Coby Communications NBPC1028 Notebook User Manual
Coby Communications Ltd. Notebook
User manual
Please read carefully before use
For assistance with this product, please contact Coby Technical Support:
718-412-4173, Mon–Fri, 8:00AM–5:30PM EST
NBPC1028
Ultra-Portable NETBOOK PC
Page 2 Coby Electronics Corporation
Table of Contents
PACKAGE CONTENTS ........................................................... 4
SAFETY PRECAUTIONS ........................................................ 5
General Operation ....................................................................................... 5
Battery .............................................................................................................. 5
Power Connection ........................................................................................ 6
Unit Components .......................................................................................... 6
NETBOOK AT A GLANCE ...................................................... 8
Top View ........................................................................................................... 8
Left View......................................................................................................... 10
Bottom View ................................................................................................. 11
BASIC OPERATION ............................................................. 12
Power ............................................................................................................................. 12
AC Power ....................................................................................................... 12
Battery Power ............................................................................................... 12
Getting Started ........................................................................................................... 13
Turning On Your Computer ..................................................................... 13
Sleep Mode ................................................................................................... 13
Shut Down .................................................................................................... 14
Keyboard Functions .................................................................................................. 14
Numeric Keypad .......................................................................................... 14
Function Key Combinations .................................................................... 14
Using the Touchpad ................................................................................... 15
FEATURES ........................................................................... 16
Using Memory Cards .................................................................................. 16
Using the Web Camera .............................................................................. 16
Using the Internet ....................................................................................... 16
Installing Device Drivers............................................................................ 17
www.cobyusa.com Page 3
Table of Contents
EXTERNAL DEVICES ........................................................... 18
Connecting a Universal Serial Bus (USB) Device ............................... 18
Connecting an External Display ............................................................. 18
Connecting an Audio Device .................................................................. 19
Connecting an External Microphone ................................................... 19
TROUBLESHOOTING .......................................................... 20
SPECIFICATIONS ................................................................. 25
Page 4 Coby Electronics Corporation
Package Contents
Congratulations on your purchase of a Coby netbook computer. This
instruction manual guides you in setting up and using your new com-
puter. Please read the manual carefully before operation, and keep it for
future reference.
This package contains:
Coby NBPC computer unit
–V AC adapter
-cell lithium-ion battery
This package may contain plastic bags or other materials that
pose a hazard to children. Be sure to safely dispose of all pack-
ing materials after opening.
Product names used herein are for identication purposes only
and may be the trademarks of their respective companies. Micro-
soft, Windows XP, Windows MCE, Windows Vista, and Windows
Sound System are trademarks of Microsoft Corporation. Intel®, In-
tel® Core TM, Intel® HD Audio (Azalia) are registered trademark of
Intel Corporation. All other brands or product names mentioned
in this manual are trademarks or registered trademarks of their
respective companies.
www.cobyusa.com Page 5
Safety Precautions
Follow the guidelines below to ensure the safe operation of
your computer.
General Operation
Set up and store the computer on a rm, at surface. Make sure that
your workspace allows for proper ventilation.
To avoid overheating, do not operate the computer on a soft surface,
such as a bed, for long periods of time.
Keep the computer away from water. Exposure to moisture may
cause malfunction or risk of electric shock.
Do not expose the computer to excessive heat, including direct
sunlight and heat-producing appliances.
To avoid potential damage to the hard drive, do not expose the com-
puter to electromagnetic elds from stereos, microwaves, or other
household appliances.
If liquid is spilled on or into the computer, unplug it immediately and
contact customer service.
Clean with a damp cloth or mild detergent; do not use harsh chemi-
cals.
Handle your computer gently to avoid hard drive damage. Do not
drop the computer.
Back up your hard drive regularly to avoid loss of data in the event of
damage.
Battery
Use only the recommended battery pack.
Page 6 Coby Electronics Corporation
Safety Precautions
Keep metallic objects, such as keys and clips, away from the battery
pack.
To avoid risk of re, keep electrical appliances away from the battery
pack.
