TG9D User Manual

MENU MAP ......................................................... 14

SAFETY ................................................................ 22

Traffic Safety......................................................... 22

Do Not Use in Hospitals....................................... 22

Do Not Use in Airplanes....................................... 22

Do Not Use in Gasoline Stations.......................... 22

Do Not Use in Explosive Sites.............................. 23

Operating Environment ........................................ 23

Standard Usage .................................................... 23

Accessories ........................................................... 23

Appropriate Maintenance..................................... 23

Emergency Calls (SOS) ........................................ 23

Use with proper care to reduce electromagnetic

interference (EMI) ......................................................... 24

GETTING STARTED .......................................... 25

PHONE OVERVIEW .................................................. 25

INSTALLATION & REMOVING .................................. 26

Installing the battery.............................................. 26

Removing the battery ............................................. 26

Installing the SIM Card.......................................... 27

Removing the SIM Card......................................... 27

Connecting the Charger......................................... 28

Removing the Charger ........................................... 29

KEYPAD DESCRIPTION ............................................ 29

ALPHANUMERIC MAPPING ...................................... 30

DISPLAY INDICATORS. ............................................. 32

BASIC OPERATION ........................................... 34

Making a Call ........................................................ 34

The SIM Card......................................................... 34

Battery and Charger .............................................. 34

Turning on the Phone............................................. 35

PIN and PIN2 (4 to 8 digits).................................. 35

PUK1 and PUK2 (8 digits).................................... 35

Calling ................................................................... 36

Dialing Emergency Numbers ................................. 36

Changing an Entry................................................. 36

Answering a Call ................................................... 36

Recent Calls ........................................................... 36

Speed Dial.............................................................. 37

Holding a Call ....................................................... 37

Multi-party Calls.................................................... 38

Voice-activated Dialing.......................................... 38

Method of Input...................................................... 39

1. T9 English........................................................................... 40

2. BoPoMoFo (Phonetic method)............................................ 40

3. Stroke of Chinese Character................................................ 42

4. PinYin (Phonetic Method)................................................... 43

MENU FUNCTION ............................................... 44

PHONE BOOK …… ................................................. 44

Search .................................................................... 44

Add Entry ............................................................... 45

Edit......................................................................... 46

Delete..................................................................... 46

Copy....................................................................... 47

P.Book Setting ........................................................ 47

1. Caller Group........................................................................ 47

2. Sorting................................................................................. 47

3. Display SIM Records .......................................................... 47

Memory.................................................................. 48

CAMERA.………..................................................... 48

Shoot ...................................................................... 48

To Album ................................................................ 49

Setting .................................................................... 49

1. Photoflash ........................................................................... 49

2. Night Shot Mode................................................................. 49

3. Add Frame........................................................................... 49

4. Special Mode....................................................................... 49

5. Continuous Mode................................................................ 50

6. Sub LCD ............................................................................. 50

7. Sound Effect........................................................................ 50

8. Advanced............................................................................. 50

~ Info Display........................................................................ 50

~ Softkey Switch.................................................................... 50

~ Timekeeper ......................................................................... 50

~ Set Size............................................................................... 50

~ Add Date............................................................................. 51

~ Add Text ............................................................................. 51

　 Turn Enable/Disabled............................................. 51

　 Set Position ............................................................. 51

　 Set Color .................................................................. 51

　 Input Content........................................................... 51

~ Set File Name ..................................................................... 51

MESSAGES…….…… ............................................. 52

SMS........................................................................ 52

1. Write.................................................................................... 52

2. Inbox ................................................................................... 52

3. Outbox................................................................................. 53

4. Delete.................................................................................. 53

5. Free Count........................................................................... 53

6. Setting ................................................................................. 53

~ Pre-Message ....................................................................... 54

~ SMS Center ........................................................................ 54

~ Valid Time .......................................................................... 54

~ Auto Display....................................................................... 54

~ Status Report....................................................................... 54

MMS....................................................................... 54

1. Write.................................................................................... 55

~ New .................................................................................... 55

　 Send Message ........................................................ 56

　 Visibility Options:..................................................... 57

　 Save.......................................................................... 57

　 Setting ...................................................................... 57

　 Add Slide.................................................................. 57

　 Delete Slide ............................................................. 57

~ From Template.................................................................... 57

2. Inbox ................................................................................... 57

3. Outbox................................................................................. 58

4. Draft.................................................................................... 58

5. Sent ..................................................................................... 58

6. Templates ............................................................................ 58

7. MMS Setting....................................................................... 58

~ Connection.......................................................................... 58

　 Add New: ................................................................. 58

　 Add from list............................................................. 58

~ Reception............................................................................ 59

　 Always ...................................................................... 59

　 Home PLMN on........................................................ 59

　 Never......................................................................... 59

~ Message Validity................................................................. 59

　 1 Hour ....................................................................... 59

　 6 Hours...................................................................... 59

　 1 Day......................................................................... 59

　 3 Days ....................................................................... 59

　 1 Week....................................................................... 59

　 Maximum .................................................................. 59

~ Allow Adverts..................................................................... 59

~ Save Sent Msgs................................................................... 59

Broadcast ............................................................... 59

1. Read .................................................................................... 59

2. Filter.................................................................................... 60

3. Auto Display ....................................................................... 60

VOICE MAIL............................................................ 60

1. Call V-mail................................................................. 60

2. Voice Mail#................................................................ 60

AUDIO PROFILES…................................................. 61

Adjust ..................................................................... 61

1. Activate ............................................................................... 61

2. Ringtone and Volume .......................................................... 61

3. Key Sound........................................................................... 61

4. Crescendo............................................................................ 61

5. SMS Rec Tone..................................................................... 62

6. Vibrator ............................................................................... 62

7. Service Tone........................................................................ 62

8. Auto Answer........................................................................ 62

9. Rename ............................................................................... 62

SETTINGS ……………. .......................................... 62

Personal................................................................. 62

1. Language............................................................................. 62

2. Greetings............................................................................. 62

3. Power On/Off Melody......................................................... 63

4. Folder On/Off Melody ........................................................ 63

5. Hot Key Setting................................................................... 63

6. Own Number....................................................................... 64

Clock...................................................................... 64

1. Set Date............................................................................... 64

2. Set Alarm ............................................................................ 64

3. Power Off............................................................................ 64

Screen..................................................................... 64

1. Standby mode...................................................................... 64

2. Color Theme........................................................................ 65

3. Network Name .................................................................... 65

4. Show Clock......................................................................... 65

5. Standby LED....................................................................... 65

6. Sub LCD Sleep Time .......................................................... 65

Call Setting ............................................................ 65

1. Call Waiting ........................................................................ 65

~ Activate............................................................................... 65

~ Cancel................................................................................. 65

~ Status .................................................................................. 66

2. Divert .................................................................................. 66

~ Forward to .......................................................................... 66

~ Unreachable........................................................................ 66

~ If No Reply......................................................................... 66

~ All Calls.............................................................................. 66

~ If Busy ................................................................................ 66

~ Status .................................................................................. 66

~ Cancel All........................................................................... 66

3. Answer Mode...................................................................... 66

4. Present Number................................................................... 67

Network.................................................................. 67

1. Select Method ..................................................................... 67

2. New Search ......................................................................... 67

3. Select Sequence................................................................... 67

Security .................................................................. 67

1. Bar Calls.............................................................................. 67

~ All Out................................................................................ 67

~ Out Intl ............................................................................... 68

~ Out X Home ....................................................................... 68

~ All In................................................................................... 68

~ In If Abr.............................................................................. 68

~ Status .................................................................................. 68

~ Cancel All........................................................................... 68

2. PIN Check........................................................................... 68

3. PIN Change......................................................................... 68

4. PIN2 Change....................................................................... 68

5. Fixed Numbers.................................................................... 68

6. SIM Lock ............................................................................ 68

~ Set Lock.............................................................................. 69

~ Change PCK....................................................................... 69

Reset Setting........................................................... 69

CALL LISTS.………. ............................................... 69

Missed Call ............................................................ 69

Incoming ................................................................ 70

Outgoing ................................................................ 70

Call Info ................................................................. 70

1. Last Call.............................................................................. 70

2. Total Calls ........................................................................... 70

3. 1-minute Beep..................................................................... 70

4. Charge Info ......................................................................... 70

~ Total Charge........................................................................ 70

~ Max Charge ........................................................................ 70

~ Unit Price............................................................................ 71

MULTI MEDIA ……................................................. 71

File Manager ......................................................... 71

~ Open File............................................................................ 71

~ Send MMS.......................................................................... 71

~ Save as Wallpaper............................................................... 71

~ Save to P.Book.................................................................... 71

~ Rename............................................................................... 71

~ Delete.................................................................................. 72

~ Delete all file ...................................................................... 72

~ File Sort.............................................................................. 72

　 By Name .................................................................. 72

　 By Date .................................................................... 72

　 By Type .................................................................... 72

~ View.................................................................................... 72

　 List ............................................................................ 72

　 Icon ........................................................................... 72

~ Detail Info........................................................................... 72

~ Password............................................................................. 72

　 Set password........................................................... 72

　 Preview all ............................................................... 72

To Album ................................................................ 73

Image ..................................................................... 73

Audio...................................................................... 73

Frame..................................................................... 73

Password Setting.................................................... 73

~ Modify password ................................................................ 73

~ Password............................................................................. 73

Free Space ............................................................. 73

Game...................................................................... 74

1. Game................................................................................... 74

~ Puzzle ................................................................................. 74

~ Hostage Salvation............................................................... 74

~ Reversi................................................................................ 74

~ Coin Elf .............................................................................. 75

JAVA ........................................................................ 75

~ Start Game.......................................................................... 75

~ Connection.......................................................................... 76

　 Connection............................................................... 76

　 Add from List ........................................................... 76

Tone Edit ................................................................ 76

1. Play ..................................................................................... 76

2. Edit...................................................................................... 77

~ Keypad functions................................................................ 77

~ Edit ..................................................................................... 77

