Page Count: 2

Item #: Qty #:

Model #:

Project #:

MX-SS-242

MX-SS-302

MX-SS-300

MX-SS-303

MX-SS-363

Width x S/S Base Galv. Base Weight

Length

MX-GL-242

MX-GL-302

MX-GL-300

MX-GL-303

MX-GL-363

UTENSIL RACK & UNDERSHELF

24” x 24”

30” x 24”

30” x 30”

30” x 36”

36” x 36”

53 lbs.

63 lbs.

77 lbs.

77 lbs.

85 lbs.

MT-SS-242

MT-SS-302

MT-SS-300

MT-SS-303

MT-SS-363

Width x S/S Base Galv. Base Weight

Length

MT-GL-242

MT-GL-302

MT-GL-300

MT-GL-303

MT-GL-363

WITH UNDERSHELF

24” x 24”

30” x 24”

30” x 30”

30” x 36”

36” x 36”

53 lbs.

63 lbs.

77 lbs.

77 lbs.

85 lbs.

SAG-MT-242

SAG-MT-302

SAG-MT-300

SAG-MT

-303

SAG-MT-363

Width x S/S Base Galv. Base Weight

Length

AG-MT-242

AG-MT-302

AG-MT

-300

AG-MT-303

AG-MT-363

BUDGET SERIES WITH UNDERSHELF

24” x 24”

30” x 24”

30” x 30”

30” x 36”

36” x 36”

53 lbs.

63 lbs.

77 lbs.

77 lbs.

85 lbs.

STAINLESS STEEL

MIXER TABLES

O-2

FEATURES:

TOP is furnished with a 2” x 1” square die embossed NO-DRIP

countertop offset edge with a 1/2” return on 4 sides.

Aluminum die cast “leg-to-shelf” clamp secures shelf to leg eliminating

unsightly nuts and bolts. Undershelf is adjustable.

MATERIAL:

MX-SS & MT-SS SERIES - Stainless Steel Base

TOP is 14 gauge stainless steel type “304” series with galvanized

understructure.

UNDERSHELF is 18 gauge stainless steel.

LEGS are 1 5/8” diameter tubular stainless steel with stainless steel bullet

feet & gussets.

UTENSIL RACK on MX-SS Series is 1 5/8” dia. stainless steel tubing with

stainless steel hooks.

MX-GL & MT-GL Series - Galvanized Steel Base

TOP is 14 gauge stainless steel type “304” series with galvanized

understructure.

UNDERSHELF is galvanized steel.

LEGS are 1 5/8” diameter, tubular galvanized steel. Gussets are

galvanized steel with 1” adjustable plastic bullet feet.

UTENSIL RACK on MX-SS Series is 1 5/8” diameter galvanized steel

tubing with stainless steel hooks.

SAG-MT & AG-MT Budget Series

TOP is heavy gauge stainless steel type “430” series with galvanized

understructure.

SAG-MT Series UNDERSHELF is 18 gauge stainless steel.

AG-MT Series UNDERSHELF is galvanized steel.

SAG-MT Series LEGS are 1 5/8” diameter, tubular stainless steel.

Gussets are stainless steel. 1” adjustable stainless steel bullet feet.

AG-MT Series LEGS are 1 5/8” diameter, tubular galvanized steel.

Gussets are galvanized steel. 1” adjustable plastic bullet feet.

NEW YORK GEORGIA TEXAS NEVADA

(800) 645-3166 (800) 832-1218 (800) 527-0353 (800) 446-8684

Fax: (631) 242-6900 Fax: (770) 775-5625 Fax: (972) 932-4795 Fax: (775) 972-1578

1-800-498-6634 Fax: 631-586-2933

smartfab@advancetabco.com

For Assistance with

Smart Modifications & Accessories Call:

www.advancetabco.com

CONSTRUCTION:

All TIG welded. Exposed weld areas polished to match

adjacent surface.

Entire T

op is mechanically polished to a satin finish and is sound

deadened. Countertop edge polished to a MIRROR FINISH.

Roll formed embossed galvanized hat channels are secured to top by

means of structural adhesive and weld studs.

Gussets welded to support hat channels.

(Optional Casters Shown)

TOL ± .500” ALL DIMENSIONS ARE TYPICAL

200 Heartland Boulevard, Edgewood, NY 11717-8380

ADVANCE TABCO is constantly engaged in a program of

improving our products. Therefore, we reserve the right to

change specifications without prior notice.

© ADVANCE TABCO, SEPTEMBER 2005

DETAILS and SPECIFICATIONS

O-2a

MT, SAG & AG Series

MX Series

Countertop Edge

Detail
