Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide
- contents
- Prefacevii
chapter 1
- Safety Warnings, Recommendations, and Tools Required1-1
chapter 2
- Dial Feature Card and Carrier Card Guidelines2-1
chapter 3
- T1 and E1 Dial Feature Cards3-1
chapter 4
- T3 Dial Feature Card4-1
chapter 5
- Universal Port Dial Feature Card5-1
chapter 6
- Troubleshooting6-1
appendix A
- Cabling SpecificationsA-1
index

Corporate Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 526-4100

Cisco AS5350 and Cisco AS5400

Universal Gateway Card

Installation Guide

Customer Order Number: DOC-7813311=

Text Part Number: 78-13311-01

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT

NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE

PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR

APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION

PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO

LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference, in which case users will be required to correct the interference at their own expense.

The following information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency

energy. If it is not installed in accordance with Cisco’s installation instructions, it may cause interference with radio and television reception. This

equipment has been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules.

These specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee

that interference will not occur in a particular installation.

Modifying the equipment without Cisco’s written authorization may result in the equipment no longer complying with FCC requirements for Class A or

Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any

interference to radio or television communications at your own expense.

You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Cisco equipment

or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more

of the following measures:

• Turn the television or radio antenna until the interference stops.

• Move the equipment to one side or the other of the television or radio.

• Move the equipment farther away from the television or radio.

• Plug the equipment into an outlet that is on a different circuit from the television or radio. (That is, make certain the equipment and the television or radio

are on circuits controlled by different circuit breakers or fuses.)

Modifications to this product not authorized by Cisco Systems, Inc. could void the FCC approval and negate your authority to operate the product.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED

“AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED,

INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND

NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL

DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR

INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

AccessPath, AtmDirector, Browse with Me, CCDE, CCIP, CCSI, CD-PAC, CiscoLink, the Cisco NetWorks logo, the Cisco Powered Network logo, Cisco

Systems Networking Academy, the Cisco Systems Networking Academy logo, Fast Step, Follow Me Browsing, FormShare, FrameShare, GigaStack, IGX,

Internet Quotient, IP/VC, iQ Breakthrough, iQ Expertise, iQ FastTrack, the iQ Logo, iQ Net Readiness Scorecard, MGX, the Networkers logo, Packet,

RateMUX, ScriptBuilder, ScriptShare, SlideCast, SMARTnet, TransPath, Unity, Voice LAN, Wavelength Router, and WebViewer are trademarks of Cisco

Systems, Inc.; Changing the Way We Work, Live, Play, and Learn, Discover All That’s Possible, and Empowering the Internet Generation, are service

marks of Cisco Systems, Inc.; and Aironet, ASIST, BPX, Catalyst, CCDA, CCDP, CCIE, CCNA, CCNP, Cisco, the Cisco Certified Internetwork Expert

logo, Cisco IOS, the Cisco IOS logo, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Enterprise/Solver, EtherChannel, EtherSwitch,

FastHub, FastSwitch, IOS, IP/TV, LightStream, MICA, Network Registrar, PIX, Post-Routing, Pre-Routing, Registrar, StrataView Plus, Stratm,

SwitchProbe, TeleRouter, and VCO are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries.

All other trademarks mentioned in this document or Web site are the property of their respective owners. The use of the word partner does not imply a

partnership relationship between Cisco and any other company. (0105R)

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

iii

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

CONTENTS

Preface vii

Document Organization vii

Document Conventions viii

Obtaining Documentation xi

World Wide Web xi

Documentation CD-ROM xi

Ordering Documentation xi

Documentation Feedback xi

Obtaining Technical Assistance xii

Cisco.com xii

Technical Assistance Center xii

Related Documentation

This guide describes how to install and connect the Cisco AS5350 and Cisco AS5400 dial feature cards.

