www.codanradio.com © Copyright 201412-20232-DA Issue 1 4/2014
ﻩﺎﮕﻧ ﮏﻳ ﺭﺩ ﺎﻫ ﯽﮔ ﻩﮋﻳﻭ
MHz 30 ﺎﺗ 2 ■
PEP ﺕﺍﻭ 125 ■
ﻂﺳﻭﺍ ﺪﺣ ﻪﻴﻧﺎﺛ 1 ﻊﻳﺮﺳ ﻥﺩﺮﮐ ﻥﻮﺗ ■
ﻪﻴﻧﺎﺛ ﯽﻠﻣ 150 >ﻪﻈﻓﺎﺣ ﻥﺩﺮﮐ ﺕﻮﺗ ■
ﯽﺴﻧﻮﮑﻳﺮﻓ ﻭ ALE ﺯﺍ ﻥﺩﺮﮐ ﯽﻧﺎﺒﻴﺘﺸﭘ ■
Hopping یﺎﻫ ﺖﻟﺎﺣ
ﻝﺎﻌﻓ ﻞﻣﺎﮐ ﺪﻧﺎﺑ یﺎﻨﻬﭘ ■
Receiver Amplifier for scanning
ﻥﺩﺮﮐ ﻦﮑﺳﺍ یﺍﺮﺑ ﻩﺬﺧﺍ ﺮﻳﺎﻔﻴﻠﭙﻣﺍ
،ﺕﺭﺍﺮﺣ یﺎﻣﺩ) 810F-ﯽﻣﺎﻈﻧ-ﺭﺎﻴﻌﻣ ■
ﻭ ﺩﺮﮔ ،ﻥﺎﺳﻮﻧ ،ﺏﺁ ﺭﺩ ﻥﺪﺷ ﺭﻭ ﻪﻁﻮﻏ
(کﺎﺧ
461-ﯽﻣﺎﻈﻧ-ﺭﺎﻴﻌﻣ یﺍﺮﺑ ﻩﺪﺷ ﻦﻳﺍﺰﻳﺩ ■
ﺭﺎﻴﺴﺑ ﻦﺘﻧﺁ ﻦﻳﺰﮕﻳﺎﺟ ﯽﻟﺎﻋ ﺩﺮﮑﻠﻤﻋ ﺎﺑ ،ﻢﮐ ﯽﮕﺘﺴﺟﺮﺑ ﺎﺑ 3040 ﺐﻳﻭ ﺕﺎﻣﻮﺗﺍ ﻦﺘﻧﺁ
ﻩﺩﺍﻮﻧﺎﺧ ﺯﺍ ﻥﺍﺩﻮﮐ یﺎﻫ ﻩﺮﺑﺎﺨﻣ ﻡﺎﻤﺗ یﺍﺮﺑ ﺮﺗﻮﻣ ﺭﺎﻴﺳ ﻦﺘﻧﺁ ﮏﻳ ،9350 ﺏﺎﻴﻣﺎﮐ
.ﺪﺷﺎﺒﻴﻣ ﻢﻫﺍﺮﻓ (HF) ﺪﻨﻠﺑ ﯽﺴﻧﻮﮑﻳﺮﻓ
ﺖﻬﺟ ﺎﻬﻨﻳﺍ ﻪﻤﻫ ﺖﺨﺳ ﻥﺎﻤﺘﺧﺎﺳ ﻭ ،ﺭﻮﺘﮑﻓ ﺯﺍ ﻩﺩﺮﺸﻓ ،ﻊﻳﺮﺳ ﻥﺩﺮﮐ ﻥﻮﺗ ﺐﻴﮐﺮﺗ
.ﺪﻨﮑﻴﻣ یﺭﺎﮑﻤﻫ ﺭﺎﻴﺳ ﻦﺘﻧﺁ ﺮﻧﻮﺗ ﺪﻴﻟﻮﺗ ﻥﺪﺷ ﻢﻫﺍﺮﻓ
ﯽﻟﺎﻋ ﺩﺮﮑﻠﻤﻋ
ﻭ ﺍﺪﺻ یﺍﺮﺑ 3040 ﻦﺘﻧﺁ ﻪﮐ ،ﻝﻭﺮﺘﻨﮐ ﻥﺍﻮﺗ RF ﺕﺍﻭ 125 ﯽﺟﺭﺎﺧ ﺖﻗﺎﻁ ﺎﺑ ﻩﺍﺮﻤﻫ
ﺮﺘﻤﮐ ﺪﻳﺎﺑ ﺮﻧﻮﺗ ﻪﮐ .ﺪﻨﮑﻴﻣ ﻩﺩﺎﻔﺘﺳﺍ ﺍﺭ ﯽﺴﻧﻮﮑﻳﺮﻓ ﺪﻧﺎﺑ ﺰﺗﺮﻫﺎﮕﻴﻣ 30 ﻪﺑ ﺎﺗ 2 ﺯﺍ ﺎﺘﻳﺩ ﺕﺎﻴﻠﻤﻋ
ﯽﺴﻧﻮﮑﻳﺮﻓ ﻭ ،ﺩﻭﺪﺤﻣ ﺎﻧ ﺖﻴﻓﺮﻅ ﺎﺑ ﻪﻈﻓﺎﺣ ﻩﺍﺮﻤﻫ ﺪﻨﮐ ﻥﻮﺗ ﻪﻴﻧﺎﺛ ﯽﻠﻣ 200 ﻪﻈﻓﺎﺣ ﺖﻗﻭ ﺯﺍ
.ﺩﻮﺸﻴﻣ ﻥﻮﺗ ﻪﻴﻧﺎﺛ ﮏﻳ ﺯﺍ ﺮﺘﻤﮐ ﺭﺩ ﻝﻮﻤﻌﻣ ﺭﻮﻁ ﻪﺑ ﺪﻳﺪﺟ یﺎﻫ
3040
ﺐﻳﻭ ﺕﺎﻣﻮﺗﺍ ﻦﺘﻧﺁ
ﻩﺎﮕﻧ ﮏﻳ ﺭﺩ ﺎﻫ ﯽﮔ ﻩﮋﻳﻭ
