Cobra Electronics PR990 FRS / GMRS TRANSCEIVER User Manual USERS MANUAL

Cobra Electronics Corporation FRS / GMRS TRANSCEIVER USERS MANUAL

USERS MANUAL

User’s Guide
2-WAY RADIO MODEL
PR990VP
Batteries and Charger
To Install or Replace Batteries:
1. Remove belt clip by releasing belt
clip latch and sliding clip up.
2. Pull down on the battery door
latch to remove the battery
compartment cover.
3. Insert the supplied four (4)
AAA rechargeable batteries
(also works with alkaline
batteries). Position batteries
according to polarity markings.
4. Replace battery compartment
cover and belt clip.
Lock Button
Locks buttons to prevent
accidental channel or
settings changes.
Charger Jack
Charger Jack (also works with
external speaker/microphones).
Printed in the Philippines Part No. 480-159-P
Battery
Compartment
Cover
Battery
Door Latch
Wrist Strap
Connector
Belt Clip
Antenna
Speaker/
Microphone
Backlit
LCD
Display
Talk Button
Press and hold to communicate with
others. With the microphone about
two (2) inches [five (5) cm] from
your mouth, speak in a normal voice.
Release the Talk button when you are
finished talking and listen for a response.
You cannot receive incoming calls while
pressing the Talk button.
NOTE Both radios must be tuned to
the same channel to communicate.
For Products Used in the U.S.A.
FCC Licensing Required
This 2-way radio operates on GMRS (General Mobile Radio Service) frequencies which require
an FCC (Federal Communications Commission) license. A user must be licensed prior to
operating on channels 1 through 7 or 15 through 22, which comprise the GMRS channels of
this radio. Serious penalties could result for unlicensed use of GMRS channels, in violation
of FCC rules, as stipulated in the Communication Act’s Sections 501 and 502 (amended).
Licensed users will be issued a call sign by the FCC, which should be used for station
identification when operating this radio. GMRS users should also cooperate by engaging
in permissible transmissions only, avoiding channel interference with other GMRS users,
and being prudent with the length of their transmission time.
For licensing information and application forms, please call the FCC Hotline at 800-418-FORM.
Request form #159 and form #605. Questions regarding the license application should be
directed to the FCC at 888-CALL-FCC. Additional information is available on the FCC’s
website at www.fcc.gov.
Safety Information for microTALK®Radios
Your wireless handheld portable transceiver contains a low power transmitter. When the Talk
button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate
at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commission
(FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices.
Important:
FCC RF Exposure Requirements: For body-worn operation, this radio has been tested and
meets the FCC RF exposure guidelines when used with Cobra®accessories supplied or
designated for this product. Use of other accessories may not ensure compliance with FCC
RF exposure guidelines. Use only the supplied antenna. Unauthorized antennas, modifications,
or attachments could damage the transmitter and may violate FCC regulations.
Normal Position:
Hold the transmitter approximately two (2) inches from your face and speak in a normal
voice, with the antenna pointed up and away.
For Products Used in Canada
Industry Canada Notice
Operation is subject to the following two (2) conditions: 1) this device may not cause
interference, and 2) this device must accept any interference, including interference that
may cause undesired operation of the device.
«IC» before the equipment certification number signifies that the Industry Canada technical
specifications were met. It does not guarantee that the certified product will operate to the
user’s satisfaction.
Product Service Questions
If you have any questions about operation or installing your new Cobra®product,
or if you are missing parts…
Please call Cobra®first! DO NOT RETURN THIS PRODUCT TO THE STORE!
See customer assistance above.
For Products Purchased in Canada
For out of warranty service, ship prepaid this product to: AVS Technologies Inc., 2100 Trans
Canada Hwy S., Montreal, Quebec, H9P 2N4. We reserve the right to repair or replace the
radio or charger with equivalent products. Please include the following information: Date of
Purchase, Model Number, Dealer Purchased From, Dealer Address, Dealer Phone Number.
For Products Purchased In The U.S.A.
If your product should require factory service, please call Cobra®first before sending your
radio, charger or batteries. This will ensure the fastest turn-around time on your repair. You
may be asked to send your products to the Cobra®factory. It will be necessary to furnish the
following to have the product serviced and returned. 1) For warranty repair include some
form of proof-of-purchase, such as a mechanical reproduction or carbon of a sales receipt.