You will also need the following publications to configure the dial feature cards:

•Refer to the Cisco AS5350 Universal Gateway Regulatory Compliance and Safety Information

document or the Cisco AS5400 Universal Gateway Regulatory Compliance and Safety Information

document to familiarize yourself with safety guidelines.

•Refer to the Cisco AS5350 Universal Gateway Chassis Installation Guide or the Cisco AS5400

Universal Gateway Chassis Installation Guide to install, replace, and troubleshoot cards and

modules.

•Refer to the Cisco AS5350 and Cisco AS5400 Universal Gateway Software Configuration Guide for

basic software configuration instructions.

•Refer to the Cisco IOS Release 12.2 software configuration guides and command reference

publications for more advanced configuration topics. These publications are available on the

Documentation CD-ROM that came with your universal gateway, on the World Wide Web from

Cisco’s home page, or you can order printed copies. See the “Obtaining Documentation” section on

page xi.

New Hardware Features

A description of new hardware features available after the release of this document can be found at the

following URLs:

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/as5350/index.htm

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/as5400/index.htm

xiv

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Preface

New Hardware Features

CHAPTER

1-1

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Safety Warnings, Recommendations, and Tools

Required

This chapter describes the safety warnings, recommendations, and tools required to install dial feature

cards in the chassis. This chapter contains the following sections:

•General Safety, page 1-1

•Maintaining Safety with Electricity, page 1-2

•Preventing Electrostatic Discharge, page 1-3

•Required Tools and Equipment, page 1-3

•Where to Go Next, page 1-4

General Safety

Any device that uses electricity must be handled carefully; follow these guidelines to ensure general

safety:

•Keep the chassis area clear and dust-free during and after installation.

•Put the removed chassis cover in a safe place.

•Keep tools away from walk areas where you and others could fall over them.

•Do not wear loose clothing that could get caught in the chassis. Fasten your tie or scarf and roll up

your sleeves.

•Wear safety glasses if you are working under any conditions that might be hazardous to your eyes.

•Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.

Warning

Ultimate disposal of this product should be handled according to all national laws and

regulations. To see translations of the warnings that appear in this publication, refer to the

Regulatory Compliance and Safety Information document that accompanied this device.

1-2

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 1 Safety Warnings, Recommendations, and Tools Required

Maintaining Safety with Electricity

Warning

Before working on equipment that is connected to power lines, remove jewelry (including rings,

necklaces, and watches). Metal objects will heat up when connected to power and ground and

can cause serious burns or can weld the metal object to the terminals. To see translations of the

warnings that appear in this publication, refer to the Regulatory Compliance and Safety

Information document that accompanied this device.

Follow these guidelines when you work on equipment powered by electricity.

•Locate the emergency power-OFF switch for the room in which you are working. Then, if an

electrical accident occurs, you can act quickly to turn OFF the power.

•Before working on the system, unplug the power cord.

•Disconnect all power before doing the following:

–

Installing or removing a dial feature card

–

Working near power supplies

Warning

When installing the unit, the ground connection must always be made first and disconnected last.

To see translations of the warnings that appear in this publication, refer to the Regulatory

Compliance and Safety Information document that accompanied this device.

•Do not work alone if potentially hazardous conditions exist.

•Never assume that power is disconnected from a circuit. Always check.

Warning

Read the installation instructions before you connect the system to its power source. To see

translations of the warnings that appear in this publication, refer to the Regulatory Compliance

and Safety Information document that accompanied this device.

•Look carefully for possible hazards in your work area, such as moist floors, ungrounded power

extension cables, frayed power cords, and missing safety ground connections.

•If an electrical accident occurs, proceed as follows:

–

Use caution; do not become a victim yourself.

–

Turn OFF power to the system.

–

If possible, send another person to get medical aid. Otherwise, assess the condition of the victim

and then call for help.

–

Determine if the person needs rescue breathing or external cardiac compressions; then take

appropriate action.

