Users Manual
User’s Guide
TWO-WAY RADIO MODEL
CXT135
NOTE This device complies with part 15 of the FCC Rules.
Operation is subject to the following two (2) conditions: (1) This
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
FCC Warnings: Replacement or substitution of transistors,
regular diodes or other parts of a unique nature, with parts other
than those recommended by Cobra may cause a violation of the
technical regulations of part 95 of the FCC rules, or violation of
type acceptance requirements of part 2 of the rules.
Making Life Easier
And Safer
Staying in touch with your family and
friends is convenient and easy when using
your microTALK® radio. Some of the many
uses you will discover include:
Communicating with others while hiking, biking,
and working; keeping track of family and friends
at a crowded public event; checking with travel companions
in another car; talking with neighbors; arranging meeting
spots with others while
shopping at the mall.
Customer Assistance
In this user’s guide, you should find all the information you need to operate your microTALK® radio. If you require
further assistance after reading this guide, Cobra Electronics offers the following customer assistance services:
For Assistance In The U.S.A.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators English and Spanish.
8:00 a.m. to 5:30 p.m. Central Time, Monday through
Friday (except holidays) 773-889-3087 (phone).
Questions English and Spanish.
Faxes can be received at 773-622-2269 (fax).
Up/Down Buttons
While in mode function, press
and release to change channels.
Press and release to adjust
the volume.
Call Button
Press and release to alert others that
you are calling. This tone is used only
to establish voice communications.
Printed in China Part No. 480-737-P Version A
Battery
Compartment
Cover
Belt Clip
Antenna
Talk Button
Press and hold to communicate with
others. With the microphone about two
(2) inches [five (5) cm] from your mouth,
speak in a normal voice.
Release the Talk button when you are
finished talking and listen for a response.
You cannot receive incoming calls while
pressing the Talk button.
NOTE Both radios must be
tuned to the same channel
to communicate.
IMPORTANT NOTICE: FCC LICENSE REQUIRED
This two-way radio operates on GMRS (General Mobile Radio Service) frequencies
which require an FCC (Federal Communications Commission) license. A user must be
licensed prior to operating on Channels 1 through 7 or 15 through 22, which comprise the
GMRS channels of this radio. which comprise the GMRS channels of this radio. Serious
penalties could result for unlicensed use of GMRS channels, in violation of FCC rules.
Operation of this radio is subject to additional rules specified in 47 C.F.R. Part 95.
Licensed users will be issued a call sign by the FCC, which should be used for
station identification when operating this radio. GMRS users should also cooperate
by engaging in permissible transmissions only, avoiding channel interference with other
GMRS users, and being prudent with the length of their transmission time.
For licensing information and application forms, please call the FCC Hotline at
800-418-FORM. Request form #159 and form #605. Questions regarding the
license application should be directed to the FCC at 888-CALL-FCC. Additional information is
available on the FCC’s website at www.fcc.gov.
Safety Information For microTALK® Radios
Your wireless handheld portable transceiver contains a low power transmitter.
When the Talk button is pushed, it sends out radio frequency (RF) signals.
The device is authorized to operate at a duty factor not to exceed 50%.
In August 1996, the Federal Communications Commissions (FCC) adopted
RF exposure guidelines with safety levels for handheld wireless devices.
Important:
FCC RF Exposure Requirements: For body-worn operation, this radio has
been tested and meets the FCC RF exposure guidelines when used with Cobra accessories
supplied or designated for this product. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines. Use only the
supplied antenna. Unauthorized antennas, modifications, or attachments
could damage the transmitter and may violate FCC regulations.
Normal Position:
Hold the transmitter approximately two (2) inches from your face and
speak in a normal voice, with the antenna pointed up and away.
Product Service Questions
If you have any questions about operation or installing your new Cobra product,
or if you are missing parts…
Please call Cobra first! DO NOT RETURN THIS PRODUCT TO THE STORE!
See customer assistance above.
For Products Purchased In The U.S.A.
If your product should require factory service, please call Cobra first before
sending your radio, charger or battery pack(s). This will ensure the fastest turn-
around time on your repair. You may be asked to send your products to the Cobra factory. It
will be necessary to furnish the following to have the product serviced
and returned. 1) For warranty repair include some form of proof-of-purchase,
such as a mechanical reproduction or carbon of a sales receipt. If you send the
original receipt, it cannot be returned. 2) Send the entire product. 3) Enclose
a description of what is happening with the product. Include a typed or clearly
printed name and address of where the product is to be returned. 4) Pack product securely
to prevent damage in transit. If possible, use the original packing material.