Do not expose the battery pack to heat or moisture.
Do not short-circuit the battery terminals.
To avoid damage to the battery, make sure that the battery catch
locks rmly in place upon installation.
Power Connection
Connect to a properly grounded outlet of the recommended volt-
age, only.
Do not use the power cord if it is damaged or frayed.
Do not connect the power cord to a loose or damaged socket.
To unplug the power cord, hold the body of the plug and pull gently.
Do not yank or stress the cord.
Disconnect the cord before cleaning the computer.
Disconnect the cord during electrical storms.
Unit Components
Do not connect the modem to a telephone line.
Connect only appropriate devices and drives to the SD, USB and mo-
dem ports on the unit. Do not insert other objects into these ports.
Do not stress, bend, or scratch the LCD. Doing so may cause it to
break.
www.cobyusa.com Page 7
Safety Precautions
Do not touch or ingest the liquid that spills from a broken LCD.
Do not operate the wireless internet within meters of a microwave
oven or plasma lamp.
Page 8 Coby Electronics Corporation
Netbook at a Glance
Illustrations in this manual may dier from the actual product.
Top View
1
2
3
4
5
6
7
8
9
10
12
11
13
1. Web camera
2. Display panel
3. Power button
4. AC adapter jack
5. LAN connection (broadband or
cable internet input)
6. VGA connection (monitor or
projector input)
7. Headphone jack
8. Microphone jack
9. USB port (x2)
10. Touchpad
11. System status indicators
12. Integrated mouse (left/right
click)
13. Keyboard
www.cobyusa.com Page 9
These indicators display your computer’s current status. Please refer to
the table below for more information.
Indicator Symbol Indicator Type Appearance Status
Power Solid blue System on
Flashing blue System in standby mode
O System o/hibernating
Battery O Battery charged
Solid red Charging
Flashing red Low battery
HDD The HDD indicator will light when data is being
written to/read from the hard disk.
Wireless LAN O No power to wireless card/
RF deactivated
Flashing blue, slow Wireless client is not associ-
ated with the network
Flashing blue,
intermediate
Wireless on/connecting
Flashing blue, rapid Wireless transmitting/re-
ceiving data
Number Lock Solid blue Number lock on/numeric
keypad active
Caps Lock Solid blue Caps lock on
Netbook at a Glance
Page 10 Coby Electronics Corporation
Left View
21 3 4
1. Security key port (security cable not included)
2. Vent
3. USB Port
4. SD Card Slot(SDHC compatible)
To avoid overheating, do not block this vent when the computer
is in use.
Netbook at a Glance
www.cobyusa.com Page 11
Bottom View
1
2
3
4
2
5
6
1. Battery pack
2. Battery latch
3. Hard drive compartment
4. Stereo speakers
5. Vent
6. SDRAM compartment
Do not attempt to disassemble or replace your hard drive. For
assistance with hard drive replacement and repair, contact a
qualied service professional.
Netbook at a Glance
Page 12 Coby Electronics Corporation
Basic Operation
Power
Your computer includes both an AC adapter and built-in, rechargeable
lithium-ion battery for maximum portability.
AC Power
Use the AC adapter to run your computer on AC power and charge the
battery. To connect the AC adapter:
Connect the power cord to the transformer pack.
Plug the power cord into an electrical outlet.
Connect the AC adapter to the AC power adapter jack of the com-
puter.
Battery Power
Make sure the battery is fully charged before rst use. The battery
power status indicator will ash when the battery is low. Connect the AC
adapter as instructed above to charge the battery.
To replace the battery:
Shut down the computer and disconnect all cables, including the AC
power cord.
Turn the computer over to access the battery release. Slide the bat-
tery release latch to the unlock position and hold.
Slide the battery out.
Slide the replacement battery into the bay until it clicks into place.
Slide the release latch to the locked position.
www.cobyusa.com Page 13
The components and programs on your computer consume
power at dierent rates. Using power-intensive components/
programs will cause the battery to drain faster.
Your computer’s operating system may run more slowly when
operating on battery power.
