Chicony Electronics Co MG-0822 Wireless Mouse User Manual 0816 US FCC
Chicony Electronics Co Ltd Wireless Mouse 0816 US FCC
Manual
IMPORTANT BATTERY INFORMATION
• Keep batteries out of reach of children.
• Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery chamber.
• Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries).
• Always remove old, weak, or worn-out batteries propmptly and recycle or proper disposal of them in accordance with Local and
National Disposal Regulations.
• If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacture's instructions and
Local and National Disposal Regulations. Before inserting new batteries, thoroughly clean the compartment with a damp paper towel,
or follow the battery manufacture's recommendations for cleanup. If fluid from the battery comes into contact with skin or clothes,
flush skin with water immediately.
• Remove the batteries if your device is to be stored for an extended period of time without being used.
PRODUCT DISPOSAL INFORMATION
Dispose of this product in accordance with Local and National Disposal Regulations.
B. PRODUCT SPECIFICATION
1. Frequency Deviation: ± 320 KHz
2. ModulationTypp: GFSK Mode
3. Transmitter Power: 0dBm Max
4. Power requirement: 2V~3.2V
5. Battery: Keyboard : 2 pieces of AA Batteries
Mouse : 2 pieces of AA Batteries
6. Battery life time : Keyboard : 1200 hours reference (operating mode)
Mouse : 110 hours reference (operating mode)
7. Operation distance : Keyboard : 10 M without signal disturbance and nodirection limit.
Mouse: 10 M without signal disturbance and no direction limit.
8. Mouse resolution : 800 DPI
9. Operating temperature : -10º C ~ +40º C
10. Storage temperature : -40º C ~ +85º C.
English
User's ManualWireless Keyboard + Mouse Kits
A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
WARNING:Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or
modifications not expressly approved by the party responsible for compliance could void your authority to operate the
equipment.
CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS.Take regular breaks and keep a
good posture. Consult your physician promptly if you notice any lost of motion or pain in your wrist when using the
keyboard.
INFORMATION FOR OPTICAL POINTING DEVICES ONLY:User-observable light is 15 microwatts in normal
operation.This product has been tested to comply with International Standard IEC 60825-1: (1993), incld. Amd.
2(2001). This product users LEDs that are inherently Class 1.
Getting Started
Thank you for choosing this 2.4G Wireless keyboard and Mouse Kits. It operates with digital radio technology to
ensure no hinder communication between the keyboard, the mouse and your computer without connecting cable.
The transmission and receiving of keyboard and mouse are free from angle restriction.
Features
• Complies with Directive 1995/5/EC of the European Parliament and Commission.
• Complies with the mutual recognition of conformity 1999 for radio and telecommunications Equipment.
• Manufactured with environmental friendly recycled materials.
• Fully compliant with original USB version 2.0
Preparing Keyboard, mouse and receiver
Before working with your new keyboard and mouse, look at the "Hardware Installation" , and take a few
one-time preparations.
Hardware Installation
• Place the receiver at least 20 cm from other electrical devices (e.g. monitor) to achieve optimum performance.
• The distance between the keyboard, mouse and receiver should not exceed 10 meter.
• Do not place the receiver on metal surfaces.
• Do not move optical mouse on following surface - Glass or any transparent materials
Dark surface
Mirror or reflecting surface
Mouse pad with too many colors
Rough surface.
Step 1: Connect the receiver
1. Plug the receiver connector into an USB port.
2. SYSTEM will take around 10 sec to find your keyboard and mouse automaticall y.
3. Put two batteries into your keyboard battery chamber, and another two batteries into your mouse battery chamber.
Setp 2: Insert batteries
Inserting batteries in mouse
The mouse requires two alkaline batteries .
(1) Please remove the battery compartment cover on the bottom of the mouse.
(2) Insert the two alkaline batteries in the battery compartment.
(3) Fix the battery compartment cover (1) on the bottom of mouse again
1 - English
User's ManualWireless Keyboard + Mouse Kits
1= Cover
2= Battery compartment
3= Channel setting button
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to
instruction. Refer to " important battery information" for disposal instructions.
1= Cover
2= Battery compartment
3= Channel setting button
1
2
3
Inserting batteries in keyboard
The keyboard requires two alkaline batteries (AA).
• Remove the battery compartment cover (1) on the bottom of the keyboard by pushing it in the direction of arrow.
• Insert two AA batteries.
The illustration in the battery compartment (2) shows how to insert the batteries properly.
• Recover the battery compartment by pushing the locking lug (2) under the battery compartment.
Note: Please do not push the channel setting button (3) to the side of the battery compartment cover. It may cause the
channel or ID change. It is the same for the mouse and keyboard.
1
2
3
Setp 3: Connect Keyboard and Mouse to your receiver
• Push the connect button on the top of receiver. The indicator on the top of receiver will start blinking.
• Push the connect button on the bottom of the keyboard and mouse to connect
Software Installation
Installing software for keyboard
• Start the computer and insert the CD ROM.
