Ice.Pure and Simple™
11100 E. 45th. Avenue
Denver, CO 80239
Phone: 303. 371. 3737
Fax: 303. 371. 6296
www.iceomatic.com
Domestic Suggested List Price Schedule
Commercial Ice Machines and Accessories
Eective Date: April 1, 2008
Ice-O-Matic
™
®
see page 12 for
our ENERGY STAR
rated machines
2
Problem Feature Solution
Ice-O-Matic Payback
Scaling due to hard water slows
ice making production
Food safety concerns about
slime-and odor-causing bacteria
in the Ice Maker
How long does it take to pay for an ice maker if you’re currently buying ice?
Number of bags purchased per day: . . . . . . . . . . . . . . . . . . . . . . . _____________________bags
Number of bags x cost per bag: . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________________cost per day
365 days x cost per day: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________________cost per year
Cost of the Ice Maker ÷ cost per year = payback period
Harvest Assist
PURE ICE ®
Consistent ice production for
the life of the ice maker, while
reducing operating costs
Built-in antimicrobial protection
for the life of the ice maker
reduces bacteria and slime
fungus growth. Ice-O-Matic’s
optional water filtration system
provides protection against
unpleasant tastes, odors and
scale formation.
Inadequate air flow due to
tight-fitting spaces reduces
ice production
Top Air Discharge Maximum ice production in a
minimum amount of space with
an ultra-low profile
Salt air corrosion of outdoor
equipment located in
coastal regions
Sea Salt Corrosion Protection All cube ice maker remote
condensers are treated with a
salt air corrosion protectant –
FREE
Forget to change the air filter? Filter-Free Air No air filter to change
Evaporator warranty 7 Year Warranty Purchase an Ice-O-Matic water
filter with your new Ice-O-Matic
Cube ice maker, replace the water
filter cartridge every 6 months,
and the evaporator is covered for
7 years – parts and labor (Available
in the USA and Canada only)
Ice-O-Matic
™
®
3
How long does it take to pay for an ice maker if you’re currently buying ice?
Number of bags purchased per day: . . . . . . . . . . . . . . . . . . . . . . . _____________________bags
Number of bags x cost per bag: . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________________cost per day
365 days x cost per day: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________________cost per year
Cost of the Ice Maker ÷ cost per year = payback period
Food Service Approximate ice usage per day
Restaurant 11/2 lbs (.45-.68 kg) per person
Cocktail 3 lbs (1.4 kg) per person / seat
Salad Bar 40 lbs (18 kg) per cubic foot
Quick Service 5 oz. (.14 kg) per 7-10 oz. (207–296 ml) drink
8 oz. (.23 kg) per 12-16 oz. (355-473 ml) drink
1 2 oz. (.34 kg) per 18-24 oz. (532-710 ml) drink
Lodging Approximate ice usage per day
Guest Ice 5 lbs ( 2.3 kg) per room
Restaurant 11/2 lbs (.45-.68 kg) per person
Cocktail 3 lbs (1.4 kg) per person / seat
Catering 1 lbs (.45 kg) per person
Healthcare Approximate ice usage per day
Patient Ice 10 lbs (4.5 kg) per bed
Cafeteria 1 lbs (.45 kg) per person
Convenience Store Approximate ice usage per day
Beverage 6 oz. (.17 kg) per 12 oz. (355 ml) drink
1 0 oz. (.28 kg) per 20 oz. (592 ml) drink
1 6 oz. (.45 kg) per 32 oz. (946 ml) drink
Cold Plate 50% more ice usage per day
Packaged Ice Weight per bag x number of bags sold per day
Sizing Your Ice-O-Matic
Ice Maker
Ice-O-Matic Installation Considerations
✔ Does the existing ice maker meet
peak usage during the hottest
part of the year?
Allow enough space for:
✔The ice maker, bin and water filter
✔ Air flow
Note: If the ice maker is limited on space,
consider a top air discharge unit
Utilities:
✔ What are the voltage characteristics of the
electrical outlet that will be used for this
ice maker?
✔ Is there a floor drain?
✔ Water source with water shut-off?
✔ Are the utilities in close proximity to the
ice maker location?
Remote installation:
✔ Is there an outdoor condenser location above the ice
maker?
✔ Roof access and penetration?
✔ Maximum pre-charged tubing line run considerations?
Note: Ice-O-Matic includes a free sea salt
corrosion protectant on cuber remote
condensers
Ask about:
✔ The 7 year warranty on the evaporator if an
Ice-O-Matic water filter is purchased with
an Ice-O-Matic Cube ice maker and replaced
every 6 months (U.S. & Canada only)
✔ Warranty program
✔ Preventive maintenance programs
✔ Planning for future growth?
If not, consider building in 20%
additional capacity on new
installations.
✔ What are the various locations or
stations in the establishment that
need Ice? Will they all be serviced
from one or multiple ice makers?
Ice-O-Matic
™
®
4
30
20
24
30
24
26
Cube Ice Makers
ICE Series™
Cube Ice Makers
Ice Production ARI Production Approx.
