HP recommends
Windows Vista™ Business
1.
Volume Mute Button with LED
10.
Left Touchpad Button
2.
Volume Down Button
11.
Hard Drive Activity LED
3.
Volume Up Button
12.
Battery Charging LED
4.
Stereo Speakers (2)
13.
Power/Standby LED
5.
Integrated Optical Drive
14.
Wireless On/Off LED
6.
2 USB 2.0 Ports
15.
Touchpad with scroll zone
7.
Microphone Jack
16.
Power Button with LED
8.
Headphone Jack
17.
Wireless On/Off Button with LED
9.
Right Touchpad Button
QuickSpecs
HP Compaq nx7300 Notebook PC
Overview
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 1
1.
Kensington Lock Slot
6.
PC Card Slot
2.
RJ-45 Port (NIC)
7.
PC Card Eject Button
3.
RJ-11 Port (Modem)
8.
VGA/External Monitor Port
4.
IEEE 1394a Port
9.
Power Connector
5.
USB 2.0 Port
At A Glance
Genuine Windows Vista Business 32,
Genuine Windows Vista Home Basic 32,
Genuine Windows XP Professional,
Genuine Windows XP Home Edition,
FreeDOS
Sleek light-weight design starting at 5.6 lb (2.54 kg) and 1.2 inch (30 mm) thin at front
15.4-inch wide screen display with BrightView option
Intel® Core™ 2 Duo processors, Intel Core Duo processors, Intel Core Solo processors, or
Intel Celeron® M processors
Mobile Intel 945GM Express Chipset or Mobile Intel 940GML Express Chipset
Up to 4GB of 533- or 667-MHz DDR2 SDRAM, dual channel memory support*
Intel Graphics Media Accelerator 950
Up to 120-GB 5400 rpm, user-removable hard drive
Optional LightScribe DVD+/-RW Drive with Double Layer
Optional 802.11 a/b/g or 802.11 b/g wireless LAN modules and optional Bluetooth®
IEEE 1394a Port
Protected by a one-year standard parts and labor warranty – certain restrictions and exclusions apply.
* Memory greater than 2 GB requires Mobile Intel 945GM Express Chipset. Above 3-GB, all memory may not be available
due to system resource requirements. 667-MHz memory is supported at a maximum speed of 533 MHz by the 940GML
Express Chipset.
QuickSpecs
HP Compaq nx7300 Notebook PC
Overview
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 2
Processors
Intel Core 2 Duo Processor T7600 (2.33-GHz, 667-FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7400 (2.16-GHz, 667-FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T7200 (2.0-GHz, 667-FSB, 4-MB L2 cache)*
Intel Core 2 Duo Processor T5600 (1.83-GHz, 667-FSB, 2-MB L2 cache)*
Intel Core 2 Duo Processor T5500 (1.66-GHz, 667-FSB, 2-MB L2 cache)*
Intel Core Duo processor T2600* (2.16-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo processor T2500* (2.00-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo processor T2400* (1.83-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo processor T2300* (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo processor T2300E* (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Core Duo Processor T2250* (1.73-GHz, 533-MHz FSB, 2-MB L2 cache) (select countries
only)
Intel Core Duo Processor T2050* (1.60-GHz, 533-MHz FSB, 2-MB L2 cache) (select countries
only)
Intel Core Solo Processor T1350* (1.86-GHz, 533-MHz FSB, 2-MB L2 cache) (select countries
only)
Intel Core Solo Processor T1300* (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)
Intel Celeron M Processor 450* (2.0-GHz, 533-MHz FSB, 1-MB L2 cache)
Intel Celeron M Processor 440* (1.86-GHz, 533-MHz FSB, 1-MB L2 cache)
Intel Celeron M Processor 430* (1.73-GHz, 533-MHz FSB, 1-MB L2 cache)
Intel Celeron M Processor 420* (1.60-GHz, 533-MHz FSB, 1-MB L2 cache)
Intel Celeron M Processor 410* (1.46-GHz, 533-MHz FSB, 1-MB L2 cache)
* Intel's numbering is not a measurement of higher performance.
NOTE:
Processor speed denotes maximum performance mode; processors will run at lower
speeds in battery optimization mode.
