Model : TBD-1SD/SB

TBD-1SD 1 1 1/10 4 198 235/8 x 313/4 x 387/8

TBD-1SB 1 1 1/10 4 198 235/8 x 313/4 x 387/8

Beer Dispensers

Beer Dispensers

TBD-1SD TBD-1SB

3 YEAR

(U.S.A only)

5 YEAR

Compressor

WARRANTY

(U.S.A only)

Model

1/2

Barrels

Swing

Door HP AMPS

Crated

Weight

(lbs.)

L x D x H

(inches)

* Depth does not include 2” for rear spacers. † Height does not include 5” for caster height. Height does not include 15-1/8” for draft arm.

†

*

more durable, efficient, beautiful

Project :

Model # :

Item # : Qty :

Available W/H :

Approval :

Ver.201601

4184 E. Conant St.

Long Beach, CA 90808

Tel. 310-900-1000

Fax. 310-900-1077

www.turboairinc.com

Underbar Equipment

Super Deluxe Series

Efficient refrigeration system

Turbo Air’s refrigerators are designed with oversized and balanced

R-134A (CFC Free) refrigeration systems. These include efficient

evaporators and condensers for faster cooling and greater efficiency.

Stainless steel cabinet construction

Super Deluxe (SD) models boast a stainless steel exterior (except

galvanized steel back and bottom). SB models are attractive

wear-resistant black vinyl exterior. Heavy gauge stainless steel

countertop is perfect for sanitation and durability. Interior is stainless

steel

except galvanized steel top

. Turbo Air Beer Dispenser model

guarantees utmost in cleanliness and long product life. It also can add

a touch of style to the most refined setting.

Forced air cooling system

Fast cooling and balanced temperature throughout the cabinet.

High-density polyurethane insulation

3” diameter stainless steel insulated beer

columns

Ergonomically designed doors

Customers’ fatigue fades away with easy grip handles and doors that

open effortlessly. These features along with self-closing doors make this

the ultimate choice in customer convenience.

LED lighting interior

Brighter and longer lasting LED lights provide attractive, enhanced

illumination compared to fluorescents. It saves energy by producing

less heat.

Refrigerator holds 33°F ~ 38°F for the best in

beverage preservation

- Does not include keg couplers

FEATURES & BENEFITS

PLAN VIEW

Turbo Air : 800-627-0032

Warranty : 800-381-7770

GK : 800-500-3519

AC : 888-900-1002

Model : TBD-1SD/SB

ELECTRICAL DATA

DIMENSIONAL DATA

Voltage

Plug Type

Full Load Amperes

Compressor HP

Refrigerant

Cord Length (ft.)

Lamp (w)

Capacity (1/2 Barrels)

Ext. Length Overall (in.)

Ext. Depth Overall (in.)

Ext. Height Overall (in.)

Net Weight (lbs.)

Gross Weight (lbs.)

# of Swing Door

SIDE VIEW

FRONT VIEW

PLAN VIEW

Beer Dispensers

Beer Dispensers

†

3 Year Parts and Labor Warranty

Additional 2 Year Warranty on Compressor

115/60/1

NEMA 5-15P

4

1/10

R-134A

8.5

25W

1

235/8 (600mm)

313/4 (806mm)

387/8 (988mm)

175

198

1

* Depth does not include 2” for rear spacers.

† Height does not include 5” for caster height. Height does not include 15-1/8” for draft arm.

235/8 (600mm)

1/2”

235/8 (600mm)

193/4 (500mm)

257/8

(656mm)

91/4

(234mm)

191/8

(486mm)

313/4 (806mm)

131/8 165/8

197/8 (505mm)

313/4 (806mm)

5”

405/8 (1031mm)

291/2 (749mm)

323/8 (822mm)

341/2 (875mm)

23/8”

151/8

(384mm)

387/8 (988mm)

Design and specifications subject to change without notice.

Actual shipping weight may differ due to extra packing materials for product protection.

(unit : inch)

*

Door

29 (738mm)

507/8 (1292mm)

253/8 (645mm)

311/4 (794mm)

Ver.201601

Underbar Equipment

Super Deluxe Series

Double faucet beer tower standard

Door locks standard

Self-contained system

4” dia. swivel casters standard

3 YEAR

(U.S.A only)

5 YEAR

Compressor

WARRANTY

(U.S.A only)
