users manual

2English

Making Life Easier & Safer

PR240

PR350WX

2-WAY RADIO MODELS

Nothing Comes Close To A Cobra™English

Owner’s Manual

Introduction

Staying in touch with your family and friends is

convenient and easy when using your microTALK®

radio. Some of the many uses you will discover include:

Communicating with others while hiking, biking, and working; keeping

track of family and friends at a crowded public event; checking with

travel companions in another car; talking with neighbors; arranging

meeting spots with others while shopping at the mall.

Secure your microTALK®

radio while on the go.

Carrying your microTALK®radio with you is

easy when using the belt clip or wrist strap.

The belt clip easily attaches to your belt, purse,

or backpack. Simply squeeze the clip and place

it where you prefer.

For Assistance In the U.S.A.

In this user’s manual, you should find all the information you need

to operate your microTALK®radio. If you require further assistance

after reading this manual, Cobra®Electronics offers the following

customer assistance services:

Automated Help Desk

English only. 24 hours a day, 7 days a week 773-889-3087 (phone).

Customer Assistance Operators

English and Spanish. 8:00 a.m. to 6:00 p.m. CT,

Monday through Friday (except holidays) 773-889-3087 (phone).

Questions

English and Spanish. Faxes can be received at 773-622-2269 (fax).

Technical Assistance

English only. www.cobra.com (on-line: Frequently Asked Questions).

English and Spanish. productinfo@cobra.com (e-mail).

For Assistance Outside the U.S.A.

Contact Your Local Dealer

Belt Clip

Wrist Strap

Customer Assistance

6500 West Cortland Street

Chicago, Illinois 60707 USA

www.cobra.com

Printed in Philippines

Part No. 480-048-P

RADIO

BIDIRECCIONAL

MODEL

Nada se compara a Cobra™Español

Manual del

propietario

PR240

PR350WX

Printed in Philippines

Part No. 480-048-P 2Español

Una vida más sencilla y segura

Introducción

Es muy fácil y práctico mantenerse en contacto con su familia y

sus amigos cuando utiliza un radio microTALK®.Usted descubrirá

gran número de aplicaciones para el radio, como las siguientes:

comunicación con otras personas en excursiones, paseos el bicicleta o en el

trabajo; contacto con la familia y los amigos en concurridos eventos públicos,

comunicación con compañeros de viaje en otro automóvil; conversaciones con

los vecinos; ponerse de acuerdo en un punto de reunión durante una visita al

centro comercial.

Transporte el radio

microTALK®con seguridad.

Es muy fácil transportar el radio microTALK®con la

pinza para cinturón o la correa para la muñeca.

La pinza se sujeta fácilmente al cinturón, un bolso o

una mochila. Sólo tiene que oprimir la pinza y

colocarla donde quiera.

Ayuda en los EE.UU.

En este manual para el usuario encontrará toda la información necesaria para

usar el radio microTALK®. Si después de leer este manual requiere ayuda

adicional, Cobra®Electronics ofrece los siguientes servicios de apoyo a clientes:

Centro automatizado de ayuda

Únicamente inglés. Disponible las 24 horas del día, todos los días del año,

llamando por teléfono al 773-889-3087.

Operadores de ayuda al cliente

Inglés y español. Disponibles de 8:00 a.m. a 6:00 p.m., hora del centro de

EE.UU., de lunes a viernes (excepto días festivos), llamando por teléfono al

773-889-3087.

Preguntas

Inglés y español. Puede enviar sus preguntas por fax al 773-622-2269.

Ayuda técnica

Únicamente inglés. www.cobra.com (en Internet: preguntas más frecuentes).

Inglés y español. Corre electrónico: productinfo@cobra.com

Ayuda fuera de los EE.UU.

Comuníquese con un distribuidor de productos Cobra®de su localidad.