1-3

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 1 Safety Warnings, Recommendations, and Tools Required

Preventing Electrostatic Discharge

Warning

This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure

that a fuse or circuit breaker no larger than 120 VAC, 15A U.S. (240 VAC, 10A international) is used

on the phase conductors (all current-carrying conductors). To see translations of the warnings that

appear in this publication, refer to the Regulatory Compliance and Safety Information document

that accompanied this device.

Preventing Electrostatic Discharge

Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD damage occurs

when electronic components are improperly handled and can result in complete or intermittent failures.

Always follow ESD-prevention procedures when you remove and replace components. Ensure that the

chassis is electrically connected to earth ground. Wear an ESD-preventive wrist strap, ensuring that it

makes good skin contact. Connect the grounding clip to an unpainted surface of the chassis frame to

safely ground unwanted ESD voltages. To guard against ESD damage and shocks, the wrist strap and

cord must operate properly. If no wrist strap is available, ground yourself by touching the metal part of

the chassis.

For safety, periodically check the resistance value of the antistatic strap, which should be between 1 and

10 megohm (Mohm).

Required Tools and Equipment

The following items are included with the universal gateway:

•RJ-45-to-DB-9 female DTE adapter (labeled TERMINAL)

•RJ-45-to-DB-25 female DTE adapter (labeled TERMINAL)

•RJ-45-to-DB-25 male DCE adapter (labeled MODEM)

•RJ-45-to-RJ-45 rollover console cable

•ESD-preventive wrist strap

•Nylon cable tie

•Cable tie holder

•Grounding lug

•Alarm connector

You might need the following equipment, which is not included:

•Straight-through RJ-45-to-RJ-45 cable for an Ethernet connection

•Ethernet hub or PC with a network interface card for Ethernet LAN connections

•One breakout cable consisting of a 36-pin connector connected to eight RJ-45 adaptors for CT1/CE1

connections

•Straight through RJ-45-to-RJ-45 cable for CT1/CE1 connections

•75-ohm coaxial cable for a CT3 connection

•PC running terminal emulation software for local administrative access

•Modem for remote administrative access

1-4

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 1 Safety Warnings, Recommendations, and Tools Required

Where to Go Next

•ESD-preventive mat

•Blank filler panel

Where to Go Next

The remaining chapters of this guide include information on installing and troubleshooting DFCs and

creating cables.

•Chapter 2, “Dial Feature Card and Carrier Card Guidelines”

•Chapter 3, “T1 and E1 Dial Feature Cards”

•Chapter 4, “T3 Dial Feature Card”

•Chapter 5, “Universal Port Dial Feature Card”

•Chapter 6, “Troubleshooting”

•Appendix A, “Cabling Specifications”

CHAPTER

2-1

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Dial Feature Card and Carrier Card Guidelines

This chapter includes the following sections:

•Overview, page 2-1

•Online Insertion and Removal (OIR) of DFCs, page 2-2

•Removing and Installing Populated Carrier Cards, page 2-2

•Getting Help, page 2-7

•Where to Go Next, page 2-7

Overview

Cisco AS5350 Chassis

The Cisco AS5350 universal gateway chassis has a motherboard, high-speed backplane, and two

backplane slots. One backplane slot accepts one dial feature card (DFC) carrier card and the other

backplane slot accepts one DFC.

Cisco AS5400 Chassis

The Cisco AS5400 universal gateway chassis has a motherboard, high-speed backplane, and four

backplane slots. Three backplane slots accept DFC carrier cards and the other backplane slot accepts one

DFC.

Dial Feature Cards

Each DFC carrier card accepts two DFCs which allow online insertion and removal (OIR). (See

Figure 2-1.)

Each DFC is a 5.1 x 13 inch PCI based interface board. The following is a brief description of the trunk

types supported:

•North American robbed-bit signaling (RBS) is supported on T1 trunks, including a variety of North

American RBS protocol, framing, and encoding types on these trunks.

•CAS is supported for E1 trunks, with R2 signaling.

•Many countries require an E1 R2 variant. Per-country defaults are provided for supervisory and

inter-register signaling.

