ConnecteDevice BTG2 Bluetooth Headset User Manual
ConnecteDevice Limited Bluetooth Headset
Users Manual
PAGE 1 / 7
BlueTrek G2 user guide
(page 1)
IMPORTANT
Before using your Bluetrek® G2 headset for the first time, you must charge it
continuously for about 2 hours, until the blue indicator light turns on. Please
refer to the “Charging Bluetrek® G2” section of this manual.
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
Caution: Changes or modifications to this Bluetooth® headset not expressly
approved by the Manufacturer could void the user’s authority to operate the
equipment.
Industry Canada notice to users and product statements
To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment
(or its transmit antenna) that is installed outdoors is subject to licensing.
Compliance to Industry Canada, technical specifications have been made in a
declaration of conformity. It does not imply that Industry Canada approved the
equipment.
(page 2)
(product picture)
(page 3)
1. Introduction
The Bluetrek G2 headset is a wireless headset based on the Bluetooth ® technology.
The Bluetooth ® technology is a standard for wireless short distance radio
communications. Devices like a headset and a mobile phone can communicate with
each other without wires within approximately 10 meters.
PAGE 2 / 7
Bluetrek® G2 is a qualified Bluetooth ® headset that complies with the Bluetooth ®
1.1 protocol. It supports two profiles: Headset Profiles and Hands-free profile.
It will work with any qualified Bluetooth® device that supports the Headset profile or
the Hands-free profile.
To check the list of qualified Bluetooth® mobile phones working with Bluetrek® G2,
please consult: www.bluetrek.com
Bluetrek® G2 headset can be used with:
- a qualified Bluetooth® mobile phone (*);
- A non-Bluetooth® mobile phone (*) connected to the Bluetooth® adaptor BT07
(optional);
(*) or another Bluetooth device supporting the Headset or Hands-free profile. This
user guide is focusing on the use of this Bluetooth® headset with a Bluetooth®
mobile phone, which is the most common application.
Your Bluetrek® G2 will allow you to take a call, initiate a call (if your phone has voice
controls), and adjust volume directly on your headset, without the need to touch your
mobile phone.
The Bluetrek® G2 headset has 5 buttons:
• “TALK “Button (central button),
• 2 “VOL+ “buttons,
• 2 “VOL- “buttons.
Please refer to the picture on page 2.
Before using Bluetrek® G2 headset, you must:
. Charge the headset; please refer to the “Charging Bluetrek® G2” section of this
user guide.
. Pair the headset with a mobile phone. Please refer to the “Pairing Bluetrek® G2”
section of this manual.
1. Charging Bluetrek® G2
Your headset is delivered uncharged. So before the first use, you must fully recharge
it for about 2 hours with the supplied charger, until the blue indicator light turns on.
The use of any other charger will automatically suspend the warranty. During
subsequent charges, the charging should take approximately 1 hour 45 minutes.
Please connect the charger to the headset and to the mains. During the charge, the
indicator light is either red if your headset battery was excessively discharged, or
purple during a normal charge. The indicator light will turn to blue when the charge is
complete.
When you hear a light beep in your headset at regular intervals, and the indicator
light flashes in red, your headset needs to be recharged.
PAGE 3 / 7
To maximize battery lifetime, it is recommended to recharge your headset to full
capacity only when the battery is low, since a battery has a lifetime of about 500
charging cycles.
If you leave your headset battery empty for an extended period of time, it could
excessively discharge the battery. In this case, you may have to charge your headset
for 10 hours or more until the battery recovers and recharges completely. The
indicator light will be red at the beginning of the charge to recover the battery
capacity, then it will turn to purple for the normal charging process.
Only switch on the headset once the blue indicator light turns on, indicating the
battery has fully recovered.
Do not let the battery charger plugged in the headset for more than 24h.
2. Pairing Bluetrek® G2
Before using the Bluetrek® G2 headset, you must pair it with your Bluetooth® mobile
phone. Pairing is the process of linking 2 Bluetooth® devices, so that they can
communicate.
The pairing only needs to be done once. Afterwards, every time you switch on your
headset, it will automatically connect to your mobile phone. If you pair your
Bluetooth® mobile phone with another Bluetooth® device, you will have to pair the
Bluetrek® G2 with your phone again before use.
The profile (Headset or Hands-Free) is automatically selected by the Mobile phone
during the Pairing stage.
IMPORTANT : Before pairing, all Bluetooth® devices must be switched off.
To initiate the pairing, put both the headset and the mobile phone within 0.3 meter (1
foot) from each other. Make sure there is no Wi-Fi equipment operating in the vicinity.
1. Switch on your phone and select the Bluetooth® discover mode on the Mobile
phone (See the Bluetooth® mobile phone user guide).
2. Press and hold (do not release it) the TALK button (see button 1 on page 2) for
about 7 seconds until the indicator light flashes red and blue alternatively. Then
release the TALK Button. A beep can be heard in the speaker.
3.Once the mobile phone detects the headset, a message is displayed with the
following information : “Bluetrek g2”.
4. Follow the phone instructions to accept the pairing. The PIN code (or passkey)
is 0000.
5. When the pairing is completed, the indicator light will switch to blue, and
flashes slowly.
If you haven’t started the discovery mode within 5 minutes, the headset will switch
off. You must then switch on your headset and start the pairing again.
PAGE 4 / 7
A very limited number of Bluetooth mobile phones require a different pairing
process that the one explained above. If your pairing process does not work, visit
our website www.bluetrek.com or consult your dealer.