6500 West Cortland Street

Chicago, Illinois 60707 USA

www.cobra.com

Pinza para el cinturón

Correa para la muñeca

Ayuda a clientes

4English

Product Features

Operation

Customer Assistance

Warranty

Nothing comes close to a Cobra™

IntroductionIntroduction

Caring for Your microTALK®Radio •

Your microTALK®radio will give you years of trouble-free service if

cared for properly. Handle the radio gently. Keep the radio away from

dust. Never put the radio in water or in a damp place. Avoid exposure

to extreme temperatures.

Batteries •

To Install or Replace Batteries:

1. Remove belt clip by releasing belt clip

latch and sliding clip up.

2. Pull down on the Battery Door Latch to

remove the battery compartment cover.

3. Insert four AAA batteries. (Always use high

quality alkaline batteries.) Position batteries

according to polarity markings.

4. Replace Battery Compartment cover and belt clip.

See information on page 20 for optional

battery pack and desktop charger

accessories ordering instructions.

Backlit LCD

Display

Battery

Compartment

Battery Door

Latch

Belt Clip

Wrist Strap

Connector

3English

Product Features

Introduction

Lock

Button

Backlit

LCD

Display

Channel

Up/Down

Buttons

Speaker/

Microphone

Call

Button

Mode

Button

Antenna

Volume Up/

Down Button(s)

External Speaker/

Microphone Jack

Important FCC Licensing Information

This radio operates on General Mobile Radio

Service (GMRS) frequencies which require a

Federal Communications Commission (FCC)

license. See page 16 for licensing and other

related information.

Light/Max

Range

Button

Talk

Button

On/Off

Power

Button

Receive/

Transmit

Tower Icon

Low

Power Icon

Lock

Icon

NOAA All

Hazards Alert Icon

(PR 350 WX only) Roger

Beep Icon

Battery

Low

Main

Channel

Numbers

Power

Saver Icon

CTCSS Privacy

Code Numbers

Scan Icon

NOAA All

Hazards Radio Icon

(PR 350 WX only)

Features

• Two-Way Radio

With a range up

to five (5) miles

(8 km).

• 22 Channels

Seven shared

with FRS/GMRS,

seven FRS only

eight GMRS only.

• 38 Privacy Codes

• 10 Channel NOAA

All Hazards Radio

(PR 350 WX only)

• NOAA All

Hazards Alert

(PR 350 WX only)

• Backlit LCD

Display

• Scan

(channel,

privacy code)

• Water Resistant

• Speaker/

Microphone Jack

• Call Alert

(10 selectable

tones)

• Lock

• “Roger Beep”

(selectable On/Off)

• Battery/

Power Saver

• Auto Squelch

• Maximum

Range Extender

• Belt Clip

• Wrist Strap

Insert Batteries

Pull Down Lock Latch

Remove Belt Clip

The Basics to Get You Started

Your microTALK®radio is easy to use.

To get started, simply:

1. Press the Power button to turn On your radio.

2. Press the Channel Up or Channel Down

button to select a channel.

Both radios must be tuned to the

same channel to communicate.

3. Press and hold the Talk button while

speaking into the microphone.

4. When finished talking, release the Talk

button and listen for a response.

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra™

Operation

Scrolling Through

the Mode Function •

By scrolling through the Mode function, you will

be able to select or turn On preferred features of

your microTALK®radio. When scrolling through

the Mode function, your radio features will be

displayed in the same predetermined order:

PR 240

Set Privacy Code

Set Channel Scan

Set Privacy Code Scan

Set Call Tones

Set “Roger Beep” On/Off

PR 350 WX

Set Privacy Code

Set NOAA All Hazard Radio Channels

Set NOAA All Hazard Alert

Set Channel Scan

Set Privacy Code Scan

Set Call Tones

Set “Roger Beep” On/Off

Channels •

To Select a Channel:

1. With the radio on, select any of the

22 channels by pressing the Channel Up

or Channel Down button.

Both radios must be tuned to the

same channel to communicate.

Channels 1 through 7 are shared with FRS/

GMRS. Channels 8 through 14 are FRS only.

Channels 15 through 22 are GMRS only.

See page 17 for FRS/GMRS frequency

allocations and compatibility charts.

