KM-1300SAH-E
Air-Cooled
KM1300SAH-E 04/04
Item # 13055
STACKABLE CRESCENT CUBER
Up to 649 kgs. of ice production per 24
hours
Stackable for 1298 kgs. per 24 hour Ice
Production in the same floor space.
CycleSaver®design
Individual crescent cube
Stainless steel evaporator
Removable air filters
Reliability is a
beautiful thing™
EverCheck®alert system
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL 770-487-2331 FAX 770-487-1325 www.hoshizaki.com
KM-1300SAH-E Cuber
Shown on Optional
B-900 Bin
Durable stainless steel exterior
B-900
B-800
ICEMAKER
DIMENSION
Width x Depth x Height
KM-1300S_H-E
122 x 69.5 x 69.5cm
DIMENSION
BY BIN SIZE
Width x Depth x Height
B-800
122 x 80 x 186.7cm
B-900
132 x 80 x 186.7cm
B-800
(2 stacked)
122 x 80 x 256.5cm
B-900
(2 stacked)
132 x 80 x 256.5cm
B-900
B-800
KM-1300SAH-E SERIES
Hoshizaki
Series
STACKABLE CRESCENT CUBER
SERVICE
Panels easily removed and all components
accessible for service.
Removable/cleanable air filters.
STORAGE BINS
B-800 - 363 kg. Application Capacity (272 kg. ARI-Rated Capacity Bin)
B-900 - 408 kg. Application Capacity (299 kg. ARI-Rated Capacity Bin)
B-1200 - 544 kg. Application Capacity
B-1500 - 680 kg. Application Capacity
OPERATING LIMITS
Ambient Temp Range 7 - 38 ˚C
Water Temp Range 7 - 32 ˚C
Voltage Range 198-254V
Water Pressure 10 - 113 psig
STAINLESS STEEL
INTERNAL EVAPORATOR
WARRANTY
ONE YEAR - Parts
ELECTRICAL & PLUMBING
220-240/50/1 (3 wire with neutral for 115V)
20 Amp Max Fuse/HACR breaker size
1.27cm OD copper or equivalent
independent potable water supply
1.52cm independent drain connection
R-404A REFRIGERANT
KM-1300SAH-E (AIR-COOLED) Up to 649 kgs. of ice production per 24 hours
Stackable for 1298 kgs. per 24 hours
KM-1300SAH-E SERIES DIMENSIONS (Metric) - CONNECTIONS
SPECIFICATIONS
UTILITY CONSUMPTION
AIR- COOLED
Model Number
Model Number
21˚
10˚ 21˚
544
512
502
502
446
400
32˚
448
395
346
27˚
32˚
Condenser Amperage Min. Circuit
Ampacity
Ice Production Per
Cycle KWH per
45 kgs.
Potable
Water
Gal. per
45 kgs.
Condenser
Water
Gal per
45 kgs.
Kgs. Cubes
Shipping
Weight
11.5 20 143 kgs.
Air-Cooled
KM-1300SAH-E 13.7 1440 5.5 33.4 NA
KM-1300SAH-E
Air Temp˚ C.
Water Temp˚ C.
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL 770-487-2331 FAX 770-487-1325 www.hoshizaki.com
We reserve the right to change specifications without notice.
Printed in U.S.A.
FRONT VIEW
SIDE VIEW
AIR-COOLED UNIT
ICE DROP ZONE
