Users manual
Switch on : Long press “ ” for 2 seconds to switch
on , the blue indicator will be on for 1 second(It will
appear voice prompt in English). Long press “ ” for
2 seconds again to enter into pairing mode,
meanwhile the red and blue indicators take turns to
flash. It will power off automatically when no device
to be connected in 10 minutes ) .
Switch off : Long press “ ” for 4
seconds to switch off ,
meanwhile the red indicator will be on for 1 second.
Briefly press “ ” to receive phone call, press it again
to end the phone call.
Long press “ ” for 2 seconds to reject the phone call.
In music mode, briefly press “ ” to pause,
and press it again to play. (when phone call comes,
the music will be off. When phone call is off, the music
will continue)
Simultaneously press “ ”and “ ” to redial the last
phone number
Restore factory
defaults
Simultaneously press “ ”and “ ” for 3 seconds
to restore factory defaults
Re-dial the last
phone number
“ ”
“ ”
“ ”
“ ”
“ ”
&
01 02 03 04
Bluetooth Headphone
Thank you for selecting our latest Bluetooth headphone, please
read this User's Manual carefully before you operate this
headphone, and please keep this manual for further reference.
Before operating, please read all the safety notice to make sure
safe and appropriate use.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Safety Notice:
Please observe the rules of the country or region which you
are in while driving.
Do not disassemble or modify the
headphone
for any reason,
otherwise, It may damage or burn the
headphone
.
If there is any quality problem, please send the
headphone
to
authorized service center for repairing.
Please keep the equipment along with all the accessories out
of the reach of children and pets. Otherwise, it may cause
suffocation and serious injury.
Do not put the device under the environment which the
temperature is too low or too high ( Below 0℃ or over 45℃).
Extreme temperatures will cause the device deformation,
reduce the charging capacity and shorten the working life.
Please do not wet the device, for the liquid can cause serious
damage to the device. Please do not touch the device by wet
hands. It is out of the maintenance range for the damage
caused by water.
Please avoid closing to the eyes of children and pets when
using the flash indicator of the device.
Please do not operate the device in thunderstorm weather.
It will damage your hearing if you listen at high
volume for a long time. It is recommended that
only use the lowest volume which is necessary
for speaking and listening to music.
1. Guide
2.Instruction
KBJ-265N
FCC ID: 2AA7XKBJ-265N
3. How to connect with two Bluetooth mobile
phones:
■ Heaphone introduction
※ Contents: Bluetooth headphone, USB charging cable,
3.5mm audio cable, user’s manual
USB Charging Cable:
1.Soft and Comfortable cover
2.Foldable Arm
3.Soft and Comfortable cover
4.Next Song/Volume Increase
5.Previous Song/Volume Decrease
6.Power Switch/Pairing/Play/Pause Receive/
Hang up phone call
7.3.5mm Plug Port
8.Indicator Light
9.Charging Port
10.Microphone
3.5mm Audio Cable:
“ ”
“ ”
“ ”
In music mode, briefly press “ ” to play next song.
Long press to increase volume.
The voice prompt will appear when the volume is
up to Maximum.
In music mode, briefly press “ ” to play previous
song. Long press to decrease volume.
Previous song
Volume Decrease
Next Song
Volume Increase
“ ”
&
Power switch
Pairing
(1) Turn on the Bluetooth function of mobile phone 1.
(2) Long press the“ ” for 4 seconds until the red and blue
indicators take turns to flash, then connect phone 1.
(3) Press “ ” for 2 seconds, Bluetooth headphone enters into
pairing mode, the red and blue indicators take turns to
flash, meanwhile phone 1 is disconnected.
(4) Turn on the Bluetooth function of mobile phone 2, find
the headphone “KBJ-265N” from the device list and make
connection.
(5) If system prompted for a password, input the password
0000 (four zero), then connect Bluetooth headphone
with mobile phone 2.
(6) Turn off the Bluetooth headphone and return on, the
headphone will be connected with both mobile phones
automatically. The voice “phone 1 connected, phone 2
connected ” will appear in English.
※ When the headphone is connected with two mobile phones,
some functions of the mobile phones may cannot work
normally.
※ After paired with phone, it will display the battery power bar of
the Bluetooth headphone in phone.
Play/Pause
Receive/
Hang up phone
call
voice function.Continuously double press “ ” to enter into voice
function.
1
2
3
4
5
6710
9
8
Bluetooth Headphone
0605 07 08
Power on
Incoming call
Disconnected
Disconnected
4. Voice Prompt Function
Voice Prompt Status
When you turn the headphone off
When you turn the headphone on
When entering into pairing mode
When you connect the second
mobile phone
When you disconnect the headphone
from the fist mobile phone
When you disconnect the headphone
from the second mobile phone
When a call comes in
When the volume is up to the
maximum
When you connect the first mobile
phone
Pairing
Connected
Connected
Power off
10:30 90%
KBJ-261N
蓝牙
现为可被发现状态
设备
已连接
ON/OFF
蓝牙通用
Volume max
5.Bluetooth Indicator Status
Red indicator flashes all the time
Charging
Work Status Indicator Light Status Remark
Switch on Blue indicator is on for 1 second
Switch off Red indicator is on for 1 second
Incoming call Blue indicator flashes 1 time
every 5 seconds
Blue indicator flashes 1 time
every 5 seconds
Connection
Phone call Blue indicator flashes 1 time
every 5 seconds
Blue indicator flashes 1 time
every 5 seconds
Play music
Low battery
warning
Pairing Red and blue indicators take
turns to flash
Voice Prompt
Voice Prompt
Voice Prompt
Voice Prompt
Voice Prompt
Red indicator is on all the time
when charging, and is off when
full charging
8.Project Specification and Instruction
- Bluetooth Version : 4.0 (CSR8635)
- Supported devices: Bluetooth mobile phones, Bluetooth
speakers Bluetooth PC and other Bluetooth devices
- Maximum work range: 33 Feet (10 Meters)
- Talk time: Around 15 Hours
- Music play: Around 13 Hours
- Charging time: 4 Hours
- Charging Voltage: DC 5V
- Work Voltage: 3.7V
- Sensitivity: 83±3dB
- Battery Capacity: 420mAh
- Frequency Response: 2.402GHz~2.480GHz
※ The actual time may vary from mobile phone types and
functions.
6.Headphone Charging
※ If the headphone shut down without battery during the
phone, calls transfer to mobile phone automatically
※ If the coming calls from two connected mobile phones at
the same time, can only can refuse the main mobile phone
coming call
7．Audio cable connection
This
headphone
is equipped with built-in non-detachable and
rechargeable lithium battery.
Please make sure that the battery is charged full for the first
time use.
■ Connect the charger to the charging port.
■ Insert the charger into the standard power outlet. red
indicator will be on when charging. If without charging,
please plug out the travel charger first, then connect it
again.
■ After full charging, red indicator will be off. Please plug out
the travel charger from the power outlet and
headphone
.
■ It will reduce the battery performance after long time /
repeatable charge and dis-charge. And it is normal
phenomenon for all the rechargeable battery.
■ Please do not dial or receive phone call during
charging, and please plug out the charger from the
headphone
, then receive the phone call. When the battery
is low, the
headphone
will appear the voice prompt and the
red indicator will flash.
■ The headphone will be off when charging.
Line Insert 3.5mm audio cable into headphone 3.5mm plug
port, the other part into audio output device(MP3/PC), then
you can enjoy music. When the Bluetooth headphone is on,
the Bluetooth function will be off if inserting the audio cable.
