12V LITHIUM-ION
MULTIFUNCTION TOOL
Model
67707
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright© 2010 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Page 2 For technical questions, please call 1-800-444-3353. SKU 67707
SAVE THIS MANUAL
Keep this manual for the safety warnings
and precautions, assembly, operating,
inspection, maintenance and cleaning
procedures. Write the product’s serial number
in the back of the manual near the assembly
diagram (or month and year of purchase if
product has no number). Keep this manual
and the receipt in a safe and dry place for
future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling, and
all other information provided with
this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that follow
this symbol to avoid possible
injury or death.
DANGER indicates a
hazardous situation
which, if not avoided, will result
in death or serious injury.
WARNING indicates a
hazardous situation
which, if not avoided, could
result in death or serious injury.
CAUTION, used with
the safety alert
symbol, indicates a hazardous
situation which, if not avoided,
could result in minor or moderate
injury.
NOTICE is used to
address practices not
related to personal injury.
CAUTION, without the
safety alert symbol, is
used to address practices not
related to personal injury.
General Power Tool Safety Warnings
WARNING Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result
in electric shock, re and/or serious
injury.
Save all warnings and instructions
for future reference.
The term ″power tool″ in the warnings
refers to your battery-operated
(cordless) Multifunction Tool.
Work area safety1.
Keep work area clean and well lit. a.
Cluttered or dark areas invite accidents.
Do not operate power tools in b.
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
Keep children and bystanders c.
away while operating a power tool.
Distractions can cause you to lose
control.
Electrical safety2.
Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
Personal safety3.
Stay alert, watch what you are a.
doing and use common sense when
operating a power tool. Do not use
Page 3For technical questions, please call 1-800-444-3353.SKU 67707
a power tool while you are tired or
under the inuence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result
in serious personal injury.
Use personal protective equipment. b.
Always wear eye protection. Safety
equipment such as a dust mask,
non-skid safety shoes, a hard hat, or
hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. c.
Ensure the Power Switch is in the off-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying
power tools with your nger on the
power switch invites accidents.
Remove any adjusting key or wrench d.
before turning the power tool on. A
wrench or a key left attached to any part
of the power tool may result in personal
injury.
Do not overreach. Keep proper e.
footing and balance at all times. This
enables better control of the power tool
in unexpected situations.
Dress properly. Do not wear loose f.
clothing or jewelry. Keep your hair,
clothing and gloves away from
moving parts. Loose clothes, jewelry
or long hair can be caught in moving
parts.
Only use safety equipment that has g.
been approved by an appropriate
standards agency. Unapproved
safety equipment may not provide
adequate protection. Eye protection
must be ANSI-approved and breathing
protection must be NIOSH-approved for
the specic hazards in the work area.
Power tool use and care4.
Do not force the power tool. Use a.
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate
for which it was designed.
Do not use the power tool if the b.
Power Switch does not turn it on
and off. Any power tool that cannot
be controlled with the power switch is
dangerous and must be repaired.
Disconnect the battery pack from c.
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such
preventive safety measures reduce
the risk of starting the power tool
accidentally.
Hold the power tool by insulated 5.
gripping surfaces when performing an
operation where the cutting tool may
contact hidden wiring. Contact with a
″live″ wire will make exposed metal parts
of the tool ″live″ and shock the operator.
Use clamps or another practical way 6.
to secure and support the work piece
to a stable platform. Holding the work
by hand or against your body leaves it
unstable and may lead to loss of control.
Store idle power tools out of reach a.
of children and do not allow persons
unfamiliar with the power tool or
these instructions to operate the
power tool. Power tools are dangerous
in the hands of untrained users.
Maintain power tools. Check for b.
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
power tool’s operation. If damaged,
have the power tool repaired before
use. Many accidents are caused by
poorly maintained power tools.
Page 4 For technical questions, please call 1-800-444-3353. SKU 67707
Keep cutting tools sharp and clean.c.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
Use the power tool and accessories d.
in accordance with these
instructions, taking into account the
working conditions and the work
to be performed. Use of the power
tool for operations different from those
intended could result in a hazardous
situation.
