Compupal Group Corporation Clock Radio with Bluetooth Users Manual
Users Manual
User Guide
Digital Clock Radio with Bluetooth
NS-CLBT01-B
NS-CLBT01-W
Before using your new product, please read these instructions to prevent any damage.
V2
FINAL
FOR PRINT
2
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
NS-CLBT01-B/NS-CLBT01-W
Digital Clock Radio with Bluetooth
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Top buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting up your radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing backup batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Connecting the AC/DC power adapter . . . . . . . . . . . . . . . . . . . . . . . 8
Using your radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the alarm sound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Setting the alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Using the snooze feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Turning off the alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Playing your radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Programming a radio station preset . . . . . . . . . . . . . . . . . . . . . . . .11
Tuning to a preset radio station . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Adjusting the LCD brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Playing audio from a Bluetooth device. . . . . . . . . . . . . . . . . . . . . .12
Connecting an audio device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Charging a device’s battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
90-day limited warranty - Insignia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-CLBT01-B or NS-CLBT01-W represents the state of the art in digital
clock radio and Bluetooth design. Your radio is designed for reliable and
trouble-free performance.
3
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Important safety instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for long
periods of time.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
To reduce the risk of fire or electric shock, do not expose this device to
rain, moisture, dripping, or splashing, and no objects filled with liquids,
such as vases, shall be placed on it.
The wall plug is the disconnecting device. The plug must remain readily
operable.
Batteries should not be exposed to excessive heat such as sunshine, fire, or
the like.
Caution
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
4
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Features
Top buttons
# Item Description
1 Pair/Preset button Press and hold for six seconds to pair your radio with a Bluetooth
device. See “Playing audio from a Bluetooth device” on page 12.
In Bluetooth mode, quickly press and release to start or stop playback.
See “Playing audio from a Bluetooth device” on page 12.
In FM mode, press to program a radio station preset or to tune to a
preset radio station. See “Programming a radio station preset” on
page 11 or “Tuning to a preset radio station” on page 11.
2 Sleep button Press to set the time or the sleep timer. For more information, see
“Setting the time” on page 8 or “Setting the sleep timer” on page 10.
3 (previous/fast reverse) button In Bluetooth mode, quickly press and release to go to the previous
song.
In FM mode, press and hold for one second to go to the next lower
radio station, or quickly press and release to manually tune to a lower
radio frequency.
4 (Alarm 1) button Press to set Alarm 1. See “Setting the alarm sound” on page 9 and
“Setting the alarm time” on page 9.
5 (next/fast forward) button In Bluetooth mode, quickly press and release to go to the next song.
In FM mode, press and hold for one second to go to the next higher
radio station, or quickly press and release to manually tune to a higher
radio frequency.
6 (Alarm 2) button Press to set Alarm 2. See “Setting the alarm sound” on page 9 and
“Setting the alarm time” on page 9.
7 button When the alarm turns on, press to turn off the alarm for 10 minutes.
See “Using the snooze feature” on page 10.
Press to adjust the LCD brightness. See “Adjusting the LCD brightness”
on page 11.
SNOOZE / DIMMER
Sleep
Source
Pair / Preset
2
1
8
2
13
4
5
6
7
910
1
2
SNOOZE / DIMMER
5
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Back
8 Source (source/standby) button When your radio is turned off (in standby mode), press to turn it on.
See “Playing your radio” on page 10.
When your radio is turned on, quickly press and release to switch
between playing the radio, a Bluetooth device, or connected audio
device. See “Playing audio from a Bluetooth device“ on page 12 or
“Connecting an audio device” on page 13.
9 (volume down) button Press to decrease the volume. While you are adjusting the volume, the
“Volume” icon lights and the current volume level (1 through 15)
appears in the middle of the LCD.
10 (volume up) button Press to increase the volume. While you are adjusting the volume, the
“Volume” icons lights and the current volume level (1 through 15)
appears in the middle of the LCD.
# Item Description
1 DC IN jack Connect the AC/DC power adapter to this the jack. See “Connecting the
AC/DC power adapter” on page 8.
2 USB port Connect a device with a micro USB or mini USB cable to charge the
device’s battery. See “Charging a device’s battery” on page 13.
3 AUX jack Connect an audio device to this jack to play the audio from the device
through the radio speakers. See “Connecting an audio device” on
page 13.
