Cisco Systems 2500-MDM19-C1 2.6 GHz LCD CPE Modem User Manual modem user guide
Cisco Systems, Inc 2.6 GHz LCD CPE Modem modem user guide
User guide
TABLE OF CONTENTS
PERMISSIONS, TRADEMARKS & DISTRIBUTION.............................................................................3
SAFETY .......................................................................................................................................................4
REGULATORY INFORMATION ..............................................................................................................5
BATTERY PRECAUTIONS........................................................................................................................6
INTRODUCTION.......................................................................................................................................7
PACKAGE INVENTORY .........................................................................................................................7
RIPWAVE MODELS.................................................................................................................................7
OPERATING FREQUENCIES .........................................................................................................................8
COMPUTER CONNECTIONS .........................................................................................................................8
MINIMUM COMPUTING REQUIREMENTS ......................................................................................9
PHYSICAL CHARACTERISTICS ........................................................................................................10
INSTALLING AN ETHERNET MODEM ............................................................................................13
INSTALLING A USB MODEM..............................................................................................................15
ACCESSING THE INTERNET..............................................................................................................20
TROUBLESHOOTING ...........................................................................................................................20
INDICATOR LIGHTS OR LCD DISPLAY .....................................................................................................20
INSTALLING NAVINI RIPWAVE MONITOR (NAVMON) ............................................................22
TROUBLESHOOTINGUSING NAVINI RIPWAVE MONITOR (NAVMON) ...............................26
UNINSTALLING NAVINI RIPWAVE MONITOR (NAVMON).......................................................30
INSTALLING NAVINI DIAGNOSTICS (NAVDIAG)........................................................................31
TROUBLESHOOTING USING NAVINI DIAGNOSTICS (NAVDIAG) ..........................................34
UNINSTALLING NAVINI DIAGNOSTICS (NAVDIAG) ..................................................................40
OPTIONAL BATTERIES .......................................................................................................................41
INSTALLING AND CHARGING THE OPTIONAL INTERNAL BATTERY ................................41
2.4 GHZ BATTERY...................................................................................................................................42
2.3 GHZ, 2.5 GHZ, 2.6 GHZ, & 3.5 GHZ BATTERY................................................................................43
OPTIONAL EXTERNAL BATTERY PACKS .....................................................................................44
CONNECTING THE STANDARD EXTERNAL BATTERY PACK (S-EBP)........................................................44
THE INDICATOR LIGHT ON THE STANDARD EXTERNAL BATTERY PACK (S-EBP)....................................45
CHARGING THE STANDARD EXTERNAL BATTERY PACK (S-EBP)............................................................45
CONNECTING AND THE DISCONNECTING HEAVY DUTY EXTERNAL BATTERY PACK (HD-EBP).............46
THE INDICATOR LIGHT ON THE HEAVY DUTY EXTERNAL BATTERY PACK (HD-EBP) ............................49
CHARGING THE HEAVY DUTY EXTERNAL BATTERY PACK (HD-EBP) ....................................................49
Ripwave Modem User Guide Navini Networks, Inc.
2 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
CARE & MAINTENANCE .....................................................................................................................50
UPGRADING THE MODEM .................................................................................................................51
ADDENDUM 1: RIPWAVE™ MODEM - PC TROUBLESHOOTING............................................52
ADDENDUM 2: END USER SOFTWARE LICENSE AGREEMENT.............................................60
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 3
40-00097-00j(4.3)
Permissions, Trademarks & Distribution
Copyright© 2001 - 2005, Navini Networks, Inc. All information contained herein and disclosed by this
document is confidential and the proprietary property of Navini Networks, Inc. and all rights therein are
expressly reserved. Acceptance of this material signifies agreement by the recipient that the information
contained in this document is confidential and that it will be used solely for the purposes set forth herein.
Acceptance of this material signifies agreement by the recipient that it will not be used, reproduced in
whole or in part, disclosed, distributed, or conveyed to others in any manner or by any means – graphic,
electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval
systems – without the express written permission of Navini Networks, Inc.
Navini Networks is a registered trademark. The Navini Networks logo, Zero-Install, Ripwave, and
Unwired by Navini are trademarks of Navini Networks, Inc. Other product and company names
mentioned herein may be trademarks and/or service marks of their respective owners.
Except for the hardware warranty, nothing herein constitutes any representation, warranty,
assurance, or guaranty of any kind.
Because of continuing developments and improvements in design, manufacturing, and deployment,
material in this document is subject to change without notification and does not represent any
commitment or obligation on the part of Navini Networks, Inc.
Navini Networks, Inc. shall have no liability for any error or damages resulting from the use of this
document.
All Navini Networks logos and trademarks are the property of Navini Networks, Inc. Unauthorized usage
is strictly prohibited without the express written permission of Navini Networks, Inc.
2001 - 2005 Navini Networks, Inc. All rights reserved.
Ripwave Modem User Guide Navini Networks, Inc.
4 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Safety
When using Navini Ripwave electronic equipment, always follow basic safety precautions to reduce the
risk of electrical shock, fire, and injury to people and/or property. Follow all warnings and instructions
that come with the equipment.
1. Do not use the equipment while you are in a bathtub, shower, pool, or spa. Exposure of the
equipment to water could cause severe electrical shock or serious damage to the equipment.
2. Do not immerse the equipment in any type of liquid. Use a damp clothe and if needed, water and a
mild detergent to clean the plastic shell. Unplug the equipment from the power source before
cleaning.
3. Follow all airport and FAA regulations when using the equipment on or near aircraft.
4. Only operate the equipment from the type of power source(s) indicated in this manual (110/220
VAC, 60/50 Hz adapter or Navini supplied battery). Any other type of input power source may cause
damage to the equipment.
5. Power the equipment using only the battery or the AC adapter cable provided, and in accordance with
the instructions specified in the user manual.
6. Do not use a frayed or damaged power cord. Do not place the power cord where it can be stepped on
or tripped over.
7. Do not touch wires where the insulation is frayed or worn unless the equipment has been
disconnected from its power source.
8. Do not overload wall outlets, power strips, or extension cords. This can cause serious electrical shock
or fire.
9. Do not place the equipment on an unstable surface. It can fall and cause injury or damage to the
equipment.
10. Do not disassemble the equipment. Removing covers exposes dangerous voltages or other risks and
also voids the warranty. Incorrect reassembly can cause equipment damage or electrical shock. Only
an authorized repair technician should service this product.
11. Do not expose the equipment to extreme hot or cold temperatures.
12. Do not use the equipment under the following conditions:
• When the equipment has been exposed to water or moisture.
• When the equipment has been damaged.
• When the power cord is damaged or frayed.
• When the equipment does not operate properly or shows a distinct change in performance.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 5
40-00097-00j(4.3)
Regulatory Information
FCC Notice
CAUTION: This device is a Radio Frequency transmitter. It is required to comply with FCC RF
exposure requirements for transmitting devices. For all LED Modems and all LCD Modems
except for the 2.6 LCD with window mount, a minimum separation distance of 8 inches (20 cm)
or more must be maintained between the antenna and all persons during device operations to
ensure compliance with the FCC’s rules for Radio Frequency Exposure. For the 2.6 LCD Modem
with a window mount, a minimum of 8.3 inches (21 cm) or more must be maintained between the
window mount antenna and all persons during device operations. If this minimum distance cannot
be maintained, exposure to RF levels that exceed the FCC’s limits may result.
FCC Compliance and Advisory Statement
This equipment has been tested and found to comply with the limits for a class B digital device,
Pursuant to Part 15 of the FCC rules. The operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed or used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna,
2) Increase the separation between the equipment and the receiver,
3) Connect the equipment to an outlet on a circuit that is different from the one to which the
receiver is connected,
4) Consult the dealer or an experienced radio/TV technician for additional suggestions.
INFORMATION TO USER
This device has been authorized as a radio frequency transmitter under the appropriate rules of the
Federal Communications Commission. Any changes or modifications not expressly approved by
Navini Networks could void the user’s authority to operate the equipment.
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE U
S
E
Ripwave Modem User Guide Navini Networks, Inc.
6 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Battery Precautions
CAUTION! To reduce risk of injury or fire, follow these instructions when handling the battery.
1. Risk of explosion is possible if the battery is replaced with one not supplied by Navini Networks.
2. Do not dispose of the battery in a fire. They may explode. Check with the local codes for battery
disposal guidelines.
3. Do not open or mutilate the battery. The battery contains substances that are toxic, corrosive, or
harmful to humans. If battery substances come in contact with the skin, seek medical help
immediately.
4. Do not attempt to recharge the battery by any means except per the instructions in this manual.
5. If using an optional internal battery, remove the battery from the equipment if the equipment is not
going to be used for a long period of time. The battery could leak and cause damage to the
equipment.
6. Exercise care when handling the battery to prevent shorting the battery with conducting materials
such as bracelets, rings, and keys.
7. Store the battery pack in a dry place, 0 to +40 degrees Celsius.
8. Dispose of used batteries according to environmental guidelines.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 7
40-00097-00j(4.3)
Introduction
Package
Inventory
Ripwave Models
Congratulations! The Ripwave Modem is a user-friendly, easy-to-
install device that helps you connect wirelessly to the Internet. It
provides complete broadband Internet access to residential and
small office/home office (SOHO) customers without the necessity
of professional hardware installation. The Ripwave Modem also
provides nomadic service availability as a computer with this
device is moved from room to room, location to location, or even
city to city as long as there is coverage in the area.
Please verify the contents of your Ripwave Modem package. If you
do not find all of these items in your package, notify the supplier
from whom you obtained it.
