Cobra Electronics DSP9200 Radar Detector with Bluetooth User Manual
Cobra Electronics Corporation Radar Detector with Bluetooth
User Manual
Frequency Display Mode Advanced
This is a new advanced and very useful mode. A graph is shown
with the detected radar frequency and where it falls in relation to
the center frequency of the closest radar gun. The closer the signal
strength bar is to the center of the display the more likely it’s a high
priority real alert.
Laser Alert Screens
With Laser signals, you will always receive full alert. The word
LASER will be shown on the display. The color of the word LASER
indicates the iRadar threat area level. When connected to the
Cobra iRadar app, the LaserRelay™ feature will be activated. Laser
alerts will be simultaneously relayed to other users of a detector
with iRadar functionality.
Frequency Display Mode On
This is a more advanced mode. The exact frequency of the
detected radar signal will also be shown.
Dual Lock® Mount
Radar/Laser/Camera Detector
DSP 9200BT
Operating Instructions
Printed in the Philippines Part No. 480-1030-P Version A
Thank you for purchasing Cobra’s new digital ultra-performance
radar/laser/camera detector.
Windshield Bracket
Mounting Slot
Power/Volume
Button Mini-USB 5V
Power Jack
Menu/Report Button
• Press once to enter
Menu Mode.
• Press and Hold to
make a User Report*
Mute/Down Button
• While alerting, press once
to manually mute audio alerts.
• In Standby and connected to
the app, press once to toggle
between available standby
screens.
City/ Button
• Switches between
Highway and City
ltering modes.
• In Menu mode, steps
forward through
menu options.
Dim/ Button
• Adjusts the
display brightness.
• In Menu mode,
steps backward
through menu
options.
Mounting
Your detector should be mounted on the windshield or dashboard of
your vehicle. Three mounting options are included:
Suction Cup Mount –
This is the best option for portability and mov-
ing the detector from car to car. Make sure to
thoroughly clean the suction cups and windshield
mounting area to insure a tight seal.
Dual Lock® Mount –
This mount is discreet and very solid for a
permanent mounting location. Make sure the
adhesive side of the included Dual Lock is securely
fastened to the windshield before adding the
weight of the detector to it.
Hook and Loop Fastener–
Included for dashboard mounting.
Suction Cup Mount
Hook & Loop Fastener
Your detector should be mounted so that it is
oriented parallel to the road. The suction cup
mount comes standard bent at a 45° angle and
Dual Lock® at 30° angle.
The metal is designed to bend without break-
ing. Adjust the angle so when mounted the
detector is level with the road.
Windshield
Incorrect Positions
Correct Position
Powering
Plug in your detector using the included
cigarette lighter adapter. This adapter
has a Mini-USB 5V output.
Note: the adapter includes a Type-A USB
port that can be used to charge your
smartphone or tablet using the manufac-
turer’s charging cable.
Turn your detector On/Off by pressing
and holding the Power/Volume button
on top of the unit.
12V Cigarette Lighter Adapter
12V Power Jack
USB Port
Menu/Settings Screen
Settings are available for customizing your
detector. When Menu is pressed, you will see will see the detec-
tor display the word MENU and then X-Alert. From this Menu
Mode, press the Button to step through the available Alert
and User Settings. Press the button to change the selected
setting. The Settings options are:
Alert Screens and Settings
Radar bands consist of X-band, K-band, and Ka-band. With Radar
signals, the signal strength meter shows signal strength of the
radar gun giving the relative proximity to the source.
The Settings Menu allows turning these bands On and Off. In addi-
tion, this detector has three modes for displaying these radar band
alerts. Frequency Display Mode On, Off, and Advanced can be se-
lected from the Settings Menu. The default is Off, but Cobra would
recommend switching to Advanced after reading this manual and
understanding the alerts graphics on the following page.
Color Coded Threat Areas*
When connected to the Cobra iRadar app, the color of the Radar
Band, Laser or Location Based Alerts and Standby Screens will
change. The color indicates the threat level for the area your ve-
hicle is located. The threat level is calculated by Cobra’s powerful
servers and displayed on your smart phone and the detector.