3. Reset.................................................................................... 78

4. Tempo.................................................................................. 78

5. Instrument ........................................................................... 78

6. Rename ............................................................................... 78

CALCUATOR ............................................................ 78

Calendar.......................................................................... 79

1. View Day Note ........................................................... 79

2. Make Note.................................................................. 79

3. Erase Note ................................................................. 80

4. View All Notes............................................................ 80

5. Go To Date................................................................. 80

Exchange Rate ....................................................... 80

Voice Memos .......................................................... 81

1. Record................................................................................. 81

2. Playback.............................................................................. 81

~ Playback ............................................................................. 81

~ Delete One.......................................................................... 81

~ Label................................................................................... 81

3. Options................................................................................ 81

~ Self Only............................................................................. 81

~ Other Party Only................................................................. 81

~ Both .................................................................................... 81

World clock ............................................................ 82

~ Set Location........................................................................ 82

　 Automatic ................................................................. 82

　 Manual...................................................................... 82

INTERNET………............................................... 82

Access WAP............................................................ 82

Favorites................................................................ 83

1. New Bookmark ................................................................... 84

2. New Folder.......................................................................... 84

3. Delete all ............................................................................. 85

4. Hotkeys ............................................................................... 85

Go To URL ............................................................. 85

WAP Settings.......................................................... 85

1. Connection .......................................................................... 85

~ Add New............................................................................. 85

　 Name ........................................................................ 85

　 Homepage ............................................................... 86

　 IP Address ............................................................... 86

　 Bearer....................................................................... 86

　 User name ............................................................... 86

　 Password ................................................................. 86

　 DNS IP address. ..................................................... 86

　 Linger Time.............................................................. 86

　 APN .......................................................................... 86

　 Security .................................................................... 86

　 Store ......................................................................... 86

~ Add from List ..................................................................... 87

　中華 WAP................................................................. 87

　台哥大 WAP ............................................................. 87

　遠傳 WAP................................................................. 87

　泛亞 WAP................................................................. 87

　東信 WAP................................................................. 87

2. Color Scheme...................................................................... 87

3. Clear Cache......................................................................... 87

4. Reset all............................................................................... 87

GPRS Setting ......................................................... 87

1. Permanent......................................................................... 87

2. Needed ............................................................................. 87

STK( SIM TOOLKIT ). ......................................... 87

BATTERY ............................................................ 89

CARE AND MAINTENANCE ........................... 90

FCC REGULATION…………………………………91

FCC RF EXPOSURE INFORMATION…………….92

Menu Map

Phone Book

zSearch

zAdd Entry

zEdit

zDelete

zCopy

zP.Book Setting

1. Caller Group

2. Sorting

3. Display SIM Records

zMemory

Camera

zShoot

zTo Album

zSetting

1. Photoflash

2. Night Shot Mode

3. Add Frame

4. Special Mode

5. Continuous Mode

6. Sub LCD

7. Sound Effect

8. Advanced

~ Info Display

~ Softkey Switch

~ Timekeeper

~ Set Size

~ Add Date

~ Add Text

~ Set File Name

Messages

z SMS

1. Write

2. Inbox

3. Outbox

4. Delete

5. Free Count

6. Setting

7. Sound Effect

8. Advanced

~ Pre-Message

~ SMS Center

~ Valid Time

~ Auto Display

~ Status Report

zMMS

1. Write

~ New

~ From Template

2. Inbox

3. Outbox

4. Draft

5. Sent

6. Templates

7. MMS Setting

~ Connection

~ Reception

~ Message Validity

~ Allow Adverts

~ Save Sent Msgs

zBroadcast

1. Read

2. Filter

z Voice Mail

1. Call V-mail

2. Voice Mail#

Audio Profile

zTypical

zSilent

zOutdoor

zIn Car

zMeeting

zCustomer

1. Activate

2. Ringtone and Volume

3. Key Sound

4. Crescendo

5. SMS Rec Tone

6. Vibrator

7. Service Tone

8. Auto Answer

Settings

zPersonal

1. Language

2. Greetings

3. Power On/Off Melody

4. Folder On/Off Melody

5. Hot Key Setting

6. Own Number

zClock

1. Set Date

2. Set Alarm

3. Power Off

zScreen

1. Standby mode

2. Color Theme

~ Pic & Text

~ Digital Clock

~ Calendar

3. Network Name

4. Show Clock

3. Standby LED

3. Sub LCD Sleep Time

zCall Setting

1. Call Waiting

~ Activate

~ Cancel

~ Status

2. Divert

~ Forward to

~ Unreachable

~ If No Reply

~ All Calls

~ IF Busy

~ Status

~ Cancel All

3. Answer Mode

~ Normal answer

~ Any key answer

~ Folder answer

4. Present Number

zNetwork

1. Select Method

2. New Search

3. Select Sequence

zSecurity

1. Bar Calls

~ All Out

~ Out Intl

~ Out x Home

~ All In

~ In If Abr

~ Status

~ Cancel All

2. PIN1 Check

3. PIN1 Change

4. PIN2 Change

5. Fixed Numbers

6. SIM Lock

~ Set Lock

~ Change PCK

zReset Setting

Call Lists

zMissed Call

zIncoming

zOutgoing

zCall Info

1. Last Call

2. Total Calls

3. 1-minute Beep

5. Charge Info

~ Total List

~ Max Charge

~ Unit Price

File Manager

1. Open File

2. Send MMS

3. Save as Wallpaper

4. Save to P.Book

5. Rename

6. Delete

7. Delete all file

8. File Sort

9. Open File

10. View

11. Detail Info.

zTo Album

zImage

zAudio

zFrame

zFree Space

zGame

1. Game

~ Puzzle

~ Hostage Salvation

~ Reversi

~ Money Master

2. Java

~ Start Game

~ Connection

zTone Edit

1. Play

2. Edit

~ Keypad function

~ Edit

3. Reset

4. Tempo

5. Instrument

6. Rename

PIM

zCalculator

zCalendar

1. View DayNote

2. Make Note

3. Erase All

4. View All Notes

5. Go To Date

zExchange Rate

zVoice Memos

1. Record

2. Playback

~ Playback

~ Delete One

~ Label

3. Options

~ Self Only

~ Other Party Only

~ Both

zWorld Clock

~ Set Location

Internet

zAccess WAP

zFavorites

1. New Bookmark

2. New Folder

3. Delete all

4. Hotkeys

zGo To URL

zWAP Settings

1. Connection

~ Add New

~ Add from List

2. Color Scheme

3. Clear Cache

4. Reset all

zGPRS Setting

1. Permanent

2. Needed

STK

Safety

Read carefully the following important safety and regulations

before you use the phone. Failure of obeying these instructions

may lead to suspension of mobile telephone services, or broke

the law. Most of all, it will cause your personal in danger.

Always adhere to the following:

Traffic Safety

Avoid using a hand-held phone while driving. For your safety,

you should park the vehicle before making or answering a call.

Using a hand-free car kit or earpiece is recommended.

Do Not Use in Hospitals

The use of mobile telephones may interfere with the

functionality of some medical devices in the hospital. Check the

law and regulations or posted notices. To avoid

electromagnetic interference (EMI) with medical devices,

please power off your phone when it is necessary.

Do Not Use in Airplanes

The use of mobile phones in an aircraft may disrupt radio

transmissions and signals. This, therefore, can be dangerous to

the operation of the aircraft. Be sure to turn off your mobile

phone when on board an aircraft. It is recommended to detach

the battery pack from the handset to prevent accidentally

turning on the phone by miss-touching the power key.

Do Not Use in Gasoline Stations

It is advisable that users switch off their mobile phones when

refueling is in process. It is dangerous that any spark may

cause an explosion or fire.

Safety

Do Not Use in Explosive Sites

The use of mobile phones should be restricted in potential

explosive atmosphere sites such as chemical plants, fuel

storage, or the area where blasting operations are in process.

Operating Environment

Mobile radio transmitting equipment, including mobile phones,

may be subject to interference and may cause danger.

Therefore, it is recommended that you follow any special

regulations in any area. Switch off your mobile phone whenever

the use is forbidden.

Standard Usage

For the satisfactory operation of the mobile phone, it should be

used in a normal operating position. Do not touch the antenna

while making a call.

Accessories

This phone can only be connected to approved accessories and

batteries. Do not connect the phone to incompatible products.

Appropriate Maintenance

Only qualified and authorized personnel should service the

mobile phone. Faulty installation or repair may be hazardous.

Emergency Calls (SOS)

An emergency call “112” can be made from the mobile phone

under any circumstances, and even the phone is locked. When

making an emergency call, you must be sure to give all the

necessary information, such as your name, your mobile phone

number, the location and the crisis situation, as accurately as

Safety

possible. In order to deliver the sufficient information to a rescue

institute, do not disconnect your phone immediately.

Use with proper care to reduce

electromagnetic interference (EMI)

This product has passed the inspection of the

Directorate-General of Telecommunications, Ministry of

Transportation and Communication, with a tested SAR value at

0.737W/Kg, maxi; which is lower than the standard value at

1.6W/Kg, maxi. Mobile phones generate high frequency energy,

electromagnetic wave, before connection; therefore, in order to

avoid EMI impact on human body, we strongly recommend you

to listen to the phone after the line is connected.

Getting Started

Phone Overview

Warning: Please do not detach any parts and only use

manufacturer original component to keep the quality call phone.

Getting Started

Installation & Removing

Installing the battery

1. Press the lock on the bottom and then slide the battery cover

backward and lift up battery cover.

2. Hold the battery and wedge it under two up corners. Press

the battery pack into place. Make sure that golden connectors

are facing the connector on the phone. As shown below

figures (1) and (2).

3. Place the cover into the track and slide it forward and lock

with cover latch. As shown below figures (3) and (4).

Removing the battery

1. Turn phone off and repeat the above item 1 to open the

battery cover. Figure (1) and (2)

2. Lift up the bottom of the battery pack and pull battery by

sliding backward to detach the battery from phone. Figure (3)

and (4).

