ChipSiP Technology CWFB11X-XXX 2.4G AP PCBA User Manual

ChipSiP Technology Co.,Ltd. 2.4G AP PCBA

user manual

CWFB1XX-XXX
Specification
Revision 01
2012/06/06
Prepared By: Jeff Hsieh
RevisionHistory
RevisionDateNotesOwner
012012/06/06InitialReleaseJeffHsieh
 
 

1.WirelessSpec.
WLAN: 1X1
Frequency Range: 802.11b/g/n HT20: 2412 – 2462MHz
802.11n HT40: 2422 – 2452MHz
Channel number: 802.11b/g/n HT20: 11 channels
802.11n HT40: 7 channels
Transmit Power:
802.11b: 20.68dBm
802.11g: 23.14dBm
802.11n HT20 : 22.60dBm
802.11n HT40 : 22.61dBm
Modulation Technology 11b/g: DSSS, OFDM
11n: OFDM
Modulation type: CCK, DQPSK, DBPSK for DSSS
64QAM. 16QAM, QPSK, BPSK for OFDM
Transition Rate:
802.11 b: 1/2/5.5/11 Mbps
802.11 g: 6/9/12/18/24/36/48/54 Mbps
802.11 n HT20MHz: 6.5 – 65Mbps
802.11 n HT40MHz: 13.5 – 135Mbps
Federal Communications Commission (FCC) Statement
You are cautioned that changes or modifications not expressly approved by the part
responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
The following statement must be included with all versions of this document supplied to an OEM or
integrator, but should not be distributed to the end user. This device is intended for OEM integrators
only. Please see the full Grant of Equipment document for other restrictions. This device must be
operated and used with a locally approved access point.
End Product Labeling:
The final end product must be labeled in a visible area with the following:
“Contains FCC ID: O7N-CWFB1XX-XXX”.