• Ripwave Modem
• Ripwave Modem AC power adapter
• PC-to-Ripwave Modem cable (USB or Ethernet straight cable)
• Ripwave Modem User Guide (on CD)
• Ripwave Modem Quick Installation Guide
• Navini Ripwave Monitor or Navini Diagnostics Installation CD
Your Ripwave Modem will operate in either the 2.3 GHz, 2.4 GHz,
2.5 GHz, 2.6 GHz, 3.4 GHz, or 3.5 GHz range. Within each
frequency range there are several model types, described on the
next page. The 2.4 GHz Modem varies slightly in appearance.
Also, in Release 4.2, the 2.4, 2.5, 2.6, 3.4, and 3.5 GHz Modems
are available in both an LED and LCD version.
Ripwave Modem User Guide Navini Networks, Inc.
8 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Operating
Frequencies
Computer
Connections
Modem Model Frequency Range Operating
Band
2.3 GHz
LED 2300E/U 2.305 GHz – 2.385 GHz WCS+
2.4 GHz
LED 2400 E/U 2.400 GHz – 2.483 ISM
2.4 GHz
LCD
2400-2483
LCD E/U 2.400 GHz – 2.483 GHz ISM
2.5 GHz
LED 2500 E/U 2.500 GHz – 2.596 GHz MMDS/ITFS
2.5 – 2.7
GHz LCD
2.5-2.6 LCD
E/U 2.500 GHz – 2.686 GHz MMDS/ITFS
2.6 GHz
LED 2600 E/U 2.596 GHz – 2.686 GHz MMDS/ITFS
3.4 GHz
LED 3400 E/U 3.410 GHz – 3.525 GHz BWA/FWA
3.4 GHz
LCD
3410-3525
LCD E/U 3.410 GHz – 3.525 GHz BWA/FWA
3.5 GHz
LED 3500 E/U 3.500 GHz – 3.600 GHz BWA/FWA
3.5 GHz
LCD
3475-3600
LCD E/U 3.475 GHz – 3.600 GHz BWA/FWA
The “E” in the model name stands for Ethernet, and the “U” in the
model name stands for Universal Serial Bus (USB). Your computer
will have one of these two types of ports for connecting the
Modem.
• An Ethernet connection will function with any Win32®
Operating System (Windows® 95 or later).
• A USB connection will function only with Windows® 98SE,
Windows® 2000, Windows® ME, or Windows® XP. It will not
work with Windows 95, Windows 98, or Windows® NT.
You must have the Ripwave Modem model with the appropriate
connection for your computer port.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 9
40-00097-00j(4.3)
Minimum
Computing
Requirements
(See, also, Addendum 1)
Operating
System1:
Ethernet Modems: Any Win32 Operating System
(OS) - Windows 952, Windows NT, Windows 983,
Windows 98SE3, Windows 2000, Windows ME3,
Windows XP4, or later version.
USB Modems: Windows 98SE3, Windows 2000,
Windows ME3, Windows XP4,5,6, or later version.
General Information:
Ensure that the pc network port is enabled.
CPU: Pentium level or higher
RAM: 32 MB or the Operating System minimum,
whichever is greater
Hard Drive: 50 MB free disk space for either monitoring
software (Navini Ripwave Monitor or Navini
Diagnostics Tool)
Monitor: 256 colors, 800 x 600 resolution
1NOTE: To upgrade your Operating System after loading the Navini Monitor or
Navini Diagnostics software, you must first uninstall Navini Monitor or Navini
Diagnostics prior to upgrading the OS. Otherwise, Navini Monitor or Navini
Diagnostics will not work. See Uninstall instructions in this Guide.
2NOTE: Internet Explorer 3.0 or higher is required for installation on Windows
95 Operating Systems.
3NOTE: The Ripwave Modem must be left powered ON whenever you shut
down or restart any Windows 98 or ME platforms. If the Modem is off, a blue
screen appears on the monitor. In the event that happens you will most likely
have to power cycle the PC.
4NOTE: Windows XP must be Service Pack Level 1 or higher.
5NOTE: Navini Diagnostics software is supported on Win98, Win98SE,
Win2000, WinME, WinXP or higher, Mac X (also called Mac10) or higher, or
Red Hat Linux 8.0 or higher. Mac users must have the Snuffit extraction
software.
6NOTE: USB will not work with Windows 95, Windows NT or Windows 98.
The Ripwave Modem installation sections include instructions for
both Ethernet and USB connections. Be sure to use the instructions
that apply to your Ripwave model. The Navini Monitor software
installation procedure is the same for any of the Ripwave models.
This manual will guide you through the simple process of installing
the Ripwave Modem and software, which has been developed to
optimize the ease and convenience for you, our valued customer.
The 2.6 GHz model is used in most of the illustrations in this
manual where there are no differences in the 2.3, 2.4, 2.5, 2.6, 3.4
& 3.5 GHz models.
If you experience any difficulties with your unit, please contact
your Service Provider or the vendor from whom you obtained your
Ripwave Modem.
Ripwave Modem User Guide Navini Networks, Inc.
10 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Physical
Characteristics
The 2.4 GHz Ripwave Modem varies in some aspects from the 2.3,
2.5, 2.6, 3.4 and 3.5 Modems. As well, the Ethernet connection on
any model varies from a USB connection. Notice the differences
highlighted in the photos below and on the following page.
2.4 GHz LED Ripwave Modem
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 11
40-00097-00j(4.3)
Physical
Characteristics,
continued
2.3, 2.5, 2.6, 3.4 & 3.5 GHz LED Ripwave Modems
Ripwave Modem User Guide Navini Networks, Inc.
12 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Physical
Characteristics,
continued
LCD Ripwave Modems (2.4, 2.5-2.7, 3.4, & 3.5 GHz)
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 13
40-00097-00j(4.3)
Installing an
Ethernet Modem
(See, also, Addendum 1)
The following instructions are for the installation of a Ripwave
Modem that has a Ethernet connection. Please read all instructions
before attempting the installation. It is advisable to turn off the
computer and the Ripwave Modem before performing the
installation.
Step Action Illustration (using LED Modem)
1. Connect the Ethernet
cable to the Ethernet
port on the computer.
2. Connect the other end of
the Ethernet cable to the
Ripwave Modem.
3. Connect the AC power
adapter to the Ripwave
Modem. Plug the other
end into a 110/220 VAC
60/50 Hz outlet.
CAUTION! Only use
the AC power adapter
specifically supplied
with the Ripwave
Modem. Using any other
adapter may cause
damage to the Modem.
Ripwave Modem User Guide Navini Networks, Inc.
14 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing an Ethernet
Modem, continued
Step Action Illustration (using LED Modem)
4. Rotate the antenna on
the Ripwave Modem
clockwise 180 degrees
to the UP position. This
reveals the Ripwave
Modem indicator lights.
CAUTION! Rotation or
movement of the
antenna in any other
direction may cause
damage to the Ripwave
Modem.
5. Turn the Modem ON.
On the 2.4 GHz modem,
do this by flipping the
On/Off switch to the up
position. On all other
models, push the On/Off
button in.
6. If the green Power LED
lights, proceed to Step 7.
(On an LCD Modem,
the display turns on.) If
not, there is a problem
with the Modem or the
AC power adapter.
Check all cables for
proper connection. If
there is still a problem,
contact the supplier who
gave you the package.
Installing an Ethernet Modem, continued
2.4 GHz
2.3, 2.5, 2.6,
3.4, 3.5 GHz
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 15
40-00097-00j(4.3)
Installing a USB
Modem
(See, also, Addendum 1)
Step Action Illustration
7.
Turn your computer on
and log in.
8. Proceed to the
“Troubleshootin
g
/
Installing Navini
Monitor” section of this
manual.
The following instructions are for the installation Ripwave Modem
that has a USB connection. Please read all instructions before
attempting the installation. It is advisable to turn off the computer
and the Ripwave Modem before performing the installation.
Note: The screenshots shown in these instructions were taken from
a laptop with Windows 2000. If you have a Windows 98SE, XP, or
ME operating system, the screens you see may vary from the
screens shown in the instructions.
Step Action Illustration (using LED Modem)
1. Connect the USB cable
to the USB port on the
computer.
2. Connect the other end of
the USB cable to the
back of the Ripwave
Modem.
Ripwave Modem User Guide Navini Networks, Inc.
16 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing a USB Modem,
continued
Step Action Illustration (using LED Modem)
3. Connect the AC power
adapter cable to the back
of the Ripwave Modem.
Plug the other end of the
cable into a 110/220
VAC, 60/50 Hz outlet.
CAUTION! Only use
the AC power adapter
specifically supplied
with the Ripwave
Modem. Using any other
adapter may cause
damage to the Modem.
4. Rotate the antenna on
the Ripwave Modem
180 degrees to the UP
position. This reveals
the Modem’s indicator
lights.
CAUTION! Rotation of
the antenna in any other
direction may cause
damage to the Modem.
5. Turn the Modem ON.
On the 2.4 GHz Modem,
do this by flipping the
On/Off switch to the up
position. On all other
models, push the On/Off
button in.
2.4 GHz 2.3, 2.5, 2.6,
3.4, 3.5 GHz
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 17
40-00097-00j(4.3)
Installing a USB Modem,
continued
Step Action Illustration
6. If the green Power LED
lights, proceed to Step 7.
(On an LCD Modem,
the display turns on.) If
not, there is a problem
with the Modem or the
AC Power Adapter.
Check all cables for
proper connection. If
there is still a problem,
contact the supplier who
gave you the package.
7.
Turn your computer ON
and log in.
