2008
CONDENSED CATALOG
& PRICE LIST
Effective April 1, 2008
passion
ONE
PART
science
TWO
PARTS
passion
ONE PART
science
TWO PARTS
888 E. Porter Road
Muskegon, MI 49441
Toll Free 800-433-9489
Phone 231-798-8888
Fax 231-798-4960
www.structuralconcepts.com
At Structural Concepts, we are passionate about the design and
manufacture of food and floral display cases for the supermarket,
foodservice and convenience store markets. Our temperature controlled
merchandisers will help you dramatically increase sales of fresh baked
goods, delicious deli products, garden-fresh produce and other specialty
items! No where else will you find such a broad offering of refrigerated air
screen and unique combination cases designed to meet a variety of display
needs. And, our on-going advancements in technology make our cases
easy to own and operate for years of trouble-free service.
Many prestigious organizations within the foodservice industry have honored Structural
Concepts for our leadership role in innovative technology development.
General Information
Quick Ship & Express3 Models ................................................................ 10-11
Accessories & Options ............................................................................ 76-77
Foodservice Representatives .................................................................... 78-79
Master Service Agents ............................................................................ 80-83
Warranty and Terms ................................................................................... 84
Factory Contact Information ......................................................................... 85
Encore®
A bakery merchandising system that includes high-volume display cases in a large
variety of styles and sizes, including service, self-service and combination cases.
Combination Cases ................................................................................ 12-17
Service Cases ........................................................................................ 18-29
Self-Service Cases .................................................................................. 30-34
Harmony®
A series of refrigerated service and combination bakery display cases that are less than
34” deep to fit through standard door openings.
Combination Cases ..................................................................................... 35
Service Cases ........................................................................................ 36-37
Renaissance®
A series of mid-volume deli and bakery merchandisers designed with a smaller footprint
than our high-volume Encore Series. Available in a variety of styles and sizes.
Service Bakery Cases ............................................................................ 38-40
Service Deli Cases ................................................................................ 41-42
Service Candy Cases .................................................................................. 43
Oasis®
A comprehensive offering of refrigerated and non-refrigerated open air-screen
merchandisers in a variety of heights and sizes, including several combination cases.
Refrigerated Air Screen Cases .................................................................. 44-49
Non-Refrigerated Self-Service Cases ............................................................... 50
Combination Cases ................................................................................ 51-52
Fusion®
A series of deli and bakery merchandisers that includes refrigerated service and specialty
combination display cases designed to integrate a variety of display merchandising
applications.
Service Deli Cases.................................................................................. 53-54
Service Bakery Cases ............................................................................. 55-56
Combination Cases ................................................................................ 57-63
Work Counter Case ..................................................................................... 64
Self-Service Open Case ................................................................................ 65
Impulse®
A series of refrigerated, non-refrigerated and warm counter top merchandisers, including
refrigerated service and air screen cases that drop into counters.
Self-Service Refrigerated Drop-In Cases ..................................................... 66-68
Service/Self-Service Non-Refrigerated Countertop Cases ............................. 69-70
Self-Service Non-Refrigerated Countertop Cases............................................... 71
Addenda®
A series of non-refrigerated self-service upright wall merchandisers designed to
compliment Encore cases. These cases support a variety of packaged and non-packaged
product applications.
Upright Self-Service Pastry Cases ............................................................. 72-73
Upright Self-Service Pastry/Hard Roll Case ..................................................... 74
Upright Self-Service Shelving/Hard Roll Case ................................................. 75
1O d F 231 798 4960 | C S S P 85
Oversized condenser coil. Our oversized coil takes
strain off the motor by increasing air flow and
consumes less energy. That means a longer life for
the refrigeration system and stronger performance
overall. With the addition of our Clean Sweep®
automatic condenser coil cleaner option, daily dust
buildup is a thing of the past.
It’s the science behind the
beauty that makes our
cases really stand out.
We invest in research and development
because you invest in refrigerated display
cases. Our R&D team creates technology that
provides a return on your investment. Most
of our advancements are designed to extend
maintenance intervals, simplify maintenance,
or automate a maintenance process. We
also create innovative ways to make our
cases more useful, more flexible, and more
customer friendly.
Breeze & Breeze-E
Owning a refrigerated display case shouldn’t
be hard work. That’s the idea behind
Structural Concepts’ Breeze™ refrigeration
system. Breeze is an easier-to-maintain,
truly slide-out refrigeration system. That’s
our science at its best. Then our passion to
meet your needs inspired another idea. NEW
Breeze-E™, the enhanced Breeze offering
a quieter system for Type II environments, is
an option available on select Oasis air screen
cases. It’s the same reliable Breeze, but better
for warmer environments! Both Breeze and
Breeze-E offer rugged reliability, unmatched
ease of service, and superior temperature
consistency.
Technology Overview:
Clean SweepTM
Clean Sweep, an option available with
Breeze and Breeze-E refrigeration
systems, helps prevent costly
breakdowns. The patent-
pending Clean Sweep™
Automatic Condenser Coil
Cleaner is an electronically
controlled brush mechanism
that automatically cleans dust and
debris from the condenser coil.
TYPE II
Breeze-E Is Type II Compliant
With Type II, your case will hold temperature even in
warmer or more humid conditions. Is Breeze-E right
for you? It depends on the environment in which the
case will be used. Many foodservice environments
call for Type II minimums based on the temperature
and humidity level in which the case must operate.
Selecting the right refrigeration system means less
maintenance and reduced cost of ownership.
Type I – Optimal performance at or below 75ºF
with 55% relative humidity.
Type II – Optimal performance at or below 80ºF
with 60% relative humidity.
It’s Quieter: Breeze-E Has Whisper Cool™
You have a lot of equipment in your operation, and all
of it together creates an annoying background din. So
when the market asked for quieter operation, Structural
Concepts stepped up to the plate. New Whisper Cool
technology is really something to shout about.
* Independent test lab results. Tests performed on SCC Oasis
model CO3660R with standard refrigeration package and
new Breeze-E.
Noise
Reduction*
45%
NEW
A “stronger” Breeze for warmer environments and quieter operation.
A reduction of 8 decibels results in a 45%
reduction in sound.
Slide-out refrigeration. Breeze is the first system truly designed to
slide out, making it quick and easy to maintain. Breeze replaces
copper tubing, which can kink or break, with flexible synthetic
hosing. Flexibility is the key: the system can slide in and out
repeatedly without risk of refrigerant leaks or blockages. Breeze’s
components can be easily reached for cleaning or adjustment, no
special tools needed. Rapid, simple service is, well, a Breeze.
Breeze’s smart microprocessor recognizes ambient conditions and
adjusts the defrost cycle automatically—longer when there’s
more ice on the coil and shorter when there’s less. Defrosting “as
needed” eliminates the ice buildup and fluctuating temperatures
associated with mechanical time clock systems. The result is
consistent temperatures—the key to product shelf life.
Case with new
Breeze-E with
Whisper Cool
(51.71dB)
Standard Case
(59.71dB)
45% Sound
Reduction
60dB
55dB
50dB
45dB
40dB
2O d F 231 798 4960 | C t S t S P 85
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
Combination Cases
HOU4852R | See page 12
H5C5650LR | See page 16HSL4850R | See page 17
HVLD56RSS | See page 15
Single cases with multiple display areas that support different product temperatures and access options while optimizing precious floor space.
RB5C5948LR | See page 40
NEW
(Narrow Depth)
HMBC4 | See page 35
HUDLR3852 | See page 13
3O d F 231 798 4960 | C S S P 85
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
C3Z3667 | See page 51
C
3Z3667
|
See
p
a
g
e 51 FSGURLR7257 | See page 58FSGURLR7257
|
See
p
a
g
e 5
8
FSP72 | See page 63
No Rear Storage
FSGUWLR7254 | See page 60
F
SGUWLR7254
|
See page 60
FSGURLR7257 | See page 58
COU2757R | See page 52
FS04837R | See page 64
FSP7242R.T1 | See page 62
With Rear Storage
FSGUWLR48.T1 | See page 59
4O d F 231 798 4960 | C t S t S P 85
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
Service Cases
Refrigerated, non-refrigerated and heated, glass enclosed display cases designed to enhance the presentation and stimulate sales of fresh food.
FSBG48R.T1 | See page 55
HV48R | See page 18 HMG3953R | See page 36 HMG5153 | See page 37
RT48 | See page 21 RTS48 | See page 22
RTS36
See page 22
RTSOW90
See page 24
DTSIW45
See page 26
DTSOW90
See page 27
DTP36
See page 28
5O d F 231 798 4960 | C S S P 85
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
G24F | See page 29
FSDG48R.T1 | See page 53 FSDG48W.T1 | See page 54
RDG5948R | See page 41
RBG4848R | See page 38 RBG5948 | See page 39 RCG4848R | See page 43
RDG7748W | See page 42
6O d F 231 798 4960 | C t S t S P 85
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
Grab-n-Go Cases
Modular, flexible display cases with an open front for easy access to food. Internal refrigeration is maintained by an innovative front air curtain.
CO4778R | See page 44
CO3660R | See page 45
HV56RSS | See page 30
B42 | See page 48
NEW
“Front Breathing”
Air Screen
7O d F 231 798 4960 | C S S P 85
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
CO2739R | See page 47
HV3638RSS | See page 32
CO4748R | See page 46 MP5348RSS | See page 49
8O d F 231 798 4960 | C t S t S P 85
DO3616R | See page 68
Glass enclosed and open reach-in display cases designed to set on or drop into counters.
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
Counter Cases
DO4837R | See page 66
DO3623R | See page 67DO3623R
|
See page 6
7
CSC3223 | See page 71
CGC3830 | See page 70 CGS2830 | See page 69
(Case shown reversed – Self Service)
9O d F 231 798 4960 | C S S P 85
CSF4231 | See page 72
Many models shown include optional features and accessories. Refer to appropriate page for breakdown of standard and optional features.
Self-service cases, for quick and easy customer selection.
PC7482 | See page 73
Non-Refrigerated Cases
HVB74SS | See page 33
PHRM5682 | See page 74
HVAD48SS | See page 34
SHRM5682 | See page 75
10 O d F 231 798 4960 | C t S t S P 85
Note: Must specify on purchase order if Express 3 or Quick-Ship models are requested. Commitments will be
made on a first-come, first-serve basis and inventory may be limited while stock is being replenished.
Available to ship within 10 Business days
Standard specifications listed below
You choose:
s%XTERIORCOLOR
s%NDPANELSTYLEWHEREAPPLICABLE
Designated by adding - QS to models
Available to ship within 3 Business days
Standard specifications listed below
Black Exterior
Black Interior
Black Trim
Designated by adding - E3 to models
QUICK SHIP PROGRAM
OASIS® Refrigerated Air Screen Cases
PROGRAM SPECS
Black interior, black exterior, self-contained
refrigeration, angled base, full end panels,
four lighted shelves, casters.
MODEL List Price
CO3678R-E3 $11,321
CO4778R-E3 $12,057
CO5978R-E3 $13,168
CO7178R-E3 $14,029
ENCORE® Combo Service Above Self-Service Cases
PROGRAM SPECS
Black interior, black exterior, black trim, self-contained
refrigeration, straight base, full end panels, 2”H display
steps, clear glass rear sliding doors.
4OPSECTIONNOTDIVIDEDON(/52
MODEL List Price
HOU3852R-E3 $15,693
HOU4852R-E3 $16,693
HOU5652R-E3 $17,861
HOU7452R-E3 $19,259
HARMONY® Refrigerated Service Cases
PROGRAM SPECS
Black interior, black trim, self-contained refrigeration, straight base, clear glass rear sliding
DOORS(-'2(-'2ONEREARSWINGINGDOOR(-'2
MUST SELECT
%XTERIORCOLORENDPANELSTYLEFULLORCUTAWAY
List Price List Price
MODEL Full Ends Cutaway Ends
HMG2653R-QS $13,822 $15,002
HMG3953R-QS $14,604 $15,784
HMG5153R-QS $15,402 $16,582
HMG6353R-QS $16,131 $17,311
HMG7553R-QS $16,725 $17,905
ENCORE® Combination Refrigerated Service
Beside Non-Refrigerated Service Cases
PROGRAM SPECS
Black interior, black trim, self-contained refrigeration,
straight base, clear glass rear sliding doors.
MUST SELECT
%XTERIORCOLORENDPANELSTYLEFULLORCUTAWAY
List Price List Price
MODEL Full Ends Cutaway Ends
H5C4850LR-QS $16,383 $17,563
H5C5650LR-QS $17,123 $18,303
H5C7450LR-QS $17,794 $18,974
ENCORE® Combo Service Above Self-Service Cases
PROGRAM SPECS
Black interior, black trim, self-contained refrigeration,
straight base, full end panels, 2”H display steps, clear
GLASSREARSLIDINGDOORS4OPSECTIONNOTDIVIDEDON
(/52
MUST SELECT
Exterior color.
MODEL List Price
HOU3852R-QS $15,693
HOU4852R-QS $16,693
HOU5652R-QS $17,861
HOU7452R-QS $19,259
ENCORE® Refrigerated Service Cases
PROGRAM SPECS
Black interior, black trim, self-contained refrigeration,
straight base, clear glass rear sliding doors.
MUST SELECT
%XTERIORCOLORENDPANELSTYLEFULLORCUTAWAY
List Price List Price
MODEL Full Ends Cutaway Ends
HV38R-QS $14,604 $15,784
HV48R-QS $15,402 $16,582
HV56R-QS $16,131 $17,311
HV74R-QS $16,725 $17,905
1O d F 231 798 4960 | C S S P 85
QUICK SHIP PROGRAM
OASIS® Refrigerated Air Screen Cases
PROGRAM SPECS
Black interior, self-contained refrigeration, four lighted
shelves, angled base, casters.
MUST SELECT
%XTERIORCOLORENDPANELSTYLEFULLORCUTAWAY
List Price List Price
MODEL Full Ends Cutaway Ends
CO3678R-QS $11,321 $11,681
CO4778R-QS $12,057 $12,417
CO5978R-QS $13,168 $13,528
CO7178R-QS $14,029 $14,389
OASIS® Refrigerated Air Screen Cases
PROGRAM SPECS
Black interior, self-contained refrigeration, two lighted
shelves, angled base, casters.
MUST SELECT
%XTERIORCOLORENDPANELSTYLEFULLORCUTAWAY
List Price List Price
MODEL Full Ends Cutaway Ends
CO3660R-QS $10,732 $11,092
CO4760R-QS $11,481 $11,841
CO5960R-QS $12,506 $12,866
CO7160R-QS $13,262 $13,622
OASIS® Combination Case
PROGRAM SPECS
Black interior, self-contained refrigeration, black shelving,
top light and shelf light, clear glass rear doors.
MUST SELECT
Exterior color
MODEL List Price
COU2757R-QS $11,153
IMPULSE® Non-Refrigerated Self-Service Countertop Case
PROGRAM SPECS
Black interior color and frame, solid back panel,
gray base.
MODEL List Price
CSC3223-QS $3,515
®
PROGRAM SPECS
Black upper frame and interior, gray lower base,
solid back panel.
MODEL List Price
CSF4231-QS $4,982
OASIS® Refrigerated Air Screen Cases
PROGRAM SPECS
Black interior, self-contained refrigeration, two
non-lighted shelves, angled base, casters.
MUST SELECT
%XTERIORCOLORENDPANELSTYLEFULLORCUTAWAY
List Price List Price
MODEL Full Ends Cutaway Ends
CO4748R-QS $10,346 $10,706
OASIS® 24”D Refrigerated Air Screen Case
PROGRAM SPECS
Black interior, self-contained refrigeration, four
lighted shelves, casters.
MUST SELECT
Exterior laminate for header, front & end panels.
MODEL List Price
B32-QS $10,799
B42-QS $11,500
B62-QS $13,372
B82-QS $17,680
Quick-Ship Models
List price shown reflects model pricing based on features
listed, non-premium laminate and end panel style. Cutaway
list price reflects cost of two ends. Exterior color selection may
add additional charges to the list price. Refer to specific model
page of catalog to determine if exterior upcharge applies.
Contact Structural Concepts’ Customer Service Department for
additional information on specific model availability.
ADDENDA Self-Service Floor Case
12 O d F 231 798 4960 | C S S P 85
ENCORE®
Combination Convertible Service Above
Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 5PPERSERVICEDISPLAYAREA
- Baffle system converts display from refrigerated to non-refrigerated
- Clear glass rear sliding doors
- Curved single pane lift-up front glass
- Adjustable clear glass shelf (15 3/4”D)
- Upper level deck (20 3/8”D)
s ,OWERREFRIGERATEDSELFSERVICEDISPLAYAREA
- Single display level consisting of bottom sheet metal deck (29 1/2”D)
- Header light
s 4WOFULLENDPANELSWITHMIRRORINTERIORLOWERSECTION
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1 3
4
2
Mirror
on inside
of end
panels
(/52
Shown with optional display steps in lower display area.
NOTE: Upper display area in HOU3852R is not divided. ABS base option
MODEL HOU3852R HOU4852R HOU5652R HOU7452R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(/52 900 5-20P 2,948
(/52 1,050 14-20P 3,431
(/52 1,060 14-20P 3,817
(/52 1,220 14-30P 4,900
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
$ISPLAYSTEPSFORLOWERDISPLAYvORv(
,IGHTEDGLASSSHELFFORLOWERDISPLAYv$
2EARWRAPPINGBOARD8”D
2EMOVABLEWIRESECURITYCOVERLOCKINGFORLOWERDISPLAYINCLUDESUPPERFRONT
GLASSLOCK
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
See page 10
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
1
O d F 231 798 4960 | C S S P 85
ENCORE®
Combination Non-Refrigerated Service
Above Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 5PPERNONREFRIGERATEDSERVICEDISPLAYAREA
- Clear glass rear sliding doors
- Curved single pane lift-up front glass
- Adjustable clear glass shelf (15 3/4”D)
- Upper level deck (20 3/8”D)
s ,OWERREFRIGERATEDSELFSERVICEDISPLAYAREA
- Single display level consisting of bottom sheet metal deck
(29 1/2”D)
- Top light
s 4WOFULLENDPANELSWITHMIRRORINTERIORLOWERSECTION
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1 3
4
2
Mirror
on inside
of end
panels
(5$,2
Shown with optional display steps in lower display area.