• Start the "Setup " program from the CD ROM and follow the instruction on the screen.
Once you have installed the software, symbols will be display on Windows task ba r, the multimedia keys can be activated.
On Screen display icon definition
The symbols indicate which keyboard mode is active. They match the displays on ordinary keyboards. The symbol is green
when the respective mode is activated and light grey when it is deactivated.
Uppercase mode (Caps Lock)
Virtual numeric keypad (Num Lock)
Stop screen output (Scroll Lock)
Keyboard battery low indicator
Mouse battery low indicator
Working with keyboard and mouse
The following sections contain information on using the keyboard and the mouse.
Using mouse wheel
In addition to the left and right buttons, the mouse also has a wheel that can be used as follows:
• As a 3rd button: Press on the wheel.
• For scrolling, e.g. in documents or on Internet pages to turn the wheel forward or back.
English - 2
User's ManualWireless Keyboard + Mouse Kits
Keyboard
The keyboard has several additional function keys and a battery status indicator.
a. Multimedia-keys
The following description of keys applies for the operating systems that support these functions (e.g. Windows ME,
Windows 2000 and Windows XP).
To use the multimedia keys in Windows 98 you must install the software provided.
Standby mode
Depending on the setting in the BIOS or operating system the computer switches to a standby mode (not under
Windows NT).
Internet
Use this key to start the default internet browser program on your system.
E-mail
Use this key to start the default e-mail program on your system.
Favorites
Open my favorites folder.
Calculator
Activate the Windows default calculato
Search
Activate the OS default search function.
Backward
Switch to the previous web page.
Forward
Switch to the next web page.
Previous Track
Use this key to skip to the forward title in the active player.
Stop
Use this key to end the playback of a title.
Play/Pause
Use this key to start or pause for a short time the playback of a title just as you would with a normal CD player.
Next Track
Use this key to skip to the next title in the active player.
Keyboard Battery Indicator
The battery indicator on the screen shows you the charging state of the batteries. If the battery indicator lights up when
a key is pressed, the batteries are gradually becoming weaker. Replace the batteries soon.
Advice of using the keyboard
The keyboard is ergonomically designed to ensure ease-of-use.
Inconvenient positioning of your keyboard and mouse, awkward arm movements or posture, working with the keyboard
or mouse for lengthy periods without a break can lead to, fatigue, and potential damage to nerves, muscles, and joints.
You can considerably reduce the risk of injury if you follow the simple rules below.
• Arrange your workplace in accordance with the recommendations for an ergonomic workstation provided in the PC
Operating Manual.
• Position the keyboard so that you can use it without any noticeable strain. The keyboard should be level with the upper
part of you body. This prevents any tension in the shoulders and arms.
• The distance between the keyboard and the edge of the desk should be 5 to 10 cm.
• When typing, hold your hands and forearms so that they form as natural a line as possible. Do not turn your hands too
far to the left or right.
• Keep your wrists straight while typing. Do not angle your hands upwards or downwards.
• Do not rest your hands on the balls of your thumbs while typing, and do not strike the keys too hard.
• Relax your hands by occasionally taking a break from typing. During these breaks you should try some stretching
exercises and rest.
Cleaning the keyboard and the mouse
• Use disinfectant wipes to clean the keyboard and the mouse.
• Do not use any solvent, which may damage the surface of your keyboard and mouse.
Troubleshooting and tips
The keyboard or mouse does not operate following installation or is not recognized.
• Make sure that the batteries have been inserted correctly according to the polarity and the receiver is well connected.
• Check that your USB port is configured properly.
• Check whether the respective channels and ID are set on the receiver keyboard and mouse.
• Make sure the batteries are not too weak.
• Remove the batteries from the device. Please press any button on the device several times to prevent any unexpected
failure after batteries being put in.
• Change the location of the receiver to and find a position with best sensitivity for receiving the signal.
• To determine whether the keyboard, mouse or computer causes the problem, test the keyboard and mouse on a
second computer if possible; or test another keyboard and mouse on your current computer.
If you are still unable to solve the problem, please contact your dealer.
If you need to exchange the keyboard, please note that you must return it to your dealer in its original packaging and
proof of purchase (receipt). Keep your receipt in a safe place after purchase.
Decreasing the volume
This key decreases the volume of the connected loudspeakers.
Mute
Use this key to switch on/off the connected loudspeakers.
Increasing the volume
This key increases the volume of the connected loudspeakers.
b. Additional Hotkeys
Refresh
Use this key to reload / upload browser data.
My Computer
Open My Computer folder.
My Document
Open My Document folder.
c. Special Features of Multimedia Keys
The proper function of the multimedia keys will depend on your system and is influenced by the following factors.
d. System Board (motherboard) and BIOS
The "Standby mode" key only functions correctly when the system board, BIOS and operating system of your computer
fully supports the ACPI function.
3 - English
User's ManualWireless Keyboard + Mouse Kits