Operating System
Preinstalled
Genuine Windows Vista Business 32*
Genuine Windows Vista Home Basic 32*
Genuine Windows XP Professional SP2
Genuine Windows XP Home Edition SP2
FreeDOS
Supported
(select drivers available on
http://www.hp.com
)
Genuine Windows Vista Business 64*†
Genuine Windows Vista Enterprise 32/64*†
Genuine Windows 2000
† 64-bit versions for Intel Core 2 Duo models only
Certified
SuSE Linux Enterprise Desktop 10
* Certain Windows Vista product features require advanced or additional hardware.
See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
and
http://www.microsoft.com/windowsvista/getready/capable.mspx
for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To
download the tool, visit
http://www.windowsvista.com/upgradeadvisor
.
Chipset
Mobile Intel 945GM Express Chipset with 667-MHz front side bus
or
Mobile Intel 940GML Express Chipset with 533-MHz front side bus
QuickSpecs
HP Compaq nx7300 Notebook PC
Standard Features
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 3
Graphics
Intel Graphics Media Accelerator 950 with up to 224-MB shared system memory
Microsoft DirectX 9 capable
Display
Internal
15.4-inch WXGA display with 1280 x 800 resolution and 16M colors
15.4-inch WXGA BrightView display with 1280 x 800 resolution and 16M
colors
15.4-inch WSXGA+ wide viewing angle display with 1680 x 1050
resolution and 16M colors
External
Up to 32-bit per pixel color depth
VGA
port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE:
Resolutions are dependent upon monitor capability, and
resolution and color depth settings.
Memory
Standard
256-MB, 512-MB, or 1024-MB 533-MHz or 667-MHz* DDR2 SDRAM
SODIMMs; two SODIMM slots supporting dual channel memory
Maximum
Supports up to 4096-MB maximum (2048-MB 667-MHz SODIMM in
slots 1 and 2; requires Mobile Intel 945GM Express Chipset)
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
* 667-MHz memory is supported at a maximum speed of 533 MHz by the Mobile Intel 940GML
Express Chipset.
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we
recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system
will perform at the lower memory speed. Above 3-GB, all memory may not be available due to
system resource requirements.
Communications
Integrated Broadcom 10/100 Ethernet PCI Controller
56K V.92 modem* with digital line guard
* Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem
availability is subject to country regulatory approval.
Wireless Devices
Support for a broad range of secure, integrated wireless LAN options featuring support for the
latest industry standards. Integrated Bluetooth is also an option (factory configurable only) and
can be combined with any one of the supported wireless LAN options.
All integrated wireless
LAN options
Wi-Fi certified
Cisco Compatible Extensions support (Version 4.0)
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-
GTC, PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi Certified for WPA2, WMM
Dual antennas integrated in the display enclosure
Intel PRO/Wireless
3945ABG Network
Connection
Intel Centrino mobile technology
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
Intel PRO/Wireless
3945BG Network
Connection
Intel Centrino mobile technology
Integrated support for 802.11b and g
Up to 54-mbps data rate
QuickSpecs
HP Compaq nx7300 Notebook PC
Standard Features
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 4
Broadcom 4311AG
WiFi Adapter
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
Broadcom 4311BG
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54-mbps data rate
HP Integrated Module
with Bluetooth 2.0
Wireless Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
Keyboard
The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with
desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both
left and right control and alt keys, and 12 function keys. US and International key layouts are
available. Other features include an integrated numeric keypad, hotkeys for instant access to
power conservation, brightness, and other features, 19-mm x 19-mm key pitch (center-to-center
spacing), 2.5-mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in
low light conditions.
One-Touch
Productivity Buttons
Provide one-touch access to the following features: Wireless On/Off, Volume down, Volume up,
and Volume Mute.
Pointing Device
Touchpad with scroll zone and two soft-touch buttons
Expansion Card Slots
One Type I/II PC Card
slot
Supports 32-bit CardBus and 16-bit PC Cards
Storage
Hard Drives
40-, 60-, 80-, 100-, 120-GB 5400 rpm SMART SATA
100-GB 7200 rpm SMART SATA
NOTE:
These hard drives are customer removable and will withstand multiple insertion/removal
cycles. Up to 8 GB is reserved for the system recovery software.
HP Mobile Data
Protection System
Hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive and protecting it during normal
use from shock and vibration.