lbs (kg)/24 hr lbs (kg)/24 hr Shipping
Model List @ 70°F Air @ 90°F Air Condensing Voltage Weight
Number Price ($) 50°F Water 70°F Water Unit Characteristics lbs (kg)
30
24
20
30
24
20
30
24
20
22
24
23
22
24
23
30
24
26
All dimensions in inches
ICE0806
ICE0606
ICE0520
ICE0500
ICE0400
ICE0320
ICE0250
ICE1006
ICE0250FA $3595 352 (160) 239 (109) Air 115/60/1 150 (68)
ICE0250FW $3595 351 (160) 284 (129) Water 115/60/1 150 (68)
ICE0250HA $3595 352 (160) 239 (109) Air 115/60/1 150 (68)
ICE0250HW $3595 351 (160) 284 (129) Water 115/60/1 150 (68)
ICE0320FA $3835 320 (145) 214 (97) Air 115/60/1 150 (68)
ICE0320HA $3835 320 (145) 214 (97) Air 115/60/1 150 (68)
ICE0320FW $3835 355 (161) 312 (142) Water 115/60/1 160 (73)
ICE0320HW $3835 355 (161) 312 (142) Water 115/60/1 160 (73)
ICE0400FA´ $4025 506 (230) 366 (166) Air 115/60/1 165 (75)
ICE0400HA´ $4025 506 (230) 366 (166) Air 115/60/1 165 (75)
ICE0400FW $4025 528 (240) 449 (204) Water 115/60/1 165 (75)
ICE0400HW $4025 528 (240) 449 (204) Water 115/60/1 165 (75)
ICE0406FA $4215 468 (213) n/a Air 208-230/60/1 165 (75)
ICE0406HA $4215 468 (213) n/a Air 208-230/60/1 165 (75)
ICE0406FW $4215 464 (211) n/a Water 208-230/60/1 165 (75)
ICE0406HW $4215 464 (211) n/a Water 208-230/60/1 165 (75)
ICE0500FA $4330 625 (284) 461 (209) Air 115/60/1 170 (77)
ICE0500HA $4330 625 (284) 461 (209) Air 115/60/1 170 (77)
ICE0500FW $4330 567 (258) 499 (226) Water 115/60/1 170 (77)
ICE0500HW $4330 567 (258) 499 (226) Water 115/60/1 170 (77)
ICE0500FR $4230 591 (269) 438 (199) Remote 115/60/1 170 (77)
ICE0500HR $4230 591 (269) 438 (199) Remote 115/60/1 170 (77)
ICE0520FA´ $4110 506 (230) 368 (167) Air 115/60/1 165 (75)
ICE0520HA´ $4110 506 (230) 368 (167) Air 115/60/1 165 (75)
ICE0520FW $4110 528 (240) 441 (200) Water 115/60/1 175 (80)
ICE0520HW $4110 528 (240) 441 (200) Water 115/60/1 175 (80)
ICE0606FA $4995 706 (321) 525 (238) Air 208-230/60/1 175 (80)
ICE0606HA $4995 706 (321) 525 (238) Air 208-230/60/1 175 (80)
ICE0606FW $4995 647 (294) 590 (268) Water 208-230/60/1 175 (80)
ICE0606HW $4995 647 (294) 590 (268) Water 208-230/60/1 175 (80)
ICE0606FR´ $4895 727 (330) 544 (247) Remote 208-230/60/1 175 (80)
ICE0606HR´ $4895 727 (330) 544 (247) Remote 208-230/60/1 170 (77)
ICE0806FA $6395 958 (435) 698 (317) Air 208-230/60/1 220 (100)
ICE0806HA $6395 958 (435) 698 (317) Air 208-230/60/1 220 (100)
ICE0806FW $6395 998 (454) 840 (381) Water 208-230/60/1 210 (96)
ICE0806HW $6395 998 (454) 840 (381) Water 208-230/60/1 210 (96)
ICE0806FR $6290 1094 (497) 762 (346) Remote 208-230/60/1 220 (100)
ICE0806HR $6290 1094 (497) 762 (346) Remote 208-230/60/1 220 (100)
ICE1006FA $7270 1109 (504) 811 (368) Air 208-230/60/1 230 (105)
ICE1006HA $7270 1109 (504) 811 (368) Air 208-230/60/1 230 (105)
ICE1006FW $7270 1121 (510) 941 (427) Water 208-230/60/1 225 (102)
ICE1006HW $7270 1121 (510) 941 (427) Water 208-230/60/1 225 (102)
ICE1006FR $7170 1201 (546) 905 (411) Remote 208-230/60/1 235 (107)
ICE1006HR $7170 1201 (546) 905 (411) Remote 208-230/60/1 235 (107)
´ ENERGY STAR qualified machine.
Please see our website www.iceomatic.com for the latest list of ENERGY STAR qualified machines and available rebates
Ice-O-Matic
™
®
5
Cube Ice Makers Top Air Discharge
30
24
20
30
24
20
30
24
20
30
24
20
ICE0500
ICE0400
ICE0250
ICE0606
ICE0250FT $3595 352 (160) 244 (111) Air 115/60/1 150 (68)
ICE0250HT $3595 352 (160) 244 (111) Air 115/60/1 150 (68)
ICE0400FT´ $4025 506 (230) 368 (167) Air 115/60/1 165 (75)
ICE0400HT´ $4025 506 (230) 368 (167) Air 115/60/1 165 (75)
ICE0500FT $4330 625 (284) 455 (207) Air 115/60/1 170 (77)
ICE0500HT $4330 625 (284) 455 (207) Air 115/60/1 170 (77)
ICE0606FT $4995 706 (321) 510 (232) Air 208-230/60/1 175 (80)
ICE0606HT $4995 706 (321) 510 (232) Air 208-230/60/1 175 (80)
24
24
24
48
26
48
24
26
Ice Production ARI Production Approx.
lbs (kg)/24 hr lbs (kg)/24 hr Shipping
Model List @ 70°F Air @ 90°F Air Condensing Voltage Weight
Number Price ($) 50°F Water 70°F Water Unit Characteristics lbs (kg )
ICE1506
ICE2106
ICE1406
ICE1406FA´ $8225 1469 (667) 1136 (516) Air 208-230/60/1 310 (141)
ICE1406HA´ $8225 1469 (667) 1136 (516)) Air 208-230/60/1 310 (141)
ICE1406FW $8225 1386 (630) 1239 (563) Water 208-230/60/1 280 (127)
ICE1406HW $8225 1386 (632) 1239 (563) Water 208-230/60/1 280 (127)
ICE1406FR $8120 1391 (632) 1150 (522) Remote 208-230/60/1 300 (136)
ICE1406HR $8120 1391 (632) 1150 (522) Remote 208-230/60/1 310 (141)
ICE1506FR´ $8265 1432 (650) 1215 (552) Remote 208-230/60/1 300 (136)
ICE1506HR´ $8265 1432 (650) 1216 (552) Remote 208-230/60/1 300 (136)
48
26
ICE1806
ICE1806FW $10270 1731 (787) 1461 (663) Water 208-230/60/1 310 (141)
ICE1806HW $10270 1731 (787) 1461 (663) Water 208-230/60/1 310 (141)
ICE1806FR $10165 1891 (860) 1468 (666) Remote 208-230/60/1 335 (152)
ICE1806HR $10165 1891 (860) 1468 (666) Remote 208-230/60/1 335 (152)
ICE2106FW $13110 2202 (1001) 1855 (842) Water 208-230/60/1 310 (141)
ICE2106HW $13110 2202 (1001) 1855 (842) Water 208-230/60/1 310 (141)
ICE2106FR $13010 2154 (979) 1723 (782) Remote 208-230/60/1 340 (155)
ICE2106HR $13010 2154 (979) 1723 (782) Remote 208-230/60/1 340 (155)
Note: The ICE1506 comes equipped with a Bin Thermostat kit
30
281/2
22
24
24
24
24
24
ICE Series™ Accessories
Three Phase (208-230/60/3) available. Specify ICE1007, ICE1407´, ICE1807 or ICE2107 only $150
Remote condensers and line sets are required for remote-cooled ice makers
See Remote Condensers
´ ENERGY STAR qualified machine.