Battery tool use and care7.
Recharge only with the Charger a.
specied by the manufacturer. A
Charger that is suitable for one type of
battery pack may create a risk of re
when used with another battery pack.
Use power tools only with b.
specically designated battery
packs. Use of any other battery packs
may create a risk of injury and re.
When battery pack is not in use, keep c.
it away from other metal objects,
like paper clips, coins, keys, nails,
screws or other small metal objects,
that can make a connection from
one terminal to another. Shorting the
battery terminals together may cause
burns or a re.
Under abusive conditions, liquid d.
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, ush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
Service8.
Have your power tool serviced by a a.
qualied repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
Multifunction Tool Safety Warnings
Maintain labels and nameplates on 1.
the tool. These carry important safety
information. If unreadable or missing,
contact Harbor Freight Tools for a
replacement.
Do not use this Multifunction Tool with 2.
any other Battery or Charger.
Avoid unintentional starting. Prepare to 3.
begin work before turning on the tool.
CAUTION: Avoid accidental injury. Keep 4.
oscillating Scraper, Cutting Blade, and
Sandpaper when operating the tool.
Avoid unintentional starting. Prepare to 5.
begin work before turning on the power
tool.
Do not lay the tool down until it has come 6.
to a complete stop. Moving parts can
grab the surface and pull the tool out of
your control.
When using a handheld power tool, 7.
hands to resist starting torque.
Do not leave the tool unattended when 8.
the battery pack it installed. Turn off the
tool, and remove the battery pack before
leaving.
9. The battery pack and Charger
get hot during use. The
pack’s heat can build up to
hazard if it does not receive adequate
ventilation, due to an electrical fault, or if
it is used in a hot environment.
Do not place the Battery Pack on a
vents on the Battery Pack. Especially
avoid placing the Battery Pack on
carpets and rugs; they are not only
Page 5For technical questions, please call 1-800-444-3353.SKU 67707
ammable, but they also obstruct
vents under the Battery Pack.
Place the Battery Pack on a stable, solid,
objects, such as drapes or walls. Keep a
the area. Frequently monitor the Battery
Pack and Charger while charging.
This product is not a toy. Keep it out of 10.
reach of children.
People with pacemakers should 11.
consult their physician(s) before use.
to heart pacemaker could cause
pacemaker interference or pacemaker
failure. In addition, people with
pacemakers should:
on.
electrical shock.
WARNING: Some dust created by power 12.
sanding, sawing, grinding, drilling, and
other construction activities, contains
chemicals known [to the State of
California] to cause cancer, birth defects
or other reproductive harm. Some
examples of these chemicals are:
cement or other masonry products
treated lumber
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to
these chemicals: work in a well ventilated
area, and work with approved safety
equipment, such as those dust masks
microscopic particles. (California Health
& Safety Code § 25249.5, et seq.)
WARNING: Handling the Charger cord 13.
on this product will expose you to lead, a
chemical known to the State of California
to cause cancer, and birth defects or
other reproductive harm. Wash hands
after handling. (California Health &
Safety Code § 25249.5, et seq.)
The warnings, precautions, and 14.
instructions discussed in this instruction
manual cannot cover all possible
conditions and situations that may occur.
It must be understood by the operator
that common sense and caution are
factors which cannot be built into this
product, but must be supplied by the
operator.
Lithium Battery Safety Warnings
LITHIUM BATTERIES STORE A
LARGE AMOUNT OF ENERGY AND
WILL VENT FIRE OR EXPLODE IF
MISTREATED:
Keep Battery Pack dry.1.
DO NOT DO ANY OF THE 2.
FOLLOWING TO THE BATTERY PACK:
Open,a.
Drop,b.
Short-circuit,c.
Incinerate, ord.
Expose to temperatures greater than e.
140°F.
Charge Battery Pack only according to 3.
the instructions in this manual.
Page 6 For technical questions, please call 1-800-444-3353. SKU 67707
Inspect Battery Pack before every use; 4.
do not use or charge if damaged.