# Item Description
Picture?
1 2 3
5.4V 1.1A USB AUX
6
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
LCD
# Icon Description
1 Preset When you are programming a radio station preset, the “Preset” icon lights and the next
available preset number (P-01 through P-10) appears in the middle of the LCD. When you
exit programming mode, these indicators disappear. See “Programming a radio station
preset” on page 11.
When you tune to a radio station preset, the preset number (P-01 through P-10) appears.
See “Tuning to a preset radio station” on page 11.
2 Volume After you select the alarm sound, this icon indicates that you can change the volume of the
alarm. See “Setting the alarm sound” on page 9.
While you are adjusting the radio volume, the “Volume” icon lights and the current
volume level (1 through 15) appears in the middle of the LCD. When you stop adjusting
the alarm or radio volume, these indicators disappear.
3 Current time Displays the current time.
4 Sleep Lights when the sleep timer is active. See “Setting the sleep timer” on page 10.
5 Alarm 1 Lights when Alarm 1 has been set. See “Setting the alarm time” on page 9.
6 AUX Lights when a connected audio device is selected as the audio source. See “Connecting an
audio device” on page 13.
7 Bluetooth Lights when a paired Bluetooth device is selected as the audio source. See “Playing audio
from a Bluetooth device” on page 12.
8 FM Lights when the radio is selected as the audio source.
9 AM/PM “AM” lights after midnight and before noon. “PM” lights after noon and before midnight.
10 Bluetooth logo Blinks slowly if you select Bluetooth as the audio source and no Bluetooth device is
connected.
Blinks quickly while pairing with a Bluetooth device.
Lights solid when a Bluetooth device is connected.
See “Playing audio from a Bluetooth device” on page 12.
11 Snooze Lights when your radio is in snooze mode. See “Using the snooze feature” on page 10.
12 Battery Lights when no backup batteries are installed or when the backup battery charge is low.
Volume Preset AUX FM BLUETOOTH
AM
PM
MHz
SLEEP SNOOZE
Buzzer
1 Radio
Buzzer
2 Radio
12:08
1
2
3
4
5
6
9
8
11
12
13
10
7
7
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Package contents
• Digital clock radio with Bluetooth
• AC/DC power adapter
• Quick Setup Guide
• User Guide
Setting up your radio
Installing backup batteries
The backup batteries provide power to backup your settings when you
unplug the AC/DC power adapter.
To install backup batteries:
Push the latch to release the battery compartment cover on the
bottom of your radio, then lift the cover off the battery compartment.
13 Alarm 2 Lights when Alarm 2 has been set. See “Setting the alarm time” on page 9.
Cautions
• Use only the size and type of batteries specified.
• Do not mix old and new batteries.
• Make sure that you follow the correct polarity as indicated in the
battery compartment.
• Do not try to recharge batteries not intended to be recharged. They
can overheat and rupture. (Follow the battery manufacturer’s
directions.)
• Do not throw batteries into a fire. Dispose of used batteries as
hazardous waste.
Note
If you unplug the AC/DC power adapter and the backup batteries are dead or
not installed, the time setting is lost.
# Icon Description
AAA
AAA
1
2
8
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Insert two AAA batteries (not included) into the battery compartment.
Make sure that the + and – symbols on the batteries align with the +
and – symbols inside the compartment.
Insert the tab on the battery compartment cover into the slot on the
battery compartment, then press the cover down until it clicks into
place.
Connecting the AC/DC power adapter
To connect the AC/DC power adapter:
Plug the small connector on the power adapter into the jack on
the back of your radio.
Plug the other connector on the power adapter into a power outlet.
Using your radio
Setting the time
To set the time:
Press for about two seconds until the hour digits blink on
the LCD.
Press or to increase the hour or press or to decrease the
hour.
Press again. The minutes digits blink on the LCD.
Press or to increase the minutes or press or to decrease
the minutes.
Press again to save the time setting and exit time setting
mode.
Note
If you unplug the AC/DC power adapter and the backup batteries
are dead or not installed, the time setting is lost.
Note
“AM” or “PM” appears on the LCD to the right of the time. When
you set the time, make sure that the “AM” or “PM” displays
correctly.