Turning On Your microTALK®Radio •

To Turn On Your Radio:

1. Press and hold the Power button until you

hear a series of audible tones indicating the

radio is On.

Your microTALK®radio is now in Standby Mode,

ready to receive transmissions. The radio is

always in Standby Mode except when the Talk,

Call or Mode buttons are pressed.

Battery Low •

When battery power is low, the Battery Low icon

will blink. Your batteries should be replaced or

recharged, if using rechargeable batteries.

Auto Battery Save •

Your microTALK®radio has a unique circuit

designed to extend battery life. If there are no

transmissions within ten (10) seconds, the radio

will automatically switch to Battery Save Mode

and Power Saver icon will flash in the display.

This will not affect the radio’s ability to receive

incoming transmissions.

Communicating with Another Person •

To Talk To Another Person:

1. Press and hold the Talk button.

2. With the microphone about two (2) inches (5 cm)

from your mouth, speak in a normal voice.

3. Release the Talk button when you are finished

talking and listen for a response.

You cannot receive incoming calls while pressing

the Talk button.

Both radios must be tuned to

the same channel to communicate.

6English

Using Your Radio

Operation

Mode Button

Channel Button

Channel Number

On/Off Power

Battery Low

Battery Save Mode

Talk Button

2 inches (5 cm)

From Mouth

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra™

Operation

Volume •

To Adjust the Volume:

1. Press the Volume Up or Volume Down button.

A double beep sound is used to indicate

the minimum and maximum volume levels

(L1 through L7).

Call Button •

To Alert Another Person That You Are Calling:

1. Press and release the Call button.

The other person will hear a two (2)

second call tone. You cannot send or

receive transmissions during the two (2)

second call tone.

See page 13 on how to select

between ten (10) call tone settings.

NOAA* All Hazards Radio Channels

and Alert (PR 350 WX only) •

You can use your microTALK®radio to listen to

NOAA All Hazards Radio channels transmitting

in your area.

You can also program your microTALK®

radio to sound a tone alert when a local NOAA

channel activates an Emergency All Hazards

Alert. This will warn you of weather, chemical,

and other civilian emergencies.

*National Oceanographic and Atmospheric Administration

Hazards Radio Icon

8English

Using Your Radio

Operation

CTCSS Privacy Codes •

CTCSS (Continuous Tone Coded Squelch System)

is an advanced tone coding system allowing you

to select one of 38 privacy codes to reduce

interference from other users on the channel.

If you are using a privacy code, both

radios must be tuned to the same channel

and privacy code to communicate. Each

channel will remember the last privacy

code you selected.

To Select a Privacy Code:

1. After selecting a channel, press the Mode

button until the small numbers next to the

channel number flash on the LCD.

2. Press the Channel Up or Channel Down button

to select a privacy code. You can hold the Up

or Down button for fast advance.

3. When your desired privacy code is displayed:

a. Press the Mode button to enter the new

setting and proceed to other functions.

b. Press the Lock button to enter the new

setting and return to Standby Mode.

c. Do not press any buttons for 15 seconds

to enter the new setting and return to

Standby Mode.

Listening for a Response •

When You are Finished Talking:

1. Release the Talk button to receive incoming

transmissions. Your microTALK®radio is

always in Standby Mode while the Talk or

Call buttons are not pressed.

Listening

Call Button

Volume Button

Volume Level

Privacy Code

Mode Button

Channel Button

Hazards Alert Icon

38 Privacy Codes

10 English

Using Your Radio Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra™

OperationOperation

To Listen to All Hazards Radio Channels

(PR 350 WX only):

1. Press the Mode button until the Weather

(All Hazards Radio) icon and the currently

selected All Hazards Radio channel are

displayed.

2. Use the Channel Up or Channel Down

button to change All Hazards Radio channels.

3. Weather (All Hazards Radio) icon will continue

to be displayed when All Hazards Radio is On.

a. Press the Mode button to proceed

to other functions.

b. Press the Lock button to exit All Hazards

Radio channel mode and return to

Standby Mode.

