Chapter1.Abouttheuserguide
Thisuserguidecontainsproductdescriptionsandinstructionsforinstallingandusingthefollowingproducts:
•ThinkPad®CompactUSBKeyboardwithTrackPoint®
•ThinkPadCompactBluetoothKeyboardwithTrackPoint
©CopyrightLenovo20131
![](/img.php?id=1930589&img=bg6.png)
2UserGuide
![](/img.php?id=1930589&img=bg7.png)
Chapter2.ThinkPadCompactUSBKeyboardwithTrackPoint
ThischapterprovidesinformationabouttheThinkPadCompactUSBKeyboardwithTrackPoint(hereafter
calledtheUSBkeyboard).
TheUSBkeyboardhasthefollowingfeatures:
•Asmartsizesavesyourdeskspace
•AnintegratedTrackPointconsistingofapointingstickandthreeclickbuttonseliminatestheneeds
foranexternalmouse
•Functionkeysprovideshortcutsforsomecommoncomputerfunctions
Theoptionpackageincludes:
•ThinkPadCompactUSBKeyboardwithTrackPoint
•Setupandwarrantyposter
•Cable
Productdescription
ThistopicprovidesageneraldescriptionoftheUSBkeyboard.
Frontview
Figure1.FrontviewoftheUSBkeyboard
1Hotkeys
Usedasshortcutsforsomecommoncomputerfunctions.Formoreinformation,see“UsingtheFn
functions”onpage7.
2TrackPoint
TheTrackPointconsistsofapointingstickandthreeclickbuttons.Formoreinformation,see““Usingthe
TrackPoint”onpage6.
©CopyrightLenovo20133
![](/img.php?id=1930589&img=bg8.png)
Rearview
Figure2.RearviewoftheUSBkeyboard
1Non-skidfeet
UsedtopreventtheUSBkeyboardfromunexpectedmoving.
2Statusindicator
WhentheUSBkeyboardissuccessfullyconnectedwiththecomputer,thestatusindicatorissolidon.
3MicroUSBconnector
UsedtoconnecttheUSBkeyboardtoacomputer.Formoreinformation,see“InstallingtheUSBkeyboard”
onpage5.
4Identicationlabel
Containsthepartnumber,versionnumber,andsomeotherproductinformation.
5Tiltfeet
Usedtoadjusttheangleofthekeyboardtoprovidecomfort.
Systemrequirements
BeforeinstallingtheUSBkeyboard,ensurethatyourcomputermeetsthefollowingrequirements:
•ThereisanavailableUSBconnectoronyourcomputer.
•Yourcomputerhasoneofthefollowingoperatingsystemsinstalled:
–Microsoft®Windows®XP(32-bit)
–MicrosoftWindowsVista(32-bitor64-bit)
–MicrosoftWindows7(32-bitor64-bit)
–MicrosoftWindows8(32-bitor64–bit)
4UserGuide
![](/img.php?id=1930589&img=bg9.png)
BeforeinstallingtheUSBkeyboard,itisrecommendedthatyouchecktheLenovo®SupportWebsiteforthe
latestsoftwareupdates,includingupdatedbasicinput/outputsystemcode(BIOS),utilityprograms,device
drivers,andothersoftwareupdates.YoucanndtheLenovoSupportWebsiteat:
http://www.lenovo.com/support
YouareresponsiblefordownloadingandinstallingdesignatedsoftwareupdatesfromtheSupportWebsite
orotherelectronicmedia,andfollowingtheinstructionsprovidedbyyourServiceProvider.
InstallingtheUSBkeyboard
ToinstalltheUSBkeyboard,dothefollowing:
1.Adjustthetiltfeettosetthekeyboardnearyourcomputertoyourpreference.
2.ConnecttheprovidedcabletoanavailableUSBconnectoronyourcomputer.Aftertheoperating
systemidentiestheUSBkeyboard,thestatusindicatorontheUSBkeyboardturnson.TheUSB
keyboardisreadyforuse.
Note:ItisrecommendedthatyouinstalltheUSBkeyboardbeforetheThinkPadCompactKeyboardwith
TrackPointdriver(hereaftercalledtheThinkpadKeyboardSuite).
InstallingthedevicedriveronWindowsoperatingsystems
ItisrecommendedthatyouinstalltheThinkPadKeyboardSuitetocustomizeadvancedsettingsbeforeyou
usetheUSBkeyboard.
IfyouareusingtheWindows7orWindows8operatingsystem,andyourcomputerisconnectedtothe
Internet,whenyouconnecttheUSBkeyboardtoyourcomputerforthersttime,amessagewillbe
displayedaskingifyouwanttoinstalltheThinkPadKeyboardSuite.ClickDownloadNowandtheThinkPad
KeyboardSuitewillbeautomaticallyinstalled.Ifthemessageisnotdisplayed,manuallyinstalltheThinkPad
KeyboardSuitebydoingthefollowing:
1.Gotohttp://support.lenovo.com/tpkeyboard.
2.LocateanddownloadtheinstallationleoftheThinkPadKeyboardSuite.
3.Double-clicktheinstallationle,andthenfollowtheinstructionsonthescreentocompletethe
installation.
4.Restartthecomputer.
UninstallingthedevicedriverfromWindowsoperatingsystems
TouninstalltheThinkPadKeyboardSuitefromtheWindowsXP,WindowsVista,Windows7,orWindows
8operatingsystem,dothefollowing:
FortheWindowsXPoperatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,clickordouble-clickAddorRemovePrograms.
3.ClickThinkPadCompactKeyboardwithTrackPointdriver,andthenclickRemove.
4.Followtheinstructionsonthescreen.
FortheWindowsVistaorWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClicktheUninstallaprogramoptionundertheProgramsmenu.
Chapter2.ThinkPadCompactUSBKeyboardwithTrackPoint5
![](/img.php?id=1930589&img=bga.png)
•ClickProgramsandFeatures.
3.SelectThinkPadCompactKeyboardwithTrackPointdriverandthenright-clickyourmouse.The
Uninstall/Changeoptionisdisplayed.
4.ClickUninstall/Change.
5.Followtheinstructionsonthescreen.
FortheWindows8operatingsystem:
•FromtheStartscreen
1.Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Then
clickSearch➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
–ClicktheUninstallaprogramoptionundertheProgramsmenu.
–ClickProgramsandFeatures.
3.SelectThinkPadCompactKeyboardwithTrackPointdriverandthenright-clickyourmouse.The
Uninstall/Changeoptionisdisplayed.
4.ClickUninstall/Change.
5.Followtheinstructionsonthescreen.
•Fromthedesktop
1.Right-clickanywhereonthedesktop,andthenclickPersonalize.ThePersonalizationwindowopens.
2.ClickControlPanelHomeinthetop-leftarea.
3.DependingonyourControlPanelmode,dooneofthefollowing:
–ClicktheUninstallaprogramoptionundertheProgramsmenu.
–ClickProgramsandFeatures.
4.SelectThinkPadCompactKeyboardwithTrackPointdriverandthenright-clickyourmouse.The
Uninstall/Changeoptionisdisplayed.
5.ClickUninstall/Change.
6.Followtheinstructionsonthescreen.
UsingtheUSBkeyboard
ThischapterprovidesinformationaboutusingtheUSBkeyboard.
UsingtheTrackPoint
TheTrackPointconsistsofapointingstickandthreeclickbuttons.Thepointingstickisusedtocontrolthe
cursor.Thethreeclickbuttonsaretheleftbutton,therightbutton,andthemiddlebutton.
Tousethepointingstick,dothefollowing:
1.Placeyourhandsattypingposition,andpressgentlyonthepointingstickinthedirectionthatyouwant
thecursortomove.Youcanpressthepointingstickawayfromyoutomovethecursorup,towardyou
tomovethecursordown,toonesideortheothertomovethecursorsideways.Thespeedatwhichthe
cursormovesdependsonthepressureyouapplytothepointingstick.
Note:Thecursormightperiodicallydrift.Stopusingthepointingstickforafewsecondsandtry
again.Thecursorwillworknormally.
6UserGuide
![](/img.php?id=1930589&img=bgb.png)
2.Toselectanitem,stopthepointingstickwhenthecursorlocatestheitemandpresstheleftorright
buttonwithyourthumb.Theleftandrightbuttonsfunctionthesameastheleftandrightbuttonsona
conventionalmouse.
Replacingthepointingstickcap
Thecapontopofthepointingstickisremovable.YoucanbuyappropriatecapsfromLenovotoreplace
yourcurrentcap.
Toremovethecaponthepointingstick,simplygraspthetopportionofthecapandpullitup.Toinstall
anewcap,alignthesquareatthebottomofthecapwiththepointingstickandpushdownuntilthecap
seatsintoposition.
Changingthepointingsticksensitivity
Whenyouareusingthepointingstick,youmightprefertousealighttouch,oryoumightwanttoapplymore
pressure.Youcanchangethewaythepointingstickrespondstoyourtouchbydoingthefollowing:
1.ClicktheThinkPadCompactKeyboardwithTrackPointicononthesystemtray.
2.IntheMousePropertieswindow,clickExternalKeyboardtab.
3.InthePointerspeedarea,movetheslidertowardSloworFastaccordingtoyourpreference.
4.ClickApply.Then,testhowthepointingstickrespondstoyournewsettingandmakeadjustmentsif
necessary.
5.ClickOKtoapplythesetting.
UsingtheThinkPadpreferredscrollingfunction
Youcanscrollthroughanactivewindowbymovingthepointingstickwhilepressingthemiddlebutton.
YoualsocanscrollthroughaninactivewindowwiththeThinkPadPreferredScrollingfunction.Tocongure
thescrollingfunction,dothefollowing:
1.ClicktheThinkPadCompactKeyboardwithTrackPointicononthesystemtray.
2.IntheMousePropertieswindow,clicktheExternalKeyboardtab.
3.Dependingonyourneeds,dooneofthefollowing:
•Toscrollthroughactivewindowsjustasaconventionalmouse,clearThinkPadPreferredScrolling.
•Toscrollthroughinactivewindows,selectThinkPadPreferredScrolling.
4.ClickOK.
Note:Ifyounditcannotscrollonsomeapplications,clearThinkPadPreferredScrollingtogetmore
compliance.
Usingthefunctionkeys
ThefollowingtabledescribesthefunctionkeysandFnkeycombinations.Bydefault,theUSBkeyboardacts
thestandardF1-F12function.AfterinstallingtheThinkpadKeyboardSuite,youcanachievethehotkey
functionbypressingFn+Fx(wherexrepresents1to12)keys.
FunctionkeyFunction
Fn+EscSwitchbetweenthehotkeyandthestandardF1-F12function.
Mutethespeaker.
Chapter2.ThinkPadCompactUSBKeyboardwithTrackPoint7
![](/img.php?id=1930589&img=bgc.png)
FunctionkeyFunction
Decreasethevolume.
Increasethevolume.
Mutethemicrophone.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Decreasethebrightness.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Increasethebrightness.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Switchbetweenthecomputerdisplayandanexternalmonitor(Windowswillshow
thesedisplayoptions).
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Enableordisablethebuilt-inwirelessnetworkingfeatures.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
•OpenControlPanel.
•OpenSettingsPanel(fortheWindows8operatingsystem).
