Continental Conair ICT100 Induction Cooker User Manual ICT100
Continental Conair Limited Induction Cooker ICT100
User Manual
ICT100 INDUCTION COOKER
Product features
1. Pollution free：No burning, no smoke and detrimental gases like carbon monoxide and sulfide.
2. Safety: no flame, no exhaust gas.
3. Cleanliness: high rigidity ceramic faceplate, easy to clean.
4. Energy saving: thermal efficiency ≥85%, saves your energy.
5. Micro-computer control function is more convenience.
6. Heating power selection.
7. Automatic cooking stop when pot or pan is removed.
8. Overheat protection.
Safety functions and features
1. High current protection.
2. Auto shut-off. Unit automatically turns off if no buttons are pressed for two hours.
3. When the voltage rises over 140V or drops to less that 90V, the nixie light will display error
codes. Once the voltage return to normal, the unit will automatically operate.
4. Pot detection. Turns off after 1 minute if pot is not compatible.
5. Pot sensor for short/ broken circuit protection.
6. Dry-pot protection. Pot sensor prevents the unit from burning pots without water, which can
cause the pot to overheat. Unit automatically turns off when pot exceeds temperature limit.
7. Built-in surge protection.
8. When the unit is off, the fan may continue running more 1 minute.
Function
1．Operation and working mode
（1） Stand by state：When connect power, the display and the indicated lights don’t work, the
unit is in the stand by state, no power output, the fan is automatic. It doesn’t work if press
other keystroke other than “ON/OFF”.
（2）Working state：When in stand by state, press “ON/OFF”，the LOW LED will on，7 segment
LED show "00"; press “+ or -” to adjust the power，press “∧ or ”∨ to adjust the time, press “ ∧
or ”∨ for 2 seconds, the digit will rise up continuously，press “ON/OFF”, the buzzer will ring, the
unit will return to stand by state. If start the unit without putting the pan or remove the pan in the
middle time, the buzzer will ring to detect the pan, the unit will turn off after 6 seconds.
Using your induction cooker
1. When in the course of the working state, if do not set the time, the display will show “00”, it
doesn’t work when press “ ”∨ at this moment, if press “ ”∧ each time, the digit will rise up by 1.
If press “ ”∧ for 2 seconds, the digit will rise up continuously until reach “99”. If pause pressing
“”∧ in the midway, the digit will stop rising up, and the time when it stop is the setting time.
2. Timer: when in the course of the working state, if set the time, it will work as per the
time. If press “ or ”∧∨ in the midway, the setting time will move down or up. When 1
minute left for the count down time, the display will show second as the count down time. When 3
seconds left for the count down time, it will ring for 3 times, and then continue heating. The
display show “00”.
This device complies with Part 18 of the FCC Rules.
3.When press the keystroke which is efficient, the buzzer will have a
short ring. If turn off the unit or set the time or happen malfunction,
the buzzer will have a long ring.
1.
Other information
error Code (nixie light display) effects
Pot overheat E1 A long beeping sound occurs
IGBT overheat E2 A long beeping sound occurs
Specifications
120V AC
model Rating voltage power rating Power range
ICT100 120V AC/ 60Hz 1400W 200W – 1400W
