Pizza Prep Tables
(one & two door models)
❒ TPP-44, ❒ TPP-60,
❒ TPP-67
Pizza Prep Series
(one & two door models)
5
YEAR
COMPRESSOR
R
R
®
S
A
V
I
N
G
S
E
N
E
R
G
Y
S
Exceptions:
CABINET CONSTRUCTION:
•Stainless steel front, top and ends. Aluminum finished back.
•Patented, removable, stainless steel foam insulated cover.
•White, vinyl coated aluminum interior cabinet liner with 300 series
stainless steel floor with coved corners. Construction of liner in
accordance with NSF standards.
•5” diameter stem castors, front castors include brakes. (optional
6” stainless steel legs available)
•Full set of 6” deep clear polycarbonate insert pans.
•19 1/2” full length removable cutting board standard.
DOORS:
•Stainless steel exterior with white aluminum interior to match
cabinet liner. Door gaskets of one piece construction, and removable
for ease in cleaning
•Doors include 12” long horizontal recessed handle with sheetmetal
interlock. Handles foamed-in-place to insure permanent attachment.
SPECIFICATIONS / FEATURES
True’s TPP series offers the industry’s coldest
temperature possible directed across and
under ingredient pans for dependable
freshness.
TPP-67
Printed in
U.S.A.
5/1/02
APPROVALS:
Also available:
• Drawered Models
• Drawer / Door Combinations Models
• Overshelf Option
• Garnish Rack Option
INSULATION:
•Entire cabinet structure and doors insulated using foamed-in-place
CFC free polyurethane foam.
SHELVING:
•Adjustable vinyl coated wire shelves (2 per door). Shelves capable
of supporting up to 250 lbs. (not included in drawered models)
•Full height shelf support pilasters, with double oblong holes on 1/2"
centers. Pilasters made of the same material as cabinet interior.
Four (4) chrome plated, stainless steel shelf clips to be included for
each shelf.
REFRIGERATION SYSTEM:
•Refrigeration system factory balanced using CFC free R134A
refrigerant.
•Factory pre-engineered capillary tube system with oversized condenser
and evaporator to reduce product pull down time and to consistently
maintain 33°F to 41°F interior cabinet temperature. (non-adjustable
capillary tube system superior to problematic expansion valve).
System includes patented airflow system - air from evaporator is
directed at pans to insure proper product temperatures are
maintained.
•Evaporator - epoxy coated at the time of manufacture to eliminate
the potential of corrosion.
ELECTRICAL CHARACTERISTICS:
•Unit completely pre-wired at factory, and ready for final connection
to a 115/60/1 phase - 15 amp dedicated outlet. A cord and plug set
to be included.
•A sole use circuit is required.
115/60/1
As of April 1, 1998
these model are in
compliance
and listed under
ANSI / NSF-7-1997-6.3
Specifications subject to change without notice.
TRUE FOOD SERVICE EQUIPMENT, INC.
St. Charles Industrial Center • P.O. Box 970 • O'Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
AIA #
SIS #
Project Name:
Location:
Item #: Qty:
Model #:
Dimensions Cord
Capacity # of (inches) NEMA Length Crated
Model Doors (Cu. Ft) Shelves LD H HP Volts PH Amps Config. (feet) Weight
TPP-44
(1)
111.4 244 1/2 35 1/4 41 1/2 1/3 115 18.6 5-15 7272
TPP-60
(2)
215.9 460 1/4 35 1/4 41 1/2 1/3 115 17.9 5-15 7325
TPP-67
(1, 2)
220.6 467 1/4 35 1/4 41 1/2 1/3 115 18.6 5-15 7390
®TPP-Series: Pizza Prep Tables (one & two door)
(1) Available in drawered model
(2) Available in combination drawer / door model
•Stainless steel front, top and sides.
•Aluminum finished back
•Interior - NSF approved, white vinyl
coated aluminum sides and top, coved
corners and stainless steel floor.
•Stainless steel patented foam insulated
cover.
•Foamed-in-place high density
polyurethane insulation (CFC free).
•Oversized and balanced, environmentally
friendly (134A) refrigeration system with
airflow directed at pans to hold 33°F to
41°F.
•6” deep clear polycarbonate insert pans
included.
•5” swivel castors standard equipment.
•Extra-deep 19 1/2” full length removable
cutting board included, height from floor,
36”.
•Adjustable vinyl coated wire shelves (door
models only).
•Door swings within cabinet dimensions.
•Front breathing
•Recessed handles.
•Epoxy coated evaporator
❒Available with 6" stainless steel legs.
❒Bun tray racks
❒Garnish rack
❒Service shelf
Standard Features ___________________________________________________________________________________________
Optional Accessories______________
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O'Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Printed in U.S.A.
Rough-In Data
TPP-44
351/4"271/4"
91/2"
411/2"
441/2"
36"
Pan Opening
113/4" X 403/8"
6"
L - 113 cm
D - 90 cm
H - 105 cm
Door
Swing - 69 cm
Top View
351/4"271/4"
91/2"
411/2"
671/4"
36"
6"
L- 171 cm
D- 90 cm
H - 105 cm
Door
Swing - 69 cm
Top View
TPP-67
51"
51"
621/2"
621/2"
32"
32"
Clearance Required For
Coolers (USA)
Sides Rear
Inches/mm Inches/mm
0 / 0 2 / 50
Specifications subject to change without notice.
351/4"
91/2"
411/2"
601/4"
6"
51"
32"
Top View
36"
Pan Opening
113/4" X 343/4"
221/4"
571/2"
Pan Opening
113/4" X 21"
Door Size
183/4" X 277/16"Door Size
255/8" X 277/16"
151/2"
TPP-60
Door Size
273/4" X 273/4"
Door Size
29" X 273/8"
L- 153 cm
D- 90 cm
H - 105 cm
Door
Swing - 56 cm
5
YEAR
COMPRESSOR
R
R
®
S
A
V
I
N
G
S
E
N
E
R
G
Y
S
Model Front Right Plan 3D
TPP-44 TFQY10E TFQY10S TFQY10P TFQY103
TPP-60 TFQ071E TFQY71S TFQY71P TFQY713
TPP-67 TFQY11E TFQY10S TFQY11P TFQY113
Pan Opening
113/4" X 403/4"Pan Opening
113/4" X 195/8"
•Slide out compressor can be serviced
easily and accessed by a single repairman.
•Self-contained system.
•Rear bumpers.
•1 year parts & labor warranty (USA)
•5 year compressor warranty