Please see our website www.iceomatic.com for the latest list of ENERGY STAR qualified machines and available rebates
Ice-O-Matic
™
®
6
➤
➤
➤
➤
➤
➤
➤
➤
�
�
�
�
�
�
24
24
39
Cube Ice Makers with Built-In Storage Bin
21 18
34
ICEU150
ICEU060
Ice Production ARI Production ARI Approx.
lbs (kg)/24 hr lbs (kg)/24 hr Bin Shipping
Model List @ 70°F Air @ 90°F Air Storage Condensing Voltage Weight
Number Price ($) 50°F Water 70°F Water lbs (kg) Unit Characteristics lbs (kg)
ICEU150FA´ $3310 171 (78) 117 (53) 74 (34) Air 115/60/1 160 (73)
ICEU150HA´ $3310 171 (78) 117 (53) 74 (34) Air 115/60/1 160 (73)
ICEU150FW $3310 175 (80) 139 (63) 74 (34) Water 115/60/1 160 (73)
ICEU150HW $3310 175 (80) 139 (63) 74 (34) Water 115/60/1 160 (73)
�
�
�
�
�
�
24
24
39
ICEU220
ICEU220FA´ $3575 238 (108) 175 (80) 74 (34) Air 115/60/1 160 (73)
ICEU220HA´ $3575 238 (108) 175 (80) 74 (34) Air 115/60/1 160 (73)
ICEU220FW $3575 260 (118) 205 (93) 74 (34) Water 115/60/1 160 (73)
ICEU220HW $3575 260 (118) 205 (93) 74 (34) Water 115/60/1 160 (73)
ICEU226FA $3815 241 (110) 168 (76) 74 (34) Air 208-230/60/1 160 (73)
ICEU226HA $3815 241 (110) 168 (76) 74 (34) Air 208-230/60/1 160 (73)
ICEU226FW $3815 232 (105) 192 (87) 74 (34) Water 208-230/60/1 160 (73)
ICEU226HW $3815 232 (105) 192 (87) 74 (34) Water 208-230/60/1 160 (73)
30
29
39
ICEU300
ICEU300FA´ $4185 309 (140) 228 (104) 112 (51) Air 115/60/1 206 (94)
ICEU300HA´ $4185 309 (140)) 228 (104) 112 (51) Air 115/60/1 206 (94)
ICEU300FW $4185 356 (162) 296 (135) 112 (51) Water 115/60/1 203 (92)
ICEU300HW $4185 356 (162) 296 (135) 112 (51) Water 115/60/1 203 (92)
**KCDSICE3020 Stacking Kit for models ICE0250 - ICE0606**
**KCDSICE3026 Stacking Kit for models ICE0806 - ICE1006**
**KCDS48ICE Stacking Kit for models ICE1406 - ICE2106**
KSF Prison Kit applicable for all Ice-O-Matic
**Stacking Kits and pricing available through IOM Parts Catalog
**For use with water- and remote-cooled units only
ICE Series™ stacking kits work with both 60- and 50-cycle ICE Series™ Cube Ice Makers
Stacking kits are not available for 22" ICE Series™ Cube Ice Makers
ICE Series™ Cube Ice Maker Stacking Kits
ICEU060A $2710 69 (31) 54 (25) 25 (11) Air 115/60/1 102 (46)
ICEU070 ICEU070A $2950 84 (38) 67 (30) 27 (11) Air 115/60/1 105 (48)
Available
May 15, 2008
Discontinued
May 15, 2008
34
15
23
´ ENERGY STAR qualified machine.
Please see our website www.iceomatic.com for the latest list of ENERGY STAR qualified machines and available rebates
Ice-O-Matic
™
®
7
Model Number Description
List
Price ($)
Approx. Shipping
Weight lbs (kg)
KBT19 Bin kit for 22” ICE and GEM Series on a 30” machine $275 22 (10)
KBT22 Bin Kit for (2) GEM0650 or (2) GEM0956 on a 48” Bin $415 33 (15)
KBT23 Bin Kit for GEM0650, GEM0950, and GEM1256 on 48” Bin $415 33 (15)
KBT24 Bin Kit for (1) GEM0650 or GEM0956 on a 22” Bin $110 10 (5)
KBT26 Bin Kit for (1) GEM1856 on a 48” Bin $215 8 (4)
KBT15022 Adapter and bin level kit for 22" cubers and nugget ice makers on IOD150 $400 12 (5)
KBT25030 Adapter and bin level kit for 30" cubers and nugget ice makers on IOD200, 250 $400 13 (5)
KBT25022 Adapter and bin level kit for 22" cubers and nugget ice makers on IOD200, 250 $400 28 (13)
KGEMDIV Field installed Gem ice diverter kit for all IOD (ED and DF) dispensers $95 1 (.5)
KGEMBIOD GEM Ice-level kit for all IOD dispensers with GEM ice maker $120 2 (1)
KGEM200 Kit, Ice Slide, Ice Level Control & KGEMDIV for Cornelius ED or DF 200 $365 5 (3)
KGEM250 Kit, Ice Slide, Ice Level Control & KGEMDIV for Cornelius ED or DF 250 $365 5 (3)
Pearl Ice™
Nugget Ice Makers
Ice Production Ice Production Approx.