If you send the original receipt, it cannot be returned. 2) Send the entire product. 3) Enclose
a description of what is happening with the product. Include a typed or clearly printed name
and address of where the product is to be returned. 4) Pack product securely to prevent
damage in transit. If possible, use the original packing material. 5) Ship prepaid and insured
by way of a traceable carrier such as United Parcel Service (UPS) or First Class Mail to
avoid loss in transit to: Cobra®Factory Service, Cobra®Electronics Corporation, 6500 West
Cortland Street, Chicago, Illinois 60707 U.S.A. 6) If the product is in warranty, upon receipt
of your product it will either be repaired or exchanged depending on the model.
Please allow approximately three (3) to four (4) weeks before contacting Cobra®for status.
If the product is out of warranty, a letter will automatically be sent informing you of the repair
charge or replacement charge. If you have any questions, please call 773-889-3087 for assistance.
For Products Purchased Outside The U.S.A. or Canada
Please contact your local dealer for product service information.
Limited 1-Year Warranty On Radio(s) And Charger
For Products Purchased in Canada
Your new Cobra®GMRS radio and charger are covered by a one (1) year replacement
warranty. If any manufacturing defect becomes apparent in these products within one (1)
year from the original date of purchase, they will be replaced. Please return the GMRS radio
or charger to your dealer with original or copy of dated proof of purchase. This warranty
does not cover damages due to careless handling, negligence, accident, abuse or failure to
follow operating instructions. Alteration of these products or defacing of the serial number
cancels all obligations of this warranty. This warranty gives you specified legal rights.
Additional warranty rights may be provided by law in some areas.
For Products Purchased In The U.S.A.
Cobra®Electronics Corporation warrants that its Cobra®GMRS radios and charger, and the
component parts thereof, will be free of defects in workmanship and materials for a period of
one (1) year from the date of first consumer purchase. This warranty may be enforced by the
first consumer purchaser, provided that the product is utilized within the U.S.A.
Cobra®will, without charge, repair or replace, at its option, defective GMRS radios, chargers,
products or component parts upon delivery to the Cobra®Factory Service department,
accompanied by proof of the date of first consumer purchase, such as a duplicated copy of
a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service,
but the return charges will be at Cobra®s expense, if the product is repaired or replaced
under warranty. This warranty gives you specific legal rights, and you may also have other
rights which may vary from state to state.
Exclusions: This limited warranty does not apply:
1) To any product damaged by accident; 2) In the event of misuse or abuse of the product or
as a result of unauthorized alterations or repairs; 3) If the serial number has been altered,
defaced, or removed; 4) If the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a particular
purpose are limited in duration to the length of this warranty. Cobra®shall not be liable for any
incidental, consequential or other damages; including, without limitation, damages resulting
from loss of use or cost of installation.
Some states do not allow limitations on how long an implied warranty lasts and/or do not
allow the exclusion or limitation of incidental or consequential damages, so the above
limitations may not apply to you.
For Products Purchased Outside The U.S.A. or Canada
Please contact your local dealer for warranty information.
90-Day Warranty On Batteries
For Products Purchased In The U.S.A. And Canada
Cobra®
, HighGear®
, microTALK®
, Safety Alert®Traffic Warning System,
Nothing comes close to a Cobra®and the snake design are registered
trademarks of Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™ and CobraMarine™ are trademarks
of Cobra Electronics Corporation, USA.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two (2) conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Warnings: Replacement or substitution of transistors, regular
diodes or other parts of a unique nature, with parts other than those
recommended by Cobra®may cause a violation of the technical
regulations of part 95 of the FCC rules, or violation of type acceptance
requirements of part 2 of the rules.
The Cobra®line of quality products includes:
CB Radios • microTALK®Radios • Radar/Laser Detectors • Safety Alert®Traffic Warning Systems •
Handheld GPS Receivers • Mobile GPS Navigation Systems • HighGear®Accessories •
CobraMarineVHF Marine Radios • Power Inverters • Accessories
Insert Batteries
Pull Down Lock Latch
Remove Belt Clip
To Charge Batteries in Radio:
1. Check to see that the batteries have
been inserted properly. See above
for battery installation instructions.
2. Insert round connector of wall charger/adapter into
the charge jack located at the top of the radio. The wall
charger/adapter has two round connectors which enables
you to charge either one or two radios at a time.
3. Plug the wall charger/adapter into electrical outlet.
It normally takes 15 hours to fully recharge batteries. It is
not recommended to recharge batteries more than 24 hours.
Estimated operation time on a full charge is 8 hours.
Use only the supplied rechargeable batteries and wall
charger/adapter for recharging your Cobra®microTALK®
radio. Non-rechargeable alkaline batteries can also be used.
Radio Charger Jack
On/Off Power Button
Press and hold until you
hear a series of audible tones
indicating the radio is on.