9
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Setting the alarm sound
Your radio has two alarms and can play the buzzer or the radio for the
alarm sound. You can use the same alarm sound for both alarms or set one
alarm to use the buzzer and the other alarm to use the radio.
To set the alarm sound:
Press (Alarm 1) or (Alarm 2). The or icon blinks on
the LCD.
To use the radio as the alarm sound, press (Alarm 1) or (Alarm 2)
once. The or icon blinks on the LCD and the alarm sound
is set to the radio. Wait three seconds to save the setting and exit alarm
sound setting mode. When the alarm turns on, the last tuned radio
station plays.
OR
To use the buzzer as the alarm sound, press (Alarm 1) or
(Alarm 2) twice. The or icon blinks on the LCD and
the alarm sound is set to the buzzer. Wait three seconds to save the
setting and exit alarm sound setting mode.
To completely turn off the alarm, press (Alarm 1) or (Alarm 2)
repeatedly until the or icon disappears from the LCD.
Setting the alarm time
Your radio has two alarms that you can set for different times.
To set the alarm time:
Press and hold (Alarm 1) or (Alarm 2) for about two seconds
until the hour digits blink on the LCD.
Press or to increase the hour or press or to decrease the
hour.
Press (Alarm 1) or (Alarm 2) again. The minutes digits blink on
the LCD.
Press or to increase the minutes or press or to decrease
the minutes.
Press (Alarm 1) or (Alarm 2) again. The icon appears on
the LCD and the time digits blink.
Note
“AM” or “PM” appears on the LCD to the right of the time. When
you set the time, make sure that the “AM” or “PM” displays
correctly.
1212
12
1Radio 2Radio
1
21
Buzzer
2
Buzzer
12
12
12
12
12
10
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Press or to increase the alarm volume or press or to
decrease the alarm volume. The alarm volume range is from 1 to 15
with 15 being the loudest setting. The default setting is 10. While you
are adjusting the volume, the “Volume” icon lights and the current
volume level number appears in the middle of the LCD.
Press (Alarm 1) or (Alarm 2) again to save the time setting and
exit alarm setting mode.
Using the snooze feature
To use the snooze feature:
• When the alarm sounds, press (SNOOZER/DIMMER). The
alarm turns off for 10 minutes and appears on the LCD.
Turning off the alarm
To turn off the alarm:
• Press any button except (SNOOZER/DIMMER).
Setting the sleep timer
You can specify the amount of time your radio waits before it turns off
automatically.
To set the sleep timer:
• Press repeatedly to select the amount of time you want
your radio to wait before it turns off automatically. You can select ,
, , , or minutes. The time you select and the icon
appear on the LCD.
• To turn off the sleep timer, press repeatedly until
appears and the icon disappears.
Playing your radio
To play your radio:
Make sure that you have connected the AC/DC power adapter. See
“Connecting the AC/DC power adapter” on page 8.
Press . Your radio turns on.
Note
You can press (SNOOZER/DIMMER) a total of six
times. If you press it a seventh time, the alarm turns off.
Notes
When you turn off your radio, it goes into standby mode.
12
SNOOZE / DIMMER
SNOOZE / DIMMER
SNOOZE / DIMMER
11
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Press or to manually select a radio frequency.
OR
Press and hold or to automatically tune to the next lower or
higher radio station.
Press or to increase or decrease the volume. While you are
adjusting the volume, the “Volume” icon lights and the current volume
level number appears in the middle of the LCD.
To turn off your radio, press and hold for two seconds.
appears on the LCD for three seconds, then your radio turns off.
Programming a radio station preset
A radio station preset lets you assign a preset number to a radio station to
make it easier to tune to a station. You can program 10 presets.
To program a radio station preset:
Tune to the radio station you want to program, then press and hold
for two seconds. The “Preset” icon lights and the next
available preset number (P-01 through P-10) appears in the middle of
the LCD. When you exit programming mode, these indicators
disappear.
If you want to use a different preset number, press or repeatedly
until the number you want appears on the LCD.
Within 10 seconds, press again to save your station preset.
If you do not press within 10 seconds, your radio exits
preset mode and your station preset is not saved.
Tuning to a preset radio station
After you program radio station presets, you can quickly tune to a preset
station.
To tune to a preset radio station:
• Quickly press and release one or more times until the
“Preset” and preset number (P-01 through P-10) for the station you
want appears on the LCD. Your radio tunes to the station.
