press the

right arrow to go to the next

track. Press the left arrow to go to

the start of the current track, if more

than ﬁve seconds have played. If

either arrow is pressed more

than once, the player will continue

moving backward or forward through

the CD. The sound will mute

while seeking.

You can also turn the tune knob to

seek to the next or previous track.

When playing an audio CD, if your

vehicle has RSE, the rear seat

operator can power on the RSE

video screen and use the remote

control to navigate through the

tracks on the CD.

Using an MP3 CD

MP3 Format

There are guidelines that must be

met, when creating an MP3

disc. If the guidelines are not met

when recording a CD-R(W), the CD

may not play. The guidelines are

(Supported Sampling rate and

Bit rates will vary based on CD or

DVD Navigation Systems):

•Sampling rate: 8 kHz, 11.025

kHz, 12 kHz, 16 kHz, 22.05 kHz,

24 kHz, 32 kHz, and 44.1 kHz,

48 kHz, 88.2 kHz, 96 kHz,

176.4 kHz, and 192 kHz.

•Bit rates supported: 8, 16, 24,

32, 40, 48, 56, 64, 80, 96,

112, 128, 160, 192, 224, 256,

and 320 kbps.

•ID3 tag information is displayed

by the radio if it is available.

The radio supports ID3 tag

information v1.0 or v1.1. The

radio will display a ﬁlename, song

name, artist name, album

name, and directory name.

•Maximum 32 characters,

including spaces, in a ﬁle

or folder name.

•Maximum number of folders is

253 with a maximum hierarchy

of eight folders.

•Create a folder structure that

makes it easy to ﬁnd songs while

driving. Organize songs by

albums using one folder for each

album. Each folder or album

should contain 18 songs or less.

•It is recommended that there is a

maximum of 192 ﬁles on a disc.

•The ﬁles can be recorded on a

CD-R or CD-RW with a maximum

capacity of 700MB.

•DVD with MP3 are not playable

on this system.

Root Directory

The root directory will be treated as

a folder. If the root directory has

compressed audio ﬁles, the directory

will be displayed as ROOT.

Infotainment System 25

All ﬁles contained directly under the

root directory will be accessed

prior to any root directory folders.

However, playlists (Px) will always

be accessed before root folders

or ﬁles.

Empty Directory or Folder

If a root directory or a folder exists

somewhere in the ﬁle structure

that contains only folders/subfolders

and no compressed ﬁles directly

beneath them, the player will

advance to the next folder in the ﬁle

structure that contains compressed

audio ﬁles and the empty folder

will not be displayed or numbered.

No Folder

When the CD contains only

compressed ﬁles, the ﬁles will be

located under the root folder.

The next and previous folder

functions will have no function on a

CD that was recorded without

folders or playlists. When displaying

the name of the folder the radio

will display ROOT.

When the CD contains only playlists

and compressed audio ﬁles, but

no folders, all ﬁles will be located

under the root folder. The left

and right arrow buttons will search

playlists (Px) ﬁrst and then go

to the root folder. When the radio

displays the name of the folder

the radio will display ROOT.

Order of Play

Tracks will be played in the following

order:

•Play will begin from the ﬁrst track

in the ﬁrst playlist and will

continue sequentially through all

tracks in each playlist. When

the last track of the last playlist

has been played, play will

continue from the ﬁrst track of

the ﬁrst playlist.

•If the CD does not contain any

playlists, then play will begin

from the ﬁrst track under the root

directory. When all tracks from

the root directory have been

played, play will continue from

ﬁles according to their numerical

listing. After playing the last

track from the last folder, play

will begin again at the ﬁrst track

of the ﬁrst folder or root

directory.

When play enters a new folder, the

display will not automatically

show the new folder name. The new

track name will appear on the

display.

File System and Naming

The song name that will display will

be the song name that is contained

in the ID3 tag. If the song name

is not present in the ID3 tag, then

the radio will display the ﬁle

name without the extension (such

as .mp3) as the track name.

Track names longer than

32 characters or four pages will be

shortened. The display will not

show parts of words on the

last page of text and the extension

of the ﬁlename will not display.

26 Infotainment System

Preprogrammed Playlists

You can access preprogrammed

playlists which were created

by WinAmp™, MusicMatch™, or

Real Jukebox™ software, however,

you will not have editing capability.

These playlists will be treated

as special folders containing

compressed audio song ﬁles.

Playing an MP3

With the ignition on, insert a CD

partway into the slot, label side up.

The player will pull it in. The

system may take some time to read

the MP3 disc. While playing a

CD, the navigation system is

available. If you insert a CD with the

system off and the ignition on, it

will start to play.

When you insert a CD, the CD tab

will display.

If you turn off the ignition or radio

with a CD in the player, it will stay in

the player. When you turn on the

ignition or radio, the CD will

start playing where it stopped, if it

was the last selected audio source.

As each new track starts to play,

the track number will appear on the

display.

If an error appears on the display,

see “CD/DVD Messages” later

in this section.

If viewing a map screen, touch the

CD screen button. The display

will split between the audio screen

and the map screen. If you do

not want to view a split screen or

you are not on a map screen, press

the AUDIO key, then press the

AUDIO key until CD is selected or

touch the CD screen button.

j/r(Pause/Play): Touch this

button to pause the CD. This button

will then change to the play

button. Touch the play button to

play the CD.

Random: Touch this screen button

to hear the disc played in random

(tracks and folders) order. Touch the

Random screen button to turn off

random play.

Infotainment System 27

r(Rewind): Touch and hold this

button to rewind quickly through

a track selection. You will hear

sound at a reduced volume. Release

this button to stop rewinding. The

display will show the elapsed time of

the track.

[(Forward): Touch and hold this

button to fast forward quickly

through a track selection. You will

hear sound at a reduced volume.

Release this button to stop fast

forwarding. The display will show

the elapsed time of the track.

qr(Folder): Select the left or

right arrow to go to the previous or

next folder on the disc.

Press the middle screen button, with

the folder name, to sort the MP3

by folder and ﬁle name. It may take

a few minutes for the system to

sort the MP3.

Sort By: Touch this screen button

to organize the MP3 to enable

you to sort the MP3 by artist, album,

and genre. It may take a few

minutes for the system to sort the

MP3.

¨SEEK / ©SEEK: Press the

right arrow to go to the next

track. Press the left arrow to go to

the start of the current track, if more

than ﬁve seconds have played. If

either arrow is pressed more

than once, the player will continue

moving backward or forward through

the CD. The sound will mute

while seeking.

You can also turn the tune knob to

seek to the next or previous

track.

When playing an MP3, if your

vehicle has RSE, the rear seat

operator can power on the RSE

video screen and use the remote

control to navigate through the MP3.

Playing a DVD

The player can be used for DVD

audio and DVD video.

With the ignition on, insert a DVD

partway into the top visible slot, label

side up. The player will pull it in

and the DVD should begin playing.

While playing a DVD, the

navigation system is available. If

you insert a DVD with the system off

and the ignition on, it will start to

play.

This feature will not operate on the

navigation screen unless the

vehicle is in P (Park).

The Rear Seat Entertainment (RSE)

video screen will start play of the

DVD when a DVD has been inserted

into the navigation system. See

“Rear Seat Entertainment System”

in the Index of your vehicle’s

owner manual for more information.

The DVD player is only compatible

with DVDs of the appropriate

region code that is printed on the

jacket of most DVDs.

28 Infotainment System

The DVD slot is compatible with

most audio CDs, CD-R, CD-RW,

DVD-Video, DVD-Audio,

DVD-R/RW, DVD+R/RW media

along with MP3 and WMA

“un-protected” formats.

There are three ways to play

a DVD:

•Once a DVD is inserted, the

system will automatically

start play of the DVD.

•If you are on a map screen,

touch the DVD screen button.

•Press the AUDIO hard key, then

touch the DVD screen button.

When a DVD is loaded in the DVD

player, the rear seat operator

can power on the RSE video screen

and use the remote control to

navigate through the DVD.

O(Power/Volume): Press this

knob to turn the system on and off.

Turn the knob to increase or

decrease the volume of the audio

system.

Press and hold this knob for more

than two seconds to turn the

navigation system, RSE, and

RSA off.

If an error appears on the display,

see “CD/DVD Messages” later

in this section.

Rear Seat Entertainment

(RSE)

If the Rear Seat Entertainment

(RSE) video screen is playing a

DVD movie and the ignition is

turned to LOCK and then back to

ACCESSORY, RUN, or START, the

RSE screen will not turn back on

automatically. To view the movie on

the RSE video screen:

•Press the remote control O

(power) button, then the r(play)

button, which will continue the

movie from where it was stopped.

•Press the r(play) screen button

on the navigation screen, which

will continue the movie from

where it was stopped.

•Eject and replace the DVD movie

from the navigation system,

which will start the movie from

the beginning.

DVD Menu Options

Once a DVD starts to play, the

menu options will automatically

appear. To display the menu

choices while a DVD is playing in

full screen, touch anywhere on

the screen.

There are three pages of menu

options. Press the right and

left arrow screen buttons to use all

Infotainment System 29

of the menu screen buttons. Menu

options are available when they

are highlighted. Some menu options

are only available when the DVD

is not playing.

Full: Press this screen button to

remove all menu options from

the display. Press anywhere on the

screen to display the menu

options.

Cursor: Touch this button to

access the cursor menu. The arrows

and other cursor options allow

you to navigate the DVD menu

options. The cursor menu options

are only available if a DVD has

a menu.

q,Q,r,R(Arrow

Buttons): Use these arrow buttons

to move around the DVD menu.

Enter: Touch this button to select

the highlighted option.

Return: Touch this button to go

back to the previous DVD menu.

Back: Touch this button to go back

to the main DVD display screen.

Move: Touch this button to

move the cursor buttons back and

forth from the bottom-right corner to

the top-left corner of the screen.

j/r(Pause/Play): Touch

this button to pause the DVD. This

button will then change to the

play button. Touch the play button

to play the DVD.

Random: Touch this button to hear

the tracks in random, rather than

sequential, order. Touch Random

again to turn off random play.

This button is not available for DVD

video.

c(Stop): Touch this button to

stop play of the DVD. Press the play

button to continue playing the DVD

from where the DVD was stopped.