Hi•Low Power Button
On channels 1 – 7 or 15 – 22,
you may select between high
power (to extend range) or
low power (to save battery life).
Channels 8 – 14 are exclusively
low power.
Call Button
Press and release to alert
others that you are calling.
Light/Max Range Button
Press and release to illuminate the display for ten (10)
seconds. Press and hold to allow all signals to be received
and extend the maximum range of your radio. To turn off
max range extender, press and release the button again
or change channels.
Channel Up/Down
Button(s)
Volume Up/Down
Button(s)
For Customer Assistance In Canada or the U.S.A.
In this user’s guide, you should find all the information you need to operate your microTALK®radio. If you require
further assistance after reading this guide, Cobra®Electronics offers the following customer assistance services:
Making Life Easier And Safer
Staying in touch with your family and friends is convenient and easy when
using your microTALK®radio. Some of the many uses you will discover include:
Communicating with others while hiking, biking, and working; keeping track of
family and friends at a crowded public event; checking with travel companions
in another car; talking with neighbors; arranging meeting spots with others
while shopping at the mall.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators English and Spanish.
8:00 a.m. to 6:00 p.m. CT, Monday through Friday
(except holidays) 773-889-3087 (phone).
Questions English and Spanish.
Faxes can be received at 773-622-2269 (fax).
Technical Assistance English only.
www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo@cobra.com (e-mail).
For Assistance Outside Canada,
the U.S.A. or in French
Contact Your Local Dealer
Channel Numbers
While in Standby mode or when selecting a
channel, shows current channel (1 through 22).
When adjusting the volume,
shows current level (1 through 7).
Lock Icon
Visible when Lock button
has been engaged.
Power Saver
Icon
Your microTALK®
radio has a unique circuit
designed to extend battery
life. If there are no
transmissions within
ten (10) seconds, the radio
will automatically switch to
Power Saver mode and the
Power Saver icon will blink.
This will not affect the
radio’s ability to receive
incoming transmissions.
Transmit/Receive Icon
Visible when transmitting
or receiving a message. Low Power Icon
Illuminates when in
Low Power mode. See
“Hi•Low Power Button”
for more details.
Battery Low Icon
Icon blinks when batteries should be
recharged (only rechargeable batteries)
or replaced (alkaline batteries).
Channel Numbers
While in Standby mode or when selecting a
channel, shows current channel (1 through 22).
When adjusting the volume,
shows current level (1 through 7).
User’s Guide
2-WAY RADIO MODEL
PR990VP
Batteries and Charger
To Install or Replace Batteries:
1. Remove belt clip by releasing belt
clip latch and sliding clip up.
2. Pull down on the battery door
latch to remove the battery
compartment cover.
3. Insert the supplied four (4)
AAA rechargeable batteries
(also works with alkaline
batteries). Position batteries
according to polarity markings.
4. Replace battery compartment
cover and belt clip.
Lock Button
Locks buttons to prevent
accidental channel or
settings changes.
Charger Jack
Charger Jack (also works with
external speaker/microphones).
Lock Icon
Visible when Lock button
has been engaged.
Low Power Icon
Illuminates when in
Low Power mode. See
“Hi•Low Power Button”
for more details.
Power Saver
Icon
Your microTALK®
radio has a unique circuit
designed to extend battery
life. If there are no
transmissions within
ten (10) seconds, the radio
will automatically switch to
Power Saver mode and the
Power Saver icon will blink.
This will not affect the
radio’s ability to receive
incoming transmissions.
Transmit/Receive Icon
Visible when transmitting
or receiving a message.
Printed in the China Part No. 480-176-P
Battery
Compartment
Cover
Battery
Door Latch
Wrist Strap
Connector
Belt Clip
Antenna
Speaker/
Microphone
Backlit
LCD
Display
Talk Button
Press and hold to communicate with
others. With the microphone about
two (2) inches [five (5) cm] from
your mouth, speak in a normal voice.
Release the Talk button when you are
finished talking and listen for a response.
You cannot receive incoming calls while
pressing the Talk button.
NOTE Both radios must be tuned to
the same channel to communicate.
For Products Used in the U.S.A.
FCC Licensing Required
This 2-way radio operates on GMRS (General Mobile Radio Service) frequencies which require
an FCC (Federal Communications Commission) license. A user must be licensed prior to
operating on channels 1 through 7 or 15 through 22, which comprise the GMRS channels of
this radio. Serious penalties could result for unlicensed use of GMRS channels, in violation
of FCC rules, as stipulated in the Communication Act’s Sections 501 and 502 (amended).