Fixed Optical Drives
CD-ROM
DVD-ROM
DVD/CD-RW Combo
DVD+/-RW SuperMulti with Double Layer
LightScribe DVD+/-RW with Double Layer
QuickSpecs
HP Compaq nx7300 Notebook PC
Standard Features
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 5
Interfaces
PC Card Slot
One - Type I/II
External Monitor
One – VGA
IEEE 1394a Port
One
External Microphone
One
Headphone/Line out
One
Power Connector
One
RJ-11
(Modem)
One
RJ-45
(NIC)
One
USB 2.0
Three
Accessory Battery
Connector
One
LED Status Indicators
Nine
Audio
PremierSound audio/speaker subsystem
ADI1981HD High Definition CODEC
Integrated 16-bit Sound Blaster Pro compatible audio
24-bit DAC
Integrated stereo speakers
External volume up, volume down, and mute buttons
Stereo headphone/line out
Stereo microphone in
Software
Preinstalled Software
with Windows Vista
or Windows XP
Adobe Acrobat Reader
HP Backup and Recovery Manager
HP Help and Support Center
HP Mobile Print Driver (Windows XP models)
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
Sonic Digital Media Plus (Windows XP models):
RecordNow! (for optional DVD+/-RW and DVD/CDRW drives)
MyDVD (DVD Authoring for optional DVD+/-RW drives)
Roxio Creator 9 (Window Vista models with optional DVD+/-RW or
DVD/CDRW drives)
Synaptics Touchpad Driver
Symantec Norton Internet Security with complimentary 60-day live
update
Intervideo WinDVD - DVD Player (for optional DVD+/-RW, DVD/CDRW
and DVD drives)
Additional software
available from the Web
Smart Card Security for HP ProtectTools
Device Access Manager for HP ProtectTools
HP Backup and
Recovery Manager
Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager
can provide data and system file protection for HP business PCs to enable fast recovery if the
system becomes corrupted or if important information is accidentally deleted. HP Backup and
Recovery Manager can perform scheduled or manual backups of the entire drive or individual files
and folders. Up to 8 GB is reserved for the system recovery software. HP Backup and Recovery
Manager can also create software recovery CDs or DVDs (requires optional hardware).
QuickSpecs
HP Compaq nx7300 Notebook PC
Standard Features
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 6
SMBIOS Version 2.4
System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools
Security Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops.
The HP ProtectTools Security Manager is an extensible client security console that delivers
enhanced security capabilities through add-on software modules. Modules currently available or
planned are:
- BIOS Configuration for HP ProtectTools
- Credential Manager for HP ProtectTools
- Device Access Manager for HP ProtectTools
Security
Standard Features
HP ProtectTools Security Manager
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
DriveLock
HP Disk Sanitizer
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased
separately)
For more information on HP security solutions refer to
http://www.hp.com/go/security
.
Power Supply
External 65-watt AC adapter, 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter).
HP Fast Charge Technology*
*Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge
Technology does not apply to 12-cell Ultra-Capacity batteries.
Battery
Primary Battery
8-cell (69Wh) high capacity Lithium-Ion
6-cell (43Wh) high capacity Lithium-Ion
Optional 8-Cell
Extended Life Battery
8-cell (52Wh) high capacity Lithium-Ion
Optional HP 12-Cell
Ultra-Capacity Battery
12-cell (95Wh) high capacity Lithium-Ion
QuickSpecs
HP Compaq nx7300 Notebook PC
Standard Features
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 7
Battery Life
8-cell (69Wh) Primary 6-cell (43Wh) Primary
Primary Battery
Up to 5 hours and 45 minutes Up to 3 hours and 30 minutes
Primary Battery and
optional HP 8-Cell
Extended Life Battery
Up to 9 hours and 45 minutes Up to 7 hours and 30 minutes
Primary Battery and
optional HP 12-Cell
Ultra-Capacity Battery
Up to 13 hours and 30 minutes
Up to 12 hours
NOTE:
Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used
by the customer. As with all batteries, the maximum capacity of this battery will decrease with time
and usage.
System Standby Time
Up to 1 week
Power Conservation
Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum
Performance Mode, or Automatic mode)
Hibernation
Standby
ACPI compliance
Service and Support
HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-
free 7 x 24 hardware technical phone support (depending on model). On-site service and warranty
upgrades are also available.