MHz 30
ﺎﺗ
www.codanradio.com
CODAN RADIO COMMUNICATIONS
Australia: +61 8 8305 0528
Canada: +1 250 382 8268
US: +1 585 419 9970
Dubai: +971 44 53 72 01
UK: +44 1252 717 272
sales@codanradio.com
Codan ﺖﮐﺮﺷ ﯽﺗﺭﺎﺠﺗ یﺎﻫ ﻪﻣﻼﻋ NGT ﻭ CODAN
یﺎﻫ ﺖﮐﺮﺷ ﻡﺎﻧ ﻭ ﻝﻮﺼﺤﻣ ﻡﺎﻧ ،ﯽﺗﺭﺎﺠﺗ ﺮﮕﻳﺩ ﻡﺎﻧ .ﺪﻨﺘﺴﻫ
ﻡﺎﻧ ﻪﺑ ﻥﺁ ﯽﺗﺭﺎﺠﺗ یﺎﻫ ﻡﺭﺁ ﻭ ﻩﺪﻳﺩﺮﮔ ﺮﮐﺫ ﺪﻨﺳ ﻦﻳﺍ ﺭﺩ ﺮﮕﻳﺩ
.ﺖﺳﺍ ﻩﺪﺷ ﺖﺒﺛ ﻥﺎﺷ ﻥﺎﮑﻟﺎﻣ
12-20232-DA Issue 1 4/2014
3040
ﺐﻳﻭ ﺕﺎﻣﻮﺗﺍ ﻦﺘﻧﺁ
ﻉﻮﺿﻮﻣ ﺮﻴﻴﻐﺗ ﺖﻬﺟ ﻞﺒﻗ ﺯﺍ ﺖﺷﺍﺩﺎﻳ ﻥﻭﺪﺑ ﺕﺍﺰﻴﻬﺠﺗ ﺕﺎﺼﺨﺸﻣ ﻭ ﺕﺎﺤﻴﺿﻮﺗ .ﺖﺳﺍ ﻩﺪﺷ ﺖﺷﺍﺩﺎﻳ ﺩﺍﺪﻋﺍ ﻉﻮﻧ
NVIS ﻦﺘﻧﺁ ﻡﺯﺍﻮﻟ ﻪﺘﺴﺑ 3040
ﻡﺯﺍﻮﻟ
(ﺖﻓ 19.7) ﺮﺘﻣ 6 ،ﻝﻭﺮﺘﻨﮐ ﻞﺒﻴﮐ NGT ﻪﺑ 3040 ■
(ﺖﻓ 19.7) ﺮﺘﻣ 6 ،ﻞﻴﺴﮐﺍﻮﮐ ﻞﺒﻴﮐ NGT ﻪﺑ 3040 ■
NVIS ﻦﺘﻧﺁ ﻡﺯﺍﻮﻟ ﻪﺘﺴﺑ 3040 ■
ﺕﺎﺼﺨﺸﻣ
ﯽﻣﻮﻤﻋ
2.5 to 30 MHz (2.4 m, 7.9 ft Whip)
2 to 12 MHz (3.5 m, 11.5 ft NVIS)
ﯽﺴﻧﻮﮑﻳﺮﻓ ﺶﺷﻮﭘ ﻪﺣﺎﺳ
125 W PEP (voice and data)
ﻥﺍﻮﺗ ﻪﺟﺭﺩ
0.4 A typical, less than 0.8 A typical while tuning
ﻕﺮﺑ ﻑﺮﺼﻣ
50 Ω
یﺩﻭﺭﻭ ﺲﻧﺍﺪﻴﭙﻣﺍ
Typically ≤1.5:1 VSWR
New frequency 1 sec average, memory tune <150 ms
ﻥﺩﺮﮐ ﻥﻮﺗ ﺖﻋﺮﺳ
Unlimited
ﻪﻈﻓﺎﺣ یﺎﻫ ﻞﻨﻴﭼ
ﯽﮑﻴﻧﺎﺨﻴﻣ
–30°C (–22°F) to 60°C (140°F), 95% humidity
ﺎﻣﺩ ﻪﺟﺭﺩ
