Chuangwei RGB Electronics NTUDB10 WIFI USB DONGLE User Manual manual1
Shenzhen Chuangwei-RGB Electronics Co., Ltd. WIFI USB DONGLE manual1
User Manual
Shenzhen skyworth RGB electronic co., LTD.
Model: NTUD - B10
Operation Instruction
Respect of customer, sincerely thank you for purchasing
SKYWORTH equipped with wireless WIFI NTUD - B10 - type
USB peripheral products.
This product can support USB2.0 protocol, based on the
IEEE802.11 a/b/g/n/ac standard design. With all the way to
send and receive all the way (2T2R) dual channel work,
maximum transmission rate of up to 866 Mbps.Ensure that
users browse and download data flow, security and stability.
NTUD - B10 wireless WIFI USB peripheral product support
Windows XP/Vista / 7 / Linux operating system.In SKYWORTH
TV, have complete embedded in the product and the driver,
without user to install, and at the same time support Linux and
Android.
Used in TV production operation is as follows:
1. Turn on the TV, switch to the "home page" interface.
2. Select "Settings" feature. "OK" to enter
3. Select "network setup" function. "OK" to enter;
4. Choose the "wireless network", "OK" to enter;
5. According to the needs, select "auto search", "manual
connection", etc. Press the "OK" to enter
6. Choose their own after the AP name "OK" to enter, Enter the
password.
Television system has the memory function, for the first time
to use should be according to the above steps, later need not
operation, boot automatically connected.If need to change the
AP or change the mode of connection, need according to the
above steps again.
For a Class B digital device or peripheral, the instructions furnished the user shall include the
following or similar statement, placed in a prominent location in the text of the manual:
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
—
——
—Reorient or relocate the receiving antenna.
—
——
—Increase the separation between the equipment and receiver.
—
——
—Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
—
——
—Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a
separation distance of at least 20 cm from all persons.
The transmitter module can not be located with any transmitter or antenna. The module shall
be only used with listed antenna(s) that has been tested and certified with this module. End
labeling: The final end product must be labeled in a visible area with the following: Contains
FCC ID: 2ANM3NTUDB10