Adjusting the LCD brightness
When you adjust the LCD brightness, your radio retains the setting and
uses this setting the next time you turn on your radio.
To adjust the LCD brightness:
Quickly press (SNOOZER/DIMMER) repeatedly to select a
brightness level. You can select , , or .
SNOOZE / DIMMER
12
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Wait a few seconds to save your setting and exit brightness mode.
Playing audio from a Bluetooth device
You can pair your radio with a Bluetooth device to play the Bluetooth
audio through your radio’s speakers.
To pair your radio with a Bluetooth device:
Press to turn on your radio, then press
repeatedly until appears on the LCD.
Make sure that your Bluetooth device is turned on and within 33 feet
(10 meters) of your radio.
On the Bluetooth device, enter pairing mode. See the instructions that
came with your Bluetooth device for information about how to enter
pairing mode.
On your radio, press and hold for six seconds. Your
radio enters pairing mode. Your radio remains in pairing mode for five
minutes or until your radio pairs with the Bluetooth device.
• If your Bluetooth device is not turned on or is too far away from
your radio, the icon on the LCD blinks every two seconds.
• While your radio is pairing with your Bluetooth device, the icon
on the LCD blinks twice a second.
• When pairing is complete, the icon on the LCD lights solid.
On the Bluetooth device, select or .
See the instructions that came with your Bluetooth device for
information about how to select a device for pairing.
To play from a paired Bluetooth device:
Press to turn on your radio, then press
repeatedly until appears on the LCD.
To control playback:
• Press or to increase or decrease the volume. While you are
adjusting the volume, the “Volume” icon lights and the current
volume level number appears in the middle of the LCD.
• Press or to go to the previous or next song.
Notes
• Your Bluetooth device must be within 33 feet
(10 meters) of your radio.
• If you turn off your Bluetooth device or move it too far
from the radio, the pairing connection is lost. When you
move the last connected device within your radio's
range, the pairing connection is restored.
• Your radio can store pairing information for eight
devices.
13
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
• Press and hold or to fast reverse or fast forward through the
songs on the Bluetooth device.
• Press to start or pause playback.
To disconnect from a paired device:
• Press Source to change to a different audio source, such as FM.
• Press and hold Source to turn off your radio.
• Unplug the AC/DC power adapter.
• Turn off the Bluetooth function on the connected device.
• Move the Bluetooth device more than 33 feet (10 meters) from your
radio.
Connecting an audio device
You can connect an audio device, such as an MP3 player, to your radio to
play music through your radio’s speakers.
To connect an audio device:
Plug an audio cable with a 3.5 mm connector (not included) into the
jack on the back of your radio and into the audio out jack on
your audio device.
Press to turn on your radio, then press
repeatedly until appears on the LCD.
Press or to increase or decrease the volume. While you are
adjusting the volume, the “Volume” icon lights and the current volume
level number appears in the middle of the LCD.
Use the controls on the audio device to control playback.
Charging a device’s battery
You can use the USB port on your radio to charge a connected device’s
battery.
To charge a device’s battery:
• Connect a USB cable (not provided) to the USB port on your radio and
to the USB port on the device.
14
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Troubleshooting
Problem Possible cause Possible solution
My Bluetooth device will not pair
with my radio.
Bluetooth is not selected as the audio
source on your radio.
Press
press
Source repeatedly until
Bluetooth appears on the LCD.
Your radio is not in pairing mode. Press and hold Pair/Preset for six
seconds.
Your Bluetooth device is too far away
from your radio.
Make sure that your Bluetooth device is within
33 feet (10 meters) of your radio.
Your Bluetooth device is not in
pairing mode.
Make sure that your Bluetooth device is in
pairing mode. See the instructions that came
with your device.
The battery level on your Bluetooth
device may be too low.
Charge the battery on your Bluetooth device,
then try pairing again.
Another paired Bluetooth device is
too close to your raido.
Another paired Bluetooth device that is too
close to your radio (such as a cell phone paired
to a headset) can interfer with pairing. Move
the other paired device away from your radio or
turn off the other paired device.
Your Bluetooth device may not use a
supported Bluetooth protocol.
Your radio supports the A2DP and AVRCP
Bluetooth protocols. Check the documentation
that came with your device to determine if it
uses a supported protocol.