To Turn On All Hazards Alert (PR 350 WX only):

1. Press the Mode button until the Alert icon

flashes and the current On or Off setting is

displayed.

2. Press the Channel Up or Channel Down button

to turn All Hazards Alert On or Off.

3. Alert icon will continue to be displayed when

All Hazards Alert is On.

a. Press the Mode button to enter the new

setting and proceed to other functions.

b. Press the Lock button or do not press any

buttons for 15 seconds to enter the new

setting and return to Standby Mode.

c. Press the Talk button to keep original

settings and return to Standby Mode.

Scan •

Your microTALK®radio can automatically scan

main channels (1 through 22) or the privacy codes

(00 through 38) within one (1) main channel.

To Scan Main Channels:

1. Press the Mode button until the Scan icon and

the main channel number flashes on the display.

2. Press the Channel Up or Channel Down button

to begin scanning the main channels.

The radio ignores privacy codes while

scanning main channels.

3. The Scan icon will continue to be displayed

when Scan is On. Your radio will continue to

scan all main channels and stop if an incoming

transmission is detected.Your radio will remain

on that channel for ten (10) seconds.

During this time, you can:

a. Press and hold the Talk button and communicate

with others. Your radio will remain on that

channel and return to Standby Mode.

b. Press the Channel Up or Channel Down

button to resume scanning channels.

c. Press the Mode button to proceed to

privacy code scanning (see page 12

for further details).

If you press the Talk button while scanning,

and not within ten (10) seconds of receiving

a transmission, you will transmit on the last

channel you transmitted or received on.

If you do not press any button within ten (10)

seconds, your radio will automatically resume

scanning main channels.

Hazards Alert Icon

Mode Button

Channel Button

Mode Button

Channel Button

Hazards Radio Icon

Mode Button

Channel Button

Scan Channels

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra™

OperationOperation

12 English

Product Features

To Scan Privacy Codes:

1. While in Standby Mode, press the Channel Up

or Channel Down button to choose the main

channel you wish to scan.

2. Press the Mode button until the Scan icon and

the privacy code number flashes on the display.

3. Press the Channel Up or Channel Down button

and your radio will begin scanning privacy

codes within the main channel you selected.

4. The Scan icon will continue to be displayed

when Scan is On. Your radio will continue

to scan privacy codes and stop an incoming

transmission is detected. Your radio will remain

on that channel and privacy code for ten (10)

seconds. During this time, you can:

a. Press and hold the Talk button to

communicate with others. Your radio

will remain on that channel and privacy

code and return to Standby Mode.

b. Press the Channel Up or Channel Down

button to resume scanning privacy codes.

c. Press the Mode button to proceed to

other functions.

If you press the Talk button while scanning,

and not within ten (10) seconds of receiving

a transmission, you will transmit on the last

channel you transmitted or received on.

If you do not press any button within ten (10)

seconds, your radio will automatically resume

scanning privacy codes.

10 Call Tone Settings •

You can choose between ten (10) different call

tone settings to transmit a unique call alert.

To Change a Call Tone Setting:

1. Press the Mode button until the letter “C”

and the current call tone number (1 through

10) is displayed. The current call tone will

sound for one (1) second.

2. Press the Channel Up or Channel Down

button to hear the other call tone settings.

3. a. Press the Mode button to enter the new

setting and proceed to other functions.

b. Press the Lock button to enter the new

setting and return to Standby Mode.

“Roger Beep” Confirmation Tone •

Your listener will hear an audible tone when you

release the Talk button. This alerts the other party

that you are finished talking and it is OK for them

to speak. This feature can be turned On or Off.

To Turn “Roger Beep” On or Off:

When turning On your microTALK®radio

for the first time, “Roger Beep” will be On.

1. Press the Mode button until the Roger

Beep icon flashes. The current On or

Off setting is displayed.

2. Press the Channel Up or Channel Down

button to select “Roger Beep” On or Off.

3. a. Press the Mode button to enter the new

setting and proceed to other functions.

b. Press the Lock button to enter the new

setting and return to Standby Mode.