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for
details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
.
QuickSpecs
HP Compaq nx7300 Notebook PC
Standard Features
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 8
Memory
256-MB 533-MHz DDR2 SDRAM
PE830A
512-MB 533-MHz DDR2 SDRAM
PE831A
1-GB 533-MHz DDR2 SDRAM
PE832A
512-MB 667-MHz DDR2 SDRAM*
EM993AA
1-GB 667-MHz DDR2 SDRAM*
EM994AA
2-GB 667-MHz DDR2 SDRAM*
EM995AA
* 667-MHz memory is supported at a maximum speed of 533 MHz by the Mobile Intel 940GML
Express Chipset.
MultiBay II Storage
(9.5-mm)
NOTE:
Requires HP
External MultiBay II
DVD-ROM MultiBay II Drive
PA849A
Combo DVD/CD-RW MultiBay II Drive
PA850A
DVD+/-RW Dual Format MultiBay II Drive
PA851A
80-GB 5400 rpm MultiBay II Hard Drive
PH357A
Other Storage
80-GB 5400 rpm Primary SATA Hard Drive
ET354AA
DVD+/-RW Double Layer Drive with LightScribe Upgrade
ET353AA
HP USB Digital Drive + 256-MB Secure Digital Card
DL702AA
HP USB Diskette Drive
DC361B
Communications
Intel PRO/Wireless 3945ABG 802.11 a/b/g WLAN option kit
EX150AA#xxx
Expansion Solutions
HP Monitor Stand
PA507A
HP Adjustable Notebook Stand
PA508A
HP External MultiBay II (9.5-mm)
PA509A#xxx
HP 4-port USB 2.0 Hub
DG954A
Power
HP 2-bay Battery Charging Station
DT533A#xxx
HP 10-bay Battery Charging Station
DT534A#ABA
Battery Adapter kit #1
PK402A
65W Smart AC Adapter
ED494AA#xxx
90W Smart AC Adapter
ED495AA#xxx
90W Smart Auto Adapter
ED493AA
65W Air/Auto/AC Combo Adapter
ED993AA#xxx
Primary 8-cell Battery Pack
PB992A
HP 8-cell Extended Life Battery
PB993A
HP 12-cell Ultra-Capacity Battery
EJ092AA
Carrying Cases
HP Entry Value Case
DL617A
HP Top Load Nylon Case
DC915A
HP Executive Leather Case
PA847A
HP Sport Backpack
DG102A
QuickSpecs
HP Compaq nx7300 Notebook PC
Options
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 9
Security
HP PCMCIA Smart Card Reader
DC350B
HP/Kensington Cable Lock
PC766A
Input/Output Devices
USB/PS2 Keyboard
DC852A#xxx
USB/PS2 Optical Mouse
DC369A
HP USB Optical Travel Mouse
F2100A
QuickSpecs
HP Compaq nx7300 Notebook PC
Options
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 10
Supports up to 4096 MB* of 533-MHz or 667-MHz** DDR2 SDRAM
Two DIMM slots
DIMM sizes supported: 256 MB, 512 MB, 1024 MB, and 2048 MB
Standard Memory
256 MB (256 MB x 1)
512 MB (512 MB x 1 or 256 MB x 2)
1024 MB (1024 MB x 1 or 512 MB x 2)
2048 MB (1024 MB x 2)
Optional Memory
Upgrades
Support for up to 4096 MB* of memory is available (with the installation of optional DDR2 SDRAM
memory kits). Both memory slots are user accessible. Please refer to the Hardware and Software
Guide for installation procedures. Maximized dual-channel performance requires SODIMMs of the
same size and speed in both memory slots.
Up to
Slot 1 Slot 2
768 MB 512 MB 256 MB
1024 MB 1024 MB
Empty
1024 MB
512 MB 512 MB
1280 MB 1024 MB
256 MB
1536 MB 1024 MB
512 MB
2048 MB 1024 MB 1024 MB
4096 MB*
2048 MB 2048 MB
NOTE:
This chart does not represent all possible memory configurations. Due to the non-industry
standard nature of some third-party memory modules, we strongly recommend using only HP
branded memory modules to ensure compatibility. If you mix memory speeds, the system will
perform at the lower memory speed.
