2English
Making Life Easier & Safer
Owner’s Manual
Nothing Comes Close To A Cobra™English
2-WAY RADIO MODEL
PR3000 DX
Printed in Philippines
Part No. 480-049-P
Owner’s Manual
Nada se compara a Cobra™Español
PR3000 DX
Printed in Philippines
Part No. 480-049-P
Introduction
Staying in touch with your family and friends is
convenient and easy when using your microTALK®
radio. Some of the many uses you will discover include:
Communicating with others while hiking, biking, and working; keeping
track of family and friends at a crowded public event; checking with
travel companions in another car; talking with neighbors; arranging
meeting spots with others while shopping at the mall.
Secure your microTALK®
radio while on the go.
Carrying your microTALK®radio with you is
easy when using the belt clip or wrist strap.
The belt clip easily attaches to your belt, purse,
or backpack. Simply squeeze the clip and place
it where you prefer.
For Assistance In the U.S.A.
In this user’s manual, you should find all the information you need
to operate your microTALK®radio. If you require further assistance
after reading this manual, Cobra®Electronics offers the following
customer assistance services:
Automated Help Desk
English only. 24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators
English and Spanish. 8:00 a.m. to 6:00 p.m. CT,
Monday through Friday (except holidays) 773-889-3087 (phone).
Questions
English and Spanish. Faxes can be received at 773-622-2269 (fax).
Technical Assistance
English only. www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo@cobra.com (e-mail).
For Assistance Outside the U.S.A.
Contact Your Local Dealer
Belt Clip
Wrist Strap
Customer Assistance
©2002 Cobra®Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
RADIO
BIDIRECCIONAL
MODEL
2Español
Una vida más sencilla y segura
Introducción
Es muy fácil y práctico mantenerse en contacto con su familia y
sus amigos cuando utiliza un radio microTALK®.Usted descubrirá
gran número de aplicaciones para el radio, como las siguientes:
comunicación con otras personas en excursiones, paseos el bicicleta o en el
trabajo; contacto con la familia y los amigos en concurridos eventos públicos,
comunicación con compañeros de viaje en otro automóvil; conversaciones
con los vecinos; ponerse de acuerdo en un punto de reunión durante una
visita al centro comercial.
Transporte el radio
microTALK®con seguridad.
Es muy fácil transportar el radio microTALK®con
la pinza para cinturón o la correa para la muñeca.
La pinza se sujeta fácilmente al cinturón, un bolso
o una mochila. Sólo tiene que oprimir la pinza y
colocarla donde quiera.
Ayuda en los EE.UU.
En este manual para el usuario encontrará toda la información necesaria para
usar el radio microTALK®. Si después de leer este manual requiere ayuda
adicional, Cobra®Electronics ofrece los siguientes servicios de apoyo a clientes:
Centro automatizado de ayuda
Únicamente inglés. Disponible las 24 horas del día, todos los días del año,
llamando por teléfono al 773-889-3087.
Operadores de ayuda al cliente
Inglés y español. Disponibles de 8:00 a.m. a 6:00 p.m., hora del centro de
EE.UU., de lunes a viernes (excepto días festivos), llamando por teléfono al
773-889-3087.
Preguntas
Inglés y español. Puede enviar sus preguntas por fax al 773-622-2269.
Ayuda técnica
Únicamente inglés. www.cobra.com (en Internet: preguntas más frecuentes).
Inglés y español. Corre electrónico: productinfo@cobra.com
Ayuda fuera de los EE.UU.
Comuníquese con un distribuidor de productos Cobra®de su localidad.
©2002 Cobra®Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
Pinza para el cinturón
Correa para la muñeca
Ayuda a clientes
Battery
Compartment
Battery Door
Latch
Belt Clip
Wrist Strap
Connector
Operation
Customer Assistance
Warranty
5
Nothing comes close to a Cobra™
Introduction
4English
Product Features
3English
Product Features
Introduction
Backlit
LCD
Display
Channel
Up/Down
Buttons
Speaker/
Microphone
Call
Button
Mode
Button
Antenna
Key Lock
Button
Hi•Low
Power Button
External Speaker/
Microphone Jack
Light/
Max Range
Button
Talk
Button
On/Off
Volume
Knob
Charger
Jack
Introduction
Backlit LCD Display
Important FCC Licensing Information
This radio operates on General Mobile Radio
Service (GMRS) frequencies which require a
Federal Communications Commission (FCC)
license. See page 18 for licensing and other
related information.