My radio is in pairing mode, but
does not pair with my Bluetooth
device.
Your Bluetooth device may not be
turned on.
Make sure that your Bluetooth device is turned
on.
You have not selected your radio on
the Bluetooth device.
Make sure that your Bluetooth device is in
pairing mode, then select NS-CLBT01-B or
NS-CLBT01-W on your Bluetooth device. See
the instructions that came your the Bluetooth
device.
Your Bluetooth device is too far away
from your radio.
Make sure that your Bluetooth device is within
33 feet (10 meters) of your radio.
Sound from my Bluetooth device
is distorted or broken up.
The volume level is set too high. Lower the volume on your radio or Bluetooth
device.
Your Bluetooth device is too far away
from your radio.
Make sure that your Bluetooth device is within
33 feet (10 meters) of your radio.
There may be something between
your radio and Bluetooth device that
is interfering.
Walls, furniture, and other objects can interfer
with the communication between your radio
and Bluetooth device. Make sure that nothing is
between your radio and Bluetooth device.
15
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Specifications
Total RMS power 2.4 W (1.2 W × 2) @1kHz, @ 10% THD
Total peak power 4.8 W
Signal-to-noise ratio ≥ 65dB
Frequency response 300Hz - 20kHz
Supported Bluetooth
protocols
A2DP
AVRCP
Speakers 2 × 40 mm
Batteries 2 AAA
Dimensions (W × D × H) 9.8 × 2.1 × 2.1 in. (250 × 54 × 54 mm)
Weight 1.1 lbs. (0.5 kg)
16
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
Legal notices
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measure:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
RSS-Gen & RSS-210 Statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil
ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement."
"This equipment complies with Industry Canada radiation exposure limits set forth for an
uncontrolled environment. Cet équipement est conforme à l'exposition aux rayonnements
Industry Canada limites établies pour un environnement non contrôlé."
CAN ICES-3 (B)/NMB-3(B)
17
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
90-day limited warranty - Insignia
Definitions:
Insignia Products (“Insignia”) warrants to you, the original purchaser of this new
Insignia-branded product (“Product”), that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of ninety (90) days from the date
of your purchase of the Product (“Warranty Period”). For this warranty to apply, your Product
must be purchased in the United States or Canada from a Best Buy or Future Shop
authorized dealer of Insignia brand products only that are packaged with this warranty
statement.
How long does the coverage last?
The Warranty Period lasts for ninety (90) days from the date you purchased the Product. Your
purchase date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of
the Product is determined to be defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or
(2) replace the Product at no charge with new or rebuilt comparable products or parts.
Products and parts replaced under this warranty become the property of Insignia and are
not returned to you. If service of Products or parts are required after the Warranty Period
expires, you must pay all labor and parts charges. This warranty lasts as long as you own your
Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail store location, please take
your original receipt and the Product to any Best Buy or Future Shop store. Make sure that
you place the Product in its original packaging or packaging that provides the same amount
of protection as the original packaging. If you purchased the Product from a Best Buy or
Future Shop online web site, mail your original receipt and the Product to the address listed
on the web site. Make sure that you put the Product in its original packaging or packaging
that provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY, Canada call
1-866-BESTBUY for Future Shop call 1-800-663-2275. Call agents may diagnose and correct
the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy or Future Shop
branded retail stores or websites to the original purchaser of the product in the county
where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
• Set up adjustments
• Cosmetic damage
• Damage due to acts of God, such as power surges
• Accident(s)
• Misuse
18
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
• Abuse
• Negligence
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods
(burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Up to three (3) pixel failures (dots that are dark or incorrectly illuminated) grouped in an
area smaller than one tenth (1/10) of the display size or up to five (5) pixel failures
throughout the display. (Pixel based displays may contain a limited number of pixels
that may not function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or
pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY
FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER
EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED
WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY
PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645
© 2013 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some
countries. All other products and brand names are trademarks of their respective owners.
19
NS-CLBT01-B/NS-CLBT01-W Digital Clock Radio with Bluetooth
www.insigniaproducts.com
INSIGNIA is a registered trademark of BBY Solutions, Inc.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC, 7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2013 BBY Solutions, Inc.
All Rights Reserved
1-877-467-4289
www.insigniaproducts.com
V2 ENGLISH
13-0221