3. Wearing Bluetrek® G2
The headset can be used on both ears. Rotate the ear clamp if you want to use it on
the other ear. Make sure the speaker is properly inserted into your ear.
4. Switching Bluetrek® G2 ON and OFF
Switching Bluetrek® G2 ON
Press and hold the TALK button for about 2 seconds until the blue indicator light is
on. A beep (2 tones) can be heard in the speaker. Release the TALK Button.
If Bluetrek G2 is paired in the Hands Free profile, it will try to connect automatically to
the paired Audio Gateway (e.g. mobile phone).
If Bluetrek G2 is paired in the Headset profile, it will stay in standby mode.
Switching Bluetrek® G2 OFF
Press and hold the TALK button for about 5 seconds until the red indicator light is on.
A beep (2 tones) can be heard in the speaker. Release the TALK Button.
5. Making a call
The voice recognition (or voice dialling) feature is not available on all mobile phones.
However you can always dial directly on your keypad. If your mobile phone offers the
voice recognition feature, you can make a call directly from the headset without any
operation on you mobile phone.
Mobile phone with voice recognition
. Make sure the voice recognition function on your mobile is activated and your voice
tags have been recorded with the phone.
. Press the TALK button shortly (when there is no incoming and no active Call). The
audio connection is established.
. Wait for the audio signal sent by the mobile phone (generally a short tone).
. Speak out the name of person you wish to call, as stored in the phone voice tags.
The mobile phone will dial the stored number.
Mobile without voice recognition
. Make sure both the headset and the mobile phone are ON and in stand-by mode.
. Dial the phone number you wish to call on your mobile phone.
. After roughly 2 seconds, the audio connection is established.
PAGE 5 / 7
6. Answering a call
When the headset rings, press the TALK button shortly.
7. Rejecting a call
Press the TALK button for about 2 seconds when the headset is ringing.
This function only works in the Hands-Free Profile.
8. Ending a call
Press the TALK button shortly to end an active call.
9. Redial Last Number
Press the TALK button for about 2 seconds if there is no active call and no incoming
call, until you hear a beep.
This function only works in the Hands-Free Profile.
10. Adjusting the volume
The headset has been designed with 2 VOL+ buttons, and 2 VOL- buttons, so that it
is perfectly ergonomic and symmetrical, whether you use it on your left or right ear.
But only 1 VOL+ button is functional to adjust the volume up, and only 1 VOL- is
functional to adjust the volume down.
So to increase the volume during an active call, make sure you press shortly and
gently on both VOL+ buttons simultaneously.
And to decrease the volume during an active call, make sure you press shortly and
gently on both VOL- buttons simultaneously.
11. Muting the microphone
To mute the microphone during an active call
Press on both VOL+ buttons, or on both VOL- buttons, simultaneously for about 2
seconds.
A periodic tone is heard in the speaker while the microphone is muted.
To end the mute function
When the microphone is muted, a short press on both VOL+ buttons, or on both
VOL-, simultaneously will end the mute function and the periodic tone will disappear.
12. Transferring a call to the mobile phone
During an active call, press the TALK button for about 2 seconds.
This function only works in the Hands-Free Profile.
PAGE 6 / 7
In the Headset profile, you can simply turn off your headset.
13. Transferring a call to Bluetrek® G2
During an active call on the mobile phone, press the TALK button shortly on the
headset to transfer the call from the mobile phone to the headset.
14. Multi Pairing
BlueTrek G2 can be paired to two Mobile Phones (Audio Gateways).
In the following description, the last paired Audio Gateway will be called Primary
Phone, and the previously paired phone will be called Secondary Phone.
For instance :
Your headset is already paired with a NOKIA 3650 mobile phone.
You perform a pairing with a SONY ERICSSON T68i phone :
- your T68i phone will be the Primary Phone,
- your NOKIA 3650 phone will be the Secondary Phone.
You Perform a second Pairing with an ERICSSON T39:
- your T39 phone will be the Primary Phone,
- your T68i phone will be the Secondary Phone.
All Outgoing Calls from Bluetrek® G2 are sent only to the Primary Phone.
However, an incoming Call on any phone (primary or secondary) will be sent to your
BlueTrek® G2 headset, and it can be answered on the headset (if BlueTrek G2 has
no link established with the other phone which is not receiving the latest incoming
call).
The multi-pairing works best with headsets which are in the headset profile.
(Note: all brand names are the property of their respective owners).
15. Troubleshooting guide
(same as old Bluetrek user guide, but add following text)
An automatic reset is done each time the headset is either charged or switched off.
So in case of problem or if your headset cannot switch off, please charge your
headset for at least 30 seconds.
16. Guidelines for safe use
Read those guidelines before using your Headset.
PAGE 7 / 7
- Do not drop or try to alter the shape of your Headset.
- Do not expose your Headset to liquid or moisture.
- Do not expose your Headset to extreme temperatures (temperature range 0-40C)
- Do not expose your Headset to fire or open flames.
- Do not try to disassemble your Headset. Service and Maintenance can only be
performed by authorized Bluetrek dealers.
- CAUTION : Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type. (voltage range : 3.1-5.5V)
- Keep your Headset away from dust and dirt.
- Do not let children play with your Headset, since it contains small parts that could
become detached and create a choking hazard.
- Check the regulation in you area if you plan to use your Headset while driving.