Press this button twice to return to

the beginning of the DVD.

r(Rewind): Touch and hold this

button to rewind through the

scene, chapters, and titles. This

button may not work when the DVD

is playing the copyright information

or the previews.

[(Forward): Touch and hold this

button to advance rapidly through

the scene, chapters, and titles. This

button may not work when the

DVD is playing the copyright

information or the previews.

Top Menu: Touch this button to

display the ﬁrst menu of the

DVD. This button is not available on

all DVDs.

Menu: Touch this button to display

the DVD menu of the current area of

the DVD that is playing. This button

is not available for DVD audio.

Search: Touch this button to

display the title search screen. The

keyboard allows you to type in

the title number of the title that you

would like to watch.

30 Infotainment System

Setup: Touch this button to display

the DVD Setup screen. This button is

only available when the DVD is not

playing. The DVD Setup screen

allows you to change the brightness,

contrast, and mode, change the

viewing on the monitor, and to

change the initial settings; language,

parental level, and aspect.

!(Brightness): Touch the up or

down screen arrows to increase

or decrease the brightness of

the navigation screen.

_(Contrast): Touch the up or

down screen arrows to increase or

decrease the contrast of the

navigation screen.

Auto (Automatic): Touch this

screen button for the system to

automatically adjust the navigation

screen background depending on

exterior lighting conditions.

Night: Touch this screen button

and the system will make the

navigation screen background

darken.

Day: Touch this screen button and

the system will make the navigation

screen background brighten.

Monitor: From the DVD Setup

screen, touch this button to adjust

the viewing angle of the DVD on the

navigation screen. This is not

available on all DVDs.

Touch the ebutton to close the

screen in from the left and right

sides.

Touch the Jbutton to ﬁll the

screen on the left and right sides.

Touch the dbutton to ﬁll the

screen on the top and bottom.

Initial Settings: From the DVD

Setup screen, touch this button to

change audio, subtitle, and

menu languages, parental level, and

to view the aspect of the DVD.

The movie must be stopped to use

this menu. These settings are

not available on all DVDs.

Audio Language: Touch English,

Francais, or Espanol to change

the language that you are listening

to.

Subtitle Language: Touch English,

Francais, or Espanol to change

the language of the subtitles.

Menu Language: Touch English,

Francais, or Espanol to change

the language of the menus.

Infotainment System 31

Parental Level: Touch this button

to change the rating level to

only allow the play of DVDs with a

certain rating. The rating selection

is 1 through 8, with 1 being a

G rating. If the 1 is selected, any

DVD with a rating above G will not

be able to be viewed without

entering a password.

When the parental level screen is

ﬁrst entered a keyboard will

appear on the display and a

four-digit password will need to be

created. Type in a password

that you will be able to remember.

Once the password is created,

you can then select a rating level.

If you would like to change the rating

level, press the Parental Level

button, then press the Password

button. Type in the password

and then change the rating level.

If the password has been forgotten,

contact your dealer.

This may not be available on all

DVDs.

Aspect: Touch this button to

change the aspect ratio of the DVD.

This may not be available on all

DVDs.

Audio: Press this button to display

the audio stream number and to

change the language heard.

Repeatedly press this button to

toggle through the available

languages. This may not be

available on all DVDs. This button is

not available when the DVD is

stopped.

Subtitle: Touch this button to

playback the video with subtitles.

Repeatedly press this button

to toggle through the available

languages. To turn the subtitles off,

press this button until Off is

selected. This button is not available

when the DVD is stopped. This

may not be available on all DVDs.

Angle: Touch this button to

adjust the viewing angle of the

DVD. Repeatedly press this button

to toggle through the angles.

This button is not available when

the DVD is stopped. This may

not be available on all DVDs.

qPage: Press this button to go to

the previous scene. This button is

not available when the DVD is

stopped. This button is not available

for DVD video.

Page r:Press this button to go to

the next scene. This button is not

available when the DVD is stopped.

This button is not available for

DVD video.

¨SEEK (Next

Track/Chapter): Press this hard

key to go to the next track or

chapter. This button may not work

when the DVD is playing the

previews.

©SEEK (Previous

Track/Chapter): Press this hard

key to return to the start of the

current track or chapter.

32 Infotainment System

Press this button again to go to the

previous track or chapter. This

button may not work when the DVD

is playing the copyright information

or the previews.

CD/DVD Messages

If Disc Read Error appears on the

display and/or the CD/DVD

comes out, it could be for one of the

following reasons:

•If a disc was inserted with an

invalid or unknown format.

•If the disc is not from a correct

region.

•If the map DVD disc was

installed into the CD slot. See

“Installing the Map DVD”

under Maps on page 44 for more

information.

•It is very hot. When the

temperature returns to normal,

the DVD should play.

•You are driving on a very rough

road. When the road becomes

smoother, the CD/DVD

should play.

•The CD/DVD is dirty, scratched,

wet, or upside down.

•The air is very humid. If so, wait

about an hour and try again.

•There may have been a problem

while burning the CD/DVD.

•The label may be caught in the

CD/DVD player.

If the CD/DVD is not playing

correctly, for any other reason, try a

known good CD/DVD.

If any error occurs repeatedly or if

an error cannot be corrected,

contact your dealer.

If playing recorded media such as a

CD or DVD, the sound quality

may be reduced due to CD or DVD

quality, the method of recording,

the quality of the music that

has been recorded, recording

speed, max media recording speed,

and the way the CD or DVD has

been handled. There may be

an increase in skipping, difficulty in

ﬁnding tracks, and/or difficulty in

loading and ejecting. If these

problems occur, check the bottom

surface of the disc. If the surface is

damaged, such as cracked,

broken, or scratched, it will not play

properly. If the surface is soiled,

see “Care of Your CDs and DVDs”

in the Index of the vehicle’s

owner manual.

If there is no apparent damage, try

a known good CD or DVD.

Infotainment System 33

Notice: If a label is added to a

CD or DVD, or more than one CD

or DVD is inserted into the slot

at a time, or an attempt is made to

play scratched or damaged

CDs or DVDs, the player could be

damaged. While using the CD

or DVD player, use only CDs or

DVDs in good condition without

any label, load one CD or DVD

at a time, and keep the player and

the loading slot free of foreign

materials, liquids, and debris.

Do not add any label to a CD

or DVD, it could get caught in the

player. If a CD or DVD is recorded

on a personal computer and a

description label is needed,

try labeling the top of the recorded

CD or DVD with a soft marker.

USB Host Support

The USB connector uses the

USB 2.0.

USB Supported Devices

•USB ﬂash sticks or pen drives.

•Portable USB Hard Drives.

Special care needs to be

taken related to the power source

of these devices (USB bus

powered vs. external power).

•Portable media adapters that

support SD Flash, Compact

Flash, or SD Micro.

Depending on the USB mass

storage device, some devices might

not be recognized. The supported

ﬁle formats for USB devices

are .mp3 and.wma ﬁles.

Music can be played directly from

the USB device and controlled

through MP3 control functions

and menu.

Playing from USB

Content can also be played directly

from the USB device.

The USB port is located, depending

on the vehicle, in the center console

or instrument panel in the APO

connection on the passenger side.

The USB icon displays when the

USB device connected.

To play a USB device:

•Connect the USB and it begins

to play.

•Press the Audio hard key until

AUX tab is selected, then

press the USB screen button.

The audio source options under

AUX menu will vary based

on your Navigation model.

34 Infotainment System

While the USB source is active, use

the following to operate USB

function:

k(Play/Pause): Press to start,

pause or resume play of the current

media source.

l(Seek Up/FWD): Press to seek

to the next track.

Press and hold to advance quickly

through playback. Release the

button to return to playing speed.

Elapsed time displays.

g(Seek Down/REV): Press to

seek to the beginning of the current

or previous track. If the track has

been playing for less than ﬁve

seconds, the previous track plays. If

playing longer than ﬁve seconds,

the current track restarts. Press and

hold to reverse quickly through

playback. Release the button

to return to playing speed. Elapsed

time displays.

TUNE: Turn the knob to the right or

left to go to the next or previous

track.

USB Music Menu: See USB Music

Menu following for more information.

USB Music Menu

Once the USB has been connected,

the main music menu appears.

Select any of the following buttons

on the USB Music Menu:

Files/Folders/Playlists: Select to

view the playlists stored on the USB.

Select a folder/playlist to view a

list of all songs in the folder/playlist.

Select a song from the list. Once

selected, Files/Folders/Playlists

Mode displays. The playlist option

would only be available if the device

has playlist.

To use the USB music menu:

1. Touch the center button to go to

the main list menu. The system

will start reading the disc.

Infotainment System 35

2. Once the disc has been read into

the system, touch USB. 3. Touch Files, Folders, or Playlists

to show a list of songs stored on

the USB device.

4. Touch to play the desired song.

36 Infotainment System

Touch the single scroll arrows on

the side of the screen to scroll

through the list. Touching the double

scroll arrows will scroll the list in

10 percent increments.

Eject: Touch when USB is to be

removed. A message displays

to safely remove it.

If the USB is disconnected without

touching Eject, the ﬁles could

become corrupted.

Infotainment System 37

Playing from an iPod

iPod

is a trademark of Apple Inc.,

registered in the U.S. and other

countries.

This feature supports the following

iPod models:

•iPod (5th generation)

•iPod Nano (1st generation

•iPod Nano (2nd generation)

•iPod Nano (3rd generation)

•iPod Classic

•iPod Touch

Video streaming or album art will

not be supported from the iPod.

For proper operation, make sure the

iPod has the latest ﬁrmware from

Apple

. iPod ﬁrmware can be

updated using the latest iTunes

application.

For more information, visit

www.apple.com/itunes

To connect and control an iPod,

connect one end of the standard

iPod USB cable to the iPod’s dock

connector. Connect the other

end to the USB port, depending on

the vehicle, in the center console

or instrument panel in the APO

connection on the passenger side.

iPod music information displays

on the radio’s display and begins

playing through the vehicle’s

audio system.

The iPod battery recharges

automatically while the ignition is on

or in the accessory position.

When the ignition is turned off while

an iPod is connected using the

iPod USB cable, the iPod battery

stops charging and the iPod

automatically turns off.

If the iPod is a model that is not

supported, it can still be listened to

in the vehicle by connecting it to

the Auxiliary Input Jack using

a standard 3.5 mm (1/8 inch) stereo

cable. See Auxiliary Devices on

page 41.

iPod Music Menu

Once the iPod has been connected,

the main music menu appears.