Vibration Safety
This tool vibrates during use. Repeated
cause temporary or permanent physical
injury, particularly to the hands, arms
and shoulders. To reduce the risk of
Anyone using vibrating tools regularly 1.
be examined by a doctor and then have
medical problems are not being caused
or worsened from use. Pregnant
women or people who have impaired
blood circulation to the hand, past hand
injuries, nervous system disorders,
diabetes, or Raynaud’s Disease
should not use this tool. If you feel any
symptoms related to vibration (such as
tingling, numbness, and white or blue
possible.
Do not smoke during use. Nicotine 2.
reduces the blood supply to the hands
Wear suitable gloves to reduce the 3.
vibration effects on the user.
Use tools with the lowest vibration when 4.
there is a choice.
5.
of work.
Grip tool as lightly as possible (while still 6.
do the work.
To reduce vibration, maintain the tool 7.
as explained in this manual. If any
abnormal vibration occurs, stop use
immediately.
SAVE THESE
INSTRUCTIONS.
GROUNDING
TO PREVENT
ELECTRIC SHOCK
AND DEATH FROM INCORRECT
GROUNDING WIRE
CONNECTION:
Check with a qualied electrician
if you are in doubt as to whether
the outlet is properly grounded.
Do not modify the Charger cord
plug provided with the tool.
Never remove the grounding
prong from the plug. Do not use
the tool if the power cord or plug
is damaged. If damaged, have it
repaired by a service facility
before use. If the plug will not t
the outlet, have a proper outlet
installed by a qualied
electrician.
Double Insulated Tools: Tools with
Two Prong Plugs
Outlets for 2-Prong Plug
Tools marked “Double Insulated” do not 1.
require grounding. They have a special
OSHA requirements and complies with
Page 7For technical questions, please call 1-800-444-3353.SKU 67707
the applicable standards of Underwriters
Standard Association, and the National
Electrical Code.
Double insulated tools may be used in 2.
either of the 120 volt outlets shown in the
preceding illustration. (See Outlets for
2-Prong Plug.)
Extension Cords
Note: Extension cords must not be used with
this item’s Charger.
Symbology
Double Insulated
Canadian Standards Association
V~ Volts Alternating Current
AAmperes
n0 xxxx/min.
(RPM)
Page 8 For technical questions, please call 1-800-444-3353. SKU 67707
SPECIFICATIONS
Charger Input 120 VAC
Battery Type
Motor Speed
Accessories
Sandpaper (2 pieces for wood
and 2 pieces for metal)
Sanding Pad
Cutting Blade
Scraper Blade
Hex Wrench
UNPACKING
When unpacking, make sure that the
item is intact and undamaged. If any parts
are missing or broken, please call Harbor
possible.
purpose tool includes Sandpaper (504) and
a Sanding Pad (503) for sanding wood or
removing paint from surfaces, a Cutting
Blade (502) to cut wood and soft metal such
as copper piping, and a Scraper Blade (501)
which can be used for scraping paint or wall
INSTRUCTIONS FOR PUTTING
INTO USE
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set up
or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Power Switch off and
remove the Battery Pack before
assembling or making any
adjustments to the tool.
Note: For additional information regarding the
parts listed in the following pages, refer
to the Assembly Diagram near the end of
this manual.
Components
Figure 1
Charger
(506)
Hex
Wrench
(505)
Scraper Blade
(501) Cutting Blade
(502)
Sandpaper
(504)
Sanding
Pad
(503)
Tool
Battery
Pack
Case (507)
SET UP
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set up
or use of this product.
Page 9For technical questions, please call 1-800-444-3353.SKU 67707
Work Piece and Work Area Set Up
Designate a work area that is clean and 1.
access by children or pets to prevent
distraction and injury.
Route the power cord of the Charger 2.
along a safe route without creating a
tripping hazard or exposing the power
cord to possible damage.
Charging the Battery Pack
The Battery Pack needs to be charged
recharge the Battery after every use.