3. Repeat above item 3 to recover the battery cover.

Getting Started

Important! : Risk of explosion if battery is replaced

by an incorrect type.

Installing the SIM Card

1. Power off the phone and remove the battery. Make the

SIM card golden contact points face downward and the

oblique-angle edge align to up left.

2. Hold the SIM around 30° into SIM card slot and slight push

the SIM card bottom into the SIM card holder. Place the

card inside the SIM holder completely and make sure the

SIM latch fixes SIM card.

Removing the SIM Card

Power off the phone and remove the battery. Press down the

SIM latch and slide SIM upward to remove SIM from holder and

slot as shown in the figure.

Getting Started

Connecting the Charger

To connect the travel charger to the mobile phone, you should

install the battery first. Follow the travel charger instruction, and

plug the connector with the ∩ sigh upside into mobile phone.

See below figure.

Note:

1. Do not remove your battery or SIM card while charging.

2. Use a compatible or appropriate charger for the phone.

3. Manipulate the charger carefully, the connector might be

damage easy.

Getting Started

Removing the Charger

When removing the charger from battery, disconnect the plug

from the electrical outlet. Press the release buttons on two

sides of the connector simultaneously and pull out the

connector from mobile phone.

Keypad Description

Button Description

Affirmative inputs: OK, Select, Call, save

and Reply.

Negative inputs: End, No, Cancel, Abort,

Quit.

Press this button to enter camera mode.

Press this key to dial out a call.

For wording input, press this button to enter

edit mode and input menu on page 39.

In the field of phone number, press this

button to access phone number of

Phonebook immediately.

End a call. Press it to delete numerals or

text from right to left. Press and hold this key

to turn off your phone.

Push keys to scroll up, down, left and right

for entering function menus, submenus and

setup selections.

Enter the phone address book

The symbol of numerals and letters.

Keypads 1~7 are set as hotkeys; refer to

hotke

setu

instructions for details. See

Getting Started

Button Description

page 63 for reference.

Push and hold this key for 2 seconds to

launch voice box function. Enter the voice

box number (general 3 digits) of your

service provider before using for the first

time.

Push and hold it for 2 seconds to turn on/off

vibration. The “+” will be automatically turn

to an international dial-up code. If you are in

Taiwan, “+” represents the international

dial-up code “002”.

Press and hold it for 2 seconds to launch

Voice Dial function as a hotkey. See page

38 Voice Dial for details.

First, enter phonebook address number (1

to 3 digits). After press this key, “#” sign will

be shown on the screen and turn into phone

number; and press the key to dial out

this call as the other quick way to making a

call.

Press this button to switch English letter

between upper and lower case.

Adjust volume during a call.

For camera, up key is for shooting the

picture and down key is for exiting the self

shooting, when the cover is folder.

Alphanumeric Mapping

Getting Started

The alphabetical and numerical keypad mapping relations are

listed on the following table:

Upper Case

Mode

Lower Case Mode

1 Space / | \ ( )[ ]{} 1 Space / | \( )[ ]{} 1

2 A B C 2 Ä Å Æ ç a b c 2 ä å à æ ç

3 D E F 3 É d e f 3 é è

4 G H I 4 g h i 4 ì

5 J K L 5 J k l 5

6 MNO6ÑÖ m n o 6 ñ ö ò

7 P Q R S 7 β p q r s 7 β

8 T U V 8 Ü t u v 8 ü ù

9 W X Y Z 9 w x y z 9

0 Space + - * / ( ) 0 Space + - * / ( ) 0

Note:

1. Press button to switch between upper and lower

case letters. Press and hold over 2 seconds, the

symbol can be switched on.

Getting Started

2. By pressing and holding , you can exchange the input

mode among Chinese input, English input, and numeric

key input.

3. Pressing a number key in the editing mode will result in the

character appeared on the display.

4. Press again the button immediately after releasing, and it

goes to the next character in sequence as above table.

Switching characters will depend upon the duration of the

key press.

5. After releasing the button and wait for a second, the cursor

will move to next spot for new input.

6. If there are any differences between the character sets

listed in the table and on the phone, please refer to the

displayed characters on the phone.

Display Indicators.

Indicator Description

The battery level indicator. The more the battery

cell is, the stronger the battery is charged. The

battery cell flashes right and left when charging,

until it is full.

The earpiece has been inserted and used.

Indicates that the phone is using a roaming

network.

The vibration function is on.

The mute function is activated.

Both mute and vibration functions are activated.

Alarm is activated.

Getting Started

Indicator Description

New message is in mailbox.

Messages are full of inbox.

Shows the signal strength of network connection at

your current location. The more the bar is, the

stronger the signal is received. (The total is four

cell.)

Shows that the data transmission cord has been

inserted.

New MMS message is in mailbox

All MMS messages are full of inbox.

Download the MMS message

Upload the MMS message

GPRS connecting

Basic Operation

Making a Call

1. Power off the phone and install your SIM card.

2. If the battery is out of power, you can still connect to your

travel charger and use the phone normally.

3. Press to turn on. If the display indicates “Enter PIN”,

key in the PIN number of your SIM card, (please refer to the

Manual provided by the telecommunication company for details)

and press .

4. Key in the area code and telephone number, and press

to dial the number.

The SIM Card

Your telecommunication company provides the SIM card.

Please use a small SIM card to fit the design of this phone. For

the SIM installation, please refer to page 27. This phone can

be used only with legally issued SIM cards and can receive or

send the calls only within the SIM network service range.

Battery and Charger

The Li-ion battery that comes with this phone is rechargeable.

Please use the charger and the battery provided by the original

manufacturer to ensure a long lifetime for the cellular phone.

1. Plug the charger into an appropriate outlet that meets the

requirements of this phone. The other end is connected to

the phone. While the phone is recharging, the screen will

automatically display the current power recharge status of

the battery via a flashing signal. The phone can still function

normally if it is turned on while being recharged. Once the

recharging process is finished, the flashing signal will stop.

2. Once the recharging process is completed, the charger can

be disconnected from the phone and electrical outlet.

Basic Operation

3. Use only chargers certified by the original mobile phone

manufacturer. This is an international charger (Model:

KWS05x 13, x is subject to change in different countries).

Read instructions on the charger label before use.

4. A ‘battery low’ message will be displayed on the screen to

alert you of battery low condition. The mobile phone will

automatically shut down when the battery is exceptionally

low.

5. If the battery is totally out of power, the battery requires to be

recharged at least ten minutes. Otherwise, it might have

difficulty to turn on.

Turning on the Phone

To turn the phone on, hold the key for about 2~3 second.

If the message “Enter PIN1:” shows on the screen, the preset

“PIN1:” code of the SIM card must be keyed in (please refer to

the Manual provided by the telecommunication company for

details). Then, press the key.

PIN and PIN2 (4 to 8 digits)

A PIN (Personal Identification Number) code is stored in your

SIM card and is supplied by your SIM card network provider.

To prevent unauthorized use, your PIN1 code will be required

every time while you turn on your phone. Key-in the correct

PIN1 code and press .

Important! :

1. If a wrong PIN code is entered three

consecutive times, the phone becomes

locked or disabled. You must ask for your

network provider to use the PUK code to

unlock or enable the phone again.

2. PIN2 code is for other functions, such as

certain number dialing and barring.

PUK1 and PUK2 (8 digits)

Basic Operation

To enable a locked PIN code, the PUK (Personal Unblocking

Key) code is required. Check with your network provider for the

code. After getting the PUK1 code and unlocking the PIN1, you

can reset your PIN1.

Calling

Enter the area code and phone number, the press button

to dial out a call.

Dialing Emergency Numbers

1. Please turn the power on first. Most networks allow users to

make emergency calls without inserting a SIM card.

2. Enter an emergency number 112;

3. In the case of no SIM card, you’ll see the indicator on

the down-left corner after turning on your phone.

4. Press or to complete the call.

Changing an Entry

Pressing the will delete the last letter or number keyed

which you entered.

Answering a Call

your phone rings or/and vibrates when receiving a call. Press

to answer the call. Press to end the call. If you are

using an earpiece, you can press the button of the earpiece to

answer or terminate the call.

Recent Calls

The phone will record all the recent calls in which you received,

dial out, and unanswered calls. After pressing to enter

Basic Operation

menu and to select submenu “Call List”, you can find out

all recent calls. The recent calls can accommodate up to 30

numbers. Press either button to browse numbers and

select a number to dial out by pressing button. There are

five choices you can select. They are “Call”, “Edit Phonebook”

and “Remove”.

Speed Dial

You may quickly search a number stored in SIM card by

entering the address (1-3 digits) of a certain phone. Every

phone number comes with an address number in phone book.

Under standby mode, you can press button to get a “#”

sign on the screen and type in the address of the phone number

which you want to dial after the “#” sign. Then, press

button to dial a call.

Holding a Call

Pressing allows you to put the on-line call on hold while

you make another call. When the second call is connected,

pressing or allows you to switch between these two

calls.

Basic Operation

Multi-party Calls

1. If, while talking to a party, you would like a third party to

join the conversation, press the key and dial the

number of the third party. Once the call goes through,

press and to conduct a three-party call.

2. If you would like to talk to a fourth party, repeat step one to

conduct a four-party call. (This system allows a maximum

6-party call.)

3. If you want to end the connection with any one of the

parties during a multi-party call, you can follow the steps

as below:

(1). Press

(2). Press the sequence number in which the party joined

the conversation. (For example, the sequence number of

the first call is 1 and the one of the second call is 2)

(3). After pressing , the party now can leave this

multi-party conversation.

Important! :

Before you make a multi-party call, make

sure you do not have a call on hold.

Voice-activated Dialing

Steps for using voice-activated dialing：

1. Store phone data in the phone book.

2. To set up voice calling function:

In the phone book menu, select the number and enter Edit

mode. Use to switch each field. In the voice-dial filed,

press and to create a new record of voice. The

message “Say Name After Beep” prompts up on the screen.