Select any of the following buttons

on the iPod Music Menu to

display the corresponding screen:

Playlist: Select this button to

view the playlists that have been

stored on the iPod. Select a playlist

name to view a list of all songs

in the playlist. Select the desired

song from the list. Once a song has

been selected “Playlist Mode”

appears on the iPod main screen to

show that music is playing from a

playlist.

Artist: Select this button to view

the artists that have been stored on

the iPod. Select an artist name

to view a list of all songs by

the artist. Select the desired song

from the list. Once a song has been

selected “Artist Mode” appears

on the iPod main screen to show

that music is being played from

a speciﬁc artist.

38 Infotainment System

Album: Select this button to view

the albums that have been stored on

the iPod. Select an album name

to view a list of all songs on

the album. Select the desired song

from the list. Once a song has

been selected “Album Mode”

appears on the iPod main screen to

show that music is being played

from a speciﬁc album.

Genres: Select this button to view

the genres that have been stored

on the iPod. Select a genre name to

view a list of all songs of that

genre. Select the desired song from

the list. Once a song has been

selected “Genre Mode” appears on

the iPod main screen to show

that music is being played from a

speciﬁc genre.

Composers: Select this button to

view the composers that have

been stored on the iPod. Select a

composer name to view a list

of all songs of that composer. Select

the desired song from the list.

Once a song has been selected

“Composer Mode” appears on the

iPod main screen to show that music

is being played from a speciﬁc

composer.

Audio Book: Select this button to

view the audio books that have

been stored on the iPod. Select an

audio book name to view a list

of all songs of that genre. Select the

desired song from the list. Once a

song has been selected “Audio Book

Mode” appears on the iPod main

screen.

Audio Book will only appear as a

valid category if this option is on

the iPod.

Podcasts: Select this button to

view the podcasts that have been

stored on the iPod. Select a name to

view a list of all songs of that

genre. Select the desired song from

the list. Once a song has been

selected “Podcast Mode” appears

on the iPod main screen.

Podcasts will only appear as a

valid category if this option is on

the iPod.

To use the iPod music menu:

1. Touch the center button to go to

the main list menu.

Infotainment System 39

2. Touch Files, Folders, or Playlists

to show a list of songs stored on

the iPod device.

3. Touch to play the desired song.

Eject iPod: Select this button

to remove the iPod. If the iPod is

disconnected without selecting

this button, the ﬁles on the iPod

could be corrupted.

Audio Book

Audiobooks can be downloaded

from iTunes

or if in .mp3.

After inserting the USB or iPod, the

following screen displays:

1. Touch the center button to go to

the main list menu.

40 Infotainment System

2. Touch Audiobooks or Podcasts

to show a list of the media

stored on the iPod device.

3. Touch to play the desired media.

Auxiliary Devices

The navigation system has an

auxiliary input jack located in the

upper right corner of the faceplate.

This is not an audio output; do

not plug the headphone set into the

front auxiliary input jack. You can

however, connect an external audio

device such as an iPod, laptop

computer, MP3 player, CD changer,

or cassette tape player, etc. to

the auxiliary input jack for use as

another source for audio listening.

Drivers are encouraged to set

up any auxiliary device while the

vehicle is in P (Park). See

“Defensive Driving” in the Index of

your vehicles owner manual for

more information on driver

distraction.

Infotainment System 41

If your vehicle has rear audio/video

input jacks, located in the rear of

the center console, they can

be used as another source for

audio/video listening.

To use a portable audio player,

connect a 3.5 mm (1/8 inch) cable

to the auxiliary input jack. When

a device is connected, the system

will detect and automatically

begin playing audio from the device

over the vehicle’s speakers.

If a device is connected and you are

listening to another source (FM,

CD, MP3, etc.), press the AUDIO

key then press the AUDIO key

repeatedly until AUX is selected or

touch the AUX screen button.

An auxiliary device must be

connected for the AUX screen

button to appear as an option to

select or the vehicle must have rear

auxiliary jacks. See “Rear Seat

Entertainment System” in the Index

of your vehicle’s owner manual

for more information on the

rear auxiliary jacks.

Navigation

Using the Navigation

System

This section presents basic

information needed to operate the

navigation system.

Use the hard keys located on the

navigation system along with the

available touch-sensitive screen

buttons on the navigation screen to

operate the system. See “Hard Keys”

after for more information.

Once the vehicle is moving, various

functions will be disabled to

reduce driver distractions.

Hard Keys

The following hard keys are located

on the navigation system:

O(Power/Volume): Press this

knob to turn the system on and off.

Turn the knob to increase or

decrease the volume to the audio

system.

If your vehicle has the Rear Seat

Entertainment (RSE) and Rear Seat

Audio (RSA), press and hold this

knob for more than two seconds to

turn off the navigation system,

the RSE, and RSA.

f(Tune/Speaker

Adjustment): Press this knob to

access the Sound screen to

adjust bass, midrange, treble, and

equalization or Digital Signal

Processing (DSP), if the vehicle has

the Bose

sound system. Turn

the tune knob to go to the next or

previous radio station. See AM-FM

Radio on page 14 and Satellite

Radio on page 21 for more

information.

Z(CD/DVD Eject): Press the

eject button to eject CDs or DVDs.

NAV (Navigation): Press this

key to view your vehicle’s current

position on the map screen.

Each press of this key will cycle

through Full Map and the tab

that displays the current audio

42 Infotainment System

source (AM, FM, CD, etc.). Full Map

displays the screen in full map

view. Selecting the audio tab will

split the screen between the

map screen and the current audio

source screen menu. See “Audio”

under AM-FM Radio on page 14 and

Satellite Radio on page 21 for

more information.

DEST (Destination): Press this key

to access the Destination Entry

screen to plan a destination or to

change the search area. See

Destination on page 65 for more

information.

RPT (Navigation Repeat): Press

this key to repeat the last voice

guidance prompt.

FAV (Favorite): Press this key to

access the preset stations. See

“Storing Radio Station Presets”

under AM-FM Radio on page 14 and

Satellite Radio on page 21 for

more information.

AUDIO: Press this key to access

the full Audio screen to change AM,

FM, XM™ Satellite Radio Service

(if equipped), CD, DVD (if

equipped), and auxiliary input. See

“Audio” under AM-FM Radio on

page 14 and Satellite Radio

on page 21 for more information.

MENU: Press this key to adjust

features for sound, radio, navigation,

and the display. See Navigation

Menu on page 53 for more

information.

¨SEEK / ©SEEK: Press the

seek arrows to seek and scan radio

stations, to seek tracks on a CD,

and to seek chapters on a DVD. See

AM-FM Radio on page 14,Satellite

Radio on page 21, and CD/DVD

Player on page 24 for more

information.

Touch-Sensitive Screen

Buttons

Touch-sensitive screen buttons are

located on the screen. When a

screen button has been selected, a

beep will sound. Screen buttons

are highlighted when a feature

is available.

Alpha-Numeric Keyboard

Letters of the alphabet, symbols,

punctuation, and numbers,

when available, will display on the

navigation screen as an alpha

or numeric keyboard. The alpha

keyboard will display when the

system requires entry of a city or

street name.

All characters are touch-sensitive

screen buttons. Touch a character to

select it.

A-Y (Accent Alphabet): Select this

screen button to select letters

with accent symbols. This button

may toggle to A-Z.

Infotainment System 43

A-Z (Alphabet): Select this screen

button to select letters from the

alphabet. This button may toggle

to A-Y.

0-9 (Numbers): Select this screen

button to select numbers.

U(Space): Select the space

screen button to enter a space

between characters or the words of

a name.

q(Backspace): Select the

backspace screen button if an

incorrect character has been

selected.

To make name selections easier,

the system will only highlight

the characters that can follow the

last one entered. For example, if

a Z is entered, a T may not be

available for selection.

If a name does not display after

entry, it may need to be entered

differently, the map DVD disc may

not contain that information, or

the correct search area has not

been selected. See Database

Coverage Explanations on page 80

for more information or Destination

on page 65 to change the search

area.

Maps

This section includes basic

information needed to know about

the map database.

Map Coverage

The maps are stored on a DVD.

The 48 contiguous United States,

along with Hawaii, Alaska, and

portions of Canada are contained

on one disc.

Refer to the “Navigation System

Map Disc” manual to view a detailed

explanation of map coverage and

detailed city lists in each region. This

manual will be in the map DVD

case when the vehicle is delivered

from the factory.

Installing the DVD Map Disc

When a DVD Map Disc is installed,

noise from the disc may occur,

this is normal system operation.

The navigation system in this vehicle

uses a DVD to store map

information. When the system loads

data from the disc, you may hear

a very slight buzz sound from

the navigation system. The sound is

similar to that of a CD player

seeking through different tracks.

This is normal operation and

may occur more frequently with the

use of XM NavTraffic.

Your dealer may have installed the

map DVD. If the map DVD was

not installed, do the following to

load it:

1. Turn the ignition on.

2. Press the O(power) knob to

turn the navigation system on

or press the NAV, DEST,

or MENU hard keys. If the MENU

hard key is selected, press

44 Infotainment System

and hold until the NAV screen is

active, or select the NAV tab

manually.

3. Touch the OK screen button to

agree to the Caution screen, if

it appears. If the map is in

split screen mode, you must push

the NAV tab button to get the

full map screen.

A. Map DVD Slot

4. Touch the Insert Map Disc

screen button. The screen will tilt

to access the map DVD slot.

5. Load the map DVD partway into

the slot. The system will pull

it in.

6. Once the map DVD is loaded,

touch the Close screen button.

The screen will close.

7. Set the search area. See

“Setting the Search Area” under

Using the Navigation System

on page 42 for more information.

Ejecting the DVD Map Disc

When the DVD map disc is

not loaded, you will not be able to

use the navigation portion of

the system.

1. Press the MENU key to enter the

Menu options, then press the

MENU key repeatedly until Nav

is selected or touch the Nav

screen button.

2. Touch the Map Database

Information screen button.

3. Touch the Change screen

button. The screen will tilt,

exposing the map DVD slot and

the map DVD will eject. Pull

the disc out.

4. Touch the Close screen button.

The screen will close.

Handling the DVD Map Disc

When handling the DVD map

disc, be careful of the following:

•Handle the disc very carefully to

avoid contamination or ﬂaws.