Charger
Socket
Battery
Pack
Charger Plug
Charger (506)
Figure 2
1.
surface in a room where the temperature
Allow a recently exhausted Battery Pack 2.
to cool completely before charging. Make
sure the Battery Pack is undamaged; do
not charge a cracked or leaking pack.
Insert the Charger’s plug into the 3.
Charger Socket on the Battery Pack, and
plug the Charger into a grounded, 120V
outlet. The indicator light on the Charger
will turn red showing that the battery is
charging.
When the indicator light turns green, 4.
the Battery Pack is fully charged. This
process will take approximately 90
minutes.
Unplug the Battery Pack from the 5.
Charger and the Charger from the wall
outlet.
Note: Do not use a battery pack immediately
the Charger and Battery Packs not in
use indoors, away from children.
Installing Attachments
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Make sure the Battery Pack is
removed from the Tool before
installing accessories, or
adjusting the tool.
To install an accessory:1.
Hold the Spindle (3) with a 13mm a.
wrench (sold separately), and unthread
the Cap Screw (1) using the Hex
Wrench (505). Remove the Cap Screw
and Retainer (2).
Cutting Blade
(502)
Four Pins on
Spindle (3)
Figure 3
b. Install the desired accessory in any one
of seven forward orientations by aligning
four of the holes in the accessory over
the four pins on the Spindle.
CAUTION: Always face the accessory away
from the handle to avoid injury.
Page 10 For technical questions, please call 1-800-444-3353. SKU 67707
Retainer (2)
Scraper Blade (501) Spindle (3)
Cap Screw (1)
Figure 4
Note: When attaching the angled Cutting
Blade (502) or Scraper Blade (501),
orient the accessory as shown in Figure
4 above, so the Cap Screw (1) will be out
of the way when working.
Replace the Retainer and Cap Screw c.
while holding the accessory. Hold the
Spindle with the wrench, then tighten
securely using the Hex Wrench.
CAUTION: Make sure that the accessory is
held securely in place by the four pins
on the Spindle as you tighten the Cap
Screw.
Note:
Pad (503) to the tool, then align a sheet
of Sandpaper (504) over the pad and
press into place.
General Operating Instructions
Secure loose work pieces using a vise 1.
or clamps (not included) to prevent
movement while working.
Install desired accessory.2.
OFF
Figure 5
Power Switch
(26)
3. Make sure the Power Switch (26) is OFF.
Tool Body
Battery Pack
Battery
Button (31)
Figure 6
4. Once the Battery Pack is fully charged,
slide it into the back of housing until it
clicks into place.
Note:
housing only one way. Match up the
shape of the tool with the shape of the
housing opening. The Battery Pack
should slide easily into the housing. Do
not force it into the Tool.
Page 11For technical questions, please call 1-800-444-3353.SKU 67707
ON
Power Switch
(26)
Figure 7
5. While holding the Tool with both hands,
slide the Power Switch (26) forward to
activate.
Do not allow contact between 6.
Sandpaper, Scraper, or Blade and
workpiece until tool is at full speed.
Avoid contact with foreign objects such 7.
as metal screws and nails when sanding,
scraping, or cutting.
Do not apply excessive pressure on the 8.
Tool. Allow the Tool to do the work.
OFF
Figure 8
Power Switch
(26)
9.
Switch (26) OFF. Allow the tool to stop
completely before setting it down.
Squeeze the Battery Buttons (31) on the 10.
side of the Battery Pack and slide the
Battery Pack out of the Tool Body.
Remove the attachment and wipe clean.11.
Store the Tool and accessories in the 12.
Case (507), out of reach of children.
Page 12 For technical questions, please call 1-800-444-3353. SKU 67707
MAINTENANCE AND
SERVICING
Procedures not specically
explained in this manual must
be performed only by a qualied
technician.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Power Switch off and
remove the Battery Pack from the
tool before performing any
inspection, maintenance, or
cleaning procedures. Unplug the
Charger before performing any
inspection, maintenance or
cleaning procedures.