Licensed users will be issued a call sign by the FCC, which should be used for station
identification when operating this radio. GMRS users should also cooperate by engaging
in permissible transmissions only, avoiding channel interference with other GMRS users,
and being prudent with the length of their transmission time.
For licensing information and application forms, please call the FCC Hotline at 800-418-FORM.
Request form #159 and form #605. Questions regarding the license application should be
directed to the FCC at 888-CALL-FCC. Additional information is available on the FCC’s
website at www.fcc.gov.
Safety Information for microTALK®Radios
Your wireless handheld portable transceiver contains a low power transmitter. When the Talk
button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate
at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commission
(FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices.
Important:
FCC RF Exposure Requirements: For body-worn operation, this radio has been tested and
meets the FCC RF exposure guidelines when used with Cobra®accessories supplied or
designated for this product. Use of other accessories may not ensure compliance with FCC
RF exposure guidelines. Use only the supplied antenna. Unauthorized antennas, modifications,
or attachments could damage the transmitter and may violate FCC regulations.
Normal Position:
Hold the transmitter approximately two (2) inches from your face and speak in a normal
voice, with the antenna pointed up and away.
For Products Used in Canada
Industry Canada Notice
Operation is subject to the following two (2) conditions: 1) this device may not cause
interference, and 2) this device must accept any interference, including interference that
may cause undesired operation of the device.
«IC» before the equipment certification number signifies that the Industry Canada technical
specifications were met. It does not guarantee that the certified product will operate to the
user’s satisfaction.
Product Service Questions
If you have any questions about operation or installing your new Cobra®product,
or if you are missing parts…
Please call Cobra®first! DO NOT RETURN THIS PRODUCT TO THE STORE!
See customer assistance above.
For Products Purchased in Canada
For out of warranty service, ship prepaid this product to: AVS Technologies Inc., 2100 Trans
Canada Hwy S., Montreal, Quebec, H9P 2N4. We reserve the right to repair or replace the
radio or charger with equivalent products. Please include the following information: Date of
Purchase, Model Number, Dealer Purchased From, Dealer Address, Dealer Phone Number.
For Products Purchased In The U.S.A.
If your product should require factory service, please call Cobra®first before sending your
radio, charger or batteries. This will ensure the fastest turn-around time on your repair. You
may be asked to send your products to the Cobra®factory. It will be necessary to furnish the
following to have the product serviced and returned. 1) For warranty repair include some
form of proof-of-purchase, such as a mechanical reproduction or carbon of a sales receipt.
If you send the original receipt, it cannot be returned. 2) Send the entire product. 3) Enclose
a description of what is happening with the product. Include a typed or clearly printed name
and address of where the product is to be returned. 4) Pack product securely to prevent
damage in transit. If possible, use the original packing material. 5) Ship prepaid and insured
by way of a traceable carrier such as United Parcel Service (UPS) or First Class Mail to
avoid loss in transit to: Cobra®Factory Service, Cobra®Electronics Corporation, 6500 West
Cortland Street, Chicago, Illinois 60707 U.S.A. 6) If the product is in warranty, upon receipt
of your product it will either be repaired or exchanged depending on the model.
Please allow approximately three (3) to four (4) weeks before contacting Cobra®for status.
If the product is out of warranty, a letter will automatically be sent informing you of the repair
charge or replacement charge. If you have any questions, please call 773-889-3087 for assistance.
For Products Purchased Outside The U.S.A. or Canada
Please contact your local dealer for product service information.
Limited 1-Year Warranty On Radio(s) And Charger
For Products Purchased in Canada
Your new Cobra®GMRS radio and charger are covered by a one (1) year replacement
warranty. If any manufacturing defect becomes apparent in these products within one (1)
year from the original date of purchase, they will be replaced. Please return the GMRS radio
or charger to your dealer with original or copy of dated proof of purchase. This warranty
does not cover damages due to careless handling, negligence, accident, abuse or failure to
follow operating instructions. Alteration of these products or defacing of the serial number
cancels all obligations of this warranty. This warranty gives you specified legal rights.
Additional warranty rights may be provided by law in some areas.
For Products Purchased In The U.S.A.
Cobra®Electronics Corporation warrants that its Cobra®GMRS radios and charger, and the
component parts thereof, will be free of defects in workmanship and materials for a period of
one (1) year from the date of first consumer purchase. This warranty may be enforced by the
first consumer purchaser, provided that the product is utilized within the U.S.A.