NOTE: Upper display area is not divided in HUDLR models.
MODEL HUDLR3852 HUDLR4852 HUDLR5652 HUDLR7452
DIMENSIONS v,Xv$x 53”H v,Xv$ x 53”H v,XvD x 53”H v,X”D x 53”H
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(5$,2 850 5-20P 1,762
(5$,2 900 14-20P 2,565
(5$,2 1,100 14-20P 2,860
(5$,2 1,150 14-30P 3,738
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITe
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR3#LEARGLASSSLIDINGDOORS REFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUs
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
$ISPLAYSTEPSFORLOWERDISPLAYvORv(
,IGHTEDGLASSSHELFFORLOWERDISPLAYv$
2EARWRAPPINGBOARD8”D
2EMOVABLEWIRESECURITYCOVERLOCKINGFORLOWERDISPLAYINCLUDESUPPERFRONT
GLASSLOCK
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
14 O d F 231 798 4960 | C S S P 85
ENCORE®
Combination Refrigerated Service
Above Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 5PPERREFRIGERATEDSERVICEDISPLAYAREA
- Clear glass rear sliding doors
- Curved single pane lift-up front glass
- Adjustable clear glass shelf (15 3/4”D)
- Upper level deck (20 3/8”D)
s ,OWERREFRIGERATEDSELFSERVICEDISPLAYAREA
- Single display level consisting of bottom sheet metal deck
(29 1/2”D)
- Top light
s 4WOFULLENDPANELSWITHMIRRORINTERIORLOWERSECTION
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1 3
4
2
Mirror
on inside
of end
panels
(52,2
Shown with optional display steps in lower display area.
NOTE: Upper display area is not divided in HURLR models.
MODEL HURLR3852 HURLR4852 HURLR5652 HURLR7452
DIMENSIONS v,Xv$x 53”H v,Xv$ x 53”H v,XvD x 53”H v,X”D x 53”H
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(52,2 850 5-20P 2,948
(52,2 890 14-20P 3,431
(52,2 900 14-20P 3,817
(52,2 1,200 14-30P 4,686
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITe
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR3#LEARGLASSSLIDINGDOORS REFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUs
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
$ISPLAYSTEPSFORLOWERDISPLAYvORv(
,IGHTEDGLASSSHELFFORLOWERDISPLAYv$
2EARWRAPPINGBOARD8”D
2EMOVABLEWIRESECURITYCOVERLOCKINGFORLOWERDISPLAYINCLUDESUPPERFRONT
GLASSLOCK
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
1
O d F 231 798 4960 | C S S P 85
ENCORE®
Combination Non-Refrigerated Service
Beside Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
Non-Refrigerated Service Side
s ADJUSTABLECLEARGLASSSHELVESv$v$v$
s 2EARSWINGOUTDOOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
Refrigerated Self-Service Side
s ADJUSTABLECLEARGLASSSHELVESv$v$v$
s "OTTOMSHEETMETALDECK
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1
3
4
2
Mirror
on inside
of end
panels
(6,$233
MODEL HVLD48RSS HVLD56RSS HVLD74RSS
$IMENSIONS v,X”D x 51”H
$RYv2EFRIGv
v,X2”D x 51”H
$RYv2EFRIGv
v,X42”D x 51”H
$RYv2EFRIGv
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(6,$233 970 14-20P 3,130
(6,$233 1,020 14-20P 4,004
(6,$233 1,150 14-20P 5,318
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITe
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
&RONT0ANEL3TYLE33TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE4&ULLWITHMIRROR #UTAWAYWITHGLASS
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUs
-USTBECHOSENWHEN
CASEISORDERED
&RONTGLASSLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EMOVABLEWIRESECURITYCOVERLOCKINGFORREFRIGERATEDSIDE
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
Non-Refrigerated
Service Side
Refrigerated
Self-Service Side
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
16 O d F 231 798 4960 | C S S P 85
ENCORE®
Combination Refrigerated Service Beside
Non-Refrigerated Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s )NTERIORDISPLAYAREASPLITREFRIGERATEDANDNONREFRIGERATED
s 4HREEADJUSTABLEREMOVABLECLEARGLASSSHELVESONEACHSIDE
v$v$v$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #LEARGLASSREARSLIDINGDOORS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s "OTTOMSHEETMETALDECK
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s 5,#ERTIFIEDTO.3&3TANDARD
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1
5
3
4
2
Mirror
on inside
of end
panels
(#,2
MODEL** H5C4850LR/H5C4850RR H5C5650LR/H5C5650RR H5C7450LR/H5C7450RR
$IMENSIONS v,X”D x 51”H v,X2”D x 51”H v,X42”D x 51”H
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(#,222 950 5-15P 1,412
(#,222 1,030 5-15P 1,655
(#,222 1,220 5-15P 2,069
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
&ROMCUSTOMERSIDE,2LEFTREFRIG22RIGHTREFRIG
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITe
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR3#LEARGLASSSLIDINGDOOR REFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE5&ULLWITHMIRROR #UTAWAYWITHGLASS
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
See page 10
1
O d F 231 798 4960 | C S S P 85
ENCORE®
Combination Non-Refrigerated Service
Above Refrigerated Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 3PLITINTERIORDISPLAYAREAUPPERNONREFRIGERATEDLOWERREFRIGERATED
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #LEARGLASSREARSLIDINGDOORSUPPERANDLOWER
s "OTTOMSHEETMETALDECK
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s 5,#ERTIFIEDTO.3&3TANDARD
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1 3
4
2
Mirror
on inside
of end
panels
(3,2
MODEL HSL3850R HSL4850R
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(3,2 850 5-15P 1,350
(3,2 880 5-15P 1,477
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
3HELVING .ONEUPPERANDLOWERAREAS ,IGHTEDGLASSSHELFINLOWERREFRIGERATEDDISPLAYv$
,IGHTEDGLASSSHELFINUPPERNONREFRIGERATEDDISPLAYAREAv$
5PPERAND,OWER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE43TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCKFORBOTHSETSOFDOORS
&RONTGLASSLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
18 O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLECLEARGLASSSHELVESv$v$v$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s "OTTOMSHEETMETALDECK
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1 3
4
5
2
Mirror
on inside
of end
panels
Black
HV48R
MODEL HV38R HV48R HV56R HV74R HV96R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
HV38R 800 5-15P 2,445
HV48R 960 5-15P 2,844
HV56R 1,020 5-15P 3,289
HV74R 1,230 14-20P 4 3,832
HV96R 1,480 14-20P 4,920
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE5&ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
See page 10
1
O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Service Case
Standard Features
s 4HREEADJUSTABLEREMOVABLEWIRESHELVESv$v$v$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s "OTTOMSHEETMETALDECK
s 4TOPLIGHTANDSHELFLIGHTS
s vPOWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1 3
4
5
2
Mirror
on inside
of end
panels
HV48
MODEL HV38 HV48 HV56 HV74
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
HV38 700 5-15P
HV48 750 5-15P
HV56 750 5-15P
HV74 980 5-15P
TRAY CAPACITY HV38* HV48* HV56* HV74*
4OPSHELFv$ XTRAYS XTRAYS XTRAYS XTRAYS
SeCONDSHELFv$ XTRAYS XTRAYS XTRAYS XTRAYS
4HIRDSHELFv$ XTRAYS XTRAYS XTRAYS XTRAYS
$ECKv$ XTRAYS XTRAYS XTRAYS XTRAYS
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITe
3TAINLESS3TEEL
.#
%XTERIOR#OLOR 1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR 2"LACK 3ILVER
'OLD
.#
3HELVING 7IRERACKS 'LASS3HELVES
5PPER2EAR 3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE 4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE 5&ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
DeDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERS
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
FrONTGLASSLOCK
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
*Trays not supplied with unit
Optional glass shelves
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
20 O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Service Candy Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLECLEARGLASSSHELVESv$v$v$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1 3
4
5
2
Mirror
on inside
of end
panels
Black
HVC48R
MODEL HVC38R HVC48R
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
HVC38R 850 5-15P 1,097
HVC48R 850 5-15P
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE4 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE5&ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
#ONTACT &ACTORY
2
O d F 231 798 4960 | C S S P 85
ENCORE®
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
24 1,200 5-15P 2,482
24 1,270 14-20P 3,639
24 1,750 14-20P 4,611
Refrigerated Display Table-Straight Front Glass
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOENDPANELS
s 3TRAIGHTSINGLEPANEFRONTTOPANDENDGLASS
s /PENUPPERREAR
s .ONREFRIGERATEDREARSTORAGE
s 3TRAIGHTLAMINATEDFRONTPANELS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
24
MODEL RT48 RT72 RT96
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HIte
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
0
#ALLFORQUOTE
)NTERIORDISPLAY,
FRONTANDREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
&RONTGLASSPOSTS3"LACK 3ILVER .#
"ACK0ANEL 3OLIDBACK7HITE "LACK .#
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
,IGHTS .ONE ,%$4OP,IGHTINGv
,%$4OP,IGHTINGv
,%$4OP,IGHTINGv
&RONT0ANEL3TYLE53TRAIGHTFRONT #URVEDFRONTFOLLOWSSHAPEOFCURVEDFRONTLEDGE
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
SeCONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
1
2
4
5
3
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
22 O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Display Table - Curved Front Glass
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s /NEREFRIGERATEDDISPLAYLEVEL
s 4WOENDPANELS
s #URVEDSINGLEPANEFIXEDFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake through rear and out front panel.
Toe kick cannot be blocked.
NOTE: Floor plan required.
NOTE: Front glass and solid surface material shipped loose.
Must be installed after case is positioned in place.
243
MODEL RTS36 RTS48 RTS60
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
243 1,200 5-20P 1,708
243 1,200 5-20P 2,392
243 1,250 5-20P 2,861
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
20
#ALLFORQUOTE
&RONT'LASS0OSTS3"LACK 3ILVER .#
%ND0ANEL 3OLIDENDWITHGLASSUPPER #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ACK0ANEL 3OLIDBACK7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE53TRAIGHTFRONT 3TEPFRONTINCREASESDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
#LEAN3WEEP©AUTOMATICCONDENSERCOILCLEANer
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
Step Front
Option
32
1
5
4
4OTOPOFGLASS
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
2
O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Inside Corner Display
- Spherical Front Glass
Standard Features
s .ONREFRIGERATEDREARSTORAGEWITHOUTDOORS
s .OENDPANELS
s 3PHERICALSINGLEPANEFIXEDFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORWARRANTY
NOTE: Floor plan required.
NOTE: Front glass and solid surface material shipped loose.
Must be installed after case is positioned in place.
MODEL RTSIW45 RTSIW90
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
243)7 1,200 1,760
243)7 1,200 3,520
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HIte
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
0
#ALLFORQUOTE
&RONT'LASS0OSTS3"LACK 3ILVER .#
%ND0ANEL .OENDPANEL 3OLIDENDWITHGLASSUPPER
#ASETOCASEGLASSEND
END
END
"ACK0ANEL 3OLIDBACK7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE53TRAIGHTFRONT 3TEPFRONTINCREASEDDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
2EFRIGERATION 2EMOTECOMPRESSORSUPPLIED
BYOTHERS
3ELFCONTAINEDREFRIGERATION4"$BASEDONLINEUP #ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
243)7
3
2
1
4
5
-USTCHOOSEONEWHENPLACINGORDER
Step Front
Option
Shown with
optional
end panels
4OTOPOFGLASS
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
#ONTACT &ACTORY
4"$ "ASED ON LINE UP
24 O d F 231 798 4960 | C S S P 85
ENCORE®
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
&RONT'LASS0OSTS3"LACK 3ILVER .#
%ND0ANEL .OENDPANEL 3OLIDENDWITHGLASSUPPER
#ASETOCASEGLASSEND
END
END
"ACK0ANEL 3OLIDPANEL7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE53TRAIGHTFRONT 3TEPFRONTINCREASESDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
2EFRIGERATION 2EMOTECOMPRESSORSUPPLIED
BYOTHERS
3ELFCONTAINEDREFRIGERATION4"$BASEDONLINEUP #ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
Refrigerated Outside Corner Display
- Spherical Front Glass
Standard Features
s /NEREFRIGERATEDDISPLAYLEVEL
s .OENDPANELS
s 3PHERICALSINGLEPANEFIXEDFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORWARRANTY
NOTE: Floor plan required.
NOTE: Front glass and solid surface material shipped loose.
Must be installed after case is positioned in place.
MODEL RTSOW45 RTSOW90
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
243/7 1,200 1,444
243/7 1,200 2,888
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
243/7
-USTCHOOSEONEWHENPLACINGORDER
Step Front
Option
3
2
1
4
5
Shown with
optional
end panels
4OTOPOFGLASS
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
#ONTACT &ACTORY
4"$ "ASED ON LINE UP
2
O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Display Table
- Curved Front Glass
Standard Features
s /NENONREFRIGERATEDDISPLAYLEVEL
s 4WOENDPANELS
s #URVEDSINGLEPANEFIXEDFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s YEARPARTSANDLABORWARRANTY
NOTE: Floor plan required.
NOTE: Front glass and solid surface material shipped loose.
Must be installed after case is positioned in place.
MODEL DTS36 DTS48 DTS60
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
$43 990 .! .! .!
$43 1,000 .! .! .!
$43 1,250 .! .! .!
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
&RONT'LASS0OSTS3"LACK 3ILVER .#
%ND0ANEL 3OLIDENDWITHGLASSUPPER #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ACK0ANEL 3OLIDPANEL7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE53TRAIGHTFRONT 3TEPFRONTINCREASESDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS #ASTERS
v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
$43 Step Front
Option
3
2
1
4
5
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
4OTOPOFGLASS
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
26 O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Inside Corner Display
- Spherical Front Glass
Standard Features
s /NENONREFRIGERATEDDISPLAYLEVEL
s .OENDPANELS
s 3PHERICALSINGLEPANEFIXEDFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s YEARPARTSANDLABORWARRANTY
NOTE: Floor plan required.
NOTE: Front glass and solid surface material shipped loose.
Must be installed after case is positioned in place.
$43)7
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
&RONT'LASS0OSTS3"LACK 3ILVER .#
%ND0ANEL .OENDPANEL 3OLIDENDWITHGLASSUPPER
#ASETOCASEGLASSEND
END
END
"ACK0ANEL 3OLIDPANEL7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE53TRAIGHTFRONT 3TEPFRONTINCREASESDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
MODEL DTSIW45 DTSIW90
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
$43)7 990 .! .! .!
$43)7 1,000 .! .! .!
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
Step Front
Option
3
2
1
4
5
Shown with
optional
end panels
4OTOPOFGLASS
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
2
O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Outside Corner Display
- Spherical Front Glass
Standard Features
s /NENONREFRIGERATEDDISPLAYLEVEL
s .OENDPANELS
s 3PHERICALSINGLEPANEFIXEDFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s YEARPARTSANDLABORWARRANTY
NOTE: Floor plan required.
NOTE: Front glass and solid surface material shipped loose.
Must be installed after case is positioned in place.
$43/7
MODEL DTSOW45 DTSOW90
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
$43/7 990 .! .! .!
$43/7 1,000 .! .! .!