Signals may not read out properly

if the disc gets contaminated

or ﬂawed.

•If the disc gets soiled, use a soft

cloth to gently wipe it out from

the center of the disc to the

outside. Do not use photographic

record cleaner, solvents, or

other cleaners.

•Do not use the disc to rest on

while writing or drawing using

any writing utensil or attach

a seal to any of the sides or

the disc.

Infotainment System 45

•Do not keep the disc in direct

sunlight, high temperatures,

or humidity.

•After using the disc, place it back

into the original case.

DVD Map Disc Messages

If Disc Read Error appears on the

display and/or the disc comes out, it

could be for one of the following

reasons:

•If the map DVD disc was

installed into the audio CD/ video

DVD slot. See “Installing DVD

Map Disc” earlier in this section.

•It is very hot. When the

temperature returns to normal,

the disc should work.

•You are driving on a very rough

road. When the road becomes

smoother, the disc should work.

•The disc is dirty, scratched, wet,

or upside down.

•The air is very humid. If so, wait

about an hour and try again.

Map Adjustments

The system allows you to adjust the

scale of view on the map. Also,

as you drive, the map will scroll

automatically based on the direction

of travel.

Map Scales

V/U(Zoom In/Zoom Out):

Touch the zoom in or out screen

buttons or the scale on the bar to

change the level of map detail. The

scale will appear on the screen once

the zoom in or zoom out screen

buttons are selected. The system

will adjust the map accordingly. The

scale of a map can range from 150 ft.

(50 m) to 250 mi. (400 km). To

change from English or metric, see

“Driver Information Center, DIC

Operation and Displays” in the Index

of your vehicle’s owner manual.

Scrolling the Map

Touch anywhere on the map screen

and the scroll symbol will appear.

Use this feature to scroll across

the map.

Move your ﬁnger in any direction on

the map screen and the map will

continue to scroll in that direction

until you remove your ﬁnger.

If scrolling while your vehicle is in

P (Park), the system will scroll

initially at a slower rate. It will

increase if you continue touching

the map screen.

If scrolling while your vehicle is in

motion, you have one scroll

speed and a limited distance to

scroll. You have to keep touching

the map screen to scroll for a longer

distance.

46 Infotainment System

If you have used the scroll feature

to scroll the map and your

vehicle icon becomes lost, press the

NAV (Navigation) key to return to

the current vehicle location on

the map.

You can use the scroll feature on

the map to set a destination.

See “Pick from Map” under

Destination on page 65 for more

information.

When scrolling on the map without

a planned route, press the GO

screen button to calculate the route

from your current position to the

destination mark.

Navigation Symbols

The following symbols are the most

common symbols that will appear

on a map screen.

Your vehicle is shown as this

symbol. It indicates the current

position and heading direction of

your vehicle on the map.

The destination symbol will appear

on the map, after a route has

been planned, marking your ﬁnal

destination.

The waypoint symbol will display on

the map after a waypoint has

been added to your route.

The waypoint symbol will be

numbered from one through

three depending on how many

intermediate waypoints have

been set.

The distance to destination symbol

indicates the distance to your

ﬁnal destination.

This symbol only appears when

time is not available or when you are

scrolling on the map.

Infotainment System 47

The distance and time to destination

symbol indicates the distance and

the estimated time remaining to your

ﬁnal destination.

The straight line to distance symbol

indicates the straight-line distance

to your destination.

This symbol will appear before you

start driving on the route or if

you are on a road where navigation

guidance cannot be given.

The north up symbol indicates the

map with North Up, known as North

Up mode.

While in North Up mode, the vehicle

icon will follow the north direction

on the map regardless of which

direction the vehicle is traveling.

Select this screen symbol to switch

between North Up and Heading

Up modes.

48 Infotainment System

The heading up symbol indicates

the map with the vehicle travel

direction up, known as Heading

Up mode.

The shaded triangle indicates the

North direction. While in Heading Up

mode, the direction your vehicle is

traveling will always be at the

top of the map screen. The vehicle

icon will always be headed in

the direction your vehicle is

traveling. Select this screen symbol

to switch between Heading Up

and North Up modes.

The No GPS symbol will appear

when your vehicle is not receiving a

Global Positioning System (GPS)

satellite signal.

See Global Positioning System

(GPS) on page 77 for more

information.

Select the MARK screen button to

store the location on the screen

in your address book.

The system will automatically store

the point in the address book.

See “Adding Destinations to the

Address Book” under Destination on

page 65 for more information.

Displaying Points of Interest (POI)

on the Map Screen

Select the POI screen button to

display or delete POI icons from

the map.

Displaying POI icons on the map let

you know where POIs (i.e.

restaurants, gas stations, etc.) are

located. This screen will appear after

selecting the POI screen button.

Infotainment System 49

Select one of the POI categories to

display or to delete POI icons

from the map screen. Once a

category has been selected, the

POI icon will display at the top of the

screen. Five categories can be

selected to display on the map

screen. When a category is selected

those POI icons will display on

the map. Press the POI screen

button again to add more POI icons.

More: Select this screen button to

view more POI categories.

POI Close to: Once a category has

been selected, select this screen

button to display the list of available

POIs for the selected POI categories.

The list provides the POI icon, the

name, the direction, and the distance

to the POI from your vehicles current

position. Use the scroll arrows to

move up and down the list. Use the

Sort by DIST. (distance), Icon,

Name, and, on Route as desired.

Go: Press this screen button, next

to the desired POI, to make this

POI a destination or a waypoint.

Select a POI name to receive

information about the POI. From this

screen you can select: Add to

Address Book, Go, Map, or Call

(if OnStar

personal calling is

activated).

Add to Address Book: Press this

screen button to add this POI to

the address book. See “Nav” under

Navigation Menu on page 53 for

information on editing address book

entries.

Go: Press this screen button to

make this POI a destination

or a waypoint.

Call: Select to initiate a call using

the OnStar Hands-Free system. The

Call button is only available if OnStar

personal calling is activated. For

more information about OnStar

Hands-Free Calling, see the OnStar

Owner Guide.

50 Infotainment System

Map: Press this screen button to

display the map showing the

location of the POI.

Show: Select this screen button to

update the map screen and the

list once a category has been

selected.

Show POI: Select ON to display

the POI icons on the map screen.

Select OFF to remove the POI icons

from the map screen.

List all Categories: Select this

screen button to list all POIs sorted

alphabetically.

Clear: To delete a category, do one

of the following:

•To delete the last added POI

category, select the Clear

screen button.

•To delete a speciﬁc POI

category:

1. Select the category.

2. Select the subcategory.

3. A pop-up conﬁrmation will

display. Select the Delete

screen button, the map screen

will display with that POI

category deleted.

Clear All: Select this screen button

to clear all selected POI categories.

A pop-up conﬁrmation will display.

Select the Delete screen button, the

map screen will display with all

POI categories deleted.

Driving on a Route

When a destination has been routed

and you are driving on route, the

map screen will automatically

display the next maneuver.

This next maneuver pop-up will

display the next maneuver direction

and how many miles or kilometers

you are from it.

Infotainment System 51

Dual Mode

This dual screen symbol displays

when the screen is in dual mode.

Dual mode displays the route on half

of the screen and a maneuver or

Interstate Exit list on the other half.

The Interstate Exit list advises of

approaching exits. Press this button

to switch between dual screen

and full screen which displays the

entire route.

When approximately 1/2 mi. (.08 km)

from the next maneuver, or two miles

while on expressways, the screen

displays the name and a detailed

view of the next maneuver. Touch

the dual mode button to hide the

detailed turn maneuver view for this

maneuver only.

Auto Reroute

When your destination is set and

you are off the planned route,

the system will automatically plan a

new route and begin to reroute.

You will be able to see the

new route highlighted on the screen.

Traveling Across Regions

If you plan to drive across many

states, you may have to change the

region selected to represent the

area you are traveling to. To change

the region, do one of the following:

•Change the selected region

in the search area when you get

closer to your destination.

See Destination on page 65.

•Change the selected region in

the search area when entering

your destination and route

settings. See Destination on

page 65.

52 Infotainment System

For example, if you were

traveling from Michigan to

Florida, change the region

currently selected in the search

area to Florida. Enter a

destination in Florida under the

Destination Entry menu.

Navigation Menu

Press the MENU hard key to adjust

several of your system’s features

and preferences. The last selected

menu screen will be the screen

that displays; Sound, Radio,

Nav (navigation), Display or Time.

Sound

Press the MENU key to enter the

Menu options, then press the MENU

key repeatedly until Sound is

selected or touch the Sound screen

button to make speaker and

equalization or DSP (Digital Signal

Processing) adjustments. See

AM-FM Radio on page 14 and

Satellite Radio on page 21 for more

information.

Radio

Press the MENU key to enter the

Menu options, then press the MENU

key repeatedly until Radio is

selected or touch the Radio screen

button to make changes for radio

information displayed, preset pages,

XM™ categories, and Automatic

Volume Control or Bose

AudioPilot

. See AM-FM Radio on

page 14 and Satellite Radio on

page 21 for more information.

Nav (Navigation)

Press the MENU key to enter the

Menu options, then press the MENU

key repeatedly until Nav is selected

or touch the Nav screen button.

Infotainment System 53

Off-Road Mode

To turn the Off-Road Mode on or

off, do the following:

1. Press the MENU key.

2. Press the Nav screen button.

3. Press the #Off-Road Mode ON

or OFF screen buttons. The

active button will be highlighted.

When the off-road mode is

turned on, the navigation

system will show the path being

traveled by the vehicle when

not on a marked road. This path

will be a simulation since the

map database coverage will not

have these roads on the

DVD. This path will be stored in

the navigation system’s

memory, see “Previous

Destination” under Destination

on page 65 for more information.

Voice Prompt

>Voice Prompt: Touch the Voice

Prompt screen button to change

the volume of the voice prompts

or to turn the voice prompts on

and off.

Voice Prompt Volume: Touch

the + (plus) or −(minus) screen

buttons to increase or to decrease

the volume of the voice prompts.

Turn voice turn

instruction: Touch the ON or

OFF screen buttons to turn voice

instructions on and off while

traveling on a planned route.

Route Preference

Touch the %Route Preference

screen button to change route

options when the system calculates

a route.

