A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation.
WARNING:
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or
modifications not expressly approved by the party responsible for compliance could void your authority to
operate the equipment.
CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS.
Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of motion
or pain in your wrist when using the keyboard.
B. PRODUCT SPECIFICATION
1 Frequency band : 2402MHz-2479 MHz
2 Frequency modulation : GFSK mode
3 Transmitter power : 0dBm
4 Power Requirement: 2V~3.2V
5 Battery: 2 pieces of AA Batteries
6 Battery life time : 1200 hours reference (operating mode)
7 Operation distance : 10 M without signal disturbance and no direction limit.
8 Operating temperature : -10o C~ +40o C.
9 Storage temperature : -40o C ~ +90o C.
Contents
Getting Started.................................................................................................................. 1
Features............................................................................................................................. 1
Preparing Keyboard and Receiver.......................................................................... 1
Hardware Installation......................................................................................................... 1
USB Interface ...................................................................................................... 1
Inserting batteries........................................ ...................................................................1
Inserting batteries into keyboard
.................................. ...................................................1
Software Installation......................................................................................................... 2
Installing software for keyboard
........................................................................................ 2
On Screen display icon definition .................................................................................... 2
Working with Keyboard …………….................................................................................. 2
Keyboard.......................................................................................................................... 2
Multimedia-keys
.............................................................................................................. 2
Additional Hotkeys
.......................................................................................................... 2
Special Features of Multimedia Keys
.............................................................................. 2
Keyboard battery indicator …………….......
..................................................................... 2
Keyboard Touch pad Intruction........................................................................................ 2
How to use the keyboard properly ................................................................................... 2
Cleaning the keyboard ………………….......................................................................... 2
Troubleshooting and Tips.................................................................................................. 3
English
Thank you for choosing this Wireless keyboard. It operates with digital radio technology to ensure no hinder communication
between the keyboard and your computer without connecting cable. The transmission and receiving of keyboard are free from
angle restriction.
Features
ٛ Complies with Directive 1995/5/EC of the European Parliament and Commission.
ٛ Complies with the mutual recognition of conformity 1999 for radio and telecommunications Equipment.
ٛ Manufactured with environmental friendly recycled materials.
ٛ Fully compliant with original USB version 1.0 and 1.1.
Preparing ceiver
Before working with your new keyboard, look at the "Hardware Installation", and take a few one-time preparations.
Hardware Installation
USB Interface
1 Plug the receiver connector into an USB port.
2 SYSTEM will take around 10 sec to find your keyboard automatically.
(PS : If your OS is Windows® 98, please follow the screen instruction to complete your keyboard
installation)
Setp 2: Insert batteries
Inserting batteries in keyboard
The Keyboard requires two alkaline batteries .
ٛ (1) Please remove the battery compartment cover on the bottom of the Keyboard.
ٛ (2) Insert the two alkaline batteries in the battery compartment.
ٛ (3) Fix the battery compartment cover (1) on the bottom of keyboard again
Dangerous!! Please only use batteries of the same type.
Inserting batteries in keyboard
The keyboard requires two alkaline batteries (AA).
ٛ Remove the battery compartment cover (1) on the bottom of the keyboard by pushing it in the direction of arrow.
ٛ Insert two AA batteries.
The illustration in the battery compartment (2) shows how to insert the batteries properly.
ٛ Recover the battery compartment by pushing the locking lug (2) under the battery compartment.
Setp 3: Connect Keyboard to your dongle
ٛ Push the connect button on the top of receiver. The indicator on the top of receiver will start blinking.
ٛ Push the connect button on the bottom of the keyboard to connect
ٛ
Installing software for keyboard
ٛ Start the computer and insert the CD ROM.
ٛ Start the "Setup " program from the CD ROM and follow the instruction on the screen.
Once you have installed the software, symbols will be display on Windows task bar, the multimedia keys can be activated.