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
&RONT'LASS0OSTS3"LACK 3ILVER .#
%ND0ANEL .OENDPANEL 3OLIDENDWITHGLASSUPPER
#ASETOCASEGLASSEND
END
END
"ACK0ANEL 3OLIDPANEL7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE53TRAIGHTFRONT 3TEPFRONTINCREASESDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK4"LACK 3TAINLESS3TEEL
7HITE
.#
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
Step Front
Option
3
2
1
4
5
-USTCHOOSEONEWHENPLACINGORDER
Shown with
optional
end panels
4OTOPOFGLASS
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
28 O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Pass Through Display
Standard Features
s .ONREFRIGERATEDDISPLAYSURFACE
s .OENDPANELS
s 3TRAIGHTLAMINATEDFRONTPANEL
s YEARPARTSANDLABORWARRANTY
$40
0RODUCT3PECIFICATION StANDARD.# /PTIONS ,IST
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
%ND0ANEL .OENDPANEL 3OLIDEND END
"ACK0ANEL 3OLIDPANEL7HITE "LACK
3TAINLESS3TEEL
.#
&RONT0ANEL3TYLE43TRAIGHTFRONT 3TEPFRONTINCREASESDEPTHOFUNITv
)NTERIORDISPLAY
FRONTREARLEDGE2
#ORIANSOLIDSURFACE"LACK
.IGHT3KY
3OLIDSURFACESPECIALCOLORSMAYINCREASELEADTIME #ALLFORQUOTE
"ASE ,EVELERS #ASTERS
v(LEGSINCREASESHEIGHTOFCASEv
4OE+ICK3"LACK 3TAINLESS3TEEL
7HITE
.#
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
MODEL DTP36 DTP48
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
MODEL WEIGHT
$40 990
$40 1,000
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
3
2
1
4
Step Front
Option
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
2
O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Service Gelato Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WO4TOPLIGHTS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 4WOROWSOFSIGNCHANNELINFRONTOFPANS
s 0AINTEDEXTERIORSPECIFYCOLOR
s 3TAINLESS3TEEL
- Interior
- Lower front panel
- Rear ledge
s ,EVELERS
s &OAMINPLACEINSULATEDTUBFULLYACCESSIBLEFOR
REFRIGERATIONSERVICEANDCLEANING
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
MODEL G24F
$IMENSIONS v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
G24F 1,550 14-30P 4,700
Product Specification Standard (N/C) Option(s) List $
4RIM#OLOR1"LACK 3ILVER .#
5PPER&RONT0ANEL2"LACK 3ILVER
0AINTEDSPECIFYCOLOR
.#
.#
5PPER2EAR3/PEN #LEARGLASSSLIDINGDOORSWOLOCK
%ND0ANEL4&ULLWITHMIRROR #UTAWAYWITHGLASS END
2EFRIGERATION "REEZE4-SELFCONTAINEDWITHREAR
INTAKEFRONTAIRDISCHARGE
ATTOEKICK(floor drain
required)
"REEZE4-SELFCONTAINEDSYSTEMWITHEVAPORATORPAN
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
0ANS 'ELATO3TAINLESS3TEELLITER
PANS
3TAINLESS3TEELONETHIRDSIZEFOODSERVICEPANSPANS .#
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
.IGHTCURTAINPULLDOWNNONLOCKING
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
$IPWELLv
%XTRASETOFPANS'ELATO3TAINLESS3TEELLITERPANS
%XTRASETOFPANS3TAINLESS3TEELONETHIRDSIZEFOODSERVICEPANS
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
G24F
2
1
-USTCHOOSEONEWHENPLACINGORDER
4
3
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
30 O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Self-Service Case - 51”H
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLECLEARGLASSSHELVESv$v$v$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3OLIDBACKPANEL
s "OTTOMSHEETMETALDECK
s /PENREACHINFRONTUNITFILLEDCUSTOMERSELECTIONFROMFRONT
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1
3
2
Mirror
on inside
of end
panels
HV56RSS
MODEL HV38RSS HV48RSS HV56RSS HV74RSS
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
HV38RSS 780 5-20P 4,226
HV48RSS 930 14-20P 5,350
HV56RSS 930 14-20P 6,143
HV74RSS 1,180 14-20P 8,010
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
&RONT0ANEL3TYLE3 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE4 &ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS-USTBECHOSEN
WHENCASEISORDERED
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EMOVABLEWIRESECURITYCOVERLOCKING
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
.OTE0RODUCTTEMPERATURESWILLBEAFFECTEDIFTHEAIRCURTAINISDISRUPTED
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
4
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
3
O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Self-Service Case - 51”H
with Rear Doors
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLECLEARGLASSSHELVESv$v$v$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #LEARGLASSREARSLIDINGDOORSWITHINNERPLEXIPLENUM
s /PENREACHINFRONT
s "OTTOMSHEETMETALDECK
s 4TOPLIGHTANDSHELFLIGHTS
s @POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1
3
4
2
Mirror
on inside
of end
panels
HV56RSSRD
MODEL HV38RSSRD HV48RSSRD HV56RSSRD HV74RSSRD
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
HV38RSSRD 780 5-20P 4,226
HV48RSSRD 900 14-20P 5,350
HV56RSSRD 950 14-20P 6,143
HV74RSSRD 1,100 14-30P 8,010
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
&RONT0ANEL3TYLE33TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE4&ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPAN
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EMOVABLEWIRESECURITYCOVERLOCKING
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE .OTE0RODUCTTEMPERATURESWILLBEAFFECTEDIFTHEAIRCURTAINISDISRUPTED
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
32 O d F 231 798 4960 | C S S P 85
ENCORE®
Refrigerated Self-Service Case - 37”H
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s /NEADJUSTABLEREMOVABLECLEARGLASSSHELFv$
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3OLIDBACKPANEL
s "OTTOMSHEETMETALDECK
s /PENREACHINFRONTUNITFILLEDCUSTOMERSELECTIONFROMFRONT
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Toe kick cannot be blocked.
1
3
4
2
Mirror
on inside
of end
panels
HV3656RSS
MODEL HV3638RSS HV3648RSS HV3656RSS HV3674RSS
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
HV3638RSS 610 5-15P 2,763
HV3648RSS 700 5-20P 3,562
HV3656RSS 750 5-30P 4,260
HV3674RSS 1,000 14-20P 5,630
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
3TAINLESS3TEELSTRAIGHTFRONTPANELREQUIRED
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
&RONT0ANEL3TYLE3 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE4 &ULLWITHMIRROR #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EMOVABLEWIRESECURITYCOVERLOCKING
.IGHTCURTAINPULLDOWNNONLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE .OTE0RODUCTTEMPERATURESWILLBEAFFECTEDIFTHEAIRCURTAINISDISRUPTED
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
3
O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Pull-Out Drawer Case
Standard Features
s 3TAYOPENPULLOUTDRAWERSWITHWIREBASKETSvXvXv
- HVB38SS - 6 drawers
- HVB56SS - 9 drawers
- HVB74SS - 12 drawers
s 4WOFULLENDPANELSNOMIRRORINSIDE
s 4TOPLIGHTANDSHELFLIGHTS
s 2ECESSEDFRONTSTORAGEFORPACKAGINGSUPPLIES
s vPOWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
3
4
2
MODEL HVB38SS HVB56SS HVB74SS
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
(6"33 650 5-15P
(6"33 950 5-15P
(6"33 1,050 5-15P
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE .#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR /PEN.ODOORS 3OLIDBACKPANELWHITE
#LEARORREFLECTIVEGLASSSLIDINGDOORS
&RONT0ANEL3TYLE3 3TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE4 &ULLNOMIRROR $EDUCTENDPANELFORCASETOCASELINEUPS END
"ASE ,EVELERS #ASTERS
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
7IREBASKETSv(#HROMEOR"LACK
"ASKETLINERSv(ORv(
4ONGSINSIDEOFBASKET
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
-AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
4HE(6"MODELSCANONLYBEJOINEDWITHOUTENDPANELSTOOTHER(6"MODELS
(6"33
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
34 O d F 231 798 4960 | C S S P 85
ENCORE®
Non-Refrigerated Acrylic Door Case
Standard Features
s 4WOADJUSTABLEREMOVABLEWIRERACKSHELVESv$v$
s #LEARACRYLICLIFTUPFREEFALLFRONTDOORS
- HVAD48SS/HVAD56SS - 6 doors
- HVAD74SS - 9 doors
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 4RAYCAPACITY
- HVAD48SS - (6) -18”x26” trays (not supplied with unit)
- HVAD56SS - (9) 18”x26” trays (not supplied with unit)
- HVAD74SS - (12) 18”x26” trays (not supplied with unit)
s 4TOPLIGHTANDSHELFLIGHTS
s 2ECESSEDFRONTSTORAGEFORPACKAGINGSUPPLIES
s vPOWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
3
4
2
Mirror
on inside
of end
panels
(6!$33
NOTE: Trays not supplied with unit.
MODEL HVAD48SS HVAD56SS HVAD74SS
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
(6!$33 700 5-15P
(6!$33 800 5-15P
(6!$33 850 5-15P
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE .#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
0AINTEDAPPLIESONLYWITH!"3ANGLEDFRONTPANELSPECIFYCOLOR
/AKVENEERWITHCLEARSEALERSTRAIGHTFRONTPANELREQUIRED
/AKVENEERSTAINEDSTRAIGHTFRONTPANELREQUIREDCOLORMATCHREQUIRED
#ALLFORQUOTE
.#
4RIM#OLOR2"LACK 3ILVER
'OLD
.#
5PPER2EAR #LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
3OLIDBACKPANELWHITE
&RONT0ANEL3TYLE33TRAIGHTFRONTLAMINATED !"3UPPERFRONTWITHANGLEDLOWERPAINTEDCASEISvLESSDEEP .#
%ND0ANEL3TYLE4&ULLWITHMIRROR $EDUCTENDPANELFORCASETOCASELINEUPS END
"ASE ,EVELERS #ASTERS
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
-AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
4HE(6!$MODELSCANONLYBEJOINEDWITHOUTENDPANELSTOOTHER(6!$MODELS
ABS base option
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
HARMONY®
3
O d F 231 798 4960 | C S S P 85
34”D Combination Convertible Service
Above Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 5PPERSERVICEDISPLAYAREA
- Baffle system converts display from refrigerated to non-refrigerated
- One rear swinging door (HMBC2)
- Clear glass rear sliding doors (HMBC3 - HMBC6)
- Clear glass lighted shelf
- Curved double pane lift-up front glass
s ,OWERREFRIGERATEDSELFSERVICEDISPLAYAREA
- Single sheet metal deck
s 4WOCUTAWAYENDPANELS
s 3TRAIGHTFRONTPANEL
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
MODEL HMBC2 HMBC3 HMBC4 HMBC5 HMBC6
$IMENSIONS
v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIORCOLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
3TAINLESS3TEEL
4RIM#OLOR2"LACK 3ILVER N/C
5PPER2EAR3#LEARGLASSSLIDINGDOORS
3WINGINGDOOR(-"#
2EFLECTIVEGLASSSLIDINGDOOR
,OWER2EAR 3OLIDBACKPANELWHITE 2EARSLIDINGDOORS
(-"#SWINGINGDOOR
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
5PPERREARDOORLOCK
,OWERREARDOORLOCK
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEAREXTENDEDPARTSANDLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
0RICETAGMOLDING
2EARWRAPPINGBOARD
$ISPLAYSTEPFORLOWERDISPLAYvORv(INLIEUOFSHELF
#LEARGLASSLIGHTEDSHELFFORLOWERDISPLAY
"OTTLESLIDEFORLOWERDISPLAY
.IGHTCURTAINPULLDOWNNONLOCKING
2EMOVABLEWIRESECURITYCOVERLOCKING
!NGLEDSHEETMETALDECK
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSABOVE&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
NOTE: Non-divided upper display area - HMBC2 & HMBC3.
Divided upper display area - HMBC4, HMBC5, HMBC6.
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
(-"# 800
(-"# 850
(-"# 880
(-"# 900
(-"# 1,150
JUNE 2008
/RDER%NTRY2EADY
NOTE: Shown with optional bottle
slide in lower display
Mirror
on inside
of end
panels
1
23
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
This model may require additional lead time
Contact factory for technical electrical information.
(-"#
HARMONY®
36 O d F 231 798 4960 | C S S P 85
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
HMG2653R 500
HMG3953R 900
HMG5153R 900
HMG6353R 1,150
HMG7553R 1,150
32”D Refrigerated Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLECLEARGLASSSHELVESv$v$v$
s /NEREARSWINGINGDOOR(-'2
s #LEARGLASSREARSLIDINGDOORS(-'2(-'2
s #URVEDDOUBLEPANELIFTUPFRONTGLASS
s 4TOPLIGHTANDSHELFLIGHTS
s 3TRAIGHTFRONTPANEL
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
MODEL HMG2653R HMG3953R HMG5153R HMG6353R HMG7553R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIORCOLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
5PPER2EAR #LEARGLASSSLIDINGDOORS
3WINGING,(HINGEDOOR
(-'2
2EFLECTIVEGLASSSLIDINGDOORS
#LEARGLASSSWINGING2(HINGEDOOR(-'2
N/C
%ND0ANEL3TYLE3&ULLWITHMIRROR #UTAWAYWITHGLASSCANNOTBEJOINED END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSANDLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGES
FORINFORMATION
0RICETAGMOLDING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSABOVE&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
HMG3953R
NOTE: Shown with cutaway
with glass end panels
1
2
3
See page 10
This model may require additional lead time
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
Contact factory for technical electrical information.
v,Xv$Xv(
HARMONY®
3
O d F 231 798 4960 | C S S P 85
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
HMG2653 400 120/1/60 5-15P
HMG3953 700 120/1/60 5-15P
HMG5153 120/1/60 5-15P
HMG6353 950
HMG7553 120/1/60 5-15P
32”D Non-Refrigerated Service Bakery
Standard Features
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s /NEREARSWINGINGDOOR(-'
s #LEARGLASSSLIDINGDOORS(-'(-'
s 4HREEWIRESHELVESv$v$v$
s 4TOPLIGHTANDSHELFLIGHTS
s vPOWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
MODEL HMG2653 HMG3953 HMG5153 HMG6353 HMG7553
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIORCOLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
5PPER2EAR #LEARGLASSSLIDINGDOORS
3WINGING,(HINGEDOOR
(-'
2EFLECTIVEGLASSSLIDINGDOORS
#LEARGLASSSWINGING2(HINGEDOOR(-'
N/C
%ND0ANEL3TYLE3&ULLWITHMIRROR #UTAWAYWITHGLASSCANNOTBEJOINED END
"ASE ,EVELERS #ASTERS
v(LEGSINCREASESHEIGHTOFCASEv
3HELVING 7IRESHELVES #LEARGLASSSHELVES
3MOKEDGLASSSHELVES
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3ECONDYEARPARTSANDLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGES
FORINFORMATION
0RICETAGMOLDING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSABOVE&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
HMG5153
NOTE: Shown with cutaway
with glass end panels
1
2
3
This model may require additional lead time
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
800
1150
120/1/60 1. 6 5-15P
RENAISSANCE®
38 O d F 231 798 4960 | C S S P 85
Refrigerated Service Case (Bakery)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLEGLASSSHELVESv$v$v$
s 4WOCUTAWAYWITHGLASSENDPANELS
s #LEARGLASSREARSLIDINGDOORS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
1 3
4
2
Black
2"'2
MODEL RBG4848R RBG5948R RBG7748R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
2"'2 850 5-20P NA
2"'2 950 5-20P 2,330
2"'2 1,100 5-20P 2,904
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER .#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE4#UTAWAYWITHGLASS &ULLWITHMIRROR END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEOVERGLASS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
&RONTPACKAGELEDGEv$
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
RENAISSANCE®
3
O d F 231 798 4960 | C S S P 85
1 3
4
2
Black
Non-Refrigerated Service Case (Bakery)
Standard Features
s 4HREEADJUSTABLEREMOVABLEWIRESHELVESv$v$v$
s 4WOCUTAWAYWITHGLASSENDPANELS
s #LEARGLASSREARSLIDINGDOORS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPLIGHTANDSHELFLIGHTS
s vPOWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s 5,#ERTIFIEDTO.3&3TANDARD
s YEARPARTSANDLABORWARRANTY
2"'
MODEL RBG4848 RBG5948 RBG7748
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS H/P NEMA PLUG
2"' 660 .! 5-15P
2"' 900 .! 5-15P
2"' 1,000 .! 5-15P
TRAY CAPACITY* RBG4848* RBG5948* RBG7748*
4OP3HELFv XTRAYS XTRAYS XTRAYS
3ECOND3HELFv XTRAYS XTRAYS XTRAYS
4HIRD3HELFv XTRAYS XTRAYS XTRAYS
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER .#
3HELVING 7IRERACKS #LEARGLASS
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE4 #UTAWAYWITHGLASS &ULLWITHMIRROR END
"ASE ,EVELERS #ASTERS
v(LEGSINCREASESHEIGHTOFCASEv
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
&RONTPACKAGELEDGEv$
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
*Trays not supplied with unit
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
RENAISSANCE®
40 O d F 231 798 4960 | C S S P 85
Combination Refrigerated Service Beside
Non-Refrigerated Service Case (Bakery)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s )NTERIORDISPLAYAREASPLITREFRIGERATEDNONREFRIGERATED
s 4HREEADJUSTABLEREMOVABLEGLASSSHELVESONEACHSIDE
v$v$v$
s 4WOCUTAWAYWITHGLASSENDPANELS
s #LEARGLASSREARSLIDINGDOORS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
1
4
2
Black
2"#,2
MODEL RB5C4848LR RB5C5948LR RB5C7748LR
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
2"#,2 870 5-15P 1,165
2"#,2 880 5-15P 1,165
2"#,2 1,100 5-20P 1,165
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER .#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE4 #UTAWAYWITHGLASS &ULLWITHMIRROR END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEOVERGLASS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
&RONTPACKAGELEDGEv$
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
3
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
RENAISSANCE®
4
O d F 231 798 4960 | C S S P 85
Refrigerated Service Case (Deli)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOCUTAWAYWITHGLASSENDPANELS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s #LEARGLASSREARSLIDINGDOORS
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPLIGHTANDSHELFLIGHTS
s /NELIGHTEDSHEETMETALSHELFv$
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
1
3
4
2
Black
2$'2
MODEL RDG4848R RDG5948R RDG7748R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
2$'2 750 5-20P 2,110
2$'2 850 5-20P 2,330
2$'2 1,000 5-20P 2,904
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER .#
3HELVING /NELIGHTEDSHELF v($ISPLAYSTEPINLIEUOFSHELF
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE4 #UTAWAYWITHGLASS &ULLWITHMIRROR END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEOVERGLASS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
&RONTPACKAGELEDGEv$
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
RENAISSANCE®
42 O d F 231 798 4960 | C S S P 85
Hot Service Case (Deli)
Standard Features
s )NDIVIDUALLYCONTROLLEDSTAINLESSSTEELHEATEDWELLSDRYHEAT
- RDG4848W - three full size & three one-third size pans
- RDG7748W - five full size & five one-third size pans
s 3TAINLESS3TEELINTERIOR
s 4WOCUTAWAYWITHGLASSENDPANELS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 3TRAIGHTLAMINATEDFRONTPANEL
s #LEARGLASSREARSLIDINGDOORS
s (EADERLIGHTSWITHSHATTERRESISTANTBULBS
s )NFRAREDOVERHEADHEATINDIVIDUALLYCONTROLLED
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s 5,#ERTIFIEDTO.3&3TANDARD
s YEARPARTSANDLABORWARRANTY
Note: Pans not supplied with case.