Allow highway: This feature allows

the system to use major roads

when calculating a planned route.

Allow toll road: This feature allows

the system to use toll roads when

calculating a planned route.

Allow ferry: This feature allows the

system to use ferries when

calculating a planned route.

Allow time and seasonal

restricted road: This feature allows

the system to use time restricted

and seasonal roads when

calculating a planned route.

54 Infotainment System

Edit Address Book

How to Add

To add an address to the address

book, see “Adding Destinations

to the Address Book” under

Destination on page 65.

Edit/View

To edit the name of an address

book:

1. Select the MENU hard key.

2. Select the NAV screen button.

3. Select the *Edit/View Address

Book screen button.

4. Select the Address book entry.

5. Touch the Name screen button

and use the alpha keyboard to

edit or add the name.

6. Touch the OK screen button to

save your changes.

To add or change the phone

number of an address book entry:

1. Select the MENU hard key.

2. Select the NAV screen button.

3. Select the *Edit/View Address

Book screen button.

4. Select the address book entry to

change.

5. Touch the Phone # screen button

and use the numeric keyboard to

input or change the phone

number.

6. Touch the OK screen button to

save your changes.

Infotainment System 55

To change the map icon of an

address book entry:

1. Select the MENU hard key.

2. Select the NAV screen button.

3. Select the *Edit/View Address

Book screen button.

4. Select the address book entry to

change.

5. Select the Icon screen button.

6. Select an icon from the list.

To add a voice tag to an address

book entry:

1. Select the MENU hard key.

2. Select the NAV screen button.

3. Select the *Edit/View Address

Book screen button.

4. Select the Add Voice tag screen

button.

5. The system will ask for you to

state the name. You will have

ﬁve seconds to state the

name. The system will respond

back with the name.

To delete an address book entry:

1. Select the MENU hard key.

2. Select the NAV screen button.

3. Select the *Edit/View Address

Book screen button.

4. Select the address book entry to

delete.

5. Press the Delete screen button

to delete the address book

entry.

To delete the entire address book:

1. Select the MENU hard key.

2. Select the NAV screen button.

3. Select the *Edit/View Address

Book screen button.

4. Select the address book entry to

delete.

5. Press and hold the Delete

screen button until the delete all

address book entries pop-up

conﬁrmation displays. Select Yes

to delete; select No to cancel

the operation.

Map Database Information

To change the map DVD and to

view the coverage areas of the

map DVD:

1. Press the Menu hard key.

2. Select the Nav tab.

3. Select the Map Database

Information screen button.

56 Infotainment System

Change: Touch this screen button

to eject or change the map DVD.

The screen will tilt, exposing

the map DVD slot and, if loaded,

the map DVD will eject. Pull the map

DVD out. Insert the map DVD

partway into the slot. The system

will pull it in.

A. Map DVD Slot

Once the map DVD is loaded touch

the Close screen button. The

screen will close.

Once the screen is closed touch the

OK screen button to proceed to

the navigation system. See Using

the Navigation System on page 42.

Coverage: Touch this screen

button to view the areas covered by

the map DVD.

Touch the up and down arrow

screen buttons to view each region

of the map DVD. The screen will

display the major cities for the

selected region.

XM NavTraffic™ (USA and

Canada)

The vehicle’s navigation system

may have an XM NavTraffic™

receiver. XM NavTraffic™ is a

subscription service provided via

XM™ Satellite Radio. XM

NavTraffic™ provides real-time

traffic information fully integrated to

the navigation system to display

current traffic conditions for a

driver’s chosen route and

surrounding area. XM NavTraffic™

allows drivers to make the most

informed, timesaving routing

decisions.

If the Traffic touch screen button is

pressed or if an attempt is made

to turn on the traffic display in

the Navigation Setup Menu without

a subscription, a warning screen

displays indicating that XM traffic is

not activated.

Infotainment System 57

Three types of traffic information for

major roadways are displayed on

the navigation system:

•Unscheduled traffic incident data,

such as accidents and disabled

vehicles

•Scheduled traffic incident data,

such as road construction and

road closures

•Traffic ﬂow information (rate of

speed data)

Traffic information is delivered to the

vehicle by the XM™ Radio

satellites. XM NavTraffic™ makes it

possible for the navigation system

to provide continuously updated

traffic information personalized for a

driver’s needs.

XM NavTraffic™ currently

broadcasts the traffic information for

many markets nationally, and the

service may be available in

more cities in the future. Visit

xmnavtraffic.com for more details on

local coverage.

A service fee is required in order to

receive the XM NavTraffic™

service.

Turning XM NavTraffic™ On

and Off

To turn traffic on or off:

1. Press the Menu hard key, then

press the Menu key repeatedly

until Nav is selected or press the

Nav screen button.

2. Touch the Traffic Options button.

3. Touch the Traffic button. This

button is highlighted when it

is active.

Selecting Alert for Approaching

Traffic Events enables the

system to show a pop-up screen

that notiﬁes of possible traffic

issues ahead.

When this feature is highlighted,

while traveling on a route,

accidents located on the route

are indicated and can be

avoided.

58 Infotainment System

Traffic Icon

The Traffic Icon appears on the

Traffic Tab, next to the word

Traffic, when traffic is found in the

local area.

The Traffic Icon has three different condition displays. These are:

Condition Traffic Status Icon

•No XM NavTraffic™ subscription.

•No Traffic is found in the local

area.

•The Traffic Feature is turned off.

Traffic events are in the area, but

none are on route.

Traffic events are on route.

Infotainment System 59

Locations and Information of

Traffic Conditions

The system may take some time to

sort the information. The list of

traffic conditions display in the order

of distance from the vehicle, at a

minimum of approximately

16 mi (25 km). If traveling on a

planned route, the list can be ﬁltered

to see traffic conditions along the

planned route. Not all traffic

conditions may be listed.

To view the traffic condition location

and information on the map:

1. Press the NAV key, then press

the NAV key repeatedly until

Traffic is selected, or touch the

Traffic screen button. A list

of traffic conditions with the

direction and distance from the

vehicle’s current position

displays.

2. Select a traffic condition to get

more detailed information of

the event.

Options

Select the Options screen button.

A Traffic Options menu displays.

Select the desired traffic related

option.

Traffic: Select to enable or disable

the traffic function.

Show Traffic ICONS: Select to

display traffic icons on the map

screen. This function allows which

traffic information displays.

60 Infotainment System

Traffic Flow Status — This touch

screen button is used to enable or

disable the green, yellow, red

and orange arrows shown beside

the roads and used to show

the traffic ﬂow or extent of a traffic

event.

•Black indicates a closed road

segment.

•Red indicates signiﬁcantly

impaired traffic ﬂow with average

speed less than 25 mph.

•Yellow indicates slightly impaired

traffic ﬂow with average speed

between 25 and 45 mph.

•Green indicates normal traffic

ﬂow with average speed

above 45 mph.

Traffic ﬂow data arrows display on

the map when scaled up to

eight miles.

Closed Road, Traffic Delays,

Incidents, and Advisories — These

four touch screen buttons are

used to turn on and to show traffic

event ICONS that appear on

the map screens.

Traffic Event Display Categories

The following are traffic condition

categories and symbols that

can appear on the display:

Category 1, Road Closure:

q(Road Closed): Road and/or

ramps closed.

Category 2, Traffic Delayed:

o/n(Stopped/Slow

Traffic): Traffic stopped, stop and

go traffic, delayed and congested

traffic.

Category 3, Incidents:

p(Alert): Object in the roadway,

disabled vehicle, or dangerous

road conditions.

t(Accident): Roadway

obstructed due to accident.

s(Road Works): Delayed traffic

due to construction.

Category 4, Advisories:

j(Road Condition): Delayed or

stopped traffic, lane blocked or

closed due to a road condition.

k(Weather): Heavy rain, snow, or

fog weather condition.

Infotainment System 61

m(Parking): Available parking

area.

l(Information): Special event,

general information, or warning.

Alert for Approaching Traffic

Events: WhenOn,ifan

approaching traffic event is within

the alert range, one of two traffic

alert pop-up screens display:

•With no route planned, while on

expressways, Approaching

Traffic Event without Avoid

screen displays.

•With route planned, Traffic Event

on Route screen displays.

If the Alert for Approaching Traffic

Events is Off, the alert pop-up

screen does not display and no

voice announcement when

approaching traffic.

On-Route

Select the On Route touch screen

button to display all events ahead on

the current active route. If no

traffic events have been reported on

route, this list will be empty.

Avoid List

Press to show previously avoided

incidences. Select an incidence

to cancel it from being on the

avoided list.

62 Infotainment System

Scrolling to Traffic Events on

the Map

While scrolling the map, traffic

condition icons may appear. To

receive information about the traffic

condition, place the cross hairs over

the traffic condition icon. After

selecting the INFO (information)

screen button, the type of traffic

condition, the street name, and a

description of the traffic condition

displays. See “Scrolling the Map”

under Maps on page 44 for more

information.

Press the NAV hard key to return to

the normal full map screen.

Detailed Traffic Event Screens

There are different types of detailed

traffic event screens. Each screen

is a variance of the one shown

on the Traffic Event Screen.

The Traffic Event screen can be

displayed by:

•Scrolling to an event on the map

and then pressing INFO.

•Selecting a traffic event listed on

the Traffic Event List screen.

•Selecting a traffic event listed on

the Traffic On Route Screen.

Back, Map, More, and Avoid

These buttons have common

functions across all three Detailed

Traffic Event screens.

Back: Press to return to the

previous screen.

Map: Press to show the related

traffic event on the map. If selected,

the Map Traffic Event Icon screen

displays.

More: Press to display more of the

traffic event description.

Avoid: This button is used to avoid

the location of an event on the

route. If selected, a new route is

calculated and the related traffic

event is avoided. After the new route

has been calculated, the navigation

system goes to the full map

screen and shows the new route.

Traffic Event Screen

Infotainment System 63

The Avoid button is only available if

the route ahead and in the Traffic

On Route List.

Traffic Voice Prompts

If the voice prompts are on,

whenever an Alert for Approaching

Traffic is displayed, the system

gives the related voice prompt. The

content of the voice prompt

depends on actual traffic event data.

The RPT (Repeat) hard key is for

navigation traffic maneuvers only. It

is not used to repeat traffic

prompts. During a traffic voice

prompt, if RPT is pressed, the

current prompt playback cancels.