White= Not Connected, Blue= Low Threat Level, Orange=
Medium Threat Area, Red= High Threat Area.
• Press and Hold to
turn the power On
and Off.
• Press to adjust the
volume.
No connection to phone. City Max
lter mode selected.
Connected to phone. Vehicle heading
north west at 55 Mph.
Radar Alerts
Frequency Display Mode Off
This is the basic alert mode. It shows the radar alert band and
signal strength.
X-Alert
K-Alert
Ka-Alert
Frequency
Auto Mute
Audio
Controls and
Connections
NOTE: This device complies with part 15 of FCC rules: Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received including interference that may cause undesired operation.
CAUTION: Modifications or parts not approved by Cobra Electronics Corporation may violate FCC
Rules and void authority to operate this equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire
de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d’en compromettre le fonctionnement.
US Pat. Nos. 6078279, 8842004, 8970422 and other US Patents Pending
• In standby, Press and Hold to
turn Quiet Drive On and Off.
• In Menu Mode, press to change
the setting.
*GPS and iRadar-based features
require connection to a Bluetooth®
Smart ready device and the
Cobra iRadar app. For a full list of
Bluetooth® Smart ready devices visit
www.bluetooth.com
Avoid blocking the detector’s view by windshield wiper blades or
dark tinting at the top of the windshield.
Note: Do not attempt to bend the mount while the detector
vis attached.
Power/Volume Button
Premium Carry Case
Alert and User Settings
Signal Strength-
Level 1= Weakest Signal
Level 5= Strongest Signal
Ka Band Alert- Red color indicates detector is
connected to the App and in a high threat area.
Ka band Alert-Orange color indicates detector is connected to
the App and in a medium threat area.
Standby Screens
The Standby Screen is the normal screen you will see while driving
when not detecting and alerting to a Radar, Laser or Location
Based Alert. The screen will vary a little from what’s seen below
based on the options and features turned On and Off or the oper-
ating modes selected.
Note: Pressing the Mute / Button when Connected will toggle
between these two screens.
Frequency Display -The exact frequency
of the detected radar signal
Red color indicates
connected and high
threat area.
Ka Band Alert. White color indicates
not connected to the app. Height and color of bar
shows signal strength.
Proximity to the center
shows likely real alert.
Downloading the App
For optimal performance and access to all this
detectors advanced features, you should download
the iRadar app and use it when you drive with this
detector. To download the app you must enter the
iTunes Store or Google Play and search for “Co-
bra iRadar”. Follow the onscreen instructions to
Cobra iRadar® App
The iRadar app separates Cobra from any other
detectors out there.
Make sure to check out the Tutorial for a full
explanation of app features. The Tutorial can be
accessed from the Menu.
Information on specific settings and explanations
of radar bands can be found by pressing the
green info icons in the settings menus. The iradar
app can also be used to change and easily adjust
the detectors settings!
AURA® Location-based Alerts (LBAs) and
iRadar Community
Your detector is capable of providing you with LBAs and iRadar
Community threat sharing data when connected to iPhone or
Android phones. The detector uses the GPS in your smartphone
to connect to and obtain the latest LBA’s and alert you to them.
Vehicle speed and compass headings use your phone’s GPS
as well. See the section on Downloading the App to add these
features and more.
Small Size. Big Performance.
The ultimate long-range detection platform packed into the
industry's smallest design. Detects all radar/laser guns and
cameras.*
Revolutionary Accuracy
Reduces the uncertainty and frustration of false alerts with Digital
Signal Processing (DSP) technology, the next level of accurate radar
detection. DSP digitizes radar signals and compares them to known
radar gun signatures to determine whether or not to sound an alert.
The Power of Community
Let the free Cobra iRadar® app and community-based detection
lead the way. iRadar gives real-time alerts to upcoming Speed &
Red Light Cameras, Live Police Activity, Radar & Laser Guns and
Caution Areas reported by other iRadar users*.