1 3
4
2
Black
2$'7
MODEL RDG4848W RDG7748W
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
2$'7 650 ,EADS
2$'7 950 ,EADS
Product Specification Standard (N/C) Option(s) List $
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER .#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE4 #UTAWAYWITHGLASS &ULLWITHMIRROR END
"ASE ,EVELERS #ASTERS
v(LEGSINCREASESHEIGHTOFCASEv
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
&RONTPACKAGELEDGEv$
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
0OWERCORD2$'702$'70
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
-AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
(EIGHTOFREARWRAPPINGBOARDDOESNOTMATCHHEIGHTOFREARWRAPPINGBOARDONBAKERYCASE
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
RENAISSANCE®
4
O d F 231 798 4960 | C S S P 85
Refrigerated Service Candy Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4HREEADJUSTABLEREMOVABLEGLASSSHELVESv$v$v$
s 4WOCUTAWAYWITHGLASSENDPANELS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s #LEARGLASSREARSLIDINGDOORS
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
1 3
4
2
Black
2#'2
MODEL RCG4848R RCG5948R RCG7748R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
2#'2 800 5-15P 1,169
2#'2 900 5-15P 1,241
2#'2 1,000 5-15P 1,624
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
.#
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER .#
5PPER2EAR3#LEARGLASSSLIDINGDOORS 2EFLECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE4 #UTAWAYWITHGLASS &ULLWITHMIRROR END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEOVERGLASS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
&RONTPACKAGELEDGEv$
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
!CRYLICCANDYTRAYSREFERTOQUANTITIESBELOW
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER-AYINCREASEHEIGHTOFCASEREFERTOSPECIFICATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
!CRYLIC#ANDY4RAY/PTION
2#'2OPTIONINCLUDESXTRAYSXTRAYS
2#'2OPTIONINCLUDESXTRAYSXTRAYS
2#'2OPTIONINCLUDESXTRAYSXTRAYS
OASIS®
44 O d F 231 798 4960 | C S S P 85
MODEL CO3678R CO4778R CO5978R CO7178R
Dimensions 36”L x 34 3/4”D x 81”H 47”L x 34 3/4”D x 81”H 59”L x 34 3/4”D x 81”H 71”L x 34 3/4”D x 81”H
List $ $10,431 $11,167 $12,278 $13,139
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White
Stainless Steel
N/C
$2,090
Header Color* 1
Curved Style
Curved-Black Curved-White
Curved-Stainless Steel
Curved-Painted (specify color)
Laminated (straight header style required)
N/C
$110
N/C
$150
Upper Front Panel Style* 2Formed ABS (painted) Straight front - reduces depth to 33 1/4” without wall spacer bracket N/C
Upper Front Panel Color* 3Black
Stainless Steel (straight front panel required)
Wilsonart® or Formica® non-premium laminates (straight front panel required)
Wilsonart® or Formica® premium laminates (straight front panel required)
N/C
$250
N/C
$260
Lower Louvered Front
Panel Color* 4
Black White
Stainless Steel
Painted (specify color)
N/C
$110
N/C
End Panel Style* 5Full end with vinyl edging Full end with laminate edging (Q4296)
Cutaway end with vinyl edging
Cutaway end with laminate edging (Q4296)
Counter cutaway end with vinyl edging (Q4292)
Counter cutaway end with laminate edging (Q4292)
Case-to-case acrylic panel (straight front panel style only)
N/C
$180/end
$180/end
$240/end
$240/end
N/C
End Panel Color* 6Black Wilsonart® or Formica® non-premium laminates (as noted in laminate charts)
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
N/C
$260/end
Call for quote
$790/end
Exterior Back Panel* Solid panel - Galvanized Solid panel - Black
Rear loading hinged doors, locking** (matches interior color) (CO36)
Rear loading hinged doors, locking** (matches interior color) (CO47,59 & 71)
$120
$1,650
$2,610
Shelving* 7(4) Non-lighted sheet metal (4) Lighted shelves
Additional non-lighted shelf
Additional lighted shelf
Magna bar peg hooks (in lieu of shelves)
$890
$260
$330
$160
Base* Casters Levelers N/C
Refrigeration* BreezeTM self-contained w/
evaporator pan (front air intake/
rear air discharge)
Remote (compressor supplied by others)
Pressure release valve (required for city of Chicago) - must be ordered with case
Breeze-E with Whisper Cool
Call for quote
$50
$1,700
Miscellaneous
(Must be chosen when
case is ordered)
Roll-down security cover, locking (increases height of case by 7”)(CO36 & 47)
Roll-down security cover, locking (increases height of case by 7”)(CO59 & 71)
Clean Sweep® automatic condenser coil cleaner
Second year parts & labor warranty (excludes compressor)
$1,850
$2,780
$990
$530
Accessories (Can be purchased
at any time. Refer to pages
76/77 for information)
Price tag molding
Night curtain, pull-down, non-locking
Removable solid security cover, locking, Stardust Silver paint
$130
$420
$920
Refrigerated Open Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s v$REMOVABLEREARWALLSPACERBRACKETNOTINCLUDEDIN
depth dimensions below)
s 4TOPLIGHT
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from front and out rear of case.
Front panel cannot be blocked and case must remain 4” from wall.
1
7
2
4
6
5
3
Vinyl edge
matches
interior
color
except
gray with
stainless
CO4778R
MODEL CO3678R CO4778R CO5978R CO7178R
WEIGHT 960 1,150 1,350 1,550
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order
NOTE: Shown with
optional cutaway
end panels.
**Minimum 40” door entry clearance required. Depth of unit with rear door 38 1/4”. Doors are not removable.
Contact factory for technical electrical information.
See page 10
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
Painted - ABS front panel only (specify color)
OASIS®
4
O d F 231 798 4960 | C S S P 85
MODEL CO3660R CO4760R CO5960R CO7160R
Dimensions 36”L x 34 3/4”D x 63 1/8”H 47”L x 34 3/4”D x 63 1/8”H 59”L x 34 3/4”D x 63 1/8”H 71”L x 34 3/4”D x 63 1/8”H
List $ $9,842 $10,591 $11,616 $12,372
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White
Stainless Steel
N/C
$2,090
Header Color* 1
Curved Style
Curved-Black Curved-White
Curved-Stainless Steel
Curved-Painted (specify color)
Laminated (straight header style required)
N/C
$110
N/C
$150
Upper Front Panel Style* 2Formed ABS (painted) Straight front - reduces depth to 33 1/4” without wall spacer bracket N/C
Upper Front Panel Color* 3Black Stainless Steel (straight front panel required)
Wilsonart® or Formica® non-premium laminates (straight front panel required)
Wilsonart® or Formica® premium laminates (straight front panel required)
N/C
$250
N/C
$260
Lower Louvered Front
Panel Color* 4
Black White
Stainless Steel
Painted (specify color)
N/C
$110
N/C
End Panel Style* 5Full end with vinyl edging Full end with laminate edging (Q4296)
Cutaway end with vinyl edging
Cutaway end with laminate edging (Q4296)
Counter cutaway end with vinyl edging (Q4292)
Counter cutaway end with laminate edging (Q4292)
Case-to-case acrylic panel (straight front panel style only)
N/C
$180/end
$180/end
$240/end
$240/end
N/C
End Panel Color* 6Black Wilsonart® or Formica® non-premium laminates (as noted in laminate charts)
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
N/C
$260/end
Call for quote
$790/end
Exterior Back Panel* Solid panel - Galvanized Solid panel - Black
Rear loading hinged doors, locking** (matches interior color) (CO36)
Rear loading hinged doors, locking** (matches interior color) (CO47, 59 & 71)
$120
$1,650
$2,610
Shelving* 7(2) Non-lighted sheet metal (2) Lighted shelves
Additional non-lighted shelf
Additional lighted shelf
Magna bar peg hooks (in lieu of shelves)
$890
$260
$330
$160
Base* Casters Levelers N/C
Refrigeration* BreezeTM self-contained w/
evaporator pan (front air intake/
rear air discharge)
Remote (compressor supplied by others)
Pressure release valve (required for city of Chicago) - must be ordered with case
Breeze-E with Whisper Cool
Call for quote
$50
$1,425
Miscellaneous
(Must be chosen when
case is ordered)
Roll-down security cover, locking (increases height of case by 7”) (CO36 & 47)
Roll-down security cover, locking (increases height of case by 7”) (CO59 & 71)
Clean Sweep® automatic condenser coil cleaner
Second year parts & labor warranty (excludes compressor)
$1,850
$2,780
$990
$530
Accessories (Can be purchased
at any time. Refer to pages
76/77 for information)
Price tag molding
Night curtain, pull-down, non-locking
Removable solid security cover, locking, Stardust Silver paint
$130
$420
$920
Refrigerated Open Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s v$REMOVABLEREARWALLSPACERBRACKETNOTINCLUDEDIN
depth dimensions below)
s 4TOPLIGHT
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from front and out rear of case.
Front panel cannot be blocked and case must remain 4” from wall.
1
7
3
4
6
5
2
Vinyl edge
matches
interior
color
except
gray with
stainless
CO4760R
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order **Minimum 40” door entry clearance required. Depth of unit with rear door 38 1/4”. Doors are not removable.
NOTE: Shown with
optional cutaway
end panels.
See page 10
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
MODEL CO3660R CO4760R CO5960R CO7160R
WEIGHT 960 1,150 1,350 1,550
Contact factory for technical electrical information.
Painted - ABS front panel only (specify color)
OASIS®
46 O d F 231 798 4960 | C S S P 85
MODEL CO4748R
Dimensions 47”L x 34 3/4”D x 50 5/8”H
List $ $10,346
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White
Stainless Steel
N/C
$2,090
Header Color* 1 Black White
Stainless Steel
Painted (specify color)
N/C
$110
N/C
Upper Front Panel Style* 2Formed ABS (painted) Straight front - reduces depth to 33 1/4” without wall spacer bracket N/C
Upper Front Panel Color* 3Black
Stainless Steel (straight front panel required)
Wilsonart® or Formica® non-premium laminates (straight front panel required)
Wilsonart® or Formica® premium laminates (straight front panel required)
N/C
$250
N/C
$260
Lower Louvered Front
Panel Color* 4
Black White
Stainless Steel
Painted (specify color)
N/C
$110
N/C
End Panel Style* 5Full end with vinyl edging Full end with laminate edging (Q4296)
Cutaway end with vinyl edging
Cutaway end with laminate edging (Q4296)
Counter cutaway end with vinyl edging (Q4292)
Counter cutaway end with laminate edging (Q4292)
Case-to-case acrylic panel (straight front panel style only)
N/C
$180/end
$180/end
$240/end
$240/end
N/C
End Panel Color* 6Black Wilsonart® or Formica® non-premium laminates (as noted in laminate charts)
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
N/C
$260/end
Call for quote
$790/end
Back Panel* Solid panel - Galvanized Solid panel - Black $120
Base* Casters Levelers N/C
Refrigeration* BreezeTM self-contained w/
evaporator pan (front air
intake/rear air discharge)
Remote (compressor supplied by others)
Pressure release valve (required for city of Chicago) - must be ordered with case
Breeze-E with Whisper Cool
Call for quote
$50
$1,425
Miscellaneous
(Must be chosen when
case is ordered)
Roll-down security cover, locking (increases height of case by 5”)
Clean Sweep® automatic condenser coil cleaner
Second year parts & labor warranty (excludes compressor)
$1,850
$990
$530
Accessories
(Can be purchased at any
time. Refer to pages 76/77 for
information)
Price tag molding
Night curtain, pull-down, non-locking
Removable solid security cover, locking
$130
$420
$920
Refrigerated Open Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELS
s 4WONONLIGHTEDSHELVESv$v$
s 4TOPLIGHT
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from front and out rear of case.
Front panel cannot be blocked and case must remain 4” from wall.
1
3
4
6
5
2
Vinyl edge
matches
interior
color
except
gray with
stainless
CO4748R
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
CO4748R 740
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order
NOTE: Shown with
optional cutaway end panels.
Contact factory for technical electrical information.
See page 10
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
Painted - ABS front panel only (specify color)
OASIS®
4
O d F 231 798 4960 | C S S P 85
34”D Refrigerated Open Air Screen Case
Standard Features
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 4TOPLIGHT
s !NGLEDBOTTOMDECK
s &OURCASTERS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
1
Mirror
on inside
of end
panels
Black
CO2739R
MODEL CO2739R
Dimensions 28”L x 34”D x 39 1/4”H
List $ $7,134
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White
Stainless Steel
N/C
$1,090
Exterior Color* 1 Choice of Wilsonart® or
Formica® non-premium
laminates
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
$620
Call for quote
$700
Refrigeration* BreezeTM self-contained w/
evaporator pan (rear air intake/
front air discharge at toe kick.)
Remote (compressor supplied by others)
Pressure release valve (required for city of Chicago) - must be ordered with case
Call for quote
$50
Miscellaneous
(Must be chosen when
case is ordered)
Second year parts & labor warranty (excludes compressor) $530
Accessories
(Can be purchased at any
time. Refer to pages 76/77 for
information)
Display steps (2”H)
Removable wire security cover, locking
Night curtain, pull-down, non-locking
$480
$500
$420
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
CO2739R 475 120/1/60 6.1 5-15P 120/1/60 0.82 1,296
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
OASIS®
48 O d F 231 798 4960 | C S S P 85
MODEL B32 B42 B62 B82
Dimensions 34”L x 24”D x 82”H 45”L x 24”D x 82”H 66”L x 24”D x 82”H 88”L x 24”D x 82”H
List $ $9,909 $10,610 $12,482 $16,790
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White
Stainless Steel
N/C
$2,090
Lower Front Panel Color* 1Black White
Stainless Steel
N/C
$110
Exterior Color* 2Black White
Stainless Steel
Wilsonart® or Formica® non-premium laminates (as noted in laminate charts)
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
N/C
$1,520
N/C
$620
Call for quote
Rear Panel* Solid panel - Black Solid panel - White $120
Shelving* 3Non-lighted shelves Lighted shelves $890
Base* Casters** Levelers N/C
Refrigeration* BreezeTM self-contained w/
evaporator pan (front air intake/
upper front air discharge)
Remote (compressor supplied by others)
Pressure release valve (required for city of Chicago) - must be ordered with case
Call for quote
$50
Miscellaneous
(Must be chosen when
case is ordered)
Clean Sweep® automatic condenser coil cleaner
Second year parts & labor warranty (excludes compressor)
$990
$530
Accessories
(Can be purchased at any
time. Refer to pages 76/77 for
information)
Price tag molding
Night curtain, pull-down, non-locking
Removable solid security cover, locking, Stardust Silver paint
$130
$420
$920
24”D Refrigerated Open Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSNOMIRRORINSIDE
s 4TOPLIGHT
s &OURADJUSTABLEREMOVABLENONLIGHTEDSHELVESv$
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake through front panel.
Front panel cannot be blocked.
NOTE: Top of header area must not be obstructed if positioned in an alcove.
B32
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
B32 610 120/1/60 16.41 5-20P 120/1/60 2.06 5,924
B42 700 220/1/60* 14.94 14-20P 120/1/60 2.52 7,511
B62 790 220/1/60* 21.39 14-30P 120/1/60 4.52 11,647
B82 900 220/1/60* 26.78 14-30P 120/1/60 4.75 15,038
Freight Class: 110 NOTE: Freight rate subject to linear foot rule. *Requires three wires plus ground
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order
**Not available with remote refrigeration
1
3
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
See page 10
This model may require additional lead time
2
OASIS®
4
O d F 231 798 4960 | C S S P 85
1
Refrigerated Open Air Screen Case
Standard Features
s 4WOCUTAWAYENDPANELSWITHACRYLIC
s /NENONLIGHTEDINTERIORSHELFv$-0233ONLY
s 4TOPLIGHTEXCLUDES-0233
s ,OCKINGCASTERS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked. 2
Black
MP5348RSS
MODEL MP3848RSS MP4448RSS MP5348RSS
Dimensions 50 1/2”L x 49 1/2”D x 38”H 50 1/2”L x 49 1/2”D x 43 5/8”H 50 1/2”L x 49 1/2”D x 53”H
List $ $9,823 $10,757 $13,026
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
MP3848RSS 680 120/1/60 17.15 5-20P 120/1/60 Call Factory Call Factory
MP4448RSS 680 120/1/60 17.46 5-20P 120/1/60 Call Factory Call Factory
MP5348RSS 720 120/1/60 16.47 5-20P 120/1/60 2.21 5,902
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White N/C
Upper Front Panel Color* 1
Black Painted (specify color) N/C
End Panel Color* 2Black Wilsonart® or Formica® non-premium laminates (as noted in laminate charts)
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
N/C
$260/end
Call for quote
Shelving* 3Non-lighted shelf
(MP5348RSS only)
Lighted shelf (MP5348RSS only)
Additional 18”D non-lighted shelf (MP5348RSS only)
Additional 18”D lighted shelf (MP5348RSS only)
Display steps (N/A with MP5348RSS)
$190
$390
$540
$130
Refrigeration* Self-contained w/evaporator
pan (rear air intake/front air
discharge at toe kick)
Remote (compressor supplied by others)
Pressure release valve (required for city of Chicago) - must be ordered with case
Call for quote
$50
Miscellaneous
(Must be chosen when
case is ordered)
Second year parts & labor warranty (excludes compressor) $530
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order
Black
3
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
OASIS®
50 O d F 231 798 4960 | C S S P 85
MODEL CO4748 CO3678 CO4778 CO5978 CO7178
Dimensions 47”L x 34 3/4”D x 50 5/8”H 36”L x 34 3/4”D x 81”H 47”L x 34 3/4”D x 81”H 59”L x 34 3/4”D x 81”H 71”L x 34 3/4”D x 81”H
List $ $6,803 $7,495 $7,835 $8,175 $8,502
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black White
Stainless Steel
N/C
$2,090
Header Color* 1
Curved Style (excludes CO4748)
Curved-Black Curved-White
Curved-Stainless Steel
Curved-Painted (specify color)
N/C
$110
N/C
$150
Upper Front Panel Style* 2Formed ABS (painted) N/C
Upper Front Panel Color* 3Black
Stainless Steel (straight front panel required)
Wilsonart® or Formica® non-premium laminates (straight front panel required)
Wilsonart® or Formica® premium laminates (straight front panel required)
N/C
$250
N/C
$260
Lower Front Panel Color* 4
Black White
Stainless Steel
Painted (specify color)
N/C
$110
N/C
End Panel Style* 5Full end with vinyl edging Full end with laminate edging (Q4296)
Cutaway end with vinyl edging
Cutaway end with laminate edging (Q4296)
Counter cutaway end with vinyl edging (Q4292)
Counter cutaway end with laminate edging (Q4292)
N/C
$180/end
$180/end
$240/end
$240/end
End Panel Color* 6Black Wilsonart® or Formica® non-premium laminates (as noted in laminate charts)
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
N/C
$260/end
Call for quote
$790/end
Back Panel* Solid panel - Galvanized Solid panel - Black $120
Shelving* 7Non-lighted metal shelves Lighted metal shelves (CO3678, 4778, 5978, 7178)
Additional non-lighted shelf (CO3678, 4778, 5978, 7178)
Additional lighted shelf (CO3678, 4778, 5978, 7178)
$890
$260
$330
Base* Casters Levelers N/C
Miscellaneous
(Must be chosen when
case is ordered)
Roll-down security cover, locking (increases height of case by 5”) (CO4748)
Roll-down security cover, locking (increases height of case by 7”) (CO3678,4778)
Roll-down security cover, locking (increases height of case by 7”) (CO5978, 7178)
Second year parts & labor warranty
$1,850
$1,850
$2,780
$530
Accessories (Can be purchased
at any time. Refer to pages
76/77 for information)
Price tag molding
Removable solid security cover, locking, Stardust Silver paint
Magna bar peg hooks (CO3678, 4778, 5978, 7178)
$130
$920
$160
Non-Refrigerated Self-Service Case
Standard Features
s 4WOFULLENDPANELS
s 4TOPLIGHT
s &OURADJUSTABLEREMOVABLENONLIGHTEDMETALSHELVES
- Two non-lighted metal shelves (CO4748)
s vPOWERCORD
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
7
3
4
6
2
Vinyl edge
matches
interior
color
except
gray with
stainless
Freight Class: 125 NOTE: Freight rate subject to linear foot rule.
