Continental Automotive Technologies 5WK49308 Transmitter User Manual Manual
Continental Automotive GmbH Transmitter Manual
Manual
Annex No.5
Page 1 of 7
Functional Description
Key: 5WK4 9308
Siemens AG
Siemens VDO Automotive SV I IC PE RF Design
IC: 267T-5WK49308 FCC ID:KR55WK49308
I:\POSTZULA\Honda\Tx\Technische_Doku_doc\Func_Description_Honda-Tx-Transmitter_v1.doc Page 1 of 6
User Manual
of the
Siemens VDO
Radio Frequency Transmitter
Type
5wk4 9308
5wk4 9309
5wk4 9348
5wk4 9349
5wk4 9542
Siemens AG
Siemens VDO Automotive SV I IC PE RF Design
IC: 267T-5WK49308 FCC ID:KR55WK49308
I:\POSTZULA\Honda\Tx\Technische_Doku_doc\Func_Description_Honda-Tx-Transmitter_v1.doc Page 2 of 6
1. GENERAL DESCRIPTION OF THE RF TRANSMITTER
The RF remote control system consists of a RF transmitter and a RF receiver
mounted within the control unit. The RF transmitter is mechanically integrated
in the head of the key. This transmitter is used to transmit information for
locking or unlocking the vehicle by a unidirectional RF transmission line for
normal remote operation by pressing a button.
In general the following functions are provided:
- Lock the car
- Unlock the car
- Unlock the trunk of the car
- Panic Alarm
Immobilizer Transponder
When the key is operating as an immobilizer transponder, communication is
done over a "contact less interface" depending on strong magnetic coupling.
The transponder is the passive side of the link and there is no RF
transmission from it involved in any aspect.
SW1
SW2
SW4
SW3
Siemens AG
Siemens VDO Automotive SV I IC PE RF Design
IC: 267T-5WK49308 FCC ID:KR55WK49308
I:\POSTZULA\Honda\Tx\Technische_Doku_doc\Func_Description_Honda-Tx-Transmitter_v1.doc Page 3 of 6
2. POWER SUPPLY
The transmitter is provided with 1 lithium battery (CR1616) that gives a
power supply of +3V.
3. TYPICAL USAGE PATTERN (FOR EUROPE ONLY)
20 lock/unlock operations in 24 hours with complete transmission duration
of 10.0 seconds (500ms/operation)
2 power window up/down operations in 24 hours with transmission duration
of 10 seconds ( 5.0 seconds for 1 operation; max. value)
→ total transmission duration of 20 seconds within 24 hours
Transmitter ON 0.83 seconds / hour
Transmitter OFF 3599.17 seconds / hour
Duty Cycle: TON / T (ON+OFF) x 100% = 0.83/ 3600 x 100 % = 0.023 %
Siemens
MLFB 5wk49308 5wk49309 5wk49348 5wk49349 5wk49542
Frequency
variant 313,85 MHz
(USA) 434.92 MHz
(EU) 313.85 MHz
(USA)
313.85 MHz
Low Power
(Japan)
434.92 MHz
(EU)
Number of
buttons 4 buttons 3 buttons 3 buttons 3 buttons
4 buttons
SW 1 Look Look Look Look Look
SW 2 Unlock Unlock Unlock Unlock Unlock
SW 3 Trunk Trunk Trunk Trunk Trunk
SW 4 Panic Panic
Siemens AG
Siemens VDO Automotive SV I IC PE RF Design
IC: 267T-5WK49308 FCC ID:KR55WK49308
I:\POSTZULA\Honda\Tx\Technische_Doku_doc\Func_Description_Honda-Tx-Transmitter_v1.doc Page 5 of 6
5. TECHNICAL DATA
Tx Electrical characteristics
Tx Europe (433.92MHz) variants:
Variants Siemens MLFB
Europe 3-button Lock-Unlock-Trunk 5wk4 9309
Europe 4-button Lock-Unlock-Trunk-Panic 5wk4 9542
Center frequency 433.92MHz
Frequency shift +/-30kHz
RF-Power (EIRP) < 10 mW
Tx US (313.85 MHz) variants:
Variants Siemens MLFB
US 3-button Lock-Unlock-Trunk 5wk4 9348
US 4-button Lock-Unlock-Trunk-Panic 5wk4 9308
Center frequency 313.85 MHz
Frequency shift +/-30kHz
RF-Power (EIRP) < 75.6 dBµV/m
Tx Japan (313.85 MHz Low Power) variant:
Variants Siemens MLFB
Japan 3-button Lock-Unlock-Trunk 5wk4 9349
Center frequency 313.85 MHz
Frequency shift +/-30kHz
RF-Power (EIRP) < 54 dBµV/m
NOTE:
Changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment.
Parameter Unit Min. Typ. Max.
Supply voltage V 2.5 3 3.3
Battery lifetime (10 actuations per day)
[/years] a 4
Siemens AG
Siemens VDO Automotive SV I IC PE RF Design
IC: 267T-5WK49308 FCC ID:KR55WK49308
I:\POSTZULA\Honda\Tx\Technische_Doku_doc\Func_Description_Honda-Tx-Transmitter_v1.doc Page 6 of 6
6.1 LABEL DESIGN Europe (433.92 MHz)
Siemens VDO
5WK4 9542
6.2 LABEL DESIGN CANADA, MEXICO, USA (314,85 MHz)
Siemens VDO
5WK4 9308
IC: 267T-5WK49308
FCC ID:KR55WK49308
Entry Owners Manual, Canada, USA:
NOTE
This device complies with part 15 of the FCC Rules and RSS-210.
Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept interference
received, including interference that may cause undesired operation.
CAUTION
Changes or modifications not expressly approved by the manufacturer
could avoid the user's authority to operate the equipment.