Anything that cancels the Alert

for Approaching Traffic, also cancels

the related voice prompt.

Traffic prompts are disabled during

OnStar

or Voice Recognition

activity.

Display

Press the MENU key to enter the

Menu options, then press the MENU

key repeatedly until Display is

selected or touch the Display screen

button.

Display Off

Touch this screen button to turn the

display off. Press any hard key to

view the display.

Brightness/Contrast/Mode

Touch this screen button to change

the brightness, contrast, and

mode of the display.

](Brightness): Touch the + (plus)

or −(minus) screen buttons to

increase or decrease the brightness

of the screen.

_(Contrast): Touch the + (plus)

or −(minus) screen buttons to

increase or decrease the contrast of

the screen.

64 Infotainment System

Auto (Automatic): Touch this

screen button for the system

to automatically adjust the screen

background depending on exterior

lighting conditions.

At night, the brightness can be

adjusted with the vehicle dimming

knob near the headlamp switch.

Night: Touch this screen button

and the system will make the map

background darker.

Day: Touch this screen button and

the system will make the map

background brighter.

Setting the Clock

Press the MENU key to enter the

menu options, then press the MENU

key repeatedly until the time is

selected or touch the time screen

button, then press the Set

screen button.

Hours: Press the −(minus)

or + (plus) signs to decrease or

increase the hours.

Minutes: Press the −(minus)

or + (plus) signs to decrease or

increase the minutes.

12/24 Format: Select the 12 screen

button for standard time; select

the 24 screen button for military

time.

Destination

Press the DEST key to access the

Destination Entry screen. From

this screen, you can select

from several options to plan a route

by entering destination points.

Search Area

The Destination Entry screen allows

you to select the area included in

the search for your destination.

A map that divides the

48 contiguous United States,

along with Hawaii, Alaska, and a

part of Canada into 14 regions

is displayed.

Before selecting a method of

destination entry, review the search

area map to make sure your

destination is located in the

highlighted region.

Infotainment System 65

Touch the Change Search Area

screen button to view the Search

Area screen. Touch the numbered

screen button to the left of the

search area map that corresponds

with the numbered region and

to view a list of states included in

the region selected. The selected

area will be highlighted on the map.

Touch the down arrow to select

CAN (Canada). Touch the

back screen button to return to the

Destination Entry screen and to

store the selected region.

To enter a destination, choose from

one of the following destination

entry methods:

Address Entry

6Address Entry: The address

entry destination method allows

you to enter an address by providing

the system with a city name or a

street name.

If you are having trouble ﬁnding a

city or a street name, do the

following:

•Input the street name ﬁrst

instead of the city name, or vice

versa.

•Input more characters or reduce

the amount of characters to

reduce or expand the available

options.

To enter a destination by entering

the city name ﬁrst, do the following:

1. Press the DEST hard key.

2. Select the 6Address Entry

screen button.

3. Select the City name button.

4. Enter the city name or touch the

Last 5 Cities screen button.

The Last 5 Cities screen

will display a list of the last ﬁve

city names that had been

entered. Select a city from the

list and it will appear in the

City name area.

If using the alpha keyboard,

ﬁnish entering the city name. If

ﬁve or less names are available,

a list will display. If more than

ﬁve are available, there will be a

screen button with a number

in it, it represents the number of

available cities. Select this

button to view the list and select

a city.

66 Infotainment System

5. Once a city has been selected

the Street name category will

automatically be selected

for entry.

Start entering the street name. If

ﬁve or less names are available,

a list will display. If more than

ﬁve are available, there will be a

screen button with a number

in it, it represents the number of

available streets. Select this

button to view the list.

6. Select the street name with the

correct preﬁx (Dr., Ln, St., etc.)

from the list.

7. Once a street has been selected,

the numeric keyboard will

display, allowing you to enter the

house number. The system

will display the house number

range that is available for

the street.

8. Select the Go screen button. The

map screen, with the destination

marked, will display.

9. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

10. Select the Start Guidance

screen button. You are now

ready to start your route.

See “Getting Started on Your

Route” later in this section

for more information.

To enter a destination by entering

the street name ﬁrst, do the

following:

1. Press the DEST hard key.

2. Select the 6Address Entry

screen button.

3. Select the Street screen button

and start entering the street

name.

If ﬁve or less names are available,

a list will display. If more than ﬁve

are available, there will be a

screen button with a number in it,

it represents the number of

available streets. Select this

button to view the list.

4. Select the street name with the

correct preﬁx from the list (Dr.,

Ln., St., etc.).

5. Once a street has been selected

the City name category will

automatically be selected

for entry.

If ﬁve or less cities are available

for the selected street, the system

will display the list of cities. If

more than ﬁve cities are available

the system will display the alpha

keyboard. Start entering the city

name. If ﬁve or less names are

available, a list will display. If

more than ﬁve are available,

there will be a screen button with

a number in it, it represents the

number of available cities. Select

this button to view the list and

select a city.

6. Once a city has been selected,

the numeric keyboard will display,

allowing you to enter the house

number. The system will display

the house number range that is

available for the street.

Infotainment System 67

7. Select the Go screen button. The

map screen, with the destination

marked, will display.

8. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

9. Select the Start Guidance screen

button. You are now ready to

start your route.

See “Getting Started on Your

Route” later in this section

for more information.

To enter a destination by entering a

cross street, do the following:

1. Press the DEST hard key.

2. Select the 6Address Entry

screen button.

3. Select the Street screen button

and start entering the street

name.

If ﬁve or less names are

available, a list will display. If

more than ﬁve are available,

there will be a screen button

with a number in it, it represents

the number of available

streets. Select this button to view

the list.

4. Select the desired street name

with the correct preﬁx from the

list (Dr., Ln., St., etc.).

5. Once a street has been selected

the Cross Street screen button

will become available. Select the

Cross Street button and start

entering the cross street name.

If ﬁve or less names are

available, a list will display. If

more than ﬁve are available,

there will be a screen button with

a number in it, it represents

the number of available cross

streets. Select this button to view

the list.

6. Select the street name with the

correct preﬁx from the list (Dr.,

Ln., St., etc.). An Information

screen will automatically display.

7. Select the Go screen button. The

map screen, with the destination

marked, will display.

8. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

9. Select the Start Guidance screen

button. You are now ready to

start your route.

See “Getting Started on Your

Route” later in this section

for more information.

Point of Interest (POI)

The Point of Interest (POI)

destination entry method allows you

to select a destination from the

POI list.

68 Infotainment System

iPoint of Interest: Touch this

screen button to access the Point of

Interest (POI) screen. From this

screen you have two options

to select/enter a destination; enter

the name using the alpha keyboard

or select a category from the

category list.

To use the point of interest

destination entry method by entering

the name, do the following:

1. Press the DEST hard key.

2. Select the iPoint of Interest

screen button.

3. Enter the POI name.

If ﬁve or less names are

available, a list will display. If

more than ﬁve are available,

there will be a screen button with

a number in it, it represents

the number of available POIs.

Select this button to view the list.

4. Select the Go screen button next

to the POI. The map screen, with

the destination marked, will

display.

5. Select the route preference

(Fastest, Shortest, or Other). The

system will calculate and

highlight the route.

6. Select the Start Guidance screen

button. You are now ready to

start your route.

See “Getting Started on Your

Route” later in this section

for more information.

To use the point of interest

destination entry method by

selecting a category, do the

following:

1. Press the DEST hard key.

2. Select the iPoint of Interest

screen button.

3. Select the Browse POI screen

button to view the list of POI

categories.

4. Select a category, and then a

sub-category.

The system will display available

POI names in the selected

sub-category or if the list is too

long the system will display

the alpha keyboard.

If the alpha keyboard is

displayed, enter the POI name

until a list of available POIs

appear. There is a screen button

with a number in it, it represents

the number of available POIs.

Select this button to view the list

and select the POI.

Infotainment System 69

5. Select the Go screen button next

to the POI. The map screen, with

the destination marked, will

display.

6. Select the route preference

(Fastest, Shortest, or Other). The

system will calculate and

highlight the route.

7. Select the Start Guidance screen

button. You are now ready to

start your route.

See “Getting Started on Your

Route” later in this section

for more information.

Address Book

The address book entry method

allows you to select a destination by

selecting an address that has

been stored in your address book.

*Address Book: Touch this

screen button to access the Address

Book screen. From this screen

you can select an address

that already exists as the

destination.

To use the address book entry

method, do the following:

1. Press the DEST hard key.

2. Select the *Address Book

screen button.

A list of your address book

addresses will display.

3. Select the Go screen button next

to the destination. The map

screen, with the destination

marked, will display.

4. Select the route preference

(Fastest, Shortest, or Other). The

system will calculate and

highlight the route.

5. Select the Start Guidance screen

button. You are now ready to

start your route.

See “Getting Started on Your

Route” later in this section

for more information.

See “Adding Destinations to the

Address Book” later in this

section.

70 Infotainment System

OnStar

Destination Download

OnStar

Destination Download (if

equipped) is a service available

for OnStar* subscribers that makes

operating your navigation system

much simpler. It allows subscribers

to request and receive navigation

assistance on-the-go.

Using OnStar

Destination

Download

Press the blue OnStar button and

an Advisor can locate a

point-of-interest or an address and

download the necessary

information or coordinates to your

navigation system. Once the

destination is downloaded, the

navigation system will search for the

address in the mapping disc’s

database. When the address is

found, it will be shown on your

navigation system’s screen along

with the buttons described below.

•Select Go, the navigation system

calculates route(s). Select a

route (i.e. Shortest Route), and

Start Guidance.

•Select Map, the navigation

system displays the Destination

Map Screen.

•Select Call, the navigation

system initiates a call to

your destination with your

Bluetooth phone (if available)

or OnStar Hands-Free Calling

(if minutes are available).

•Select Add to Address Book, the

navigation system copies the

downloaded destination to

the address book and displays

the new address book entry.

•Select Back, the navigation

system cancels your OnStar

Destination Download and

returns to the previous screen.

The downloaded address will not

be added to the previous

destinations.