The setting you select will be saved when you

turn your radio Off and On again. When the

Roger Beep is On, the Roger Beep icon will

be displayed.

Channel Button

Mode Button

Select Channel

Scan Privacy Codes

Call Tone Setting

Mode Button

Channel Button

Roger Beep Off

Mode Button

Channel Button

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra™

Operation

14 English

Using Your Radio

Display Illumination •

To Illuminate Your Display:

1. Press and release the Light/Max Range button

to illuminate the display for ten (10) seconds.

Auto Squelch/Maximum Range •

Your microTALK®radio is equipped with Auto

Squelch, which automatically shuts Off weak

transmissions and unwanted noise due to

terrain, conditions, or if you’ve reached your

maximum range limit.

You can temporarily turn Off Auto Squelch or

turn On Maximum Range Extender, allowing all

signals to be received and extending the maximum

range of your radio.

To Temporarily Turn Off Auto Squelch:

1. Press and hold the Light/Max Range button

up to five (5) seconds. Hearing two (2) beeps

indicates the Maximum Range Extender is

On (see below).

To Turn Maximum Range Extender On:

1. Press and hold the Light/Max Range button

for five (5) seconds. You will hear two (2) beeps

indicating the Maximum Range Extender is On.

To Turn Maximum Range Extender Off:

1. Press and release the Light/Max Range

button or change channels.

Lock Function •

The Lock function locks the Channel,

Mode, and Power buttons to prevent

accidental operation.

To Turn the Lock On or Off:

1. Press and hold the Lock button for

two (2) seconds.

A double beep sound is used to confirm

your Lock On or Off request. When in

Lock Mode, the Lock icon will be displayed.

Speaker/Microphone Jack •

Your microTALK®radio can be fitted with

an external Speaker/Microphone, freeing

your hands for other tasks. Contact your

local Cobra®dealer or Cobra®directly

for optional accessories. Only Cobra®

authorized accessories are recommended.

To Attach Your Speaker/Microphone:

1. Open the Speaker/Microphone tab on

top of your microTALK®radio.

2. Insert the plug into the Speaker/

Microphone jack.

Operation

Lock Icon

Lock Button

Light/Max Range

Speaker/Microphone

Customer Assistance WarrantyIntroduction

Nothing comes close to a Cobra™

Operation

16 English

Using Your Radio

microTALK®Range •

Your microTALK®radio has a range of

up to five (5) miles (8 km). Your range will

vary depending on terrain and conditions.

In flat, open country your radio will

operate at maximum range.

Buildings and foliage in the path of the

signal can reduce the range of the radio.

Dense foliage and hilly terrain will

further reduce the range of the radio.

On FRS channels 8 through 14, your radio

automatically switches to low power, which

will limit the range the radio can communicate.

Remember, you can achieve maximum

range by using Maximum Range

Extender. See page 14 for details.

Reduced Range

Maximum Range

Operation

General Specifications •

Nominal

Unit

Nominal

Unit

C.Transmitter

1. Power

GMRS . . . . . . . . . . . . . . . . . . . .W 1

FRS Only . . . . . . . . . . . . . . . . .mW 500

2. Carrier Frequency Stability . . . ±Hz 500

3. Modulation Limiting . . . . . . . . KHz 2.5

4. Carrier Attack Time . . . . . . . . . mS 80

5. Audio Frequency Response

@ 300 HZ . . . . . . . . . . . . . . . . . dB -12

@ 2500 HZ . . . . . . . . . . . . . . . . dB +6

6. Audio Distortion . . . . . . . . . . . . % 3

7. Hum Noise . . . . . . . . . . . . . . . . dB 30

8. Transient Frequency Behavior

a) TX On . . . . . . . . . . . . . . . . . mS 30

b) TX Off . . . . . . . . . . . . . . . . . mS 5

A. FRS/GMRS

Frequency

Allocation and

Compatibility

Important: Please note that Cobra®GMRS

models with 15 channels may designate

different channel numbers for the same

frequency. For example, a Cobra®15 channel

GMRS model would need to be tuned to

channel 11 in order to communicate with

a 22 channel GMRS tuned to channel 15.

