Wireless Keyboard + Mouse Kits User’s Manual
~ English ~
A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must accept any interference received, including interference
that may cause undesired operation.
WARNING:
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not
expressly approved by the party responsible for compliance could void your authority to operate the equipment.
CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS.
Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of motion or pain in
your wrist when using the keyboard.
INFORMATION FOR OPTICAL POINTING DEVICES ONLY:
This product has been tested to comply with International Standard IEC 60825-1: (1993), incld. Amd. 2(2001). This
product users LEDs that are inherently Class 1.
IMPORTANT BATTERY INFORMATION
Keep batteries out of reach of children.
Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery
compartment.
Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries).
Always remove old, weak, or worn-out batteries promptly and recycle or proper disposal of them in accordance with
Local and National Disposal Regulations.
If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacture's
instructions and Local and National Disposal Regulations. Before inserting new batteries, thoroughly clean the
compartment with a damp paper towel, or follow the battery manufacture's recommendations for cleanup. If fluid from
the battery comes into contact with skin or clothes, flush skin with water immediately.
Remove the batteries if your device is to be stored for an extended period of time without being used.
PRODUCT DISPOSAL INFORMATION
Dispose of this product in accordance with Local and National Disposal Regulations.
B. PRODUCT SPECIFICATION
1. Power requirement: 3V
2. Battery : Keyboard : 2 pieces of AAA Batteries
Mouse : 2 pieces of AA Batteries
3. Battery life time : Keyboard : 900 hours reference (operating mode)
Mouse : 300 hours reference (operating mode)
4. Operation distance : Keyboard : 10 M without signal disturbance and no direction limit.
Mouse : 10 M without signal disturbance and no direction limit.
5. Mouse resolution : 800 DPI
6. System support: Windows 2000/XP/Vista
7. Operating temperature : 0°C ~ +40°C
8. Storage temperature : -40°C ~ +65°C
MCE Wireless Keyboard User’s Manual
- 1 -
Getting Started
Thank you for choosing this 2.4G Wireless keyboard and Mouse Kits. It operates with digital radio technology to ensure
no hinder communication between the keyboard, the mouse and your computer without connecting cable.
The transmission and receiving of keyboard and mouse are free from angle restriction.
Features
Complies with Directive 1995/5/EC of the European Parliament and Commission.
Complies with the mutual recognition of conformity 1999 for radio and telecommunications Equipment.
Manufactured with environmental friendly recycled materials.
Fully compliant with original USB version 1.0 and 1.1.
Preparing Keyboard, mouse and receiver
Before working with your new keyboard and mouse, look at the "Hardware Installation", and take a few one-time
preparations.
Hardware Installation
Place the receiver at least 20 cm from other electrical devices (e.g. monitor) to achieve optimum performance.
The distance between the keyboard, mouse and receiver should not exceed 10 M.
Do not place the receiver on metal surfaces.
Do not move optical mouse on following surface -
Glass or any transparent materials
Dark surface
Mirror or reflecting surface
Mouse pad with too many colors
Rough surface.
Step 1: Connect the receiver
Plug the dongle connector into an USB port.
SYSTEM will take around 10 sec to find your keyboard and mouse automatically.
Step 2: Insert batteries
Inserting batteries in mouse
The mouse requires two NiMH AA batteries.
Remove the battery compartment cover on the bottom of the mouse
First push the battery puller in then insert two NiMH AA batteries into battery compartment.
Fix the battery compartment cover (1) on the bottom of mouse again.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions.
Refer to "Important Battery Information" for disposal instructions.
Inserting batteries in keyboard
The keyboard requires two alkaline batteries (AA).
Remove the battery compartment cover (1) on the bottom of the keyboard by pushing it in the direction of arrow.
Insert two AA batteries.
The illustration in the battery compartment (2) shows how to insert the batteries properly.
Recover the battery compartment by pushing the locking lug (2) under the battery compartment.
Note: Please do not push the channel setting button (3) at one side of the battery compartment cover. It may cause the
channel or ID change. It is the same to mouse and keyboard.
Step 3: Connection
Push the connect button on the top of receiver. The indicator will be blinking.
Push the connect button on the bottom of keyboard or mouse.
Software Installation for Displaying Modes
This software supports Windows 2000/XP/Vista.