Receive/
Transmit
Tow er Icon
Hi•Low
Power Icon
Lock Icon
Keystroke Tones Icon
Call Tones and
VibrAlert™Icon Roger Beep Icon
Signal Strength
Meter Icon
Battery Level
Indicator
Main Channel
Numbers Power Saver Icon
CTCSS Privacy
Code Numbers
Scan Icon
Vox Icon
Features
• Two-Way Radio
with up to a six (6)
mile (10 km) range
• 22 Channels
(7 shared with
FRS/GMRS,
7 FRS only,
8 GMRS only)
•38 PRIVACY
Codes
• Hands-Free
Operation (VOX)
• VibrAlert®
Silent Paging
• Signal
Strength Meter
• Scan
(channel, privacy
code)
• Selectable
Hi•Low Power
(in GMRS)
• Backlit
LCD Display
• Call Alert
(10 selectable
tones)
• Lock
• Speaker/
Microphone Jack
• “Roger Beep”
(selectable On/Off)
• Battery/Power Saver
• Keystroke Tones
(selectable On/Off)
• Auto Squelch
• Maximum Range
Extender
•Belt Clip
• Wrist Strap
Caring for Your microTALK®Radio •
Your microTALK®radio will give you years of trouble-free service if
cared for properly. Handle the radio gently. Keep the radio away from
dust. Never put the radio in water or in a damp place. Avoid exposure
to extreme temperatures.
Batteries •
To Install or Replace Batteries:
1. Remove belt clip by releasing belt clip
latch and sliding clip up.
2. Pull down on the Battery Door Latch to
remove the battery compartment cover.
3. Insert four (4) AAA batteries. (Always use high
quality alkaline batteries.) Position batteries
according to polarity markings.
4. Replace Battery Compartment cover and belt clip.
Contact your local Cobra®dealer
or Cobra®directly for optional
charger accessories.
Insert Batteries
Pull Down Lock Latch
Remove Belt Clip
The Basics to Get You Started
Your microTALK®radio is easy to use.
To get started, simply:
1. Rotate the On/Off Volume knob to
turn On your radio.
2. Press the Channel Up or Channel Down
button to select a channel.
Both radios must be tuned to the
same channel to communicate.
3. Press and hold the Talk button while
speaking into the microphone.
4. When finished talking, release the Talk
button and listen for a response.
Customer Assistance WarrantyIntroduction
7
Nothing comes close to a Cobra™
Operation
6English
Using Your Radio
Turning On Your microTALK®Radio •
To Turn On Your Radio:
1. Rotate the On/Off Volume knob clockwise
to turn On your radio and adjust the volume.
A series of tones will indicate the radio is On.
Your microTALK®radio is now in Standby Mode,
ready to receive transmissions. The radio is
always in Standby Mode, except when the
Talk, Call or Mode buttons are pressed.
Battery Low •
Your microTALK®radio has a battery level meter
that shows when battery power is decreasing.
The greater the number of ascending bars visible,
the stronger the battery level. When the battery
level is low, the last bar and “bALo” will flash
indicating your batteries should be replaced
or recharged, if using rechargeable batteries.
Auto Battery Save •
Your microTALK®radio has a unique circuit
designed to extend battery life. If there are
no transmissions within ten (10) seconds,
the radio will automatically switch to Battery
Save Mode and Power Saver icon will flash
in the display. This will not affect the radio’s
ability to receive incoming transmissions.
Communicating with Another Person •
To Talk To Another Person:
1. Press and hold the Talk button.
2. With the microphone about two (2)
inches (5 cm) from your mouth,
speak in a normal voice.
3. Release the Talk button when you are
finished talking and listen for a response.
You cannot receive incoming calls while
pressing the Talk button.
Both radios must be tuned to
the same channel to communicate.