lbs (kg)/24 hr lbs (kg)/24 hr Dimensions Shipping
Model List @ 70°F Air @ 90°F Air WxDxH Voltage Weight
Number Price ($) 50°F Water 70°F Water in. Characteristics lbs (kg)
GEM0650
GEM650A $6725 700 (318) 520 (236) 21 x 24 x 27 115/60/1 205 (93)
GEM650W $6725 745 (338) 605 (274) 21 x 24 x 27 115/60/1 200 (91)
GEM650R $6950 615 (279) 560 (254) 21 x 24 x 27 115/60/1 220 (100)
GEM956A $8515 1080 (490) 780 (354) 21 x 24 x 27 208-230/60/1 215 (98)
GEM956W $8515 1100 (499) 925 (420) 21 x 24 x 27 208-230/60/1 215 (98)
GEM956R $8830 920 (417) 830 (376) 21 x 24 x 27 208-230/60/1 215 (98)
GEM0956
Pearl Ice™ Makers Modular
GEM1256A $11605 1220 (553) 945 (429) 30 x 24 x 27 208-230/60/1 285 (129)
GEM1256W $11605 1345 (610) 1110 (503) 30 x 24 x 27 208-230/60/1 285 (129)
GEM1256R $11500 1110 (503) 1005 (456) 30 x 24 x 27 208-230/60/1 285 (129)
GEM1256
Dispenser Model GEM0650 GEM0956 GEM1256 GEM1856
Ice-O-Matic IOD150 KBT15022 + KGEMDIV KBT15022 + KGEMDIV N/A N/A
Ice-O-Matic IOD200 or IOD250
KBT25022 + KGEMDIV +
KGEBIOD
KBT25022 + KGEMDIV +
KGEMBIOD
KBT25030 + KGEMDIV +
KGEMBIOD N/A
Cornelius ED or DF150
KBT15022 + R629088514
(Cornelius)
KBT15022 + R629088514
(Cornelius) N/A N/A
Cornelius ED or DF200 KBT25022 + KGEM200 KBT25022 + KGEM200 KBT25030 + KGEM200 N/A
Cornelius ED or DF250 KBT25022 + KGEM250 KBT25022 + KGEM250 KBT25030 + KGEM250 N/A
Pearl Ice™ Makers - Dispenser Application Chart
Pearl Ice™ Makers Accessories
D
C
B
A
A
B
C
D
SCALE: 1:12
SW DRAWING FILE: iso doc .SLDDRW
PART NO.
Sheet1 of
UNLESS OTHERWISE
SPECIFIED DIMENSIONS
ARE IN INCHES
MATERIAL:
FINISH:
DO NOT SCALE DRAWING
23
456
7
8
876543 2
THIS DRAWING MAY NOT
BE REPRODUCED OR USED
WITHOUT WRITTEN CONSENT
FROM MILE HIGH
EQUIPMENT COMPANY.
1011380
1011380
ICE-O-MATIC
®
ENODIS
TOLERANCES ARE:
.XX ± 0.015
.XXX ± 0.010
FRACTIONS ± 1/32
ANGLES ± 1/2 °
HOLES ± 0.005
TITLE / DESCRIPTION
MATERIAL P/N: MT:
BR:
BALLOON LEGEND
4
7
M:
D:
ITEM NUMBER
QUANTITY CTL:
27
21
24
D
C
B
A
A
B
C
D
SCALE: 1:12
SW DRAWING FILE: iso doc .SLDDRW
PART NO.
Sheet1 of
UNLESS OTHERWISE
SPECIFIED DIMENSIONS
ARE IN INCHES
MATERIAL:
FINISH:
DO NOT SCALE DRAWING
23
456
7
8
876543 2
THIS DRAWING MAY NOT
BE REPRODUCED OR USED
WITHOUT WRITTEN CONSENT
FROM MILE HIGH
EQUIPMENT COMPANY.
1011380
1011380
ICE-O-MATIC
®
ENODIS
TOLERANCES ARE:
.XX ± 0.015
.XXX ± 0.010
FRACTIONS ± 1/32
ANGLES ± 1/2 °
HOLES ± 0.005
TITLE / DESCRIPTION
MATERIAL P/N: MT:
BR:
BALLOON LEGEND
4
7
M:
D:
ITEM NUMBER
QUANTITY CTL:
27
21
24
D
C
B
A
A
B
C
D
SCALE: 1:12
SW DRAWING FILE: iso doc .SLDDRW
PART NO.
Sheet1 of
UNLESS OTHERWISE
SPECIFIED DIMENSIONS
ARE IN INCHES
MATERIAL:
FINISH:
DO NOT SCALE DRAWING
23
456
7
8
876543 2
THIS DRAWING MAY NOT
BE REPRODUCED OR USED
WITHOUT WRITTEN CONSENT
FROM MILE HIGH
EQUIPMENT COMPANY.
1011380
1011380
ICE-O-MATIC
®
ENODIS
TOLERANCES ARE:
.XX ± 0.015
.XXX ± 0.010
FRACTIONS ± 1/32
ANGLES ± 1/2 °
HOLES ± 0.005
TITLE / DESCRIPTION
MATERIAL P/N: MT:
BR:
BALLOON LEGEND
4
7
M:
D:
ITEM NUMBER
QUANTITY CTL:
27
30
24
Ice-O-Matic
™
®
GEM1856A $16080 2130 (968) 945 (429) 42 x 24 x 27 208-230/60/1 425 (193)
GEM1856
Available late
April, 2008
27
24 42
8
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
Flake Ice Makers Modular
W
D
H
W
D
H
16
231/2
32
16
231/2
32
16
231/2
32
Flake Ice Makers
Flake Ice Maker Chassis Only
26
48
231/2
EMF800
EMF1106
EMF2306
EMF450
Flake Ice Makers with Built-In Storage Bin
W
D
H
Ice Production Approx.
lbs (kg)/24 hr Bin Dimensions Shipping
Model List @ 70°F Air Storage WxDxH Voltage Weight
Number Price ($) 50°F Water lbs (kg) in. Characteristics lbs (kg)
EF250
EF450
EF800
Note: All condensing units are AIR cooled.
