KT-1087 BLUETOOTH KEYBOARD USER MANUAL
Getting Start
Thank you for choosing this ultrathin keyboard with Bluetooth technology to ensure no hinder
communication between the keyboard and your computer without connecting cable. The transmission
and receiving of keyboard are free from angle restriction.
Features
¾ Use high technological Bluetooth (Broadcom BCM2042).
¾ Powered by 2 AA batteries
¾ Ultra-low power consumption
Product Specification
1. Frequency Range: 2402 MHz ~ 2480 MHz
2. Input Voltage / current: 3Vdc. 30mA
3. Battery State: Battery low detect voltage: 2.2V +/- 5%
Cut off detect voltage：2.0V +/- 5%
4. Operation Distance: 10 meter at free space
5. Operatiing Temperature: -10°C ~ +40°C
6. Storage Temperature: -40°C ~ +85°C
System Support : HP Web OS
Keyboard Dimensions : X= 285.5mm, Y= 130.2mm, Z= 6.4mm
Keyboard weight : Weight: 360+/-10g (with 2 X AA batteries)
Power Switch
The keyboard shall support a power slider with two states:
• Off – the keyboard and components shall be powered off and not draw power from the battery
• On – the keyboard shall be on and draw power based on the power behaviour defined earlier
State Indicator LED:
• When in pairing mode the LED shall flash green every 3 seconds until the keyboard has exited
pairing mode.
• When the keyboard has successfully paired to a device the LED shall show solid green for a
period of 5 seconds
• Once the keyboard is paired with a partner the LED shall not turn on when resuming from sleep
Special Function Keys:
Key Name Function Additional
Function
CARD VIEW Invokes and dismisses Card View
REMINDERS Maximize and minimize reminders
KEYBOARD Invokes and dismisses Virtual
keyboard
BRIGHTNESS
+ Increases Screen brightness
BRIGHTNESS
- Decreases Screen brightness
PLAY/PAUSE Press to play or pause song
REVERSE Press once to go to previous song Press and Hold to
rewind thru current song
FORWARD Press once to go to next song
Press and Hold to
forward thru current
song
VOL + Increase volume
VOL - Decrease Volume
MUTE Mute sound
POWER LCD Screen On and Off Press and Hold to bring
up Power modes
CONTROL Shortcut Key
LAUNCHER Invokes and dismisses Launcher
(Apps)
SYMBOL Invokes and dismisses Symbol table Sym + Key brings up
relative symbols
CURSOR
LEFT, RIGHT,
UP AND
DOWN
Moves cursor relative to its onscreen
position; in direction of arrow key
Shift + Cursor key
highlights text/content
from current cursor
position in direction of
arrow keys
SHIFT Hold Shift to capitalizes letters or
select alternate symbol See cursor keys above
TAB Indents sentence/ paragraph Tabs thru text fields
(e.g. web pages / forms)
FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference wil not occur in
a particular installation. If this equipment does cause harmful interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful Interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
The product comply with the US/Canada portable RF exposure limit set forth for an
uncontrolled environment and are safe for intended operation as described in this manual. The
further RF exposure reduction can be achieved if the product can be kept as far as possible from
the user body or set the device to lower output power if such function is available.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Industry Canada Statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio
exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit
pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris
un brouillage susceptible de provoquer un fonctionnement indésirable.
WARNING:
You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS.
Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of
motion or pain in your wrist when using the keyboard.