*Must choose one when placing order **Note: 40” minimum door entry clearance is required
NOTE: Shown with
optional cutaway
end panels.
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
CO4748 625 120/1/60 0.31 5-15P
CO3678 725 120/1/60 2.18 5-15P
CO4778 760 120/1/60 2.18 5-15P
CO5978 900 120/1/60 2.18 5-15P
CO7178 1,100 120/1/60 3.36 5-15P
5
CO5978
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
Straight front - reduces depth to 33 1/4” without wall spacer bracket
Laminated (Straight header style required) (N/A on C04748)
Painted - ABS front panel only (specify color)
OASIS®
5
O d F 231 798 4960 | C S S P 85
MODEL C3Z3667 C3Z4867
Dimensions 36”L x 41 7/8”D x 67 1/2”H 48”L x 41 7/8”D x 67 1/2”H
List $ $16,819 $18,247
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black Stainless Steel $2,090
Exterior Color* 1Choice of Wilsonart® or
Formica® non-premium
laminates
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
$620
Call for quote
$1,320
Upper/Middle Rear* Clear glass sliding doors Reflective glass sliding doors $260
Base* Levelers Casters** $340
Refrigeration* BreezeTM self-contained w/
evaporator pan (rear air intake/
front air discharge at toe kick)
Pressure release valve (required for city of Chicago) - must be ordered with case $50
Miscellaneous
(Must be chosen when
case is ordered)
Rear door locks
Second year parts & labor warranty (excludes compressor)
$210
$530
Accessories
(Can be purchased at any
time. Refer to pages 76/77 for
information)
Display steps (2 1/2”H) (in lieu of shelf)
Night curtain, pull-down, non-locking
Removable wire security cover, locking
$480
$420
$500
Combination Ambient/Refrigerated Service
Above Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 5PPERSERVICEDISPLAYAREA
- Fixed front glass
- Non-refrigerated with 12”D shelf and 14”D deck
- Clear glass rear sliding doors
s -IDDLESERVICEDISPLAYAREA
- Fixed front glass
- Single display level (15”D)
- Baffle system converts from refrigerated to non-refrigerated
- Clear glass rear sliding doors
s ,OWERSELFSERVICEDISPLAYAREAWITHOPENREACHINFRONT
and 17”D solid shelf
s 4WOFULLENDPANELSWITHMIRRORINTERIORLOWERSECTION
s 2EARWRAPPINGBOARDv$
s 4TOPLIGHTANDSHELFLIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
1
Black
Black
Mirror
on inside
of end
panels
Vinyl edge
matches
interior color
except gray
with stainless
C3Z3667
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order **May increase height of case - refer to specification sheet
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
C3Z3667 910 120/1/60 16.52 5-20P
C3Z4867 1140 120/1/60 17.52 5-20P
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
OASIS®
52 O d F 231 798 4960 | C S S P 85
Combination Non-Refrigerated Service
Above Refrigerated Self-Service Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 5PPERSERVICEDISPLAYAREA
- Fixed front glass
- Non-refrigerated with 12”D glass shelf and 19 1/2”D deck
- Clear glass rear sliding doors
s ,OWERSELFSERVICEDISPLAYAREAWITHOPENREACHIN
front and angled deck
- Single display level consisting of bottom deck (21 7/8”D)
s 4WOFULLENDPANELSWITHMIRRORINTERIORLOWERSECTION
s 4TOPLIGHTANDSHELFLIGHTS
s &OURCASTERS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be locked.
1
Mirror
on inside
of end
panels
Black
Black
COU2757R
MODEL COU2757R
Dimensions 28”L x 34 1/2”D x 56 7/8”H
List $ $11,153
Product Specification Standard (N/C) Option(s) List $
Interior Color* Black Stainless Steel $2,090
Exterior Color* 1 Choice of Wilsonart® or
Formica® non-premium
laminates
Wilsonart® or Formica® premium laminates (as noted in laminate charts)
Other manufacturer’s laminates
Stainless Steel
$620
Call for quote
$1,320
Upper Rear* Clear glass sliding doors Reflective glass sliding doors $260
Refrigeration* BreezeTM self-contained w/
evaporator pan (rear air intake/
front air discharge at toe kick)
Pressure release valve (required for city of Chicago) - must be ordered with case $50
Miscellaneous
(Must be chosen when
case is ordered)
Rear door lock (upper display area)
Second year parts & labor warranty (excludes compressor)
$210
$530
Accessories
(Can be purchased at any
time. Refer to pages 76/77 for
information)
Display steps (2”H) (in lieu of shelf)
Night curtain, pull-down, non-locking
Removable wire security cover, locking
$480
$420
$500
Freight Class: 110 NOTE: Freight rate subject to linear foot rule.
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
Specifications and pricing subject to change without notice.
*Must choose one when placing order
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
COU2757R 530 120/1/60 6.91 5-15P
See page 10
Dimensions shown are not exact. Refer to Factory Specification drawings for more detail.
FUSION®
5
O d F 231 798 4960 | C S S P 85
Refrigerated Service Case (Deli)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s #LEARGLASSREARSLIDINGDOORS
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 4TOPSHELFANDNOSELIGHTS
s /NELIGHTEDMETALSHELF
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3$'24
MODEL FSDG48R.T1 FSDG72R.T1 FSDG96R.T1 FSDG144R.T1
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
,OWER&RONT0ANEL3"LACK 3TAINLESS3TEEL
&RONT'LASS3TYLE4#URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE6 &ULLWITHSTAINLESSMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEOVERGLASS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
v($ISPLAYSTEPS.!WITHSHELF
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES#ANBEPURCHASED
ATANYTIME2EFERTOPAGES
FORINFORMATION
2EARWRAPPINGBOARDv$
0RICETAGMOLDING
Straight
front glass
option
2
6
5
3
1
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
4
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3$'24 950 14-20P 120/1/60 3,053
&3$'24 1,150 14-20P 120/1/60 3,217
&3$'24 1,270 14-20P 120/1/60 3,792
&3$'24 2,150 14-30P 120/1/60 7,888
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
54 O d F 231 798 4960 | C S S P 85
Hot Service Case (Deli)
Standard Features
s )NDIVIDUALLYCONTROLLEDSTAINLESSSTEELHEATEDWELLSDRYHEAT
- FSDG48W.T1 - three full size & three one-third size 4”D pans
- FSDG72W.T1 - five full size & five one-third size 4”D pans
- FSDG96W.T1 - seven full size & seven one-third size 4”D pans
s 3TAINLESS3TEELINTERIOR
s 4WOCUTAWAYWITHGLASSENDPANELS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s #LEARGLASSREARSLIDINGDOORS
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s (EADERLIGHTSWITHSHATTERRESISTANTBULBS
s )NFRAREDOVERHEADHEATINDIVIDUALLYCONTROLLED
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s 5,#ERTIlEDTO.3&3TANDARD
s YEARPARTSANDLABORWARRANTY
NOTE: Pans not supplied with case.
1 2
&3$'74
NOTE: Only available with glass end panels.
MODEL FSDG48W.T1 FSDG72W.T1 FSDG96W.T1
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Options(s) List $
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR&OR-
MICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
,OWER&RONT0ANEL3"LACK 3TAINLESS3TEEL
&RONT'LASS3TYLE4#URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
#ONTROLKNOBGUARDS
3
5
Straight front
glass option
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
4
Heated
MODEL WEIGHT VOLTS ++ (60 Hz) AMPS
(Single Phase)
AMPS
(Three Phase) NEMA Plug
&3$'74) 770 (EATED #IRCUIT 220 ,EADS
&3$'74) 800 (EATED #IRCUIT 220 ,EADS
&3$'74) 1,100 (EATED #IRCUIT 220 43 ,EADS
-USTCHOOSEONEWHENPLACINGORDER
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
5
O d F 231 798 4960 | C S S P 85
Refrigerated Service Case (Bakery)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s #LEARGLASSREARSLIDINGDOORS
s 4WOLIGHTEDGLASSSHELVESv$v$
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 4TOPSHELFANDNOSELIGHTS
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
1 2
MODEL FSBG48R.T1 FSBG72R.T1
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
,OWER&RONT0ANEL3"LACK 3TAINLESS3TEEL
&RONT'LASS3TYLE4#URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE6&ULLWITHSTAINLESSMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEOVERGLASS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
0RICETAGMOLDING
3
6
5
Straight
front glass
option
&3"'24
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3"'24 940 14-20P 120/1/60 3,053
&3"'24 1,130 14-20P 120/1/60 3,217
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
4
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
56 O d F 231 798 4960 | C S S P 85
Service Non-Refrigerated Case (Bakery)
Standard Features
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s #LEARGLASSREARSLIDINGDOORS
s 4WONONLIGHTEDWIRESHELVES
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 4TOPSHELFANDNOSELIGHTS
s &RONTELECTRICALACCESS
s vPOWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1 2
MODEL FSBG48.T1 FSBG72.T1
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
,OWER&RONT0ANEL3"LACK 3TAINLESS3TEEL
&RONT'LASS3TYLE4#URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE6&ULLWITHSTAINLESSMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
3HELVING 7IRESHELVES #LEARGLASSNONLIGHTEDSHELVES
"ASE ,EVELERS #ASTERS
v(LEGSINCREASESHEIGHTOFCASEv
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
0RICETAGMOLDING
3
6
5
Straight
front glass
option
&3"'4
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
&3"'4 750 120/1/60 5-15P
&3"'4 900 120/1/60 5-15P
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
4
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
5
O d F 231 798 4960 | C S S P 85
Combination Cold Service Above
Cold Self-Service Case - 13” Short Dome
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOCUTAWAYWITHGLASSENDPANELS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 4TOPSHELFANDNOSELIGHTS
s !DJUSTABLEREMOVABLEMETALSHELVESLOWERDISPLAY
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3'52,2
MODEL FSGURLR4854 FSGURLR7254 FSGURLR9654
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3'52,2 1,500 120/1/60 5-30P 120/1/60 4,502
&3'52,2 1,800 14-20P 120/1/60 6,116
&3'52,2 2,100 14-30P 120/1/60 7,100
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 3TAINLESS3TEEL
5PPER&RONT0ANEL3"LACK 3ILVER
0AINTEDSPECIFYCOLOR
N/C
N/C
4RIM4"LACK 3ILVER N/C
&RONT'LASS3TYLE7#URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
2EAR3TORAGE $RYSTORAGEWITHSLIDINGSOLID
doors
2EFRIGERATEDSTORAGEWITHSLIDINGSOLIDDOORS
%ND0ANEL3TYLE6#UTAWAYWITHGLASS #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDBLOWER
COILSYSTEMWITHELECTRICALLEADS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITH
CASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHENCASEIS
ORDERED
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
0RICETAGMOLDING
1
2
6
5
3
4
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
7
FUSION®
58 O d F 231 798 4960 | C S S P 85
Combination Cold Service Above
Cold Self-Service Case - 16” Tall Dome
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOCUTAWAYWITHGLASSENDPANELS
s #URVEDSINGLEPANELIFTUPFRONTGLASS
s 4TOPSHELFANDNOSELIGHTS
s !DJUSTABLEREMOVABLEMETALSHELVESLOWERDISPLAYAREA
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3'52,2
MODEL FSGURLR4857 FSGURLR7257 FSGURLR9657
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3'52,2 1,250 120/1/60 5-30P 120/1/60 4,502
&3'52,2 1,350 120/1/60 14-20P 120/1/60 6,116
&3'52,2 2,200 120/1/60 14-30P 120/1/60 7,100
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 7HITE
3TAINLESS3TEEL
0AINTEDSPECIFYCOLORS
N/C
N/C
5PPER&RONT0ANEL3"LACK 3ILVER
0AINTEDSPECIFYCOLORS
N/C
N/C
4RIM4"LACK 3ILVER N/C
&RONT'LASS3TYLE #URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
2EAR3TORAGE $RYSTORAGEWITHSLIDINGSOLID
doors
2EFRIGERATEDSTORAGEWITHSLIDINGSOLIDDOORS
%NDPANEL3TYLE6#UTAWAYWITHGLASS #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDBLOWER
COILSYSTEMWITHELECTRICALLEADS
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHENCASEIS
ORDERED
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
,IGHTEDUPPERMETALSHELFv$
2EARWRAPPINGBOARDv$
0RICETAGMOLDING
1
2
3
4
6
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
5
FUSION®
5
O d F 231 798 4960 | C S S P 85
Combination Hot Service Above
Refrigerated Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOCUTAWAYWITHGLASSENDPANELS
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 2EFRIGERATEDLOWERDISPLAYAREA
- T-8 top and nose lights
- Single display level (21 3/4”D)
- Integrated average product temperature of 41˚F
s (OTSERVICEDISPLAYAREA
- Individually controlled stainless steel heat wells (dry heat)
FSGUWLR48.T1 - three full size & three one-third size pans
FSGUWLR72.T1 - five full size & five one-third size pans
FSGUWLR96.T1 - seven full size & seven one-third size pans
- Curved single pane lift-up front glass
- Infrared overhead heat (individually controlled)
- Header lights with shatter resistant bulbs
- Integrated average product temperature of 160˚F
s 5,#ERTIlEDTO.3&3TANDARD
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3'57,24
NOTE: Only available with cutaway glass end panels.
NOTE: Pans not supplied with case.
MODEL FSGUWLR48.T1 FSGUWLR72.T1 FSGUWLR96.T1
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR
,OWERDISPLAYAREA
"LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
,OWER&RONT0ANEL3"LACK 3TAINLESS3TEEL
&RONT'LASS3TYLE4 #URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EMOVABLEWIRESECURITYCOVERLOCKING
.IGHTCURTAINPULLDOWNNONLOCKING
2EARWRAPPINGBOARDv$
#ONTROLKNOBGUARDS
0RICETAGMOLDING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
1 2
4
5
-USTCHOOSEONEWHENPLACINGORDER
3
Refrigerated/Heated
MODEL WEIGHT VOLTS++ (60 Hz) AMPS***
(Single Phase)
AMPS***
(Three Phase) NEMA PLUG BTUH
&3'57,24 1,020 ,EADS 2,489
&3'57,24 1,200 ,EADS 3,118
&3'57,24 1,900 ,EADS 3,840
Contact factory for technical electrical information.
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
60 O d F 231 798 4960 | C S S P 85
Combination Hot Service Above
Refrigerated Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOCUTAWAYWITHGLASSENDPANELS
s ,EVELERS
s 2EFRIGERATEDLOWERDISPLAYAREA
- T-8 top light and nose lights
- Single display level
- Integrated average product temperature of 41˚F
s (OTSERVICEDISPLAYAREA
- Individually controlled stainless steel heat wells (dry heat)
FSGUWLR4854 - three full size pans (not included)
FSGUWLR7254 - five full size pans (not included)
FSGUWLR9654 - seven full size pans (not included)
- Curved single pane lift-up front glass
- Infrared overhead heat (individually controlled)
- Header lights with shatter resistant bulbs
- Integrated average product temperature of 160˚F
s 5,#ERTIlEDTO.3&3TANDARD
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3'57,2
NOTE: Pans not supplied with case.
MODEL FSGUWLR4854 FSGUWLR7254 FSGUWLR9654
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR
,OWERDISPLAYAREA
"LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 3TAINLESS3TEEL
5PPER&RONT0ANEL "LACK 3ILVER N/C
4RIM#OLOR3"LACK 3ILVER N/C
&RONT'LASS3TYLE4 #URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
%ND0ANEL3TYLE6#UTAWAYWITHGLASS #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EARWRAPPINGBOARDv$
#ONTROLKNOBGUARDS
0RICETAGMOLDING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
1
2
4
5
-USTCHOOSEONEWHENPLACINGORDER
3
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3'57,2 1,400 ,EADS 2,033
&3'57,2 1,700 ,EADS 2,686
&3'57,2 2,000 ,EADS 4,132
6
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
6
O d F 231 798 4960 | C S S P 85
1
3
4
2
&3357,24
NOTE: Only available with cutaway glass end panels.
NOTE: Pans not supplied with case.