EF250A32S $6030 400 (182) 143 (65) 32 x 28 x 41 115/60/1 250 (114)
EF250A38S $6465 400 (182) 213 (97) 38 x 28 x 41 115/60/1 265 (120)
EF450A32S $6200 472 (214) 143 (65) 32 x 28 x 41 115/60/1 250 (114)
EF450A38S $6700 472 (214) 213 (97) 38” x 28” x 41 115/60/1 265 (120)
EF450A48S $7335 472 (214) 315 (143) 48 x 28 x 41 115/60/1 295 (134)
EF800A38S $7870 772 (351) 213 (97) 38 x 28 x 41 115/60/1 290 (132)
EF800A48S $8675 772 (351) 315 (143) 48 x 28 x 41 115/60/1 325 (148)
Ice Production Approx.
lbs (kg)/24 hr Shipping
Model List @ 70°F Air Condensing Voltage Weight
Number Price ($) 50°F Water Unit Characteristics lbs (kg)
EMF450AS $5100 488 (222) Air 115/60/1 175 (79)
EMF450WS $5100 552 (251) Water 115/60/1 175 (79)
EMF800AS $6470 780 (354) Air 115/60/1 195 (89)
EMF800WS $6470 852 (387) Water 115/60/1 195 (89)
EMF1106AS $8165 1092 (496) Air 208-230/60/1 225 (102)
EMF1106WS $8165 1140 (518) Water 208-230/60/1 225 (102)
EMF1106RS $8050 1152 (524) Remote 208-230/60/1 225 (102)
EMF2306AS $16410 2252 (1022) Air 208-230/60/1 370 (168)
EMF2306WS $16410 2624 (1193) Water 208-230/60/1 370 (168)
EMF2306RS $16300 2376 (1079) Remote 208-230/60/1 370 (168)
Ice Production Approx.
Lbs (Kgs)/24 hr Shipping
Model List @ 70°F Air Condensing Voltage Weight
lbs (kg)
EF450A $5680 472 (214) Air 115/60/1 160 (73)
EF800A $6600 772 (350) Air 115/60/1 160 (73)
Ice-O-Matic
™
®
9
W
D
H
Remote Condensers
Approx.
Dimensions Shipping
Model List WxDxH Voltage Weight
Number Price ($) Description in. Characteristics
lbs (kg)
VRC1001B $1315 Remote Condenser for ICE0500 29½ x 293⁄16 x 39 115/60/1 122 (55)
VRC1061B $1315 Remote Condenser for ICE0606, EMF1106, 29½ x 293⁄16 x 39 208-230/50-60/1 124 (56)
ICE0605
VRC2061B $1315 Remote Condenser for ICE0806, 29½ x 293⁄16 x 39 208-230/50-60/1 124 (56)
ICE0805, ICE1006, ICE1005, EMF2306
VRC2661B $1330 Remote Condenser for 1405, 1406, 1407, 1506 29½ x 293⁄16 x 39 208-230/50-60/1 126 (57)
VRC5061B $1900 Remote Condenser for 1806, 1807, 2106,2107 29½ x 293⁄16 x 39 208-230/50-60/1 145 (66)
For Nugget Ice Makers
Model
Number
List
Price($) Description
Dimensions
WxDxH
in.
Voltage
Characteristics
Approx.
Shipping
Weight
lbs (kg)
GRC1001 $1090 Remote Condenser for GEM0650 45 x 221/8 x 291/2115/60/1 95 (43)
GRC1061 $1310 Remote Condenser for GEM0956 45 x 221/8 x 291/2208-230/60/1 95 (43)
GRC2061 $1310 Remote Condenser for GEM1256 45 x 221/8 x 291/2208-230/60/1 95 (43)
For Cube and Flake Ice Makers
Approx.
Shipping
Model List Weight
Number Price ($) Description lbs (kg)
RT325 404 $305 25 ft. (7.6m) Precharged Tubing Kit for units using R-404A refrigerant 13 (6)
RT340 404 $390 40 ft. (12.2m) Precharged Tubing Kit for units using R-404A refrigerant 18 (8)
RT345 404 $400 45 ft. (13.7m) Precharged Tubing Kit for units using R-404A refrigerant 19 (9)
RT360 404 $470 60 ft. (18.2m) Precharged Tubing Kit for units using R-404A refrigerant 26 (12)
RT375 404 $590 75 ft. (23.0m) Precharged Tubing Kit for units using R-404A refrigerant 33 (15)
Precharged Tubing Kits
17.3”
(440 mm)
Adjustable
12 “ (305 mm)
18” (457 mm)
24” (610 mm)
33.4” (847 mm)
23.8” (605 mm)
H
DW
Ice-O-Matic
™
®
10
Storage Bins
Model Number Description
List
Price ($)
Approx. Shipping
Weight lbs (kg)
KBT5 Bin Kit for (1) 30” ICE Series™ Cuber on a 48” Bin $380 30 (14)
KBT7 Bin Kit for (1) 16” Flaker on a 48” Bin $380 32(15)
KBT8 Bin Kit for (1) 16” Flaker on a 30” Bin $370 20(9)
KBT9 Bin Kit for (2) Flakers on a 48” Bin $440 31 (14)
KBT14 Bin Kit for (1) 16” Flaker on a 22” Bin $240 15 (7)
KBT19 Bin kit for 22” ICE and GEM Series on a 30” machine $275 22 (10)
KBT22 Bin Kit for (2) GEM0650, GEM0956 or (2) GEM0650 GEM0956 on a 48” Bin $415 33 (15)
KBT23 Bin Kit for GEM0650, GEM0950, and GEM1256 on 48” Bin $415 33 (15)
KBT24 Bin Kit for (1) GEM0650 or GEM0956 on a 22” Bin $110 10 (5)
KBT26 Bin Kit for (1) GEM1856 on a 48” Bin $215 8 (4)
KBT41 Bin Kit for (1) 16” Flaker on 48” Bin $830 30 (14)
KBT42 Bin Kit for (2) 16” Flaker on 48” Bin $830 30 (14)
KBT61 Bin Kit for (1) 16” Flaker on 60” Bin $830 30 (14)
KBT62 Bin Kit for (2) 16” Flaker on 60” Bin $830 30 (14)
For combining wider bins with smaller models
Bin Tops
24
24
34
CRT125
B25PP $1140 255 (116) 190 (86) 30 x 31 x 28 90 (41)
B40PS $1385 365 (166) 270 (123) 30 x 31 x 371/2 135 (61)
B42PS $1460 374 (170) 275 (125) 22 x 31 x 50 135 (61)
B55PS $1615 556 (253) 400 (182) 30 x 31 x 50 155 (70)
B100PS $2230 927 (421) 670 (304) 48 x 31 x 50 230 (105)
B120SP† $4430 1193 (542) 896 (406) 48 x 34 x 54 300 (136)
B120SS† $5455 1193 (542) 896 (406) 48 x 34 x 54 300 (136)
B150SP† $5095 1499 (681) 1135 (516) 60 x 34 x 54 325 (148)
B150SS† $6275 1499 (681) 1135 (516) 60 x 34 x 54 325 (148)
B170SP† $5465 1866 (848) 1417 (644) 60 x 34 x 66 355 (161)
B170SS† $6600 1866 (848) 1417 (644) 60 x 34 x 66 355 (161)
CRT125 $1110 94 (43) 74 (34) 24 x 24 x 34 90 (41)
�
�
�
�
�
�
W
D
H
BINS
†Bin Top is included free of charge for each Flake or Cube Ice Maker if B120, 150 or 170 bin, Bin Top and ice maker accompaning the bin are ordered together and on the same order.