•Navigatetosearchdependingonyouractiveapplications.
•OpenSearchPanel(fortheWindows8operatingsystem).
•Viewopenapplications.
•Switchbetweenopenapplications(fortheWindowsXPoperatingsystem).
•OpenMyComputer.
•Viewallapplications(fortheWindows8operatingsystem).
Fn+SHasthesamefunctionastheSysRqkeyonaconventionalkeyboard.
Fn+BHasthesamefunctionastheBreakkeyonaconventionalkeyboard.
Fn+KHasthesamefunctionastheNumericLockkeyonaconventionalkeyboard.
Fn+PHasthesamefunctionasthePausekeyonaconventionalkeyboard.
8UserGuide
![](/img.php?id=1930589&img=bgd.png)
IftheFnkeycombinationsdonotworkcorrectlyonsomeThinkPadcomputerswiththeWindowsXP
operatingsystem,ensurethatthecomputerhasthelatestversionoftheLenovoSystemInterfacedriveror
thehotkeyutilitydriverinstalled.
Themostup-to-datesoftwareanddevicedriversforyourThinkPadcomputerarealwaysavailablefor
downloadat:
http://www.lenovo.com/support
Notes:
•EnsurethattheFnkeycombinationsarefunctionalonthekeyboardofyourThinkPadcomputer.Thereare
softwaredependenciestogetthemostcompleteFnkeycombinationsupportforyourThinkPadcomputer.
•MostoftheFnkeycombinationsdonotworkwiththeThinkPadSLseriesnotebookcomputers,Lenovo
desktopcomputers,andcomputersfromothermanufacturers.
•SomeFnkeycombinationshavedifferentfunctionsondifferentThinkPadcomputermodels.
•OntheWindows8operatingsystem,whenyoupressFn+Esc,hotkeyF4,ortheCapsLockkeyfortherst
time,anOnScreenDisplaywindowmightbedisplayed.Ifyouwanttoshowtheonscreendisplay,click
OK.Ifyoudonotwanttoshowtheonscreendisplay,clickNo,thankyou.Tochangetheonscreen
displaysetting,clicktheExternalKeyboardtabintheMousePropertywindow,selectOnScreen
Displays.WhentheboxbeforeOnScreenDisplaysisingrey,itmeansthattheUSBkeyboardfollows
thesystemdefaultsetting,youcanchangethesystemsettingbyclickingAdvancedOSDsetting.
FormoreinformationabouttheFnkeycombinations,refertotheAccessHelpinformationsystemthat
comeswiththeThinkPadcomputer.
Troubleshooting
ThischaptercontainstroubleshootinginformationfortheUSBkeyboard.
Problem:AllorsomeoftheFnfunctionkeycombinationsorfunctionkeysdonotwork.
Solution:Readthefollowingforsolutionsorexplanations:
•EnsurethatyouhavecorrectlyinstalledtheThinkPadKeyboardSuite.
•EnsurethatalltheFnfunctionkeycombinationsarefunctionalonthekeyboardofyourThinkPad
computer.TherearesoftwaredependenciestogetthemostcompleteFnkeyandhotkeycombination
supportforyourThinkPadcomputer.YoucangetmoredetailedinformationabouttheFnfunctionkey
combinationsfromthedocumentationthatcomeswithyourThinkPadcomputer.Youmightneedto
downloadtheupdatedsoftwarecomponentsforyourThinkPadcomputerat:
http://www.lenovo.com/support
•TheFnfunctionkeycombinationsworkwithalltheThinkPadcomputersexceptThinkPadSLseries
notebookcomputers.MostoftheFnfunctionkeycombinationsdonotworkwithThinkPadSLseries
notebookcomputers,Lenovodesktopcomputers,orcomputersfromothermanufacturers.
•ItisnormalifyoufoundsomeoftheFnfunctionkeycombinationsactdifferentlyondifferentThinkPad
computermodelsduetothedifferencesoftheapplicationsinstalledonyournotebookcomputers.
•Somefunctionkeysarenotsupporteddependingonyouroperatingsystemandcomputer.
Problem:TheTrackPointcursordriftswhenthecomputeristurnedonorafterthecomputerresumes
normaloperation.
Solution:ThecursormightdriftwhenyouarenotusingtheTrackPointduringnormaloperation.Thisis
anormalfeatureoftheTrackPointandisnotadefect.Cursordriftingmightoccurforseveralseconds
underthefollowingconditions:
Chapter2.ThinkPadCompactUSBKeyboardwithTrackPoint9
![](/img.php?id=1930589&img=bge.png)
•Thecomputeristurnedon.
•Thecomputerresumesnormaloperation.
•TheTrackPointpointingstickiskeptpressedforalongtime.
•Thetemperaturechanges.
Tosolvetheproblem,youcantryreconnectingtheUSBkeyboardorrestartyourcomputer.
Problem:Ipressedabuttononce,butthecomputerrespondedasifIpressedittwice.
Solution:Dependingonyouroperatingsystem,adjustthekeyboardrepeatdelayorrepeatratesettings
bydoingoneofthefollowing:
•ForWindowsXPandWindowsVista:
1.DependingonyourStartmenumode,clickStart➙ControlPanelorStart➙Settings➙Control
Panel
2.DependingonyourControlPanelmode,clickordouble-clickKeyboard.
3.ClicktheSpeedtab.
4.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
5.ClickOK.
.
•ForWindows7:
1.DependingonyourStartmenumode,clickStart➙ControlPanelorStart➙Settings➙Control
Panel
2.ClicktheViewbymenuandselectSmalliconsorLargeicons.TheAllControlPanelItems
categoryisexpanded.
3.ClickKeyboard.
4.ClicktheSpeedtab.
5.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
6.ClickOK.
•ForWindows8:
–FromtheStartscreen
1.Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms,and
thenclickSearch➙ControlPaneltoopenControlPanel.
ClicktheViewbymenuandselecttheSmalliconsorLargeiconsview.TheAllControlPanel
Itemscategoryisexpanded.
2.ClickKeyboard.
3.ClicktheSpeedtab.
4.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
5.ClickOK.
–Fromthedesktop
1.Right-clickanywhereonthedesktop,andthenclickPersonalize.ThePersonalizationwindowis
displayed.
2.ClickControlPanelHomeinthetop-leftareatoopenControlPanel.
3.ClicktheViewbymenuandselecttheSmalliconsorLargeiconsview.TheAllControlPanel
Itemscategoryisexpanded.
4.ClickKeyboard.
10UserGuide
![](/img.php?id=1930589&img=bgf.png)
5.ClicktheSpeedtab.
6.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
7.ClickOK.
Problem:TheThinkPadKeyboardSuitecannotbeautomaticallyinstalledwhenIconnectthekeyboardto
mycomputerforthersttime.
Solution:Tosolvetheproblem,dothefollowing:
1.EnsurethatyouareusingtheWindows7orWindows8operatingsystem.
2.EnsurethatyourcomputerhasbeenconnectedtotheInternet.
3.EnsurethatyouhaveenabledtheautomaticWindowsupdatefeaturebydoingthefollowing:
a.OpenControlPanel.
b.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickHardwareandSound➙DevicesandPrinters.
•ClickDevicesandPrinters.
c.Right-clickyourcomputericonundertheDevicesmenu,andthenselectDeviceinstallation
Settings.
d.FollowtheinstructionsonthescreentoenabletheautomaticWindowsupdatefeature.
4.EnsurethatyouhaveinstalledallWindowsupdatesbydoingthefollowing:
a.OpenControlPanel.
b.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickSystemandSecurity➙WindowsUpdate.
•ClickWindowsUpdate.
c.ClickCheckforupdatestoinstallWindowsupdates.
5.DisconnecttheUSBkeyboardfromthecomputerandthenreconnectit.
6.Iftheabovetipsstillarenotworkable,itmightbecausedbytheversionorlanguageofyouroperating
system.Youcanmanuallyinstallthedriverbydoingthefollowing:
a.Gotohttp://support.lenovo.com/tpkeyboard.
b.Locateanddownloadtheinstallationleofthedriver.
c.Double-clicktheinstallationle,andthenfollowtheinstructionsonthescreentocompletethe
installation.
Problem:IttakesalongtimetopairtheUSBkeyboardwiththecomputerontheWindows7operating
system.
Solution:Itisnotaproblem.WhentheclockontheUSBkeyboardicondisappears,theUSBkeyboardis
successfullypairedwiththecomputer.Ifitfails,tryreconnectingitagain.
Productspecications
ThefollowingtabledescribestheUSBkeyboardspecications.
Keys84/85/89keys(variesbycountry)
ColorRavenblack
Dimensions(heightxwidthxdepth)305.5mmx164.0mmx13.5mm(notincludingthetiltfeet)
Chapter2.ThinkPadCompactUSBKeyboardwithTrackPoint11
![](/img.php?id=1930589&img=bg10.png)
WeightAbout441g(Includingthecable)
Connectortype4-pinUSBTypeA
Cablelength1.5m(4.92feet)
Operatingvoltage+5V(Typical)
Powerconsumption100mAmaximum
SysteminterfaceUSB
SupportedoperatingsystemWindows8(32-bitand64-bit)
Windows7(32-bitand64-bit)
WindowsVista(32-bitand64-bit)
WindowsXP(32-bit)
12UserGuide
![](/img.php?id=1930589&img=bg11.png)
Chapter3.ThinkPadCompactBluetoothKeyboardwith
TrackPoint
ThischapterprovidesinformationabouttheThinkPadCompactBluetoothKeyboardwithTrackPoint
(hereaftercalledtheBluetoothkeyboard).
Productdescription
ThistopicprovidesageneraldescriptionoftheBluetoothkeyboard.
Frontview
Figure3.FrontviewoftheBluetoothkeyboard
1Hotkeys
Usedasshortcutsforsomecommoncomputerfunctions.Formoreinformation,see“UsingtheFn
functions”onpage19.
2Statusindicator
UsedtoindicatethestatusoftheBluetoothkeyboard.
StatusColorDescription
FadinginGreenTheBluetoothkeyboardisturnedon.
BlinkingtwiceatonesecondintervalsGreenTheBluetoothkeyboardisinpairingmodeoris
establishingaconnectionwiththecomputer.
BlinkingforvetimesGreenTheBluetoothkeyboardhasestablishedaconnection
withthecomputer.
FadingoutGreenTheBluetoothkeyboardisturnedoff.
BlinkingforthreetimesAmberThebatterypoweroftheBluetoothkeyboardislow.
©CopyrightLenovo201313
![](/img.php?id=1930589&img=bg12.png)
3Powerswitch:UsedtoturnonorturnofftheBluetoothkeyboard.
ToturnontheBluetoothkeyboard,slidedownthepowerswitchandpressitforonesecond.Thestatus
indicatorstartstofadein.ToturnofftheBluetoothkeyboard,slidedownthepowerswitchandholditforat
leastthreeseconds.Thestatusindicatorstartstofadeout.
Figure4.TurnonandturnofftheBluetoothkeyboard
Note:Tosavethebatterypower,turnofftheBluetoothkeyboardwhenitisnotinuse.
4TrackPoint
TheTrackPointconsistsofapointingstickandthreeclickbuttons.Formoreinformation,see““Usingthe
TrackPoint”onpage6.