Install the software to display keyboard and mouse modes:
Start the computer and insert the CD ROM.
Start the "Setup "program from the CD ROM and follow the instruction on the screen.
Once you have installed the software, the following symbols will display on Windows taskbar.
The symbols indicate which keyboard or mouse mode is active. They match the displays on ordinary keyboard and
mouse. The symbol is green when the respective mode is activated and light grey when it is deactivated.
MCE Wireless Keyboard User’s Manual
- 2 -
Uppercase mode (Caps Lock)
Virtual numeric keypad (Num Lock)
Stop screen output (Scroll Lock)
Working with keyboard and mouse
The following sections contain information on using the keyboard and the mouse.
Mouse
In addition to two buttons, the mouse also has a wheel that can be used as follows:
As a 3rd button: press on the wheel.
For scrolling, e.g. in documents or on Internet pages: turn the wheel forward or back.
Keyboard
The keyboard has several additional function keys and a battery status indicator.
a. Multimedia-keys
The following description of keys applies for the operating systems that support these functions (e.g. Windows
2000/XP/Vista).
Previous Track
Use this key to skip to the forward title in the active player.
Play/Pause
Use this key to start or pause for a short time the playback of a title just as you would do with a normal CD player.
Next Track
Use this key to skip to the next title in the active player.
Stop
Use this key to end the playback of a title.
Increasing the volume
This key increases the volume of the connected loudspeakers.
Decreasing the volume
This key decreases the volume of the connected loudspeakers.
Mute
Use this key to switch on/off the connected loudspeaker.
b. Special features of multimedia keys
The proper function of the multimedia keys is dependent on your system.
Low Battery Instruction
a. Keyboard battery indicator
The battery indicator on the screen shows you the charging state of the batteries. If the battery indicator lights up when a
key is pressed, the batteries are gradually becoming weaker. Replace them in the near time
b. Mouse battery indicator
The battery indicator on the screen shows you the charging state of the batteries. If the battery indicator lights up when
you are using the mouse, the batteries are gradually becoming weaker. Replace them in the near time.
Advice of using the keyboard
Inconvenient arrangement of the input and output devices, awkward arm movements or posture, or working with the
keyboard for lengthy periods without a break can lead to tenseness, fatigue, and damage to the locomotors system
(nerves, muscles, tendons, and joints).
You can considerably reduce the risk of this happening if you follow the advice given below.
Arrange your workplace in accordance with the recommendations for an ergonomic workstation provided in the PC
Operating Manual.
Position the keyboard so that you can use it without any noticeable strain. The keyboard should be level with the upper
part of you body. This prevents any tension in the shoulders and arms.
The distance between the keyboard and the edge of the desk should be 5 to 10 cm.
When typing, hold your hands and forearms so that they form as natural a line as possible. Do not turn your hands too
far to the left or right.
Keep your wrists straight while typing. Do not angle your hands upwards or downwards.
Keyboard battery low indicator
Mouse battery low indicator
MCE Wireless Keyboard User’s Manual
- 3 -
Do not rest your hands on the balls of your thumbs while typing, and do not strike the keys too hard.
Relax your hands by occasionally taking a break from typing. During these breaks you should rest your hands on the
balls of your thumbs or place your arms on the armrests of your chair.
Cleaning the keyboard and the mouse
Use disinfectant wipes to clean the keyboard and the mouse.
Do not use any dissolvent, which may damage the surface of your keyboard and mouse.
Troubleshooting and tips
The keyboard or mouse does not operate following installation or is not recognized.
Make sure that the batteries have been inserted correctly according to the polarity and the receiver is well connected.
Check that your USB port is configured properly.
Make the connection between the receiver, keyboard and mouse. Follow “Hardware Installation”/“Step 3”/Connection.
Make sure the batteries are not too weak.
Remove the batteries from the device. Please press any button on the device several times to prevent any unexpected
failure after batteries being put in.
Change the location of the receiver to have a best sensitivity.
To determine whether the keyboard, mouse or computer causes the problem test the keyboard and mouse on another
computer if possible; or test another keyboard and mouse on your current computer.
If you are still unable to solve the problem, please contact your point of sale or your dealer.
If you need to exchange the keyboard, please note that you must return it to your dealer in its original packaging and also
a produce proof of purchase (receipt). Keep your receipt in a safe place after purchase.
