Chic Technology CKM32XXX WIRELESS KEYBOARD User Manual PMU CKM00035
Chic Technology Corporation WIRELESS KEYBOARD PMU CKM00035
users manual
Web Home
Web Forward
Web Favorites
Volume Down
Fast Backward
E-mail
Web Search
Web Stop
Volume Up
Play/Pause
Web Backward
Web Refresh
Mute
Stop
Fast Forward
15 Easy Hot Keys of the Internet Wireless Keyboard
3Figure 3-3-2
2-2. Select the Keyboard Channel
Notice:
- Please skip this section if the keyboard is the one-channel version.
1) The two-channel switch is located on the back of the keyboard. Select Channel "1" or "2".
2) Put the batteries into the battery case.
2-3. Select the Mouse Channel
Notice:
- Please skip this section if the mouse is the one-channel version.
1) The two-channel switch is located at the back of the mouse. Select Channel "1" or "2".
2) Put the batteries into the battery case.
2-4. Link the Wireless Keyboard and the Wireless Optical Mouse with the Receiver
1) Please turn on your PC. The LED indicator on the receiver will light.
2) Press the ID Link Button on the receiver and the LED indicator will blink. The receiver
is ready to automatically link with the keyboard and the mouse.
3) Press the ID Link Buttons of the keyboard and the mouse.
4) The LED indicator on the receiver is light while you successfully finish the keyboard and
the mouse linkage.
5) The LED indicator of the receiver will blink while you use the keyboard or the mouse.
6) If you need to re-link the mouse, the keyboard or after changing the batteries, please
repeat the steps 2~3.
7) If the selected channel is interfered by other wireless-mouse or keyboard users nearby,
please change the Link ID by re-linkage or select the other channel immediately.
8) There are 256 changeable IDs for each channel.
3. Install Driver
3-1. Notice
1) The driver supports Windows 95, Windows 98, Windows NT, Windows 2000, Windows
ME and Windows XP.
2) The driver may be automatically installed.
3) The driver CD-ROM contents the drivers of the keyboard and the mouse. Please select to
install the keyboard driver or the mouse driver at the pop-up window.
3-2. Install Keyboard Driver
1) Insert the driver CD-ROM to your PC.
2) If the driver does not be automatically
installed, please double click the
file "Menu.exe" and follow the
setup instructions to complete the
driver installation.
3) A Keyboard Setting icon will
appear on the taskbar of
Windows after you successfully
finish the installation.
4) You can double click the Keyboard Setting
icon and follow the selection instructions
to set the keyboard functions.
3-3. Introduction of Hot Keys
Notice:
- The keyboard hot keys may be different due to various keyboard models. There are
two versions of hot keys as below.
3Figure 3-2-4
1) Version I: 19 easy hot keys of Internet and Multimedia control
(1) Web Backward
(2) Web Forward
(3) Web Stop
(4) Web Refresh
(5) Web Search
(6) Web Favorites
(7) Web Home
(8) E-mail
(9) PC Sleep
(10) My Computer
(11) Calculator
(12) Mute
(13) Volume Down
(14) Volume Up
(15) Play/Pause
(16) Stop
(17) Fast Backward
(18) Fast Forward
(19) Media Player
2) Version II: 15 easy hot keys of Internet and Multimedia control
(1) Web Home
(2) E-mail
(3) Web Backward
(4) Web Forward
(5) Web Search
(6) Web Refresh
(7) Web Favorites
(8) Web Stop
(9) Mute
(10) Volume Down
(11) Volume Up
(12) Stop
(13) Fast Backward
(14) Play/Pause
(15) Fast Forward
3-4. Install Mouse Driver
1) Insert the driver CD-ROM to your PC.
2) If the driver does not automatically installed,
please double click the file "Menu.exe" and
follow the setup instructions to complete the
driver installation.
3) A Mouse Setting icon will appear on the
taskbar of Windows after you successfully finish
the installation.
4) You can double click the Mouse Setting icon and
follow the selection instructions to set the mouse
Button functions.