NOTE: For Windows
2000, you must be
logged into an account
having Administrative
privileges to install the
Ripwave Modem and its
software.
8. Plug-and-Play will
detect the Ripwave
device now attached to
the computer, and it will
launch the Plug-and-
Play application.
If this does not happen,
the problem may be due
to one of the following:
• Windows NT and
Windows 95 do not
support a USB
device.
• The Modem is not
turned on.
• The Modem is not
connected properly
to the computer.
Ripwave Modem User Guide Navini Networks, Inc.
18 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing a USB Modem,
continued
Step Action Illustration
9. The Add New Hardware
Wizard dialog box
appears. Click Next to
continue.
Windows 2000 Screen
10. Insert the Ripwave
Installation CD into the
computer’s CD-ROM
drive.
11. Select the ‘Search for
the best driver for your
device’ option. Click
Next to continue.
Windows 2000 Screen
12. Select the ‘CD-ROM
drive’ checkbox. Click
Next to continue.
Windows 2000 Screen
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 19
40-00097-00j(4.3)
Installing a USB Modem,
continued
Step Action Illustration
13. Confirm that the drive
location is correct (it
may be different than
the one shown in the
illustration). The file to
be installed should say
‘NETNNUSB.INF”.
Click Next to continue
Windows 2000 Screen
14. Windows will finish
installing the software
files required for the
Ripwave Modem
operation. Click Finish.
NOTE: For Window 98,
a window may appear
asking for drivers to be
installed from the
Windows 98 setup disk.
If so, insert the
Windows 98 setup disk
into the CD-ROM drive
at this time and accept
the defaults.
Windows 2000 Screen
15. After clicking Finish,
the System Settings
Change window appears
asking if you want to
restart your computer
now. Click Yes.
You must restart your
computer at this point
before proceeding.
Windows 2000 Screen
16. After the computer
restart is complete,
proceed to the
“Troubleshooting”
section of the manual.
Ripwave Modem User Guide Navini Networks, Inc.
20 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Accessing the
Internet
Troubleshooting
Indicator Lights or
LCD Display
With your Modem now installed, and both the Modem and
computer power on, you should be able to surf the Internet! To
access the Internet, open the web browser that is installed on your
computer.
After installation, if you are experiencing difficulties with your
Internet connection, please review the Minimum Computing
Requirements and Addendum 1 to ensure your computer meets
those requirements. Next, go back over the installation procedures
and ensure those steps were completed properly.
Assuming the computer requirements are met and the installation
steps were completed as required, you will need to observe the
light indicators on the front of the LED Modem or the signal sync
and signal strength indicators on the LCD Modem. You also may
need to install the monitoring software. This software is provided
on a CD that came in your Modem package. Navini offers two
types of monitoring software. The first type, called the Navini
Ripwave Monitor, is available with Ripwave Modems that have a
software release prior to release 4.0. The second type, called the
Navini Diagnostics Tool, is available with Ripwave Modems that
have a software release of 4.0 or greater.
The Navini Monitor and Navini Diagnostics software assists in
solving connection problems as well as providing information
about the battery power in cases where batteries are used. Batteries
are optional with some Ripwave LED Modems.
The indicator lights on the front of the LED Modem provide
valuable information about its operation. They change appearance
to designate the state of the items that they represent. Used in
conjunction with the monitoring software, you can troubleshoot
signal issues, network connections, and power problems.
The LCD Display performs the same function as the indicator
lights. However, instead of using colored lights, it provides a text-
based display.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 21
40-00097-00j(4.3)
Indicator Lights or LCD
Display, continued
LED Indicator Lights:
Signal Strength Indicator (SSI) Light
Constant Green: Strong signal
Constant Yellow: Medium signal
Constant Red: Weak signal
Flashing Red: No signal
Battery Indicator Light
Constant Yellow: Battery is charging
Constant Red: Battery is less than 20% charged
Flashing Red: Battery is less than 10% charged
Off: Battery is fully charged or not installed
Power Indicator Light
Constant Green: The Modem is ON (AC or DC power)
LCD Display Symbols
Sync Indicator Antenna symbol appears when the Modem is in sync and
s
y
nc stren
g
th is at least −110 dBm.
Signal Strength
Bars
1 bar means signal strength > −110 dBm and ≤ −90 dBm
2 bars mean signal strength > −90 dBm and ≤ −80 dBm
3 bars mean signal strength > −80 dBm and ≤ −70 dBm
4 bars mean signal strength > −70 dBm
Signal Strength
Indicator (SSI)
Power
Indicator
Battery
Indicator
Signal Strength
Indicator (SSI)
Power
Indicator
Battery
Indicator
Power
Indicator
Battery
Indicator
Sync Indicator Signal Strength
Bars
Signal Strength
Indicator (SSI)
Power
Indicator
Battery
Indicator
Signal Strength
Indicator (SSI)
Power
Indicator
Battery
Indicator
Power
Indicator
Battery
Indicator
Sync Indicator Signal Strength
Bars
Sync IndicatorSync Indicator Signal Strength
Bars
Ripwave Modem User Guide Navini Networks, Inc.
22 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing Navini
Ripwave
Monitor
(NavMon)
Navini’s monitoring software (Navini Ripwave Monitor or Navini
Diagnostics) provides two types of information: signal strength and
quality of the incoming signal. It also can provide information
about the connectivity to the Service Provider’s network. These
displays may be required when troubleshooting Modem problems.
The next few sections will discuss how to install, troubleshoot
with, and uninstall your Navini Ripwave Monitor (NavMon)
software. If your Ripwave Modem has a software release of 4.0 or
greater, you do not have the NavMon. You have the Navini
Diagnostics software. You should refer to the sections that discuss
how to install, troubleshoot with, and uninstall your Navini
Diagnostics software.
Before you install your NavMon software, please note:
For Windows NT and Windows 2000 you must log into an
account having Administrative privileges in order to install the
Navini Monitor software.
For Windows 98, and 98SE Operating Systems (OS), the OS
CD may be required to complete this installation. If prompted,
insert the OS CD into the CD-ROM drive and accept the
defaults.
After the NavMon software is loaded, if you must upgrade your
PC OS, first uninstall NavMon prior to upgrading the OS.
Otherwise, NavMon will not work. See Uninstall instructions
in this Guide.
Note: The screenshots shown in these instructions were taken from
a laptop with Windows 2000. If you have a Windows 98, XP,
or ME operating system, the screens you see may vary from the
screens shown in the instructions.
Step Action Illustration
1. Shut down all programs,
including anti-virus
software programs,
before installing the
Navini Ripwave
Monitor software.
2. Insert the NavMon
Installation CD into the
CD-ROM drive.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 23
40-00097-00j(4.3)
Installing Navini Ripwave
Monitor (NavMon),
continued
Step Action Illustration
3. At the bottom left-hand
corner of your screen,
click Start > Run. In
the Run window, enter
e:\setup in the Open
field (where “e”
represents the CD
drive). Use whatever
letter represents your
CD drive. Click OK to
continue.
Windows 2000 Screen
4. The InstallAnywhere
window appears. The
progress bar indicates
that InstallAnywhere has
initialized.
Windows 2000 Screen
5. The Navini Ripwave
Monitor Introduction
screen appears. Click
Next to continue.
Windows 2000 Screen
6. The License Agreement
screen appears. Read the
Licensing Agreement.
Select the I Accept
option, and click Next to
continue.
NOTE: If the License
Agreement is not
accepted, you cannot
install the software.
Windows 2000 Screen
Ripwave Modem User Guide Navini Networks, Inc.
24 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing Navini Ripwave
Monitor (NavMon),
continued
Step Action Illustration
7. The Ripwave
Positioning screen
appears. Read the screen
for positioning the
Ripwave Modem for
optimum performance.
Click Next to continue.
Windows 2000 Screen
8. The Choose Install
Folder screen appears.
Enter the name of the
folder where you wish to
install the software.
Click Next to continue.
The default installation
folder provided by the
software is shown in the
illustration.
Windows 2000 Screen
9. The Pre-Installation
Summary screen
appears. Review the
contents for accuracy.
Click Install to
continue.
NOTE: For your
installation and
computer, this screen
may have different
information than what is
shown in the illustration.
Windows 2000 Screen
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 25
40-00097-00j(4.3)
Installing Navini Ripwave
Monitor (NavMon),
continued
Step Action Illustration
10. The Installing screen
will display as the
application files are
loaded.
Windows 2000 Screen
11. At the Install Complete
screen, click Done to
close the window.
Windows 2000 Screen
12.
After clicking Done the
System Settings Change
window appears, asking
if you want to restart
your computer now.
Click Yes.
NOTE: You must restart
your computer at this
point before proceeding.
Windows 2000 Screen
Ripwave Modem User Guide Navini Networks, Inc.
26 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Troubleshooting
Using Navini
Ripwave
Monitor
(NavMon)
To open the NavMon software application, click on the “Start”
button and select Programs→Navini Ripwave Monitor→Ripwave
Monitor.
The Navini Ripwave Monitor icon will appear in the toolbox tray
of your computer. Double-click on this icon.
A window with icons and, provided your Modem is on, bar graphs,
will pop up. Notice the bottom right corner of the window shows
the Equipment Identification (EID) for your specific Ripwave
Modem. If you talk with a Service Technician while
troubleshooting, you may be asked for this number.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 27
40-00097-00j(4.3)
Troubleshooting Using
Navini Ripwave Monitor
(NavMon), continued
The icons represent the PC, the connection between the PC and the
Modem, the Modem, the connection between the Modem and the
Base Station, and the Base Station with which the Modem is
communicating.
