User Manual

Bluetooth Keyboard Users Manual

Getting Start

Thank you for choosing this ultrathin keyboard with Bluetooth technology to ensure no hinder communication between the

keyboard and your computer without connecting cable. The transmission and receiving of keyboard are free from angle

restriction.

Features

¾ Use high technological Bluetooth (Broadcom BCM2042).

¾ Powered by 2 AAA batteries

¾ Ultra-low power consumption

Product Specification

1. Frequency Range: 2402 MHz ~ 2480 MHz

2. Input Voltage / current: 3Vdc. 30mA

3. Voltage/ Current of charger mode: 2V~3.2VDC

4. Battery State: Battery low detect voltage: 2.2V +/- 5%

Cut off detect voltage：2.0V +/- 5%

5. Operation Distance: 10 meter at free space

Hot Keys

Status light indicator

¾ Battery Status Led

Battery low : Red LED brighten 0.5s,and waiting 5sec

¾ Connect Status Led

Power ON : Blue LED brighten 5sec

Pairing ： Blue LED flash 0.5s/0.5s (3min)

Searching: Blue LED brighten 5sec continued to success

Before Use

¾ Insert Battery

¾ Set power switch is On

Troubleshooting and Tips

The keyboard does not operate following installation or is not recognized.

• Make sure the batteries are not too weak.

• To determine whether the keyboard, mouse or computer causes the problem test the keyboard and mouse on a

second computer if possible; or test another keyboard and mouse on your current computer.

If you are still unable to solve the problem, please contact your point of sale or your dealer.

If you need to exchange the keyboard, please note that you must return it to your dealer in its original packaging and

also a produce proof of purchase (receipt). Keep your receipt in a safe place after purchase.