Follow the instructions and voice the name, in which you

want to save, to microphone. After first time input, the system

Basic Operation

will play back it for you to recognize the voice. With your

confirmation, the system will request you to input the second

time. If the voice-activated name is already used in the phone

book, then repeat the above procedure and recreate it. After

done, press to Modify, Play and Delete.

3. Using the voice dialing：

(1). Press and hold key for two seconds when the

screen is on.

(2). After the beep, voice the name for the number you want

to call, into the phone.

(3). The mobile phone will play the sample first. After your

confirmation, the number will be dialed.

Method of Input

Only under edit mode, you can input the content by various

methods. This mobile phone has three fields for edit; that is;

name field of Phonebook, content of Message, and Note of

Personal Info. Manager. After enter these three items, press

to enter edit mode. According to the setup of language,

you can have default setting of input method in your own

language. However, if you want to change to other methods,

press to enter submenu. For characters input, you can

have T9 English, ABC(English), 123 (numeric), Symbols,

BoPoMoFo (phonetic symbols with Chinese characters), and

Stroke for Traditional Chinese. By using up and down to

select the input method you want. Then, press to confirm.

No matter that T9 English or ABC English methods, press

turn on function for upper case and lower case。By pressing and

holding , you can switch to Symbols. By pressing and

holding , you can switch among Chinese, English, and

Numeric methods.

Basic Operation

1. T9 English

While inputting, you can only press the button of letter without

selecting particular one. The T9 English will smartly detect what

you want for written wording. Switch upper case and lower

case by press ; for example, you can have upper case of

first letter 『Eng』, or all in upper case 『ENG』, or all in lower

case 『eng』by switching and pressing numeric button

『123』.

Example：Smart

Button pressed as follows as below：

Æ press onceÆ press once Æ

press once Æ press once Æ press once

Only six steps to have a word “Smart” completely. After keying

in 7、6、2、7、8, two words can be selected. One is Smart and

the other is Roast. Press to select the wording such as

“Roast”. Use to deselect the yellow highlight. If you

want to re-highlight the whole wording, press to recover it.

For adding a space，press 。 Press and Hold

over 2 seconds, then Symbols input will be allowed you to

enter.

2. BoPoMoFo (Phonetic method)

(1). Phonetic characters and keypads list

Keypad Phonetic Keypad Phonetic

Basic Operation

characters characters

0 □ˊˇˋ 6 ㄔㄘㄧㄣ

1 ㄅㄉㄚ 7 ㄇㄋㄜ

2 ㄍㄐㄞ 8 ㄏㄒㄠㄡ

3 ㄓㄗㄢㄦ 9 ㄕㄙㄨㄤ

4 ㄆㄊㄛㄏ＊ㄈㄌㄝ

5 ㄎㄑㄟ＃ㄩㄖㄥ

(2). How to use

(a). Input phonetic characters: follow Chinese phonetics

rule to press a numeric button corresponded to the first

character and then press the second. On the screen, you

can‘t find what you want. Go to the second tier by press

to search. After finding the composed characters,

you can key in the third character to come out the word you

need.

(b). Select the tone by pressing .

(c). On the bottom of screen, there are six selections

numeric 1~6 corresponded to Chinese words. Press and Hold

(around 2 seconds) numeric 1~6, the word is selected into the

edit box.

(d). If you can’t find the word on screen, press to go

to second tier.。

Example：Phonetic character of Chinese word ”冗” is ㄖ、ㄨ、

ㄥ、ˇ。

Button pressed as following：

press once Æ press once Æ press once Æ

Basic Operation

press once Æ browseÆ(press once Æ 再按

一次 )press and hold numeric 1。

3. Stroke of Chinese Character

The principle of Chinese stroke is to follow sequence of

handwriting to combine all characters into a Chinese word.

(1). Stroke characters and keypads list:

Keypad Stroke characters Keypad Stroke characters

1 ㄧ (horizontal) 4 ヽ (a dot)

2 丨 (vertical) 5 乛 (a turning stroke )

3 丿 (the falling left

stroke)

6 ？ (un-known)

(2). How to use：

According to sequence of Chinese stroke, press numeric

keypads corresponded with stroke characters as shown as

above table one by one. There are five types of them. That is

horizontal, vertical, the falling left stroke in Chinese character,

dot, a turning stroke in Chinese character, and unknown key. If

you are not sure exact stroke for next, you can just press

numeric 6 for unknown instead.

Example: Stroke of Chinese word ”仁” is 丿、丨、ㄧ、ㄧ.

Button pressed as below:

press once Æ press once Æ press once

Æ press onceÆPress and Hold numeric 1.

Under the bottom selection part, you can find the word you want.

Press and hold numeric key 1~6 to select the word. If you do

not find it, press to browse.

Basic Operation

4. PinYin (Phonetic Method)

When using PinYin phonetic characters, press keypads

corresponded to English phonetic letter. It will automatically

detect and come out a Chinese word.

Example: PinYin of Chinese word ”王” is w、a、n、g。

Button pressed as following:

Press onceÆ Press once Æ Press once Æ

Press once Æ Press onceÆ Press and hold numeric 2。

As the same as other input methods, press and hold numeric

keypad 1~6. Using to browse the second tier. ???

Menu Function

For speedy access with certain options, press to proceed

with XG for internet, SMS, MMS, Audio Profile, Hot Key Setting,

and Soft Key Switch. This mobile phone provides different

features and several options to meet your needs by manipulating

：

Phone Book ……

The phonebook menu lets you save

the names and phone numbers in the

SIM card or in the memory of the

phone, press or twice to

enter this menu. You may also have

Search, Add Entry, Edit, Delete, Copy,

P.Book Setting and Memory Status. This menu will show the

records according to the sort you selected, and the detail window

will show the content of current record. Depended on the

selection of SIM or phone itself, phone memory module has 11

fields, and SIM module has 6 fields. You can use to move

forward and backward to those fields. If you want to get into the

submenu, press button. With inputting completely,

press to enter submenu for selecting save or

discard this record. If there are three sets of phone number,

press , and then press to select the one you want to dial

out.

In search function, the “search name” input window will be

Menu Function

displayed on the screen. After typing in the name that you want

to search for, then press . If the input methods are needed,

press to enter it. When the first letter you typed fits in with

your list, the first one will be highlighted and all matched data will

be listed down. You can use to browser and view the rest

data.

Add Entry

After pressing key to launch the function, items of new

record including memory type SIM/Phone, name, tel. number,

picture, caller groups, voice dial, e-mail, address record number,

and birthday, will be displayed on the screen. Blank is not

allowed in both name and phone fields.

1. The phone will automatically assign a memory location to

store the data on the SIM or phone itself according to your

selection.

2. You will need to enter both the phone number and name, and

no data will be stored if you leave any of these two items in

blank. In the name field, press to enter text entry mode,

and press to enter submenu input methods selection.

See on page 39.

3. Empty filed is not allowed in phone number. Three sets of

phone numbers can be input for handset setting (NVM), and

one phone number is for SIM card setting

4. Picture is appeared when receiving a call. As long as you

store data into phone memory location, it will allow you to

select from Instant Snapshot or Album or Image picture

folders shown on screen. When the selected picture is

locked, enter password to unlock. SIM card has no this

function.

5. You may assign a caller group to a phone number, so that you

can identify it next time when it comes in. There are 7 default

choices accessible by pressing and choosing from

Menu Function

the submenu; that is, Family, VIP, Colleagues, Friend,

Classmates, Business, and None.

6. Move to the field of Voice Dial and press to start this

function to record the voice into your voice record. Refer to

page 38.

7. Enter E-mail address to the field with handset setting (NVM).

By pressing to search, e-mail symbol @ and _

underscore, and ”.” dot can be found and entered into it

8. Normally, the phone will automatically generate an address

number on input field. If you want to assign a memory

address to the data, you may enter the address and the

phone will store the data to the address you assign. However,

if you put it empty, no data can be stored.

9. Enter the birthday and date format will be dd/mm/yyyy.

Edit

This function is for you to modify or edit an existed record. Use

to select the field you want to modify. All fields and items

should be manipulated as the same as above “New function”. In

the Voice Dial field, Modify, Play, and Delete can be selected in

the submenu to record the voice, play and remove the voice from

this field

Delete

Select this function to remove the phone record from your

address book. After launching this function, three selections are

“Delete One”, “Delete All in SIM”, and “Delete All in Phone” in

submenu by press . A message prompt will ask for your

confirmation of this deletion before execute deleting. Press

to save data or to discard.

Menu Function

Copy

You may use this function to copy single or all phone records to

SIM or handset memory at your will. On launching this function,

the system will automatically provide you an available position.

You may also give a designated position to save your data instead

of system assigned number.

P.Book Setting

1. Caller Group

It is for setting a ring tone in corresponsive with a specific

incoming call. After entering into this option, select one of the six

ring tone groups to setup such as Family, VIP, Colleagues,

Friends, Classmates, and Business by keys. Press the

key to enter this option, the key to select the ring tone from

the list, and press to play the tone. Press the key to

switch the selected tone.

2. Sorting

This function is for you to select the way phone number is sorted

in your phone list. You may sort By Pinyin (Chinese Phonetic Alp)

or By Alphabet and save the sort setting into the handset.

3. Display SIM Records

There are two display modes. One is to display the phone

numbers that are restored in handset only. The other is to

display all the phone numbers no matter that are saved in handset

or SIM card. You can switch your screen to show the phone

numbers by handset only or by all at your willing.

Menu Function

Memory

This provides inquiry about the total number of records and the

empty spaces left for the phone records in the current SIM and the

memory of the handset. Also, you can know how many Voice Dial

numbers is in phone list.

At this stage, memory size of SIM is 100 records in total and that

of handset is 500. Voice Dial only is sum up to 20.

Camera.……….

Press to enter camera selections.

Before using the camera, the camera

function can be pre-setup.

