HiveNet™ is a rugged transportable repeater which can

be linked with other HiveNet repeaters over RF links, to

create a network of linked repeaters. A HiveNet repeater

network is self-healing, allowing for repeaters to be

added and removed on the fl y, as well as being rapidly

confi gurable for expanded area coverage.

INTEROPERABLE ENCRYPTED NETWORK

HiveNet repeaters and links can be any frequency band (VHF,

UHF, 700/800/900 MHz). HiveNet is available as an analog only or

analog and P25 digital (mixed mode) repeater network giving users

full forwards and backwards compatibility with existing legacy

equipment. In P25 Digital mode, HiveNet will pass all encrypted

voice and data transparently through the repeater network using

AES-256 encryption, meaning all communications are secure in the

case of a HiveNet repeater being compromised. HiveNet repeaters

are interoperable with a wide range of subscriber radios from all P25

supported vendors.

HEARTBEAT SIGNAL FOR ROAMING

Conventional repeater systems require users to manually change

channel to move between repeaters. HiveNet has the unique

functionality of a heartbeat signal which enables a user to roam

freely within the HiveNet repeater network coverage area, without

having to change channels. The heartbeat signal ensures a users

portable radio is locked onto the best HiveNet repeater site for

optimal coverage and reliable communications.

RUGGED AND RAPIDLY DEPLOYABLE

HiveNet repeaters are lightweight and housed in a compact

watertight polyethylene Pelican™ case. The case includes soft grip

handles, in-line wheels, press and pull latches and a telescoping

handle for rapid deployment. A HiveNet repeater is low power

consumption, allowing it to operate from internal batteries, vehicle

batteries or additional add-on external batteries. HiveNet is based

on a transportable repeater solution but can be installed as a fi xed

network infrastructure.

 FEATURES AT A GLANCE

 Full encryption of the system and

repeater links

 Heartbeat signal for roaming throughout

the repeater network

 Self-healing network for easy adding

and removing of repeaters

 Rapidly deployable outdoors or within

vehicles

 Interoperable with a wide range of

subscriber radios

 Full P25 Compliance

 Compact and impact resistant

12-20305-EN Issue 1 5/2014

HiveNet™ TACTICAL REPEATER

www.codanradio.com

CODAN RADIO COMMUNICATIONS

Australia: +61 8 8305 0528

Canada: +1 250 382 8268

 US: +1 585 419 9 970

 Dubai: +971 44 53 72 01

 UK: +44 1252 717 272

 LMRsales@codanradio.com

HiveNet™ TACTICAL REPEATER

CODAN™, HiveNet™, MRAY™ and Vizor ™ are

trademarks of Codan Limited. Other brand, product

and company names mentioned in this document

are trademarks or registered trademarks of their

respective holders.

Values noted are typical. Equipment descriptions and

specifi cations subject to change without notice or

obligation.

12-20305-EN Issue 1 5/2014

SPECIFICATIONS

Repeater Bands 136-174, 380-520, 768-869, 896-960 MHz

Encryption DES-OFB / AES-256 (FIPS certifi ed)

Modulation Types Analog, P25, Mixed Mode

Size 24.6” (62.5 cm) wide, 11.7” (29.7 cm) high and 19.7” (50.0 cm) deep

Weight 50 lbs. (22.68 kg)

Operating Temperature –40°C to + 60°C (100% Duty Cycle - lid open)

–40°C to + 40°C (100% Duty Cycle - lid closed)

+ 40°C to + 50°C (50% Duty Cycle - lid closed)

+ 50°C to + 60°C (10% Duty Cycle - lid closed)

Power outputs 0.5 to 8 Watts (VHF / UHF)

0.5 to 3 Watts (700/800/900 MHz)

30 Watts (VHF / UHF / 700 MHz / 800 MHz)

Power 110/220 Vac and/or 12 Vdc

Battery Life (10% duty cycle, 30 W output) 8 hours (10.5 AHr internal battery)

30 hours (35 AHr external battery)

90 hours (100 AHr external battery)

Type of battery Absorbent Glass Mat (AGM) - Rechargeable

Internal Duplexer Frequency Separation VHF: ≥ 2.0 MHz or ≥ 4.5 MHz separation

400 MHz UHF: ≥ 5.0 MHz separation

700 MHz UHF: ≥ 30 MHz separation

800 MHz UHF: ≥ 45 MHz separation

900 MHz UHF: ≥ 24 MHz or 39 MHz separation