The symbols indicate which keyboard mode is active. They match the displays on ordinary keyboards. The symbol is green
Keyboard
The keyboard has several additional function keys and a battery status indicator.
a. Multimedia-keys
The following description of keys applies for the operating systems that support
these functions (e.g. Windows ME, Windows 2000 and Windows XP, special
PC/MCE function for Vista Multimedia system).
Standby mode
Depending on the setting in the BIOS or operating system the computer switches to a standby mode (not under Windows
NT).
WWW Internet mode
Use this key to start the default internet browser program on your system.
Stop
Use this key to end the playback of a title.
Play
Use this key to start the playback of a title just as you would with a normal CD player.
Channel up/down
Use this key to back or skip to the next title in the active player.
Volume up/down
This key is to increase/decreases the volume of the connected speakers.
b. Special Features of Multimedia Keys
PC/MCE
The proper function of the multimedia keys will depend on your system and is influenced by the following factors.
Keyboard Battery Indicator
The battery indicator on the screen shows you the charging state of the batteries. If the battery indicator lights
up when a key is pressed, the batteries are gradually becoming weaker. Replace the batteries soon.
Keyboard Touch Pad
Table 1 shows the gesture supported in relative coordination of the touchpad.
Touchpad
Gesture
Function
Touch
Function Diagram Touchpad
Equivalents
Moving Move cursor Slide Finger
Click (Tap) Left button
click Tap one finger
Middle button
click Middle button
click Tap 2 fingers
Right button
click Right button
click Tap 3 fingers
Double click Left button
double click Double tap one finger
Drag Left button
drag Tap and drag
Vertical two
fingers scroll Middle button
vertical scroll
Slide two fingers
vertically
Horizontal two
fingers scroll
Middle button
horizontal
scroll
Slide two fingers
horizontally
Table 1 Gesture Function Table
How to use the keyboard properly
The keyboard is ergonomically designed to ensure ease-of-use.
Inconvenient positioning of your keyboard, awkward arm movements or posture, working with the keyboard or for lengthy
periods without a break can lead to, fatigue, and potential damage to nerves, muscles, and joints. You can considerably
reduce the risk of injury if you follow the simple rules below.
ٛ Arrange your workplace in accordance with the recommendations for an ergonomic workstation provided in the
PC Operating Manual.
ٛ Position the keyboard so that you can use it without any noticeable strain. The keyboard should
be level with the upper part of you body. This prevents any tension in the shoulders and arms.
ٛ The distance between the keyboard and the edge of the desk should be 5 to 10 cm.
ٛ When typing, hold your hands and forearms so that they form as natural a line as possible. Do not
turn your hands too far to the left or right.
ٛ Keep your wrists straight while typing. Do not angle your hands upwards or downwards.
ٛ Do not rest your hands on the balls of your thumbs while typing, and do not strike the keys too hard.
ٛ Relax your hands by occasionally taking a break from typing. During these breaks you should try some
stretching exercises and rest.
Cleaning the keyboard
ٛ Use disinfectant wipes to clean the keyboard.
ٛ Do not use any solvent, which may damage the surface of your keyboard.
The keyboard does not operate following installation or is not recognized.
ٛ Make sure that the batteries have been inserted correctly according to the polarity and the receiver is
well connected.
ٛ Check that your USB port is configured properly.
ٛ Check whether the respective channels and ID are set on the receiver keyboard.
ٛ Make sure the batteries are not too weak.
ٛ Remove the batteries from the device. Please press any button on the device several times to prevent any
unexpected failure after batteries being put in.
ٛ To determine whether the keyboard or computer causes the problem, test the keyboard on a second computer
if possible; or test another keyboard on your current computer.
If you are still unable to solve the problem, please contact your dealer.
If you need to exchange the keyboard, please note that you must return it to your dealer in its original
packaging and
proof of purchase (receipt). Keep your receipt in a safe place after purchase.