Web Backward
Web Forward
Web Stop
Web Refresh
Web Search
Web Favorites
Web Home
E-mail
PC Sleep
My Computer
Calculator
Mute
Volume Down
Volume Up
Play/Pause
Stop
Fast Backward
Fast Forward
Media Player
19 Easy Hot Keys of the Internet Wireless Keyboard
3Figure 3-3-1
Web Home
Web Forward
Web Favorites
Volume Down
Fast Backward
E-mail
Web Search
Web Stop
Volume Up
Play/Pause
Web Backward
Web Refresh
Mute
Stop
Fast Forward
15 Easy Hot Keys of the Internet Wireless Keyboard
3Figure 3-3-2
2-2. Select the Keyboard Channel
Notice:
- Please skip this section if the keyboard is the one-channel version.
1) The two-channel switch is located on the back of the keyboard. Select Channel "1" or "2".
2) Put the batteries into the battery case.
2-3. Select the Mouse Channel
Notice:
- Please skip this section if the mouse is the one-channel version.
1) The two-channel switch is located at the back of the mouse. Select Channel "1" or "2".
2) Put the batteries into the battery case.
2-4. Link the Wireless Keyboard and the Wireless Optical Mouse with the Receiver
1) Please turn on your PC. The LED indicator on the receiver will light.
2) Press the ID Link Button on the receiver and the LED indicator will blink. The receiver
is ready to automatically link with the keyboard and the mouse.
3) Press the ID Link Buttons of the keyboard and the mouse.
4) The LED indicator on the receiver is light while you successfully finish the keyboard and
the mouse linkage.
5) The LED indicator of the receiver will blink while you use the keyboard or the mouse.
6) If you need to re-link the mouse, the keyboard or after changing the batteries, please
repeat the steps 2~3.
7) If the selected channel is interfered by other wireless-mouse or keyboard users nearby,
please change the Link ID by re-linkage or select the other channel immediately.
8) There are 256 changeable IDs for each channel.
3. Install Driver
3-1. Notice
1) The driver supports Windows 95, Windows 98, Windows NT, Windows 2000, Windows
ME and Windows XP.
2) The driver may be automatically installed.
3) The driver CD-ROM contents the drivers of the keyboard and the mouse. Please select to
install the keyboard driver or the mouse driver at the pop-up window.
3-2. Install Keyboard Driver
1) Insert the driver CD-ROM to your PC.
2) If the driver does not be automatically
installed, please double click the
file "Menu.exe" and follow the
setup instructions to complete the
driver installation.
3) A Keyboard Setting icon will
appear on the taskbar of
Windows after you successfully
finish the installation.
4) You can double click the Keyboard Setting
icon and follow the selection instructions
to set the keyboard functions.
3-3. Introduction of Hot Keys
Notice:
- The keyboard hot keys may be different due to various keyboard models. There are
two versions of hot keys as below.
3Figure 3-2-4
1) Version I: 19 easy hot keys of Internet and Multimedia control
(1) Web Backward
(2) Web Forward
(3) Web Stop
(4) Web Refresh
(5) Web Search
(6) Web Favorites
(7) Web Home
(8) E-mail
(9) PC Sleep
(10) My Computer
(11) Calculator
(12) Mute
(13) Volume Down
(14) Volume Up
(15) Play/Pause
(16) Stop
(17) Fast Backward
(18) Fast Forward
(19) Media Player
2) Version II: 15 easy hot keys of Internet and Multimedia control
(1) Web Home
(2) E-mail
(3) Web Backward
(4) Web Forward
(5) Web Search
(6) Web Refresh
(7) Web Favorites
(8) Web Stop
(9) Mute
(10) Volume Down
(11) Volume Up
(12) Stop
(13) Fast Backward
(14) Play/Pause
(15) Fast Forward
3-4. Install Mouse Driver
1) Insert the driver CD-ROM to your PC.
2) If the driver does not automatically installed,
please double click the file "Menu.exe" and
follow the setup instructions to complete the
driver installation.
3) A Mouse Setting icon will appear on the
taskbar of Windows after you successfully finish
the installation.
