Open the PDF directly: View PDF PDF.
Page Count: 2

APPROVALS:
Specifi cations subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
T-19
T-19
Model
Solid
Doors
Capacity
(Cu. Ft.)
(liters)
# of
Shelves
Cabinet Dimensions
(inches)
(mm)
LDH*
HP Voltage Amps
NEMA
Confi g.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
T-19 1 19
538
327
686
24 1/2
623
78 1/8
1985
1/3
1/3
115/60/1
230-240/50/1
5.0
3.0
5-15P
▲
9
2.74
230
105
* Height does not include 3 1/4
"
(83 mm) for castors or 6
"
(153 mm) for optional legs. ▲ Plug type varies by country.
6/04
R
S
A
V
I
N
G
S
E
N
E
R
G
Y
S
5
YEAR
COMPRESSOR
WARRANTY
USA
True’s solid door reach-in’s are
designed with enduring quality that
protects your long term investment.
Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower utility
costs, superior food safety and the
best value in today’s food service
marketplace.
Oversized, factory balanced,
refrigeration system holds 33°F to
38°F (.5°C to 3.3°C) for the best in
food preservation.
300 series stainless steel solid doors
and front. The fi nest stainless
available; higher tensile strength
for fewer dents and scratches.
Adjustable, heavy duty PVC coated
shelves.
Positive seal self-closing door.
Lifetime guaranteed door hinges
and torsion type closure system.
Bottom mounted units feature:
“No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest,
most grease free area of kitchen.
Easily accessible condenser coil for
cleaning.
T Series:
Reach-In Solid Door Refrigerator
STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Front Side Plan 3D
PLAN VIEW
KCL
25/8
"
(67 mm)
733/8
"
(1864 mm)
T-19 TFE015E TFE015S TFE015P TFE0153
T-19
DESIGN
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures,
lower utility costs, superior food safety
and the best value in today’s food
service marketplace.
REFRIGERATION SYSTEM
• Factory engineered self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains 33°F to
38°F (.5°C to 3.3°C) for the best in food
preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True reach-in’s a superior
low velocity, high volume airfl ow
design. This unique design insures
faster temperature recovery and
shorter run times in the busiest of food
service environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen. Allows
for storage area on top of unit.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel front
grill and shroud. Anodized quality
aluminum exterior ends and back.
• Interior - attractive, NSF approved,
white aluminum liner. 300 series
stainless fl oor with coved corners.
• Insulation - entire cabinet structure
and solid doors are foamed-in-
place using high density, CFC free,
polyurethane insulation.
• Cabinet mounted on a welded, heavy
duty galvanized frame rail. Rail dipped
in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fi tted with 2 1/2" (64 mm)
diameter stem castors - locks provided
on front set.
DOORS
• 300 series stainless steel exterior with
white aluminum door liner to match
cabinet interior. Doors extend full
width of cabinet shell. Door locks
standard.
• Positive seal self-closing doors.
Lifetime guaranteed door hinges and
torsion type closure system.
• Lifetime guaranteed recessed door
handles. Each door fi tted with 12"
(305 mm) long recessed handle that
is foamed-in-place with a sheet
metal interlock to insure permanent
attachment.
• Magnetic door gaskets of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC
coated wire shelves 22 7/8"L x 18 1/4"D
(582 mm x 464 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves
are adjustable on 1/2" (13 mm)
increments.
• Each shelf capable of supporting up to
250 lbs. (114 kg).
LIGHTING
• Incandescent interior lighting - safety
shielded. Lights activated by rocker
switch mounted above doors.
MODEL FEATURES
• Exterior mounted temperature
monitor.
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for fi nal connection to a
115/60/1 phase - 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
❒ 230 - 240V / 50 Hz.
❒ 6" (153 mm) standard or seismic/
fl anged legs.
❒ Additional shelves.
❒ Novelty baskets.
❒ Remote cabinets (condensing unit
supplied by others), consult factory
technical service department for BTU
information.
115/60/1
NEMA-5-15R
FRONT VIEW TOP VIEW
T Series:
Reach-In Solid Door Refrigerator
813/8
"
(2067 mm)
31/4
"
(83 mm)
43/4
"
(121 mm)
781/8
"
(1985 mm)
27
"
(686 mm)
251/2
"
(648 mm)
241/2
"
(623 mm)
217/8
"
(556 mm)