Scrolling Through
the Mode Function •
By scrolling through the Mode function, you will
be able to select or turn On preferred features of
your microTALK®radio. When scrolling through
the Mode function, your radio features will be
displayed in the same predetermined order:
Set Privacy Codes
Set VOX On/Off
Set VOX Sensitivity Level
Set Channel Scan
Set Privacy Code Scan
Set VibrAlert®and/or Call Alert
Set Call Tones
Set “Roger Beep” On/Off
Set Keystroke Tones On/Off
Channels •
To Select a Channel:
1. With the radio On, select any of the
22 channels by pressing the Channel Up
or Channel Down button.
Both radios must be tuned to the
same channel to communicate.
Channels 1 through 7 are shared with FRS/
GMRS. Channels 8 through 14 are FRS only.
Channels 15 through 22 are GMRS only.
See page 17 for FRS/GMRS frequency
allocations and compatibility charts.
On/Off Power
Battery Low
Battery Save Mode
Talk Button
Mode Button
Channel Button
Channel Number
Operation
2 inches (5 cm)
From Mouth
Customer Assistance WarrantyIntroduction
9
Nothing comes close to a Cobra™
Operation
8English
Using Your Radio
CTCSS Privacy Codes •
CTCSS (Continuous Tone Coded Squelch System)
is an advanced tone coding system allowing you
to select one of 38 privacy codes to reduce
interference from other users on the channel.
If you are using a privacy code, both
radios must be tuned to the same channel
and privacy code to communicate. Each
channel will remember the last privacy
code you selected.
To Select a Privacy Code:
1. After selecting a channel, press the Mode
button until the small numbers next to the
channel number flash on the LCD.
2. Press the Channel Up or Channel Down button
to select a privacy code. You can hold the Up
or Down button for fast advance.
3. When your desired privacy code is displayed:
a. Press the Mode button to enter the new
setting and proceed to other functions.
b. Press the Lock button to enter the new
setting and return to Standby Mode.
c. Do not press any buttons for 15 seconds
to enter the new setting and return to
Standby Mode.
Listening for a Response •
When You are Finished Talking:
1. Release the Talk button to receive incoming
transmissions. Your microTALK®radio is
always in Standby Mode while the Talk or
Call buttons are not pressed.
Volume •
To Adjust the Volume:
1. Rotate the On/Off Volume knob.
Call Button •
To Alert Another Person That You Are Calling:
1. Press and release the Call button.
The other person will hear a two (2) second
call tone. You cannot send or receive
transmissions during the two (2) second
call tone.
See page 13 on how to select
between ten (10) call tone settings.
Selectable High•Low Power Output •
When in close proximity to another party or during
favorable conditions, you can switch from High to
Low Power to extend battery life.
This feature applies to GMRS channels
1 through 7 and 15 through 22 only.
Channels 8 through 14 operate
exclusively on Low Power.
To Switch from High to Low Power:
1. Press and release the Hi•Low button.
When in High Power and using channels
1 through 7 and 15 through 22, the Hi icon
will be visible in the LCD display.
When in Low Power and when using channels
8 through 14, the Low icon will be visible in
the LCD display.
Mode Button
Channel Button
Privacy Code
Listening
Volume Knob
Call Button
Hi•Low Button
Low Power Icon
Hi Power Icon
Operation
38 Privacy Codes
Customer Assistance WarrantyIntroduction
11
Nothing comes close to a Cobra™
Operation
10 English
Using Your Radio
Voice Activated Transmit (VOX) •
In VOX Mode, your microTALK®radio can be
used “hands-free,” automatically transmitting
when you speak. You can set the VOX sensitivity
level to fit the volume of your voice and avoid
transmissions triggered by background noise.
To Turn VOX Mode On or Off:
1. Press the Mode button until the VOX icon
flashes on the LCD. The current On or Off
setting is displayed.
2. Press the Channel Up or Channel Down
button to turn VOX On or Off.
3. a. Press the Mode button to enter the
selected On or Off setting and proceed
to other functions.
b. Press the Lock button to enter the
selected On or Off setting and return
to Standby Mode.
To Set the Sensitivity:
1. Press the Mode button until the VOX
icon flashes and the current sensitivity
level is displayed.
The current sensitivity level is displayed
with letters “LE” and a number 1 through
5, 5 being the most sensitive level and
1 being the least sensitive level.
2. Press the Channel Up or Channel Down
button to change the setting.
3. a. Press the Mode button to enter the selected
setting and proceed to other functions.
b. Press the Lock button to enter the selected
setting and return to Standby Mode.