Rearview
Figure5.RearviewoftheBluetoothkeyboard
1Non-skidfeet
UsedtopreventtheBluetoothkeyboardfromunexpectedmoving.
2NFCtag
UsedforpairingtheBluetoothkeyboardbyNearFieldCommunication(NFC)function.
3Chargingindicator
UsedtoindicatethechargingstatusoftheBluetoothkeyboard.WhentheBluetoothkeyboardisincharging,
thechargingindicatorisblinking.WhentheBluetoothkeyboardisfullycharged,thechargingindicator
issolidon.
14UserGuide
![](/img.php?id=1930589&img=bg13.png)
4MicroUSBconnector
YoucanchargetheBluetoothkeyboardbyinsertingoneendoftheprovidedcabletotheMicroUSB
connectorandanotherendtothecomputer.
5Identicationlabel
Containsthepartnumber,versionnumber,andsomeotherproductinformation.
6Tiltfeet
Usedtoadjusttheangleofthekeyboardtoprovidecomfort.
Systemrequirements
BeforeinstallingtheBluetoothkeyboard,ensurethatyourcomputermeetsthefollowingrequirements:
•ThereisanavailableIntegratedBluetoothhostonyourcomputer.
•Yourcomputerhasoneofthefollowingoperatingsystemsinstalled:
–MicrosoftWindowsXP(32-bit)
–MicrosoftWindowsVista(32-bitor64-bit)
–MicrosoftWindows7(32-bitor64-bit)
–MicrosoftWindows8(32-bitor64–bit)
BeforeinstallingtheBluetoothkeyboard,itisrecommendedthatyouchecktheLenovoSupportWebsitefor
thelatestsoftwareupdates,includingupdatedbasicinput/outputsystemcode(BIOS),utilityprograms,
devicedrivers,andothersoftwareupdates.YoucanndtheLenovoSupportWebsiteat:
http://www.lenovo.com/support
YouareresponsiblefordownloadingandinstallingdesignatedsoftwareupdatesfromtheSupportWebsite
orotherelectronicmedia,andfollowingtheinstructionsprovidedbyyourServiceProvider.
PairingtheBluetoothkeyboardwiththecomputer
ToestablishaconnectionandexchangedatabetweentheBluetoothkeyboardandthecomputer,youneed
topairtheBluetoothkeyboardwiththecomputer.
Notes:
•ItisrecommendedthatyoupairtheBluetoothkeyboardbeforeinstalltheThinkPadCompactKeyboard
withTrackPointdriver(hereaftercalledtheThinkPadKeyboardSuite).
•OnceyouhavesuccessfullypairedtheBluetoothkeyboardwiththecomputer,youjustneedtoturnon
thepowerswitchontheBluetoothkeyboardeachtimeyouuseit.Thestatusindicatorwillblinkin
greenforvetimesandthenturnsoff.
Dependingonyouroperatingsystem,youcanpairtheBluetoothkeyboardwiththecomputerbydoingone
ofthefollowing:
FortheWindowsXPoperatingsystem:
1.TurnontheBluetoothradiointhecomputer.
2.Double-clicktheMyBluetoothPlacesiconintheWindowsnoticationareaoronthedesktop.
Chapter3.ThinkPadCompactBluetoothKeyboardwithTrackPoint15
![](/img.php?id=1930589&img=bg14.png)
3.SlidedownthepowerswitchandpressitforonesecondtoturnontheBluetoothintheBluetooth
keyboard.Thestatusindicatorstartstoash.
4.Dependingonyourmenumode,clickViewdevicesinrangeorSearchfordevicesinrange.
5.Double-clicktheThinkPadCompactBluetoothKeyboardwithTrackPointiconinthelist.
6.TypethepasscodeshownonthecomputerscreenintotheBluetoothkeyboard,andthenpress
Enter.Thepairingprocessbegins.Afterthestatusindicatorturnsoff,theBluetoothkeyboardhas
beensuccessfullypairedwiththecomputerandaconnectionisestablishedbetweentheBluetooth
keyboardandthecomputer.
7.ClickClosewhenawindowisdisplayedtoconrmthattheBluetoothkeyboardisconnectedwith
theoperatingsystem.
FortheWindowsVistaorWindows7operatingsystem:
1.TurnontheBluetoothradiointhecomputer.
2.ClickStart➙ControlPanel,andthendependingontheoperatingsystemyouareusing,doone
ofthefollowing:
•FortheWindowsVistaoperatingsystem,double-clickBluetoothDevices,andthenclickAdd
WirelessDevice.
•FortheWindows7operatingsystem,clickDevicesandPrinters➙Addadevice.
3.SlidedownthepowerswitchandpressitforonesecondtoturnontheBluetoothintheBluetooth
keyboard.Thestatusindicatorstartstoash.
4.SelecttheThinkPadCompactBluetoothKeyboardwithTrackPointiconfromthelistandclickNext.
5.TypethepasscodeshownonthecomputerscreenintotheBluetoothkeyboard,andthenpress
Enter.Thepairingprocessbegins.Afterthestatusindicatorturnsoff,theBluetoothkeyboardhas
beensuccessfullypairedwiththecomputerandaconnectionisestablishedbetweentheBluetooth
keyboardandthecomputer.
6.ClickClosewhenawindowisdisplayedtoconrmthattheBluetoothkeyboardisconnectedwith
theoperatingsystem.
FortheWindows8operatingsystem:
1.TurnontheBluetoothradiointhecomputer.
2.Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms,click
Settings➙ChangePCSettings➙Devices.
3.SlidedownthepowerswitchandpressitforonesecondtoturnontheBluetoothintheBluetooth
keyboard.Thestatusindicatorstartstoash.
4.SelecttheKeyboard(ThinkPadCompactBluetoothKeyboardwithTrackPoint)iconfromthelist
andclickNext.
5.TypethepasscodeshownonthecomputerscreenintotheBluetoothkeyboard,andthenpressEnter.
Thepairingprocessbegins.Afterthestatusindicatorturnsoff,theBluetoothkeyboardhasbeen
successfullypairedwiththecomputerandaconnectionisestablishedbetweentheBluetoothkeyboard
andthecomputer.
6.ClickClosewhenawindowisdisplayedtoconrmthattheBluetoothkeyboardisconnectedwith
theoperatingsystem.
Note:Ifawindowisdisplayedindicatingthattheconnectionfails,right-clicktheThinkPadCompact
BluetoothKeyboardwithTrackPointiconandselectDisabletodisabletheBluetoothkeyboard.Then,pair
theBluetoothkeyboardwiththecomputeragain.
16UserGuide
![](/img.php?id=1930589&img=bg15.png)
AftertheoperatingsystemidentiestheBluetoothkeyboard,theBluetoothkeyboardwillbereadyforuse.
Foradditionalinformationonthisproduct,goto:
http://www.lenovo.com/support/keyboards
PairingbyNFCFunction:
Forsomeoperatingsystems,youalsocanpairtheBluetoothkeyboardwiththeNFC-enabledcomputerby
NFCfunction.TheNFCtagisinthebottom-leftcorneroftheBluetoothkeyboardbackside.
TopairtheBluetoothkeyboardbyNFCfunction,dothefollowing:
1.AligntheNFCreaderwiththeNFCtagontheBluetoothkeyboard.
2.Awindowisdisplayedtoconrmwhetheryouwanttoaddadevice.
3.Clickthewindow.Thestatusindicatorashes5timesandfadeout.TheBluetoothkeyboardis
connectedwiththecomputer.
InstallingthedevicedriveronWindowsoperatingsystems
ItisrecommendedthatyouinstalltheThinkPadKeyboardSuitetocustomizeadvancedsettingsbeforeyou
usetheBluetoothkeyboard.
IfyouareusingtheWindows7orWindows8operatingsystem,andyourcomputerisconnectedtothe
Internet,whenyouconnectthekeyboardtoyourcomputerforthersttime,amessagewillbedisplayed
askingifyouwanttoinstalltheThinkPadKeyboardSuite.ClickDownloadNowandtheThinkPadKeyboard
Suitewillbeautomaticallyinstalled.Ifthemessageisnotdisplayed,manuallyinstalltheThinkPadKeyboard
Suitebydoingthefollowing:
1.Gotohttp://support.lenovo.com/tpkeyboard.
2.LocateanddownloadtheinstallationleoftheThinkPadKeyboardSuite.
3.Double-clicktheinstallationle,andthenfollowtheinstructionsonthescreentocompletethe
installation.
4.Restartthecomputer,andtheThinkPadKeyboardSuiteisinstalledonyourcomputer.
UninstallingthedevicedriverfromWindowsoperatingsystems
TouninstalltheThinkPadKeyboardSuitefromtheWindowsXP,WindowsVista,Windows7,orWindows
8operatingsystem,dothefollowing:
FortheWindowsXPoperatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,clickordouble-clickAddorRemovePrograms.
3.ClickThinkPadCompactKeyboardwithTrackPointdriver,andthenclickRemove.
4.Followtheinstructionsonthescreen.
FortheWindowsVistaorWindows7operatingsystem:
1.ClickStart➙ControlPanelorStart➙Settings➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
•ClicktheUninstallaprogramoptionundertheProgramsmenu.
•ClickProgramsandFeatures.
3.SelectThinkPadCompactKeyboardwithTrackPointdriverandthenright-clickyourmouse.The
Uninstall/Changeoptionisdisplayed.
Chapter3.ThinkPadCompactBluetoothKeyboardwithTrackPoint17
![](/img.php?id=1930589&img=bg16.png)
4.ClickUninstall/Change.
5.Followtheinstructionsonthescreen.
FortheWindows8operatingsystem:
•FromtheStartscreen
1.Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Then
clickSearch➙ControlPanel.
2.DependingonyourControlPanelmode,dooneofthefollowing:
–ClicktheUninstallaprogramoptionundertheProgramsmenu.
–ClickProgramsandFeatures.
3.SelectThinkPadCompactKeyboardwithTrackPointdriverandthenright-clickyourmouse.The
Uninstall/Changeoptionisdisplayed.
4.ClickUninstall/Change.
5.Followtheinstructionsonthescreen.
•Fromthedesktop
1.Right-clickanywhereonthedesktop,andthenclickPersonalize.ThePersonalizationwindowopens.
2.ClickControlPanelHomeinthetop-leftarea.
3.DependingonyourControlPanelmode,dooneofthefollowing:
–ClicktheUninstallaprogramoptionundertheProgramsmenu.
–ClickProgramsandFeatures.
4.SelectThinkPadCompactKeyboardwithTrackPointdriverandthenright-clickyourmouse.The
Uninstall/Changeoptionisdisplayed.
5.ClickUninstall/Change.
6.Followtheinstructionsonthescreen.
UsingtheBluetoothkeyboard
ThischapterprovidesinformationaboutusingtheBluetoothkeyboard.
UsingtheTrackPoint
TheTrackPointconsistsofapointingstickandthreeclickbuttons.Thepointingstickisusedtocontrolthe
cursor.Thethreeclickbuttonsaretheleftbutton,therightbutton,andthemiddlebutton.