Use only approved battery packs to power your computer. Us-
ing an incompatible battery may increase the risk of re or ex-
plosion.
Do not attempt to disassemble or modify the battery pack. A
battery pack other than the one specied by us, or a disassem-
bled or modied battery pack, is not covered by the warranty.
When disposing of the battery, comply with local ordinances
and regulations. Do not attempt to dispose of the battery in
your household trash.
Getting Started
Open the display panel and adjust it for comfortable viewing.
Turning On Your Computer
Press the power button to turn on the computer.
Sleep Mode
When you nish working with your computer, you can put it to sleep or
shut it down.
Use sleep mode if you will be away from your computer for only a short
time. To enter sleep mode:
Basic Operation
Page 14 Coby Electronics Corporation
Click the Start menu and select Sleep, or
Press Fn + Esc.
Wait until the power indicator light starts blinking (indicating
that the computer is in sleep) before you move your computer.
Moving your computer while the hard disk is spinning may cause
damage or loss of data.
To wake the computer, press the Power button.
Shut Down
Your computer should be shut down when not in use for hours or
more. Enter the Start menu and select Shut Down to turn o the com-
puter.
Keyboard Functions
Your computer’s standard keyboard incorporates a numeric keypad and
function keys.
Numeric Keypad
When enabled, the keys indicated below can be used as a -key nu-
meric keypad. To enable or disable the numeric keypad, press Fn+Ins/
NumLk.
Function Key Combinations
The function keys allow you to change your computer’s operating
features instantly. See below for more information on using function key
combinations.
Basic Operation
www.cobyusa.com Page 15
Key Description
Fn + Esc Put your computer in sleep mode.
Fn + F1 Enable/disable the built-in wireless internet.
Fn + F3 Mute.
Fn + F4 Enable/disable the touch pad.
Fn + F5 Shift to other connected display devices, i.e. another monitor.
Fn + F6 Decrease display brightness.
Fn + F7 Increase display brightness.
Fn + F8 Decrease computer volume.
Fn + F9 Increase computer volume.
Fn + F10 Turn on/o the LCD screen.
Fn + Ins/NumLk Enable/disable the Numeric keypad.
Using the Touchpad
Use the touchpad and integrated mouse to navigate your computer’s
operating system. To move the cursor on the screen, slide your nger-
tip over the touchpad in the direction in which you want the cursor to
move.
Use the left/right click buttons on the integrated mouse just as you
would the left/right click on a conventional mouse to select objects,
open programs, or retrieve information.
Use one nger only to navigate the touchpad. Moisture or dirt
may cause the touchpad to function incorrectly.
Sharp objects or excessive pressure may damage the touchpad’s
surface.
Do not attempt to remove the cover of the touchpad.
Basic Operation
Page 16 Coby Electronics Corporation
Features
Using Memory Cards
Your computer includes an SD memory card slot for easy transfer of
data. To insert a memory card, orient the memory card with the label
upward. Gently slide the card into the slot.
When a memory card is fully inserted, the rear half of the card will
remain outside of the card slot.
To remove a memory card, grasp it by the end and pull gently.
Using the Web Camera
The built-in web camera can be used for capturing photos, recording
video, or as a component of chat and conferencing applications.
Windows Vista users will need to install a third-party dedicated
application in order to take pictures and video using the web-
cam.
Using the Internet
Your computer comes with LAN port for Ethernet connection or local
area network (LAN), as well as a built-in wireless connection.
LAN Port
The LAN port supports a standard RJ- connector, and allows you to
connect the computer to an Ethernet connection and local area network
(LAN).
www.cobyusa.com Page 17
Do not attempt to connect a telephone cable (types RJ11, RJ14,
RJ25, RJ61) to the LAN port. Doing so may short-circuit your
computer.
Wireless
An isotropic antenna system is built into the display for optimal recep-
tion, enabling wireless communication wherever you are. To connect to
the internet wirelessly, press Fn + F. The computer will automatically
search and connect to an available network.
Installing Device Drivers
A compatible device driver is required to ensure correct operation and
performance of each component in your computer.
