AEA4440YXA Compressor Data Sheet

Drawing Information

Housing Diagram Page 2 Wiring Diagram Page 3

General Information

Compressor Model AEA4440YXA Oil Charge (cc) 303

Bill Of Material AE630AT-603-A2 Oil Type POE

Application HIGH Heat Pump (Evap range) N/A

Evaporating Range +20F to +55F Displacement 0.735

Rating Conditions ARI BTUH 3960

Rating Point +45F Horse Power 1/3

Refrigerant R-134A Discharge Line Size 0.25

Frequency 60 Suction Line Size 0.3125

Electrical Information

Voltage ( 60 Hz ) 115-60-1 Voltage Range ( 60 Hz ) 103.5 - 126.5

Voltage ( 50 Hz ) 100-50-1 Voltage Range ( 50 Hz ) 90 - 110

Rating Voltage 115-60-1 RLA 7.2

LRA 32.7 Motor Type CSIR

Start Capacitor Mfd/Volt 145-175/110 Run Capacitor Mfd/Volt N/R

Power 620 Phase 1

Maximum Continuous Current 8.9 Energy Efficiency Rating 6.39

Component Information

Relay Box NONE Integral Relay Box NONE

Capacitor Cabinet Assembly NONE Start Capacitor NONE

Production Run Capacitor NONE Crankcase Heater NONE

Primary Relay NONE Primary Vendor Number NONE

Secondary Relay NONE Secondary Vendor Number NONE

Vendor Over Load NONE Fan Over Load NONE

Terminal Cover NONE Cover Gasket NONE

Bale Strap NONE Over Load Spring NONE

PRV NONE LP Kit N/A

Grommet 70711 Roto Lock Gasket NONE

Sleeve 70459 Roto Lock Valve NONE

Housing Diagram

Wiring Diagram