The Signal Strength and Signal Quality are dynamic bar graphs
that indicate how well your Modem is receiving signals from the
Base Station. The Signal Strength is a negative number; therefore,
the stronger the signal, the lower (in absolute value) the number
displayed to the right of the bar. For example, -75 indicates a
stronger signal than –90. On the other hand, the Signal Quality is a
positive number; therefore, the higher the quality of the signal, the
higher the number displayed to the right of the second bar. For
example, 21 indicates a better signal than 15.
To increase the strength and quality of the signal, change the
location of the Ripwave Modem. Try moving it closer to a window,
to a higher location, away from other wireless devices (microwave
ovens, cordless phones), and away from metal objects (shelves, file
cabinets). As the Ripwave Modem is repositioned, observe the
Signal Strength and Signal Quality bar graphs. Position the Modem
for maximum signal strength and quality.
PC BTS
Connection
from PC to
M
odem
Modem Connection
from Modem
to BTS
Ripwave Modem User Guide Navini Networks, Inc.
28 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Troubleshooting Using
Navini Ripwave Monitor
(NavMon), continued
If you make a service call to your Service Provider, the Technician
may ask you to read the numbers to the right of the signal bar
graphs. These will help the Technician to evaluate the best position
for your Ripwave Modem. The Battery Strength bar graph and the
number to the right of it indicate how much charge is left in the
battery. Not all Modems have the battery option. Only some LED
Modems have a battery option. Without a battery in the Modem,
the Battery Strength bar graph and number will be disabled (grayed
out).
If the connection between the PC and the Modem or between the
Modem and the Base Station is interrupted, a, red circle with a
slash will be positioned over the corresponding icon.
In this example, the cable connecting the computer and Modem is
not operational; the wireless signal between Modem and Base
Station is down; and there is no battery being used.
To check connectivity to the Service Provider’s network, click the
Advanced button on the NavMon window. The Advanced section
of the window appears and displays several strings of characters
representing selected IP-addressable nodes in the network. These
strings of characters (displayed) and the associated IP addresses
(not displayed) are configurable by the Service Provider on a BTS-
per-BTS basis. Note that if the connection between the Ripwave
Modem and the Base Station is down, the Advanced button will be
disabled (grayed out).
The blue question marks on the right side of the Advanced section
indicate that all connections are untested. Now click on the Run
Tests button at the bottom of the window. The PC will attempt to
ping the IP address associated with each one of the character
strings. Each blue question mark will change to either a blue
checkmark or a red circle with a slash mark. A blue checkmark
indicates that the connection to the IP is good. A red circle with a
slash mark indicates there is a problem with that connection to that
IP (although the problem could be that an incorrect or unreachable
IP was configured).
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 29
40-00097-00j(4.3)
Troubleshooting Using
Navini Ripwave Monitor
(NavMon), continued
The features of the Advanced and Run Tests buttons are to be used
in conjunction with your Service Provider Technician to resolve
problems. There is no need to use these features unless you are
experiencing problems with the Modem.
Ripwave Modem User Guide Navini Networks, Inc.
30 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Uninstalling
Navini Ripwave
Monitor
(NavMon)
If for some reason you need to uninstall the Navini Ripwave
Monitor software, e.g., to upgrade your Operating System
software, follow the procedure below.
Note: The screen shots shown in these instructions were taken from a laptop
with Windows 2000. If you have a Windows 98, XP, or ME operating system,
the screens you see may vary from the screens shown in the instructions.
Step Action Illustration
1. On your computer
screen lower left corner,
click on Start >
Programs > Navini
Ripwave Monitor >
Uninstall Ripwave
Monitor. The Install-
Anywhere Uninstaller
screen appears. Click
Uninstall.
Windows 2000 Screen
2. The screen will cycle
through as the
application files are
uninstalled.
Windows 2000 Screen
3. The Uninstall Complete
screen appears when
finished. Click on Quit
to close the Uninstall
screen.
Windows 2000 Screen
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 31
40-00097-00j(4.3)
Uninstalling Navini
Ripwave Monitor
(NavMon), continued
Installing Navini
Diagnostics
(NavDiag)
Step Action Illustration
4. Restart the PC to
complete the uninstall
process. This will ensure
it functions properly
after uninstalling.
If your Ripwave Modem has a software release prior to 4.0, you
have the Navini Monitor software and not the Navini Diagnostics.
Note: The screenshots shown in these instructions were taken from
a laptop with Windows 2000. If you have a Windows 98, XP, or
ME operating system, the screens you see may vary from the
screens shown in the instructions.
Step Action Illustration
1. Shut down all programs,
including anti-virus
software programs,
before installing the
Navini Diagnostics
software.
2. Insert the Navini
Diagnositcs Installation
CD into the CD-ROM
drive.
3. Open the CD by clicking
on the My Computer
icon. Double-click on
the folder named
Navini_Diagnostics.
4. Double-click on the icon
for the file
navdiag_windows.exe*.
This will automatically
start the installation of
Navini Diagnostics.
*If your PC is running Mac
or Linux software, you will
need the navdiag_mac.sit or
navdiag_linux.bin file. Mac
users will need the Snuffit
extraction software.
Example:
Double-click
this file.
These 2 files used only
for USB Modems.
Double-click
this file.
These 2 files used only
for USB Modems.
Ripwave Modem User Guide Navini Networks, Inc.
32 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing Navini
Diagnostics (NavDiag),
continued
Step Action Illustration
5. The InstallAnywhere
window appears. The
progress bar indicates
that InstallAnywhere has
initialized.
Windows 2000 Screen
6. The Navini Diagnostics
Language screen
appears*. Select a
language and click OK
to continue.
Windows 2000 Screen
*NOTE: Your version of NavDiag may automatically attempt to
match whatever language is set on your PC under Regional
Options. The language selection concerns how NavDiag displays
its screens. If you receive an error message concerning the
language, click OK and NavDiag will default to English. The 3
languages supported by NavDiag at this time are: English (U.S.),
Spanish (Spain), and Dutch (Holland).
7. The progress bar
indicates the files being
installed.
Windows 2000 Screen
8. The Navini Diagnostics
Introduction screen
appears. Click Next to
continue.
Windows 2000 Screen
Installing Navini
Diagnostics (NavDiag), continued
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 33
40-00097-00j(4.3)
Step Action Illustration
9. The License Agreement
screen appears. Read the
Licensing Agreement.
Select the I Acce
p
t
Windows 2000 Screen
option, and click Next to
continue.
NOTE: If the License
Agreement is not accepted,
you cannot install the
software.
10. The Choose Install
Folder screen appears.
Enter the name of the
folder where you wish to
install the software.
Click Next to continue.
NOTE: The default
installation folder provided
by the software is shown in
the illustration.
Windows 2000 Screen
11. The Choose Shortcut
Folder screen appears.
Select On the Desktop
and click Next to
continue.
Windows 2000 Screen
12. The Pre-Installation
Summary screen
appears. Review the
contents for accuracy.
Click Install to
continue.
For your installation and
computer, this screen
may have different
information than what is
shown in the illustration.
Windows 2000 Screen
Ripwave Modem User Guide Navini Networks, Inc.
34 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Installing Navini
Diagnostics (NavDiag),
continued
Troubleshooting
Using Navini
Diagnostics
(NavDiag)
Step Action Illustration
13. The Installing screen
will display as the
application files are
loaded.
14. At the Install Complete
screen, click Done to
close the window.
Windows 2000 Screen
To open the Navini Diagnostics software application, double-click
on the Navini Diagnostics icon on your desktop.
Navini Diagnostics.lnk
The Connection Status screen will open and display data if the
Modem is in session. The screen will refresh live data every
second.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 35
40-00097-00j(4.3)
Troubleshooting Using
Navini Diagnostics
(NavDiag), continued
The icons represent the PC, the connection between the PC and the
Modem, the Modem, the connection between the Modem and the
Base Station, and the Base Station to which the Modem is
communicating. Check marks over the connections indicate
working connections.
If the connection between the PC and the Modem or between the
Modem and the Base Station is interrupted, an “X” is positioned
over the corresponding icon.
The Signal Strength and Signal Quality are dynamic bar areas that
indicate how well your Modem is receiving signals from the Base
Station. In particular, the Signal Strength bar area graphically
represents the strength of the Absolute BTS Synchronization
Signal received by the Modem. The strength of the signal is
represented by a group of colored bars. The higher the pile of bars
goes, the stronger the signal is. The color of the bars also gives an
indication of the strength of the signal. Green bars indicate an
excellent signal. Orange bars indicate a good signal while red bars
indicate a weak signal.
Ripwave Modem User Guide Navini Networks, Inc.
36 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Troubleshooting Using
Navini Diganostics
(NavDiag), continued
The Signal Quality bar area graphically represents the Signal-to-
Noise Ratio (SNR) of the downlink access code channel (ACC)
received by the Modem. Again, the SNR is represented by a group
of colored bars. The higher the pile of bars goes, the better the SNR
of the signal. The color of the bars also gives an indication of the
quality of the signal. Green lines indicate a high SNR. Orange lines
indicate a moderate SNR while red lines indicate a low SNR.
To increase the strength and quality of the signal, change the
location of the Ripwave Modem. Try moving it closer to a window,
to a higher location, away from other wireless devices (microwave
ovens, cordless phones), and away from metal objects (shelves, file
cabinets). As the Ripwave Modem is repositioned, observe the
Signal Strength and Signal Quality bars. Position the Modem for
maximum signal strength and quality.