Please refer to the chart below for channel/

frequency number compatibility.

A = Channel No. For

22 Channel GMRS Models

B = Channel No. For 15

Channel GMRS Models

C = Type of Radio Service

D = Frequency in MHz

E = Power in Watts

AB C D E

1 1 FRS/GMRS 462.5625 1.0

2 2 FRS/GMRS 462.5875 1.0

3 3 FRS/GMRS 462.6125 1.0

4 4 FRS/GMRS 462.6375 1.0

5 5 FRS/GMRS 462.6625 1.0

6 6 FRS/GMRS 462.6875 1.0

7 7 FRS/GMRS 462.7125 1.0

8 FRS 467.5625 0.5

9 FRS 467.5875 0.5

10 FRS 467.6125 0.5

11 FRS 467.6375 0.5

12 FRS 467.6625 0.5

13 FRS 467.6875 0.5

14 FRS 467.7125 0.5

15 11 GMRS 462.5500 1.0

16 8 GMRS 462.5750 1.0

17 12 GMRS 462.6000 1.0

18 9 GMRS 462.6250 1.0

19 13 GMRS 462.6500 1.0

20 10 GMRS 462.6750 1.0

21 14 GMRS 462.7000 1.0

22 15 GMRS 462.7250 1.0

B. Receiver

1. Sensitivity

For 12 DB SINAD . . . . . . . . . . dBm -121

For Call Signal Detection . . . . dBm -121

2. Max. Audio Output

@10% THD . . . . . . . . . . . . . . . mW 200

3. Max. S/N Ratio

@ 1mV RF Input . . . . . . . . . . . dB 50

4. Squelch

a) Sensitivity . . . . . . . . . . . . . . dBm -121

b) Attack Time . . . . . . . . . . . . . mS 150

c) Closing Time . . . . . . . . . . . . mS 200

5. Audio Frequency Response

@ 300 HZ . . . . . . . . . . . . . . . . . dB -3

@ 2500 HZ . . . . . . . . . . . . . . . . dB -10

6. Signal Displacement BW . . . +/-KHZ 5

7. Adjacent Channel Rejection . . . dB 40

8. Intermodulation Rejection . . . . dB 65

9. Spurious Response Rejection . dB 55

D. Power Supply

1. Battery Life (5:5:90 RATIO)

With Alkaline Batteries . . . . . . . HR 24

2. Battery Operating Range . . . . . . V 4.2 - 6.0

Nominal

Unit

Operation WarrantyIntroduction

Nothing comes close to a Cobra™

Customer Assistance

18 English

Licensing,Assistance &Warranty

IMPORTANT NOTICE: FCC LICENSE REQUIRED

This two-way radio operates on GMRS (General Mobile Radio Service) frequencies which

require an FCC (Federal Communications Commission) license. A user must be licensed prior

to operating on channels 1 through 7 or 15 through 22, which comprise the GMRS channels

of this radio. Serious penalties could result for unlicensed use of GMRS channels, in violation

of FCC rules, as stipulated in the Communications Act’s Sections 501 and 502 (amended).

Licensed users will be issued a call sign by the FCC, which should be used for station

identification when operating this radio. GMRS users should also cooperate by engaging

in permissible transmissions only, avoiding channel interference with other GMRS users,

and being prudent with the length of their transmission time.

For licensing information and application forms, please call the FCC Hotline at

800-418-FORM. Request form #159 and form #605. Questions regarding the license

application should be directed to the FCC at 888-CALL-FCC. Additional information

is available on the FCC’s website at www.fcc.gov.

Safety Information for microTALK®Radios

Your wireless handheld portable transceiver contains a low power transmitter. When the Talk

button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate

at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions

(FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices.