MODEL FSSUWLR72.T1 FSSUWLR96.T1
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR
,OWERDISPLAYAREA
"LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1 #HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
4RIM#OLOR2"LACK 3ILVER N/C
,OWER&RONT0ANEL3"LACK 3TAINLESS3TEEL
&RONT'LASS3TYLE4 #URVED 3TRAIGHT N/C
5PPER2EAR5#LEARGLASSSLIDINGDOORS 2EmECTIVEGLASSSLIDINGDOORS
"ASE ,EVELERS v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
&RONTGLASSLOCK
3CALESTANDWITHAPPLIANCERECEPTACLEREQUIRESSEPARATEELECTRICAL
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
2EMOVABLEWIRESECURITYCOVERLOCKING
.IGHTCURTAINPULLDOWNNONLOCKING
2EARWRAPPINGBOARDv$
#ONTROLKNOBGUARDS
0RICETAGMOLDING
5
Combination Hot Service and Self-Service
Above Refrigerated Air Screen Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOCUTAWAYWITHGLASSENDPANELS
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 2EFRIGERATEDLOWERDISPLAYAREA
- T-8 top light and nose light
- Single display level (21 3/4”D)
- Integrated average product temperature of 41˚F
s (OTSERVICEDISPLAYAREA
- Individually controlled stainless steel heat wells (dry heat)
FSSUWLR72.T1 - three full size & three one-third size pans,
and self-service display area
FSSUWLR96.T1 - five full size & five one-third size pans,
and self-service display area
- Curved single pane lift-up front glass (service side)
- Header light with shatter resistant bulbs
- Infrared overhead heat (individually controlled)
- Integrated average product temperature of 160˚F
s 5,#ERTIlEDTO.3&3TANDARD
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
-USTCHOOSEONEWHENPLACINGORDER
Refrigerated/Heated
MODEL WEIGHT VOLTS++ (60 Hz) AMPS***
(Single Phase)
AMPS***
(Three Phase) NEMA PLUG BTUH
&3357,24 1,350 ,EADS 3,118
&3357,24 1,550 ,EADS 3,840
Contact factory for technical electrical information.
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
62 O d F 231 798 4960 | C S S P 85
Combination Preparation/Refrigerated
Air Screen Case (with Rear Storage)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 2EFRIGERATEDLOWERDISPLAYAREA
- T-8 top light and nose light
- Adjustable/removable non-lighted metal shelf (15 1/2”D)
- Bottom display deck (21 3/4”D)
s 0REPARATION!REA
- Adjustable condiment pan rail
- Sanalite® work surface (16”D)
- Non-refrigerated rear storage (with one stainless steel shelf) without doors
- Three sided glass sneeze guard
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlCATIONTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
2
&3024
Note: Pans not supplied with case.
MODEL FSP4842R.T1 FSP7242R.T1 FSP9642R.T1 (Remote only)
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 3TAINLESS3TEEL
3NEEZE'UARD0OSTS "LACK 3ILVER N/C
2EAR3TORAGE .ONREFRIGERATEDWITHOUTDOORS
WITHONESHELF
.ONREFRIGERATEDWITHDOORSWITHONESHELF
2EFRIGERATEDWITHINSULATEDDOORSWITHONESHELF
2EAR7ORK3URFACE 7HITE3ANALITE 3TAINLESS3TEEL
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
.OTAVAILABLEONMODEL
&3024
2EMOTECOMPRESSORSUPPLIEDBYOTHERSSTANDARD&3024
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITH
CASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHENCASEIS
ORDERED
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
.IGHTCURTAINPULLDOWNNONLOCKING
2EMOVABLEWIRESECURITYCOVERLOCKING
0RICETAGMOLDING
!DDITIONALNONLIGHTEDMETALSHELF
1
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3024 950 120/1/60 5-30P 120/1/60 3,870
&3024 1,320 14-20P 120/1/60 5,805
&3024 1,900 .! .! .! 120/1/60 7,764
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
6
O d F 231 798 4960 | C S S P 85
Combination Preparation/Refrigerated
Air Screen Case (without Rear Storage)
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3TRAIGHTLAMINATEDUPPERFRONTPANEL
s 0AINTEDLOWERFRONTPANEL
s 2EFRIGERATEDLOWERDISPLAYAREA
- T-8 top light and nose light
- Adjustable/removable non-lighted metal shelf (15 3/4”D)
- Bottom display deck
s 0REPARATION!REA
- Adjustable condiment pan rails
- Sanalite® work surface (7 1/2”D)
- Sanalite® removable flip-up ledge (7 1/2”D)
- Three sided glass sneeze guard
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
2
FSP72
Note: Pans not supplied with case.
MODEL FSP48 FSP72 FSP96
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
/AKVENEERWITHCLEARSEALER
/AKVENEERSTAINEDCOLORMATCHREQUIRED
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 3TAINLESS3TEEL
3NEEZE'UARD0OSTS "LACK 3ILVER N/C
2EAR7ORK3URFACE 7HITE3ANALITE 3TAINLESS3TEEL
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
v(LEGSINCREASESHEIGHTOFCASEv
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPAN
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITH
CASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHENCASEIS
ORDERED
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
.IGHTCURTAINPULLDOWNNONLOCKING
2EMOVABLEWIRESECURITYCOVERLOCKING
0RICETAGMOLDING
!DDITIONALNONLIGHTEDMETALSHELF
1
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
FSP48 950 120/1/60 ,0 120/1/60 .!
FSP72 1,550 ,0 120/1/60 6,378
FSP96 2,000 ,0 120/1/60 10,517
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
FUSION®
64 O d F 231 798 4960 | C S S P 85
Open Lower Refrigerated Work Counter Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s !DJUSTABLEREMOVABLELIGHTEDMETALSHELF
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3/2
MODEL FSO4837R FSO7237R
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3/2 950 120/1/60 5-20P 120/1/60 3,359
&3/2 1,550 5-30P 120/1/60 4,363
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 3TAINLESS3TEEL
5PPER&RONT0ANEL3"LACK 3ILVER
0AINTEDSPECIFYCOLOR
N/C
N/C
4RIM4"LACK 3TAINLESS3TEEL N/C
%ND0ANEL3TYLE5&ULLWITHMIRROR #ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
7ORK3URFACE6,AMINATED 3OLID3URFACEMATERIAL
3TAINLESS3TEEL
"LACKOR7HITE3ANALITE
#ALLFORQUOTE
N/C
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITH
CASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHENCASEIS
ORDERED
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
0RICETAGMOLDING
2
53
6
1
4
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
Mirror on
inside of end
panels
FUSION®
6
O d F 231 798 4960 | C S S P 85
Refrigerated Self-Service Open 60”H Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s !DJUSTABLEREMOVABLENONLIGHTEDMETALSHELVING
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s POWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake from rear and out front panel at toe kick.
Front panel cannot be blocked.
&3/2
MODEL FSO4860R FSO7260R FSO9660R
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
&3/2 850
&3/2 1,180
&3/2 1,350
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER -AYINCREASEHEIGHTOFCASEREFERTOSPECIlCATIONSHEET
Contact factory for technical electrical information
Product Specification Standard (N/C) Options(s) List $
)NTERIOR#OLOR "LACK 7HITE
3TAINLESS3TEEL
N/C
%XTERIOR#OLOR1#HOICEOF7ILSONARTOR
&ORMICANONPREMIUM
LAMINATES
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
3TAINLESS3TEEL
#ALLFORQUOTE
,OWER&RONT0ANEL2"LACK 3TAINLESS3TEEL
5PPER&RONT0ANEL3"LACK 3ILVER
0AINTEDSPECIFYCOLOR
N/C
N/C
4RIM4"LACK 3ILVER N/C
%ND0ANEL3TYLE5&ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEGLASSEND
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE ,EVELERS #ASTERSNOTAVAILABLEWITHREMOTEREFRIGERATION
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
FRONTAIRDISCHARGEATTOEKICK
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITH
CASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHENCASEIS
ORDERED
,IGHTEDMETALSHELVES
2EARLOADINGDOORS
%NERGYEFlCIENTFANS
#LEAN3WEEPAUTOMATICCONDENSERCOILCLEANER
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
0RICETAGMOLDING
JUNE 2008
/RDER%NTRY2EADY 2
5
3
1
4
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
Mirror on
inside of end
panels
IMPULSE®
66 O d F 231 798 4960 | C S S P 85
Self-Service Refrigerated Drop-In
Counter Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOGLASSENDPANELS
s 4TOPLIGHT
s 4HREENONLIGHTEDMETALSHELVESv$
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake and discharge out rear. Counter must be
configured to allow air to be drawn in and discharged out the back.
Refer to specification sheet for ventilation requirements.
NOTE: Height of display case above counter is 37 1/4”
1
3
2
$/2
MODEL DO3637R DO4837R
$IMENSIONS
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 3TAINLESS3TEEL
%XTERIOR#OLOR1"LACK 3TAINLESS3TEEL
5PPER2EAR23OLID0ANEL 3LIDINGCLEARGLASSDOORSWITHINNERPLEXIPLENUM
3HELVING3.ONLIGHTEDSHELVES ,IGHTEDSHELVES
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
ANDDISCHARGE
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
2OLLDOWNSECURITYCOVERLOCKINGINCREASESHEIGHTOFCASEBYv
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
.IGHTCURTAINPULLDOWNNONLOCKING
2EMOVABLESOLIDSECURITYCOVERLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
$/2 720 14-20P 120/1/60 4,358
$/2 780 14-20P 120/1/60 4,512
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
v,Xv$Xv( v,Xv$Xv(
IMPULSE®
6
O d F 231 798 4960 | C S S P 85
$/2
Self-Service Refrigerated Drop-In
Counter Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOGLASSENDPANELS
s 4TOPLIGHT
s /NENONLIGHTEDSHELFv$
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake and discharge out rear. Counter must be
configured to allow air to be drawn in and discharged out the back.
Refer to specification sheet for ventilation requirements.
NOTE: Height of display case above counter is 23 1/4”
MODEL DO3623R DO4823R
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR "LACK 3TAINLESS3TEEL
%XTERIOR#OLOR1 "LACK 3TAINLESS3TEEL
5PPER2EAR23OLID0ANEL 3LIDINGCLEARGLASSDOORSWITHINNERPLEXIPLENUM
3HELVING3.ONLIGHTEDSHELF ,IGHTEDSHELF
v($ISPLAYSTEPINLIEUOFSHELF
.#
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
ANDDISCHARGE
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARDOORLOCK
2OLLDOWNSECURITYCOVERLOCKINGINCREASESHEIGHTOFCASEBYv
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
.IGHTCURTAINPULLDOWNNONLOCKING
2EMOVABLESOLIDSECURITYCOVERLOCKING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE 2EQUIRESTHREEWIRESPLUSGROUND
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
$/2 600 120/1/60 5-20P 120/1/60 2,200
$/2 700 14-20P 120/1/60 2,817
1 2
3
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
IMPULSE®
68 O d F 231 798 4960 | C S S P 85
$/2
Self-Service Refrigerated Drop-In
Counter Case
Standard Features
s "REEZE©2EFRIGERATION3YSTEM3EEPAGE
s 4WOGLASSENDPANELS
s 4TOPLIGHT
s POWERCORD
s )NTEGRATEDAVERAGEPRODUCTTEMPERATUREOF&
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORYEARCOMPRESSORWARRANTY
NOTE: Compressor air intake and discharge out rear of case. Counter must be
configured to allow proper ventilation around refrigeration package.
NOTE: Height of display case above counter is 15 1/2”
MODEL DO3616R DO4816R
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR%XTERIOR#OLOR "LACK 3TAINLESS3TEEL
2EFRIGERATION "REEZE4-SELFCONTAINEDW
EVAPORATORPANREARAIRINTAKE
ANDDISCHARGE
2EMOTECOMPRESSORSUPPLIEDBYOTHERS
0RESSURERELEASEVALVEREQUIREDFORCITYOF#HICAGOMUSTBEORDEREDWITHCASE
#ALLFORQUOTE
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTYEXCLUDESCOMPRESSOR
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
.IGHTCURTAINPULLDOWNNONLOCKING
2EMOVABLESOLIDSECURITYCOVERLOCKING
$ISPLAYSTEP
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
Self-Contained Refrigeration/Dry Remote Refrigeration with Leads
MODEL WEIGHT VOLTS AMPS NEMA PLUG VOLTS AMPS BTUH
$/2 600 120/1/60 5-15P 120/1/60 1,330
$/2 700 120/1/60 5-15P 120/1/60 1,805
Shown with optional
display step
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
This model may require additional lead time
IMPULSE®
6
O d F 231 798 4960 | C S S P 85
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
CGS2830 270 120/1/60 5-15P
CGS3830 350 120/1/60 5-15P
CGS2830
Service/Self-Service Non-Refrigerated
Countertop Case - Straight Front
Standard Features
s #LEARGLASSSWINGINGDOORS
s 3TRAIGHTFRONTGLASSANDENDS
s 4TOPLIGHT
s 4HREELIGHTEDSHELVES
s 3HELVESADJUSTABLEREMOVABLEFORSERVICESELFSERVICEAPPLICATION
s POWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s /NEYEARPARTSANDLABORWARRANTY
NOTE: Case can be reversed to provide rear door access for customer self-service.
Shelf brackets are adjustable to accommodate new position.
MODEL CGS2830 CGS3830
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR%XTERIOR#OLOR1"LACK 3TAINLESS3TEEL
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
1
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
IMPULSE®
70 O d F 231 798 4960 | C S S P 85
Service/Self-Service Non-Refrigerated
Countertop Case - Curved Front
Standard Features
s #LEARGLASSSWINGINGDOORS
s #URVEDFRONTGLASSANDENDS
s 4TOPLIGHT
s 4HREELIGHTEDSHELVES
s 3HELVESADJUSTABLEREMOVABLEFORSERVICESELFSERVICEAPPLICATIONS
s POWERCORD
s %4,SANITATIONCONFORMSTO.3&
s %4,,ISTED#ERTIFIEDTO#!.#3!
s /NEYEARPARTSANDLABORWARRANTY
NOTE: Case can be reversed to provide rear door access for customer self-service.
Shelf brackets are adjustable to accommodate new position.
MODEL CGC2830 CGC3830
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Product Specification Standard (N/C) Option(s) List $
)NTERIOR%XTERIOR#OLOR1"LACK 3TAINLESS3TEEL
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
CGC2830
1
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
CGC2830 400 120/1/60 5-15P
CGC3830 450 120/1/60 5-15P
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
IMPULSE®
7
O d F 231 798 4960 | C S S P 85
Self-Service Non-Refrigerated Countertop Case
Standard Features
s &OURTRAYSUPPORTSHELVESv$
s "LACKINTERIORCOLORANDFRAME
s 3ELFCLOSINGSWINGINGFRONTDOORS
s 4SIDELIGHTSWITHPROTECTIVESHIELDS
s vPOWERCORD
s %4,,ISTED#ERTIFIEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
CSC3223
NOTE: Holds (4) 18”x26” trays. Trays not supplied with unit.
MODEL CSC3223
$IMENSIONS v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
CSC3223 300 120/1/60 5-15P
Product Specification Standard (N/C) Option(s) List $
"ASE1v(WITHBAGAREA'RAY v(WITHOUTBAGAREA"LACK
v(WITHBAGAREA"LACK
'RAPHICS .ONE vHEADERSIGNPLAINCLEARACRYLIC
vHEADERSIGNWITHGRAPHICSCUSTOMERSUPPLIEDARTWORK
&RONTDOORGRAPHICSCUSTOMERSUPPLIEDARTWORK
2EAR23OLID0ANEL -IRROREDPANEL
#LEARGLASSSWINGINGDOORS
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
2
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIFICATIONDRAWINGSFORMOREDETAIL
See page 10
1
ADDENDA®
72 O d F 231 798 4960 | C S S P 85
Upright Self-Service Pastry Case - 65 1/4”H
Standard Features
s 4WOGLASSENDPANELS
s &OURTRAYSUPPORTSHELVESv$
s "LACKINTERIORCOLORANDFRAME
s 3ELFCLOSINGSWINGINGFRONTDOORS
s 4SIDELIGHTS
s vPOWERCORD
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
2
CSF4231
MODEL CSF4231
$IMENSIONS v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
CSF4231 650 5-15P
Product Specification Standard (N/C) Option(s) List $
%XTERIOR1'RAY "LACK
7ILSONARTOR&ORMICANONPREIUMLAMINATEASNOTEDINLAMINATECHARTS
7ILSONARTOR&ORMICAPREIUMLAMINATEASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATE
.#
.#
#ALLFORQUOTE
"ASE23TRAIGHTBASEWITHv$
PACKAGELEDGE
"ASEWITHSTORAGEDOORANDLEDGE
"ASEWITHSTORAGEDOORANDWITHOUTLEDGE
.#
'RAPHICS .ONE &RONTDOORGRAPHICSCUSTOMERSUPPLIEDARTWORK
(EADERSIGNPLAIN
(EADERSIGNWITHGRAPHICSCUSTOMERSUPPLIEDARTWORK
5PPER2EAR33OLIDBACKPANEL #LEARGLASSSWINGINGDOORSWITHOUTLOCK
2EmECTIVEGLASSSWINGINGDOORSWITHOUTLOCK
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
3ECONDYEARPARTSLABORWARRANTY
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
See page 10
3
NOTE: Holds (8) 18”x26” trays. Trays not supplied with unit.