After user folders the cover, press and

hold Up button of the volume key

over 2 ~3 seconds, self shoot function is activated and under

shoot mode. Up button is to take the picture, and Down button

is to exit the shoot mode. After shooting and displaying on the

sub LCD screen, press Up button for save the picture into Image

folder (Multimedia/File Manager/Image) or press Down to discard

it.

Shoot

In the shoot mode, press , when the button pressed voice is

heard, the picture is caught on the screen. If want to save the

picture, press . Except for save option, there are more

options such as Save, MMS, Save to Wallpaper, Save to P.Book,

To Album, and Rename. For MMS, refer to page 54.

Menu Function

To Album

After entering this section, to view and browser the picture by

pressing . Press to enter submenu that is including

Open File, Send MMS, Save as Wallpaper, Rename, Delete File,

Delete all File, File Sort, and View. For album functions, the

manipulation will be the same with File Manager on page 71.

Setting

Before using the camera, you can adjust the setting with press

button.

1. Photoflash

You can select whether turn on or off photoflash. When the

photoflash function switch on, the flash discharges for shooting a

picture. The screen displays on the left-top corner.

2. Night Shot Mode

It enables to take dark scenes such as night view. You can press

to turn on or turn off this function. When this function is on,

there is an indicator on the left-top corner of the screen.

3. Add Frame

According to the shooting scene, there are ten sets of frame can

be added into your picture. The function can be on or off. Use

to switch different frames.

4. Special Mode

Except for normal format, you can set up special mode including

Embossment, Negative Film, Sketch, oil Painting, Black & White,

Menu Function

and Sepia.

5. Continuous Mode

When Continuous Mode is activated on the screen, nine

pictures will be taken continuously after pressing this button .

The interval time can be proceeded to setup as 2 Sec, 4 Sec and 8

Sec by pressing . After these 9 pictures are shot, the 9

pictures can be displayed on the screens at the same time.

6. Sub LCD

On the Sub LCD, display the photo.

7. Sound Effect

When set to activate, the sound effect will come with it.

8. Advanced

For proceeding more advanced setting, special mode, timekeeper,

continuous mode and add text to the picture.

~ Info Display

When setting with certain functions，the symbol will be display on

the screen such as 、、、，and etc.

~ Softkey Switch

Enable or disable the cue button for and whether be

shown on left and right corners of the screen.

~ Timekeeper

This function can be on or off. When this function is activated,

there is an indicator on the screen. After the button is

pressed, the second count will be displayed on the screen and the

picture will be taken after 9 seconds.

~ Set Size

The numbers of recorded pixels are from large size 352X288,

smallest size 60X80 and middle 128X160. Selecting a small

size can reduce the memory stored space. This is very useful

Menu Function

for attaching image in MMS to deliver. Normal display will be

128X160 format on screen. 352X288 and 60X80 would be

shown as abnormal format on the screen.

~ Add Date

Press to activate this function to show the date on the image

file.

~ Add Text

Turn Enable/Disabled

The function can be on or off.

Turn Enable/Disabled

The function can be on or off.

 Set Position

The text can be indicated at the position Top, or Middle or Bottom.

Set Color

Press to enter palette and select color by pressing .

Input Content

After moving the cursor into text input field, press to enter

edit mode. Refer to page 39 for Input Mode.

~ Set File Name

Pre-define the image file name. Press to enter dialogue

box and press to enter edit mode. Press one more

time to use Input Mode on page 39.

Menu Function

Messages…….……

The phone allows you to send and edit

Short Messages (SMS). Whenever you

receive a text or voice message, an

indicator will appear on the display. The

messages might have problems to deliver

between different network services.

Please contact with your service provider.

SMS

Selecting this menu allows you to input a phone number you

would like to send, together with a message. After editing, press

to enter submenu for Send, Send & Store, Send & Save to

Pre-Message, and Store. Send function can deliver out the

message, and Send & Store can complete both delivering and

saving. Store function only save the message into the SIM card.

Currently, handset memory is not supported to store messages.

1. Write

Under Write item, press button to enter content edit mode

as well as press button again, you can have Input Mode,

Pre-Message, Bitmap, Animation, and sound in the message

content to send.

If you want to add text, pre-message, picture, animation, or sound,

use keys to move on selected items such as picture, and

then press to confirm.

For text input method, refer to page 39 for detail.

After confirming OK by pressing , in the field of phone

number, you can press key to enter phonebook and search

the number directly.

2. Inbox

Menu Function

After launching the Inbox, details of all messages stored in the

SIM will be displayed on the screen. Details include the name,

phone number of the sender, and the sending time of message.

All unread messages will be indicated by an envelope sign “”.

Press the key to select and display a message on the

screen. If the content of message is too large, you can press

keys to browse message. Also, press key to enter the

submenu including Delete, Forward, Reply, Call and Store. The

Delete function can erase the record of message in the SIM card;

the Forward function can forward a message to other people; the

Reply function can reply to the sender of the message; The Call

function will allow you to dial out the phone number directly and

the Store function can save the phone of message to the SIM card

or handset.

3. Outbox

Same functions as above.

4. Delete

This menu provides the same interface to operate as described in

the Read menu, with the exception of the key denoting a

delete confirm dialog. Or, you can select “Delete All” at the

bottom of list, and it will allow you to delete all the files after

confirming deletion. Both messages of Inbox and Outbox can be

deleted.

5. Free Count

This menu tells you the total messages stored on the SIM card

and how much free memory space is available on the SIM card.

For this handset, it allows you to keep 50 messages in SIM card

space.

Important! : When size of the message is too large and over a

regular store space, this message might be identified as two or

three, or even over three. Therefore, the free space in reality will

be less than that displayed on the screen.

6. Setting

Menu Function

The following items can be setup:

~ Pre-Message

This menu allows you to set up eight sets of user pre-define text in

a prompt window of Pre-Message. On the indicated items,

press to have the input window to key in pre-message text

and press again to save it.

~ SMS Center

This menu item allows you to enter SMS center phone number.

Messages will be sent to and received from other users through

exchange center of the network’s message service, although this

service may not necessarily be supported by your network.

~ Valid Time

This menu allows you to specify the time in which your messages

are going to be stored at the message service center or network

service. You can select between numbers of predefined periods. If,

however, nothing is selected the phone will automatically choose

a sensible default value for you.

~ Auto Display

The menu controls actions when incoming messages come in. If it

is switched on, you have the option to read the message

immediately. If it is switched off, you are notified on the display by

a “” indicator.

~ Status Report

When sending out a message, the receiver will return a receipt to

SMS and SMS will forward it back to sender.

MMS

MMS allows you to send messages that content with pictures,

animation, and sound to other cellular phone or email account.

The message will be presented as slides that include text,

pictures, animation and sound. The mobile phone enables to send

a Multi-Media message with maximum 40KB at a time. For the

size to store text, image, and audio file, there are 5MB in total.

This function is provided by telecommunication company. Please

Menu Function

contact you supplier.

1. Write

You can set up your personal MMS template under edit function.

After entering the function, press to enter edit mode to enter

T9 English, ABC, Symbols, Numbers, emotional expression

symbol and . Press to switch different input method, and

press to confirm. Refer to page 39 for input methods.

Important! :

If the message “MMS Connection Not Set” is

displayed on the screen, please set with

MMS Setting Æ ConnectionÆAdd from list,

and then select the MMS company you

used.

~ New

If you want to add picture, animation, or sound, use keys to

move on selected item such as picture, and then press to

go back to antecedent menu. On text field, you can press

and press keys to select the template you want to edit. After

enter the edit mode, follow above edit instruction to edit contents.

To add image, press keys to select the pictures you would

like to send.

To add sound, press keys to select the sound file.

Menu Function

To add new slides, press to move to new slide “+”, then

press button to confirm and enter to next slide.

You can press button to exit edit mode. You can choose to

save message as a draft or quit without save it.

Menu of MMS include:

Send Message

press to send message. Then press to enter the

phone number or email address that you would like to send to.

The screen will pop up a message “Send this 1K message?” If

you want to cancel sending this message press . If you want

to send the message, press to enter phone number or email

address from phonebook. With accessing the phonebook, press

to enter it. Sending to multiple addresses, a space is

required to separate different addresses. Please refer to page 39

for input detail.

After complete the edit, pressing to enter menu section.

Press keys to select 1. Send MMS, 2.Send Email, 3. Cancel

Send, 4 Advanced. After the item is selected, press to

confirm the selection.

Under advanced setting, press to select the item that you

want to perform and then press or to confirm your

setting and go back to upper menu. Advanced setting include:

a. Delivery Timing:

Delivery Timing allows you to set date and time to send the

message. The valid time depend on the setting of email server.

You can set Maximum, 30 minutes, One hour, Six hours, One day,

One week.

b. Message Title: press button to enter edit mode. Press

to start editing. For Method of input, refer to page 39.

c. Priority Class：

You can set message priority and class. Message priority include:

Menu Function

Low, Normal, and High priority. Message class include Personal,

Advertisement, and Informational

d. Cc and Bcc

Press keys to move to Cc field or Bcc Field to add numbers

or email addresses from phonebook. Press to enter edit

mode, press to input text to the field.

Please refer to method of input on page 39.

Visibility Options:

This function allows you to preview the content of message before

send it out.

Save

You can save the content of message as a draft and modify the

draft anytime at your will. Or you can save the content of message

as a template.

Setting

Entering setting section, you may press keys to select

1.Slide Duration and 2. Slide Format, then press to confirm

your setting.

a. Slide Duration is the display duration of every MMS slide.

b. Slide Format allows you to set how the image to be displayed

on the screen. There are 4 formats: Image Bottom, Image Top,

Image Left, and Image Right.

Add Slide

Delete Slide

~ From Template

Select the name of template and press button to open or

delete it. If no template in memory, it shows empty template.

2. Inbox

Menu Function

All incoming MMS messages will be saved into Inbox. Same as

regular messages, the system will also lists the information of

sender, so you would know the MMS is sent by which mobile

phone number or email account. The format and method of

receiving MMS are depend on the service that provide by your

service provider.

