User Manual (Quick Start Guide) rev

Quick Start Guide
Z240IE
E12257_Zen_AiO_Z240IE_QSG.indd 1 2016/12/9 �� 02:35:10
IR Camera module*
Camera Microphone
Wireless Keyboard Wireless Mouse
Mode
button
Mode Up
button
Mode Down
button
* Available on selected models only
E12257_Zen_AiO_Z240IE_QSG.indd 2 2016/12/9 �� 02:35:11
Power button
2-in-1
card reader
USB 3.1 Gen1
USB 3.1 Gen2 Type-C
USB 2.0
HDMI-out
LAN port
Power
input
Kensington®
security slot
Microphone
Headphone
* This port may vary per model
ASUS hereby delcares that this All-in-One PC is in compliance with the essential requirements
and other relevant provisions of Directive 1995/5/EC.
HDMI-in*
E12257_Zen_AiO_Z240IE_QSG.indd 3 2016/12/9 �� 02:35:12
NOTE:
• Theappearanceofthewirelessmousemayvaryperregion,please
refer to the steps above according to the model of your mouse.
• UsingSuperSpeedUSBdevicesand2.4GhzUSBwirelessdevicesat
the same time may aect the wireless device performance.
• Thewirelessmousehasapowersavingfeatureandwillentersleep
modeafterafewminutesofinactivity.Towakeyourmouse,press
any button on your mouse.
To use your wireless mouse (on selected models)
15060-92210000
SERVICE AND SUPPORT
Visit our multi-language web site at
https://www.asus.com/support
E12257
First Edition
December 2016
1. Flip your bundled mouse over.
2. Open the bottom cover:
A. Press down on the lower
half of the bottom cover.
B. Push the latch up.
3. Remove the bottom cover.
4. Removethewirelessdongle
from the mouse and insert it
into an empty USB port on
your ASUS All-in-One PC.
E12257_Zen_AiO_Z240IE_QSG.indd 4 2016/12/9 �� 02:35:12