ADDENDA®
7
O d F 231 798 4960 | C S S P 85
Upright Self-Service Pastry Case - 83 1/4”H
Standard Features
s &OURADJUSTABLEREMOVABLETRAYSUPPORTSHELVES
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3OLIDUPPERBACKPANEL
s /PENLOWERREARSTORAGE
s 3INGLEPANEGLASSFRONTSWINGINGDOORSWITHSTAYOPENFEATURE
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPANDSHELFLIGHTS
s vPOWERCORD
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
3
6
5
Black
PC5682
MODEL PC3982 PC5682 PC7482
$IMENSIONS v,Xv$Xv( v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
PC3982 900 43 5-15P
PC5682 920 5-15P
PC7482 1,150 5-15P
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIlCATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
4
2
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR 7HITE "LACK
%XTERIOR#OLOR1 0AINTEDSPECIFYCOLOR 7ILSONARTOR&ORMICANONPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
.#
#ALLFORQUOTE
5PPER2EAR23OLIDBACKPANELWHITE -IRRORBACKPANEL
-IRRORSLIDINGDOORS
2EmECTIVEGLASSSLIDINGDOORS
(EADER3TYLE3#URVED 3QUARE
3HELVING4 4RAYSUPPORTSHELVESv$ #HROMEWIRERACKSv$
"LACKWIRERACKSv$
%ND0ANEL3TYLE5 &ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEENDGLASS
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE3TYLE6 3TRAIGHTWITHOUTFRONTSTORAGE 3TRAIGHTWITHFRONTSTORAGEANDWASTEBIN
!NGLEDWITHFRONTSTORAGEANDWASTEBIN
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARSLIDINGSTORAGEDOORS
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
0RICETAGMOULDING
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
Mirror
on inside
of end
panels
ADDENDA®
74 O d F 231 798 4960 | C S S P 85
Upright Self-Service Pastry/Hard Roll Case
83 1/4”H
Standard Features
s 4WOADJUSTABLEREMOVABLETRAYSUPPORTSHELVES
- PHRM5682 Capacity: (18) 9”x26” trays (not supplied)
PHRM7482 Capacity: (24) 9”x26” trays (not supplied)
s /NEROWOFACRYLICBINSBELOWDOORS
- (4) in model PHRM5682
- (6) in model PHRM7482
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3OLIDUPPERBACKPANEL
s /PENLOWERREARSTORAGE
s 3INGLEPANEGLASSFRONTSWINGINGDOORSWITHSTAYOPENFEATURE
s 3TRAIGHTLAMINATEDFRONTPANEL
s 4TOPANDSHELFLIGHTS
s vPOWERCORD
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
3
4
5
Black
0(2-
MODEL PHRM5682 PHRM7482
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
0(2- 1,050 5-15P
0(2- 1,100 5-15P
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR 7HITE "LACK
%XTERIOR#OLOR1 0AINTEDSPECIFYCOLOR 7ILSONARTOR&ORMICANONPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
.#
#ALLFORQUOTE
5PPER2EAR23OLIDBACKPANELWHITE -IRRORBACKPANEL
2EmECTIVESLIDINGDOORS
(EADER3TYLE3#URVED 3QUARE
%ND0ANEL3TYLE4&ULLWITHMIRROR #UTAWAYWITHGLASS
#ASETOCASEENDGLASS
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
END
"ASE3TYLE53TRAIGHTWITHOUTFRONTSTORAGE 3TRAIGHTWITHFRONTSTORAGEANDWASTEBIN
!NGLEDWITHFRONTSTORAGEANDWASTEBIN
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARSLIDINGSTORAGEDOORS
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
0RICETAGMOLDING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
2
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
Note: Trays not supplied with case.
Mirror
on inside
of end
panels
ADDENDA®
7
O d F 231 798 4960 | C S S P 85
Upright Self-Service Shelving/Hard Roll Case
83 1/4”H
Standard Features
s 4WOADJUSTABLEREMOVABLEHARDROLLSHELVESv$
s 4WOROWSOFACRYLICBINS
- (8) in model SHRM5682
- (12) in model SHRM7482
s 4WOFULLENDPANELSWITHMIRRORINTERIOR
s 3OLIDUPPERBACKPANEL
s /PENLOWERSTORAGE
s 4TOPANDSHELFLIGHTS
s vPOWERCORD
s %4,,ISTED#ERTIlEDTO#!.#3!
s YEARPARTSANDLABORWARRANTY
1
3
4
Black
3(2-
MODEL SHRM5682 SHRM7482
$IMENSIONS v,Xv$Xv( v,Xv$Xv(
,IST
Self-Contained Refrigeration/Dry
MODEL WEIGHT VOLTS AMPS NEMA PLUG
3(2- 900 5-15P
3(2- 1,100 5-15P
Product Specification Standard (N/C) Option(s) List $
)NTERIOR#OLOR 7HITE "LACK
%XTERIOR#OLOR10AINTEDSPECIFYCOLOR 7ILSONARTOR&ORMICANONPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
7ILSONARTOR&ORMICAPREMIUMLAMINATESASNOTEDINLAMINATECHARTS
/THERMANUFACTURERSLAMINATES
.#
#ALLFORQUOTE
5PPER2EAR23OLIDBACKPANELWHITE -IRRORBACKPANEL
(EADER3TYLE3#URVED 3QUARE
%ND0ANEL3TYLE4&ULLWITHMIRROR #UTAWAYWITHOUTGLASS
$EDUCTENDPANELFORCASETOCASELINEUPS
END
END
"ASE3TYLE53TRAIGHTWITHOUTFRONTSTORAGE 3TRAIGHTWITHFRONTSTORAGEANDWASTEBIN
!NGLEDWITHFRONTSTORAGEANDWASTEBIN
-ISCELLANEOUS
-USTBECHOSENWHEN
CASEISORDERED
2EARSLIDINGSTORAGEDOORS
3ECONDYEARPARTSLABORWARRANTY
!CCESSORIES
#ANBEPURCHASEDATANY
TIME2EFERTOPAGESFOR
INFORMATION
0RICETAGMOLDING
&REIGHT#LASS./4%&REIGHTRATESUBJECTTOLINEARFOOTRULE
"ASEDONOPERATINGCONDITIONSOF&ANDRELATIVEHUMIDITY
3PECIFICATIONSANDPRICINGSUBJECTTOCHANGEWITHOUTNOTICE
-USTCHOOSEONEWHENPLACINGORDER
5
2
$IMENSIONSSHOWNARENOTEXACT2EFERTO&ACTORY3PECIlCATIONDRAWINGSFORMOREDETAIL
Mirror
on inside
of end
panels
2” H Display Steps (for lower area).
Display Steps
ACCESSORIES & MISCELLANEOUS OPTIONS
4” H Display Steps (for lower area). Display Steps For model C3Z(L)67
(for lower area).
Display Steps For models CO2739R and
COU2757R (for lower area). 3” H Display Steps For model FSDG(L)R.T1
(N/A with shelf). Display Steps For model DO(L)16R.
Security Covers, Night Curtain & Package Ledge
Wire Security Cover
Removable, locking wire
security cover includes two
padlocks keyed alike.
Solid Security Cover
Removable, locking solid aluminum
security cover with Stardust Silver
powder-coated finish.
Roll-Down Locking Security Covers
Cover rolls up into the header when not in use. This feature must be
specified when ordering case. Roll-down covers increase the height of the
case as noted on specific models.
Night Curtain
Pull-down non-locking energy efficient
curtain.
6 3/4” D Front Package Ledge
This feature must be specified when
ordering case.
OHE I
O I
O I OF
H
EIR
OF
I
E E
O
NOTE: See model pages for case specific compatibility
E = Encore, H = Harmony, R = Renaissance, O = Oasis, F = Fusion, I = Impulse, A = Addenda
F
ACCESSORIES AND OPTIONS
ACCESSORIES AND OPTIONS
ACCESSORIES & MISCELLANEOUS OPTIONS
Scale Stand
Stainless steel scale stand with appliance recepta-
cle requires separate electrical circuit. This feature
must be specified when ordering case.
Rear Wrapping Board
Wrapping board is constructed of white Sanalite®.
Removable without tools for cleaning.
Price Tag Molding
1 1/2” H Wire Baskets
for HVB(L)SS cases. Available in black
or chrome.
4” H Wire Baskets
For HVB(L)SS cases. Black only. Clear Liner / Divider
For Wire baskets in HVB(L)SS cases. Available in
1 1/2” H & 4” H.
Bottle Slide
Gravity fed bottle slide for lower area of
HMBC(L) cases.
Control Knob Guards
For hot cases. Acrylic Candy Trays
For Model RCG(L)48R. See page 43 for size
dimensions and quantities per case.
NOTE: See model pages for case specific compatibility
E = Encore, H = Harmony, R = Renaissance, O = Oasis, F = Fusion, I = Impulse, A = Addenda
ROF
H
E
IA
RFRF
H
E
EEE
RF
R
Structural Concepts has partnered with both Wilsonart® and Formica® to offer all of their “non-premium” laminate collections at
no additional cost to our customers. An upcharge will apply to laminates noted as “premium” from these collections. Case lead
time may be affected with the use of “premium” laminates. Full color Wilsonart® or Formica® charts are available from our
company representatives or can be viewed online via the manufacturer’s website at: www.wilsonart.com and www.formica.com
Other manufacturer’s (ie: Pionite®, Nevamar® etc.) laminates are available. Contact us for details or quote.
Laminates
www.wilsonart.com
www.formica.com
H
FOODSERVICE REPRESENTATIVE LIST
ALABAMA
The Hansen Group
Phone 770-667-1544
Fax 770-667-1491
sales@thehansengroup.net
ALASKA
Roller & Associates
Phone 509-990-5520
Fax 509-272-1770
steve@rollerassoc.com
ARIZONA
Johnson Pike & Associates Inc.
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
ARKANSAS
The Wallin Group
Phone 501-663-2438
Fax 501-663-2439
jheimbach@wallingroup.com
CALIFORNIA
Southern CA
Hodak Kolstad Marketing
Zip Codes: 90000-93499
Phone 714-898-1003
Fax 714-898-5438
info@hodakkolstad.com
Northern CA
Premier Marketing Group
Zip Codes: 93500-96699
Phone 916-361-9500
Fax 916-361-4500
premiermktg@kitchenreps.com
COLORADO
Johnson Pike & Associates Inc.
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
CONNECTICUT
Hatch-Jennings
Zip Codes: 06000-06700
Phone 978-456-8702
Fax 978-456-8067
kristenp@hatch-jennings.com
Posternak-Bauer Associates
Zip Codes: 06800-06999
Phone 914-793-9000
Fax 914-793-9209
info@pbarep.com
DELAWARE
BHG/Nordon
Phone 856-910-8070
Fax 856-910-8072
info@bachovinhealygroup.com
FLORIDA
Preferred Marketing Agents
Zip Codes: 32000-32399 &
32600-34999
Phone 954-943-1661
Fax 954-943-9209
jkinni@pmafla.com
The Hansen Group
Zip Codes: 32400-32599
Phone 770-667-1544
Fax 770-667-1491
sales@thehansengroup.net
GEORGIA
The Hansen Group
Phone 770-667-1544
Fax 770-667-1491
sales@thehansengroup.net
HAWAII
Pacific Rim Rep Group
Phone 808-524-8884
Fax 808-524-8817
ms-prreps@hawaii.rr.com
IDAHO
Roller & Associates
Phone: 509-990-5520
Fax 509-272-1770
steve@rollerassoc.com
ILLINOIS
Elite Marketing
Zip Codes: 60000-61899 &
60601-60701
Phone 630-516-9260
Fax 630-516-9261
jdziuban@elitemarketinginc.net
Burlis-Lawson Group, Inc.
Zip Codes: 61900-62999
Phone 636-391-0086
Fax 636-391-9391
sharon@burlislawson.com
INDIANA
HRI, Inc.
Zip Codes: 46000-46302 &
46412-47999
Phone 586-771-0335
Fax 586-771-3083
info@hri-inc.com
Elite Marketing
Zip Codes: 46303-46411
Phone 630-516-9260
Fax 630-516-9261
jdziuban@elitemarketinginc.net
IOWA
Burlis-Lawson Group, Inc.
KANSAS
KENTUCKY
Phone 440-842-2800
Fax 440-842-2833
rose@wbmarket.net
LOUISIANA
The Wallin Group
Phone 504-733-3344
Fax 504-733-0854
swray@wallingroup.com
MAINE
Hatch-Jennings
Phone 978-456-8702
Fax 978-456-8067
kristenp@hatch-jennings.com
MARYLAND
Lane Marketing Group
Phone 410-974-1108
Fax 410-757-0293
hdq@lanegroup.com
MASSACHUSETTS
Hatch-Jennings
Phone 978-456-8702
Fax 978-456-8067
kristenp@hatch-jennings.com
MICHIGAN
HRI, Inc.
Zip Codes: 48000-49799 &
49901-49999
Phone 586-771-0335
Fax 586-771-3083
info@hri-inc.com
Clark, Malone & Associates
Northern MI (UP)
Zip Codes: 49800-49900
Phone 414-326-3600
Fax 414-326-3601
bob@clarkmalone.com
MINNESOTA
Hollander Company
Phone 952-829-5500
Fax 952-829-9664
admin@hollandercompany.com
MISSISSIPPI
The Wallin Group
Phone 601-992-7260
Fax 601-992-7350
tsimmons@wallingroup.com
MISSOURI
Burlis-Lawson Group, Inc.
Phone 636-391-0086
Fax 636-391-9391
sharon@burlislawson.com
MONTANA
Johnson Pike & Associates Inc.
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
NEBRASKA
Burlis-Lawson Group, Inc.
NEVADA
Zip Codes: 89000-89199
Phone 714-898-1003
Fax 714-898-5438
info@hodakkolstad.com
Premier Marketing Group
(Northern)
Zip Codes: 89300-89899
Phone 916-361-9500
Fax 916-361-4500
premiermktg@kitchenreps.com
FOODSERVICE REPRESENTATIVES
Phone 515-277-5876
Burlis-Lawson Group, Inc.
Fax 515-277-5896
Phone 913-599-2210
WB Marketing
Fax 913-599-2517
Phone 913-599-2210
Fax 913-599-2517
Hodak Kolstad Marketing
debbie@burlislawson.com
debbie@burlislawson.com
todd@burlislawson.com
FOODSERVICE REPRESENTATIVES
FOODSERVICE REPRESENTATIVE LIST
NEW HAMPSHIRE
Hatch-Jennings
Phone 978-456-8702
Fax 978-456-8067
kristenp@hatch-jennings.com
NEW JERSEY
Posternak-Bauer Associates
Zip Codes: 07000-07999 &
08800-08999
Phone 914-793-9000
Fax 914-793-9209
info@pbarep.com
BHG/Nordon
Zip Codes: 08000-08799
Phone 856-910-8070
Fax 856-910-8072
info@bachovinhealygroup.com
NEW MEXICO
Johnson Pike & Associates Inc.
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
NEW YORK
Link2 Hospitality Solutions
Zip Codes: 12000-14999
Phone 585-254-1780
Fax 585-254-2154
rward@qualityrepsource.com
Posternak-Bauer Associates
Zip Codes: 10000-11999
Phone 914-793-9000
Fax 914-793-9209
info@pbarep.com
NORTH CAROLINA
Swanson-Girard & Associates
Phone 704-521-8811
Fax 704-521-8801
bschaab@swanson-girard.com
NORTH DAKOTA
Hollander Company
Phone 952-829-5500
Fax 952-829-9664
admin@hollandercompany.com
OHIO
WB Marketing
Phone 440-842-2800
Fax 440-842-2833
rose@wbmarket.net
OKLAHOMA
Ettinger-Rosini & Assoc.
Phone 214-343-2548
Fax 214-343-2727
toni@ettros.com
OREGON
Roller & Associates
Phone 503-890-6477
Fax 360-882-0637
lenny@rollerassoc.com
PENNSYLVANIA
BHG/Nordon
Zip Codes: 16900-19669
Phone 856-910-8070
Fax 856-910-8072
info@bachovinhealygroup.com
WB Marketing
Zip Codes: 15000-16899
Phone 440-842-2800
Fax 440-842-2833
rose@wbmarket.net
RHODE ISLAND
Hatch-Jennings
Phone 978-456-8702
Fax 978-456-8067
kristenp@hatch-jennings.com
SOUTH CAROLINA
Swanson-Girard & Associates
Phone 704-521-8811
Fax 704-521-8801
bschaab@swanson-girard.com
SOUTH DAKOTA
Hollander Company
Phone 952-829-5500
Fax 952-829-9664
admin@hollandercompany.com
TENNESSEE
The Hansen Group
Zip Codes: 37000-37999 &
38400-38900
Phone 770-667-1544
Fax 770-667-1491
sales@thehansengroup.net
The Wallin Group
Zip Codes: 38000-38399
Phone 901-370-4724
Fax 901-370-4734
dlagraize@wallingroup.com
TEXAS
Ettinger-Rosini & Assoc.
Zip Codes: 75000-79799
Phone 214-343-2548
Fax 214-343-2727
toni@ettros.com
Johnson Pike & Associates Inc.
Zip Codes: 79800-79999
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
UTAH
Johnson Pike & Associates Inc.
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
VERMONT
Hatch-Jennings
Phone 978-456-8702
Fax 978-456-8067
kristenp@hatch-jennings.com
VIRGINIA
Lane Marketing Group
Phone 410-974-1108
Fax 410-757-0293
hdq@lanegroup.com
WASHINGTON D.C.
Lane Marketing Group
Phone 410-974-1108
Fax 410-757-0293
hdq@lanegroup.com
WASHINGTON
Roller & Associates
Phone 206-547-3555
Fax 206-547-8630
customerservice@rollerassoc.com
WEST VIRGINIA
Lane Marketing Group
(Charleston)
Zip Codes: 25000-25399
Phone 410-974-1108
Fax 410-757-0293
hdq@lanegroup.com
WB Marketing
(except Charleston)
Zip Codes: 24700-24999 &
25400-26884
Phone 440-842-2800
Fax 440-842-2833
rose@ wbmarket.net
WISCONSIN
Hollander Company
(LaCrosse)
Zip Codes: 54601-54603
Phone 952-829-5500
Fax 952-829-9664
admin@hollandercompany.com
Clark, Malone & Associates
(except LaCrosse)
Zip Codes: 53000-54600 &
54604-54999
Phone 414-326-3600
Fax 414-326-3601
bob@clarkmalone.com
WYOMING
Johnson Pike & Associates Inc.
Phone 303-572-0084
Fax 303-572-8152
jpa@johnsonpike.com
CANADA
Consult Factory
Christine Clark (Customer Service)
Phone 800-433-0142
MEXICO, SOUTH AMERICA,
CARIBBEAN, CENTRAL
AMERICA, COSTA RICA,
VENEZUELA, PUERTO RICO
MerkoLAT
Phone 561-961-1389
Fax 561-792-6351
info@merkolat.com
MASTER SERVICE AGENT LISTING
To process a request for WARRANTY RELATED SERVICE, please follow the steps below:
Identify the unit’s model and serial numbers. This information can be found on the silver serial label attached to the 1.
unit. The serial label is typically on the rear of the merchandiser near your electrical access.
Contact the Master Service Agent for your area. 2.
Master Service Agent will invoice Structural Concepts if the issue is covered under warranty. The customer will be 3.
responsible for non-warranty claims (e.g. routine maintenance, operator inflicted damage, tampering with settings by
non-authorized service contractor, etc.)