3. Outbox

When a MMS is sent, if the receiver’s mobile phone does not

support MMS function, a SMS (short message) will be sent to your

mobile phone to inform you. You may also connect to the internet

via WAP function for sending and receiving MMS.

4. Draft

You may save the incomplete messages as a draft, and go back

to modify it anytime at your will.

5. Sent

Users may also save all sent messages. When a message is

sent successfully, it will be saved under the folder of Sent

6. Templates

Select the name of template and press button to open or

delete it. If no template in memory, it shows empty template.

7. MMS Setting

You can use this function to set up the connection for receiving

MMS.

~ Connection

Add New:

Allow you to add a new connection, please refer to page 85.

WAP connection set up.

Add from list

There are 5 items under this list that include: 中華 MMS、台哥大

MMS、遠傳 MMS、泛亞 MMS、東信 MMS。 Press button after

Menu Function

select the telecommunication company, a new connection is set

up and lists on your connection menu.

~ Reception

Always

Home PLMN on

Never

~ Message Validity

1 Hour

6 Hours

1 Day

3 Days

1 Week

Maximum

~ Allow Adverts

Allow you to turn on or turn off the advertisement function.

~ Save Sent Msgs

Allow you to automatically turn on or turn off to save the

messages that are sent.

Broadcast

The Broadcast function is to send the message to all users in a

certain region via the telecommunication network. This function is

provided by telecommunication company. Please contact you

supplier.

1. Read

This allows you to read the last broadcast message received. The

phone stores this last message only when it is switched on.

Menu Function

2. Filter

This allows you to select the type of cell broadcast message you

want to receive. The filter menu contains a list of codes for CB

type of messages, which are defined by the network service.

~ All

Receive all broadcast messages.

~ None

Receive no messages.

~ List

List all the channels in which you want the messages to be

received. Depended on different broadcast area, the number of

the channel will be different. By pressing the key, you can

enter selection menu to add or delete.

3. Auto Display

This allows you to switch the auto display function on/off. When

the function is set on, broadcast messages will automatically be

displayed. Using the arrow keys allows you to scroll the

messages. Pressing OK or NO allows you to exit. Broadcast

messages automatically disappear after a short period of time.

(Note: The function requires the support by telecommunication

network service. Contact you telecommunication service

provider if you want to use this service.)

Voice Mail

1. Call V-mail

This menu allows you to enter your voice mailbox and listen to

calls. (You need to set the number of your mailbox before you use

this function.)

Important! : You can also enter your voice mailbox

by pressing in the idle mode.

2. Voice Mail#

Enter you voice mail dial-in number which is always provided by

Menu Function

mobile phone company.

Audio Profiles…

There are 6 profiles (Typical, Silent,

Outdoor, Handsfree, Meeting, and

Customer) to meet your different needs.

After selecting a suitable profile, push

Activate to enable profile. If you want to

personalize the profile, launch the Adjust

menu and select the item you want to personalize.

Adjust

You can change the setting of the follow profiles with this function.

1. Activate

Activate all settings under the selected profile.

2. Ringtone and Volume

Using the keys allows you to select the ringing tone pattern.

When the tone is selected and is played, you can set up the

volume of tone at the same time. There are 36 different ringing

tones or melodies for your selection.

3. Key Sound

You can set on/off the volume of the keypad tones. They are

DTMF, Silent, Normal, Parrot Tone 1.

4. Crescendo

In this menu, the ring tone is adjusted to ascending. It can be

turn on or off.

Menu Function

5. SMS Rec Tone

When receiving SMS message, the phone will alert you with ring.

You can select to turn it on or off.

6. Vibrator

You may switch on/off the vibrator. This feature depends on which

model you are using.

7. Service Tone

When this function is set on, the phone will generate a tone when

a network is available.

8. Auto Answer

Under this menu selection, you may enable or disable the auto

receiving function for incoming calls while you are using an

earpiece.

9. Rename

On the selected file, enter dialogue box to rename the file name.

Under the edit mode, press to enter Input Mode on page 39.

Settings …………….

Your phone offers many options, making

it your best partner.

Personal

1. Language

You may select the display language in this menu. There are

English, and T-Chinese.

2. Greetings

Menu Function

You may enter greeting words in the edit window so that the

phone will display greetings each time you turn it on.

3. Power On/Off Melody

You may select the melody that will play each time you turn the

phone on.

4. Folder On/Off Melody

Reset shortcut keys have the following functions:

Long Key 1

5. Hot Key Setting

Reset shortcut keys have the following functions:

Long Key 1 is predefined as Call Voice Mail Box.

2. Messages ------------------ Long Key 2

3. Silent ----------------------- Long Key 3

4. Show Clock ------------------- Long Key 4

5. Calendar -------------- Long Key 5

6. Calculator ------------------ Long Key 6

7. Record ----------------- Long Key 7

8. Image ----------------- Long Key 8

9. Standby Mode ----------------- Long Key 9

This function allows you to press a designated key for 2 seconds,

while in idle mode, to activate a function.

If users want to change the programming of shortcut keys, please

follow the procedures described below:

a. Enter the menu. Use to select the numeric key to be used

for setting. Press to confirm.

b. Then use again to choose the function to be set. Press

to confirm.

Menu Function

6. Own Number

You may store the SIM number in the phone.

Clock

You may set time, date, alarm and auto on with the clock setting

function.

1. Set Date

After launching the menu, push the keys arrow to select

setting date, time, data format and time format. If you select

12-hour system, the cursor will stop at AM/PM, push the

arrow keys to select AM/PM. You may push the arrow

keys to select date and time formats.

Available date formats: yy/ mm/ dd or dd/ mm/ yy or mm/ dd/ yy.

Available time formats: 24-hour or 12-hour

2. Set Alarm

It provides a set of alarm ring tone. The user may set the date,

time, melody, and note of the alarm by using .

You may select three different modes: Disabled, Once, and

Repeat.

3. Power Off

In this menu, you may set the function and the time of turning off

your handset daily.

Screen

1. Standby mode

There are 3 standby screen modes: picture and text, clock, digital

clock and calendar.

Menu Function

2. Color Theme

You may adjust the color background, and wording for the

subjects of menu functions.

3. Network Name

You can decide whether display the name of the networking

phone company on the screen.

4. Show Clock

Set “show clock” to display time and date on the screen.

5. Standby LED

After this Standby LED function is enabled, the standby flash will

be around 5 Sec to discharge interval.

6. Sub LCD Sleep Time

Allow you to set up the time to enter sleep mode. When over 5

sec or 10 sec, or 30 sec, or 1min on standby mode, the sub LCD

will enter sleep mode.

Call Setting

1. Call Waiting

You may set the call waiting function on and off in this menu.

~ Activate

After you have set the call waiting to Activate, you will be alerted

by audio and video signals when another call is coming in while

you are making a call.

~ Cancel

If you set this function to Cancel, the phone will not alert you of

another incoming call but directly divert that call to other number

or your voice mailbox.

Menu Function

~ Status

It reports current status for Activate or Cancel

2. Divert

Call divert is a common telecommunication service, when you are

unable to answer a call or the signal is out of service range, you

can divert all incoming calls to another number.

~ Forward to

Set the number you want your calls be diverted to and the Delay

before divert (default is 15 seconds). When a call comes in, the

phone will divert the call to the preset number after the delay time.

~ Unreachable

Set “divert when not reached” function on or off.

~ If No Reply

Set ‘divert if not answered’ function on or off.

~ All Calls

Set ‘divert all calls’ on or off.

~ If Busy

Set ‘divert when busy’ function to on or off.

~ Status

Get status of all divert functions.

~ Cancel All

The function of this option will cancel the setting for diverting all

incoming calls.

3. Answer Mode

Press any key to receive the incoming call when this function is

enabled.

~ Normal answer

Press to answer when this function is enabled.

~ Any key answer

Press any key to receive the incoming call.

~ Folder answer

Menu Function

Open folder to answer incoming call.

4. Present Number

This option sets the handset to show or not to show its phone

number when dialing out a call.

Network

This menu allows you to select and register with the network

that you want the phone to use.

1. Select Method

When the phone is switched on, it looks for available networks

and then selects one of them. You can also manually select the

desired network from the list.

2. New Search

You can search available networks and manually select one of

them.

3. Select Sequence

You can add the networks by manually. Enter the Country Code

and Network Code to add the new network into the list.

Security

1. Bar Calls

Call barring is a telecommunication network function to enable

users to bar both incoming and outgoing calls in different

conditions. Enter the Supplementary Services Password

(obtainable from service provider) before setting up call barring.

Please set mailbox to OFF before applying call barring.

~ All Out

You may bar all out calls (except emergency call) with this

function.

Menu Function

~ Out Intl

You may bar all out international calls with this function.

~ Out X Home

You may bar all out international calls during roaming except calls

to home country.

~ All In

You may bar all ingoing calls with this function.

~ In If Abr

You may bar all ingoing calls (roaming) when you are abroad with

this function.

~ Status

You may check the status of call barring with this function.

~ Cancel All

You may cancel all barrings this function.

Note: The availability of barring services is subject to the

network functions.

2. PIN Check

This function provides you with two options. One is to make PIN

Enable, and the other is to make PIN Disable.

3. PIN Change

Make sure that you have PIN enabled. When you switch the

power on, the phone will prompt you to input the PIN number.

4. PIN2 Change

Changes the PIN2 number. You need to input the original PIN2

number before you make changes. (Please contact your

telecommunication company for detail.)

5. Fixed Numbers

This function only dials the numbers in the fixed dialing

phonebook. (It needs the PIN2 number).

6. SIM Lock

Menu Function

This function allows you to lock the phone with a specific SIM card.

This feature is designed to prevent somebody else from using

your lost or stolen SIM card(s).

~ Set Lock

To activate the SIM lock function.

~ Change PCK

This allows you to change PCK code.

Note: The factory default PCK is supported by the

manufacturer is (0000).

Reset Setting

After entering into this option, you may select whether or not to

convert the settings of your handset to the reset settings.