•The CT3 DFC provides physical line termination for a channelized T3 ingress trunk line, and it uses

an onboard multiplexer to multiplex 28 channelized T1 lines into a single channelized T3 line.

2-2

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Online Insertion and Removal (OIR) of DFCs

•Universal access (analog modem or digital calls) is supported when an interface is configured for

ISDN PRI signaling. PRI signaling is available for both T1 and E1 trunks.

In any single DFC slot, you can install your choice of:

•One T1, E1, or T3 dial feature card

•One universal port card

Online Insertion and Removal (OIR) of DFCs

All DFCs on the Cisco AS5350 and Cisco AS5400 chassis support online insertion and removal (also

known as hot swapping). You can install, remove, replace, and rearrange the DFCs without turning off

the chassis power.

When the chassis detects that a DFC is installed or removed, it automatically runs diagnostic and

discovery routines, acknowledges the presence or absence of the DFC, and resumes chassis operation

without any operator intervention.

See:

•Chapter 3, “T1 and E1 Dial Feature Cards,” to perform OIR of the T1 or E1 DFC.

•Chapter 4, “T3 Dial Feature Card,” to perform OIR of the T3 DFC.

•Chapter 5, “Universal Port Dial Feature Card,” to perform OIR of the universal port DFC.

Removing and Installing Populated Carrier Cards

Caution The carrier cards that carry the DFCs are not hot swappable. Removing a card while the system is

still powered on may cause permanent damage to electronic circuits on the card.

The DFC carrier card plugs into one of the backplane slots and supports two DFCs. The carrier card

increases backplane capacity and allows OIR of the DFCs. (See Figure 2-1.)

Figure 2-1 Carrier Card With Two 8 PRI CT1 Cards

Warning

Before working on a chassis or working near power supplies, unplug the power cord on AC units;

disconnect the power at the circuit breaker on DC units. To see translations of the warnings that

appear in this publication, refer to the Regulatory Compliance and Safety Information document

that accompanied this device.

29032

2-3

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Removing and Installing Populated Carrier Cards

Warning

Before performing any of the following procedures, ensure that power is removed from the DC

circuit. To ensure that all power is OFF, locate the circuit breaker on the panel board that services

the DC circuit, switch the circuit breaker to the OFF position, and tape the switch handle of the

circuit breaker in the OFF position. To see translations of the warnings that appear in this

publication, refer to the Regulatory Compliance and Safety Information document that

accompanied this device.

Caution Before you remove a carrier card, read Chapter 1, “Safety Warnings, Recommendations, and Tools

Required”

Removing a Populated Carrier Card

Warning

Before opening the chassis, disconnect the telephone-network cables to avoid contact with

telephone-network voltages. To see translations of the warnings that appear in this publication,

refer to the Regulatory Compliance and Safety Information document that accompanied this

device.

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity. To

see translations of the warnings that appear in this publication, refer to the Regulatory

Compliance and Safety Information document that accompanied this device.

To remove a populated carrier card, follow the steps below:

Step 1 Power off the chassis.

Step 2 Disconnect all interface cables from the universal gateway and secure them out of the way.

Step 3 Loosen the two captive screws that secure the carrier card to the chassis until each screw is free of the

chassis. (See Figure 2-2 and Figure 2-3.)

Figure 2-2 Loosen the Captive Screws on the Cisco AS5350

36002

Carrier card

DFC

Captive screw

Chassis

2-4

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Removing and Installing Populated Carrier Cards

Figure 2-3 Loosen the Captive Screws on the Cisco AS5400

Step 4 Grasp the DFC handles and gently pull toward you to guide the carrier card out of the slot. Place one

hand under the carrier card as you pull it out of the chassis. (See Figure 2-4 and Figure 2-5.)

Note Use the DFC handles to remove the carrier card. Ensure that the DFCs are secured to the

carrier card.