Most installations require a reboot to update the driver. Be sure to
perform this step when prompted.
Failing to reboot may compromise the system’s stability and re-
quire reinstallation of the operating system.
Features
Page 18 Coby Electronics Corporation
External Devices
Your computer includes multiple connection ports for maximum perfor-
mance and productivity.
Do not connect or disconnect any external device cables other than
USB cables while the computer power is on. To avoid possible damage
to attached devices, wait at least ve seconds after the computer is shut
down to disconnect external devices.
Connecting a Universal Serial Bus (USB) Device
Your computer comes with three Universal Serial Bus Ports compatible
with USB . or USB . devices such as a keyboard, mouse, camera, hard
disk drive, printer, and scanner. USB devices may be connected and
disconnected without rebooting the computer (hot swapping), and al-
low specic classes of hardware to be used without requiring individual
device drivers to be installed.
When using a high power consumption USB device such as USB
ODD, use an external device power adapter to avoid system
damage.
Connecting an External Display
You can connect a VGA monitor via the computer’s built-in VGA port.
To connect a VGA monitor, plug the -pin display cable into the corre-
sponding VGA port on your computer.
To shift to other connected display devices, press Fn + F. You may also
select a device using the Control Panel Display menu.
www.cobyusa.com Page 19
Connecting an Audio Device
Your computer includes one headphone jack for use in connecting
headphones, speakers, or other audio output devices. To connect, insert
the audio device plug into the jack.
Connecting an External Microphone
Your computer includes one external jack for connecting a microphone.
To connect, insert the microphone plug into the jack.
External Devices
Page 20 Coby Electronics Corporation
Troubleshooting
If you have a problem with this device, please read the troubleshooting
guide below and check our website at www.cobyusa.com for Frequently
Asked Questions (FAQs) and rmware updates. If these resources do not
resolve the problem, please contact Technical Support.
Address
Coby Electronics Technical Support
56-65 Rust Street
Maspeth, NY 11378
Email
techsupport@cobyusa.com
Web
www.cobyusa.com
Phone
718-412-4173: Mon–Fri, 8:00AM–5:30PM EST
www.cobyusa.com Page 21
Problem Solution
Display
Computer does not turn on. If using AC power, check that the AC adapter is securely con-
nected to the computer and the power cord is plugged into a
working electrical outlet.
If using battery power, check that the battery is charged.
Computer turns on, but there
is no screen image.
Conrm that the screen brightness level is not at its minimum
setting. (To increase brightness, press Fn +F7.)
If using battery power, check that the battery is installed
correctly.
If using AC power, check that the AC adapter is connected to
the computer and the power cord is plugged into a working
electrical outlet.
Screen goes blank while the
computer is on.
Screen saver may be enabled; touch the touchpad or any key
to exit screen saver mode.
If power management is enabled, the computer may have en-
tered sleep mode. Press the power button to exit sleep mode.
Keyboard
A number appears when you
enter a letter.
The numeric lock function is enabled. To disable it, press Fn +
Insert.
All or some of the keys on the
external numeric keypad do
not work.
Make sure that the external numeric keypad is securely con-
nected to the computer.
Sleep/Hibernation Mode
The computer enters sleep
mode unexpectedly.
Check that the battery is charged.
Troubleshooting
Page 22 Coby Electronics Corporation
Problem Solution
If the processor overheats, the computer will automatically
enter sleep mode to allow the computer to cool and to protect
the processor and other internal components. Check that the
computer is properly ventilated and not hot to the touch.
Check the sleep mode settings. The computer enters sleep
mode (the sleep indicator turns on) immediately after Power-
on self-test (POST).
The critical low-battery error
message appears, and the
computer immediately turns
o.
Connect the AC adapter to the computer, or replace the bat-
tery with a fully charged one.
The computer does not return
from sleep mode, or the sleep
indicator stays on and the
computer does not work.
Check the sleep indicator light to conrm that your system
is in sleep mode. If it has turned o, your computer has
gone into hibernation mode. Press the power button to exit
hibernation mode.
