Foodservice Division: (800) 441-8440
MHC/Retail Display Divisions: (800) 637-5100
FAX: (302) 653-2065 or 653-3036
For custom configuration or fabrication needs,
contact our SpecFAB Division.
Phone: (302) 653-3000. FAX: (302) 653-3091.
E-mail: specfab@eaglegrp.com
EG40.04 Rev.08/04
Spec sheets available for viewing, printing or downloading from our online literature library at www.eaglegrp.com
Foodservice Equipment • Material Handling, Healthcare & Cleanroom Equipment • Retail Display
Stainless steel legs
Stainless steel feet
Lexan®ice cover
Cold plates
Speed rails
catalog sheet
EG40.04
Optional Accessories Model # Qty.
100 Industrial Boulevard • Clayton, DE 19938-8903 USA • (302) 653-3000 • www.eaglegrp.com
Eagle Foodservice Equipment, Eagle MHC, SpecFab, and Retail Display are divisions of Eagle Group. ©2004 by the Eagle Group
Ice Chests
1800 Series
#B2IC-18 ice chest
Item #:
Model #:
Project #:
SIS #:
• Standard models 8˝ (203mm) depth,
newly added 12˝ and 16˝ (305 and
406mm) depth models.
• All models now come standard with
stainless steel sliding covers.
• Stainless steel all-welded construction
with fiberglass insulation for non cold
plate models.
• 7-circuit cold plate with foamed-in-place
insulation available in 24˝ (610mm) and
longer models.
• Ice bins are either fabricated or deep
drawn 304 stainless steel, depending
on size.
• Welded crossbraced legs with adjustable
plastic feet.
• 5˝ (127mm) stainless steel backsplash.
NEW
NEW
Details & Specifications
Foodservice Division: (800) 441-8440 • MHC/Retail Display Division: (800) 637-5100 • Fax: (302) 653-2065 • www.eaglegrp.com
Although every attempt has been made to ensure the accuracy of the information provided, we cannot be held responsible for
typographical or printing errors. Information and specifications are subject to change without notice. Please confirm at time of order.
1800 Series Ice Chests
Design and Construction Features
• Stainless steel type 304 ice bin, backsplash, front,
and ice cover.
• Stainless steel ends, galvanized back panel.
• 11⁄2˝ (38mm) drain centered in ice bin front and back.
• 15⁄8˝ (41mm) diameter heavy gauge crossbraced
galvanized tubular legs with 12 gauge gussets.
• High-impact, corrosion-resistant, fully-adjustable
bullet feet.
• 5˝ (127mm) backsplash.
• Fiberglass insulation for non-cold plate models.
• Ice bins are either deep-drawn one-piece construction
or fabricated depending on depth, with 8˝, 12˝, or 16˝
(203, 305, or 406mm) depths available.
• Cold plates (models 24˝ and longer):
aluminum casting with seven stainless steel beverage
grade tubing circuits. Cold plates are mounted flush
with interior bottom of ice bin for easy cleaning and
maximum efficiency. Drain is 1⁄2˝ (13mm) NPT and
centered in ice bin front and back. 1⁄4˝ (6mm) tube
connections provided.
SIDE VIEW
FRONT VIEW
SIDE VIEW
FRONT VIEW
SIDE VIEW
FRONT VIEW
Models without Cold Plate
TOP VIEW
#B2IC-18 #B36IC-18
TOP VIEW
TOP VIEW
SIDE VIEW
FRONT VIEW
TOP VIEW
#B2IC-18-7 #B36IC-18-7
Models with Cold Plate
ice bin ice
width x length weight depth capacity
in. mm lbs. kg in. mm lbs. kg model #
8˝ 203 25 11.3 B12IC-18
18˝ x 12˝ 457 x 305 23 10.4 12˝ 305 37 16.8 B12IC-12D-18
16˝ 406 49 22.2 B12IC-16D-18
8˝ 203 44 20.0 B18IC-18
18˝ x 18˝ 457 x 457 35 15.9 12˝ 305 65 29.5 B18IC-12D-18
16˝ 406 87 39.5 B18IC-16D-18
8˝ 203 63 28.6 B2IC-18 *
18˝ x 24˝ 457 x 610 50 22.7 12˝ 305 94 42.6 B2IC-12D-18
16˝ 406 125 56.7 B2IC-16D-18
8˝ 203 82 37.2 B30IC-18
18˝ x 30˝ 457 x 762 60 27.2 12˝ 305 123 55.8 B30IC-12D-18
16˝ 406 163 73.9 B30IC-16D-18
* Model #B2IC-18 features deep-drawn seamless design ice bin.
ice bin ice
width x length weight depth capacity
in. mm lbs. kg in. mm lbs. kg model #
8˝ 203 101 45.8 B36IC-18
18˝ x 36˝ 457 x 914 70 31.8 12˝ 305 151 68.5 B36IC-12D-18
16˝ 406 201 91.2 B36IC-16D-18
8˝ 203 120 54.4 B42IC-18
18˝ x 42˝ 457 x 1067 82 37.2 12˝ 305 180 81.6 B42IC-12D-18
16˝ 406 239 108.4 B42IC-16D-18
8˝ 203 139 63.1 B48IC-18
18˝ x 48˝ 457 x 1219 94 42.6 12˝ 305 208 94.3 B48IC-12D-18
16˝ 406 278 126.1 B48IC-16D-18
7-circuit cold plate available for 24˝ (610mm) and longer. Add suffix “-7”
to model number. Example: B21C-18-7
Optional Lexan®ice cover available for “B2” models only. Add suffix “N”
to model number. Example: NB2IC-18