Figure 2-4 Removing the Carrier Card from the Cisco AS5350

Figure 2-5 Removing the Carrier Card from the Cisco AS5400

Step 5 After you remove the carrier card from the chassis, set it aside on an ESD-preventive mat.

37159

Carrier

card

DFC DFC

Captive

screw Captive

screw

Chassis

36003

37160

2-5

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Removing and Installing Populated Carrier Cards

Step 6 If the backplane slot is to remain empty, install a blank cover over the open slot to ensure proper airflow

inside the chassis. (See Figure 2-6.)

Figure 2-6 Blank Filler Panel

Installing a Populated Carrier Card

To install a populated carrier card:

Step 1 Slide the carrier card into the slot until it touches the backplane connector. (See Figure 2-7 and

Figure 2-8.)

Figure 2-7 Install the Carrier Card in the Cisco AS5350

Figure 2-8 Install the Carrier Card in the Cisco AS5400

Step 2 Align the captive screws with their holes, and seat the card completely.

36033

36004

37161

2-6

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Removing and Installing Populated Carrier Cards

Step 3 Tighten the two captive screws to secure the carrier card to the chassis. (See Figure 2-9 and Figure 2-10.)

Figure 2-9 Tighten the Captive Screws on the Cisco AS5350

Figure 2-10 Tighten the Captive Screws on the Cisco AS5400

Step 4 If the carrier card has a blank DFC slot, install a blank cover over the open DFC slot to ensure proper

airflow inside the chassis. (See Figure 2-11.)

Figure 2-11 Blank DFC Cover

Step 5 For AC powered units, reconnect the AC power cord. For DC powered units, remove the tape from the

circuit breaker switch handle, and reinstate power by moving the handle of the circuit breaker to the ON

position. For more information on the AC and DC power supplies, refer to the chassis installation guide

that came with your universal gateway.

Step 6 Reconnect all interface cables.

36005

Captive screw

37162

Captive

screw Captive

screw

36033

2-7

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Getting Help

For information about technical support, onsite service, and exchange and repair services, refer to the

“Obtaining Technical Assistance” section on page -xii in the “Preface.”

Where to Go Next

For instructions on installing and removing dial feature cards, refer to:

•Chapter 3, “T1 and E1 Dial Feature Cards.”

•Chapter 4, “T3 Dial Feature Card.”

•Chapter 5, “Universal Port Dial Feature Card.”

•Chapter 6, “Troubleshooting.”

•Appendix A, “Cabling Specifications.”

2-8

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 2 Dial Feature Card and Carrier Card Guidelines

Where to Go Next

CHAPTER

3-1

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

T1 and E1 Dial Feature Cards

This chapter describes the installation and removal procedures for the T1 and E1 dial feature cards

(DFC) and includes the following sections:

•Overview, page 3-1

•Online Installation and Removal of the T1 or E1 DFC, page 3-3

•Configuring Input Impedance for the E1 DFC, page 3-11

•Getting Help, page 3-14

•Where to Go Next, page 3-14

Overview

You can install a T1 or E1 dial feature card in any dial feature card slot of the universal gateway chassis.

(See Figure 3-1 through Figure 3-3.)

Each T1 or E1 DFC provides physical line termination for multiple DS-0 channels and uses onboard

HDLC controllers to terminate digital (ISDN) calls. For network specifications see Table 3-1 and

Table 3-2. You can use the bantam ports on the DFC to monitor a line.

Note The Cisco AS5350 and Cisco AS5400 support only one type of WAN DFC at a time. Refer

to Chapter 6, “Troubleshooting” for more information.