Stay One Step Ahead
Cobra's powerful servers and complex algorithms take massive
amounts of historical user data and distill it into a threat level for
your vehicle. This detector's display will change color matching the
severity and urgency of the threat level to keep you one step ahead*.
Just What You Want to Hear
A suite of several Cobra technologies help to further eliminate
unwanted and false alerts. These include: SpeedMute™
*
, Auto Mute
Mode, QuietDrive™ Mode, AutoCity™
*
, CAS Immunity and
TFS rejection.
*GPS and iRadar-based features require connection to a Bluetooth® Smart ready
device and the Cobra iRadar app. For a full list of Bluetooth® Smart ready devices
visit www.bluetooth.com
Quiet Drive
Screen Saver
Auto Off
System Info
Restore Default
*GPS and iRadar-based features require connection to a Bluetooth® Smart ready
device and the Cobra iRadar app. For a full list of Bluetooth® Smart ready devices visit
www.bluetooth.com
Band Frequency of Guns
X 10.525
K 24.150
Ka 33.800
34.300
34.700
34.950
35.500
DSP9200BT_MANL.indd 1 4/23/15 5:18 PM
Location Based Alerts:
LBA Only:
LBA and Radar:
The distance will count down as you approach the Location-based
Alerts (LBA) Area.
The alert types are:
Photo-enforced Areas
Red-light Cameras
Speed Cameras
LBAs will start as you approach the actual location. If both a radar
and Location-based alerts happen at the same time, both will be
displayed side by side.
Description Interpretation Recommended Response
Tone repeats slowly at
first, then speeds up
rapidly.
Probably police radar. FULL ALERT
Tone sounds one time
only.
Probably a false alarm.
Exercise caution
Tone repeats slowly as
you approach a hill or
bridge, then speeds up
sharply as you reach it.
Probably police radar beyond
the hill or bridge.
FULL ALERT
Tone repeats slowly
for a short period.
Probably a false alarm. Exercise caution
Any type of laser alert. Laser alerts are
never false alarms.
FULL ALERT
Responding to Alerts Limited 1-Year Warranty
Cobra Electronics Corporation warrants that this product and the component parts
thereof, will be free of defects in workmanship and materials for a period of one
year from the date of first consumer purchase. This warranty may be enforced by
the first consumer purchaser. If the product is under warranty, it will be repaired or
exchanged depending on the model as determined at Cobra’s sole discretion. Such
remedy shall be your sole and exclusive remedy for any breach of warranty.
The procedure for obtaining service and support, and the applicability of this
warranty, will vary depending on the country or jurisdiction in which you purchased
and utilize the product. For the details on obtaining product service, support and
warranty please visit www.cobra.com/support
Provided that the product is utilized within the U.S.A.- Cobra will, without charge,
repair or replace, at its option, defective products, or component parts upon delivery
to the Cobra Factory Service department, accompanied by proof of the date of first
consumer purchase, such as a duplicated copy of a sales receipt. You must pay any
initial shipping charges required to ship the product for warranty service, but the
return charges, to an address in the U.S.A., will be at Cobra’s expense, if the product
is repaired or replaced under warranty.
This warranty gives you specific legal rights, and you may also have other rights
which may vary from state to state and country to country.
Exclusions: This limited warranty does not apply: 1) To any product damaged by
accident; 2) In the event of misuse, ordinary wear, failure to follow directions, or
improper maintenance of the product or as a result of unauthorized alterations
or repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the
product was purchased or is utilized in a jurisdiction not covered by the limited
warranty.
All implied warranties, including warranties of merchantability and fitness for a
particular purpose are limited in duration to the length of this warranty. Cobra shall
not be liable for any incidental, consequential or other damages; including, without
limitation, damages resulting from loss of use or cost of installation.
Some states and countries do not allow limitations on how long an implied
warranty lasts and/or do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which
vary from state to state and country to country.
Screen Saver
Your detector has a Screen Saver mode. When Screen Saver is
turned On (factory default is 3 minutes), the screen will change
to Dark from it's Bright, Dim, or Dimmer setting after the time
interval selected. While the screen is Dark, a small white dot will
move on the screen to indicate the unit is turned On.