VOX Sensitivity Level
Operation
VOX Icon
Mode Button
Channel Button
Scan •
Your microTALK®radio can automatically scan
main channels (1 through 22) or the privacy codes
(00 through 38) within one (1) main channel.
To Scan Main Channels:
1. Press the Mode button until the Scan icon and
the main channel number flashes on the display.
2. Press the Channel Up or Channel Down button
to begin scanning the main channels.
The radio ignores privacy codes
while scanning main channels.
3. The Scan icon will continue to be displayed
when scan is On. Your radio will continue to
scan all main channels and stop if an incoming
transmission is detected. Your radio will
remain on that channel for ten (10) seconds.
During this time, you can:
a. Press and hold the Talk button to communicate
with others. Your radio will remain on that
channel and return to Standby Mode.
b. Press the Channel Up or Channel Down
button to resume scanning channels.
c. Press the Mode button to proceed to
privacy code scanning (see page 12
for further details).
If you press the Talk button while scanning
and not within ten (10) seconds of receiving
transmission, you will transmit on the last
channel you transmitted or received on.
If you do not press any button within ten
(10) seconds, your radio will automatically
resume scanning main channels.
Scanning Channels
Mode Button
Channel Button
Customer Assistance WarrantyIntroduction
13
Nothing comes close to a Cobra™
Operation
12 English
Using Your Radio
To Scan Privacy Codes:
1. While in Standby Mode, press the Channel Up
or Channel Down button to choose the main
channel you wish to scan.
2. Press the Mode button until the Scan icon and
the privacy code number flashes on the display.
3. Press the Channel Up or Channel Down button
and your radio will begin scanning privacy
codes within the main channel you selected.
4. The Scan icon will continue to be displayed
when scan is On. Your radio will continue to
scan privacy codes and stop as incoming
transmission is detected. Your radio will
remain on that channel and privacy code for
ten (10) seconds. During this time, you can:
a. Press and hold the Talk button to
communicate with others. Your radio will
remain on that channel and privacy code
and return to Standby Mode.
b. Press the Channel Up or Channel Down
button to resume scanning privacy codes.
c. Press the Mode button to proceed to next
available Mode function.
If you press the Talk button while scanning
(see page 11 for further details) and not within
ten (10) seconds of receiving transmission,
you will transmit on the last channel you
transmitted or received on.
If you do not press any button within ten
(10) seconds, your radio will automatically
resume scanning privacy codes.
Channel Button
Mode Button
Select Channel
Scan Privacy Codes
Operation
VibrAlert®and Call Tones •
Your microTALK®radio can alert you to
incoming signals by sounding an audible
call tone, by vibrating silently, or both.
To Change Call Settings:
1. Press the Mode button until the Call Setting
icon flashes on the LCD. The current setting
(Vibrate + Ring, Vibrate Only, or Ring Only)
is displayed.
2. Press the Channel Up or Channel Down
button to change the call setting.
3. a. Press the Mode button to enter the new
setting and proceed to other functions.
b. Press the Lock button to enter the new
setting and return to Standby Mode.
10 Call Tone Settings •
You can choose between ten (10) different call
tone settings to transmit a unique call alert.
To Change a Call Tone Setting:
1. Press the Mode button until the letter “C”
and the current call tone number (1 through
10) is displayed. The current call tone will
sound for one (1) second.
2. Press the Channel Up or Channel Down
button to hear the other call tone settings.
3. a. Press the Mode button to enter the new
setting and proceed to other functions.
b. Press the Lock button to enter the new
setting and return to Standby Mode.
Mode Button
VibrAlert®+ Ring
VibrAlert®Only
Ring Only
Channel Button
Mode Button
Call Tone Setting
Channel Button
14 English
Using Your Radio Customer Assistance WarrantyIntroduction
15
Nothing comes close to a Cobra™
Operation
“Roger Beep” Confirmation Tone •
Your listener will hear an audible tone when you
release the Talk button. This alerts the other party
that you are finished talking and it is OK for them
to speak. This feature can be turned On or Off.
To Turn “Roger Beep” On or Off:
When turning On your microTALK®radio
for the first time, “Roger Beep” will be On.
1. Press the Mode button until the Roger
Beep icon flashes on the LCD. The current
On or Off setting is displayed.