Check that the battery is charged. A depleted battery will
cause the computer to automatically enter hibernation mode.
If the battery is depleted, connect to AC power and press the
power button to exit hibernation mode.
If the system still does not return from sleep mode, your sys-
tem has stopped responding. Reset the computer by pressing
and holding the Power button for 4 seconds or more. Unsaved
data may be lost.
If the computer fails to reset, unplug the AC adapter and
remove, then reinsert, the battery.
Troubleshooting
www.cobyusa.com Page 23
Problem Solution
The screen is unreadable or
distorted.
Check that screen resolution and color quality are correctly
set.
Check that the monitor type is correct. This information is
available under the menu Display Settings > Monitor.
Conrm that the display device driver is installed correctly.
This information is available under the menu Personalize >
Display Settings > Advanced Settings > Adapter. The Adapter
Information window should display the correct device driver
name.
NOTE: The device driver name depends on the video chip that
has been installed on your computer. Click the Properties
button and check the “Device status” box to conrm that
the device is working properly. If not, click the Troubleshoot
button.
Incorrect characters appear on
the screen.
Check that your application and operating system are cor-
rectly installed.
Missing, discolored, or bright
dots appear on the screen
every time you turn on your
computer.
Check that the surface of the screen is not scratched or dam-
aged. If there is no visible damage, these small idiosyncrasies
are a standard element of TFT screen technology and will not
aect the computer’s performance.
Sound
No sound can be heard from
the speaker even when the
volume is turned up.
Conrm that the Mute function is o.
Check that no external device, such as a headphone or
speaker, is plugged into the audio output (headphone) jack.
Check that speakers are selected as a playback device.
Troubleshooting
Page 24 Coby Electronics Corporation
Problem Solution
Battery
Your computer shuts down
before the battery status in-
dicator turns on, or continues
to operate after the battery
status indicator lights.
Remove and reinsert the battery. If the problem persists, you
may need to replace the battery.
The operating time for a
fully charged battery is short,
or the computer does not
operate with a fully charged
battery.
Remove and reinsert the battery. If the problem persists, you
may need to replace the battery.
The surge protector in the battery might be active. Turn o
the computer for one minute to reset the protector; then turn
on the computer again.
The battery does not charge. Replace the battery.
Hard Drive
The hard disk drive does not
work.
In the Boot menu in AMI Setup Utility, make sure that the
hard disk drive is included in the Boot Sequence.
Other Problems
The computer does not
respond.
Turn o the computer by pressing and holding the power
button for 4 seconds or more. If the computer still does not
respond, remove the AC adapter and the battery.
Your computer may lock if it enters sleep mode during a
communication operation. To prevent this from happening,
disable the sleep timer when you are working on the internet
or network.
For your safety, never attempt to repair the device yourself. Attempting
to do so will invalidate the warranty. Internal components of the device
carry a risk of electric shock.
Troubleshooting
www.cobyusa.com Page 25
Specications
Display Type 10.2” TFT LCD (Matte)
Display Resolution 1024x600 (WSVGA)
CPU Intel Atom™ 1.6 GHz
Hard Drive 2.5” SATA 160 GB (5400 RPM)
Memory 1 GB DDRII RAM
RAM Type: PC2-5300 DDR2 SO-DIMM (667 MHz)
Installed: 1024 MB (single SO-DIMM)
Maximum: 2048 MB (single SO-DIMM)
Networking Wi-Fi 802.11 b/g
Ethernet 10/100 Mb
Connectivity USB 2.0 Hi-Speed (x3)
A/V Connections VGA Video Out
3.5 mm Headphone Out
3.5 mm Microphone In
Additional Features Integrated Web Camera, 1.3 MP Resolution
Integrated Microphone
SD Memory Card Reader (SDHC compatible)
Keyboard US-International
Battery 3-cell Li-ion (2-3 hours runtime)
Unit Dimensions 10.15” x 7.67” x 1.13” (WHD)
Specications are subject to change without notice.
FCC STATEMENT
Changes or modifications not expressly approved by the party responsible for
compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