An order that does not indicate a specic ice maker for each B120, 150 or 170 bin, and orders that consist of individual Bin Tops, are subject to List Pricing.
Note: KBT41, 42, 61 and 62 Bin Tops are available at no extra charge if included on a B120, B150 or B170 Order.
Insulated ice storage
Application ARI Bin Approx.
Bin Bin Dimensions Shipping
Model List Storage Storage WxDxH* Weight
Number Price ($) lbs (kg) lbs (kg) in. lbs (kg)
Ice-O-Matic
™
®
11
Application ARI Bin Approx.
Bin Bin Dimensions Shipping
Model List Storage Storage WxDxH* Weight
Number Price ($) lbs (kg) lbs (kg) in. lbs (kg)
Ice Dispensers
301/4
Cup Clearance 101/16
395/8
3011/16
IOD250
301/4
3011/16
Cup Clearance 101/16
355/8
IOD200
For Cube and Nugget Ice
221/4
3011/16
Cup Clearance 101/16
355/8
IOD150
Approx.
Dimensions ARI Shipping
Model List Dispenser WxDxH Bin Storage Voltage Weight
Number Price ($) Operated by in. lbs (kg) Characteristics lbs (kg)
IOD150 $3975 Cup Activated 221/4 x 3011/16 x 355/8 150 (68) 115/60/1 139 (63)
IOD200 $4760 Cup Activated 301/4 x 3011/16 x 355/8 200 (91) 115/60/1 190 (86)
IOD250 $5715 Cup Activated 301/4 x 3011/16 x 355/8 250 (100) 115/60/1 195 (89)
Accessories: Ice Dispensers
Model Number Description
List
Price ($)
Approx. Shipping
Weight lbs (kg)
KBT15022 Adapter and bin level kit for 22" cubers and nugget ice makers on IOD150 $400 12 (5)
KBT25030 Adapter and bin level kit for 30" cubers and nugget ice makers on IOD200, 250 $400 13 (5)
KBT25022 Adapter and bin level kit for 22" cubers and nugget ice makers on IOD200, 250$400 28 (13)
KGEMDIV Field installed Gem ice diverter kit for all IOD (ED and DF) dispensers $95 1 (.5)
KGEMBIOD GEM Ice-level kit for all IOD dispensers with GEM ice maker $120 2 (1)
KWGFID Water glass filler kit for IOD150, 200, 250 $275 2 (1)
Ice-O-Matic
™
®
12
Accessories: Hotel Dispensers
TKNS $185 500 tokens for use with CD40230 7 (3)
Model CD40030, 40130, 40230 Dispensers accept all 30” Ice Series™ Cube Ice Makers (excluding the ICE1506)
Model CD40022 Dispensers accept all 22” Ice Series™ Cube Ice Makers
Note #1: CD40022 and CD40030 Series units do not require an Adapter and Bin Level Kit
Note #2: Water dispensers and coin / token mechanisms cannot be field installed on the CD40130
or CD40230 Series Dispensers
Note #3: CD40130 and CD40230 Series Dispensers cannot have a water dispenser and coin / token
mechanism on the same machine
Note #4: The CD40230 accepts 1 US Quarter or token only. Multiple coin / token mechanism can be
special-ordered and field-installed at additional cost. Contact Ice-O-Matic for more details.
331/2
531/4
30
CD40030
22
331/2
Approx.
Dimensions Shipping
Model List Dispenser WxDxH Bin Storage Voltage Weight
Number Price ($) Operated by in. Lbs (Kgs) Characteristics lbs (kg)
531/4
CD40022
Cube Ice Dispensers
CD40022 $4240 Push 22 x 331/2 x 531/4 120 (55) 115/60/1 200 (91)
CD40030 $4980 Push 30 x 331/2 x 531/4 180 (81) 115/60/1 230 (105)
CD40130 $5490 Push / Water 30 x 331/2 x 531/4 180 (81) 115/60/1 230 (105)
CD40230 $5565 Coin / Token 30 x 331/2 x 531/4 180 (81) 115/60/1 230 (105)
Hotel Ice Dispensers
No. Model Name Harvest Rate Energy Use Water Use
1 ICEU150HA 112 11.8 34
2 ICEU150FA 112 11.8 34
3 ICEU220HA 175 8.80 30.3
4 ICEU220FA 175 8.80 30.3
5 ICEU300HA 228 8.60 32.9
6 ICEU300FA 228 8.60 32.9
7 ICE0400HA 368 6.10 24.4
8 ICE0400FA 368 6.10 24.4
9 ICE0400HT 357 6.30 25
10 ICE0400FT 357 6.30 25
11 ICE0520HA 370 5.90 23.1
12 ICE0520FA 370 5.90 23.1
13 ICE0606HR with condensing unit VRC1061 502 6.28 24.9
14 ICE0606FR with condensing unit VRC1061 502 6.28 24.9
19 ICE1406HA 1136 5.06 19.9
20 ICE1406FA 1136 5.06 19.9
21 ICE1407HA 1131 5.04 19.6
22 ICE1407FA 1131 5.04 19.6
23 ICE1506HR with condensing unit VRC2661 1216 4.63 19.1
24 ICE1506FR with condensing unit VRC2661 1216 4.63 19.1
ENERGY STAR Rated Ice Makers
Please see our website www.iceomatic.com
for the latest list of ENERGY STAR qualified
machines and available rebates
Ice-O-Matic
™
®
13
Filter System Sizing Chart
Ice-O-Matic Cube Ice Maker Ice-O-Matic Flake Ice Maker Ice-O-Matic Pearl Ice Maker Recommended Ice-O-Matic Water Filter
ICEU060, 150, 220, 225, 226, 300, 305 EMF450, EF250, EF450, EMF2306, IFQ1 (Single Manifold cartridge Filter System)
ICE0250, 0305, 0320, 0325, 0400, 0405, IFI4C or IFI8C (Single inline Filter System)
ICE0406, 0500, 0520, 0525, 0605, 0606,
ICE0605, 0606, 0806 EMF800, EF800, MFI0800, 0805, GEM0650, 0655, 0956 IFQ1 (Single Manifold cartridge Filter System)
ICE 1005, 1006, 1405, 1406,1506, EMF1106, EMF2306, MFI1256, 1255 GEM1256, GEM1856 IFQ2 (Dual Manifold cartridge Filter System)
ICE 1806, 2106
Water Filtration Systems
IFQ Filtration Systems - See Sizing Chart Below
11 H" x 2.25 W"
IFI SERIES
IFI Inline Filter - See Sizing Chart Below
Flow Approx.