Tousethepointingstick,dothefollowing:
1.Placeyourhandsattypingposition,andpressgentlyonthepointingstickinthedirectionthatyouwant
thecursortomove.Youcanpressthepointingstickawayfromyoutomovethecursorup,towardyou
tomovethecursordown,toonesideortheothertomovethecursorsideways.Thespeedatwhichthe
cursormovesdependsonthepressureyouapplytothepointingstick.
Note:Thecursormightperiodicallydrift.Stopusingthepointingstickforafewsecondsandtry
again.Thecursorwillworknormally.
2.Toselectanitem,stopthepointingstickwhenthecursorlocatestheitemandpresstheleftorright
buttonwithyourthumb.Theleftandrightbuttonsfunctionthesameastheleftandrightbuttonsona
conventionalmouse.
18UserGuide
![](/img.php?id=1930589&img=bg17.png)
Replacingthepointingstickcap
Thecapontopofthepointingstickisremovable.YoucanbuyappropriatecapsfromLenovotoreplace
yourcurrentcap.
Toremovethecaponthepointingstick,simplygraspthetopportionofthecapandpullitup.Toinstall
anewcap,alignthesquareatthebottomofthecapwiththepointingstickandpushdownuntilthecap
seatsintoposition.
Changingthepointingsticksensitivity
Whenyouareusingthepointingstick,youmightprefertousealighttouch,oryoumightwanttoapplymore
pressure.Youcanchangethewaythepointingstickrespondstoyourtouchbydoingthefollowing:
1.ClicktheThinkPadCompactKeyboardwithTrackPointicononthesystemtray.
2.IntheMousePropertieswindow,clickExternalKeyboardtab.
3.InthePointerspeedarea,movetheslidertowardSloworFastaccordingtoyourpreference.
4.ClickApply.Then,testhowthepointingstickrespondstoyournewsettingandmakeadjustmentsif
necessary.
5.ClickOKtoapplythesetting.
UsingtheThinkPadpreferredscrollingfunction
Youcanscrollthroughanactivewindowbymovingthepointingstickwhilepressingthemiddlebutton.
YoualsocanscrollthroughaninactivewindowwiththeThinkPadPreferredScrollingfunction.Tocongure
thescrollingfunction,dothefollowing:
1.ClicktheThinkPadCompactKeyboardwithTrackPointicononthesystemtray.
2.IntheMousePropertieswindow,clicktheExternalKeyboardtab.
3.Dependingonyourneeds,dooneofthefollowing:
•Toscrollthroughactivewindowsjustasaconventionalmouse,clearThinkPadPreferredScrolling.
•Toscrollthroughinactivewindows,selectThinkPadPreferredScrolling.
4.ClickOK.
Note:Ifyounditcannotscrollonsomeapplications,clearThinkPadPreferredScrollingtogetmore
compliance.
ChargingtheBluetoothkeyboard
YoucanchargetheBluetoothkeyboardbyconnectingtheBluetoothkeyboardtothecomputerwiththe
providedcable.ItisrecommendedthatyoufullychargetheBluetoothkeyboardbeforeyouuseitforthe
rsttime.Anaveragefullchargingtimeis2.5to3hours.WhentheBluetoothkeyboardisincharging,the
chargingindicatorisblinking.WhentheBluetoothkeyboardisfullychargedwiththechargingindicatorsolid
on,youarerecommendedtodisconnecttheBluetoothkeyboardfromthecomputer.KeepingtheBluetooth
keyboardconnectedtothecomputerwillnotkeeponcharging.WhenyouwanttochargetheBluetooth
keyboardforanothertime,reconnecttheBluetoothkeyboardtothecomputer.Itisrecommendedthatyou
chargethebatteryatleastonetimeineverysixmonths.
Usingthefunctionkey
ThefollowingtabledescribesthefunctionsofFnkeysandFnkeycombinations.TheBluetoothkeyboard
actsthedefaulthotkeyfunction.AfterinstallingtheThinkpadKeyboardSuite,youcanachievethestandard
F1-F12functionbypressingFn+Fx(wherexrepresents1to12)keys.
Chapter3.ThinkPadCompactBluetoothKeyboardwithTrackPoint19
![](/img.php?id=1930589&img=bg18.png)
FunctionkeyFunction
Fn+EscSwitchthedefaultFnfunctionbetweenthehotkeyandthestandardF1-F12
funtion.
Mutethespeaker.
Decreasethevolume.
Increasethevolume.
Mutethemicrophone.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Decreasethebrightness.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Increasethebrightness.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Switchbetweenthecomputerdisplayandanexternalmonitor(Windowswill
showthesedisplayoptions).
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
Enableordisablethebuilt-inwirelessnetworkingfeatures.Awindowwillbe
displayedwarningthatturningoffthewirelesswilldisconnectthewirelessmice
andkeyboards.
Note:ThisfunctionkeymightnotworkontheWindowsXPandWindowsVista
operatingsystems.
•OpenControlPanel.
•OpenSettingsPanel(fortheWindows8operatingsystem).
•Navigatetosearchdependingonyouractiveapplications.
•OpenSearchPanel(fortheWindows8operatingsystem).
•Viewopenapplications.
•Switchbetweenopenapplications(fortheWindowsXPoperatingsystem).
•OpenMyComputer.
•Viewallapplications(fortheWindows8operatingsystem).
Fn+SHasthesamefunctionastheSysRqkeyonaconventionalkeyboard.
20UserGuide
![](/img.php?id=1930589&img=bg19.png)
FunctionkeyFunction
Fn+BHasthesamefunctionastheBreakkeyonaconventionalkeyboard.
Fn+KHasthesamefunctionastheNumerickeyonaconventionalkeyboard.
Fn+PHasthesamefunctionasthePausekeyonaconventionalkeyboard.
Fn+DeleteUnpairtheBluetoothkeyboardfromthecomputer.
Note:IfyouhaveconguredtheBluetoothkeyboardinonecomputerand
wanttocongureitinanothercomputer,itisrecommendedthatyouunpairthe
Bluetoothkeyboardfromthepreviouscomputerrst.
IftheFnkeycombinationsdonotworkcorrectlyonsomeThinkPadcomputerswiththeWindowsXP
operatingsystem,ensurethatthecomputerhasthelatestversionoftheLenovoSystemInterfacedriver
installed.
Themostup-to-datesoftwareanddevicedriversforyourThinkPadcomputerarealwaysavailablefor
downloadat:
http://www.lenovo.com/support
Notes:
•EnsurethattheFnkeycombinationsarefunctionalonthekeyboardofyourThinkPadcomputer.Thereare
softwaredependenciestogetthemostcompleteFnkeycombinationsupportforyourThinkPadcomputer.
•MostoftheFnkeycombinationsdonotworkwiththeThinkPadSLseriesnotebookcomputers,Lenovo
desktopcomputers,andcomputersfromothermanufacturers.
•SomeFnkeycombinationshavedifferentfunctionsondifferentThinkPadcomputermodels.
•OntheWindows8operatingsystem,whenyoupressFn+Esc,hotkeyF4,ortheCapsLockkeyfortherst
time,anOnScreenDisplaywindowmightbedisplayed.Ifyouwanttoshowtheonscreendisplay,click
OK.Ifyoudonotwanttoshowtheonscreendisplay,clickNo,thankyou.Tochangetheonscreen
displaysetting,clicktheExternalKeyboardtabintheMousePropertywindow,selectOnScreen
Displays.WhentheboxbeforeOnScreenDisplaysisingrey,itmeansthattheBluetoothkeyboard
followsthesystemdefaultsetting,youcanchangethesystemsettingbyclickingAdvancedOSDsetting.
FormoreinformationabouttheFnkeycombinations,refertotheAccessHelpinformationsystemthat
comeswiththeThinkPadcomputer.
Troubleshooting
ThischaptercontainstroubleshootinginformationfortheBluetoothkeyboard.
Problem:AllorsomeoftheFnfunctionkeycombinationsorfunctionkeysdonotwork.
Solution:Readthefollowingforsolutionsorexplanations:
•EnsurethatyouhavecorrectlyinstalledtheThinkPadKeyboardSuite.
•EnsurethatalltheFnfunctionkeycombinationsarefunctionalonthekeyboardofyourThinkPad
computer.TherearesoftwaredependenciestogetthemostcompleteFnkeyandhotkeycombination
supportforyourThinkPadcomputer.YoucangetmoredetailedinformationabouttheFnfunctionkey
combinationsfromthedocumentationthatcomeswithyourThinkPadcomputer.Youmightneedto
downloadtheupdatedsoftwarecomponentsforyourThinkPadcomputerat:
http://www.lenovo.com/support
Chapter3.ThinkPadCompactBluetoothKeyboardwithTrackPoint21
![](/img.php?id=1930589&img=bg1a.png)
•TheFnfunctionkeycombinationsworkwithalltheThinkPadcomputersexceptThinkPadSLseries
notebookcomputers.MostoftheFnfunctionkeycombinationsdonotworkwithThinkPadSLseries
notebookcomputers,Lenovodesktopcomputers,orcomputersfromothermanufacturers.
•ItisnormalifyoufoundsomeoftheFnfunctionkeycombinationsactdifferentlyondifferentThinkPad
computermodelsduetothedifferencesoftheapplicationsinstalledonyournotebookcomputers.
•Somefunctionkeysarenotsupporteddependingonyouroperatingsystemandcomputer.
Problem:TheTrackPointcursordriftswhenthecomputeristurnedonorafterthecomputerresumes
normaloperation.
Solution:ThecursormightdriftwhenyouarenotusingtheTrackPointduringnormaloperation.Thisis
anormalfeatureoftheTrackPointandisnotadefect.Cursordriftingmightoccurforseveralseconds
underthefollowingconditions:
•Thecomputeristurnedon.
•Thecomputerresumesnormaloperation.
•TheTrackPointpointingstickiskeptpressedforalongtime.
•Thetemperaturechanges.
Tosolvetheproblem,youcantryreconnectingtheBluetoothkeyboardorrestartyourcomputer.
Problem:Ipressedabuttononce,butthecomputerrespondedasifIpressedittwice.
Solution:Dependingonyouroperatingsystem,adjustthekeyboardrepeatdelayorrepeatratesettings
bydoingoneofthefollowing:
•ForWindowsXPandWindowsVista:
1.DependingonyourStartmenumode,clickStart➙ControlPanelorStart➙Settings➙Control
Panel
2.DependingonyourControlPanelmode,clickordouble-clickKeyboard.
3.ClicktheSpeedtab.
4.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
5.ClickOK.
.
•ForWindows7:
1.DependingonyourStartmenumode,clickStart➙ControlPanelorStart➙Settings➙Control
Panel
2.ClicktheViewbymenuandselectSmalliconsorLargeicons.TheAllControlPanelItems
categoryisexpanded.
3.ClickKeyboard.
4.ClicktheSpeedtab.
5.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
6.ClickOK.
•ForWindows8:
–FromtheStartscreen
1.Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms,and
thenclickSearch➙ControlPaneltoopenControlPanel.
ClicktheViewbymenuandselecttheSmalliconsorLargeiconsview.TheAllControlPanel
Itemscategoryisexpanded.
22UserGuide
![](/img.php?id=1930589&img=bg1b.png)
2.ClickKeyboard.
3.ClicktheSpeedtab.
4.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
5.ClickOK.