2. Press the Channel Up or Channel Down
button to select “Roger Beep” On or Off.
3. a. Press the Mode button to enter the new
setting and proceed to other functions.
b. Press the Lock button to enter the new
setting and return to Standby Mode.
The setting you select will be saved when you
turn your radio Off and On again. When the
“Roger Beep” is On, the “Roger Beep” icon
will be displayed.
Keystroke Tones •
With Keystroke Tones turned On, your radio
will sound beeps each time you press a button
or change a setting.
To Change Keystroke Tones:
1. Press the Mode button until the Keystroke
Tones icon flashes on the LCD. The current
On or Off setting is displayed.
2. Press the Channel Up or Channel Down
button to turn Keystroke Tones On or Off.
3. a. Press the Mode button to enter the new
setting and proceed to other functions.
b. Press the Lock button to enter the new
setting and return to Standby Mode.
Operation
Mode Button
Roger Beep On
Channel Button
Mode Button
Keystroke Tones On
Channel Button
Display Illumination •
To Illuminate Your Display:
1. Press and release the Light/Max Range button
to illuminate the display for ten (10) seconds.
Auto Squelch/Maximum Range •
Your microTALK®radio is equipped with Auto Squelch,
which automatically shuts Off weak transmissions
and unwanted noise due to terrain, conditions, or if
you’ve reached your maximum range limit.
You can temporarily turn Off Auto Squelch or
turn On Maximum Range Extender, allowing all
signals to be received and extending the
maximum range of your radio.
To Temporarily Turn Off Auto Squelch:
1. Press the Light/Max Range button less
than five (5) seconds.
If you hear two (2) beeps, you have turned the
Maximum Range Extender On (see below).
To turn Maximum Range Extender On:
1. Press and hold the Light/Max Range button
for at least five (5) seconds until you hear
two (2) beeps which indicates the Maximum
Range Extender is On.
To Turn Maximum Range Extender Off:
1. Press and release the Light/Max Range
button or change channels.
Lock Function •
The Lock button locks the Channel, Mode, and Hi•
Low Power buttons to prevent accidental operation.
To Turn the Lock Button On or Off:
1. Press and hold the Lock button for
two (2) seconds.
A double beep sound is used to confirm
your Lock On or Off request. When in
Lock Mode, the Lock icon will be displayed.
Light/Max Range
Light/Max Range
Lock Button
Lock Mode
Customer Assistance WarrantyIntroduction
17
Nothing comes close to a Cobra™
Operation
General Specifications •
Nominal
Unit
Nominal
Unit
C.Transmitter
1. Power
GMRS . . . . . . . . . . . . . . . . . . . .W 2
FRS Only . . . . . . . . . . . . . . . . .mW 500
2. Carrier Frequency Stability . . . ±Hz 500
3. Modulation Limiting . . . . . . . . KHz 2.5
4. Carrier Attack Time . . . . . . . . . mS 80
5. Audio Frequency Response
@ 300 HZ . . . . . . . . . . . . . . . . . dB -12
@ 2500 HZ . . . . . . . . . . . . . . . . dB +6
6. Audio Distortion . . . . . . . . . . . . % 3
7. Hum Noise . . . . . . . . . . . . . . . . dB 30
8. Transient Frequency Behavior
a) TX On . . . . . . . . . . . . . . . . . mS 30
b) TX Off . . . . . . . . . . . . . . . . . mS 5
A. FRS/GMRS
Frequency
Allocation and
Compatibility
Important: Please note that Cobra®GMRS
models with 15 channels may designate
different channel numbers for the same
frequency. For example, a Cobra®15 channel
GMRS model would need to be tuned to
channel 11 in order to communicate with
a 22 channel GMRS tuned to channel 15.
Please refer to the chart below for channel/
frequency number compatibility.