Call Lists.……….

This menu records the charges and the

length of time or duration of all incoming

and outgoing calls in hours, minutes,

and seconds. Please contact with your

telecommunication company for

providing charge information.

Missed Call

After entering this menu selection, the screen will display all the

missed call. You can use select one of records, press

to call, move to phonebook into your SIM or handset memory for

save and remove.

Launching the menu and listing all the missed call. One more

function is listed on the manual “Delete All” records of call lists.

Menu Function

Incoming

List all of answered calls. The functions are the same with above.

Outgoing

List all of dial-out calls. The function is the same with above.

Call Info

This menu records the charges and the length of time or duration

of all incoming and outgoing calls in hours, minutes, and seconds.

1. Last Call

This displays the duration of the last call.

2. Total Calls

This displays the total duration of all incoming and outgoing calls.

3. 1-minute Beep

This sends you a warning beep every minute, while a call is in

progress.

4. Charge Info

This function allows you to calculate telephone fee to facilitate

cost control.

Note : This function including Total Charge, Max Charge and

Unit Price will be supported by telecommunication service

provider. Please contact with your supplier for detail.

~ Total Charge

This displays the total charge of all calls. Pressing allows

you to reset the value, but it requires entering PIN2 before you do.

~ Max Charge

This allows you to set a maximum limit to your total cost. You can’t

dial any number if you go over your limit until the total charge has

Menu Function

been reset. As similar to total charge, you need to enter PIN2 for

setting.

~ Unit Price

This allows you to enter the unit price. After entering your PIN 2

code you can input price and unit. Pressing allows you to

select different entry fields.

Multi Media ……

File Manager

Under file manager menu, Image, Audio,

and OSD frames can be manipulated as

below functions.

~ Open File

On the selected file, press to open it as full screen display.

~ Send MMS

By using to select the file, press to send MMS. Refer

to page 54 for detail.

~ Save as Wallpaper

You can save the file as wallpaper.

~ Save to P.Book

You can save the file as picture displayed when the call is coming.

~ Rename

On the selected file, enter dialogue box to rename the file name.

Under the edit mode, press to enter Input Mode on page 39.

Chinese file name is not supported.

Menu Function

~ Delete

Delete the selected file.

~ Delete all file

~ File Sort

Enables all files sorting.

By Name

By Date

By Type

~ View

List

Press to display selected image.

Icon

Display 9 image files on the screen at the same time.

~ Detail Info.

The detail information will include image type, file name, file date,

and file size.

~ Password

This item only apply to below Album and Image.

Set password

Set the password on the selected picture. Press to enter

the password on the dialogue box. With the repeat typing the

confirm password, press again to complete the setting.

The locker symbol will be displayed on the screen instead of the

picture itself. Note that password is not less than 4 digits. The

password will remain the same unless the password is changed

or unlocked.

Preview all

When the password is set, the pictures are not allowed to preview.

Menu Function

To Album

After the picture is taking by using camera, the saved image file

will be sent to this manageable folder. For album functions, the

manipulation will be the same as File Manager on page 71.


In the phonebook, there are image files will be displayed on the

screen when you review or browse it or when you receive the

calls. Those images will be managed and stored under this

folder.

Audio

Ring tones or download audio file are stored under this folder.

Frame

This folder contains all the frame, Standby mode picture,

background picture、and special mode picture.

Password Setting

~ Modify password

This function allows you to change the password when the

password is set.

~ Password

When locked, it shows that the password protection is activated.

Free Space

This menu tells you the total space stored and how much free

memory space is available.

Menu Function

Game

1. Game

~ Puzzle

Choose your own picture from camera snapshot, last game, or file

manager to start game. By using and to move

empty grid till the whole picture is well compiled. Press left soft

key for viewing the picture and press to exit the game.

Enable the user to turn on or off the game sound.

~ Hostage Salvation

Choose the picture for bad guy from camera snapshot, last game

or file manager to start game. By pressing 1 to 9 numeric keys,

shoot the bad guy and win 10 points for each shoot. In case

innocent figure shot, 5 points is deducted. Total time is 2

minutes. Enable the user to turn on or off the game sound.

~ Reversi

Before starting a game, the sequence order must be selected

(“Play First” or “Player Later”). When the game starts, you can use

and keys to position the black piece. Press to

confirm the surrounding of white piece. When the chessboard is

full of pieces, if there are more blacks than whites, black wins the

game. The game under this section allow you to save and

continue the game without restart over every time. Press to

save your score and pause. Press the same button to

continue the game. You may also save the score and exit the

game by pressing to leave. When you next time enter to

Menu Function

the same game, select stored game to continue the game when

you left last time. Any incoming calls while playing games, you

may press button to answer the call and save the game that

is been played.

~ Coin Elf

Before the game, you can read the help. When the game start,

the coin should be selected on the screen, The money master will

follow the coin to move, the player have to move and lead the

money master to win the treasure. Press to pause the

game,, and use and to move.

Java

Press to enter Java game。 Press with selected game

and then press to start the game。 If you want to stop the

game for a while, you can just press to pause it.。 Press

to enter function menu； By using to select “Info”，you

can review data or version of this game. If selecting “Delete”，

the dialogue will delete the game after confirm. If “Download” is

selected, it will start to download game。For “Exit”，then it will

return to the previous submenu.。If you want to back to main menu,

press 。 Regarding of the rule of Java game, please read

the guide from the download website of Java game.

~ Start Game

PPBall

When the PP ball game is selected，press to enter it，and

press to start. You can select the continuous previous

Menu Function

game, or start the new game. With selecting the new game,

press twice to enter HELP。 There are three balls in the

game. The player owns the red ball. During the game, three

balls will collide each other. By using and ,

remaining your red ball in the chessboard and even colliding other

balls are out of bounds are the winner.

AdvCopter

With selecting AdvCopter game，press to enter，and then

press to start the new game。By using key, select the

New Game, Stage, Ranking or Help. In the game, press any key

to rise the copter, release the key you pressed, the copter will

move down and drop the bomb.

~ Connection

Refer to page 85 for WAP Setting.

Connection

Add from List

Tone Edit

Under this function, you can create your own tone and setup them

as your ring tone under Audio Profile. There are total 5 tones are

allowed you to edit. Press to enter edit mode including

play, edit, reset, tempo, instrument, and name。

1. Play

This section sllows you to display the edited melody from the

mobile phone. Press to exit while playing. Otherwise, the

system will exit until the melody is complete played.

Menu Function

2. Edit

~ Keypad functions

Numeric 1-7 represent the musical notation from Do toSi, 60

notes can be entered.

High octave

Delay in one beat for previous note

A rest

Raise half tone or a dot to extend half beat for previous

note.

One extend (half beat or a quarter beat) and lower.

~ Edit

follow the steps below：

a. Press numeric pads 1~7 to select note. Press to delay in

one beat for previous note, display on screen as”-“. Press

to enter a rest note displayed as”0 “

b. Press to switch into higher octave

c. Press to raise or lower half tone, “#” or “.” is displayed on

screen.

d. Press to switch for long note “-half tone = a quarter tone”

and for lower octave “.” If higher octave is selected, there won’t be

any mark for lower octaves.

e. After a tone is edited, press to shift the cursor to the next

position, and then continue editing the next tone.

f. If the setting is not correct, please move the cursor to the

incorrect symbol to have direct revision or move the cursor to last

the note and press to delete the note and re-enter.

g. Once editing is complete, press to exit. If users want to

Menu Function

restore the original setting, press to cancel the editing.

3. Reset

After confirming to tone reset settings, the defined tone will be

clear.

4. Tempo

There are 5 modes: More slowly, Slowly, Normal, Fast, More fast.

You can select any of the modes to adjust the rhythm.

5. Instrument

Select the instrument to edit the tone including BritePno, Marimba,

Harp, Crystal, and Banjo.

6. Rename

Allow you to enter the name for the tone. Under dialogue box,

press to enter edit mode. For Input methods, refer to page

on page 39.

PIM…..…….…….

Under this function, you can do simple

mathematical calculations and currency

exchanges.

Calcuator

1. When “ 0 ” is shown enter the operational

digits. (press key for decimal point)

2. Choose operational sign: See on the screen

shown + ~addition; shown -~ subtraction, shown

*~ multiplication, and /~division

Menu Function

3. Enter second number.

4. Press or key to get the result. If a mistake is made

during the operation, press key to make a correction.

Holding key for few seconds clears all the digits.

Calendar

You may check your reminders in this menu. First, the current

date will be displayed.

Push the arrow keys to select

date, push to launch calendar menu,

and push to exit menu. You may push

the arrow keys to select a reminder, and then push to

launch the selected reminder menu (View Day Note, Make Note,

Erase Note, View All Notes, Go To Date).

1. View Day Note

Select today’s reminder to view content, and push to edit

or erase content.

2. Make Note

You may select reminder type (reminder, phone, meeting,

Birthday).

Push the arrow keys to select reminder types which

including Meeting, Birthday, Anniversary, and Customize.

Set date:

Menu Function

Set time:

Set alarm: After the time and date of the reminder are keyed

in, press the key to set the alarm for the reminder, and the

key to shut off the alarm of the reminder.

In the reminder field, you can input the memo. Refer to text input

methods on page 39.

3. Erase Note

Select erase types: erase reminders of chosen day, erase one by

one, erase all, and auto delete. In auto delete, there are 3 items;

they are auto del 1 month before, auto del 2 month before, and

auto del 3 month before.

4. View All Notes

While checking all the notes, press to enter the delete,

modify or move data menu option. Press to view the

content of each individual note. If the content is over a page long,

press key to change pages.

5. Go To Date

Enter the date on which you want to receive the reminder.

Exchange Rate

For first time users, push buttons to move cursor to Set Rate

to key in exchange rate for Domestic and Foreign. After setting,

enter the Domestic currency value, the Foreign exchange value

will be automatically calculated on the screen.

Menu Function

Voice Memos

Voice reminder allows users to record a maximum 20-second

audio input. The main advantage of this function is to assist users

in record messages when they do not have a pen and paper at

hand.