–Fromthedesktop
1.Right-clickanywhereonthedesktop,andthenclickPersonalize.ThePersonalizationwindowis
displayed.
2.ClickControlPanelHomeinthetop-leftareatoopenControlPanel.
3.ClicktheViewbymenuandselecttheSmalliconsorLargeiconsview.TheAllControlPanel
Itemscategoryisexpanded.
4.ClickKeyboard.
5.ClicktheSpeedtab.
6.MovetheRepeatdelayslidertoLongortheRepeatrateslidertoSlow.
7.ClickOK.
Problem:TheBluetoothkeyboardisnotrecognizedbyyourcomputer.
Solution:Tosolvetheproblem,dothefollowing:
•EnsurethattheBluetoothradioonthecomputeristurnedonandtheBluetoothworks.
•EnsurethattheBluetoothconnectionbuttononthekeyboardisturnedon.
•FortheWindowsXPoperatingsystem,ensurethatyouhavedownloadedandinstalledthelatest
Bluetoothsoftware.IfyouareusingaLenovocomputerwithBroadcomBluetoothsolution,checkand
updatetothelatestBluetoothforWindows(BTW)version(BTW5.6.0.8800orlaterversion).
•EnsurethattheBluetoothkeyboardiswithinthemaximumBluetoothrange(10m).
Problem:TheBluetoothkeyboardlags.
Solution:Tosolvetheproblem,trymovingtheBluetoothkeyboardclosertothecomputerandremoving
otherobjectswithwirelesssignalstoavoidsignalinterference.
Problem:TheThinkPadKeyboardSuitecannotbeautomaticallyinstalledwhenIconnectthekeyboardto
mycomputerforthersttime.
Solution:Tosolvetheproblem,dothefollowing:
1.EnsurethatyouareusingtheWindows7orWindows8operatingsystem.
2.EnsurethatyourcomputerhasbeenconnectedtotheInternet.
3.EnsurethatyouhaveenabledtheautomaticWindowsupdatefeaturebydoingthefollowing:
a.OpenControlPanel.
b.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickHardwareandSound➙DevicesandPrinters.
•ClickDevicesandPrinters.
c.Right-clickyourcomputericonundertheDevicesmenu,andthenselectDeviceinstallation
Settings.
d.FollowtheinstructionsonthescreentoenabletheautomaticWindowsupdatefeature.
4.EnsurethatyouhaveinstalledallWindowsupdatesbydoingthefollowing:
Chapter3.ThinkPadCompactBluetoothKeyboardwithTrackPoint23
![](/img.php?id=1930589&img=bg1c.png)
a.OpenControlPanel.
b.DependingonyourControlPanelmode,dooneofthefollowing:
•ClickSystemandSecurity➙WindowsUpdate.
•ClickWindowsUpdate.
c.ClickCheckforupdatestoinstallWindowsupdates.
5.RemovetheBluetoothkeyboardfromthecomputerandthenreconnectit.
6.Iftheabovetipsstillarenotworkable,itmightbecausedbytheversionorlanguageofyouroperating
system.YoucanmanuallyinstalltheThinkPadKeyboardSuitebydoingthefollowing:
a.Gotohttp://support.lenovo.com/tpkeyboard.
b.Locateanddownloadtheinstallationleofthedriver.
c.Double-clicktheinstallationle,andthenfollowtheinstructionsonthescreentocompletethe
installation.
Problem:TheBluetoothkeyboardmightfailtoresumefromsuspendontheWindows7orWindows8
operatingsystem.
Solution:YoucancheckifselectivesuspendisdisabledbygoingtoDeviceManagerandnavigatingtothe
Bluetoothkeyboard.Right-clicktheBluetoothkeyboardandgotothePropertiespage.ClearAllowthe
computertoturnoffthisdevicetosavepoweronthePowerManagementtab.
Problem:IttakesalongtimetopairtheBluetoothkeyboardwiththecomputerontheWindows7operating
system.
Solution:Itisnotaproblem.WhentheclockontheBluetoothkeyboardicondisappears,theBluetooth
keyboardissuccessfullypairedwiththecomputer.Ifitfails,tryreconnectingitagain.
Productspecications
ThefollowingtabledescribestheBluetoothkeyboardspecications.
Keys84/85/89keys(Variesbycountry)
ColorRavenblack
Dimensions(HeightxWidthxDepth)305.5mmx164.0mmx13.5mm(notincludingthetiltfeet)
Weight458g(includingthecable)
PCinterfaceBluetooth3.0
Operatingvoltage3.7V(Typical)
BatteryCapability500mA(Typical)
Powerconsumption30mAmaximum
Cablelength1.5m(4.92feet)
SupportedoperatingsystemUSBTypeAconnector
Windows8(32-bitand64-bit)
Windows7(32-bitand64-bit)
WindowsVista(32-bitand64-bit)
WindowsXP(32-bit)
24UserGuide
![](/img.php?id=1930589&img=bg1d.png)
AppendixA.ServiceandSupport
Thefollowinginformationdescribesthetechnicalsupportthatisavailableforyourproduct,duringthe
warrantyperiodorthroughoutthelifeofyourproduct.RefertotheLenovoLimitedWarrantyforafull
explanationofLenovowarrantyterms.
Onlinetechnicalsupport
Onlinetechnicalsupportisavailableduringthelifetimeofaproductat:
http://www.lenovo.com/support
Productreplacementassistanceorexchangeofdefectivecomponentsalsoisavailableduringthewarranty
period.Inaddition,ifyouroptionisinstalledinaLenovocomputer,youmightbeentitledtoserviceatyour
location.ALenovotechnicalsupportrepresentativecanhelpyoudeterminethebestalternative.
Telephonetechnicalsupport
InstallationandcongurationsupportthroughtheCustomerSupportCenterwillbeavailableuntil90days
aftertheoptionhasbeenwithdrawnfrommarketing.Afterthattime,thesupportiscancelled,ormade
availableforafee,atLenovo’sdiscretion.Additionalsupportisalsoavailableforanominalfee.
BeforecontactingaLenovotechnicalsupportrepresentative,pleasehavethefollowinginformationavailable:
optionnameandnumber,proofofpurchase,computermanufacturer,model,serialnumberandmanual,
theexactwordingofanyerrormessage,descriptionoftheproblem,andthehardwareandsoftware
congurationinformationforyoursystem.
Yourtechnicalsupportrepresentativemightwanttowalkyouthroughtheproblemwhileyouareatyour
computerduringthecall.
Telephonenumbersaresubjecttochangewithoutnotice.Themostup-to-datetelephonelistforLenovo
Supportisalwaysavailableathttp://www.lenovo.com/support/phone.Ifthetelephonenumberforyour
countryorregionisnotlisted,contactyourLenovoresellerorLenovomarketingrepresentative.
©CopyrightLenovo201325
![](/img.php?id=1930589&img=bg1e.png)
26UserGuide
![](/img.php?id=1930589&img=bg1f.png)
AppendixB.LenovoLimitedWarranty
L505-0010-0208/2011
ThisLenovoLimitedWarrantyconsistsofthefollowingparts:
Part1-GeneralTerms
Part2-Country-specicT erms
Part3-WarrantyServiceInformation
ThetermsofPart2replaceormodifytermsofPart1asspeciedforaparticularcountry.
Part1-GeneralTerms
ThisLenovoLimitedWarrantyappliesonlytoLenovohardwareproductsyoupurchasedforyourownuseand
notforresale.ThisLenovoLimitedWarrantyisavailableinotherlanguagesatwww.lenovo.com/warranty.
WhatthisWarrantyCovers
LenovowarrantsthateachLenovohardwareproductthatyoupurchaseisfreefromdefectsinmaterialsand
workmanshipundernormaluseduringthewarrantyperiod.Thewarrantyperiodfortheproductstartson
theoriginaldateofpurchaseasshownonyoursalesreceiptorinvoiceorasmaybeotherwisespecied
byLenovo.Thewarrantyperiodandtypeofwarrantyservicethatapplytoyourproductareasspecied
in“Part3-WarrantyServiceInformation”below.Thiswarrantyonlyappliestoproductsinthecountry
orregionofpurchase.
THISWARRANTYISYOUREXCLUSIVEWARRANTYANDREPLACESALLOTHERWARRANTIES
ORCONDITIONS,EXPRESSORIMPLIED,INCLUDING,BUTNOTLIMITEDTO,ANYIMPLIED
WARRANTIESORCONDITIONSOFMERCHANTABILITYORFITNESSFORAPARTICULARPURPOSE.
ASSOMESTATESORJURISDICTIONSDONOTALLOWTHEEXCLUSIONOFEXPRESSOR
IMPLIEDWARRANTIES,THEABOVEEXCLUSIONMAYNOTAPPL YTOYOU.INTHATEVENT,SUCH
WARRANTIESAPPL YONL YTOTHEEXTENTANDFORSUCHDURATIONASREQUIREDBYLAWAND
ARELIMITEDINDURATIONTOTHEWARRANTYPERIOD.ASSOMESTATESORJURISDICTIONSDO
NOTALLOWLIMITATIONSONTHEDURATIONOFANIMPLIEDWARRANTY,THEABOVELIMITATION
ONDURATIONMAYNOTAPPL YTOYOU.
HowtoObtainWarrantyService
Iftheproductdoesnotfunctionaswarrantedduringthewarrantyperiod,youmayobtainwarrantyserviceby
contactingLenovooraLenovoapprovedServiceProvider.AlistofapprovedServiceProvidersandtheir
telephonenumbersisavailableat:www.lenovo.com/support/phone.
Warrantyservicemaynotbeavailableinalllocationsandmaydifferfromlocationtolocation.Chargesmay
applyoutsideaServiceProvider’snormalservicearea.ContactalocalServiceProviderforinformation
specictoyourlocation.
CustomerResponsibilitiesforWarrantyService
Beforewarrantyserviceisprovided,youmusttakethefollowingsteps:
•followtheservicerequestproceduresspeciedbytheServiceProvider;
©CopyrightLenovo201327
![](/img.php?id=1930589&img=bg20.png)
•backuporsecureallprogramsanddatacontainedintheproduct;
•providetheServiceProviderwithallsystemkeysorpasswords;
•providetheServiceProviderwithsufcient,free,andsafeaccesstoyourfacilitiestoperformservice;
•removealldata,includingcondentialinformation,proprietaryinformationandpersonalinformation,from
theproductor,ifyouareunabletoremoveanysuchinformation,modifytheinformationtopreventits
accessbyanotherpartyorsothatitisnotpersonaldataunderapplicablelaw.TheServiceProvidershall
notberesponsibleforthelossordisclosureofanydata,includingcondentialinformation,proprietary
information,orpersonalinformation,onaproductreturnedoraccessedforwarrantyservice;
•removeallfeatures,parts,options,alterations,andattachmentsnotcoveredbythewarranty;
•ensurethattheproductorpartisfreeofanylegalrestrictionsthatpreventitsreplacement;
•ifyouarenottheownerofaproductorpart,obtainauthorizationfromtheownerfortheServiceProvider
toprovidewarrantyservice.
WhatYourServiceProviderWillDotoCorrectProblems
WhenyoucontactaServiceProvider,youmustfollowthespeciedproblemdeterminationandresolution
procedures.