A = Channel No. For
22 Channel GMRS Models
B = Channel No. For 15
Channel GMRS Models
C = Type of Radio Service
D = Frequency in MHz
E = Power in Watts
a = 2.0/0.5 (selectable)
b = 0.5
ABC D E
1 1 FRS/GMRS 462.5625 a
2 2 FRS/GMRS 462.5875 a
3 3 FRS/GMRS 462.6125 a
4 4 FRS/GMRS 462.6375 a
5 5 FRS/GMRS 462.6625 a
6 6 FRS/GMRS 462.6875 a
7 7 FRS/GMRS 462.7125 a
8 FRS 467.5625 b
9 FRS 467.5875 b
10 FRS 467.6125 b
11 FRS 467.6375 b
12 FRS 467.6625 b
13 FRS 467.6875 b
14 FRS 467.7125 b
15 11 GMRS 462.5500 a
16 8 GMRS 462.5750 a
17 12 GMRS 462.6000 a
18 9 GMRS 462.6250 a
19 13 GMRS 462.6500 a
20 10 GMRS 462.6750 a
21 14 GMRS 462.7000 a
22 15 GMRS 462.7250 a
B. Receiver
1. Sensitivity
For 12 DB SINAD . . . . . . . . . . dBm -121
For Call Signal Detection . . . . dBm -121
2. Max. Audio Output
@10% THD . . . . . . . . . . . . . . . mW 200
3. Max. S/N Ratio
@ 1mV RF Input . . . . . . . . . . . dB 50
4. Squelch
a) Sensitivity . . . . . . . . . . . . . . dBm -121
b) Attack Time . . . . . . . . . . . . . mS 150
c) Closing Time . . . . . . . . . . . . mS 200
5. Audio Frequency Response
@ 300 HZ . . . . . . . . . . . . . . . . . dB -3
@ 2500 HZ . . . . . . . . . . . . . . . . dB -10
6. Signal Displacement BW . . . +/-KHz 5
7. Adjacent Channel Rejection . . . dB 60
8. Intermodulation Rejection . . . . dB 65
9. Spurious Response Rejection . dB 55
D.Power Supply
1. Battery Life (5:5:90 RATIO)
With Alkaline Batteries . . . . . . . HR 24
2. Battery Operating Range . . . . . . V 4.2 - 6.0
Nominal
Unit
16 English
Using Your Radio
Speaker/Microphone Jack •
Your microTALK®radio can be fitted with an
external Speaker/Microphone, freeing your
hands for other tasks. See page 20 for optional
accessories ordering information. Only Cobra®
authorized accessories are recommended.
To attach your Speaker/Microphone:
1. Open the Speaker/Microphone tab on
top of your microTALK®radio.
2. Insert the plug into the Speaker/
Microphone jack.
Signal Strength Meter •
Your microTALK®radio has a signal strength
meter that shows the strength of your incoming
and outgoing transmissions. The ascending bars
next to the signal strength indicate the strength
of the signal. The greater the number of bars
visible, the stronger the signal. The fewer
number of bars visible, the weaker the signal.
microTALK®Range •
Your microTALK®radio has a range of
up to six (6) miles (10 km). Your range will
vary depending on terrain and conditions.
In flat, open country your radio will
operate at maximum range.
Buildings and foliage in the path of the
signal can reduce the range of the radio.
Dense foliage and hilly terrain will
further reduce the range of the radio.
On FRS channels 8 through 14, your radio
automatically switches to low power, which
will limit the range the radio can communicate.
Remember, you can achieve maximum
range by using Maximum Range
Extender. See page 15 for details.
Speaker/Microphone
Signal Strength
Operation
Maximum Range
Reduced Range
Reduced Range
Operation WarrantyIntroduction
19
Nothing comes close to a Cobra™
Customer Assistance
18 English
Licensing,Assistance &Warranty
IMPORTANT NOTICE: FCC LICENSE REQUIRED
This two-way radio operates on GMRS (General Mobile Radio Service) frequencies which
require an FCC (Federal Communications Commission) license. A user must be licensed prior
to operating on channels 1 through 7 or 15 through 22, which comprise the GMRS channels
of this radio. Serious penalties could result for unlicensed use of GMRS channels, in violation
of FCC rules, as stipulated in the Communications Act’s Sections 501 and 502 (amended).
Licensed users will be issued a call sign by the FCC, which should be used for station
identification when operating this radio. GMRS users should also cooperate by engaging
in permissible transmissions only, avoiding channel interference with other GMRS users,
and being prudent with the length of their transmission time.
For licensing information and application forms, please call the FCC Hotline at
800-418-FORM. Request form #159 and form #605. Questions regarding the license
application should be directed to the FCC at 888-CALL-FCC. Additional information
is available on the FCC’s website at www.fcc.gov.