11 to 15.5 V DC (12 V DC nominal)
DC ﯽﺗﺎﻴﻠﻤﻋ ﺶﺷﻮﭘ ﻪﺣﺎﺳ
Open circuit, short circuit, over voltage, over temperature,
voltage transients, high VSWR
ﺖﻈﻓﺎﺤﻣ
Temperature, Immersion, Dust, Vibration
810F-ﯽﻣﺎﻈﻧ-ﺭﺎﻴﻌﻣ
Designed to standard
461-ﯽﻣﺎﻈﻧ-ﺭﺎﻴﻌﻣ
147 mm W x 167 mm D x 240 mm H; 5.8” x 6.6” x 9.4”
(excludes spring and whip)
ﺩﺎﻌﺑﺍ
3.15 kg (6.9 lbs) including spring and whip
ﻥﺯﻭ
M14 stud, 40 mm (1.6”) long
ﻥﺩﺮﮐ ﺐﺼﻧ
ﻩﺎﻴﺳ ﮓﻧﺭ
ﻩﺮﺑﺎﺨﻣ یﺎﻫ یﺭﺎﮔﺯﺎﺳ
ﺲﭘ ﻥﺍﺩﻮﮐ HF یﺎﻫ ﻩﺮﺑﺎﺨﻣ ﻩﺍﺮﻤﻫ ﻶﻣﺎﮐ 3040 ﻦﺘﻧﺁ ﺎﺘﻳﺩ ﻝﻭﺮﺘﻨﮐ ﺲﻴﻓﺮﺘﻧﺍ
ﻡﺎﻤﺗ ﺭﺩ ﻪﮐ 3040 ﻦﺘﻧﺁ .ﺩﺭﺍﺩ یﺭﺎﮔﺯﺎﺳ ﺮﺘﻳﺮﭘﺁ یﺍﺮﺑ ﺖﺳﺍ ﻑﺎﻔﺷ ﻥﺩﺮﮐ ﻥﻮﺗ
ﺩﺎﺠﻳﺍ) ALE ﻭ ،ﻩﺬﺧﺁ ﻥﺩﺮﮐ ﻦﮑﺳﺍ ﻪﻠﻤﺠﻨﻣ ﺩﺭﺍﺩ ﺭﺎﮔﺯﺎﺳ ﻶﻣﺎﮐ ﺩﺮﮑﻠﻤﻋ ﺎﻫ ﺩﻮﻣ
.ﺖﺳﺍ ﻩﺪﺷ ﻦﻳﺍﺰﻳﺩ (ﮏﻴﺗﺎﻣﻮﺗﺍ ﻁﺎﺒﺗﺭﺍ
ﺖﺨﺳ ﻦﻳﺍﺰﻳﺩ
ﺐﺼﻧ ﺭﺩ ﺕﺎﻗﻭﺍ ﯽﻠﻴﺧ ﻪﮐ ﺖﺨﺳ ﻂﻳﺍﺮﺷ ﺮﺑﺍﺮﺑ ﺭﺩ ﺖﻣﻭﺎﻘﻣ ﺎﺑ 3040 ﻦﺘﻧﺁ
ﻩﺪﺷ ﻦﻳﺍﺰﻳﺩ ﺩﻮﺸﻴﻣ ﻪﺑﺮﺠﺗ (HF) ﺪﻨﻠﺑ ﯽﺴﻧﻮﮑﻳﺮﻓ ﺎﺑ ﺭﺎﻴﺳ ﺎﻫ ﻩﺮﺑﺎﺨﻣ ﻥﺩﺮﮐ
ﺐﺒﺳ ﻪﮐ ﻩﺪﺷ ﺐﮐﺮﻣ ﻥﺯﻭ ﻢﮐ ﺵﻮﭘ ﮏﻳ ﺎﺑ ﻩﺍﺮﻤﻫ ﯽﻠﺧﺍﺩ یﺎﻫ ﮏﻴﻧﻭﺮﺘﮑﻟﺍ .ﺖﺳﺍ
ﻝﻮﺼﺤﻣ ﮏﻳ .ﺩﺯﺎﺴﻴﻣ ﻢﻫﺍﺮﻓ ﺰﻴﻧ ﺍﺭ ﺯﺍﺰﺘﻫﺍ ﺏﺬﺟ ﻪﻳﺎﭘ ﻭ ﺩﻮﺸﻴﻣ ﻥﺁ ﺖﻈﻓﺎﺤﻣ
،ﺕﺭﺍﺮﺣ یﺎﻣﺩ یﺍﺮﺑ 810F-ﯽﻣﺎﻈﻧ-ﺭﺎﻴﻌﻣ ﺎﺑ ﻖﻓﺍﻮﻣ ﻭ ﺏﺁ ﺪﺿ ﻶﻣﺎﮐ ﻪﮐ
.ﺪﺷﺎﺒﻴﻣ کﺎﺧ ﻭ ﺩﺮﮔ ﻭ ﻥﺎﺳﻮﻧ ،ﺏﺁ ﺭﺩ ﻥﺪﺷ ﺭﻭ ﻪﻁﻮﻏ