OnStar Download Screen

Start Guidance Screen

Infotainment System 71

Route Guidance Not Active

If an OnStar destination is

downloaded while route guidance is

not active, the navigation system

displays an OnStar Destination

Download Screen and operations

will continue as outlined in the Using

OnStar Destination Download

section:

Route Guidance Active

If OnStar downloads a destination

while route guidance is already

active, the navigation system adds

the downloaded destination as

the next waypoint in the existing

route. All features such as Call and

Add to Address Book will be

available for the waypoint. Refer to

the section on Waypoints for

more information.

Previous Destinations

Previous OnStar Destination

Downloads are saved under

Previous Destinations in the

navigation system where they can

be accessed or saved to the

address book.

Important Notes regarding OnStar

Destination Download:

•The map disc must be installed

in the radio for OnStar

Destination Download to function.

•If the navigation system is turned

off when the destination download

is attempted, the navigation

system will automatically turn

on and display the OnStar

Destination Download Screen.

The radio will remain on after

the download occurs.

•If the navigation system is turned

off when the destination download

is attempted, the navigation

system will automatically turn on

and display the OnStar

Destination Download Screen.

The radio remains on after the

download occurs.

•If OnStar downloads a destination

and the address is not found in

the mapping disc’s database and

routing by coordinates is not

available, the Go and Map

buttons gray out and routing will

not be available. Press the blue

OnStar button for further

assistance.

•The Call button grays out when

there is no phone number

available for your destination and

while connected to OnStar.

72 Infotainment System

Map Destination Screen

Functions

If the map screen is used to show

destination, it will have map

screen capabilities such as Go,

Mark, Zoom, Scroll, etc. The

address is shown at the top of the

screen.

Getting Started on Your Route

Once you have entered a

destination there are several

functions that can be performed.

Press the DEST hard key to access

the Route screen.

Turn List

Turn List: Touch this screen button

to view the list of turn maneuvers

for the entire route and to avoid

turns on the route.

Q/R(Scroll Arrows): Touch the

up and down arrow screen buttons

to scroll through the list of

maneuvers.

Avoid: Touch this screen button,

next to the adjacent street name, to

avoid the maneuver.

The map screen will display. Select

the Fastest, Shortest, or Other

screen buttons. Press the Start

Guidance screen button. The route

will re-calculate without the

selected avoided maneuver.

Destination Map Screen

Infotainment System 73

Avoid List: Select this screen

button to cancel an avoided turn.

The list of selected avoided turns will

display. Select the turn to cancel

the turn from being avoided.

r(Route Preview): Select this

screen button to preview the

entire route in either direction.

t(Reverse Skip): Select this

screen button to go back to the start

point or previous waypoint.

q/r(Reverse Scroll): Select

this screen button to scroll to

the start point or previous waypoint.

This button will toggle between

slow and fast speed.

j(Pause): Select this screen

button to pause the route preview,

while in reverse or fast forward

scroll.

r/[(Fast Forward

Scroll): Select this screen button to

scroll to the next waypoint or to

the ﬁnal destination. This button will

toggle between slow and fast

speed.

u(Fast Forward Skip): Select

this screen button to go to the next

waypoint or to the ﬁnal destination.

Detour

Detour: Select this screen button

from the Route screen, then

select to detour 1 mile, 3 miles,

or 5 miles (1 km, 3 km, or

5 km) around the current route. You

may also select to detour the

whole route if necessary. This option

is only available while you are

driving on your current planned

route.

Voice Prompt

Select this screen button from the

Route screen to turn voice prompts

on or off and to change the

volume of voice prompts. See “Nav”

under Navigation Menu on

page 53 for more information.

74 Infotainment System

Add Waypoint

Add Waypoint: Select this screen

button from the Route screen.

This feature allows you to add up to

three waypoints to the current

route, between your start point and

ﬁnal destination. Once a waypoint

has been added, the points can

be edited or deleted.

To add a waypoint:

1. Press the DEST hard key.

2. Select the Add Waypoint screen

button. This button will only

appear if a route has been

calculated.

3. Using the desired method of

entering a destination, enter

the waypoint. See “Destination”

previously for more information.

4. Select the route preference

(Fastest, Shortest, or Other). The

system will calculate and

highlight the route.

5. Select the Start Guidance screen

button. You are now ready to

start your route.

6. To add the second and third

waypoints, press the DEST

hard key, then select the Add

screen button, where you would

like the next waypoint to fall

on the route.

7. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

8. Select the Start Guidance screen

button. You are now ready to

start your route.

To delete a waypoint from your

current route:

1. Press the DEST hard key.

2. Select the Delete screen button

for the desired waypoint to

delete.

3. The system will display a pop-up

conﬁrmation message. Choose

Yes to delete the waypoint; touch

No to cancel this operation.

4. Select the route preference

(Fastest, Shortest, or Other).

The system will calculate

and highlight the route.

5. Select the Start Guidance screen

button. You are now ready to

start your route.

Infotainment System 75

Suspend Guidance

Press this screen button, from the

Route screen, to put the current

route on hold.

Resume Guidance

Press this screen button, from the

Route screen, to resume guidance

on the current route.

Cancel Guidance

Press this screen button, from the

Route screen, to cancel the

current route.

Adding Destinations to the

Address Book

There are two ways to add a

destination to the address book:

•To add the current ﬁnal

destination to the address book,

press the Mark screen button

from the map screen. The system

will automatically save the ﬁnal

destination information in

the address book.

•Press the Add to Address Book

screen button when available

on POI information screens,

Destination Entry screens, or POI

screens. The system will

automatically save this

information in the address book.

See “Nav” under Navigation Menu

on page 53 for information on editing

address book entries.

Adding or Changing Preset

Destinations

This feature allows you to add or

change one of ﬁve preset

destinations. When a destination

has been added as a preset

destination, it will be available to

select from the Destination

Entry screen. See “Preset

Destination” previously for

information on how to select a

preset destination as a ﬁnal

destination.

To store the current ﬁnal destination

as a preset destination:

1. Select the Mark screen button

from the map screen to add

the current ﬁnal destination. The

Address Book screen will

appear.

2. Select the Name screen button.

An alpha-keyboard will display.

Enter the name.

3. Press and hold one of the

buttons at the bottom of the

screen until a pop-up

conﬁrmation displays.

The name will appear in that

preset destination screen button

and is now available to select

from the Destination Entry

screen.

76 Infotainment System

To store an address book entry as a

preset destination:

1. Select the MENU hard key.

2. Select the Nav screen button or

press the MENU key until the

Nav screen button is selected or

touch the Nav screen button.

3. Select the Edit/View screen

button.

4. Select the address book entry

that you would like to store as

the preset destination. Select the

Name screen button to add a

name, if needed.

5. Press and hold one of the

buttons at the bottom of the

screen until a pop-up

conﬁrmation displays.

The name will appear in the that

preset destination screen

button and is now available to

select from the Destination Entry

screen.

Global Positioning

System (GPS)

The navigation system determines

the position of the vehicle by

using satellite signals, various

vehicle signals, and map data.

At times, other interferences such

as the satellite condition, road

conﬁguration, the condition of the

vehicle and/or other circumstances

can interfere with the navigation

system’s ability to determine

the accurate position of the vehicle.

The GPS shows the current

position of the vehicle using signals

sent by the GPS Satellites of the

United States Department of

Defense. When the vehicle is not

receiving signals from the satellites,

a symbol appears on the map

screen. Refer to Navigation Symbols

on page 47.

This system may not be available or

interferences may occur if:

•Signals are obstructed by tall

buildings, trees, large trucks,

or a tunnel.

•Objects that are placed on top of

or near the instrument panel.

•Satellites are being repaired or

improved.

•After-market glass tinting has

been applied to the vehicle’s

windshield.

Notice: Do not apply after-market

glass tinting to the vehicle’s

windows. Glass tinting interferes

with the system’s ability to

receive GPS signals and causes

the system to malfunction.

The window might have to be

replaced to correct the problem.

This would not be covered by

the warranty.

Infotainment System 77

For more information if the GPS is

not functioning properly, see If

the System Needs Service

on page 79 and Problems with

Route Guidance on page 78.

Vehicle Positioning

At times, the position of the vehicle

on the map may be inaccurate

due to one or more of the following

reasons:

•The road system has changed.

•The vehicle is driving on slippery

road surfaces such as in sand,

gravel, and/or snow.

•The vehicle is traveling on

winding roads.

•The vehicle is on a long straight

road.

•The vehicle is approaching a tall

building or a large vehicle.

•The surface streets run parallel

to a freeway.

•The vehicle has just been

transferred by a vehicle carrier or

a ferry.

•The current position calibration is

set incorrectly.

•The vehicle is traveling at high

speed.

•The vehicle changes directions

more than once, or when the

vehicle is turning on a turn table

in a parking lot.

•The vehicle is entering and/or

exiting a parking lot, garage,

or a lot with a roof.

•The GPS signal is not received.

•A roof carrier is installed on

your vehicle.

•The vehicle is being driven with

tire chains.

•The tires are replaced.

•The tire pressure for your tires is

incorrect.

•The tires are worn.

•The ﬁrst time the map DVD is

inserted.

•The battery is disconnected for

several days.

•The vehicle is driving in heavy

traffic where driving is at low

speeds, and the vehicle is

stopped and started repeatedly.

If problems are experienced with the

navigation system, see your

dealer.

Problems with Route

Guidance

Inappropriate route guidance may

occur under one or more of the

following conditions:

•You have not turned onto the

road indicated.

•Route guidance may not be

available when using automatic

rerouting for the next right or

left turn.

78 Infotainment System

•The route may not be changed

when using automatic rerouting.

•There is no route guidance when

turning at an intersection.

•Plural names of places may be

announced occasionally.

•It may take a long time to

operate automatic rerouting

during high-speed driving.

•Automatic rerouting may display

a route returning to the set

waypoint if you are heading for a

destination without passing

through a set waypoint.

•The route prohibits the entry of a

vehicle due to a regulation by

time or season or any other

regulation which may be given.

•Some routes may not be

searched.

•The route to the destination may

not be shown if there are new

roads, if roads have recently

changed, or if certain roads are

not listed on the map DVD.

See Ordering Map DVDs

on page 79.

To recalibrate the vehicle’s position

on the map, see your dealer.

If the System Needs

Service

If the navigation system needs

service and the steps listed here

have been followed but there are still

problems, see your dealer for

assistance.

Ordering Map DVDs

The map DVD in the vehicle is the

most up-to-date information

available when the vehicle was

produced. The map DVD is updated

periodically, provided that the

map information has changed.