Safety Information for microTALK®Radios
Your wireless handheld portable transceiver contains a low power transmitter. When the Talk
button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate
at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions
(FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices.
Important:
To maintain compliance with the FCC’s RF guidelines, hold the transmitter at least 2 inches
(5 centimeters) from your face and speak in a normal voice, with the antenna pointed up
and away. If you wear the handset on your body while using the headset accessory, use only
the Cobra®supplied belt clip for this product and ensure that the antenna is at least 1 inch
(2.5 centimeters) from your body while transmitting. If the distance between the antenna
and the body is LESS THAN 1.0 inch (2.5 cm), DO NOT USE THIS DEVICE IN THE BODY
WORN CONFIGURATION. Use only the supplied antenna. Unauthorized antennas, modifications,
or attachments could damage the transmitter and may violate FCC regulations.
Normal Position:
Hold the transmitter approximately 2 inches from your face and speak in a normal voice,
with the antenna pointed up and away.
Customer Assistance
If you have any questions about operation or installing
your new Cobra®product, or if you are missing parts…
Please call Cobra®first! DO NOT RETURN THIS PRODUCT
TO THE STORE! See customer service on page 2.
Product Service Questions
If your product should require factory service, please call Cobra®first before sending your radio.
This will ensure the fastest turn-around time on your repair. You may be asked to send your radio to the
Cobra®factory. It will be necessary to furnish the following to have the product serviced and returned.
1) For Warranty Repair include some form of proof-of-purchase, such as a mechanical reproduction
or carbon of a sales receipt. If you send the original receipt, it cannot be returned; 2) Send the entire
product; 3) Enclose a description of what is happening with the radio. Include a typed or clearly
printed name and address of where the radio is to be returned; 4) Pack radio securely to prevent
damage in transit. If possible, use the original packing material; 5) Ship prepaid and insured by way
of a traceable carrier such as United Parcel Service (UPS) or First Class Mail to avoid loss in transit
to Cobra®Factory Service, Cobra®Electronics Corporation, 6500 West Cortland Street, Chicago,
Illinois 60707 USA; 6) If the radio is in warranty, upon receipt of your radio it will either be
repaired or exchanged depending on the model. Please allow approximately 3 – 4 weeks before
contacting Cobra®for status. If the radio is out of warranty, a letter will automatically be sent
informing you of the repair charge or replacement charge. If you have any questions, please call
773-889-3087 for assistance.
Limited 1-Year Warranty For Products Purchased in the U.S.A.
Cobra®Electronics Corporation warrants that its Cobra®GMRS Radios, and the component parts
thereof, will be free of defects in workmanship and materials for a period of one (1) year from the
date of first consumer purchase. This warranty may be enforced by the first consumer purchaser,
provided that the product is utilized within the U.S.A. Cobra®will, without charge, repair or replace,
at its option, defective GMRS radios, products or component parts upon delivery to the Cobra®
Factory Service department, accompanied by proof of the date of first consumer purchase, such
as a duplicated copy of a sales receipt. You must pay any initial shipping charges required to ship
the product for warranty service, but the return charges will be at Cobra®’s expense, if the product
is repaired or replaced under warranty. This warranty gives you specific legal rights, and you may
also have other rights which may vary from state to state.
Exclusions: This limited warranty does not apply: 1) To any product damaged by accident;
2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or
repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the owner of the
product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a particular purpose
are limited in duration to the length of this warranty. Cobra®shall not be liable for any incidental,
consequential or other damages; including, without limitation, damages resulting from loss of
use or cost of installation. Some states do not allow limitations on how long an implied warranty
lasts and/or do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitations may not apply to you.
For products purchased outside the U.S.A., please contact your local dealer for
warranty information.
Warranty
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Warnings: Replacement or substitution of transistors, regular diodes or
other parts of a unique nature, with parts other than those recommended by
Cobra®may cause a violation of the technical regulations of part 95 of the FCC
Rules, or violation of type acceptance requirements of part 2 of the Rules.