TheServiceProviderwillattempttodiagnoseandresolveyourproblembytelephone,e-mailorremote
assistance.TheServiceProvidermaydirectyoutodownloadandinstalldesignatedsoftwareupdates.
Someproblemsmayberesolvedwithareplacementpartthatyouinstallyourselfcalleda“Customer
ReplaceableUnit”or“CRU.”Ifso,theServiceProviderwillshiptheCRUtoyouforyoutoinstall.
Ifyourproblemcannotberesolvedoverthetelephone;throughtheapplicationofsoftwareupdatesor
theinstallationofaCRU,theServiceProviderwillarrangeforserviceunderthetypeofwarrantyservice
designatedfortheproductunder“Part3-WarrantyServiceInformation”below.
IftheServiceProviderdeterminesthatitisunabletorepairyourproduct,theServiceProviderwillreplace
itwithonethatisatleastfunctionallyequivalent.
IftheServiceProviderdeterminesthatitisunabletoeitherrepairorreplaceyourproduct,yoursole
remedyunderthisLimitedWarrantyistoreturntheproducttoyourplaceofpurchaseortoLenovofora
refundofyourpurchaseprice.
ReplacementProductsandParts
Whenwarrantyserviceinvolvesthereplacementofaproductorpart,thereplacedproductorpartbecomes
Lenovo’spropertyandthereplacementproductorpartbecomesyourproperty.OnlyunalteredLenovo
productsandpartsareeligibleforreplacement.ThereplacementproductorpartprovidedbyLenovomay
notbenew,butitwillbeingoodworkingorderandatleastfunctionallyequivalenttotheoriginalproductor
part.Thereplacementproductorpartshallbewarrantedforthebalanceoftheperiodremainingonthe
originalproduct.
UseofPersonalContactInformation
Ifyouobtainserviceunderthiswarranty,youauthorizeLenovotostore,useandprocessinformationabout
yourwarrantyserviceandyourcontactinformation,includingname,phonenumbers,address,ande-mail
address.Lenovomayusethisinformationtoperformserviceunderthiswarranty.Wemaycontactyouto
inquireaboutyoursatisfactionwithourwarrantyserviceortonotifyyouaboutanyproductrecallsorsafety
issues.Inaccomplishingthesepurposes,youauthorizeLenovototransferyourinformationtoanycountry
wherewedobusinessandtoprovideittoentitiesactingonourbehalf.Wemayalsodiscloseitwhere
requiredbylaw.Lenovo’sprivacypolicyisavailableatwww.lenovo.com/.
28UserGuide
![](/img.php?id=1930589&img=bg21.png)
WhatthisWarrantyDoesnotCover
Thiswarrantydoesnotcoverthefollowing:
•uninterruptedorerror-freeoperationofaproduct;
•lossof,ordamageto,yourdatabyaproduct;
•anysoftwareprograms,whetherprovidedwiththeproductorinstalledsubsequently;
•failureordamageresultingfrommisuse,abuse,accident,modication,unsuitablephysicaloroperating
environment,naturaldisasters,powersurges,impropermaintenance,orusenotinaccordancewith
productinformationmaterials;
•damagecausedbyanon-authorizedserviceprovider;
•failureof,ordamagecausedby,anythirdpartyproducts,includingthosethatLenovomayprovideor
integrateintotheLenovoproductatyourrequest;
•anytechnicalorothersupport,suchasassistancewith“how-to”questionsandthoseregardingproduct
set-upandinstallation;
•productsorpartswithanalteredidenticationlabelorfromwhichtheidenticationlabelhasbeen
removed.
LimitationofLiability
LenovoisresponsibleforlossordamagetoyourproductonlywhileitisintheServiceProvider’spossession
orintransit,iftheServiceProviderisresponsibleforthetransportation.
NeitherLenovonortheServiceProviderisresponsibleforlossordisclosureofanydata,including
condentialinformation,proprietaryinformation,orpersonalinformation,containedinaproduct.
UNDERNOCIRCUMSTANCES,ANDNOTWITHSTANDINGTHEFAILUREOFESSENTIALPURPOSE
OFANYREMEDYSETFORTHHEREIN,SHALLLENOVO,ITSAFFILIATES,SUPPLIERS,RESELLERS,
ORSERVICEPROVIDERSBELIABLEFORANYOFTHEFOLLOWINGEVENIFINFORMEDOFTHEIR
POSSIBILITYANDREGARDLESSOFWHETHERTHECLAIMISBASEDINCONTRACT,WARRANTY,
NEGLIGENCE,STRICTLIABILITYOROTHERTHEORYOFLIABILITY:1)THIRDPARTYCLAIMS
AGAINSTYOUFORDAMAGES;2)LOSS,DAMAGEORDISCLOSUREOFYOURDATA;3)SPECIAL,
INCIDENTAL,PUNITIVE,INDIRECTORCONSEQUENTIALDAMAGES,INCLUDINGBUTNOTLIMITED
TOLOSTPROFITS,BUSINESSREVENUE,GOODWILLORANTICIPATEDSAVINGS.INNOCASE
SHALLTHETOTALLIABILITYOFLENOVO,ITSAFFILIATESS,SUPPLIERS,RESELLERSORSERVICE
PROVIDERSFORDAMAGESFROMANYCAUSEEXCEEDTHEAMOUNTOFACTUALDIRECT
DAMAGES,NOTTOEXCEEDTHEAMOUNTPAIDFORTHEPRODUCT.
THEFOREGOINGLIMITATIONSDONOTAPPL YTODAMAGESFORBODIL YINJURY(INCLUDING
DEATH),DAMAGETOREALPROPERTYORDAMAGETOTANGIBLEPERSONALPROPERTYFOR
WHICHLENOVOISLIABLEUNDERLAW.ASSOMESTATESORJURISDICTIONSDONOTALLOW
THEEXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,THEABOVE
LIMITATIONOREXCLUSIONMAYNOTAPPL YTOYOU.
YourOtherRights
THISWARRANTYGIVESYOUSPECIFICLEGALRIGHTS.YOUMAYHAVEOTHERRIGHTS
ACCORDINGTOTHEAPPLICABLELAWSOFYOURSTATEORJURISDICTION.YOUMAYALSO
HAVEOTHERRIGHTSUNDERAWRITTENAGREEMENTWITHLENOVO.NOTHINGINTHIS
WARRANTYAFFECTSSTATUTORYRIGHTS,INCLUDINGRIGHTSOFCONSUMERSUNDERLAWS
ORREGULATIONSGOVERNINGTHESALEOFCONSUMERGOODSTHATCANNOTBEWAIVED
ORLIMITEDBYCONTRACT.
AppendixB.LenovoLimitedWarranty29
![](/img.php?id=1930589&img=bg22.png)
Part2-Country-specicT erms
Australia
“Lenovo”meansLenovo(Australia&NewZealand)PtyLimitedABN70112394411.Address:Level
10,NorthTower,1-5RailwayStreet,Chatswood,NSW,2067.Telephone:+61280038200.Email:
lensyd_au@lenovo.com
ThefollowingreplacesthesamesectioninPart1:
WhatthisWarrantyCovers:
Lenovowarrantsthateachhardwareproductthatyoupurchaseisfreefromdefectsinmaterialsand
workmanshipundernormaluseandconditionsduringthewarrantyperiod.Iftheproductfailsduetoa
covereddefectduringthewarrantyperiod,LenovowillprovideyouaremedyunderthisLimitedWarranty.
Thewarrantyperiodfortheproductstartsontheoriginaldateofpurchasespeciedonyoursalesreceiptor
invoiceunlessLenovoinformsyouotherwiseinwriting.Thewarrantyperiodandtypeofwarrantyservice
thatapplytoyourproductaresetforthbelowinPart3-WarrantyServiceInformation.
THEBENEFITSGIVENBYTHISWARRANTYAREINADDITIONTOYOURRIGHTSANDREMEDIESAT
LAW,INCLUDINGTHOSEUNDERTHEAUSTRALIANCONSUMERLAW.
ThefollowingreplacesthesamesectioninPart1:
ReplacementProductsandParts:
Whenwarrantyserviceinvolvesthereplacementofaproductorpart,thereplacedproductorpartbecomes
Lenovo’spropertyandthereplacementproductorpartbecomesyourproperty.OnlyunalteredLenovo
productsandpartsareeligibleforreplacement.ThereplacementproductorpartprovidedbyLenovomay
notbenew,butitwillbeingoodworkingorderandatleastfunctionallyequivalenttotheoriginalproductor
part.Thereplacementproductorpartshallbewarrantedforthebalanceoftheperiodremainingonthe
originalproduct.Productsandpartspresentedforrepairmaybereplacedbyrefurbishedproductsorparts
ofthesametyperatherthanbeingrepaired.Refurbishedpartsmaybeusedtorepairtheproduct;andrepair
oftheproductmayresultinlossofdata,iftheproductiscapableofretaininguser-generateddata.
ThefollowingisaddedtothesamesectioninPart1:
UseofPersonalContactInformation:
Lenovowillnotbeabletoperformourserviceunderthiswarrantyifyourefusetoprovideyourinformation
ordonotwishustotransferyourinformationtoouragentorcontractor.Youhavetherighttoaccess
yourpersonalcontactinformationandrequestcorrectionofanyerrorsinitpursuanttothePrivacyAct
1988bycontactingLenovo.
ThefollowingreplacesthesamesectioninPart1:
LimitationofLiability:
LenovoisresponsibleforlossordamagetoyourproductonlywhileitisintheServiceProvider’spossession
orintransit,iftheServiceProviderisresponsibleforthetransportation.
NeitherLenovonortheServiceProviderisresponsibleforlossordisclosureofanydata,including
condentialinformation,proprietaryinformation,orpersonalinformation,containedinaproduct.
30UserGuide
![](/img.php?id=1930589&img=bg23.png)
TOTHEEXTENTPERMITTEDBYLAW,UNDERNOCIRCUMSTANCESANDNOTWITHSTANDING
THEFAILUREOFESSENTIALPURPOSEOFANYREMEDYSETFORTHHEREIN,SHALLLENOVO,
ITSAFFILIATES,SUPPLIERS,RESELLERS,ORSERVICEPROVIDERSBELIABLEFORANYOFTHE
FOLLOWINGEVENIFINFORMEDOFTHEIRPOSSIBILITYANDREGARDLESSOFWHETHERTHE
CLAIMISBASEDINCONTRACT,WARRANTY,NEGLIGENCE,STRICTLIABILITYOROTHERTHEORY
OFLIABILITY:1)THIRDPARTYCLAIMSAGAINSTYOUFORDAMAGES;2)LOSS,DAMAGEOR
DISCLOSUREOFYOURDATA;3)SPECIAL,INCIDENTAL,PUNITIVE,INDIRECTORCONSEQUENTIAL
DAMAGES,INCLUDINGBUTNOTLIMITEDTOLOSTPROFITS,BUSINESSREVENUE,GOODWILLOR
ANTICIPATEDSAVINGS.INNOCASESHALLTHETOTALLIABILITYOFLENOVO,ITSAFFILIATESS,
SUPPLIERS,RESELLERSORSERVICEPROVIDERSFORDAMAGESFROMANYCAUSEEXCEEDTHE
AMOUNTOFACTUALDIRECTDAMAGES,NOTTOEXCEEDTHEAMOUNTPAIDFORTHEPRODUCT.