*If you do not see your state listed, or for additional updates, please visit our website at www.structuralconcepts.com or
call your Technical Service Rep.
*If you have a service contractor that you work with on a regular basis, please share this information with our Technical
Service Representative. In most cases, we will honor your request to have a specific contractor do the service work, but will
need to contact them first to authorize repair and invoicing.
STATE COMPANY NAME PHONE FAX
ALABAMA
Birmingham Heritage Service Group 205-833-1216 205-833-1690
Leeds Southeast Company 205-699-5777 205-699-5019
Mobile Air Tec Refrigeration 251-639-1137 251-639-1138
Montgomery Central Alabama Refrigeration 334-834-2222 334-834-4300
ALASKA
Anchorage Polar Refrigeration 907-349-3500 907-344-7053
ARIZONA
Phoenix Andrews Refrigeration 602-992-9560 602-992-9570
ARKANSAS
Little Rock Scotts Refrigeration 501-562-1863 501-562-2308
CALIFORNIA
Anaheim Norms Refrigeration 714-236-3600 714-236-0607
Oxnard Koolco Mechanical 805-604-0309
Roseville R&M Refrigeration 916-784-3600
San Diego Refrigeration 858-270-5555 619-293-0870
Visalia A.R.C. Comfort 800-300-7700 559-627-2151
COLORADO
Denver/Ft Collins/Co. Springs General Parts & Service 800-892-0455 303-308-1723
CONNECTICUT
Enviro Services 781-444-5945 781-444-5948
FLORIDA
Jacksonville Fournier Refrigeration 904-260-0464 904-268-8065
Jacksonville Heritage Service Group 904-264-1940 904-264-1947
Lakeland - Tampa Newberry’s Refrigeration 863-688-8871 863-683-2698
Lantana Excell Refrigeration 561-585-0342 561-547-0069
Melbourne Market Refrigeration 800-622-0426 321-951-4308
Miami All Phase 305-235-7827 305-874-9314
Orlando Heritage Service Group 407-316-8010 407-996-2760
Pensacola Heritage Service Group 850-478-5533 850-478-7062
Pompano Beach/S Florida Heritage Service Group 954-971-0456 954-977-7317
Pompano Beach/S Florida Prime Mechanical Services 954-971-2444 954-971-2441
Tallahassee Premium Services 850-668-8566 850-425-5776
Tampa Heritage Service Group 813-620-1777 813-621-3339
W Palm Beach Smithco Refrigeration 561-833-3793 561-832-9051
MASTER SERVICE AGENTS
805-604-0312
San Diego
Salinas Traboh Inc. 831-758-6646 831-758-0791
San Francisco South City Refrigeration 800-200-8256 650-588-7726
Santa Rosa California Refrigeration 707-544-5313 707-545-6823
MASTER SERVICE AGENTS
MASTER SERVICE AGENT LISTING
STATE COMPANY NAME PHONE FAX
GEORGIA
(Jacksonville, FL) Fournier Refrigeration 904-260-0464 904-268-8065
Atlanta Heritage Service Group 770-368-1465 770-368-2044
Fayetteville T&O Refrigeration 770-461-5217 770-461-0569
Macon Metro Air 478-788-3826 478-785-0358
Savannah Heritage Service Group 912-965-9621 912-965-9622
HAWAII
Kaneohe Shobu’s Refrigeration 808-479-5817 808-484-2221
Maui A&I Refrigeration 808-877-7866 808-877-2126
Oahu Pacific Refrigeration 808-488-5244 808-488-3845
IDAHO
Garden City Boise Refrigeration 208-344-0709 208-344-4457
ILLINOIS
Chicago/Rockford/NW IN General Parts & Service 800-880-3604 630-595-0006
Urbana Frosty Refrigeration 217-367-7925 217-367-1058
Wauconda U.S. Refrigeration 847-526-1099 847-526-9982
INDIANA
(Cincinnati, OH) Commercial Parts Service 800-837-2828
Indianapolis Heritage Service Group 317-544-4326 317-544-4327
Indianapolis/Terre Haute/
Bloomington General Parts & Service 800-410-9794 317-290-8085
Muncie Turner Commercial Ref. 765-288-5306 765-288-5363
KANSAS
Wichita General Parts & Service 866-211-5439 316-315-0660
KENTUCKY
(Cincinnati, OH) Commercial Parts Service 800-837-2828
Louisville Heritage Service Group 502-569-7722
Louisville Platt Mechanical 502-896-9886 502-491-0680
Murray Randy Thornton 270-753-8181 270-753-2130
LOUISIANA
Baton Rouge Eagle Refrigeration 225-751-6912 225-751-6916
Baton Rouge Heritage Service Group 225-667-8314 225-262-2692
Harahan Abear Refrigeration 504-733-3600 504-733-3692
Lake Charles C&W Refrigeration 337-474-4432 337-562-7999
New Orleans Heritage Service Group 504-734-8864 504-733-2559
Shreveport Heritage Service Group 318-636-2008 318-636-2122
Shreveport TD Refrigeration 318-747-8844 318-226-1455
MARYLAND
Baltimore EMR Service 410-467-8080 410-243-2509
MASSACHUSETTS
Needham(Covers CT, MA, RI) Enviro Services 781-444-5945 781-444-5948
MICHIGAN
Ferndale Penguin Refrigeration 248-542-3158 248-542-3058
Mid-Michigan Swanson Food Equipment 517-852-0779 517-852-0637
Mount Pleasant Heritage Service Group 989-775-6560 989-775-6563
New Hudson Four Streams Services 248-437-4400 734-786-1220
Saginaw Schroder Store Fixture 989-233-2973 989-790-3008
MINNESOTA
Minneapolis Heritage Service Group 651-633-0400 651-697-7346
Twin Cities/Rochester/St. Cloud General Parts & Service 800-279-9980 952-944-7101
MASTER SERVICE AGENTS
STATE COMPANY NAME PHONE FAX
MISSISSIPPI
Gulfport Geiger Heating & Air 228-832-2465 228-832-1027
Jackson Heritage Service Group 601-607-3340 601-607-3499
Terry Yates Refrigeration 601-878-0130 601-878-2617
MISSOURI
Kansas City/Springfield/
St. Joseph/(Topeka, KS) General Parts & Service 800-279-9967 816-421-1270
St. Louis, Chesterfield,
St. Charles, Granite City Commercial Services 636-519-7000 314-965-9727
NEBRASKA
Omaha Marking Refrigeration 402-895-0255 402-895-6295
Omaha (Serving Iowa) General Parts & Service 888-831-4031 402-408-9991
NEVADA
Las Vegas Heritage Service Group 702-558-3188 702-564-6804
Las Vegas JJ07 Refrigeration 702-300-4823 702-233-0047
State Line Summit Refrigeration 775-588-1288 775-562-2660
NEW JERSEY
Orange Neil Sullivan & Associates 973-678-2155 973-678-5728
Paterson Airtron 973-684-5002 973-684-4130
NEW MEXICO
Albuquerque Certified Service 505-343-9934 505-343-9964
NEW YORK
Buffalo Mesmer Refrigeration 716-855-0575 716-855-3268
College Point All Service Refrigeration 718-746-7965 718-746-6054
New Hyde Park Day & Nite Refrigeration 516-719-8842 516-378-1735
New York Bev Service 212-246-6588 212-246-6586
New York Enviro Services 781-444-5945 781-444-5948
New York United Air 845-561-5030 845-561-0038
Rochester Flower City Restaurant Service 585-482-5890 585-482-5915
Syracuse ABC Refrigeration 315-455-7083 315-455-5923
NORTH CAROLINA
Charlotte Day & Nite Refrigeration 803-746-7163 803-746-7164
Charlotte Freeman Refrigeration 704-394-8234 704-394-0998
Greensboro Greensboro Refrigeration 336-272-9361 336-272-8411
Raleigh Heritage Service Group 919-481-3535 919-481-1470
Winston-Salem Cool Brew Refrigeration Svc 336-785-1242 336-771-7313
NORTH DAKOTA
Bismarck River City Refrigeration 701-250-8300 701-250-8390
Fargo Dakota Refrigeration 701-235-9698 701-235-5207
Fargo General Parts & Service 800-279-9987 701-235-0539
OHIO
Cincinnati Commercial Parts Service 800-837-2828
Cleveland Daly Refrigeration 216-441-2323 216-441-1331
Columbus Commercial Parts Service 614-221-0057 614-221-3622
Dayton Commercial Parts Service 937-259-0091 937-259-0753
OKLAHOMA
Oklahoma City Heritage Service Group 405-228-0707
Oklahoma City Hinton Refrigeration 405-946-2766 405-946-2765
OREGON
Medford Applied Refrigeration 541-245-5513 541-245-4468
Milwaukee Key Mechanical 503-231-0731 503-236-5848
MASTER SERVICE AGENT LISTING
MASTER SERVICE AGENTS
STATE COMPANY NAME PHONE FAX
PENNSYLVANIA
Allentown Howard Refrigeration 610-434-3877 610-434-2677
Bridgeville B.E. Refrigeration 412-564-9000 412-564-9005
Harrisburg Hobart Sales & Service 717-564-6202 717-564-2184
Philadelphia R.S. Sales & Service 215-333-9200 215-333-8874
State College Berrena Refrigeration 814-238-0238 814-238-8668
RHODE ISLAND
(Needham, MA) Enviro Service 781-444-5945 781-444-5948
SOUTH CAROLINA
Charleston Aero Services 843-747-4700 843-747-7059
Charleston Heritage Service Group 877-428-1605 877-969-4576
Columbia Heritage Service Group 803-865-5131 803-865-5524
Greenville Refrigeration Services 864-292-0092 864-292-0611
Lexington Excell Refrigeration 803-939-1914 803-939-7002
Myrtle Beach Heritage Service Group 843-626-4209 843-626-1942
Rock Hill Day & Nite Refrigeration 803-746-7163 803-746-7164
SOUTH DAKOTA
Rapid City Al Cornella Refrigeration 605-348-4684 605-348-5105
Sioux Falls Mulder Refrigeration 605-338-1897 605-338-1820
TENNESSEE
Chattanooga FESCO 423-624-3381 423-624-3383
Knoxville FESCO 865-522-5764 865-522-0982
Knoxville Heritage Service Group 865-577-1004 865-577-8151
Memphis Heritage Service Group 901-379-0900 901-379-0935
Nashville FESCO 615-724-1118 615-724-1121
Nashville Heritage Service Group 615-254-8688 615-254-8696
Nashville T&O Refrigeration 770-461-5217 770-461-0569
TEXAS
Dallas/Fort Worth Heritage Service Group 817-831-1144 817-831-2324
Dallas/Fort Worth/ Mesquite R.S.I 972-279-3800 972-331-2276
Houston Heritage Service Group 713-839-0100 713-839-0115
Houston Houston North Refrigeration 713-692-7702 281-389-4728
San Antonio Heritage Service Group 210-921-1355 210-590-6792
San Antonio Heye Refrigeration 210-226-7772 210-226-8228
UTAH
W Jordan Michael’s Commercial Service 801-446-9299 801-446-1992
VERMONT
Essex Junction KC Mechanical 802-878-0800 802-878-7001
VIRGINIA
Ashland Central Ice 804-550-7860 804-550-7861
Manassas Park Nationwide Refrigeration 703-330-7500 703-330-1945
Norfolk Heritage Service Group 757-545-2145 757-545-2146
Richmond Heritage Service Group 804-501-0890 804-501-0891
WASHINGTON
Seattle Seattle Refrigeration 206-762-7740 206-762-1730
WEST VIRGINIA
Charleston Heritage Service Group 304-941-0055 304-941-0056
WISCONSIN
Milwaukee/Green Bay/
Wausau/Rhinelander/Madison General Parts & Service 800-279-9976 262-650-6660
MASTER SERVICE AGENT LISTING
WARRANTY AND TERMS
Standard Limited Warranty
WARRANTY AND TERMS
Structural Concepts Standard limited warranties:
One-year parts/one year labor/five year motor compressor.
Parts-One Year: Structural Concepts warrants to the original purchasers, the
equipment manufactured by it to be free from defects in material and workmanship
under normal use and service within 12 months from the date of original shipment
from the factory.
Any items returned to the factory must be authorized by Structural Concepts Technical
Service Department and be shipped prepaid. Replacements will be shipped collect.
This warranty does not include any material, which has been subject to misuse,
neglect, damage in transit, accident, negligence, or alteration.
Labor-One Year: Structural Concepts warrants to the original purchasers, the
equipment manufactured by it. Structural Concepts will for a period of 12 months
from the date of original shipment from the factory pay the cost of labor for repairs
and replacement of parts that it has determined to be defective.
This warranty does not include the cost of labor for initial installation, start-up,
correction of improper installations, misapplications, repair caused by abuse and neg-
ligence, modifications, normal adjustments, drive time to and from repair site, and
freon recovery. The cost of service labor reimbursed will be based on straight-time
rate and reasonable time for the repair of defect.
All service labor charges are subject to approval by Structural Concepts Technical
Service Department. Contact your Master Service Agent. (See pages 80-83)
Motor-Compressor-Five Year: Structural Concepts warrants to the original purchasers
that it will repair or exchange at our option, at any time during the five years fol-
lowing the date of original shipment from the factory a motor-compressor assembly
of like design and capacity if the motor-compressor assembly or any part thereof is
returned prepaid to nearest authorized jobber and is proved to our satisfaction to be
inoperative due to defects in material or factory workmanship.
This warranty applies to the original motor compressor only.
The term “motor-compressor assembly” consists of the stator, rotor, eccentric rod,
eccentric shaft piston, wrist pin, suction valve, discharge valve, and the cast housing
in which these parts are enclosed.
This warranty does not apply to any electrical controls, condenser, evaporator, fan motors,
overload switch, starting relay, temperature control, dryer, accumulator, or wiring harnesses
after the first year. No claims can be made against this warranty for spoilage of product.
Replacement of the motor-compressor assembly must receive a prior approval from Structural
Concepts Technical Service Department.
This warranty does not apply to compressors furnished by Structural Concepts that are
remote from the case.
General Conditions: Structural Concepts recommends that the installation, inspection, and
start-up of refrigeration equipment be performed by a qualified refrigeration technician.
Structural Concepts makes no other expressed or implied warranty, and no person or
representative of the seller is authorized to add to the seller’s liabilities in connection with its
products other than what is expressed.
These warranties do not apply to remote (compressor supplied by others) motor
compressor applications.
Warranties listed here are for equipment located inside the continental United States
and Canada.
All claims must contain the following information:
s4HEMODELANDSERIALNUMBEROFTHEEQUIPMENT
s4HEDATEOFTHEEQUIPMENTFAILUREANDPLACEOFINSTALLATION
s4HENAMEANDADDRESSOFTHEAGENCYTHATPERFORMEDTHESERVICEWORK
s!COMPLETEDESCRIPTIONOFTHEEQUIPMENTFAILURECIRCUMSTANCESRELATINGTOTHATFAILURE
parts replaced and itemized list of all labor charges incurred.
Structural Concepts shall not be liable for any default or delay in performance caused by any
contingency beyond its control.
Warranties do not include any food or business loss and transportation charges to or from
Structural Concepts factory.
Condenser coils must be cleaned at regular intervals. Failure to do so can cause compressor
malfunction and will void warranty. Cases are designed to operate in an environment of
75˚ F ambient and 55% relative humidity.
Structural Concepts Terms Of Sale
1. PRICES. This price list supersedes all other price lists. Structural Concepts
reserves the right to change the price of equipment without notice. All
quotations for equipment shall be void if not accepted within 30 days.
2. DELIVERY. Shipping or delivery date is approximate. Seller will not be liable
for failure to deliver due to strikes, suppliers’ delays, changes requested by
Buyer or any causes beyond its control.
3. SHIPMENT. When possible, Buyer’s requested delivery carrier will be used.
Structural Concepts, however, reserves the right to ship via any responsible
carrier. Shipping charges are payable by the consignee and any claims arising
as to such charges must be resolved between the carrier and consignee.
4. DAMAGE. Claims for damage in transit must be made by the consignee with
the carrier. Structural Concepts assumes no responsibility for damages while
in transit.
5. TAXES. Federal, state, city sales or use taxes are not included with these prices.
6. CANCELLATIONS. Buyer may cancel its order, reduce quantities, revise specifications
or extend schedules only by mutual agreement with Seller. Reasonable and proper
cancellation charges will apply. These charges shall take into account expenses already
incurred and commitments made by Seller on behalf of the Buyer’s order.
7. RETURNED GOODS. No product may be returned unless authorized by Structural
Concepts corporate office. If return of product is authorized, consignee shall be required
to pay a restocking and/or handling charge. Product must be returned freight prepaid
and have not been used. Product must be received by Seller in the same condition as
originally shipped.
FACTORY CONTACT INFORMATION
Structural Concepts Corporation
888 E. Porter Road
Muskegon, MI 49441
Toll-Free 800-433-9489
Phone 231-798-8888
Fax 231-798-4960
www.structuralconcepts.com
Customer Support
Western States
Christine Clark - Customer Service Rep
800-433-0142 Extension 1
cclark@structuralconcepts.com
David Faoro - Technical Service Rep
800-433-0142 Extension 2
dfaoro@structuralconcepts.com
Eastern States
Janell Yonker - Customer Service Rep
800-433-0103 Extension 1
jyonker@structuralconcepts.com
Tom Wernstrom - Technical Service Rep
800-433-0103 Extension 2
twernstrom@structuralconcepts.com
Sales
Terry A. Hoelle, CFSP
National Sales Manager - Foodservice Division
231-798-6237
thoelle@structuralconcepts.com
Rod Herrington
Eastern Region Sales Manager - Foodservice Division
231-798-6345
rherrington@structuralconcepts.com
Jeff Schneider
VP Sales & Marketing
231-798-6258
jschneider@structuralconcepts.com
888 E. Porter Road
Muskegon, MI 49441
www.structuralconcepts.com
Toll-Free 800-433-9489
Phone 231-798-8888
Fax 231-798-4960
