Condoplex Monitoring Systems UMWWS water sensor User Manual CondoplexUM WWSwatersensormanual 20141205 2
Condoplex Monitoring Systems Inc water sensor CondoplexUM WWSwatersensormanual 20141205 2
Users Manual
UM-WWS
Water Sensor
Identifying the Parts:
1. Antenna
2. Learn I Test Button
3. Probe (Water Detection)
4. Battery Lid
5. Buzzer
Accessories:
1 Probe cable
1 Set of mounting screws
1 Battery
Getting Started
• Remove battery lid by sliding it in the direction of the
arrow on the bottom of the water sensor.
• Pull battery clip out and connect to battery then re-insert
into the water sensor.
Page 1
1 2
3
4
5
Detailed Programming and Setup Instructions:
• Place the Receiving Device into Learning Mode (see
instruction for your particular receiving device).
• Then press the Red Button on the Water Sensor being
learned. The Receiving Device will provide an
audible and/or visual indication of code acceptance.
• While the Receiving Device is still in Learning Mode,
repeat the above with each Water Sensor to be
programmed.
• Positioning the Water Sensor in place on a level
surface or wall Mount using the provided screws.
• Use Probe Extender to (1) monitor hard-to-reach
places.
• (2) Water Sensor must be placed high-up off the floor,
or (3) when a pad is required to cover a larger radius
space.
• To activate the extender, insert Probe Extender plug
into the socket on the Water Sensor's and mount using
the screws provided
Normal Operation:
.
. When the probe touches water, the sensor will sound an alarm
and send a signal to a receiving device. Sensor will continue
alert until the probe is dry. Sensor can be reset or alarm
silenced by pressing the Red Button.
Page 2
Regulatory Notices
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna,
- Increase the separation between the equipment and receiver,
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's
authority to operate this equipment.
This device complies with part 15 of the FCC Rules and with
Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the
device
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts delicence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire debrouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
Page 3
Limited Warranty
Condoplex warrants it’s products for a period of two years from the
date of purchase, this product will be free from defects in material
and workmanship. Condoplex at its option will repair or replace this
product or any component of the product found to be defective
during the warranty period. Replacement will be made with a new
or remanufactured product or component. If the product is no longer
available. replacement may be made with a similar product. This is
your exclusive, nontransferable warranty. Keep the original sales
receipt. Proof of purchase is required to obtain warranty
performance. Condoplex service centers, or retail stores selling this
products do not have the right to alter, modify or in any way change
the terms and condition of this warranty. This warranty does not
cover normal wear of parts or damage resu1ting from any of the
following: negligent use or misuse of the product, use of improper
voltage or current. use: contrary to the operating instructions,
disassembly, repair or alteration by anyone other than Condoplex or
an authorized service center. Further, the warranty does not cover
Acts of God, such as fire, flood, hurricanes and tornadoes or any
batteries that are used in this unit. It is your responsibility to
regularly test the function ability of the product to ensure proper
operation. Condoplex shall not be liable to any party for any
damages that results from the failure of this product. Condoplex
shaI1 not be liable for any incidental or consequential damages
caused by the breach of any express or implied warranty. Except to
the extent prohibited by applicable law, any implied warranty or
merchantability or fitness for a particular purpose is limited in
duration to the duration of the above warranty. Some states,
province or jurisdiction do not allow the exclusion or limitation of
incidental or consequential damages or limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you. This warranty gives you specific legal rights, and
you may also have other rights that vary from state to state or
province to province.
Page 4