The History graphs plot the change in signal strength and signal
quality over time. The graphs cover the last minute and are updated
every second. Read the graphs from right to left. The right side of
the graph represents the most recent status of your Modem.
At the bottom of the Connection Status screen, are four parameters.
These parameters are BTS ID, Network ID, Active SW Version,
and Standby SW Version. The BTS ID and Network ID indicate
the BTS to which the Modem is currently synchronized and the
network in which the Modem is operating. Active SW Version and
Standby SW Version indicate the version number of the software
currently loaded in the “active side” and “standby side” of the
Modem’s flash memory.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 37
40-00097-00j(4.3)
Troubleshooting Using
Navini Diganostics
(NavDiag), continued
The two letters in parenthesis following the release number
indicate the type of software load. JD indicates Joint Detection,
while EN indicates Enhanced Nulling.
On the left-hand side of the screen, there are five screen options:
Connection Status, Configuration, Trend Analysis, Statistics, and
About. The following screen will appear when you press the
Configuration button.
The Configuration screen enables you to update your Modem’s
software if you are so directed by your Service Provider. If you
must update your Modem’s software, your Service Provider will
provide you with instructions regarding what to do.
The Allow Customer Satisfaction Reporting box gives you control
over whether your Service Provider is allowed to monitor your
Modem using the remote CPE Logging function and to use your
computer to store the CPE log files created by this function. By
default, this box is checked which means the Service Provider can
monitor your Modem. Currently, this feature works only with LED
Modems.
The Trend Analysis screen enables you to view how some Modem
parameters evolve over time. With this screen, you can select up to
three parameters to plot. To view the Trend Analysis screen, press
the Trend Analysis button.
Ripwave Modem User Guide Navini Networks, Inc.
38 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Troubleshooting Using
Navini Diganostics
(NavDiag), continued
By pressing the Plot Graph button, the following screen will
appear. This screen displays the value of the selected parameters
over the last five minutes, updated once every second. The graphic
scrolls from right to left.
To view the Statistics screen, press the Statistics button. The
statistics screen enables you to view the current value of selected
parameters. These values are updated as they change over time.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 39
40-00097-00j(4.3)
Troubleshooting Using
Navini Diganostics
(NavDiag), continued
The About screen provides vital information such as the version of
the Navini Diagnostics software currently installed in your
computer. It also provides a website address and telephone number
where you can contact your Service Provider. To view the About
screen, press the About button. An example of the About screen
follows.
A Help button appears on the top right corner of all the NavDiag
windows. The Help button gives you two options. The first option,
On NavDiag, provides help text on the functionality of the
NavDiag program. The second option, About NavDiag, is
equivalent to clicking on the About icon.
Ripwave Modem User Guide Navini Networks, Inc.
40 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Uninstalling
Navini
Diagnostics
(NavDiag)
If for some reason you need to uninstall the Navini Diagnostics
software, e.g., to upgrade your Operating System software, follow
the procedure below.
Note: The screen shots shown in these instructions were taken from a laptop
with Windows 2000. If you have a Windows 98, XP, or ME operating system,
the screens you see may vary from the screens shown in the instructions.
Step Action Illustration
1. On your computer
screen lower left corner,
click on Start >
Programs > NavDiag >
Uninstall.
Windows 2000 Screen
2. The Install-Anywhere
Uninstaller screen
appears. Click
Uninstall.
Windows 2000 Screen
3. The screen will indicate
the application files are
uninstalled.
Windows 2000 Screen
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 41
40-00097-00j(4.3)
Uninstalling Navini
Diagnostics (NavDiag),
continued
Optional
Batteries
Installing and
Charging the
Optional Internal
Battery
Step Action Illustration
4. The Uninstall Complete
screen appears when
finished. Click on Quit
to close the Uninstall
screen.
Windows 2000 Screen
5. Restart the PC to
complete the uninstall
process. This will ensure
the uninstall process
completes successfully.
The Ripwave LED and LCD Modems have two types of optional
batteries associated with them: internal and external battery packs.
The internal battery pack is inserted into the Modem. Currently,
this battery pack has been manufacture discontinued. However,
existing internal battery packs are still supported.
The external battery packs come in two sizes. The Standard
External Battery Pack (S-EBP) provides approximately 16 Watt-
Hours of power while the Heavy Duty-External Battery Pack (HD-
EBP) provides approximately 44 Watt-Hours of power.
This section describes how to install and charge the optional
internal and external battery packs.
If you have an internal battery packs, the battery pack is installed in
the bottom of the Ripwave Modem. The battery compartment of
the 2.4 GHz Ripwave Modem varies from the 2.3, 2.5, 2.6, 3.4 and
3.5 GHz models. To install and charge or remove the battery pack,
follow the steps based on your model of Modem.
Ripwave Modem User Guide Navini Networks, Inc.
42 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
2.4 GHz Battery
Step Action Illustration
1. Squeeze both tabs to
remove or install the
battery pack cover.
Note that the cover is
not used when the
battery pack is installed
in the Modem.
2. Install the battery pack
into the Ripwave
Modem, ensuring that
the contacts on the
battery pack mate with
the contacts in the
Modem and that both
slides snap down
securely.
3. Reinstall the battery
pack cover on the
Modem.
4. To charge the battery,
connect the AC adapter
to the Modem and to an
AC power source
(110/220 VAC, 60/50
Hz). The battery
immediately will begin
charging regardless of
whether the On/Off
switch is on. However,
the pack will charge
faster if the on/off
switch is in the OFF
position.
If the on/off switch is
ON, the light indicator
will be constant yellow.
When fully charged, the
light will go off.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 43
40-00097-00j(4.3)
2.3 GHz, 2.5 GHz, 2.6
GHz, & 3.5 GHz Battery
Step Action Illustration
1. Applying light pressure,
push the tab on the
battery pack cover to
remove it from the
bottom of the Modem.
2. Install the battery pack
into the Modem,
ensuring that the
contacts mate and that
both sides snap down
securely.
3. Reinstall the battery
pack cover on the
Modem.
4. To charge the battery,
connect the AC adapter
to the Modem and to an
AC power source. The
battery will begin
charging immediately
regardless of whether
the On/Off switch is on.
However, the pack will
charge faster if the
on/off switch is in the
OFF position.
If the on/off switch is
ON, the light indicator
will be constant yellow.
When fully charged, the
light will go off.
Ripwave Modem User Guide Navini Networks, Inc.
44 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Optional External
Battery Packs
Connecting the
Standard External
Battery Pack (S-
EBP)
The external batteries are not installed inside the Modem. Instead
they are connected to the Modem. Before we discuss how to
connect and charge the external battery packs, let’s discuss the
differences between the Standard External Battery Pack (S-EBP)
and the Heavy Duty External Battery Pack (HD-EBP).
The S-EBP can be used with any of the LED or LCD Modems.
The HD-EBP can be used with all LED and LCD Modems
except for the 2.4 GHz LED Modem. The 2.4 GHz Modem can
use only the S-EBP.
The HD-EBP provides 44 Watt-Hours of power while the S-
EBP provides 16 Watt-Hours of power.
The amount of time the S-EBP and HD-EBP can operate before
recharging varies. This time is dependent of the usage run on
the Ripwave Modem. The following table shows example
approximations for how long the batteries can run before a
recharge is required.
Usage Approximate hours of Usage Before
Recharge Required
S-EBP HD-EBP
Standard 2.2 5.9
Moderate 1.5 4.0
Heavy 1.2 3.4
To connect the S-EBP to any of the LED or LCD Modems, plug
the battery’s pig-tail cord into the input socket located on the back
of the Modem.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 45
40-00097-00j(4.3)
The Indicator Light
on the Standard
External Battery
Pack (S-EBP)
Charging the
Standard External
Battery Pack (S-
EBP)
The S-EBP has one indicator light that resides on top of the unit.
This light has four states associated with it. The states are
described below.
Light is off when any of the following apply:
• The battery is not connected to a Modem or to the battery
charger
• The battery is connected to a Modem but the Modem is off
• The battery is connected to a Modem and the Modem is on
but the battery is empty of power
Light is green when the battery is on and fully charged.
Light is amber when the battery has power but is no longer
fully charged. If the battery is connected to the battery charger,
an amber light means the battery is being charged.
Light is red when the battery is low on power. When the
battery is low, it has approximately 15% of its charge left.
The S-EBP will need to be recharged when the battery is connected
to a Modem and the Modem is turned on but the LED on top of the
battery remains off (indicating the battery has no power) or is red
(indicating the battery level is low).
To recharge the S-EBP, use only the 12V charger that came with
the S-EBP. Using any other charger may damage the battery. To
charge the S-EBP, plug the 12V adapter into the 12V input socket
on the S-EBP.
NOTE: The battery may charge while it is connected to a Modem.
NOTE: Do not attempt to plug the 12V adapter into the Modem as this may
harm the Modem.
Ripwave Modem User Guide Navini Networks, Inc.
46 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Connecting and
Disconnecting the
Heavy Duty
External Battery
Pack (HD-EBP)
For LED Modems
If you have a HD-EBP, the battery pack is installed in the bottom
of the Ripwave Modem. The bottom of the LED Ripwave Modem
varies from the bottom of the LCD Modem. To install and or
remove the battery pack, follow the steps based on your model of
Modem.
Step Action Illustration
1. Remove the cover from
the bottom of the LED
Modem.
2. Place the back prong of
the HD-EBP into the
back portion of the
opening on the Modem.
3. Depress the front button
on the HD-EBP so that
the front prong moves in
toward the center of the
HD-EBP.
4. Place the front part of
the opening on the LED
Modem over the front
prong on the battery.