5) Ship prepaid and insured by way of a traceable carrier such as United Parcel
Service (UPS) or First Class Mail to avoid loss in transit to:
Cobra Factory Service
Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 U.S.A.
6) If the product is in warranty, upon receipt of your product it will either be
repaired or exchanged depending on the model.
Please allow approximately three (3) to four (4) weeks before contacting Cobra
for status. If the product is out of warranty, a letter will automatically be sent
informing you of the repair charge or replacement charge. If you have any
questions, please call 773-889-3087 for assistance.
For Products Purchased Outside The U.S.A.
Please contact your local dealer for product service information.
Limited 1-Year Warranty On Radio(s)
For Products Purchased In The U.S.A.
Cobra Electronics Corporation warrants that its Cobra GMRS radio(s), and the component parts
thereof, will be free of defects in workmanship and materials for a period of one year from
the date of first consumer purchase. This warranty may be enforced by the first consumer
purchaser, provided that the product is utilized within the U.S.A.
Cobra will, without charge, repair or replace, at its option, defective GMRS radio(s),
products or component parts upon delivery to the Cobra Factory Service department,
accompanied by proof of the date of first consumer purchase, such as a duplicated copy
of a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service,
but the return charges will be at Cobra’s expense, if the product is repaired or replaced
under warranty. This warranty gives you specific legal rights, and you may also have other
rights which may vary from state to state.
Exclusions: This limited warranty does not apply:
1) To any product damaged by accident; 2) In the event of misuse or abuse of the product or
as a result of unauthorized alterations or repairs; 3) If the serial number has been altered,
defaced, or removed; 4) If the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a particular
purpose are limited in duration to the length of this warranty. Cobra shall not be liable for any
incidental, consequential or other damages; including, without limitation, damages resulting
from loss of use or cost of installation.
Some states do not allow limitations on how long an implied warranty lasts and/or
do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitations may not apply to you.
For Products Purchased Outside The U.S.A.
Please contact your local dealer for warranty information.
LCD
Display
Maximum range may vary and is based on unobstructed
line-of-sight communication under ideal conditions.
Installing Batteries
To Install or Replace Batteries:
1. Remove belt clip by releasing belt clip
latch and sliding clip up.
2. Pull up on the battery door latch to remove the
battery compartment cover.
3. Insert three (3) AAA batteries. Position
batteries according to polarity markings.
4. Replace battery compartment cover
and belt clip.
Insert Batteries
Pull Latch Up
Remove Belt Clip
Trademark Acknowledgement
Cobra®, microTALK®, Nothing Comes Close to a Cobra® and the snake design are registered
trademarks of Cobra Electronics Corporation, U.S.A. Cobra Electronics Corporation™ is a
trademark of Cobra Electronics Corporation, U.S.A.
The Cobra® line of quality products includes:
CB Radios • microTALK® Radios • Radar/Laser Detectors • Safety Alert® Traffic Warning Systems •
HighGear® Accessories • CobraMarine® VHF Radios • Power Inverters • Trucker Nav Systems •
LED Lights • Jumpstarters Accessories
Combination
Speaker/
Microphone
Charge Jack
WR
TX
Channel Numbers
While in Standby mode or when selecting
a channel, shows current channel (1 through 22).
When adjusting the volume,
shows current level (1 through 8).
Battery Low Icon
Blinks when battery power level is low.
Your microTALK® radio has a unique circuit
designed to extend battery life. If there are no
transmissions within ten (10) seconds, the radio
will automatically switch to Battery Save mode.
This will not affect the radio’s ability to receive
incoming transmissions.
Receive Icon
Visible when receiving
a message.
Transmit Icon
Visible when transmitting
a message.
Channel/Volume
Indicator
Visible when receiving
a message.
“ CH” is visible when in
Standby mode or when
selecting a channel.
“ LE” is visible when
adjusting volume.
Technical Assistance
English only. www.cobra.com
(on-line: Frequently Asked Questions).
English and Spanish. productinfo@cobra.com
(e-mail).
For Assistance Outside The U.S.A.
Contact Your Local Dealer
Weather Icon
Visible when in NOAA Weather radio
mode. You can use your microTALK®
radio to listen to NOAA All Hazards
Radio channels transmitting in your area.
Mode/Power Button
Press and release to enter
mode function to change
channels.
The channel numbers will blink
when that mode is selected. Use
the Up/ Down buttons to select
a channel.
Press and hold to turn the
radio On or Off.
Press and release again
to enter the NOAA Weather
Channels.
Use the Up/Down buttons to
select the strongest weather
channel in your area.