20 English
Accessories & Order Form
21
Español
Customer Assistance
Name
Address (No P.O. Boxes)
City State/Province Zip Country
Telephone
Credit Card Number Type: ❒Visa ❒Mastercard ❒Discover Exp. Date
Customer Signature
Item # U.S. Cost Each Qty Amount
U.S. Subtotal
(Tax if Applicable)
Shipping/Handling
Total
Optional Accessories
You can find accessories at your local Cobra®dealer,
or in the U.S.A. you can order directly from Cobra.
®
Ordering From U.S.
Call 773-889-3087 for pricing or visit www.cobra.com.
For credit card orders, complete and return this order
form to fax number 773-622-2269. Or call 773-889-3087
(Press 1 from the main menu) 8:00 a.m. to 6:00 p.m. CT,
Monday through Friday.
Make check or money order payable to:
Cobra®Electronics, Attn: Accessories Dept.
6500 West Cortland Street, Chicago, IL 60707 USA
To order online, please visit our website: www.cobra.com
The Cobra®
line of quality
products includes:
CB Radios
microTALK®Radios
Radar/Laser Detectors
Safety Alert®Traffic
Warning Systems
Accessories
GPS (Global
Positioning System)
HighGear™Accessories
Amount Shipping/Handling*
$10.00 or less . . . . . $3.00
$10.01-$25.00 . . . . . $5.50
$25.01-$50.00 . . . . . $7.50
$50.01-$90.00 . . . . $10.50
$90.01-$130.00 . . . $13.50
$130.01-$200.00 . . $16.50
$200.01 plus . . . . . 10% of
purchase
Tax Table
Ohio, Wisconsin add 5%
Indiana, Michigan add 6%
Illinois add 8.75%
*For AK, HI and PR add additional $26.95 for FedEx Next Day or
$10.95 for FedEx 2nd Day. Excludes weekends and holidays shipments.
Please allow 2-3 weeks for delivery in the U.S. Prices subject to
change without notice.
•
Formularios de
pedidos y accesorios
Ayuda a clientes
Nombre
Dirección (no se aceptan apartados postales)
Ciudad Estado o provincia Código postal País
Teléfono
Número de tarjeta de crédito Tipo: ❒Visa ❒ Mastercard ❒ Discover Fecha de vencimiento
Firma del cliente
Núm. artículo Costo unitario en EE.UU. Cantidad Importe
Subtotal en EE.UU.
(Impuesto,
de ser aplicable)
Manejo y envío
Total
Accesorios optativos
Encontrará accesorios de alta calidad con los distribuidores
Cobra®de su localidad. En Estados Unidos, también puede
colocar su pedido directamente con Cobra®.
Pedidos en los EE.UU.
Llame al 773-889-3087 para conocer los precios o visite
www.cobra.com.
Para pedidos con tarjeta de crédito,
llene este formulario de pedidos y envíelo por fax al
773-622-2269. También puede llamar al 773-889-3087
(marque 1 en el menú principal) de 8:00 a.m. a 6:00 p.m.,
hora del centro de EE.UU., de lunes a viernes.
Elabore el cheque o giro monetario a la orden de:
Cobra®Electronics, Attn: Accessories Dept.
6500 West Cortland Street, Chicago, IL 60707 USA
Para efectuar pedidos vía Internet,
visite nuestro sitio en www.cobra.com
La línea de
productos de
calidad Cobra®
también incluye:
Radios de banda
ciudadana (CB)
radios microTALK®
detectores de
radar y láser
sistemas de
advertencia de
tráfico Safety Alert®
GPS
accesorios HighGear™
Importe Manejo y envío*
$10,00 o menos. . . . $3,00
$10,01-$25,00 . . . . . $5,50
$25,01-$50,00 . . . . . $7,50
$50,01-$90,00 . . . . $10,50
$90,01-$130,00 . . . $13,50
$130,01-$200,00 . . $16,50
$200,01 plus. . . . . 10% de
la compra
Tabla de impuestos
Ohio y Wisconsin, agregue el 5%
Indiana y Michigan, agregue el 6%
Illinois, agregue el 8,75%
*Para envíos a Alaska, Hawaii y Puerto Rico, agregue $26,95 para envíos
por FedEx para el día siguiente o $10,95 para envíos por FedEx para el
día subsiguiente. Excluye los fines de semana y días festivos.
Plazo de entrega dentro de los EE.UU. será entre 2 y 3 semanas.
Los precios están sujetos a cambios sin aviso previo. •