For any questions about the

operation of the navigation

system or the update process,

contact the GM Nav Disc

Center toll-free phone number,

1-877-NAV-DISC (1-877-628-3472)

or go to the center’s website,

www.gmnavdisc.com. For any

updates or replacements, call the

GM Nav Disc Center or order a new

disc online. Have the Vehicle

Identiﬁcation Number (VIN) available

when ordering to ensure the

correct and most up-to-date DVD

map disc for the vehicle is sent. See

“Vehicle Identiﬁcation Number

(VIN)” in the Index of the vehicle’s

owner manual for more information.

Infotainment System 79

After receiving the updated disc,

replace the old disc in the navigation

system. See “Installing the DVD

Map Disc” and “Ejecting the

DVD Map Disc” under Maps on

page 44. Dispose of the old disc to

avoid confusion about which

disc is the most current.

Database Coverage

Explanations

Coverage area depends upon the

map detail available. Some

areas have greater map detail than

others. The navigation system

works only as well as the information

provided on the map disc. See

Ordering Map DVDs on page 79 on

how to obtain updated map

information.

Voice Recognition

The navigation system’s voice

recognition allows for hands-free

operation of the navigation system,

audio system, and OnStar

features. The DVD map disc must

be installed in the navigation system

for voice recognition to work. See

“Installing the DVD Map Disc” under

Maps on page 44. Voice recognition

can be used when the ignition is

on or when Retained Accessory

Power (RAP) is active. See

“Retained Accessory Power (RAP)”

in the Index of your vehicle’s

owner manual for more information.

To use voice recognition, do the

following:

1. Push and hold the SRCE

(source) steering wheel control

until you hear a beep. The audio

system, if on, will mute.

2. Clearly state one of the

commands listed on the following

pages.

Helpful Hints for Stating

Commands

•When a multiple command is

available, choose the command

that best works for you.

•Words that are in brackets are

optional. For example, for the

command Radio [band] [select]

FM, stating Radio FM or

Radio select FM are both valid

commands.

•When the system recognizes the

command the system will:

− either perform the function

− ask you to conﬁrm your choice

by clearly stating “yes or no”

− issue an error message such

as “System does not

recognize this command” or

direct you to “Please start

speaking after the beep”

•If the system is not yet ready, the

system may state “System is

checking the disc. Please wait.”

80 Infotainment System

•To cancel a command or if the

system response does not

match your verbal command,

press and hold the talk symbol

button. The system will reply,

“System will cancel the

voice recognition”.

•If you experience difficulty with

the system recognizing a

command, try saying it more

softly, and wait for a few seconds

after the beep, or you may just

try saying it again.

•Background noise may cause

voice commands to be

misunderstood, including airﬂow

noise from wind.

•To use the voice recognition

system, the map DVD must

be loaded.

This system is able to recognize

commands in three different

languages. The system will only

recognize commands based on the

language selected from the

Driver Information Center (DIC).

See “Driver Information Center, DIC

Vehicle Personalization” in the

Index of your vehicles owner

manual.

Voice Recognition Commands

The following list shows all of the

voice commands available for

the navigation system with a brief

description of each. The commands

are listed with the optional words

in brackets. To use the voice

commands, refer to the instructions

listed previously.

Voice Tag Commands

The following are voice tag

commands you can access by

clearly stating the commands

exactly as they are written. You may

have up to 40 voice tag entries for

destinations.

Navigation go to [destination]

(voice tag), navigation select

[destination] (voice tag): These

commands instruct the system

to select a destination saved under

the voice tag you have stored.

When a destination is requested

using a voice tag, the system

will state, “Press or say cancel if not

correct”. To cancel this voice tag

destination, using voice recognition,

push and hold the SRCE button

on the steering wheel until you hear

a beep, then say “cancel”.

Canceling voice tag destination by

voice recognition, must be done

within ﬁve seconds after the

voice prompt.

If you are not currently driving on a

route, the system will automatically

create the voice tag destination

as the ﬁnal destination. If you are

currently driving on a route, the

system will automatically create the

voice tag destination as a

waypoint. Up to three waypoints can

be created.

Storing Voice Tags

From the address book entry

information page, press the Add

Voice tag screen button. The system

will respond “Name Please?”.

Infotainment System 81

Navigation Help

Navigation Help: This command

instructs the system to assist

with navigation commands.

Display Commands

Use the following display commands

to set the display mode.

Display [set] day [mode]: Use this

command to set the display to

daytime mode.

Display [set] night [mode]: Use

this command to set the display

to night mode.

Display [set] auto [mode]: Use

this command to set the display to

automatic mode. The system

will change between day and night

mode automatically.

System help: This command

instructs the system to assist with

display commands.

Radio Commands

The following are radio commands

you can access by clearly stating

the commands exactly as they

are written. The commands are only

available when you are in one of

the following audio modes, AM, FM,

or XM™ (if equipped).

Radio: This command instructs the

system to turn the audio system

on.

Radio [band] [select] AM, radio

[band] [select] FM, radio [band]

[select] XM, radio [band] [select]

satellite: These commands

instruct the system to go to either

the AM, FM, or XM (if equipped).

Radio [select] (frequency)

AM, radio [select] (frequency)

FM: These commands instruct the

system to go to a speciﬁc

frequency on either AM or FM.

Radio [select] (channel) XM, radio

[select] (channel) satellite: These

commands instruct the system to

go to a speciﬁc channel on the

XM™ band (if equipped). The

channel must be a valid channel or

the system will keep the radio at

the current station setting. The

system will pause while searching

for the channel.

Radio help: This command

instructs the system to assist with

radio commands.

CD Commands

The following are CD, MP3, and

DVD commands that can be

accessed by clearly stating the

commands exactly as they

are written.

CD, DVD, Disc: Use this command

to select a CD, DVD, or disc that

is currently loaded.

82 Infotainment System

CD, DVD, Disc, [select] track

(one, two, three, etc.): This

command instructs the system to

select a speciﬁc track number.

CD, DVD, Disc select next

folder: Use this command to select

the next folder on the MP3 or

audio DVD.

CD, DVD, Disc select previous

folder: Use this command to select

the previous folder on the MP3 or

audio DVD.

CD help, DVD help, Disc

help: This command instructs the

system to assist with CD and

DVD commands.

Auxiliary Commands

The following auxiliary commands

can be accessed by clearly

stating the commands exactly as

they are written. The commands are

available when the auxiliary

source is available.

Aux, Auxiliary: Use this command

to select the auxiliary device,

when a device is connected.

OnStar

Command

OnStar: This command instructs

the system to connect to OnStar

You will enter the OnStar

voice

recognition system. Refer to

your OnStar

manual for more

information.

Voice Help

Voice help: This command will

provide a description of help

commands that are available to use.

Infotainment System 83

✍NOTES

84 Infotainment System

Adding Destinations to the

Address Book ..................... 76

Adding or Changing Preset

Destinations ........................ 76

Alpha-Numeric Keyboard .......... 43

AM-FM Radio ......................... 14

Audio Book ............................ 40

Auto Reroute ......................... 52

Auxiliary Devices .................... 41

Canadian Vehicle Owners

(Propriétaires des Véhicules

Canadiens) .......................... 4

Canceling Guidance ................ 13

DVD Player ........................ 24

CD/DVD Messages ................. 33

Cleaning the Display Screen .... 13

Database Coverage

Explanations ....................... 80

Deleting Personal Information ..... 9

Destination, Navigation ............ 65

Devices, Auxiliary .................... 41

Display .................................. 64

Driving on a Route ................. 51

DVD Map Disc Messages ........ 46

DVD Menu Options ................. 29

DVD/CD Player ...................... 24

Edit Address Book .................. 55

Ejecting the DVD Map Disc ...... 45

Finding a Station ............... 15, 21

Getting Started on Your

Route ................................ 73

Global Positioning System

(GPS) ................................ 77

Guidance Volume ................... 13

Handling the DVD Map Disc ..... 45

Hard Keys ............................. 42

Hybrid Screens ....................... 13

Installing the DVD Map Disc ..... 44

Introduction ............................. 3

Language — English/Metric ....... 9

Limit Features While Driving ...... 9

Map Adjustments .................... 46

Map Coverage ....................... 44

Map Database Information ....... 56

Map Scales ........................... 46

Maps .................................... 44

Nav (Navigation) ..................... 53

Navigation

Destination ......................... 65

Menu ................................. 53

Symbols ............................. 47

Using the System ................ 42

INDEX i-1

Off-Road Mode ....................... 54

OnStar

Destination

Download ........................... 71

Ordering

Map DVDs ......................... 79

Overview, Infotainment

System ................................ 4

Playing a DVD ....................... 28

Playing an Audio CD ............... 24

Playing from an iPod

............. 38

Playing from USB ................... 34

Playing the Radio .............. 14, 21

Problems with Route

Guidance ........................... 78

Radio .................................... 53

Radio Data System (RDS) ....... 20

Radio Menu ..................... 18, 23

Radios

AM-FM Radio ..................... 14

CD/DVD Player ................... 24

Satellite ............................. 21

Radios (cont.)

Rear Seat Entertainment

(RSE) ................................ 29

Route Preference .................... 54

Satellite Radio ........................ 21

Scrolling the Map ................... 46

Setting the Clock ............... 10, 65

Setting the Search Area,

Entering an Address and

Point of Interest, and

Storing Preset

Destinations ........................ 10

Sound ................................... 53

Sound Menu ..................... 16, 22

Storing Radio Station

Presets ..................... 9, 16, 22

Symbols, Navigation ................ 47

System Needs Service, If ......... 79

Touch-Sensitive Screen

Buttons .............................. 43

Traveling Across Regions ......... 52

USB Host Support .................. 34

USB Music Menu ................... 35

USB Supported Devices .......... 34

Using an MP3 CD .................. 25

Using OnStar

Destination

Download ........................... 71

Using Your Stored Preset

Destinations ........................ 13

Vehicle Positioning .................. 78

Voice Prompt ......................... 54

Voice Recognition ................... 80

Voice Recognition Commands .. 81

XM NavTraffic™ (USA and

Canada) ............................. 57

XM™ Satellite Radio Service .... 23

i-2 INDEX

Chevrolet 2010 Silverado 1500 Navigation Manual Guide

Navigation menu

Versions of this User Manual:

Views

Navigation
