Continental Automotive Systems, Inc. PASS Tranceiver PASS FCC ation rev Bx

Exhibit D Users Manual per 2 1033 b3

_
Continental Confidential and Proprietary
USERS MANUAL
The PASS module is not a consumer electronics product designed to interface to
a “end user”, instead this module will exclusively be connected to a vehicles head
unit, in that context, the main step to establish a connection are as follows.l
1. The PASS module established a connection to a live mobile network
2. The vehicle starts then the head units starts establishing a connection to the
PASS module via WiFi or Bluetooth
3. After steps 1 and 2 have been completed successfully, data can be transferred
between the life network and the vehicle’s head unit.
4. There is no human interaction in the steps and the connection cannot be broken
or altered
5. Connection and data transfer is fully software driven. The PASS module and the
head unit will have the appropriate software that allows for communication