Figure 3-1 2-Port T1 or E1 DFC

35840

T1 or E1 ports

Bantam ports

0Rx

ACT

2 PRI

3-2

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 3 T1 and E1 Dial Feature Cards

Overview

Figure 3-2 4-Port T1 or E1 DFC

Figure 3-3 8-Port T1 or E1 DFC

56023

T1 or E1 ports

Bantam ports

0Rx

ACT

4 PRI

OK/

MAINT

123

Table 3-1 T1 DFC Network Specifications

Description Specification

Line rate 1.544 Mbps

Data rates (per port) number x 56 or number x 64 kbps, where

number = 1 to 24

Standards AT&T Pub. 62411, 54016, and 43081,

and ANSI T1.403

Input impedance 100 ohms per port

Table 3-2 E1 DFC Network Specifications

Description Specification

Line rate 2.048 Mbps

Data rate (per port) number x 56 or number x 64 kbps, where number = 1 to 31.

Input impedance 75 or 120 ohms per port

Note The factory default setting for the E1 ports is 120 ohm. Use a software

command to change the impedance. Refer to the, Cisco AS5350 and

Cisco AS5400 Universal Gateway Card Installation Guide.

29030

3-3

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 3 T1 and E1 Dial Feature Cards

Online Installation and Removal of the T1 or E1 DFC

Overview

To remove a DFC without dropping any calls or connections, you will need to take the DFC out of service

by using the busyout command to disable the DFC. The busyout command is executed on a per DFC

basis and will gracefully disable the card by waiting for the active services to terminate.

If you have active calls on the DFC after executing the busyout command, wait for the calls to drop. Use

the show busyout command to view the status of the termination process.

Caution The online installation and removal (OIR) of new cards should be done ONLY during times of low

CPU utilization, such as during maintenance.

Caution To avoid erroneous failure messages, remove or insert only one DFC at a time.

When you replace a DFC with a new DFC of the same type in the same slot, the system software will

recognize the new trunk interfaces and bring them up automatically.

If you replace the existing DFC with a new DFC of a different type, you will have to reconfigure the

system. For configuration details, refer to the Cisco AS5350 and Cisco AS5400 Universal Gateway

Software Configuration Guide.

Removing the T1 or E1 DFC

To remove the T1 or E1 DFC, follow these steps:

Note Following these steps are examples of the output from each command.

Step 1 Determine which slot the DFC is in by entering the show chassis command in privileged EXEC mode:

Router# show chassis slot

Figure 3-4 Slot Numbering on the Cisco AS5350 Chassis

36006

Slot 2 Slot 0 Slot 1 Slot 3

3-4

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 3 T1 and E1 Dial Feature Cards

Online Installation and Removal of the T1 or E1 DFC

Figure 3-5 Slot Numbering on the Cisco AS5400 Chassis

Step 2 Initialize the software busyout procedure by entering the busyout command:

Router# busyout slot-number

Step 3 Enter the show busyout command to check busyout status for that specific slot:

Router# show busyout slot-number

Step 4 You may use the clear port command to immediately disable active calls on the universal port card

(UPC). For more information on the UPC, see Chapter 5, “Universal Port Dial Feature Card”. Use the

show controller command to show the universal port card associated with the T1 or E1 DFC.

Router# show controller t1/e1 slot-number/control-number timeslot timeslot-number

Router# clear port slot-number/port number

Note The clear port command only applies to the universal port DFC.

Step 5 Verify that the OIR/MAINT LED is off; this indicates that the DFC is offline and ready to be removed.

Note The OK/MAINT LED is green before you enter the busyout command. After you enter the

busyout command, the LED changes to yellow. The LED turns off after all calls are

disconnected and resources are taken out of service, indicating that busyout is complete.

Step 6 Attach an ESD-preventive wrist strap.

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity. To

see translations of the warnings that appear in this publication, refer to the Regulatory

Compliance and Safety Information document that accompanied this device.

Step 7 Disconnect all interface cables from the DFC and secure them out of the way.

34977

Slot 1Slot 0

Slot 2

Slot 4

Slot 6

Slot 3

Slot 5

Slot 7

3-5

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 3 T1 and E1 Dial Feature Cards

Online Installation and Removal of the T1 or E1 DFC

Step 8 Loosen the two captive screws that secure the DFC to the chassis until each screw is free of the chassis.