Memory Upgrades
256-MB 533-MHz DDR2 SDRAM
PE830A
512-MB 533-MHz DDR2 SDRAM
PE831A
1024-MB 533-MHz DDR2 SDRAM
PE832A
512-MB 667-MHz DDR2 SDRAM
EM993AA
1024-MB 667-MHz DDR2 SDRAM
EM994AA
2048-MB 667-MHz DDR2 SDRAM
EM995AA
* Memory greater than 2 GB requires Mobile Intel 945GM Express Chipset. Above 3-GB, all memory may not be available
due to system resource requirements.
** 667-MHz memory is supported at a maximum speed of 533 MHz by the Mobile Intel 940GML Express Chipset.
QuickSpecs
HP Compaq nx7300 Notebook PC
Memory
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 11
Removable Media Drive Support
Quantity Supported
Drive Bay
LightScribe DVD+/-RW Drive with
Double Layer
One
Fixed optical drive bay
DVD+/-RW SuperMulti Drive with
Double Layer
One
Fixed optical drive bay
DVD/CD-RW Combo Drive
One
Fixed optical drive bay
DVD-ROM Drive
One
Fixed optical drive bay
Hard Drive Support
Quantity Supported
Drive Bay
Primary Hard Drives
100-GB 7200 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
120-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
100-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
80-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
60-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
40-GB 5400 rpm SMART SATA
Hard Drive
One
Dedicated hard drive bay
QuickSpecs
HP Compaq nx7300 Notebook PC
Storage
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 12
System Unit
Dimensions
(HxWxD)
1.2 in (at front) x 14.1 in x 10.2 in
30 mm (at front) x 357 mm x 260 mm
Weight
5.6 lb (2.54 kg)
NOTE:
Height varies depending upon where on the notebook the measurement is made. Weight
includes 6-cell battery, 60-GB hard drive, 512-MB memory, 802.11 wireless communications
module. Weight varies by configuration and components.
Stand-Alone Power
Requirements
Normal Operating
Voltage
19 V
Average Operating
Power
25 W
Max Operating Power
< 65 W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
Shock
Operating
125 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude
(unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Industry Standard
Certifications
Blue Angel
No
UL
Yes
CSA
Yes
FCC Compliance
Yes
Energy Star Compliant
Yes
ICES
Yes
GS
Yes
Australia / NZ A-Tick
Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
MIC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian
Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 13
HP 65W Smart AC
Adapter
Dimensions
4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight
0.62 lb (280 g)
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC, 0.85 A at 180 VAC
Output
Output power 65W
65W
DC output
18.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide
safety standards – IEC60950, EN60950, UL60950, Class1, SELV;
Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over
200,000 hours at 25°C ambient condition.
Option Kit Contents
65W AC Adapter, power cable, warranty booklet
Optional HP 12-Cell
Ultra-Capacity Battery
Dimensions
(H x W x L)
1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight
1.77 lb (0.803 kg)
Cells/Type
12-cell Lithium-Ion
Energy
Voltage
14.8V
Watt-hour Capacity
95Wh
Amp-hour Capacity
6.45Ah
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
Smart Adapter
3 to 4 hours
System ON
4 to 5 hours (depending on system power
consumption)
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on
battery
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 14
Optional HP 8-Cell
Extended Life Battery
Dimensions
(H x W x L)
1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
Weight
1.00 lb (0.455 kg)
Cells/Type
8-cell Lithium-Ion
Energy
Voltage
14.4V
Watt-hour Capacity
52Wh
Amp-hour Capacity
3.6Ah
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF mode or
Standby
3 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 90
minutes when system is OFF
Fuel Gauge
When pressed, LEDs light indicating level of charge remaining on
battery
69Wh Primary 8-Cell
Battery
Dimensions
(H x W x L)
0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)
Weight
0.980 lb (0.445 kg)
Cells/Type
8-cell Lithium-Ion
Energy
Voltage
14.4V
Watt-hour Capacity
69Wh
Amp-hour Capacity
4.8Ah
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (-10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 1.5
hours when system is OFF
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 15
43Wh Primary 6-Cell
Battery
Dimensions
(H x W x L)
0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)
Weight
0.74 lb (0.336 kg)
Cells/Type
6-cell Lithium-Ion
Energy
Voltage
10.8V
Watt-hour Capacity
43Wh
Amp-hour Capacity
4.0Ah
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (-10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF Mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 1.5
hours when system is OFF
15.4-inch Color TFT
WSXGA+ Wide Viewing
Angle Display
Active Area
(W x H)