5. Release the button on
the battery.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 47
40-00097-00j(4.3)
For LED Modems,
continued
For LCD Modems
Step Action Illustration
6. Press firmly down on
the Modem so that the
Modem firmly connects
with the HD-EBP.
7. Plug the HD-EBP’s pig-
tail cord into the power
slot on the Modem.
8. To remove the battery
pack from the Modem,
unplug the pig-tail cord.
Depress the front button
on the HD-EBP. Lift the
Modem off of the
battery pack.
Step Action Illustration
1. Depress the front button
on the HD-EBP so that
the front prong moves in
towards the center of the
HD-EBP.
Ripwave Modem User Guide Navini Networks, Inc.
48 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
For LCD Modems,
continued
Step Action Illustration
2. Place the back slot of
the LCD Modem over
the back prong of the
HD-EBP.
3. Place the front part of
the opening on the LCD
Modem over the front
prong on the battery.
4. Release the button on
the battery.
5. Press firmly down on
the Modem so that the
Modem firmly connects
with the HD-EBP.
6. Plug the HD-EBP’s pig-
tail cord into the power
slot on the Modem.
7. To remove the battery
pack from the Modem,
unplug the pig-tail cord.
Depress the front button
on the HD-EBP. Lift the
Modem off of the
battery pack.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 49
40-00097-00j(4.3)
The Indicator Light
on the Heavy Duty
External Battery
Pack (HD-EBP)
Charging the
Heavy Duty
External Battery
Pack (HD-EBP)
The HD-EBP has one indicator light that resides on the back end of
the unit near the pig-tail cord. This light has four states associated
with it. The states are described below.
Light is off when any of the following apply:
• The battery is not connected to a Modem or to the battery
charger
• The battery is connected to a Modem but the Modem is off
• The battery is connected to a Modem and the Modem is on
but the battery is empty of power
Light is green when the battery is on and fully charged.
Light is amber when the battery has power but is no longer
fully charged. If the battery is connected to the battery charger,
an amber light means the battery is being charged.
Light is red when the battery is low on power. When the
battery is low, it has approximately 15% of its charge left.
The HD-EBP will need to be recharged when the battery is
connected to a Modem and the Modem is turned on but the LED on
the back of the battery remains off (indicating the battery has no
power) or is red (indicating the battery level is low).
To recharge the HD-EBP, use only the 12V charger that came with
the HD-EBP. Using any other charger may damage the battery.
To charge the HD-EBP:
Plug the 12V adapter into the 12V input socket on the HD-
EBP.
Plug the other end of the adapter into an electrical wall socket.
NOTE: Do not attempt to plug the 12V adapter into the Modem as this may
harm the Modem.
NOTE: The battery may charge while it is connected to a Modem.
Ripwave Modem User Guide Navini Networks, Inc.
50 050503_pv1.1_Ripwave Modem User
Guide_40-00097-00j(4.3)
Care &
Maintenance
The Ripwave Modem is designed to give years of trouble-free
service. To ensure operation, read the following care and
maintenance instructions.
Keep the Modem free of dust and moisture. If the Modem gets
wet, use a towel to dry it immediately.
Handle the Modem gently. Dropping it or mishandling it can
cause damage to the plastic shell or the electronic circuitry.
Keep the Modem away from high temperatures. Heat can cause
damage to the plastic shell or the electronic circuitry.
Use only a mild detergent and a soft, damp cloth to clean the
Modem. Do not use any chemicals or abrasives to clean the
plastic shell.
If there is a problem with the Modem, do not attempt to repair
it yourself. Report the problem to your Service Provider.
If you are going to upgrade your Operating System after
loading the Navini monitoring software (Navini Ripwave
Monitor or Navini Diagnostics), you must first uninstall the
monitoring software prior to upgrading the OS. Otherwise, the
monitoring software will not work. See Uninstall instructions
in this Guide.
The Ripwave Modem must be left powered ON whenever you
shut down or restart any Windows 98 or ME platforms. If the
Modem is off, a blue screen appears on the monitor. In the
event this happens you will mostly likely have to power cycle
the PC.
Navini Networks, Inc. Ripwave Modem User Guide
0500503_pv1.1_Ripwave Modem User Guide _ 51
40-00097-00j(4.3)
Upgrading the
Modem
There are three different ways to upgrade the software that makes
the Modem work.
Your Service Provider may perform an over-the-air (OTA)
upgrade, where the up-to-date software files are transferred
wirelessly from the Base Station to your Modem.
Your Service Provider may provide a downloadable web file or
CD-ROM with software to be installed on your PC and used to
upgrade the Modem. This method is used for systems that have
a software release prior to 4.0. You will need the CCU Tool to
load the software.
Your Service Provider may instruct you to use your Navini
Diagnostics Tool to upgrade your Modem software load. This
method is used for systems that have a software release of 4.0
or greater and have the NavDiag monitoring software installed.
The latter two methods are used only if the Modem was not
powered on during the OTA upgrade process. The OTA upgrade is
normally transparent to the user; in other words, there should be no
noticeable service interruption. The web or CD upgrade comes
with instructions and takes a minimal amount of time to complete.
Note: If you use the Navini Diagnostics Tool to upgrade your
Modem software load, the computer connected to your Modem
must already have an IP address. If your computer does not have an
IP address, contact your Service Provider. If you attempt to
upgrade your Modem software through the Navini Diagnostics
Tool and the computer does not have an assigned IP address, you
may see one of the following error messages:
Ripwave Modem User Guide Navini Networks, Inc.
050503_pv1.1_Ripwave Modem User Guide_
40-00097-00j(4.3)
52
ADDENDUM 1: Ripwave™ Modem - PC Troubleshooting
- For Use With All Ripwave Modems, Navini Ripwave Monitor Software, and Navini Diagnostics
Software -
PC Operating Systems
Prior to installing the Navini Ripwave Monitor or Navini Diagnostics software, please check to insure
that the PC Operating System meets the criteria given in the table below. If these criteria are not met,
unpredictable problems may occur as a result of installation. It is recommended that the user have the
latest Windowsc updates installed prior to installing the Navini Ripwave Monitor or Navini Diagnostics
software.
Operating System Ethernet interface USB interface Notes
Win95 Supported Not Supported 1, 2
Win98 Supported Supported 2
Win98, 2nd ed. Supported Supported 2
WinME Supported Supported 2
Win 2000 Supported Supported 2, 4
Win NT 3.0/4.0 Supported Not Supported 1, 2, 4
Win XP Supported Supported 3, 4
Note 1: USB was not supported in this software release
Note 2: Internet Explorer 3.0 or higher is required
Note 3: Requires Service Pack 1
Note 4: To load the Navini Ripwave Monitor or Navini Diagnostics software, the user MUST have Administrative
privileges.
USB Interface
The USB Modem allows for a single PC to be connected to the Ripwave Modem via a USB interface, or
multiple PC’s connected via a USB hub. The Modem conforms to USB 1.1 standards. The Ethernet
packets generated by the PC are encapsulated within the USB protocol and transferred to the Modem.
The packets are then sent over-the-air. The USB Modem is fully supported for PC’s using Windows 98,
Windows ME, Windows 2000, and Windows NT 5.0.
To install the Modem using a USB interface, you must connect the Modem to the PC first and insert the
CD that comes with the modem in the package to load the USB “Miniport” driver. After installing the
USB Miniport driver, the PC may or may not need to be restarted, depending upon the type of Operating
System and the particular installation. The system will prompt if a reboot is necessary.
Now install the Navini Ripwave Monitor or Navini Diagnostics software. You must ALWAYS reboot
the PC after installing or uninstalling this software. Failure to do may gravely affect PC operation.
Navini Networks, Inc. Ripwave Modem User Guide
050503_pv1.1_Ripwave Modem User Guide_
40-0097-00j(4.3)
53
Ethernet Interface
The Ethernet Modem may be connected to a PC via an Ethernet connection. Also, it is possible to
connect multiple PC devices to a single Modem. The multi-PC configuration is transparent to the PC
users and is analogous to a multi-PC configuration on a normal Ethernet LAN. Check with your Service
Provider if multiple IP addressing is required for your particular configuration. The distinct advantage of
the Ethernet Modem is that it connects to any device that has an Ethernet interface. This makes it ideal
for small businesses that have a mix of devices, such as Unix machines, Apple Computers, etc. IP
addresses can be assigned to the devices dynamically via a DHCP server, or as Fixed IP assignments, or
Point-to-Point Protocol Over Ethernet (PPPoE).
Multiple Interface Environments
When a PC has an internal interface (for example, a Wireless Ethernet interface) in addition to the
Ripwave Modem, you should do the following:
• If the wireless connection is not required, disable the internal wireless connection
• If the built-in wireless connection is required for local networking and wireline Ethernet is used via
the Ripwave Modem for Internet connection, change the interface metric configuration so that the
wireline interface’s default gateway is used. (See your Operating System’s User Guide.)
Routers
Neither the Navini Ripwave Monitor nor the Navini Diagnostics software will work if it goes through a
router.
Battery
Older Ripwave Modems gave the user the option of buying an 1800 mA Li-Ion battery. With the optional
battery, the user could be connected to the Internet anytime and anywhere there is RF coverage without
the need for a power outlet. The Modem battery was rated to provide 30 minutes to 90 minutes of use
without recharging (depending on activity).
Configuration Options
Ripwave Modem User Guide Navini Networks, Inc.
050503_pv1.1_Ripwave Modem User Guide_
40-00097-00j(4.3)
54
Results of Correct Navini Monitor Installation
Experienced PC users can check the results of the Navini Ripwave Monitor installation by
looking at the log file that is created during the installation process. The log file is named
“Ripwave_Monitor_InstallLog.log.” It is located under c:\Program Files\Navini Ripwave
Monitor.