Important:

To maintain compliance with the FCC’s RF guidelines, hold the transmitter at least 2 inches

(5 centimeters) from your face and speak in a normal voice, with the antenna pointed up

and away. If you wear the handset on your body while using the headset accessory, use only

the Cobra®supplied belt clip for this product and ensure that the antenna is at least 1 inch

(2.5 centimeters) from your body while transmitting. If the distance between the antenna

and the body is LESS THAN 1.0 inch (2.5 cm), DO NOT USE THIS DEVICE IN THE BODY

WORN CONFIGURATION. Use only the supplied antenna. Unauthorized antennas, modifications,

or attachments could damage the transmitter and may violate FCC regulations.

Normal Position:

Hold the transmitter approximately 2 inches from your face and speak in a normal voice,

with the antenna pointed up and away.

This device complies with part 15 of the FCC rules. Operation is subject

to the condition that this device does not cause harmful interference.

FCC Warnings: Replacement or substitution of transistors, regular diodes or

other parts of a unique nature, with parts other than those recommended by

Cobra®may cause a violation of the technical regulations of part 95 of the FCC

Rules, or violation of type acceptance requirements of part 2 of the Rules.

Customer Assistance

If you have any questions about operation or installing

your new Cobra®product, or if you are missing parts…

Please call Cobra®first! DO NOT RETURN THIS PRODUCT

TO THE STORE! See customer service on page 2.

Product Service Questions

If your product should require factory service, please call Cobra®first before sending your radio.

This will ensure the fastest turn-around time on your repair. You may be asked to send your radio to the

Cobra®factory. It will be necessary to furnish the following to have the product serviced and returned.

1) For Warranty Repair include some form of proof-of-purchase, such as a mechanical reproduction

or carbon of a sales receipt. If you send the original receipt, it cannot be returned; 2) Send the entire

product; 3) Enclose a description of what is happening with the radio. Include a typed or clearly

printed name and address of where the radio is to be returned; 4) Pack radio securely to prevent

damage in transit. If possible, use the original packing material; 5) Ship prepaid and insured by way

of a traceable carrier such as United Parcel Service (UPS) or First Class Mail to avoid loss in transit

to Cobra®Factory Service, Cobra®Electronics Corporation, 6500 West Cortland Street, Chicago,

Illinois 60707 USA; 6) If the radio is in warranty, upon receipt of your radio it will either be

repaired or exchanged depending on the model. Please allow approximately 3 – 4 weeks before

contacting Cobra®for status. If the radio is out of warranty, a letter will automatically be sent

informing you of the repair charge or replacement charge. If you have any questions,

please call 773-889-3087 for assistance.

Limited 2-Year Warranty For Products Purchased in the U.S.A.

Cobra®Electronics Corporation warrants that its Cobra®GMRS Radios, and the component parts

thereof, will be free of defects in workmanship and materials for a period of two (2) years from the

date of first consumer purchase. This warranty may be enforced by the first consumer purchaser,

provided that the product is utilized within the U.S.A. Cobra®will, without charge, repair or replace,

at its option, defective GMRS radios, products or component parts upon delivery to the Cobra®

Factory Service department, accompanied by proof of the date of first consumer purchase, such

as a duplicated copy of a sales receipt. You must pay any initial shipping charges required to ship

the product for warranty service, but the return charges will be at Cobra®’s expense, if the product

is repaired or replaced under warranty. This warranty gives you specific legal rights, and you may

also have other rights which may vary from state to state.

Exclusions: This limited warranty does not apply: 1) To any product damaged by accident;

2) In the event of misuse or abuse of the product or as a result of unauthorized alterations or

repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the owner of the

product resides outside the U.S.A.

All implied warranties, including warranties of merchantability and fitness for a particular purpose

are limited in duration to the length of this warranty. Cobra®shall not be liable for any incidental,

consequential or other damages; including, without limitation, damages resulting from loss of

use or cost of installation. Some states do not allow limitations on how long an implied warranty

lasts and/or do not allow the exclusion or limitation of incidental or consequential damages,

so the above limitations may not apply to you.

For products purchased outside the U.S.A., please contact your local dealer for

warranty information.

Warranty

18 English

Licensing, Assistance & Warranty