4) You can double click the Mouse Setting icon and
follow the selection instructions to set the mouse
Button functions.
Web Backward
Web Forward
Web Stop
Web Refresh
Web Search
Web Favorites
Web Home
E-mail
PC Sleep
My Computer
Calculator
Mute
Volume Down
Volume Up
Play/Pause
Stop
Fast Backward
Fast Forward
Media Player
19 Easy Hot Keys of the Internet Wireless Keyboard
3Figure 3-3-1
F1~F10
Auto Scroll
Backspace
Close Application
Connect to Internet
Control Lock
Control Panel
Copy
Cut
Delete
Double Click
Down
Drag Lock
End
Enter
Esc
Explorer
Find Computer
Find File
Home
Horizontal
Wheel
Interent Explorer
Backward
Interent Explorer
Forward
Lanuch Default
Browser
Lanuch Default
E-mail
Left
Maximize Windows
Middle Button
Minimize All
Windows
Minimize
Windows
Page Down
Page Up
Paste
Redo
Right
Run...
Shift Lock
Space
Start Menu
System Help
System Property
Tab
Undo
Undo Minimize
All Windows
Universal Scroll
Universal Zoom
Up
3Figure 3-4-4
3Figure 3-4-5
4. Optional Charging Modes for Wireless Optical Mouse
Notice:
- Ni-MH rechargeable batteries are recommended.
- There are three charge modes for the rechargeable version.
- Please skip this section if your mouse is not rechargeable. (Some mice may provide only
one charge mode.)
- Recommendation: Please do not use the mouse during charge periods.
4-1. Charge from PC
Connect the mouse to the USB port of the PC with the USB to DC cable.
4-2. Charge from Adaptor
Connect the mouse with the AC to DC adaptor.
4-3. Charge from Receiver
Place the rechargeable mouse on the receiver and then connect the receiver with the AC to
DC adaptor.
5. Battery Notice
1) At the first time of usage, please charge the AAA batteries at least 6 to 8 hours or 10 to 12 hours
for the AA batteries.
2) The LED indicator or the scroll wheel on the mouse will light while the mouse is low battery.
Please change or recharge the batteries immediately.
3) If the keyboard is in the status of low battery, the LED indicator on the keyboard will be light
while typing any key and a low-battery icon will appear on the taskbar of Windows. Please
change the batteries immediately.
4) Click any button of the keyboard or the mouse or press the scroll wheel to wake up the
keyboard or the mouse while they are in the sleeping mode.
PMU-CKM00035
Made in China
Internet Wireless Keyboard Combo
with Wireless Optical Mouse
User's Quick Guide
Notice:
Federal Communications Commission (FCC) requirements, Part 15
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Any changes of modifications not expressly approved by the grantee of this device could void the users authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Congratulations on your purchase of the Combination of Internet Wireless Keyboard and
Wireless Optical Mouse. Please carefully read the User's Quick Guide to learn about the
installation and the powerful functions of your new Internet Wireless Keyboard with Wireless
Optical Mouse.
1. Contents of Package1. Contents of Package
1)Internet Wireless Keyboard
2)Wireless Optical Mouse
3)Receiver (with PS/2 connectors)
4)Batteries for Keyboard: AA x 2 or x 3
5)Rechargeable Batteries for Wireless Optical Mouse: AA or AAA x 2
6)Driver CD-ROM
7)User's Quick Guide
Optional Parts for Wireless Optical Mouse
(The optional parts may be different due to various wireless optical mice.)
1) AC to DC Adaptor
2) USB to DC Cable
2. Install Hardware
Notice:
- The locations of the channel switch and the link button may be different due to various
keyboard shapes.
- Some models may be designed as one-channel version, which will not have a channel switch.
2-1. Install the Receiver with PS/2 Connectors
1) Please turn off your PC.
2) Plug the mouse PS/2 connector (green) on the receiver into the PS/2 mouse port of the PC.
3) Plug the keyboard PS/2 connector (purple) on the receiver into the PS/2 keyboard port of the
PC.
3Figure 2-1