-------
Install Begin: Tue Jul 20 12:06:49 CDT 2004
Install End: Tue Jul 20 12:06:58 CDT 2004
Created with Zero G's InstallAnywhere 4.5.3 Enterprise Build 1394
Summary
-------
Installation: Successful.
33 SUCCESSES
0 WARNINGS
0 NONFATAL ERRORS
0 FATAL ERRORS
Action Notes:
None.
Install Log Detail:
Custom Action: com.navini.iatool.KillMon
Status: SUCCESSFUL
Check Disk Space: C:\Program Files\Navini Ripwave Monitor
Status: SUCCESSFUL
Additional Notes: NOTE - Required Disk Space: 23,260,112; Free Disk Space: 30,808,473,600
Install Directory: C:\Program Files\Navini Ripwave Monitor\jre
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Install Directory: C:\Program Files\Navini Ripwave Monitor\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Install Directory: C:\Program Files\Navini Ripwave Monitor\UninstallerData\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Custom Action: com.navini.iatool.KillMon
Status: SUCCESSFUL
Install Uninstaller: Ripwave Monitor (Install All Uninstaller Components)
Navini Networks, Inc. Ripwave Modem User Guide
050503_pv1.1_Ripwave Modem User Guide_
40-0097-00j(4.3)
55
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\UninstallerData\Uninstall inst.exe
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\UninstallerData\Uninstall inst.lax
Status: SUCCESSFUL
Install Directory: C:\Program Files\Navini Ripwave Monitor\UninstallerData\resource\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Install File: C:\Program Files\Navini Ripwave Monitor\UninstallerData\resource\iawin32.dll
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\UninstallerData\resource\remove.exe
Status: SUCCESSFUL
Make Registry Entry: Key:
HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall\Ripwave Monitor, Value Name:
DisplayName, Value Data: Ripwave Monitor
Status: SUCCESSFUL
Make Registry Entry: Key:
HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall\Ripwave Monitor, Value Name:
UninstallString, Value Data: "C:\Program Files\Navini Ripwave Monitor\UninstallerData\Uninstall inst.exe"
Status: SUCCESSFUL
Install Uninstaller: Ripwave Monitor (Install All Uninstaller Components)
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\instpro5.exe
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\NAVMON.exe
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\navpro5.inf
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\NAVPRO5.sys
Status: SUCCESSFUL
Registry Entries: Create the InstallDir Key
Status: SUCCESSFUL
Set Environment Variable: PATH = C:\Program Files\Navini Ripwave Monitor
Status: SUCCESSFUL
Install File: C:\Program Files\Navini Ripwave Monitor\reboot.exe
Status: SUCCESSFUL
Install Directory: C:\Documents and Settings\All Users\Start Menu\Programs\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Ripwave Modem User Guide Navini Networks, Inc.
050503_pv1.1_Ripwave Modem User Guide_
40-00097-00j(4.3)
56
Install Directory: C:\Documents and Settings\All Users\Start Menu\Programs\Navini Ripwave Monitor\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Create Shortcut: C:\Documents and Settings\All Users\Start Menu\Programs\Navini Ripwave Monitor\Ripwave
Monitor.lnk
Status: SUCCESSFUL
Create Shortcut: C:\Documents and Settings\All Users\Start Menu\Programs\Navini Ripwave Monitor\Uninstall
Ripwave Monitor.lnk
Status: SUCCESSFUL
Install Directory: C:\WINNT\system32\DRIVERS\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Install File: C:\WINNT\system32\DRIVERS\NAVPRO5.sys
Status: SUCCESSFUL
Install Directory: C:\WINNT\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Install File: C:\WINNT\killmon.exe
Status: SUCCESSFUL
Execute Target File: reboot.exe
Status: SUCCESSFUL
Results of Correct Navini Diagnostics Installation
Experienced PC users can check the results of the Navini Diagnostics installation by looking at
the log file that is created during the installation process. The log file is named
“Ripwave_Diagnostics_InstallLog.log.” It is located under c:\Program Files\Navini
Diagnostics.
-------
Install Begin: Tue Jul 20 12:15:22 CDT 2004
Install End: Tue Jul 20 12:15:30 CDT 2004
Created with Zero G's InstallAnywhere 4.5.3 Enterprise Build 1394
Summary
-------
Installation: Successful with warnings.
2 SUCCESSES
1 WARNINGS
Navini Networks, Inc. Ripwave Modem User Guide
050503_pv1.1_Ripwave Modem User Guide_
40-0097-00j(4.3)
57
0 NONFATAL ERRORS
0 FATAL ERRORS
Action Notes:
None.
Install Log Detail:
Check Disk Space: C:\Program Files\NavDiag
Status: SUCCESSFUL
Additional Notes: NOTE - Required Disk Space: 29,363,315; Free Disk Space: 30,806,179,840
Install Directory: C:\Program Files\NavDiag\
Status: SUCCESSFUL
Get Registry Entry: Key: HKEY_LOCAL_MACHINE\SOFTWARE\Navini Networks\NavDiag, ValueName:
InstallDirectory
Status: WARNING
Additional Notes: WARNING - Win32Exception
Make Registry Entry: Key: HKEY_LOCAL_MACHINE\SOFTWARE\Navini Networks, Value Name: , Value Data:
Status: SUCCESSFUL
Make Registry Entry: Key: HKEY_LOCAL_MACHINE\SOFTWARE\Navini Networks\NavDiag, Value Name: , Value
Data:
Status: SUCCESSFUL
Make Registry Entry: Key: HKEY_LOCAL_MACHINE\SOFTWARE\Navini Networks\NavDiag, Value Name:
InstallDirectory, Value Data: C:\Program Files\NavDiag
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\Uninstall\
Status: SUCCESSFUL
Install Uninstaller: Navini Diagnostics (Install All Uninstaller Components)
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\jre
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\Uninstall\Uninstall NavDiag.exe
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\Uninstall\Uninstall NavDiag.lax
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\Uninstall\resource\
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\Uninstall\resource\iawin32.dll
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\Uninstall\resource\remove.exe
Status: SUCCESSFUL
Ripwave Modem User Guide Navini Networks, Inc.
050503_pv1.1_Ripwave Modem User Guide_
40-00097-00j(4.3)
58
Make Registry Entry: Key:
HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall\Navini Diagnostics, Value Name:
DisplayName, Value Data: Navini Diagnostics
Status: SUCCESSFUL
Make Registry Entry: Key:
HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Uninstall\Navini Diagnostics, Value Name:
UninstallString, Value Data: "C:\Program Files\NavDiag\Uninstall\Uninstall NavDiag.exe"
Status: SUCCESSFUL
Install Uninstaller: Navini Diagnostics (Install All Uninstaller Components)
Status: SUCCESSFUL
Create LaunchAnywhere: Navini Diagnostics.exe (Install All LaunchAnywhere Java Executable Components)
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\Navini Diagnostics.exe
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\Navini Diagnostics.lax
Status: SUCCESSFUL
Create LaunchAnywhere: Navini Diagnostics.exe (Install All LaunchAnywhere Java Executable Components)
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\data\
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\data\images\
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\billboard.gif
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\splash.gif
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\buttonbar.gif
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\about2.gif
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\about1.gif
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\about.gif
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\images\uninstall.gif
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\data\log\
Navini Networks, Inc. Ripwave Modem User Guide
050503_pv1.1_Ripwave Modem User Guide_
40-0097-00j(4.3)
59
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\data\lib\
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\lib\ctl.jar
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\lib\navDiag.jar
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\lib\jfreechart-0.9.13.jar
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\lib\jcommon-0.8.8.jar
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\data\lib\log4j.jar
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\data\doc\
Status: SUCCESSFUL
Install Directory: C:\Program Files\NavDiag\config\
Status: SUCCESSFUL
Install File: C:\Program Files\NavDiag\config\NavDiag.lcf
Status: SUCCESSFUL
Install Directory: C:\Documents and Settings\luis\Start Menu\Programs\NavDiag\
Status: SUCCESSFUL
Create Shortcut: C:\Documents and Settings\luis\Start Menu\Programs\NavDiag\Navini Diagnostics.lnk
Status: SUCCESSFUL
Create Shortcut: C:\Documents and Settings\luis\Start Menu\Programs\NavDiag\Uninstall.lnk
Status: SUCCESSFUL
Install Directory: C:\Documents and Settings\luis\Desktop\
Status: SUCCESSFUL
Additional Notes: NOTE - Directory already existed
Create Shortcut: C:\Documents and Settings\luis\Desktop\Navini Diagnostics.lnk
Status: SUCCESSFUL
Ripwave Modem User Guide Navini Networks, Inc.
050503_pv1.1_Ripwave Modem User Guide_
40-00097-00j(4.3)
60
ADDENDUM 2: End User Software License Agreement
between
Navini Networks, Inc.
and
Buyer
ARTICLE 1
IMPORTANT MESSAGE
1.1 Act of Assent. Installing the Software indicates that you have read, understand and accept this
License Agreement.
ARTICLE 2
LICENSES
2.1 Grant of License. The Software and related Documentation, are the intellectual property of Navini
Networks, Inc. and are protected by law. Navini Networks, Inc. grants to Buyer a personal,
nonexclusive, nontransferable worldwide license, for revocable use (as permitted herein) of the
Software based on the terms and conditions of this License Agreement and the Master Supply
Agreement to which it is attached. Buyer is permitted to install and use the Software on its
server, but only in conjunction with the Navini Hardware. Buyer is not permitted to rent, sell or
otherwise transfer the Software to any third parties.
