Functional Description
User Manual
of the
Continental
Radio Frequency Transmitter
Model:
IK4CH-01 and IK4PL-01 (433.92 MHz)
IK3CH-01 (315 MHz)
(Key Fob)
Continental Automotive France SAS
Interior Division- Body & Security
-2- Apr. 11, 2017
Functional description of the IK4CH-01, IK4PL-01, IK3CH-01
key
1 General Product Information
This document gives an overview of the different device operation modes and the RF transmissions
performance of the key model IK4CH-01, IK4PL-01, IK3CH-01. In this document the device is
referenced as "key", even if the mechanical backup key might be separated from it.
1.1 Trade mark
Continental
1.2 Brand
Continental
Continental Automotive France SAS
Interior Division- Body & Security
-6- Apr. 11, 2017
4 Button functions
The validation of the accurate frequency deviation and the measurement of the transmission function
of the key are implemented based on RF test software. The graphic below shows the functionality of
the buttons.
First
Button
press
Second
Button
press
Third
Button
press
Fourth Button
press
Fifth button
press
CW Flow
CW Fup
Continuous
RF data
frame
CW Fup
Stop RF emission
Button
Lock
Continental Automotive France SAS
Interior Division- Body & Security
-7- Apr.11, 2017
5 Key fobs Variants
Product reference
Product variant
Drawing
IK4PL-01
A2C398083
marking : 04
EdG 433.92MHz
Lock/Unlock/Light/Trunk
433.92 MHz
IK4CH-01
A2C398080
marking : 02
HdG 433.92MHz
Lock/Unlock/Light/Trunk
433.92 MHz
Continental Automotive France SAS
Interior Division- Body & Security
-8- Apr., 11, 2017
IK3CH-01
A2C398081
marking : 01
HdG 315MHz
Lock/Unlock/Light/Trunk
315 MHz
IK4CH-01
A2C398084
marking : 06
HdG 433.92MHz
RES
Lock/Unlock/RES/Trunk
433.92 MHz
Continental Automotive France SAS
Interior Division- Body & Security
-9- Apr. 11, 2017
IK4PL-01
A2C398086
marking : 08
EdG 433.92MHz
RES
Lock/Unlock/RES/Trunk
433.92 MHz