Rate Pressure Max. Shipping
Model List Max. Max. Operating Micron Weight
Number Price ($) Description gpm psi Temp °F (° C) Rating lbs (kg)
IFI8C $105 Single Inline Cartridge 1.0 100 100 (38) 10 2 (.9)
3/8" Compression
IFI4C $105 Single Inline Cartridge 1.0 100 100 (38) 10 2 (.9)
1/4" Compression
IOM Replacement Cartridges
IFQ1
15"H x 6"W
x 4"D IFQ1 $295 Single filter 1.5 125 100 (38) 1 4 (1.8)
Flow Approx.
Rate Pressure Max. Shipping
Model List Max. Max. Operating Micron Weight
Number Price ($) Description gpm psi Temp °F (° C) Rating lbs (kg)
IFQ2 $715 Dual filter 3.0 125 100 (38) 1 8 (4)
Optional water pressure gauges included with IFQ1 and IFQ2 ltration Systems
IFQ2
16"H x 10"W
x 6"D
Optional water pressure gauges included with IFQ1 and IFQ2 ltration Systems
IOMQ $105 Single quick-twist replacement cartridge for IFQ1 or IFQ2
IOMWFRC $105 Single replacement filter with male quick connect fittings for IF1, IF2, IF3, IF4
Filter Cartridge Features:
• Inhibit the formation of scale
• Remove dirt and sediment
• Reduce chlorine and taste & odor
Ice-O-Matic recommends the use of water filtration with all Ice Making products.
Ice-O-Matic
™
®
14
Bin Chart
* MFI Flakers are available internationally only.
** KBT41, 42, 61 and 62 Bin Tops are available at no extra charge if included on a B120, B150 or B170 order.
Note: 30” wide cubers combined with a B120, B150 or B170 must be ordered with 2 Filler Kits.
Ice Makers
50Hz 60Hz Model No.
Capacity
Width
B25
255 lbs
(116 kg)
30 in.
B40
365 lbs
(166 kg)
30 in.
B42
374 lbs
(170 kg)
22 in.
B55
556 lbs
(252 kg)
30 in.
B100
927 lbs
(420 kg)
48 in.
B120
1193 lbs
(541 kg)
48 in.
B150
1499 lbs
(680 kg)
60 in.
B170
1866 lbs
(846 kg)
60 in.
<EMF450 KBT 8 KBT 8 KBT 14 KBT 8 KBT 7 KBT 41** KBT 61** KBT 61**
<EMF450 (2) N/A N/A N/A N/A KBT 9 KBT 42** KBT 62** KBT 62**
<EMF800 KBT 8 KBT 8 KBT 14 KBT 8 KBT 7 KBT 41** KBT 61** KBT 61**
<EMF800 (2) N/A N/A N/A N/A KBT 9 KBT 42** KBT 62** KBT 62**
<EMF1106 KBT 8 KBT 8 KBT 14 KBT 8 KBT 7 KBT 41** KBT 61** KBT 61**
<EMF1106 (2) N/A N/A N/A N/A KBT 9 KBT 42** KBT 62** KBT 62**
<EMF2306 N/A N/A N/A N/A Kit not required Kit not required Kit not required Kit not required
<GEM0650 KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
<GEM0650 (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
=GEM0655 KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
=GEM0655 (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
<GEM0956 KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
<GEM0956 (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
<GEM1256 Kit not required Kit not required N/A Kit not required KBT23 N/A N/A N/A
<GEM1856 N/A N/A N/A N/A KBT26 KBT26 N/A N/A
<ICE0250 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Kit not required Kit not required
=ICE0305 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Kit not required Kit not required
<ICE0320 KBT 19 KBT 19 Kit not required KBT 19 N/A N/A N/A N/A
=ICE0325 KBT 19 KBT 19 Kit not required KBT 19 N/A N/A N/A N/A
<ICE0400 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
=ICE0405 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
<ICE0406 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
<ICE0500 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
<ICE0520 KBT 19 KBT 19 Kit not required KBT 19 N/A N/A N/A N/A
=ICE0525 KBT 19 KBT 19 Kit not required KBT 19 N/A N/A N/A N/A
=ICE0605 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
<ICE0606 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
=ICE0805 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
<ICE0806 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
=ICE1005 Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
<ICE1006* Kit not required Kit not required N/A Kit not required KBT 5 Filler Kit Required Filler Kit Required Filler Kit Required
=ICE1405 N/A N/A N/A N/A Kit not required Kit not required Kit not required Kit not required
<ICE1406* N/A N/A N/A N/A Kit not required Kit not required Kit not required Kit not required
<ICE1506 N/A N/A N/A Kit not required N/A N/A N/A N/A
<ICE1806* N/A N/A N/A N/A Kit not required Kit not required Kit not required Kit not required
<ICE2106* N/A N/A N/A N/A Kit not required Kit not required Kit not required Kit not required
<MFI0500 * KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
<MFI0500 * (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
<MFI0800 * KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
<MFI0800 * (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
=MFI0805 * KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
=MFI0805 * (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
=MFI1255 * KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
=MFI1255 * (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
<MFI1256 * KBT19 KBT19 KBT24 KBT19 KBT23 KBT23 N/A N/A
<MFI1256 * (2) N/A N/A N/A N/A KBT22 KBT22 N/A N/A
Kits for combining wider bins with smaller models
Ice-O-Matic
™
®
15
Cube Ice Makers - ICE Series
• Three years Parts and Labor.