Note: While Screen Saver is activated, any alert will turn the
display back on at the last brightness setting (Bright, Dim or Dim-
mer). Touching any button will also turn On the display.
For any questions about operating or installing this new Cobra product,
PLEASE CONTACT COBRA FIRST…do not return this product to the retail
store. The contact information for Cobra will vary depending on the country
in which you purchased and utilize the product. For the latest contact
information, please go to www.cobra.com/support
For products purchased in the U.S.A. you may also call 1-773-889-3087.
For Products Purchased in the U.S.A., if your product should require factory
service, please go to www.cobra.com/support and follow the instructions for
returning your product to the Cobra Factory Service Department for service.
Trademark Acknowledgment
Cobra®, AURA® , Cobra iRadar®, LaserEye®, Nothing Comes Close to a
Cobra®, and the snake design are registered trademarks of Cobra Electronics
Corporation, USA.
Cobra Electronics Corporation
™
, AutoCity
™
, LaserRelay
™
, SmartScope
™
, and
SpeedMute
™
are trademarks of Cobra Electronics Corporation, USA.
iPhone® and iPod® touch are trademarks of Apple, Inc, registered with the
U.S. and other countries.
The Bluetooth® word mark is a registered trademark owned by Bluetooth
SIG, Inc. and any use of such marks by Cobra Electronics Corporation
is under license. Other trademarks and trade names are those of their
respective owners.
Android™ is a trademark of Google, Inc. Use of this trademark is subject to
Google permission.
Dual Lock® is a registered trademark of 3M Corporation.
Auto Off Mode
Your detector includes an Auto Off feature - when turned On, it
will turn off the detector after the selected amount of time. The
detector will turn off after this time if no alerts are detected and no
movement is sensed from the iRadar app. The options are 30, 60,
90 minutes or Off. The default setting for this setting is Off.
Note: This feature should only be used if your detectors power
switch does not turn off with the vehicle's ignition. In addition,
we recommend to only enable this feature if you use the detector
with the iRadar app. Using it with the app will prevent unin-
tended shut downs on longer trips.
Advance App Controlled Functions
This detector is capable of supporting some advanced functions
controlled by the iRadar app. They are not in the detectors
Settings Menu, and are instead easily adjust and changed in the
iRadar App.
SpeedMute™
This feature will automatically mute unwanted alerts while
driving below a selectable speed setting. This can be turned
On and Off and the speed setting adjusted in the iRadar app.
AutoCity™
This feature automatically switches between Highway and
City modes based on speed and other information from your
smartphone. It can be turned On and Off in the app.
Phone Mode Advanced Audio Routing Over Bluetooth
Select “Phone” for Alert Audio in the iRadar app. Managed
audio is sent to the vehicles stereo via Bluetooth or wired Aux
Input. Alerts can also be sent to a Bluetooth headset.
Auto Mute Mode
When Auto Mute is On, the audio volume of all alerts is
automatically reduced after 4 seconds. The signals will remain
muted for as long as the signal is detected. When Auto Mute is
Off, the alerts will sound at full volume for as long as the signal
is detected. The factory setting for Auto Mute is On.
Voice or Tone Mode
You can set your detector to sound alerts and confirm menu
settings with either a Voice or a Tone Alert. Voice Alert provides
voice messages in addition to tones. Tone Alert provides tones
only. The factory setting is Voice Alert.
Quiet Drive™
Quiet Drive is a muted driving mode for times when a driver
wants less audible feedback while talking with passengers,
on the phone, etc. This mode is Off by default. If switched
On, it will turn to Off again after the detector is power cycled.
When Quiet Drive is On, the display will Show "QUIET" on the
Standby Screen like below.
Note: You can also enter Quiet Drive by Pressing and Holding the
Mute Button.
Threat Area Alert
Threat Area alerts will also be displayed on the screen. The Detection
Scanner will stop moving and become a solid bar that will blink.
