Z-START

GUIDE

This guide gives you specific

information for the CLP 521Z and

CLP 621Z printers from Citizen that is

not contained in the other user manuals

and documents.

Thermal Label & Barcode Printer

CLP-521Z

CLP-621Z

Using An Existing Driver

To use an existing driver previously installed on your system, you will still need to install

the printer following the procedure shown in section 3. After installation, you can then

modify the existing printer driver to use the new Citizen printer instead.

Go to the “PrintPrint

PrintPrint

Printerer

erer

ers and Fs and F

s and Fs and F

s and Faxax

axax

axee

ee

ess

ss

s” menu from the “Start > Settings” button. RIGHTRIGHT

RIGHTRIGHT

RIGHT-click on

the original printer driver to be changed and then click on the properties option.

Click on the “Ports” tab and you will see a screen similar to the one shown here. The

current “port” for the printer will be

highlighted, e.g. “USB001”.

You must find the port that is already

allocated to the nene

nene

new Citizen Z printw Citizen Z print

w Citizen Z printw Citizen Z print

w Citizen Z printerer

erer

er

that has just been installed. This may

also be a USB port, but it will have a

different number.

Click on the tick-box to select it and

then click on OK and the original

printer is now configured to print to

the new one.

*For further information and more detailed instructionsplease contact our local office:

For Europe, Middle East and Africa For North and South America:

Citizen SCitizen S

Citizen SCitizen S

Citizen Syy

yy

ystst

stst

stems Eurems Eur

ems Eurems Eur

ems Europeope

opeope

ope Citizen SCitizen S

Citizen SCitizen S

Citizen Syy

yy

ystst

stst

stems Americaems America

ems Americaems America

ems America

wwwwww

wwwwww

www.citizen-eur.citizen-eur

.citizen-eur.citizen-eur

.citizen-europe.comope.com

ope.comope.com

ope.com wwwwww

wwwwww

www.citizen-s.citizen-s

.citizen-s.citizen-s

.citizen-syy

yy

ystst

stst

stems.comems.com

ems.comems.com

ems.com

Tel UK: +44 (0) 20 8893 1900 Torrance, California.

Tel Germany: +49 (0) 711 3906 420 Tel: +1 310 781 1460

Printed in Europe JM74915-Z0

For Further Information . . .

4

What does the “Z” mean?

Label printers talk a variety of different languages! Our printers

usually use their own Citizen language but we have created a

version that specifically understand the ZPL® language from

Zebra®.

So your CLP 521Z or CLP 621Z printer understands this ZPL®

language instead of the normal Citizen language.

How does this affect me?

In normal operation, you will notice no difference in operation of

your printer. It will still print labels in the same way and media

and ribbons are loaded in exactly the same way to a normal printer.

Please refer to the other quick-start guides for details of media

loading and operation of the printer.

However, the configuration and setup of some of the printer’s

internal settings will be a little different. This may not affect you

either if your printer can be used in an ‘out of the box’

configuration.

What does this guide say?

This guide explains the differences in the printer’s configuration

system and also explains the best printer driver to use with

different applications including the Windows® operating systems

Windows® is a registered trademark of Microsoft Corporation in the United States

and/or other countries. ZPL® and Zebra® are registered trademarks of Zebra

Technologies (ZIH Corp) in the United States and/or other countries.

1

Introduction

How to Use VuePrintTM

The VuePrint menu system is used to make changes to the settings of

the printer. Please refer to the Quick Start Guide for more details on

its operation. You can access the VuePrint system by switching on

the printer holding down the [MODE] key.

Machine Information

This section of the print out will give you details specific to your

printer, such as the version of firmware, total distance printed by your

printer and the media sensor or optional interfaces.

Current Menu Settings

The “Page Setup”, “After Print” and “Interface” menus are exactly the

same on these printers. However, the System Setup menu has some

different parameters.

- The Metric/Inch option is only used to change the display in the

VuePrint menu output and has no effect on printer operation and

layout

- The Control Prefix, Format Prefix and Delimiter Prefix are all

changeable in these printers. This changes the ‘command codes’

that the printer recognizes as actions for the printer. You will

only need to change this for specific customer applications.

- The “Media Power Up” option (either On or Off) determines

whether or not the printer feeds the paper to the top-of-form

(start of a new label) when the printer is turned on. This is “on”

by default but you may choose to switch this off for certain

applications.

- The “Control Code” and “Emulation Select” menu options are

not present or needed on the CLP 521Z or 621Z printers.

2

Using VuePrintTM Configuration System

Z-START

GUIDE