• Five years Parts coverage on the evaporator and
compressor.
• Seven years Parts and Labor on the evaporator when you
purchase an Ice-O-Matic water filter with your cube ice
maker and replace the filter every six months (available in
the U.S. and Canada only)
Flake Ice Makers - Model numbers EF and EMF
• Two years Parts and Labor.
Pearl Ice Makers - Models GEM
• Three years Parts and Labor.
• Five years Parts coverage on the compressor.
Every Ice-O-Matic Ice Maker is backed by a warranty that provides both parts and labor coverage.
• Buy a new Ice-O-Matic IFQ Series Water Filtration System with a new ICE Series™ Cube Ice Maker, replace the filter
cartridge every 6 months, and Ice-O-Matic will extend the limited cuber evaporator warranty to 7 years parts and labor.
• New ice maker and filter must be installed at the same time.
• Must send in both the ice maker and water filter registration cards within 10 days of installation. Registration card must include
the filter serial number(s).
• Must send in additional registration card for each new replacement cartridge installed (replacement cartridges have
individual serial numbers). This must be done every 180 days (6 months) or less.
• Program is available with all IFQ1, IFQ2, IFI4, and IFI8 filter systems.
• Replacement cartridge must be an Ice-O-Matic replacement cartridge IOMQ or IOMWFRC
(See sizing chart for cartridge requirements).
• Available in the USA and Canada only.
• All prices Ex-Factory Denver, Colorado.
• Terms: Cash With Order or Sight Draft Bill of Lading unless credit is approved by our Credit Department.
• This price list is effective April 1, 2008 and supersedes all previous price schedules.
• Specifications and prices are subject to change without notice.
• Production capacities are based on tests conducted in Denver, CO and are dependent on water quality and
condition of the unit.
• All height dimensions of bins and ice makers with built-in storage include the height of the legs where applicable.
• Domestic distributors who sell any 50-cycle machines must pay a 6% up-charge
Water Filtration System Extended Warranty Program
Ice Maker Warranty
Terms and Conditions
General Information
*Please see warranty statement for details
Model IOD has a 2 year parts warranty and a 1 year labor warranty
CD Series Hotel Dispensers have a 3 years parts and labor warranty
Ice-O-Matic
™
®
Model Numbering System
Electrical characteristics of all units are coded in the Model Number by a one digit number appearing after the basic family size. See code below.
No. of Service Required
Code Number *Volts **Cycles Phase (Including Ground)
0 115 60 1 3
5 230 50 1 3
6 208-230 60 1 3
7 208-230 60 3 4
*Two voltage values separated by a hyphen (-) means that the unit is capable of operating over this voltage range.
IFI • 4 • C
Water Filtration Systems
Fitting Type: C = Compression
Fitting Size: 4 = 1/4", 8 = 3/8"
Filter Type: IFI = Ice-O-Matic Filter, INLINE TYPE
IFQ • 1
Number of Cartridges: 1 = Single, 2 = Dual
Filter Type: IFQ = Ice-O-Matic Filtration System, IFQ
Series
The Model Number fully describes the unit. A letter code identifies the model series. A two or three digit number identifies the basic family size and
electrical characteristics. A second letter code identifies the type of condenser. Cabinet size is identified by a two digit number. Finish is identified by a
letter code.
The following examples illustrate how Model Numbers are developed:
EF • 80 0 A • 38 • S
Flake Ice Makers
Cabinet Finish: S = Stainless Steel
Cabinet Size: 32, 38 or 48
Condenser A = Air
Type: W = Water
R = Remote
Unit electrical characteristics: 0, 5, 6, ...
(see electrical table below)
Basic Family Size: (e.g.) 25, 45, 80, etc.
Model:
EF = Self-Contained Flake Ice Maker
EMF = Modular Flake Ice Maker
ICE • 060 6 F • A • 1 • XX Specific Designation
Design Revision Level
Condenser A = Air
Type: W = Water
R = Remote
T = Air/Top Air Discharge
Cube Size: F = Full Cube
H = Half Cube
Unit electrical characteristics: 0, 5, 6, 7
(see electrical table below)
Basic Family Size: 025, 040, 050, 060, etc.
Model ICE = Modular Cuber Model Series
ICEU = Undercounter Cuber
ERC • 26 6 • 1
Indicates Single Circuit Condenser
Unit Electrical Characteristics: 0 or 6
Size: Condenser Family Size.
Model: Remote Condenser
Cube Ice Makers
Remote Condensers
Part No: 2060 Rev: J-3-08
©2008 Ice-O-Matic
CD
IOD • 1 5 0
Dispensers
Model: CD = Corridor Hotel Dispenser
IOD = Ice Only Countertop Dispenser
Rated Storage Capacity
Other model nomenclature same as Flake or Cube Ice Maker nomenclature
GEM • 095 • 6 • A
Pearl ICE™ Makers
Modular Pearl Ice
Ice production Approximately 950 lbs.
B • 55 • PS
PS/SP/S = Stainless Steel/Galvanized
Exterior
SS = All Stainless Steel Exterior
PP = Plastic Exterior
Approx. Size: 55= 550 lbs. capacity
Model B = Bin
Bins
Voltage — Coded the same as other
IOM equpment. 6=208-230/60/1
Pearl Ice available in 115v and 208-230
A=Air Cooled W=Water Cooled
R=Remote Condenser
Ice-O-Matic
™
®