(See Figure 3-6 and Figure 3-7.)

Figure 3-6 Loosen the Captive Screws on the Cisco AS5350

Figure 3-7 Loosen the Captive Screws on the Cisco AS5400

Step 9 Grasp the DFC handle with one hand and pull the card toward you until the card slides free of the chassis.

Grasp the ventilated metal cover with your other hand to support and guide the DFC out of the slot. (See

Figure 3-8 and Figure 3-9.)

Caution Avoid touching any pins or circuit board components during removal and installation of a DFC.

36814

0RxACT

2 PRI

Carrier

card

DFC

Captive

screw

Captive

screw

Chassis

37163

Captive

screw Captive

screw

3-6

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 3 T1 and E1 Dial Feature Cards

Online Installation and Removal of the T1 or E1 DFC

Figure 3-8 Remove the DFC from the Cisco AS5350

Figure 3-9 Remove the DFC from the Cisco AS5400

Step 10 After you remove the DFC from the chassis, set it aside on an ESD-preventive mat.

Step 11 If the DFC slot is to remain empty, install a blank cover over the open DFC slot to ensure proper airflow

inside the chassis. (See Figure 3-10.)

Figure 3-10 Blank DFC Cover

The following output is an example of online insertion and removal of a E1 DFC in slot 6 of the

Cisco AS5400:

Router# show chassis slot 6

Slot 6:

DFC type is E1 8 PRI DFC

OIR events:

Number of insertions = 0, Number of removals = 0

DFC State is DFC_S_OPERATIONAL

Router#

Router# busyout 6

Busyout in progress for 6

Router# show busyout 6

Busyout status for trunk DFC slot = 6:

DFC slot busyout is in progress

(p - pending, s - static(cfg/exec), d - dynamic, n - none)

6/0 :s s p p p p p p p p p p p p p n p p p p p p p p p p p p p p p

36815

0Rx

ACT

2 PRI

37164

36033

3-7

Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide

78-13311-01

Chapter 3 T1 and E1 Dial Feature Cards

Online Installation and Removal of the T1 or E1 DFC

6/1 :s s s p p p p p p p p p p p p n p p p p p p p p p p p p p p p

6/2 :s s s p p p p p p p p p p p p n p p p p p p p p p p p p p p p

6/3 :s s s s p p p p p p p p p p p n p p p p p p p p p p p p p p p

6/4 :s s s p p p p p p p p p p p p n p p p p p p p p p p p p p p p

6/5 :s s s p p p p p p p p p p p p n p p p p p p p p p p p p p p p

6/6 :s s s p p p p p p p p p p p p n p p p p p p p p p p p p p p p

6/7 :s s p p p p p p p p p p p p p n p p p p p p p p p p p p p p p

Router#

Router# show controller e1 6/0 timeslot 1-31

E1 6/0 is up:

DS0 Type Modem Status rxA rxB rxC rxD txA txB txC txD

1 pri - idle

2 pri - idle

3 pri-modem 1/70 active

4 pri-modem 1/46 active

5 pri-modem 1/22 active

6 pri-modem 4/61 active

7 pri-modem 4/53 active

8 pri-modem 4/45 active

9 pri-modem 4/37 active

10 pri-modem 4/29 active

11 pri-modem 4/21 active

12 pri-modem 4/13 active

13 pri-modem 4/05 active

14 pri-modem 2/105 active

15 pri-modem 2/97 active

16 pri-D channel - -

17 pri-modem 2/89 active

18 pri-modem 2/81 active

19 pri-modem 2/73 active

20 pri-modem 2/65 active

21 pri-modem 2/57 active

22 pri-modem 2/49 active

23 pri-modem 2/41 active

24 pri-modem 2/33 active

25 pri-modem 2/25 active

26 pri-modem 2/17 active

27 pri-modem 2/09 active

28 pri-modem 2/01 active

29 pri-modem 1/107 active

30 pri-modem 1/99 active

31 pri-modem 1/91 active
