DCM-500B_H
•CleanCycle12®-Every 12 hours, unit performs 15 minute purge to rid itself of impurities
•Corrosion resistant stainless steel exterior
•Up to 567 lbs. of ice production per 24 hours, with 40 lbs. built-in storage
•Easy to chew, cubelet ice
•Self contained design reducing opportunities for cross contamination
•Dispenses ice and water
•Protected by HoshiGuard Antimicrobial Agent
SD-450 Stand / SD-500 Stand
•Heavy duty stand for floor model icemaker/dispenser
•Corrosion resistant stainless steel exterior
•Easy cleaning with attractive appearance
•Locking doors standard on SD-500
Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com
DIMENSIONS
WxDxH
DCM-500B_H
11/09
Item # 13226
SANITARY CUBELET ICE MACHINE/DISPENSER
Warranty
Valid in United States, Canada, Puerto Rico, & U.S.Territories. Contact factory for warranty in
other countries.
Two Year - Parts & Labor on entire machine.
Five Year - Parts on: Compressor, air-cooled condenser.
DCM-500B_H
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
DCM-500B_H
26 x 221/2 x 40
*AutoCad available on KCL
DCM-500BAH
Air-Cooled
Shown on an optional
SD-500 Stand
DCM-500BWH
Water-Cooled
SD-450
261/4 x 22 x 321/2
ICE WATER
ICE WATER
ICICEEWAWATERTER
DCM-500
Countertop
SD-450
optional
stand
DCM-500
Countertop
with optional
6” legs
DCM-500
Floor Model
with optional
stand
®
SD-500
optional
stand
SD-500
259/10 x 22 x 323/4
618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com
©HOSHIZAKI AMERICA, INC.
UTILITY CONSUMPTION
AIR-COOLED
Model Number
70˚
50˚ 70˚
535
90˚
80˚
90˚
Gal. Per
100 LBS.
DCM-500BAH
Air Temp˚ F.
Water Temp˚ F.
SPECIFICATIONS
Model Number Condenser Amperage Shipping
Weight
12 276 lbs.
DCM-500BAH
12.0
6.6
461
396
510
438
485
416
358
Air-Cooled
385
90/70 70/50
4.4
O P E R AT I N G L I M I T S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 90˚F
• Water Pressure 10 - 113psig
• Voltage Range 104 - 127V
ELECTRICAL&PLUMBING/DCM-500B_H
• 115V/60/1
• 20 amp Max Fuse Size
• 1/2" FPT Water Inlet
• 3/4" FPT x2 Drain
SERVICE
• Panels easily removed and all components
accessible for service.
• Removable/cleanable air filter.
(Air-cooled model only)
Printed in U.S.A.
KWH per
100 LBS.
90/70 70/50
WATER-COOLED
70˚
50˚ 70˚
567
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
529
500
549
519
539
509
481
495
DCM-500BWH 12.0
4.7 12.0
4.1
11.5 269 lbs.
DCM-500BWH Water-Cooled
N/A 110 lbs.
SD-450 N/A
Min. Circuit
Ampacity
20
20
N/A
Hoshizaki
DCM-500B_H
DIMENSIONS
WxDxH
SANITARY CUBELET ICE MACHINE/DISPENSER
ICE WATER
40
46
6
81/8
Dispensing
height
22 26
18
Electrical supply
junction box
Air Flow
Removable
Cleanable air
filter
3/8 FPT
Condenser
water drain
(Water-cooled
units only)
1/2 water
inlet FPT
1/2 FPT
Condenser
water supply
(Water-cooled
units only)
3/4 FPT
bin drain
3/4 FPT
drip tray
drain
For best performance
allow 6” clearance
for air circulation
41/2
141/2
111/4
121/2
13/4 13/4
ICE and WATER
Dispenser nozzles
Pushbutton
operation for
ICE and
WATER
Ice making
switch
OFF/ON
Select Portion
or Continuous
Dispensing
40 lb. Capacity Built-in Bin
Counter Top
Counter Top
Floor Model
with Optional Stand
ICE WATER
ICE WATER
ICE WATER
46
40
26
26
221/2
221/2
261/4
40
22
321/2
721/2
SD-450
261/2
321/2
6”
adj.
legs
261/4
22
CUBELET DIMENSIONS
5/8"
3/4"
1/2"
3/8"
DCM-500B_H
26 x 221/2 x 40
SD-450
261/4 x 22 x 321/2
SD-500
259/10 x22 x 323/4
• Hands-free ice machine/dispenser
• Optional stand
• Optional stand with locking doors
N/A 98 lbs.
SD-500 N/A N/A
12.0
SD-500
323/4
263/4
6" Adj.
Legs
257/8
22