1. Record

When users want to record messages, they simply enter this

menu and press the “Record” key to start the recording process.

2. Playback

~ Playback

When users want to play the messages, they simply enter this

menu and press the “Play” key to listen to the recorded message.

If there is a * mark before a certain record, it means the message

has not been played before.

~ Delete One

In this menu, users can delete the saved records individually.

~ Label

When users enter this menu, they can check the time, date and

record length when a certain record was recorded.

3. Options

In this menu, users can select one of the following methods of

recording:

~ Self Only

When this function is on, it can only record the conversation of this

phone content.

~ Other Party Only

When this function is on, it can only record the conversation of the

call content.

~ Both

This function enables users to record directly from the callers and

Menu Function

the content of conversation.

Note: The ‘2-way recording’ (default) will be resumed after

each recording.

When on the line, press to enter record item, and press

to confirm recording.

World clock

After entering into this option, you may press keys to browse

the current time of the place over the world.

~ Set Location

You may set your present location to browse the time in

different countries with the time display function.

Automatic

The mobile phone will automatically set the location for you.

Manual

You may select your own location with the manual setup.

Internet……….

Access WAP

You can use this function to browse

the World Wide Web to get the latest

information. The data will appear in a

special format compatible with your

mobile phone. You might have to

the World Wide Web.

Menu Function

Graphic and Message of Browser

Shows the version of OPENWAVE and Copyrights.

Definition of WAP Keys

Button General Long Key

End WAP

Return to previous page or

clear figures.

Return to previous page or

clear figures.

When input words, use

shift to switch between

capital and small letters.

Call out browser menu

Call out My Favorite

Favorites

You can connect with the Internet immediately by using the

bookmarks.

There are 1-12 my Favorites are set on screen. Browser them

Menu Function

by using . On the selected item, press to access

internet.

Press to select other function such as New Bookmark, New

Folder, Delete all, and Hotkeys.

If there is not existed bookmark within folder, manipulate to

move the cursor to the context, and build new bookmark and

Hotkeys. If the bookmark is existed, then it will display with title,

URL, and folder name that can be modified and saved.

1. New Bookmark

Press numeric key 1, and enter Title and URL to save as a

bookmark. To enter the field of Title, press to enter edit mode

first, and press button to select T9 English, symbol, numbers,

Emotions, and abc input method. You may also press keys to

select a exist Title. When using T9 English and ABC method to

input, you can press to switch upper case and lower case or

first letter capital.

Press to go to the bottom of screen, a Save button appears on

screen, press to save the bookmark; press to go back

to Bookmarks menu.

2. New Folder

Press to enter Folder edit mode. Press numeric key 2 to

create a new folder. After entering edit mode, use the same

input methods as above. After entering complete text, repeat

pressing until a “Save” button shown on screen, press to

save data. Or you can press button to go back to Bookmark

menu.

Menu Function

3. Delete all

Allows you to delete all folders and bookmarks.

4. Hotkeys

There are 1-9 numeric keys enable to be set as hotkeys. If you

wan to assign numeric key 1 as a hotkey for the specific website,

use to move the cursor to “1 Unassigned” and press

button to go to bookmark list. Press to select that specific

website URL. Then press to select the bookmark to

complete the hotkey setting.

Go To URL

This allows you to set up the protocol web site.

WAP Settings

After entering this menu selection, users can program the mobile

phone to search for the SIM card to see if it is equipped with

GPRS function.

1. Connection

You can select one of the six files preset in the menu to connect.

The connection will be made through the chosen file.

~ Add New

Name

Enter the “name” function screen, you can clear the preset file

Menu Function

(press the key), name and rename it.

Homepage

You can reset the homepage by pressing the key to clear

the preset Web address and keying in the new web address

you want.

IP Address

This function allows you to set the IP web address you want to

connect to.

Bearer

Supports both GPRS, and CSD.

User name

This function allows you to set a username to register to the WAP

website. The function need to be supported by your

telecommunication service provider.

Password

Set the password for logging in the WAP website.

DNS IP address.

Set DNS IP address to register to WAP website. The service is

provided by telecommunication company.

Linger Time

Modify Linger Time for connection, press button to enter

Linger Time field. The default setting is 90 seconds. (Unit:

second)

APN

If you select GPRS to browse, you need to input the Access Point

Name of your system service provider.

Security

This function provides the Internet security service, you can select

on or off.

Store

Menu Function

Save all settings.

~ Add from List

中華 WAP

台哥大 WAP

遠傳 WAP

泛亞 WAP

東信 WAP

2. Color Scheme

Color palette will provide three colors: Blue, Red and Green.

3. Clear Cache

This option allows you to clear all data from Cache temporary

memory.

4. Reset all

Select this option to go back to WAP default setting.

GPRS Setting

Two functions under GPRS setting menu:

1. Permanent

2. Needed

STK( SIM TOOLKIT ).

This selection menu can only be displayed if

your SIM card supports Value-added

Menu Function

Services. Regarding the details as to how to use SIM services, as

well as price and other information, please contact your

telecommunication Service Company.

Important :

The STK service is provided by your

telecommunication company. The name of

menu, title, and content are defined by your

telecommunication company. Due to the

content size may be too big to fit into the

screen of your mobile phone, some of text

may not be displayed.

Battery

 The battery is rechargeable up to hundreds of times, but it

capacity will reduce. You may need to replace a new battery

when the operation duration (calling and standing duration)

reduces evidently.

 Remove charger from the source each time after charging.

Over charging will shorten the life of the battery. Avoid

charging a battery for over 24 consecutive hours.

 Use only batteries certified by the mobile phone

manufacturer.

 Extreme temperatures will affect charging performance. The

desirable ambient temperature for charging is 0°C-45°C

(32°F-113°F).

 Do not use damaged or old batteries.

 Avoid contacts of the + and – poles of the battery with metals,

such as coins, scissors, and pens. It will damage or cause

short circuit to the battery. Place spare batteries in a safe

place or wrap them up with insulated materials before putting

inside your pocket or handbags.

 Extreme temperatures will reduce the capacity or shorten the

life of batteries. Avoid placing batteries in extreme

temperatures, such as inside vehicles or near air-conditioner

outlets. The desirable battery storage temperature is

15°C-25°C (59°F-77°F). Batteries that have been charged

may not work properly in extreme temperatures.

 Keep batteries away from water or fire.

 Dispose batteries according to local environmental

regulations.

Care and Maintenance

Follow the instructions below to take care of your mobile phone.

They will help you to enjoy life with this product.

 Keep the mobile phone and its accessories out of children’s

reach.

 Keep the mobile phone dry. Rain, moisture and liquid contain

minerals which will corrode the circuit of the mobile phone.

 Keep the mobile phone away from dirt or dust.

 Keep the mobile phone away from heat. Heat will shorten the

life of electronics, damage the battery, or even deform or

corrode the shell of the mobile phone.

 Keep the mobile phone away from coldness. Condensation

takes place and the moisture will damage the circuit board

when the mobile phone resumes normal temperature.

 Do not open the mobile phone. Non-professional treatment

may cause damage to the mobile phone.

 Avoid falling, impact or vibration of the mobile phone.

Improper external force may damage the circuit of the mobile

phone.

 Do not clean the mobile phone with chemical solutions or

detergents. Gently wipe the shell of the mobile phone with a

soft cotton cloth and clear water or mild soap.

 Use accessories and batteries from the manufacturer.

 Contact your nearest service station if the mobile phone is

out of order. Our well-trained technicians will provide you the

best service.

FCC Regulations

Conditions of Use

Operation of this TG9D mobile phone is subject to the following two

conditions; (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including

interference that may cause undesired operation.

This TG9D mobile phone generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

If this device does cause harmful interference to radio or television

reception, which can be determined by turning the device on and off,

the user is encouraged to try to correct the interference by one or more

of the following measures:

1). Reorient or relocate the receiving antenna.

2). Increase the distance between the device and receiver.

3). Connect the device into an outlet on a circuit different from that to

which the receiver is connected.

4). Consult the dealer or an experienced radio/TV technician for help.

The radiated output power of this internal wireless radio is far below

the FCC radio frequency exposure limits. Nevertheless, the wireless

radio shall be used in such a manner that the radio is 2.5 cm or further

from the human body. However, the user of wireless radios may be

restricted in some places or situations, such as aboard airplanes. If

you are unsure of restrictions, you are encouraged to ask for

authorization before turning on the wireless radio. Several restrictions

and cautions of using mobile phone are listed in the Safety.

FCC RF Exposure Information

Read this information before using your handset

In August 1996 the Federal Communication Commission (FCC) of

the United States with its action in Report and Order FCC 96-326

adopted an updated safety standard for human exposure to radio

frequency (RF) electromagnetic energy emitted by FCC regulated

transmitters. Those guidelines are consistent with the safety

standard previously set by both U.S and international standards

bodies. The design of this phone complies with the FCC guidelines

and these international standards.

Use only the supplied or an approved antenna. Unauthorized

antennas, modifications, or attachments could impair call quality,

damage the phone, or result in violation of FCC regulations.

Do not use the phone with a damaged antenna. If a damaged

antenna comes into contact with the skin, a minor burn may result.

Please contact your local dealer for replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations. To comply

with FCC RF exposure requirements, a minimum separation

distance of 0.6 inches (1.5 cm) must be maintained between the

user’s body and the handset, including the antenna. Third-party

belt-clips, holsters, and similar accessories used by this device

should not contain any metallic components. Body-worn

accessories that do not meet these requirements may not comply

with FCC RF exposure requirements and should be avoided.

For more information about RF exposure, please visit the FCC

website at www.fcc.gov

Compal Electronics TG9D 1900 MHz PCS Band Cellular Phone User Manual Eng Rev 042604

Compal Electronics Inc 1900 MHz PCS Band Cellular Phone Eng Rev 042604

Manual Update

Navigation menu

Namespaces

Views

Navigation
