Compupal Group OMS100BT 2.0 Bluetooth Speaker User Manual

Compupal Group Corporation 2.0 Bluetooth Speaker Users Manual

Users Manual

Shockproof and Waterproof Bluetooth Wireless Speaker
Shockproof and Waterproof Bluetooth Wireless Speaker
Haut-Parleur Sans Fil Bluetooth Étanche à L'eau Et Résistant Aux Chocs
Altavoz Bluetooth Inalámbrico, Resistente Al Agua y a Los Golpes
Kabelloser Bluetooth-Lautsprecher, Stoßfest und Wasserdicht
Altoparlante Bluetooth Wireless Antiurto e Impermeabile
耐衝撃耐水 Bluetooth ワイヤススーカー
防震防无线牙扬声器
B01GF4YAWI
Welcome Guide · English
Part Qty
Waterproof BT speaker
1
Charging cable
1
Hang tag
1
Portable Bluetooth Speaker
Contents:
Before getting started, ensure the package contains the following components:
2
1. Plug small end of the USB charging cable into micro USB jack under the rubber USB cover.
2. Plug the other end of the USB charging cable into an available USB port on your computer or a USB power adaptor on wall.
3. Red LED is on in the front of the speaker during charging. When full charged, the LED will go off.
Note: When battery is low, the speaker will have a warning tone.
1. Short press the power button on the speaker. Blue LED is flashes slowly in the front of the speaker.
2. Navigate to your devices Bluetooth settings, turn on Bluetooth, and then search for available devices.
3. Select Paring Name from a list of available devices on your Bluetooth device. The Blue LED turns solid when your device is
paired.
4. Choose the music on your device to play through the speaker.
5. Adjust speaker volume through the + and the buttons on top of the speaker.
6. To disconnect from the paired Bluetooth device, turn off Bluetooth on your device.
Note:
1) The maximum Bluetooth range is 33 feet.
2) Make sure the volume level on your Bluetooth device is at least 50%.
3) When speaker is turned on, it will try to connect the last paired Bluetooth device automatically within 20s. If the last paired
Bluetooth device is out of range, it will automatically search for another device for pairing.
When paired to your mobile phone:
1. With a coming call, short press the button to answer it.
2. Press the + or the button to increase or decrease the speakerphone volume.
3. Short press the button again to end the phone call.
4. Long press the button to reject the incoming call.
5. For Android users: make sure that the Phone Audio function is active in the Bluetooth settings.
Operation Instructions
Step 1:
Charging the speaker
Step 2:
Play music through Bluetooth
Step 3:
Using the Speakerphone
1. Short press the power button on the top of the speaker to turn on the speaker.
2. Plug one end of a 3.5mm stereo cable (not included) into AUX jack on back of the speaker, the AUX have the first priority will
automatically change to AUX mode from Bluetooth mode.
3. Plug the other end of the stereo cable into your music player such as MP3, PC, CD player, mobile phones etc.
4. Adjust speaker volume through the + and the buttons on top of the speaker.
# Component Description
1 Volume down
Short press to decrease the volume and long press to go to previous song.
2 Power &
Multi-function
1. Short press the power button to turn on the speaker and the blue LED flashes quickly
with a warning tone.
2. Long press(3s) the power button to disconnect current connection with a warning tone
and enter to pairing state again;
3. Long press(5s) the power button to turn off the speaker and the blue LED off with a
warning tone.
1. Short press the button to answer the phone call.
2. To end a call, short press the button again.
3. To reject a call, long press the button.
NOTE: For Android users: make sure that the Phone Audio function is active in the
Bluetooth settings.
3 Volume up Short press to increase the volume and long press to go to next song.
4 AUX IN jack Connect an external source, such as an MP3 player.
5 Reset Short press to automatically reboot system.
6 USB jack Plug the small end of the charging cable into this jack to charge the speaker.
7
LED Bluetooth is not connected: Blue LED flashes quickly;
Successful Bluetooth connection: Solid blue LED.
AUX signal mode: Solid blue LED.
Speaker turned off: LED off.
Step 4:
Play music through AUX
Warranty Information
To obtain a copy of the warranty for this
product:
Visit amazon.com/AmazonBasics/Warranty
Contact Customer Service at 1
-
866
-
216
-
1072
-
o
r
-
