General Specifications •
Nominal
Unit
Nominal
Unit
C.Transmitter
1. Conducted Power
GMRS . . . . . . . . . . . . . . . . . . . .W 3
FRS Only . . . . . . . . . . . . . . . . .mW 500
2. Carrier Frequency Stability . . . ±Hz 500
3. Modulation Limiting . . . . . . . . KHz 2.5
4. Carrier Attack Time . . . . . . . . . mS 80
5. Audio Frequency Response
@ 300 HZ . . . . . . . . . . . . . . . . . dB -12
@ 2500 HZ . . . . . . . . . . . . . . . . dB +6
6. Audio Distortion . . . . . . . . . . . . % 3
7. Hum Noise . . . . . . . . . . . . . . . . dB 30
8. Transient Frequency Behavior
a) TX On . . . . . . . . . . . . . . . . . mS 30
b) TX Off . . . . . . . . . . . . . . . . . mS 5
A. FRS/GMRS
Frequency
Allocation and
Compatibility
Important: Please note that Cobra®GMRS
models with 15 channels may designate
different channel numbers for the same
frequency. For example, a Cobra®15 channel
GMRS model would need to be tuned to
channel 11 in order to communicate with
a 22 channel GMRS tuned to channel 15.
Please refer to the chart below for channel/
frequency number compatibility.
A = 22 Channel GMRS
Channel No. Displayed
B = Channel No. For 15
Channel GMRS Models
C = Type of Radio Service
D = Frequency in MHz
E = Power in Watts ERP
a = 3.0/2.0/0.5 (selectable)
b = 0.5
AB C D E
1 1 FRS/GMRS 462.5625 a
2 2 FRS/GMRS 462.5875 a
3 3 FRS/GMRS 462.6125 a
4 4 FRS/GMRS 462.6375 a
5 5 FRS/GMRS 462.6625 a
6 6 FRS/GMRS 462.6875 a
7 7 FRS/GMRS 462.7125 a
8 FRS 467.5625 b
9 FRS 467.5875 b
10 FRS 467.6125 b
11 FRS 467.6375 b
12 FRS 467.6625 b
13 FRS 467.6875 b
14 FRS 467.7125 b
15 11 GMRS 462.5500 a
16 8 GMRS 462.5750 a
17 12 GMRS 462.6000 a
18 9 GMRS 462.6250 a
19 13 GMRS 462.6500 a
20 10 GMRS 462.6750 a
21 14 GMRS 462.7000 a
22 15 GMRS 462.7250 a
B. Receiver
1. Sensitivity
For 12 DB SINAD . . . . . . . . . . dBm -121
For Call Signal Detection . . . . dBm -121
2. Max. Audio Output
@10% THD . . . . . . . . . . . . . . . mW 200
3. Max. S/N Ratio
@ 1mV RF Input . . . . . . . . . . . dB 50
4. Squelch
a) Sensitivity . . . . . . . . . . . . . . dBm -121
b) Attack Time . . . . . . . . . . . . . mS 150
c) Closing Time . . . . . . . . . . . . mS 200
5. Audio Frequency Response
@ 300 HZ . . . . . . . . . . . . . . . . . dB -3
@ 2500 HZ . . . . . . . . . . . . . . . . dB -10
6. Signal Displacement BW . . . +/-KHz 5
7. Adjacent Channel Rejection . . . dB 60
8. Intermodulation Rejection . . . . dB 65
9. Spurious Response Rejection . dB 55
D. Power Supply
1. Battery Life (5:5:90 RATIO)
With Alkaline Batteries . . . . . . . HR 24
2. Battery Operating Range . . . . . . V 4.2 - 6.0
Nominal
Unit