13.0 x 8.1 in (33.1 x 20.7 cm)
Diagonal Size
15.4 in (39.1 cm)
Surface Treatment
Anti-glare
Number of Colors
Up to 16M
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
170 nit (typical)
Pixel Resolution
Pitch
0.197 mm
Format
1680 x 1050
Configuration
RGB stripe
Backlight
CCFL
PPI
129
Viewing Angle
±65° Horizontal, ± 50° Vertical (typical)
15.4-inch Color TFT
WXGA Display
Active Area
(W x H)
13.0 x 8.1 in (33.1 x 20.7 cm)
Diagonal Size
15.4 in (39.1 cm)
Surface Treatment
Anti-glare
Number of Colors
Up to 16M
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
170 nit (typical)
Pixel Resolution
Pitch
0.259 mm
Format
1280 x 800
Configuration
RGB stripe
Backlight
CCFL
PPI
98
Viewing Angle
±45° Horizontal, ±25° Vertical (typical)
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 16
15.4-inch Color TFT
WXGA BrightView
Display
Active Area
(W x H)
13.0 x 8.1 in (33.1 x 20.7 cm)
Diagonal Size
15.4 in (39.1 cm)
Surface Treatment
BrightView
Number of Colors
Up to 16M
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
170 nit (typical)
Pixel Resolution
Pitch
0.259 mm
Format
1280 x 800
Configuration
RGB stripe
Backlight
CCFL
PPI
98
Viewing Angle
±45° Horizontal, ±25° Vertical (typical)
Hard Drives
100-GB 7200 rpm SATA
Drive Weight
0.25 lb (113 g)
Capacity
100 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
1 ms
Average
10 ms
Maximum
18 ms
Rotational Speed
7200 rpm
Logical Blocks
195,371,568
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
120-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
120 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
234,441,648
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 17
100-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
100 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
195,371,568
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
80-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
80 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
156,301,488
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
60-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
60 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
117,231,408
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 18
40-GB 5400 rpm SATA
Drive Weight
0.22 lb (101 g)
Capacity
40 GB
Height
0.37 in (9.5 mm)
Width
2.75 in (70 mm)
Interface
ATA-7 / SATA 1.0a
Transfer Rate
Synchronous (maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track
3 ms
Average
13 ms
Maximum
24 ms
Rotational Speed
5400 rpm
Logical Blocks
78,165,360
Operating Temperature
41° to 140° F (5° to 60° C) [case temp]
Features
ATA Security
Removable Storage Drives – Fixed Bay
CD-ROM Drive
Access Times
Random
<110 ms CD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
Transfer Mode
Multiword DMA Mode 2
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW
Supported Media
(write)
None
Max Media Capacity
(read)
700 MB
Transport
Tray Loading
DVD-ROM Drive
Access Times
Random
<116 ms CD
<125 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X-DVD
10,800 KB/s
Transfer Mode
Multiword DMA Mode 2
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW
Supported Media
(write)
None
Max Media Capacity
(read)
4.7 GB
Transport
Tray Loading
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 19
DVD/CD-RW Combo
Drive
Access Times
Random
<110 ms CD
<130 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
24X CD-RW
3,600 KB/s
Transfer Mode
Multiword DMA Mode 2
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW
Supported Media
(write)
CD-R, CD-RW
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
700 MB
Transport
Tray loading
LightScribe DVD+/-RW
Drive with Double
Layer
Access Times
Random
<175 ms CD
<230 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
16X CD-RW
2,400 KB/s
8X DVD+R
10,800 KB/s
4X DVD+RW
5,400 KB/s
8X DVD-R
10,800 KB/s
4X DVD-RW
5,400 KB/s
2.4X DVD+R(9)
2,700 KB/s
Transfer Mode
Multiword DMA Mode 2
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, LightScribe
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport
Tray Loading
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 20
DVD+/-RW SuperMulti
Drive with Double
Layer
Access Times
Random
<175 ms CD
<230 ms DVD
Max Data Transfer Rate
24X CD-ROM
3,600 KB/s
8X DVD
10,800 KB/s
24X CD-R
3,600 KB/s
16X CD-RW
2,400 KB/s
8X DVD+R
10,800 KB/s
4X DVD+RW
5,400 KB/s
8X DVD-R
10,800 KB/s
4X DVD-RW
5,400 KB/s
2.4X DVD+R(9)
2,700 KB/s
5X DVD-RAM
6,750 KB/s
Transfer Mode
Multiword DMA Mode
Interface
EIDE
Supported Media
(read)
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED
MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD
(Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW,
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW,
DVD+R, DVD+RW, DVD-RAM
Supported Media
(write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM
Max Media Capacity