2.2 Ownership Rights. Under this Agreement, Buyer does not acquire any rights of ownership in the
Software and related Documentation and subsequent releases and versions licensed by Navini
Networks, Inc. to Buyer pursuant to this License Agreement, whether in printed or machine-
readable format. Buyer acquires only the right to use the Software and related Documentation
subject to the terms and conditions of this Agreement. Buyer promises to keep the Software in
confidence for the benefit of Navini Networks, Inc. and agrees to destroy or return the Software
and all copies at such time as Buyer chooses to cease using the Software or upon termination or
cancellation of this License Agreement for any reason.
2.3 Backup Copies. Buyer may copy the Software for safekeeping (archival) or backup purposes,
provided that all such copies of the Software are subject to the provisions of this License
Agreement, and also provided that each copy shall include in readable format any and all
confidential, proprietary, and copyright notices or markings contained in the original.
2.4 Assignment. The rights granted in this License Agreement are restricted for use solely by Buyer
and may not be assigned, transferred, or sublicensed, however Buyer may grant access to its
server to End-Users. Each Buyer shall be authorized to make use of the Software in the form in
which it is provided to Buyer solely for Buyer’s own computer server location. Buyer represents
that it will not use the Software for any purpose that is not expressly delineated in this
Agreement. Further Buyer represents that it will comply with all export, re-export, and other
laws in its use of the Software.
Navini Networks, Inc. Ripwave Modem User Guide
050503_pv1.1_Ripwave Modem User Guide_
40-0097-00j(4.3)
61
2.5 Suitability.
a. Buyer alone is responsible for determining which software best suits Buyer’s needs, for
installing and operating the Software, and for the results obtained. Accordingly, each
Buyer should determine its needs, and evaluate the Software’s capabilities before making
a final decision about licensing the software.
b. Navini Networks, Inc. makes no representation that the Software conforms to or satisfies
any federal, state, or local laws. Buyer is encouraged to engage professional assistance
from attorneys and engineers to evaluate the suitability of the Software for Buyer’s use.
c. Navini Networks, Inc. makes no claims that the Software is suitable for Buyer’s intended
purposes.
2.6 Remote Digital Access. Navini Networks, Inc. reserves the right, but is not obligated to digitally
access the Software for the purposes of upgrading and maintaining the Software.
2.7 U.S. GOVERNMENT RESTRICTED RIGHTS. All Software provided to the U.S. Government
pursuant to solicitations issued on or after December 1, 1995 is provided with the commercial
license rights and restrictions described elsewhere herein. All Software provided to the U.S.
Government pursuant to solicitations issued prior to December 1, 1995 is provided with
“Restricted Rights” as provided for in FAR, 48 CFR 52.227-14 (June 1987) or DFAR, 48 CFR
252.227-7013 (Oct 1988), as applicable
ARTICLE 3
TRADE SECRETS
3.1 Trade Secret. Navini Networks, Inc. considers the licensed Software covered by this License
Agreement to be a trade secret. Navini Networks, Inc. does not disclose any information to
Navini Networks, Inc. competitors or potential competitors. Buyer shall not disclose any design,
code, or technological know-how gained by access to the Software to Licensor’s competitors.
Buyer shall not use design, code, or documentation gained by access to the Software to develop a
similar technology or a competing software product. To attempt to or to do so, the Parties
acknowledge, understand and agree, constitute a material breach of this License Agreement.
3.2 Third Party Intellectual Property. Buyer acknowledges, understands and agrees that the licensed
Software covered by this License Agreement may contain Intellectual Property owned by Third
Parties and duly licensed to Navini Networks, Inc. Copyright, Patent and other laws protect Third
Party Intellectual Property manufactured with, marketed with, or otherwise bundled with the
licensed Software. Buyer promises to keep such Third Party Intellectual Property in confidence
to the benefit of the Third Party, agrees not to reverse engineer or otherwise decompile Third
Party Intellectual Property, and agrees to stop using, destroy and/or return such Third Party
owned Intellectual Property under the same terms and conditions as the licensed Software as set
forth in this License Agreement.
Ripwave Modem User Guide Navini Networks, Inc.
050503_pv1.1_Ripwave Modem User Guide_
40-00097-00j(4.3)
62
ARTICLE 4
INDEMNIFICATIONS AND WARRANTY
4.1 Intellectual Property Indemnification; Entire Liability. ARTICLE 15 OF THE SUPPLY
AGREEMENT TO WHICH THIS AGREEMENT IS ATTACHED STATES THE ENTIRE
LIABILITY OF NAVINI NETWORKS, INC. WITH RESPECT TO INFRINGEMENT OF
COPYRIGHTS, TRADE SECRETS, TRADEMARKS, PATENTS, AND OTHER
INTELLECTUAL PROPERTY RIGHTS BY THE LICENSED SOFTWARE,
DOCUMENTATION, OR ANY PARTS THEREOF, AND NAVINI NETWORKS, INC.
SHALL HAVE NO ADDITIONAL LIABILITY WITH RESPECT TO ANY ALLEGED OR
PROVEN INFRINGEMENT.
4.2 Warranty. EXCEPT AS GRANTED IN THE BODY OF THE SUPPLY AGREEMENT TO
WHICH THIS LICENSE AGREEMENT IS ATTACHED, THE LICENSED SOFTWARE IS
PROVIDED BY NAVINI NETWORKS, INC. “AS IS” AND WITHOUT WARRANTY OF
ANY KIND OR NATURE, WRITTEN OR ORAL, EXPRESS OR IMPLIED, INCLUDING
(WITHOUT LIMITATION) THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. THIS LIMITATION OF WARRANTIES WAS A
MATERIAL FACTOR IN THE ESTABLISHMENT OF THE LICENSE FEE CHARGED FOR
EACH SPECIFIC ITEM OF SOFTWARE LICENSED.
ARTICLE 5
LIMITATION OF LIABILITY
5.1 Consequential Damages. TO THE MAXIMUM EXTENT PERMITTED BY THE APPLICABLE
LAW, IN NO EVENT SHALL NAVINI NETWORKS, INC. OR ANY THIRD PARTY
INVOLVED IN THE CREATION, PRODUCTION, DELIVERY, OR LICENSING OF THE
SOFTWARE BE LIABLE FOR ANY LOST REVENUES, PROFITS OR DATA OR OTHER
SPECIAL, INDIRECT, INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES,
HOWEVER CAUSED AND REGARDLESS OF THEORY OF LIABILITY, EVEN IF NAVINI
NETWORKS, INC. HAS, OR SHOULD HAVE HAD ANY KNOWLEDGE, ACTUAL OR
CONSTRUCTIVE, OF THE POSSIBILITY OF SUCH DAMAGES.
5.2 License-Fee Limitation. Except for the indemnification provisions of Article 15, Navini
Networks, Inc.’s maximum liability for damages is limited to the license fees paid by Buyer under
this Agreement for the particular licensed Software that caused the damages.
5.3 Loss of Data. Software error can cause a significant loss of data. Navini Networks, Inc. shall not
be responsible for any loss of data. Navini Networks, Inc.’s responsibility is to correct the
Software error as provided in this License Agreement or the Supply Agreement to which it is
attached. It is Licensee’s responsibility to have adequate backup procedures to protect Buyer
from significant loss of valid data.
Navini Networks, Inc. Ripwave Modem User Guide
050503_pv1.1_Ripwave Modem User Guide_
40-0097-00j(4.3)
63
ARTICLE 6
OBJECT CODE ONLY-NO MODIFICATIONS
6.1 Modifications. In order to maintain the “trade secret” status of the information contained in the
Licensed Software, Navini Networks, Inc. provides the Software in object-code form only. Buyer
shall not modify, enhance, adapt, disassemble, translate, decompile or otherwise decode any
portion of the object code of the Software module. Buyer shall not use the Software without a
license to the Software object code. The object code contains the license number, date of license,
and other license information. This information is placed in the object-code portions to prevent
unauthorized and unlicensed distributions of the Software. Buyer shall not subvert or change any
of this information. Further Buyer shall not make, full or partial, copies of any documentation
whether printed or machine- readable media supplied with the Licensed Software unless
expressly granted prior written permission by Navini Networks, Inc.
6.2 Responsibility for Damages. Buyer is subject to the provisions of the Supply Agreement with
respect to the Software (including Section 16). Buyer is fully liable and responsible for any
damages, indirect or direct, and costs that Navini Networks, Inc. may incur if Buyer appoints a
subcontractor who accesses the Software without Navini’s prior written consent. Buyer shall
defend, indemnify, and hold Navini Networks, Inc., its directors, officers, employees, agents,
Authorized Partners, and other representatives harmless accordingly for all costs and direct and
indirect damages sustained by Navini Networks, Inc. However, if the subcontractor is pre-
approved by Navini in writing for access to the Software, then this Section shall not apply.
6.3 Copyright Notices. Buyer shall not remove any copyright or proprietary rights notice or
identification that indicates Navini Networks, Inc. ownership from any part of the licensed
Software, it being expressly understood and agreed that the existence of such copyright notice
should not be construed as an admission or presumption that publication of the licensed Software
has occurred.
END OF AGREEMENT
Copyright © 2001-2005 Navini Networks, Inc.
All rights reserved. Printed in the USA.
Navini Networks is a registered trademark. Zero-Install, Ripwave, and Unwired by Navini are
trademarks of Navini Networks, Inc. Other product and company names mentioned herein may be
trademarks and/or service marks of their respective owners. Rev. 052302