Using the Report Button
You can report to the iRadar Community when you see an
active police speed enforcement by pressing the MENU
button for 2 seconds.
iRadar Community
As you approach a specific Threat Area you
will hear a short beep and then the app will
indicate the Cobra’s assessment of the
reliability of the threat.
High-Threat Area means multiple reports
have confirmed a legitimate threat in the
area recently.
Medium or Low-Threat Area means signals
have been detected but have either not been
confirmed or have not been reported lately.
Paying attention to threat areas will allow
you to be warned of potential threats
before you enter radar detection range.
Community Radar/Laser alert sharing
means that you have an entire network
of users working to keep you and your
wallet safe.
When you, or any other iRadar user, detects a radar or laser signal
the alert information is anonymously sent to Cobra’s cloud servers.
Within seconds, that information is processed and displayed on your
map as part of a Threat Area.
Highway, City, City Max and AutoCity™ Modes:
Highway Mode provides full immediate response to all signals de-
tected. Use this mode when you are driving on interstate highways.
Automatic door openers operate in X and K-band frequencies.
To minimize unwanted false alerts in an urban environment where
these sources exist, use one of the City Filtering Modes below:
• Highway: Maximum long range alerting.
• City: automatically mutes X-band audible
alert until signal strength reaches level 3
or above.
• City MAX: Maximum filtering against
urban false signal sources.
Highway
City
City Max
Dim/ Button
Illumination
The display illumination intensity can be adjusted to suit driving
conditions with three levels and Dark Mode:
• Factory default is Bright.
• Use Dark mode to blank the screen for discreet use. In this mode,
alerts will sound but not show. (A small white dot will move
on the screen).
You can adjust the illumination by pressing the Dim button repeatedly
to step through the levels.
Far Away Getting Closer Close
For more information on pairing with Bluetooth devices consult
your phone’s owners manual.
If you are having trouble initializing or maintaining your
Bluetooth connection completely turn off your smartphone and
detector device, wait 30 seconds, and then turn them back on.
Optional Accessories
You can find quality Cobra products and accessories at your local Cobra
dealer, or in the U.S.A., you can order directly from Cobra at www.cobra.com
Windshield
Mounting Bracket
Includes suction cups
Item #545-159-N-001
Dual Port Power Adapter
Includes adjustable plug
(up to 90˚) and fuse
Item # CLP-2B
Straight Combination Radar
USB Cord
Includes plug and USB
Output
Item # PWR USB-01
Install Mount
Includes 3M Dual Lock
Item # 545-002
Pairing/Connecting with Your Detector
GPS and iRadar-based features require connection to a
Bluetooth
®
Smart ready device and the Cobra iRadar app. For a full list of
Bluetooth® Smart ready devices visit www.bluetooth.com
Please note, this is the newer Bluetooth® Smart technology
and pairing is not always done in the same manner and menus as
conventional Bluetooth. This detector will NOT APPEAR in the
Bluetooth Settings menu of your iPhone®.
For iPhone® 4S and later with Bluetooth® Smart:
a. Power on the detector. If not connected, it will be in the
Pairing Mode automatically.
b. Make sure your iPhone Bluetooth is turned On
c. Start the Cobra iRadar application. Press the Menu icon in
the upper left corner of the app and select Devices. Follow the
onscreen instructions to complete the pairing and connection.
d. When complete, you will see
“CONNECTING” appear on the
detector screen.
For Android™ :
a. Power on the detector. If not connected, it will be in the
Pairing Mode automatically.
b. Make sure the your Android™ device’s Bluetooth is turned On
and go to the Bluetooth Settings Menu. For most devices this
can be found by pressing; Settings > Bluetooth.
c. Press Scan for Devices and/or wait for the device list to popu-
late and then select iRadar. Pairing can take up to 30 seconds.
d. The phone might show “Paired but not connected” in this
menu. That’s OK as the connection will be completed after
opening the iRadar App.
Premium Carry Case
Includes storage for cords
and mounts
Item # CCRD1
Known Speed Trap Areas
Caution Areas (High
Accident Areas)
DSP9200BT_MANL.indd 2 4/23/15 5:18 PM