(read)
8.5 GB
Max Media Capacity
(write)
8.5 GB
Transport
Tray Loading
PremierSound Audio
Hardware
Implementation
ADI1981HD High Definition CODEC
Volume Controls
Up, down, and mute buttons
Full Duplex
Yes
Sound Blaster Pro
compatible
Yes
Microphone Jack
Stereo or mono
Headphone/Line Out
Jack
Stereo
Audio Output Quality
Frequency Response
20 Hz – 20 kHz
Signal to Noise Ratio
>85 dB
Total Harmonic
Distortion
0.01%
Noise Floor
-110 dB
Play/Record Sampling
Rate
(s)
8 kHZ – 48kHz
DAC
16, 20 or 24-bit
ADC
16 or 20-bit
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 21
Internal Speakers
Power Rating
2 Watts
Impedance
4 Ohms
Communications
Integrated Broadcom
10/100 Ethernet PCI
Controller
(BCM4401)
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-
14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses
21-30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
100 Mbit/s
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management
ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Manageability
Wake-on-LAN from standby and hibernation (configurable; Magic
Packet and Microsoft Wake-Up Frame)
PXE 2.1 Remote Boot
Statistics Gathering (RMON, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Interface
32-bit PCI, 33-MHz
NIC Device Driver
Name
Broadcom 440X 10/100 Integrated Controller
Drivers Available
Microsoft Windows XP
Microsoft Windows 2000
V.92 56K Data/Fax
Modem
Form Factor
MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC
Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian
ACA, CE Mark, Other Countries
Data Mode Capabilities
V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities
TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
Command Set
V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
Broadcom 4311BG
802.11b/g WiFi Adapter
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at
www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
17.5 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 23
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.026 lb (12 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN
may also be compatible with certain third-party software supplicants.
5.
Broadcom 4311AG
802.11a/b/g WiFi
Adapter
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at
www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz and 5 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 24
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
17.5 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode
3
: 390 mW (nominal)
Sleep mode: 20 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.026 lb (12 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN
may also be compatible with certain third-party software supplicants.
5.
Intel PRO/Wireless
3945ABG 802.11a/b/g
Network Connection
Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 25
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at
www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz and 5 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
15 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode
3
: 150 mW (nominal)
Sleep mode: 30 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 26
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet (required for Cisco Compatible Extensions support)
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN
may also be compatible with certain third-party software supplicants.
5.
Intel PRO/Wireless
3945BG 802.11b/g
Network Connection
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
Interoperability
Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at
www.hp.com/go/notebooks/WLAN
)
Frequency Band
2.4 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 4).
Sub-channels
Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol
CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
(for
CKK)
2
15 dBm
Output Power
(for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption
Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode
3
: 150 mW (nominal)
Sleep mode: 30 mW (max)
Power Management
ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Range
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 27
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
PCI-Express MiniCard
Weight
0.013 lb (6 g)
Dimensions
0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage
3.3v +/- 10%
Temperature
Operating
Non-operating
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet (required for Cisco Compatible Extensions support)
LED Activity
LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
1.
Maximum output power may vary by country according to local regulations.
2.
In Power Save Polling mode.
3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4.
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN
may also be compatible with certain third-party software supplicants.
5.