TO PREVENT SERIOUS INJURY
FROM TOOL FAILURE:
Do not use damaged equipment.
If abnormal noise or vibration
occurs, have the problem
corrected before further use.
BEFORE EACH USE,1. inspect the
general condition of the tool. Check for
loose screws, misalignment or binding of
moving parts, cracked or broken parts,
damaged Charger electrical wiring, and
any other condition that may affect its
safe operation. Sandpaper should not be
Scraper and Cutting Blade should be
clean and sharp.
AFTER USE,2. wipe external surfaces of
the tool with clean cloth.
3. WARNING! Do not use if either
the Battery Pack or Charger (506) are
damaged in any way.
Dispose of Battery Pack properly. Do 4.
not short, incinerate or open Charger
or Battery Pack. Keep Charger and
Battery Pack dry.
Page 13For technical questions, please call 1-800-444-3353.SKU 67707
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start. Battery Pack needs charging1.
Battery Pack not properly seated. 2.
Connection to Battery Pack 3.
damaged.
Charge Battery Pack.1.
Check that Battery Pack is fully inserted into tool 2.
so that it snaps into place.
Check that the terminals inside the tool are not 3.
technician if needed.
Tool operates slowly. Battery Pack needs charging.1.
Job is for a more powerful tool.2.
Charge Battery Pack.1.
Use a stronger powered tool.2.
Performance
decreases over time.
Accessory dull or damaged.1. Keep cutting accessories sharp. Replace as 1.
needed. Replace sandpaper when it becomes
worn or torn.
Excessive noise or
rattling.
Internal damage or wear. Have technician service tool.
Overheating. Forcing tool to work too fast.1.
Accessory misaligned. 2.
Accessory dull or damaged. 3.
Blocked motor housing vents.4.
Allow tool to work at its own rate.1.
Check and correct accessory to fence and/or 2.
table alignment.
Keep cutting accessories sharp. Replace as 3.
needed. Replace sandpaper when it becomes
worn or torn.
4.
approved dust mask/respirator while blowing dust
out of motor using compressed air.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect power supply before service.
PLEASE READ THE FOLLOWING CAREFULLY
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
Page 14 For technical questions, please call 1-800-444-3353. SKU 67707
PARTS LIST & ASSEMBLY DIAGRAM
Part Description Qty
1 Cap Screw M8 x 12 1
2 Retainer 1
3 Spindle 1
4 Rubber Casing 1
5 Circlip for shaft 26 1
6 Spring Washer 1
7 Bearing 6000 1
8 Block 1
9 Bushing 1
10 Screw ST4 x 20 4
11 Reducer 1
12 Circlip for Shaft 4 1
13 Bearing 625 1
14 Shaft 1
15 Bearing 608 1
16 Screw M3 x 18 2
17 Seal Packing Collar 2
18 Middle Cover 1
19 Seal Packing Collar 2
20 Motor 1
21 Trigger 1
22 Spring 1
23 Right Housing 1
Part Description Qty
24 1
26 Power Switch 1
27 Screw ST3.2 x 14 2
28 Electrical Contact 1
29 Screw ST3.2 x 14 4
30 Battery Cover (Front) 1
31 Battery Button 2
32 Button Spring 2
33 Pole End Plate 1
34 1
35 Protection Board 1
36 Charging Port 1
37 Screw ST2 x 8 4
38 Charging Indicator 1
39 Battery Cover (End) 1
41 Screw ST3.2 x 14 3
501 Scraper Blade 1
502 Cutting Blade 1
503 Sanding Pad 1
504 Sandpaper 4
505 Hex Wrench 1
506 Charger 1
507 Case (not shown) 1
Page 15For technical questions, please call 1-800-444-3353.SKU 67707
LIMITED 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase. This
warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to
you.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the complaint
replace the product at our election or we may elect to refund the purchase price if we cannot
readily and quickly provide you with a replacement. We will return repaired products at our
expense, but if we determine there is no defect, or that the defect resulted from causes not
within the scope of our warranty, then you must bear the cost of returning the product.
vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
