Clam Corporation, Inc. Manual – 102181

Model No.

- 8309 -

Specifications

Set-Up

ŀHeight: 60 inches

ŀLength: 72 inches

ŀWidth: 48 inches

Collapsed

ŀHeight: 6 inches

ŀLength: 36 inches

ŀWidth: 48 inches

ŀWeight: 45lbs

- Clam Customer Service Information -

NOTICE!! Once used, this shelter cannot be returned to the store. If you have a

Warranty Claim, please contact Clam Corporation Customer Service by email

inquiry or direct by calling:

ŀCustomer Service Hrs: - 8am to 4pm, Mon. - Fri. Central Standard Time

ŀClam Corporation, Inc.

600 Clydesdale Trail

Medina, MN 55340

ŀPhone - 763-231-4120

ŀFax - 763-231-4121

ŀWebsite – www.clamcorp.com

ŀEmail – www.customerservice@clamcorp.com

2

- Set-Up Instructions -

ŀUnfold the unit and unzip the doors at both ends. Locate and remove the folded Flexible Rods

and Latch Clips from the unit.

ŀThrough the doorway of one end, grasp the center of the nearest Hoop Tube and pivot it

upwards towards you into a vertical position. Next pull the same Hoop Tube straight up, sliding

it until the holes near the ends are engaged by the Spring Buttons of the Canopy Poles. Lay the

erected Hoop Tube down onto the unit.

ŀGo around to the opposite doorway and erect the other Hoop Tube in the same fashion. Lay both

erected Hoop Tubes against one another.

102190 Tent (not shown)

101682 Flexible Rod

102191 Hoop Tube

101168 Latch Clip

101152 Canopy Pole

Spring Button

101150 Hole Cover

101116 Molding

3

- Set-Up Instructions (cont.)-

ŀFrom outside the unit, unfold the Flexible

Rods into a straightened position.

ŀThrough either doorway, reach into the Tent

and find a Rod Pocket located on either

corner of the Hoop Tube coming from the

opposite side of the unit. Going through the

doorway, slide one end of a Flexible Rod into

this Rod Pocket, using the Flexible Rod to

push the Hoop Tube into its vertical position.

Use one hand to hold it steady and the other

to rotate the other Hoop Tube into its vertical

position, before inserting the other end of the

Flexible Rod into its corner Rod Pocket

located diagonally across the unit. With the

Flexible Rod now bowed downward, secure

the center to the Velcro located in the center

Roof Panel of the Tent.

ŀLocate the other Flexible Rod and insert its

ends into the remaining Rod Pockets, then

resecure the Roof Panel Velcro to include this

Flexible Rod also.

ŀAt the crossing location of the Flexible Rods,

use your fingers to push the Rods upwards,

reversing the bow direction and tightening the

surrounding Tent.

FETY INSTRUCTIONS

- Take-Down Instructions -

ŀRemove the Flexible Rods, fold them up, and

place them both onto the same floor half.

ŀOne Hoop Tube at a time, use your fingers to

disengage the Spring Buttons and collapse

each Hoop Tube before rotating them down

onto their respective floors.

ŀGo around the unit and gather the Tent

material onto the floor, so that when folded,

all will be protected between folded floors.

ŀFold the empty floor half onto the floor half

containing the folded Flexible Rods. Use the

provided Latch Clips to secure the unit

together by placing them on the outside

edges. The Eyelets of the Latch Clips may be

used as an anchor point for roping down gear

on top of the unit while pulling to your fishing

destination.

Notice!! - The Tow Rope of this unit is intended for walking use only. Any damage incurred

from pulling behind a motorized vehicle is not covered under warranty.

Flexible Rod

Rod Pocket

4

- Safety Instructions -

Please fully understand and follow all safety instructions as outlined. Failure to do so could

result in severe injury or death.

ŀDo not use open flame heaters in your ice shelter. Injury or death may result from fire if tent

fabric is exposed to open flame. The tent is not fireproof, but the fabric is treated with a fire

retardant that meets CPAI-84 specifications. Application of any foreign substance may render

the flame retardant properties ineffective. Ice Armor fabric will melt when contact is made with

hot surfaces (i.e., heaters).

ŀDeath from asphyxiation may result from use of oxygen depleting heaters. Open all vents for

fresh air ventilation.

ŀNever leave shelter unattended when set up.

ŀDue to the increase in traffic (snowmobiles, autos, etc.) on area lakes, ice fishing can be

hazardous at night. If you choose to fish at night or in poor visibility conditions, be sure to take

precautions with lights or reflectors to show drivers your whereabouts. Night time: exterior

reflectors must be visible to reduce risk of collisions.

- Warranty -

Clam Corporation, Inc. warrants to the original retail purchaser that all Clams are free from

manufacturer’s defects for one (1) year from the date of original purchase. Warranty does not cover

cracked windows, tent tears, broken or bent hoops due to high wind weather conditions or

unattended use. Clam Corporation will replace or repair any part found defective within the one (1)

year time limit. All parts must be returned to Clam Corporation, Inc. Before returning any parts, you

must first call or write and acquire a return authorization. All returns must be returned postage-

prepaid and include the original cash register receipt (date and purchase price).

- Limitation of Liability -

It is expressly understood that Clam Corporation’s liability for its products, whether due to breach

of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated

above. Clam Corporation is not liable for any injury, loss, damage, or expense, whether direct or

consequential, including but not limited to loss of use, income, profit, or damage to material arising

in connection with the sale, installation, use of, inability to use, or the repair or replacement of

Clam Corporation products. Clam Corporation reserves the right to make alterations or

modifications in its products at any time, which in its opinion, may improve the performance and

efficiency of the product. It shall not be obligated to make such alterations or modifications to

products already in service.