HP Integrated Module
with Bluetooth
Wireless Technology
Bluetooth Specification
2.0 Compliant
Dimensions
1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
79 (1 MHz) available channels
Data Rates and
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric
Transmit Power
-6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Peak (Tx) 264 mW
Peak (Rx) 231 mW
Sleep <1 mW
Antenna
Internally integrated within module
Range
Up 33 ft (10 m)
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
OS Support
Microsoft Windows XP Professional and Home
Microsoft Windows 2000
Bluetooth Software
Supported
Broadcom Bluetooth for Windows
Microsoft Windows XP Bluetooth Software
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 28
Security
Full support of Bluetooth Security Provisions
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Temperature
Operating
-4° to 158° F (-20° to 70° C)
Non-operating
-40° to 176° F (-40° to 80° C)
Humidity
Operating
10% to 90%
Non-operating
5% to 95%
Altitude
Operating
15,000 ft (4,572 m)
Non-operating
40,000 ft (12,192 m)
Bluetooth Profiles
Supported
(with Bluetooth for Windows 4.0 software)
Serial Port Profile (SPP)*
Dial-Up Networking (DUN)*
Generic Object Exchange Profile (GOEP)
Object Push Profile (OPP)*
File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)*
Personal Area Networking Profile (PAN)*
Human Interface Device Profile (HID)*
FAX Profile (FAX)
Basic Imaging Profile (BIP)
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
*
indicates the profile is also supported by Microsoft Windows XP SP2
Environmental Data
Eco-Label
Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
US Energy Star
US Federal Energy Management Program (FEMP)
Taiwan Green Mark
China Energy Conservation Program
IT ECO declaration
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on a "Typically Configured Notebook."
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 29
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
23 W
23.5 W
23 W
Sleep (Energy Star
low power mode)
1.72 W 1.88 W 1.73 W
Off
1.90 W 1.98 W 1.90 W
Heat Dissipation*
115 VAC 230 VAC 100 VAC
Normal Operation
78.5 BTU/hr 80.2 BTU/hr 78.5 BTU/hr
Sleep
5.9 BTU/hr 6.4 BTU/hr 5.9 BTU/hr
Off
6.5 BTU/hr 6.8 BTU/hr 6.5 BTU/hr
*NOTE
: Heat dissipation is calculated based on the measured watts,
assuming the service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL
(wake on LAN) disabled.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
3.0
28.0
Fixed Disk (random
writes)
3.9
33.8
Optical Drive
(sequential reads)
34.0
System fan is usually off except when charging the battery
System Fan On
29.0
Idle
34.0
Fixed Disk
(random writes)
42.0
Batteries
This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater than 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.
Battery type and chemistry used in the product:
Primary battery
6-cell high capacity Lithium-Ion battery pack
Real Time Clock battery
CR2032 (coin cell), Lithium
Additional Information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 30
ISO/IEC 15412
Input devices of this product comply with ISO 9241, part 9.
Plastics parts weighing over 0.055 pounds (25 grams) used in the
product are marked per ISO 11469 and ISO1043.
This product contains 0% recycled materials (by wt.)
This product is greater than 85% recycle-able when properly disposed of
at end of life.
Packaging
Packaging Materials
External:
Corrugated Paper 920 g
Internal:
EPE Foam 266 g
LDPE Bag 14 g
Corrugated/Paper 210 g
The plastic packaging material is made from 0% recycled content.
The corrugated paper packaging materials contains at least 80%
recycled content.
HP follows these guidelines to decrease the environmental impact of
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
Material Usage
This product does not contain any of the following substances in excess
of regulatory limits (for reference of these limits please refer to the HP
General Specification of the Environment
(
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html
):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 31
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
End-of-life
Management and
Recycling
HP offers our customers several other options for handling their aging
computers while also minimizing the impact on the environment-
including product trade-in and leasing services-in addition to recycling
services.
Please go to:
http://www.hp.com/recycle
or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or
disposed of in a responsible manner.
Hewlett-Packard
Corporate
Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Environment website
http://www.hp.com/environment
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/
operations/envmanagement.html
Copyright © 2007 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows, Windows Vista, and Windows XP are registered trademarks or trademarks of
Microsoft Corporation in the U.S. and/or other countries. Core Duo, Centrino, and SpeedStep are registered trademarks or
trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc.,
in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing
herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein.
QuickSpecs
HP Compaq nx7300 Notebook PC
Technical Specifications
DA - 12614 Worldwide QuickSpecs — Version 3 — 1.30.2007
Page 32

Navigation menu