THEFOREGOINGLIMITATIONSDONOTAPPL YTODAMAGESFORBODIL YINJURY(INCLUDING
DEATH),DAMAGETOREALPROPERTYORDAMAGETOTANGIBLEPERSONALPROPERTYFOR
WHICHLENOVOISLIABLEUNDERLAW.
ThefollowingreplacesthesamesectioninPart1:
YourOtherRights:
THISWARRANTYGIVESYOUSPECIFICLEGALRIGHTS.YOUALSOHAVEOTHERRIGHTSATLAW,
INCLUDINGUNDERTHEAUSTRALIANCONSUMERLAW.NOTHINGINTHISWARRANTYAFFECTS
STATUTORYRIGHTSORRIGHTSATLAW,INCLUDINGRIGHTSTHATCANNOTBEWAIVEDOR
LIMITEDBYCONTRACT.
Forexample,ourproductscomewithguaranteesthatcannotbeexcludedundertheAustralianConsumer
Law.Youareentitledtoareplacementorrefundforamajorfailureandcompensationforanyother
reasonablyforeseeablelossordamage.Youarealsoentitledtohavetheproductsrepairedorreplacedifthe
productsfailtobeofacceptablequalityandthefailuredoesnotamounttoamajorfailure.
NewZealand
ThefollowingisaddedtothesamesectioninPart1:
UseofPersonalInformation:
Lenovowillnotbeabletoperformourserviceunderthiswarrantyifyourefusetoprovideyourinformationor
donotwishustotransferyourinformationtoouragentorcontractor.Youhavetherighttoaccessyour
personalinformationandrequestcorrectionofanyerrorsinitpursuanttothePrivacyAct1993bycontacting
Lenovo(Australia&NewZealand)PtyLimitedABN70112394411.Address:Level10,NorthTower,1-5
RailwayStreet,Chatswood,NSW,2067.Telephone:61280038200.Email:lensyd_au@lenovo.com
Bangladesh,Cambodia,India,Indonesia,Nepal,Philippines,VietnamandSriLanka
ThefollowingisaddedtoPart1:
DisputeResolution
Disputesarisingoutoforinconnectionwiththiswarrantyshallbenallysettledbyarbitrationheldin
Singapore.Thiswarrantyshallbegoverned,construedandenforcedinaccordancewiththelawsof
Singapore,withoutregardtoconictoflaws.IfyouacquiredtheproductinIndia,disputesarisingoutofor
inconnectionwiththiswarrantyshallbenallysettledbyarbitrationheldinBangalore,India.Arbitration
inSingaporeshallbeheldinaccordancewiththeArbitrationRulesofSingaporeInternationalArbitration
Center(“SIACRules”)thenineffect.ArbitrationinIndiashallbeheldinaccordancewiththelawsofIndia
thenineffect.Thearbitrationawardshallbenalandbindingonthepartieswithoutappeal.Anyaward
AppendixB.LenovoLimitedWarranty31
![](/img.php?id=1930589&img=bg24.png)
shallbeinwritingandsetforththendingsoffactandtheconclusionsoflaw.Allarbitrationproceedings,
includingalldocumentspresentedinsuchproceedingsshallbeconductedintheEnglishlanguage.The
Englishlanguageversionofthiswarrantyprevailsoveranyotherlanguageversioninsuchproceedings.
EuropeanEconomicArea(EEA)
ThefollowingisaddedtoPart1:
CustomersintheEEAmaycontactLenovoatthefollowingaddress:EMEAServiceOrganisation,Lenovo
(International)B.V.,Floor2,Einsteinova21,85101,Bratislava,Slovakia.Serviceunderthiswarrantyfor
LenovohardwareproductspurchasedinEEAcountriesmaybeobtainedinanyEEAcountryinwhichthe
producthasbeenannouncedandmadeavailablebyLenovo.
Russia
ThefollowingisaddedtoPart1:
ProductServiceLife
Theproductservicelifeisfour(4)yearsfromtheoriginaldateofpurchase.
Part3-WarrantyServiceInformation
ProductTypeCountryorRegionofPurchaseWarrantyPeriodTypeofWarrantyService
ThinkPadCompactUSB
KeyboardwithTrackPointWorldwide3years1,4
ThinkPadCompact
BluetoothKeyboard
withTrackPoint
Worldwide1year1,4
Ifrequired,yourServiceProviderwillproviderepairorexchangeservicedependingonthetypeofwarranty
servicespeciedforyourproductandtheavailableservice.Schedulingofservicewilldependuponthetime
ofyourcall,partsavailability,andotherfactors.
TypesofWarrantyService
1.CustomerReplaceableUnit(“CRU”)Service
UnderCRUService,theServiceProviderwillshipCRUstoyouatitscostforinstallationbyyou.CRU
informationandreplacementinstructionsareshippedwithyourproductandareavailablefromLenovoatany
timeuponrequest.CRUsthatareeasilyinstalledbyyouarecalled“Self-serviceCRUs”.“Optional-service
CRUs”areCRUsthatmayrequiresometechnicalskillandtools.InstallationofSelf-serviceCRUsisyour
responsibility.YoumayrequestthataServiceProviderinstallOptional-serviceCRUsunderoneoftheother
typesofwarrantyservicedesignatedforyourproduct.Anoptionalserviceofferingmaybeavailablefor
purchasefromaServiceProviderorLenovounderwhichSelf-serviceCRUswouldbeinstalledforyou.
YoumayndalistofCRUsandtheirdesignationinthepublicationthatwasshippedwithyourproduct
oratwww.lenovo.com/CRUs.TherequirementtoreturnadefectiveCRU,ifany,willbespeciedinthe
instructionsshippedwithareplacementCRU.Whenreturnisrequired:1)returninstructions,aprepaid
returnshippinglabel,andacontainerwillbeincludedwiththereplacementCRU;and2)youmaybecharged
forthereplacementCRUiftheServiceProviderdoesnotreceivethedefectiveCRUfromyouwithinthirty
(30)daysofyourreceiptofthereplacementCRU.
2.On-siteService
32UserGuide
![](/img.php?id=1930589&img=bg25.png)
UnderOn-SiteService,aServiceProviderwilleitherrepairorexchangetheproductatyourlocation.You
mustprovideasuitableworkingareatoallowdisassemblyandreassemblyoftheproduct.Somerepairs
mayneedtobecompletedataservicecenter.Ifso,theServiceProviderwillsendtheproducttothe
servicecenteratitsexpense.
3.CourierorDepotService
UnderCourierorDepotService,yourproductwillberepairedorexchangedatadesignatedservicecenter,
withshippingattheexpenseoftheServiceProvider.Youareresponsiblefordisconnectingtheproductand
packingitinashippingcontainerprovidedtoyoutoreturnyourproducttoadesignatedservicecenter.
Acourierwillpickupyourproductanddeliverittothedesignatedservicecenter.Theservicecenterwill
returntheproducttoyouatitsexpense.
4.CustomerCarry-InService
UnderCustomerCarry-InService,yourproductwillberepairedorexchangedafteryoudeliverittoa
designatedservicecenteratyourriskandexpense.Aftertheproducthasbeenrepairedorexchanged,itwill
bemadeavailabletoyouforcollection.Ifyoufailtocollecttheproduct,theServiceProvidermaydisposeof
theproductasitseest,withnoliabilitytoyou.
5.Mail-InService
UnderMail-InService,yourproductwillberepairedorexchangedatadesignatedservicecenterafteryou
deliveritatyourriskandexpense.Aftertheproducthasbeenrepairedorexchanged,itwillbereturnedto
youatLenovo’sriskandexpense,unlesstheServiceProviderspeciesotherwise.
6.CustomerTwo-WayMail-InService
UnderCustomerTwo-WayMail-InService,yourproductwillberepairedorexchangedafteryoudeliveritto
adesignatedservicecenteratyourriskandexpense.Aftertheproducthasbeenrepairedorexchanged,
itwillbemadeavailabletoyouforreturnshippingatyourriskandexpense.Ifyoufailtoarrangereturn
shipment,theServiceProvidermaydisposeoftheproductasitseest,withnoliabilitytoyou.
7.ProductExchangeService
UnderProductExchangeService,Lenovowillshipareplacementproducttoyourlocation.Youare
responsibleforitsinstallationandvericationofitsoperation.Thereplacementproductbecomesyour
propertyinexchangeforthefailedproduct,whichbecomesthepropertyofLenovo.Youmustpackthe
failedproductintheshippingcartoninwhichyoureceivedthereplacementproductandreturnittoLenovo.
Transportationcharges,bothways,shallbeatLenovo’sexpense.Ifyoufailtousethecartoninwhichthe
replacementproductwasreceived,youmayberesponsibleforanydamagetothefailedproductoccurring
duringshipment.YoumaybechargedforthereplacementproductifLenovodoesnotreceivethefailed
productwithinthirty(30)daysofyourreceiptofthereplacementproduct.
SuplementodeGarantíaparaMéxico
EsteSuplementoseconsideraparteintegrantedelaGarantíaLimitadadeLenovoyseráefectivoúnicay
exclusivamenteparalosproductosdistribuidosycomercializadosdentrodelTerritoriodelosEstados
UnidosMexicanos.Encasodeconicto,seaplicaránlostérminosdeesteSuplemento.
Todoslosprogramasdesoftwareprecargadosenelequiposólotendránunagarantíadetreinta(30)díaspor
defectosdeinstalacióndesdelafechadecompra.Lenovonoesresponsabledelainformaciónincluida
endichosprogramasdesoftwarey/ocualquierprogramadesoftwareadicionalinstaladoporUstedo
instaladodespuésdelacompradelproducto.
AppendixB.LenovoLimitedWarranty33
![](/img.php?id=1930589&img=bg26.png)
Losserviciosnocubiertosporlagarantíasecargaránalusuarional,previaobtencióndeunaautorización.
Enelcasodequesepreciseunareparacióncubiertaporlagarantía,porfavor,llamealCentrodesoporte
alclienteal001-866-434-2080,dondeledirigiránalCentrodeservicioautorizadomáscercano.Sino
existieseningúnCentrodeservicioautorizadoensuciudad,poblaciónoenunradiode70kilómetros
desuciudadopoblación,lagarantíaincluirácualquiergastodeentregarazonablerelacionadoconel
transportedelproductoasuCentrodeservicioautorizadomáscercano.Porfavor,llamealCentrode
servicioautorizadomáscercanoparaobtenerlasaprobacionesnecesariasolainformaciónrelacionada
conelenvíodelproductoyladireccióndeenvío.
ParaobtenerunalistadelosCentrosdeservicioautorizados,porfavor,visite:
http://www.lenovo.com/mx/es/servicios
Importadopor:
LenovoMéxicoS.deR.L.deC.V.
