Compupal Group MG-LBTS01IR Bluetooth Light Speaker User Manual Light IR

Compupal Group Corporation Bluetooth Light Speaker Light IR

Users Manual

Bluetooth Light Speaker Quick Start Guide
Introduction
This Bluetooth Light Speaker is a perfect combination of LED lamp and Bluetooth Speaker. It’s
equipped with infrared remote control for easier use. You will be surprised to match it well with
your desk lamp. Enjoy it!
The Package Contents
1x Bluetooth Light Speaker
1x Infrared remote control
1x Quick Start Guide
Caution
1. Please read and follow all instructions before operating this product.
2. Heed all warnings on the product and in the operation instructions.
3. Please cut power off before install or uninstall the product.
4. When LED lamp on, suggest not touch the product surface in case being burned.
5. To get better remote control performance, please do not place light proof obstacle on
front of the product.
6. Suggest not use metal lampshade in case the wireless signal suffers from
attenuation.
7. With LED lamp on, if not plan to listen music, suggest to turn Bluetooth off by
pressing Bluetooth power button on remote control. It can save power, extend
Bluetooth lifetime and reduce interference to lamp from Bluetooth.
8. With LED lamp on and brightness not reaching 100%, there maybe some slight
background noise which is normal.
9. External dimmer does not work for the product. You can adjust lamp brightness by
using remote control.
10. Do not open the product to avoid electronic shock. Repair has to be performed by a
qualified technician.
11. Cut power off if not to use the product for a long period of time.
12. The product has a wireless transmission distance up to 33ft, but wireless
performance may be affected in different operating environment.
13. Keep the product out of extreme heat and humidity. Do not install it near heaters,
stoves or any other source of heat.
14. Do not use the product during lightning storms. Turn the power off to prevent damage
to the product due to lightning and power-line surges.
15. Please do not stare at the light source for a long time to protect your eyes.
16. If cleaning is required, use a soft dry cloth. Before cleaning, unplug the device from
the electrical source.
Product Installation
1. Take the Bluetooth Light Speaker, Remote control, Quick start guide out of your package.
2. Pull out the insulation sheet on the remote control to make it work.
3. Before installing the Light Speaker into your lamp system, make sure the power is off.
4. Screw Light Speaker into E26 socket.
5. Turn the power on, white LED will be lit and speaker will enter Bluetooth pairing status with
indication LED blinking fast in blue. You can use remote control to reduce white LED
brightness to observe indication LED status.
LED lamp function
1. LED lamp brightness has 5 levels: 0%, 25%, 50%, 75% and 100%.
2. You can short press button on remote control to adjust LED lamp brightness.
Speaker function
1. Make sure Bluetooth Speaker is at pairing status (indication LED blinking fast in blue)
2. Make sure Bluetooth device (smart phone, pad etc) has open Bluetooth.
3. Enter Bluetooth interface to search for new device and select “MG-LBTS01IR” for paring.
During pairing, some Bluetooth devices require to enter password. Just type four zeros
“0000”.
4. Indication LED will stop blinking and keep solid in blue after Bluetooth connected.
5. Open music player to play the music you like.
6. You can use your Bluetooth device (smart phone, pad etc) or remote control to do
play/pause, volume up/down, last track, next track, mute operation and so on.
Note
1. If your Bluetooth device (smart phone, pad etc) has ever connected this Bluetooth Light
Speaker, it supports Bluetooth automatically reconnect without pairing.
2. There is a Bi-color (red/blue) LED for Bluetooth, volume control and mute indication:
- Bluetooth pairing: blinking fast in blue;
- Bluetooth reconnecting: blinking slowly in blue;
- Bluetooth connected: blue color on in solid;
- Mute status: red color on in solid;
- Volume control: blue color on in solid and red color blinking with every volume adjusting
operation.
Remote control function:
No Button Function description
1 Bluetooth
power
Short press to open Bluetooth. Indication LED on.
Short press to close Bluetooth. Indication LED off.
2 Mute Short press to mute.
Short press to unmute.
3 Play/Pause Short press to play music.
Short press to pause music.
4 Volume
down
Short press to decrease volume.
Long press to decreasing volume continually.
5 Volume up Short press to increase volume.
Long press to increasing volume continually.
6 Last track Short press to enter last track (If music has been played for a
Note:
Some function on remote control may not be supported by some Bluetooth devices. You can
control directly through the Bluetooth device.
Product Specification
Product name: Bluetooth Light Speaker
Model: MG-LBTS01IR
Driver unit: 1.5’’ full range driver
Rated lamp power: 7W
Rated speaker power: 3W with 1% THD
Rated voltage: 100-240V Socket: E26
Power factor (PFC) 0.68
Standby power consumption 0.5W
Rated useful luminous flux: 300lm
Color temperature: 3000K
Color rendering index 80
Product dimension (W X D X H): 2.7X2.7X3.9 in. (68X68X98mm)
Remote control dimension (W X D X H): 1.6X3.4X0.3 in. (40X86X7mm)
FCC Part 15 Statement
1. This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
FCC ID: Z5YMG-LBTS01IR
while, it will back to beginning of the music).
Long press to fast backward.
7 Next track Short press to enter next track.
Long press to fast forward.
8 LED
lamp
Short press to adjust LED lamp brightness.
Brightness has 5 levels: 0%, 25%, 50%, 75% and 100%.
9 Bluetooth
pairing
Short press to cut the Bluetooth connection with current
Bluetooth device. Bluetooth Light Speaker enters pairing status
with indication LED blinking fast in blue.
Trouble shooting
See below for solutions to common problems. If you have more questions to your Bluetooth
Light Speaker, you may contact with local distributor for assistance.
Symptom Solution
Bluetooth indication LED not on
Please make sure your Bluetooth Light
Speaker has been powered on.
Try to short press Bluetooth power button on
remote control.
Speaker does not produce sound
Please make sure your Bluetooth Light
Speaker has been powered on.
Make sure the volume is turned up to audible
listening level for both Speaker and your
Bluetooth device (smart phone, pad etc).
Make sure the Bluetooth is successfully
connected.
Bluetooth can not be connected Make sure the Bluetooth is open on your
Bluetooth device.
Make sure correct Bluetooth pairing password
has been entered if required.
During Bluetooth paring, please do not open
too many Bluetooth devices to avoid
interference to Bluetooth connection.
If failed at pairing, short press Bluetooth
paring button on remote control to pair again.
Or you can try to pair with another Bluetooth
device.
This product may not be able to set up
Bluetooth connection successfully with some
non smart phones from Oppo, ZTE, Lenovo
etc.
Sound distortion WAV and MID files are often poor quality.
Therefore distortion and noise are easily
noticed with powered speakers.
Check the volume level and decrease if
necessary.
Infrared remote control is not working well Please make sure there is no light proof
obstacle on front of the Bluetooth Light
Speaker.
Please make the control distance within 5
meters.
Please try to aim at the center of the
Bluetooth Light Speaker front face.
Please replace the battery in remote control.
