Communication Components DAB1819125G2 PCS GSM/EDGE 125W Dual Amplifier Booster User Manual
Communication Components Inc PCS GSM/EDGE 125W Dual Amplifier Booster
User Manual
GSM/EDGE Dual Amplifier Booster
CCI Model Number DAB-1819-125-G2
USER’S GUIDE
Product Description:
DAB-1819-125-G2 Dual Amplifier Booster:
The CCI GSM Dual Amplifier-Booster Module (DAB) consists of two linear power
amplifiers with intermodulation level control circuitry, each capable of generating a
125 Watt GSM/EDGE signal.
Operation Description:
The DAB-1819-125-G2 Dual Amplifier Booster is designed to supply a nominal
output power level of 125 Watts (51 dBm) per channel. Although the gain of the Dual
Amplifier Booster is fixed, the output can be adjusted by setting the input power level.
Operation and Installation Instructions:
The following instructions should be followed when installing the unit in service:
• Apply a 29-33VDC input voltage to the DC Input connector of the Dual
Amplifier-Booster Module.
• Insure that the DC Source is capable of delivering up to 30 Amps at 31VDC.
• Apply a GSM/EDGE signal of up to +40dBm to each RF input port of the Dual
Amplifier-Booster Module.
• The Dual Amplifier-Booster Module will provide approximately 11dB or less of
RF Gain.
• Check the RF output to insure the proper output power is present.
{Approximately 125 Watts (51dBm) per channel}.
• Adjust the input power level to insure the output power level is in compliance
with the values indicated in the table on page 2.
COMMUNICATION
COMPONENTS INC
Extending Wireless Coverage
89 Leuning Street Phone: 201-342-3338
2nd Floor Fax: 201-342-3339
S
outh Hackensack, NJ 07606 www.cciproducts.com
z Page 2
• Install the Alarm Connector to the Alarm Output connector of the Dual
Amplifier-Booster/Combiner Module.
Setting the RF Output Power on the DAB-1819-125-G2 Booster Amplifier
The RF output power is not adjustable on the DAB & DAC Booster Amplifier. The
user must adjust the RF input power to the Booster Amplifier such that the RF output
power level does not exceed the levels shown below in order for the RF output
spectral emissions to be compliant with the FCC spurious emissions limit of -13 dBm
outside of the assigned frequency block. These levels must not be exceeded.
Channel Center
Frequency (MHz) Maximum RF
0utput (Watt)*
1930.2-1989.8 100
* Note: The Maximum RF Output Power is after any passive losses after the Booster Amplifier such as
filters and cables.
This equipment complies with Part 24 of the FCC rules. Any changes or
modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