Cobra®will, without charge, repair or replace, at its option, defective GMRS radios, chargers,
products or component parts upon delivery to the Cobra®Factory Service department,
accompanied by proof of the date of first consumer purchase, such as a duplicated copy of
a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service,
but the return charges will be at Cobra®s expense, if the product is repaired or replaced
under warranty. This warranty gives you specific legal rights, and you may also have other
rights which may vary from state to state.
Exclusions: This limited warranty does not apply:
1) To any product damaged by accident; 2) In the event of misuse or abuse of the product or
as a result of unauthorized alterations or repairs; 3) If the serial number has been altered,
defaced, or removed; 4) If the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and fitness for a particular
purpose are limited in duration to the length of this warranty. Cobra®shall not be liable for any
incidental, consequential or other damages; including, without limitation, damages resulting
from loss of use or cost of installation.
Some states do not allow limitations on how long an implied warranty lasts and/or do not
allow the exclusion or limitation of incidental or consequential damages, so the above
limitations may not apply to you.
For Products Purchased Outside The U.S.A. or Canada
Please contact your local dealer for warranty information.
90-Day Warranty On Batteries
For Products Purchased In The U.S.A. And Canada
Cobra®
, HighGear®
, microTALK®
, Safety Alert®Traffic Warning System,
Nothing comes close to a Cobra®and the snake design are registered
trademarks of Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™ and CobraMarine™ are trademarks
of Cobra Electronics Corporation, USA.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two (2) conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Warnings: Replacement or substitution of transistors, regular
diodes or other parts of a unique nature, with parts other than those
recommended by Cobra®may cause a violation of the technical
regulations of part 95 of the FCC rules, or violation of type acceptance
requirements of part 2 of the rules.
The Cobra®line of quality products includes:
CB Radios • microTALK®Radios • Radar/Laser Detectors • Safety Alert®Traffic Warning Systems •
Handheld GPS Receivers • Mobile GPS Navigation Systems • HighGear®Accessories •
CobraMarineVHF Marine Radios • Power Inverters • Accessories
Insert Batteries
Pull Down Lock Latch
Remove Belt Clip
To Charge Batteries in Radio:
1. Check to see that the batteries have
been inserted properly. See above
for battery installation instructions.
2. Insert round connector of wall charger/adapter into
the charge jack located at the top of the radio. The wall
charger/adapter has two round connectors which enables
you to charge either one or two radios at a time.
3. Plug the wall charger/adapter into electrical outlet.
It normally takes 15 hours to fully recharge batteries. It is
not recommended to recharge batteries more than 24 hours.
Estimated operation time on a full charge is 8 hours.
Use only the supplied rechargeable batteries and wall
charger/adapter for recharging your Cobra®microTALK®
radio. Non-rechargeable alkaline batteries can also be used.
Radio Charger Jack
On/Off Power Button
Press and hold until you
hear a series of audible tones
indicating the radio is on.
Hi•Low Power Button
On channels 1 – 7 or 15 – 22,
you may select between high
power (to extend range) or
low power (to save battery life).
Channels 8 – 14 are exclusively
low power.
Call Button
Press and release to alert
others that you are calling.
Light/Max Range Button
Press and release to illuminate the display for ten (10)
seconds. Press and hold to allow all signals to be received
and extend the maximum range of your radio. To turn off
max range extender, press and release the button again
or change channels.
Channel Up/Down
Button(s)
Volume Up/Down
Button(s)
For Customer Assistance In Canada or the U.S.A.
In this user’s guide, you should find all the information you need to operate your microTALK®radio. If you require
further assistance after reading this guide, Cobra®Electronics offers the following customer assistance services:
Making Life Easier And Safer
Staying in touch with your family and friends is convenient and easy when
using your microTALK®radio. Some of the many uses you will discover include:
Communicating with others while hiking, biking, and working; keeping track of
family and friends at a crowded public event; checking with travel companions
in another car; talking with neighbors; arranging meeting spots with others
while shopping at the mall.
Automated Help Desk English only.
24 hours a day, 7 days a week 773-889-3087 (phone).
Customer Assistance Operators English and Spanish.
8:00 a.m. to 6:00 p.m. CT, Monday through Friday
(except holidays) 773-889-3087 (phone).
Questions English and Spanish.
Faxes can be received at 773-622-2269 (fax).
Technical Assistance English only.
www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo@cobra.com (e-mail).
For Assistance Outside Canada,
the U.S.A. or in French
Contact Your Local Dealer
Battery Low Icon
Icon blinks when batteries should be
recharged (only rechargeable batteries)
or replaced (alkaline batteries).

Navigation menu