Av.SantaFe505,Piso15
Col.CruzManca
Cuajimalpa,D.F.,México
C.P .05349
Tel.(55)50008500
34UserGuide
![](/img.php?id=1930589&img=bg27.png)
AppendixC.Electronicemissionnotices
ForelectronicemissionsinformationonClassBdigitaldevicesandcomplianceinformation,refertothe
RegulatoryNoticespublicationthatisavailableontheLenovoSupportWebsiteat:
http://www.lenovo.com/support/keyboards
Lenovo,Einsteinova21,85101Bratislava,Slovakia
ThinkPadCompactBluetoothKeyboardwithTrackPoint:modelnumber(KT-1255)
RFExposureStatement
TheradiatedenergyfromtheThinkPadCompactBluetoothKeyboardwithTrackPointconformstotheFCC
limitoftheSAR(SpecicAbsorptionRate)requirementsetforthin47CFRPart2section1093.
LowPowerLicense-ExemptRadioCommunicationDevices(RSS-210)
Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseinterference,and(2)this
devicemustacceptanyinterference,includinginterferencethatmaycauseundesiredoperationofthedevice.
Permisd’émissionàfaiblepuissance–Casdesappareilsdecommunicationsradio
L’utilisationdecedispositifestautoriséeseulementauxconditionssuivantes:(1)ilnedoitpasproduirede
brouillage,et(2)l’utilisateurdudispositifdoitêtreprêtàacceptertoutbrouillageradioélectriquereçu,même
sicebrouillageestsusceptibledecompromettrelefonctionnementdudispositif.
FederalCommunicationsCommissionDeclarationofConformity
ThinkPadCompactUSBKeyboardwithTrackPoint–0B47190
ThinkPadCompactBluetoothKeyboardwithTrackPoint–0B47190
©CopyrightLenovo201335
RadiationExposureStatement:
ThisequipmentcomplieswithICradiationexposurelimitssetforthforanuncontrolledenvironment.
Déclarationd'expositionauxradiations:
Cetéquipementestconformeauxlimitesd'expositionauxrayonnementsICétabliespourunenvironnement
noncontrôlé.
![](/img.php?id=1930589&img=bg28.png)
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
toPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,uses,andcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe
determinedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferenceby
oneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
•Consultanauthorizeddealerorservicerepresentativeforhelp.
Lenovoisnotresponsibleforanyradioortelevisioninterferencecausedbyusingotherthanspeciedor
recommendedcablesandconnectorsorbyunauthorizedchangesormodicationstothisequipment.
Unauthorizedchangesormodicationscouldvoidtheuser'sauthoritytooperatetheequipment.
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)
thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesiredoperation.
ResponsibleParty:
Lenovo(UnitedStates)Incorporated
1009ThinkPlace-BuildingOne
Morrisville,NC27560
PhoneNumber:919-294-5900
IndustryCanadaClassBemissioncompliancestatement
ThisClassBdigitalapparatuscomplieswithCanadianICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.
EuropeanUnion-CompliancetotheElectromagneticCompatibilityDirective
ThisproductisinconformitywiththeprotectionrequirementsofEUCouncilDirective2004/108/EConthe
approximationofthelawsoftheMemberStatesrelatingtoelectromagneticcompatibility.Lenovocannot
acceptresponsibilityforanyfailuretosatisfytheprotectionrequirementsresultingfromanon-recommended
modicationoftheproduct,includingtheinstallationofoptioncardsfromothermanufacturers.
ThisproducthasbeentestedandfoundtocomplywiththelimitsforClassBInformationTechnology
EquipmentaccordingtoEuropeanStandardEN55022.ThelimitsforClassBequipmentwerederived
fortypicalresidentialenvironmentstoprovidereasonableprotectionagainstinterferencewithlicensed
communicationdevices.
Lenovo,Einsteinova21,85101Bratislava,Slovakia
GermanClassBcompliancestatement
36UserGuide
![](/img.php?id=1930589&img=bg29.png)
DeutschsprachigerEUHinweis:
HinweisfürGerätederKlasseBEU-RichtliniezurElektromagnetischenVerträglichkeit
DiesesProduktentsprichtdenSchutzanforderungenderEU-Richtlinie2004/108/EG(früher89/336/EWG)zur
AngleichungderRechtsvorschriftenüberdieelektromagnetischeVerträglichkeitindenEU-Mitgliedsstaaten
undhältdieGrenzwertederEN55022KlasseBein.
Umdiesessicherzustellen,sinddieGerätewieindenHandbüchernbeschriebenzuinstallierenundzu
betreiben.DesWeiterendürfenauchnurvonderLenovoempfohleneKabelangeschlossenwerden.
LenovoübernimmtkeineVerantwortungfürdieEinhaltungderSchutzanforderungen,wenndasProdukt
ohneZustimmungderLenovoverändertbzw.wennErweiterungskomponentenvonFremdherstellernohne
EmpfehlungderLenovogesteckt/eingebautwerden.
Deutschland:
EinhaltungdesGesetzesüberdieelektromagnetischeVerträglichkeitvonBetriebsmitteln
DiesesProduktentsprichtdem„GesetzüberdieelektromagnetischeVerträglichkeitvonBetriebsmitteln“
EMVG(früher„GesetzüberdieelektromagnetischeVerträglichkeitvonGeräten“).DiesistdieUmsetzungder
EU-Richtlinie2004/108/EG(früher89/336/EWG)inderBundesrepublikDeutschland.
ZulassungsbescheinigunglautdemDeutschenGesetzüberdieelektromagnetischeVerträglichkeit
vonBetriebsmitteln,EMVGvom20.Juli2007(früherGesetzüberdieelektromagnetische
VerträglichkeitvonGeräten),bzw.derEMVEGRichtlinie2004/108/EC(früher89/336/EWG),für
GerätederKlasseB.
DiesesGerätistberechtigt,inÜbereinstimmungmitdemDeutschenEMVGdasEG-Konformitätszeichen
-CE-zuführen.VerantwortlichfürdieKonformitätserklärungnachParagraf5desEMVGistdieLenovo
(Deutschland)GmbH,Gropiusplatz10,D-70563Stuttgart.
InformationeninHinsichtEMVGParagraf4Abs.(1)4:
DasGeräterfülltdieSchutzanforderungennachEN55024undEN55022KlasseB.
KoreaClassBcompliancestatement
JapanVCCIClassBcompliancestatement
LenovoproductserviceinformationforTaiwan
AppendixC.Electronicemissionnotices37
![](/img.php?id=1930589&img=bg2a.png)
38UserGuide
![](/img.php?id=1930589&img=bg2b.png)
AppendixD.Notices
Lenovomaynotoffertheproducts,services,orfeaturesdiscussedinthisdocumentinallcountries.Consult
yourlocalLenovorepresentativeforinformationontheproductsandservicescurrentlyavailableinyour
area.AnyreferencetoaLenovoproduct,program,orserviceisnotintendedtostateorimplythatonlythat
Lenovoproduct,program,orservicemaybeused.Anyfunctionallyequivalentproduct,program,orservice
thatdoesnotinfringeanyLenovointellectualpropertyrightmaybeusedinstead.However,itistheuser's
responsibilitytoevaluateandverifytheoperationofanyotherproduct,program,orservice.
Lenovomayhavepatentsorpendingpatentapplicationscoveringsubjectmatterdescribedinthis
document.Thefurnishingofthisdocumentdoesnotgiveyouanylicensetothesepatents.Youcansend
licenseinquiries,inwriting,to:
Lenovo(UnitedStates),Inc.
1009ThinkPlace-BuildingOne
Morrisville,NC27560
U.S.A.
Attention:LenovoDirectorofLicensing
LENOVOPROVIDESTHISPUBLICATION“ASIS”WITHOUTWARRANTYOFANYKIND,EITHEREXPRESS
ORIMPLIED,INCLUDING,BUTNOTLIMITEDTO,THEIMPLIEDWARRANTIESOFNON-INFRINGEMENT,
MERCHANTABILITYORFITNESSFORAPARTICULARPURPOSE.Somejurisdictionsdonotallow
disclaimerofexpressorimpliedwarrantiesincertaintransactions,therefore,thisstatementmaynotapply
toyou.
Thisinformationcouldincludetechnicalinaccuraciesortypographicalerrors.Changesareperiodically
madetotheinformationherein;thesechangeswillbeincorporatedinneweditionsofthepublication.
Lenovomaymakeimprovementsand/orchangesintheproduct(s)and/ortheprogram(s)describedinthis
publicationatanytimewithoutnotice.
Trademarks
ThefollowingtermsaretrademarksorservicemarksofLenovointheUnitedStates,othercountries,orboth:
Lenovo
ThinkPad
TrackPoint
Microsoft,Windows,andWindowsVistaaretrademarksoftheMicrosoftgroupofcompanies.
Othercompany,product,orservicenamesmaybetrademarksorservicemarksofothers.
Recyclinginformation
Lenovoencouragesownersofinformationtechnology(IT)equipmenttoresponsiblyrecycletheirequipment
whenitisnolongerneeded.Lenovooffersavarietyofprogramsandservicestoassistequipmentownersin
recyclingtheirITproducts.ForinformationonrecyclingLenovoproducts,goto:
http://www.lenovo.com/recycling
RecyclinganddisposalinformationforJapanisavailableat:
http://www.lenovo.com/recycling/japan
©CopyrightLenovo201339
![](/img.php?id=1930589&img=bg2c.png)
RecyclinginformationforBrazil
DeclaraçõesdeReciclagemnoBrasil
DescartedeumProdutoLenovoForadeUso
Equipamentoselétricoseeletrônicosnãodevemserdescartadosemlixocomum,masenviadosàpontosde
coleta,autorizadospelofabricantedoprodutoparaquesejamencaminhadoseprocessadosporempresas
especializadasnomanuseioderesíduosindustriais,devidamentecerticadaspelosorgãosambientais,de
acordocomalegislaçãolocal.
ALenovopossuiumcanalespecícoparaauxiliá-lonodescartedessesprodutos.Casovocêpossua
umprodutoLenovoemsituaçãodedescarte,ligueparaonossoSACouencaminheume-mailpara:
reciclar@lenovo.com,informandoomodelo,númerodesérieecidade,amdeenviarmosasinstruções
paraocorretodescartedoseuprodutoLenovo.
40UserGuide
![](/img.php?id=1930589&img=bg2d.png)
AppendixE.RestrictionofHazardousSubstancesDirective
(RoHS)
EuropeanUnionRoHS
LenovoproductssoldintheEuropeanUnion,onorafter3January2013meettherequirementsofDirective
2011/65/EUontherestrictionoftheuseofcertainhazardoussubstancesinelectricalandelectronic
equipment(“RoHSrecast”or“RoHS2”).
FormoreinformationaboutLenovoprogressonRoHS,goto:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
ChinaRoHS
TheinformationinthefollowingtableisapplicableforproductsmanufacturedonorafterMarch1,2007for
saleinthePeople’sRepublicofChina.
TurkishRoHS
TheLenovoproductmeetstherequirementsoftheRepublicofTurkeyDirectiveontheRestrictionoftheUse
ofCertainHazardousSubstancesinElectricalandElectronicEquipment(EEE).
UkraineRoHS
IndiaRoHS
RoHScompliantasperE-Waste(Management&Handling)Rules,2011.
©CopyrightLenovo201341
![](/img.php?id=1930589&img=bg2e.png)
42UserGuide
![](/img.php?id=1930589&img=bg30.png)
PartNumber:0B58442
PrintedinChina
(1P)P/N:0B58442
*1P0B58442*
